Standalone DVR User’s Manual

V1.2.0

Table of Contents

1111 FEATURES AND SPECIFI

FEATURES AND SPECIFICATIONS

FEATURES AND SPECIFIFEATURES AND SPECIFI

1.1

Overview

1.11.1

1.2

1.21.2

1.3333

1.1.

Overview

OverviewOverview

Features

FeaturesFeatures

Specifications

SpecificationsSpecifications

................................................................................................................................... 1

.................................................................................................................................... 1

........................................................................................................................... 2

CATIONS

CATIONSCATIONS

Standalone DVR User’s Manual

....................................................... 1

1.3.1 Smart Box Series ................................................................................................................ 2

1.3.2 960H Smart 1U Series ....................................................................................................... 6

1.3.3 2CIF Smart 1U Series ...................................................................................................... 10

1.3.4 Enhanced 960H Smart 1U/ Enhanced 960H(V2) Smart 1U Series .......................... 14

1.3.5 Enhanced 2CIF Smart 1U/4-ch 960H Smart 1U/ Enhanced 2CIF(V2) Smart 1U

Series 18

1.3.6 General 2CIF Mini 1U Series/ General 960H Mini 1U/ General 2CIF(V2) Mini 1U

Series 23

1.3.7 Enhanced 2CIF Mini 1U / Enhanced 960H Mini 1U/ Enhanced 2CIF(V2) Mini 1U

Series 28

1.3.8 Economic 2CIF Mini 1U Series ....................................................................................... 33

1.3.9 General 960H Mini 1U/ General 960H (V2) Mini 1U Series ....................................... 36

1.3.10 Enhanced 960H Mini 1U Series ................................................................................. 40

1.3.11 2CIF Small Mini 1U Series ......................................................................................... 44

1.3.12 2HDD 2CIF 1U Series ................................................................................................. 48

1.3.13 2HDD 1U Entry-level Series ....................................................................................... 52

1.3.14 2HDD 2CIF 1.5U Series .............................................................................................. 56

1.3.15 2HDD 960H 1.5U Entry-level Series ......................................................................... 61

1.3.16 4HDD 960H 1.5U Entry-level Series ......................................................................... 65

1.3.17 8HDD 960H 2U Entry-level Series ............................................................................ 70

2222 OVERVIEW AND CONTROL

OVERVIEW AND CONTROLSSSS

OVERVIEW AND CONTROLOVERVIEW AND CONTROL

2.1

Front Panel

2.12.1

Front Panel

Front PanelFront Panel

2.1.1 Smart 1U Series ................................................................................................................ 75

2.1.2 Mini 1U Series ................................................................................................................... 76

2.1.3 Small Mini 1U Series ........................................................................................................ 79

2.1.4 1U Series ........................................................................................................................... 79

2.1.5 1.5U Series ........................................................................................................................ 83

............................................................................................................................. 75

............................................................... 75

Standalone DVR User’s Manual

2.1.6 2U Series ........................................................................................................................... 85

2.2

Rear Panel

2.22.2

Rear Panel

Rear PanelRear Panel

2.2.1 Smart Box Series .............................................................................................................. 87

2.2.2 General 2CIF Mini 1U / General 960H Mini 1U Series ............................................... 88

2.2.3 Enhanced 2CIF Mini 1U / Enhanced 960H Mini 1U Series ........................................ 89

2.2.4 General 960H Mini IU Series .......................................................................................... 91

2.2.5 Enhanced 960H Mini 1U Series ..................................................................................... 92

2.2.6 Economic 2CIF Mini 1U Series ....................................................................................... 94

2.2.7 960H Smart 1U /2CIF Smart 1U Series ........................................................................ 95

2.2.8 Enhanced 2CIF Smart 1U /4-ch 960H Smart 1U Series ............................................. 96

2.2.9 Enhanced 960H Smart 1U Series .................................................................................. 97

2.2.10 2CIF Small Mini 1U Series ......................................................................................... 98

2.2.11 2HDD 1U Entry-level Series ....................................................................................... 99

2.2.12 2HDD 2CIF 1.5U Series ............................................................................................ 100

2.2.13 2HDD 960H 1.5U Entry-level Series ....................................................................... 100

2.2.14 4HDD 960H 1.5U Entry-level Series ....................................................................... 101

2.2.15 8HDD 960H 2U Entry-level Series .......................................................................... 102

2.2.16 General 2CIF(V2) Mini 1U /4-ch General 960H (V2) Mini 1U Series ................. 104

2.2.17 Enhanced 2CIF(V2) Smart 1U / 4-ch Enhanced 960H(V2) Smart 1U Series ... 106

2.2.18 8/16-ch Enhanced 2CIF(V2) Mini 1U Series .......................................................... 107

2.2.19 2HDD 2CIF 1U Series ............................................................................................... 109

.............................................................................................................................. 87

2.3

Connection Sample

2.32.3

2.4

2.42.4

2.5

2.52.5

2.6

2.62.6

3333 INSTALLATIO

Connection Sample

Connection SampleConnection Sample

2.3.1 Smart Box Series ............................................................................................................ 110

2.3.2 Smart 1U /Mini 1U Series .............................................................................................. 111

2.3.3 2CIF Small Mini 1U Series ............................................................................................ 112

2.3.4 1U Series ......................................................................................................................... 113

2.3.5 1.5U/2U Series ................................................................................................................ 114

Remote Control

Remote ControlRemote Control

Mouse Control

Mouse ControlMouse Control

Virtual Keyboard & Front Panel

Virtual Keyboard & Front PanelVirtual Keyboard & Front Panel

2.6.1 Virtual Keyboard ............................................................................................................. 119

2.6.2 Front Panel ...................................................................................................................... 119

INSTALLATION AND CONNECTIONS

INSTALLATIOINSTALLATIO

............................................................................................................. 110

.................................................................................................................... 115

...................................................................................................................... 117

......................................................................................... 119

N AND CONNECTIONS

N AND CONNECTIONSN AND CONNECTIONS

................................................ 120

iii

3.1

3.13.1

3.2

3.23.2

3.3

3.33.3

Check Unpacked DVR

Check Unpacked DVRCheck Unpacked DVR

About Front Panel and Real Panel

About Front Panel and Real PanelAbout Front Panel and Real Panel

HDD Installation

HDD InstallationHDD Installation

................................................................................................................... 120

Standalone DVR User’s Manual

........................................................................................................ 120

................................................................................... 120

3.3.1 Smart Box Series ............................................................................................................ 120

3.3.2 Smart 1U Series .............................................................................................................. 121

3.3.3 1U/Mini 1U/Small Mini 1U Series ................................................................................. 122

3.3.4 1.5U series ....................................................................................................................... 123

3.3.5 2U series .......................................................................................................................... 123

3.3.6 Rack Installation .............................................................................................................. 124

3.4

Connecting Power Supply

3.43.4

3.5

3.53.5

3.6

3.63.6

3.7

3.73.7

Connecting Power Supply

Connecting Power SupplyConnecting Power Supply

Conn

Connecting Video Input and Output Devices

ecting Video Input and Output Devices

ConnConn

ecting Video Input and Output Devicesecting Video Input and Output Devices

3.5.1 Connecting Video Input.................................................................................................. 125

3.5.2 Connecting Video Output .............................................................................................. 125

Connecting Audio Input & Output, Bidirectional Audio

Connecting Audio Input & Output, Bidirectional AudioConnecting Audio Input & Output, Bidirectional Audio

3.6.1 Audio Input ....................................................................................................................... 126

3.6.2 Audio Output .................................................................................................................... 126

Alarm Input and Output Connection

Alarm Input and Output ConnectionAlarm Input and Output Connection

.................................................................................................. 125

.................................................................. 125

.................................................. 125

................................................................................. 126

3.7.1 Alarm Input and Output Details .................................................................................... 127

3.7.2 Alarm Input Port .............................................................................................................. 129

3.7.3 Alarm Output Port ........................................................................................................... 129

3.8

RS485

3.83.8

3.9

3.93.9

4444 OVERVIEW OF NAVIGATI

OVERVIEW OF NAVIGATION AND CONTROLS

OVERVIEW OF NAVIGATIOVERVIEW OF NAVIGATI

4.1

4.14.1

4.1.1 Boot up ............................................................................................................................. 131

................................................................................................................................... 130

RS485RS485

Other Interfaces

Other InterfacesOther Interfaces

Boot up an

Boot up and Shutdown

Boot up anBoot up an

d Shutdown

d Shutdownd Shutdown

................................................................................................................... 130

ON AND CONTROLS

ON AND CONTROLSON AND CONTROLS

....................................................................................................... 131

................................ 131

Standalone DVR User’s Manual

4.1.2 Shutdown ......................................................................................................................... 131

4.1.3 Auto Resume after Power Failure ................................................................................ 131

4.1.4 Replace Button Battery .................................................................................................. 131

4.2

Startup Wizard

4.24.2

4.3

4.34.3

Startup Wizard

Startup WizardStartup Wizard

Navigation Bar

Navigation BarNavigation Bar

4.3.1 Main Menu ....................................................................................................................... 135

4.3.2 Output Screen ................................................................................................................. 135

4.3.3 Favorites .......................................................................................................................... 135

4.3.4 Tour ................................................................................................................................... 136

4.3.5 PTZ ................................................................................................................................... 136

4.3.6 Color ................................................................................................................................. 136

4.3.7 Search .............................................................................................................................. 136

4.3.8 Alarm Status .................................................................................................................... 136

4.3.9 Channel Info .................................................................................................................... 136

4.3.10 Remote Device ........................................................................................................... 136

4.3.11 Network ....................................................................................................................... 137

4.3.12 HDD Manager ............................................................................................................. 137

4.3.13 USB Manager ............................................................................................................. 137

..................................................................................................................... 132

..................................................................................................................... 135

4.4

Preview................................................................................................................................. 137

4.4.1 Preview ............................................................................................................................. 137

4.4.2 Preview Control Interface .............................................................................................. 138

4.4.3 Right Click Menu ............................................................................................................. 140

4.4.4 Preview Display Effect Setup ........................................................................................ 140

4.5

PTZ ........................................................................................................................................ 142

4.5.1 PTZ Settings .................................................................................................................... 142

4.5.2 PTZ Control ..................................................................................................................... 144

4.6

Record and Snapshot....................................................................................................... 150

4.6.1 Encode ............................................................................................................................. 150

4.6.2 Schedule .......................................................................................................................... 153

4.6.3 Motion detect record/snapshot ..................................................................................... 158

4.6.4 Alarm Record/Snapshot ................................................................................................. 161

4.6.5 Manual Record/Snapshot .............................................................................................. 163

4.6.6 Holiday Record/Snapshot .............................................................................................. 164

4.6.7 Other Record/Snapshot ................................................................................................. 166

4.7

USB Device Auto Pop

4.74.7

USB Device Auto Pop----up

USB Device Auto PopUSB Device Auto Pop

................................................................................................... 166

upup

4.8

4.84.8

4.9

4.94.9

Main Menu

Main MenuMain Menu

Operation

OperationOperation

Standalone DVR User’s Manual

............................................................................................................................ 167

.............................................................................................................................. 167

4.9.1 Search .............................................................................................................................. 167

4.9.2 Backup.............................................................................................................................. 175

4.9.3 Shut Down ....................................................................................................................... 177

4.10

4.10 Information

4.104.10

4.11

4.11 Sett

4.114.11

5555 WEB OPERATION

Information

InformationInformation

4.10.1 System Info ................................................................................................................. 177

4.10.2 Event ............................................................................................................................ 181

4.10.3 Network ....................................................................................................................... 181

4.10.4 Log ............................................................................................................................... 184

Setting

ing

SettSett

inging

4.11.1 Camera ........................................................................................................................ 185

4.11.2 Network ....................................................................................................................... 196

4.11.3 Event ............................................................................................................................ 214

4.11.4 Storage ........................................................................................................................ 228

4.11.5 System ......................................................................................................................... 238

WEB OPERATION

WEB OPERATIONWEB OPERATION

............................................................................................................................ 177

................................................................................................................................... 185

............................................................................... 259

5.1

Network Connection

5.15.1

5.2

5.25.2

5.3

5.35.3

5.4

5.45.4

5.5

5.55.5

5.6

5.65.6

Network Connection

Network ConnectionNetwork Connection

...................................................................................................................................... 259

LoginLogin

LAN Mode

LAN ModeLAN Mode

Real

Real----time Monitor

RealReal

PTZ

PTZPTZ

Image/Relay

Image/Relay----out

Image/RelayImage/Relay

5.6.1 Image ................................................................................................................................ 264

5.6.2 Relay output .................................................................................................................... 264

............................................................................................................................. 260

time Monitor

time Monitortime Monitor

........................................................................................................................................ 263

............................................................................................................ 259

................................................................................................................ 262

out

.................................................................................................................. 264

outout

5.7

5.75.7

5.8

5.85.8

Standalone DVR User’s Manual

WAN Login

WAN LoginWAN Login

Setup

SetupSetup

........................................................................................................................... 265

..................................................................................................................................... 266

5.8.1 Camera ............................................................................................................................. 266

5.8.2 Network ............................................................................................................................ 273

5.8.3 Event ................................................................................................................................. 289

5.8.4 Storage ............................................................................................................................. 297

5.8.5 System.............................................................................................................................. 301

5.9

Information

5.95.9

5.10

5.10 Playback

5.105.10

5.11

5.11 Alarm

5.115.11

5.12

5.12 Log out

5.125.12

Information

InformationInformation

5.9.1 Version ............................................................................................................................. 314

5.9.2 Log .................................................................................................................................... 314

5.9.3 Connection Log ............................................................................................................... 315

5.9.4 Online User ...................................................................................................................... 316

Playback

PlaybackPlayback

Alarm

AlarmAlarm

Log out

Log outLog out

............................................................................................................................ 314

............................................................................................................................... 316

..................................................................................................................................... 320

.................................................................................................................................. 321

5.13

5.13 Un

5.135.13

6666 PROFESSIONAL SURVEIL

7777 FAQ

APPENDIX A

APPENDIX A HDD CAPACITY CALCULA

APPENDIX AAPPENDIX A

APPENDIX

APPENDIX BBBB COMPATIBLE

APPENDIX APPENDIX

Appendix B

Appendix B----1 Compatible USB list

Appendix BAppendix B

Un----install Web Control

install Web Control

UnUn

install Web Controlinstall Web Control

PROFESSIONAL SURVEILLANCE SYSTEM

PROFESSIONAL SURVEILPROFESSIONAL SURVEIL

FAQ

...................................................................................................... 323

FAQFAQ

HDD CAPACITY CALCULATION

HDD CAPACITY CALCULAHDD CAPACITY CALCULA

COMPATIBLE BACKUP DEVICES

COMPATIBLE COMPATIBLE

1 Compatible USB list

1 Compatible USB list1 Compatible USB list

........................................................................................................ 321

LANCE SYSTEM

LANCE SYSTEMLANCE SYSTEM

BACKUP DEVICES

BACKUP DEVICESBACKUP DEVICES

............................................................................................... 332

...................................... 322

TION

....................................... 330

TIONTION

....................................... 332

vii

Appendix B

Appendix B----2222 Compatible

Appendix BAppendix B

Appendix B

Appendix B----3333 Compatible Portable HDD list

Appendix BAppendix B

Appendix B

Appendix B----4444 Compatible USB DVD List

Appendix BAppendix B

Appendix B

Appendix B----5 Compatible SATA DVD List

Appendix BAppendix B

Appendix B

Appendix B----6666 Compatible SATA HDD List

Appendix BAppendix B

APPENDIX

PENDIX CCCC COMPATIBLE CD/DVD BU

APAP

PENDIX PENDIX

Compatible SD Card list

CompatibleCompatible

Compatible Portable HDD list

Compatible Portable HDD listCompatible Portable HDD list

Compatible USB DVD List

Compatible USB DVD ListCompatible USB DVD List

5 Compatible SATA DVD List

5 Compatible SATA DVD List5 Compatible SATA DVD List

Compatible SATA HDD List

Compatible SATA HDD ListCompatible SATA HDD List

COMPATIBLE CD/DVD BURNER LIST

COMPATIBLE CD/DVD BUCOMPATIBLE CD/DVD BU

SD Card list

SD Card listSD Card list

....................................................................................... 333

................................................................................... 333

.................................................................................. 333

Standalone DVR User’s Manual

.............................................................................. 333

................................................................................. 334

RNER LIST

RNER LISTRNER LIST

............................. 338

APPENDIX

APPENDIX DDDD COMPATIBLE DISPLAYER

APPENDIX APPENDIX

APPENDIX E COMPATIBL

APPENDIX E COMPATIBLE SWITCHER

APPENDIX E COMPATIBLAPPENDIX E COMPATIBL

APPENDIX F

APPENDIX F COMPATIBLE WIRELESS

APPENDIX FAPPENDIX F

APPENDIX G

APPENDIX G CHANNEL SETTINGS INF

APPENDIX GAPPENDIX G

APPENDIX H

APPENDIX H EARTHING

APPENDIX HAPPENDIX H

APPENDIX I TOXIC OR

APPENDIX I TOXIC OR HAZARDOUS MATERIALS

APPENDIX I TOXIC OR APPENDIX I TOXIC OR

COMPATIBLE DISPLAYER LIST

COMPATIBLE DISPLAYERCOMPATIBLE DISPLAYER

E SWITCHER

E SWITCHERE SWITCHER

COMPATIBLE WIRELESS MOUSE LIST

COMPATIBLE WIRELESS COMPATIBLE WIRELESS

CHANNEL SETTINGS INFO OF HYBRID MODE

CHANNEL SETTINGS INFCHANNEL SETTINGS INF

EARTHING

EARTHINGEARTHING

......................................................................... 344

HAZARDOUS MATERIALS OR ELEMENTS

HAZARDOUS MATERIALS HAZARDOUS MATERIALS

LIST

....................................... 339

LISTLIST

................................................... 340

MOUSE LIST

MOUSE LISTMOUSE LIST

O OF HYBRID MODE

O OF HYBRID MODEO OF HYBRID MODE

........................... 341

.............. 342

OR ELEMENTS

OR ELEMENTSOR ELEMENTS

....... 350

Standalone DVR User’s Manual

viii

Welcome

Thank you for purchasing our DVR! This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series standalone DVR features and functions. Before installation and operation please read the following safeguards and warnings

carefully!

Standalone DVR User’s Manual

Important Safeguards and Warnings

．．．．

Electrical safety

All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. We assume no liability or responsibility for all the fires or electric shock caused by

improper handling or installation.

．．．．

Transportation security

Heavy stress, violent vibration or water splash are not allowed during transportation, storage and installation.

．．．．

Installation

Keep upwards. Handle with care. Do not apply power to the DVR before completing installation. Do not place objects on the DVR.

．．．．

Qualified engineers needed

All the examination and repair work should be done by the qualified service engineers. We are not liable for any problems caused by unauthorized modifications or attempted repair.

．．．．

Environment

The DVR should be installed in a cool, dry place away from direct sunlight, inflammable, explosive substances and etc.

6. Accessories

Be sure to use all the accessories recommended by manufacturer. Before installation, please open the package and check all the components are included. Contact your local retailer ASAP if something is broken in your package.

7. Lithium battery Improper battery use may result in fire, explosion, or personal injury! When replace the battery, please make sure you are using the same model!

Standalone DVR User’s Manual

1111 FEATURES AND SPECIFICATIONS

FEATURES AND SPECIFICATIONS

FEATURES AND SPECIFICATIONSFEATURES AND SPECIFICATIONS

1.1

1.1 Overview

Overview

1.11.1

OverviewOverview

The standalone series DVR is an excellent digital monitor product designed for security field.

It adopts embedded Linux OS to maintain reliable operation. It is easy to use and can realize surveillance function after some simple setups. It has various functions such as record, playback, monitor at the same time and can guarantee audio video synchronization. This series product has advanced technology and strong network data transmission function.

This series device adopts embedded design to achieve high safety and reliability. It can work in the local end, and at the same time, when connecting it to the professional surveillance software (PSS), it can connect to the security network to realize strong network and remote monitor function. It can be easily upgraded to HD system while

remain original cable layout. It realizes full local record and playback featuring simple operations. The DVR of the HDCVI port can perfectly work with the HD cameras and realize much longer transmission distance.

This series product can be widely used in various areas such as banking,

telecommunication, electric power, interrogation, transportation, intelligent resident zone, factory, warehouse, resources, and water conservancy.

1.2

1.2 Features

Features

1.21.2

FeaturesFeatures

This series product has the following features:

 Real-time surveillance Support VGA port and HDMI port. Realize the surveillance through displayer. Support HDMI, VGA, and TV output at the same time.

 Storage function Special data format to guarantee data security and can remove the risk of the vicious data modification. Support digital watermark.

 Compression format Support multiple-channel audio and video. An independent hardware decodes the audio and video signal from each channel to maintain video and audio synchronization.

 Backup function Support backup operation via USB port (such as U disk, portable HDD, burner) Client-end user can download the file to local HDD to backup via network.

Standalone DVR User’s Manual

Series

 Record & playback function Support each channel real-time record independently, and at the same time it can support search, forward play, network monitor, record search, download and etc. Support various playback modes: slow play, fast play, backward play and frame by frame play. Support time title overlay so that you can view event accurate occurred time

Support customized zoom function during the preview.

 Network operation Support network remote real-time monitor, remote record search and remote PTZ control.

 Alarm activation function Several relay alarm outputs to realize alarm activation and on-site light control. The alarm input port and output has the protection circuit to guarantee device safety.

 Communication port RS485 port can realize alarm input and PTZ control. RS232 port can connect to keyboard to realize central control, and can also connect to PC COM to upgrade system and realize maintenance, and matrix control. Standard Ethernet port can realize network access function.

 PTZ control Support PTZ decoder via coaxial cable.

 Intelligent operation Mouse operation function

In the menu, support copy and paste setup function

 UPNP (Universal Plug and Play) Establish mapping connection between LAN and WAN via UPNP protocol.

Slight function differences may be found due to different series.

1.3

1.3 Specification

Specificationssss

1.31.3

SpecificationSpecification

1.3.1 Smart Box Series

System

Parameter

Main Processor

System Resources

Interface User-friendly graphical user interface

2CIF Real-time Smart Box

High-performance industrial embedded micro controller

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback and network operation simultaneously

960H Smart Box Series

Standalone DVR User’s Manual

Compression

Standard

Video monitor

Input

USB mouse, remote control Devices

Input Method

Shortcut

Function

Arabic number, English character, donation and extension Chinese

(optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click

USB mouse to switch screen.

Video

Compression H.264

Audio Compression G711A, G711U , PCM

Video Input 4-CH composite video input: (NTSC/PAL) BNC (1.0V

1-ch TV output (Inner core pin: Ф3.5mm). Video

Output

1-ch VGA output

1-ch HDMI output.

Support TV/VGA /HDMI video output at the same time.

Video Standard

Record

Speed

Support PAL/NTSC.

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per

channel

P- P,

75Ω)

Video

1/4 windows(Optional) Partition

Monitor

Touring

Support monitor tour functions such as alarm, motion detection, and

schedule auto control.

PAL/NTSC

Real-time monitor：

D1 704×576/704×480

Resolution (PAL/NTSC)

Playback

All-ch: 2CIF 704×288/704×240

(25/30fps)

D1 704×576/704×480 (12/15fps)

Playback All-ch:960×576/960×480 (25/30fps)

Support dual streams: extra stream resolution CIF 352×288/ 352×240,

QCIF 176×144/176×120.


6-level image quality (Adjustable) Quality

Privacy mask

Image Information

Support one privacy mask of user-defined size in full screen.

Support max 4 zones.

Channel information, time information and privacy mask zone.

TV Adjust Adjust TV output zone suitable to anamorphic video.

Standalone DVR User’s Manual

Channel Lock

Channel

Information

Color Configuratio n

Audio Audio Input

Audio Output

Bidirectional Talk Output

Hard disk

Record and playback

Hard Disk 1 built-in SATA port. Support one 2.5-inch HDD.

Hard Disk Occupation

Recording

Mode

Storage Mode

Recording Length

Playback Repeat Way

Record Search

Playback

Mode

Various File Switch Ways

Playback Way

Multi-chann el Playback

Cover secret channel with black screen though system is encoding

normally.

Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and

motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

1-ch audio input (Inner core pin: Ф3.5mm)

1-ch audio output (Inner core pin: Ф3.5mm)

Reuse the audio input/output port

Video：56-900MByte/h

Audio: 56～900MByte/h

Manual recording, motion detection recording, schedule recording and

alarm recording

Priority: Manual recording> alarm recording>motion detection

recording>schedule recording.

Support channel record quota setup

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and

reverse play mode.

Can switch to previous or next file or any file in current play list.

Can switch to file on other channel of the same time. (If there is a file)

Support file continuous play, when a file is end system auto plays the next

file in the current channel

Support mark playback

There is 1/4/-channel playback mode.

Window Zoom

Partial Enlargemen t

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone

to activate partial enlargement function.

Standalone DVR User’s Manual

Backup function

Network Function

Motion Detection and Alarm

Interface

System Information

HDD backup

Backup Mode

Network control

Motion Detection

Video Loss Alarm can activate screen message prompt.

External Alarm

Manual Alarm Control

Alarm Input N/A

Alarm Output

Alarm Relay N/A

USB

Interface

Network connection

RS485 N/A

RS232 N/A

Hard Disk Information

Data Stream Statistics

Log statistics

Version

On-line user Display current on-line user

Support peripheral USB backup device. (Flash disk, portable disk and

etc.)

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as motion detection and video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as

professional surveillance software (PSS)

Support zero-channel encoding function

Bidirectional talk function

Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.

Various sensitivity levels.

Alarm can activate record or screen message prompt.

N/A

2 USB 2.0 ports (Rated max current: 800mA).

1 RJ45 10M/100M self-adaptable Ethernet port

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files.

Support various search engines such as time and type.

Display version information: channel amount, alarm input and output

amount, system version and release date.

Standalone DVR User’s Manual

User Management

Upgrade Web browser, client-end and update tool.

General

Parameter

User Manageme

Password

Authenticati on

Power

Power Consumptio n

Working

Temperatur e

Working Humidity

Air Pressure

Dimension 192x 128 x 32mm

Weight About 0.5KG(Exclude HDD)

Installation Mode

Multi-lever user management; various management modes

Integrated management for local user, serial port user and network user.

Configurable user power.

Support user /group and its corresponding rights modification.

No limit to the user or group amount.

Password modification

Administrator can modify other user’s password.

Account lock strategy

Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout

/shutdown/ restart.

Right authentication when shut down to make sure only those proper

people can turn off DVR

Power adapter 5V2A -φ4.0

8W (exclude HDD)

-10℃－＋55℃

10%－90%

86kpa－106kpa

Desktop installation

×φ

1.7

1.3.2 960H Smart 1U Series

System

Parameter

Main

Processor

4-ch 8-ch 16-ch

High-performance industrial embedded micro controller

System Resources

Interface User-friendly graphical user interface

Input Devices

Input Method

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback

and network operation simultaneously

Front panel, USB mouse, remote control

Arabic number, English character, donation and extension Chinese

(optional)

Standalone DVR User’s Manual

Compression Standard

Video monitor

Shortcut Function

Copy/paste operation, USB mouse right-key shortcut menu, double click

USB mouse to switch screen.

Video Compression H.264

Audio Compression G711A, G711U , PCM

4-CH composite video

Video Input

Video Output

Video Standard

Record Speed

Video

input: (NTSC/PAL)

BNC (1.0V

P- P,

75Ω)

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output.

1-ch VGA output.

Support TV/VGA video output at the same time.

Support PAL/NTSC.

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per

channel

1/4 windows(Optional) 1/4/8/9 windows 1/4/8/9 /16 windows

Partition

Monitor

Touring

Support monitor tour functions such as alarm, motion detection, and

schedule auto control.

PAL/NTSC

Real-time monitor：

960H 960 ×576/960×480

Resolution (PAL/NTSC )

Playback：

All-channel: 960H 960 ×576/960×480 D1 704×576/704×480, HD1

352×576/352×480, 2CIF 704×288/704×240, CIF 352×288/ 352×240 ,

QCIF 176×144/176×120

Support dual streams: extra stream resolution CIF 352×288/ 352×240,

QCIF 176×144/176×120.


6-level image quality (Adjustable) Quality

Privacy mask

Image Information

Support one privacy mask of user-defined size in full screen.

Support max 4 zones.

Channel information, time information and privacy mask zone.

8-CH composite video input: (NTSC/PAL) BNC (1.0V

P- P,

75Ω)

16-CH composite video input: (NTSC/PAL) BNC (1.0V

75Ω)

P- P,

TV Adjust Adjust TV output zone suitable to anamorphic video.

Channel Lock

Cover secret channel with black screen though system is encoding

normally.

Screen-lock function to prevent unauthorized user seeing secret video.

Standalone DVR User’s Manual

Channel Information

Color Configuratio

Audio N/A

Hard disk

Record and

playback

Hard Disk 1 built-in SATA port. Support 1 HDD.

Hard Disk Occupation

Recording Mode

Storage Mode

Recording

Length

Playback Repeat Way

Record Search

Playback Mode

Various File Switch Ways

Playback Way

Multi-chann el Playback

Channel name, recording status, screen lock status, video loss status and

motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and

alarm recording

Priority: Manual recording> alarm recording>motion detection

recording>schedule recording.

Support channel record quota setup

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and

reverse play mode.

Can switch to previous or next file or any file in current play list.

Can switch to file on other channel of the same time. (If there is a file)

Support file continuous play, when a file is end system auto plays the next

file in the current channel

Support mark playback

There is 1/4/9/16-channel playback mode.

(It may vary due to different series.)

Window Zoom

Partial Enlargemen

Backup function

Backup

Mode

Network

control

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone

to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk and

etc.)

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

Standalone DVR User’s Manual

Network Function

Motion Detection and

Alarm

Interface

System Information

User Management

View alarm information such as motion detection and video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as

professional surveillance software (PSS)

Support zero-channel encoding function

Motion Detection

Video Loss Alarm can activate screen message prompt.

External Alarm

Manual

Alarm Control

Alarm Input N/A

Alarm Output

Alarm Relay N/A

USB Interface

Network connection

RS485 N/A

RS232 N/A

Hard Disk Information

Data Stream

Statistics

Log statistics

Version

On-line user Display current on-line user

User Manageme nt

Password Authenticati

Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.

Various sensitivity levels.

Alarm can activate record or screen message prompt.

N/A

2 USB 2.0 ports.

1 RJ45 10M/100M/1000M self-adaptable Ethernet port

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files.

Support various search engines such as time and type.

Display version information: channel amount, alarm input and output

amount, system version and release date.

Multi-lever user management; various management modes

Integrated management for local user, serial port user and network user.

Configurable user power.

Support user /group and its corresponding rights modification.

No limit to the user or group amount.

Password modification

Administrator can modify other user’s password.

Standalone DVR User’s Manual

on Account lock strategy

Five times login failure in thirty minutes may result in account lock.

Upgrade Web browser, client-end and update tool.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout

General Parameter

Power DC 12V

Power

Consumptio n

Working Temperatur e

Working Humidity

Air Pressure

Dimension

Weight 1.0-1.5KG(Exclude HDD)

Installation Mode

/shutdown/ restart.

Right authentication when shut down to make sure only those proper

people can turn off DVR

≤

25W (With adapter, exclude HDD)

-10℃－＋55℃

10%－90%

86kpa－106kpa

SMART 1U case. 205(W) x205 (D) x41mm(H) SMART 1U case.

Desktop installation

1.3.3 2CIF Smart 1U Series

System

Parameter

Main Processor

High-performance industrial embedded micro controller

16-ch

270(W) x205 (D) x41mm(H)

System Resources

Interface User-friendly graphical user interface

Input Devices

Input Method

Shortcut Function

Compression Standard

Video Compression H.264

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback

and network operation simultaneously

Front panel, USB mouse, remote control

Arabic number, English character, donation and extension Chinese

(optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click

USB mouse to switch screen.

Audio Compression N/A

Standalone DVR User’s Manual

Video monitor

Video Input 16-CH composite video input: (NTSC/PAL) BNC (1.0V

Video

Output

Video Standard

Record

Speed

Video

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output.

1-ch VGA output.

Support TV/VGA video output at the same time.

Support PAL/NTSC.

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per

channel

1/4/8/9 /16 windows Partition

Monitor

Touring

Support monitor tour functions such as alarm, motion detection, and

schedule auto control.

PAL/NTSC

Real-time monitor：

Resolution (PAL/NTSC )

D1 704×576/704×480

Playback：

1/2-ch: D1 704×576/704×480, HD1 352×576/352×480, 2CIF

704×288/704×240, CIF 352×288/ 352×240 , QCIF 176×144/176×120

3-16-ch: CIF 352×288/ 352×240, QCIF 176×144/176×120

Support dual streams: extra stream resolution QCIF 176×144/176×120.


6-level image quality (Adjustable) Quality

Privacy

mask

Image Information

Support one privacy mask of user-defined size in full screen.

Support max 4 zones.

Channel information, time information and privacy mask zone.

P- P,

75Ω)

TV Adjust Adjust TV output zone suitable to anamorphic video.

Channel Lock

Channel Information

Color Configuratio n

Audio N/A

Hard disk

Hard Disk 1 built-in SATA port. Support 1 HDD.

Hard Disk Occupation

Cover secret channel with black screen though system is encoding

normally.

Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and

motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

Video：56-900MByte/h

Standalone DVR User’s Manual

Record and playback

Recording Mode

Storage Mode

Recording Length

Playback Repeat Way

Record Search

Playback Mode

Various File

Switch Ways

Playback Way

Multi-chann el Playback

Manual recording, motion detection recording, schedule recording and

alarm recording

Priority: Manual recording> alarm recording>motion detection

recording>schedule recording.

Support channel record quota setup

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and

reverse play mode.

Can switch to previous or next file or any file in current play list.

Can switch to file on other channel of the same time. (If there is a file)

Support file continuous play, when a file is end system auto plays the next

file in the current channel

Support mark playback

There is 1/4/9/16-channel playback mode.

(It may vary due to different series.)

Backup function

Network

Function

Window

Zoom

Partial

Enlargemen t

Backup Mode

Network control

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone

to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk and

etc.)

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and

video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as

professional surveillance software (PSS)

Support zero-channel encoding function

Standalone DVR User’s Manual

Motion Detection and

Alarm

Interface

System Information

User Management

Upgrade Web browser, client-end and update tool.

Motion Detection

Video Loss Alarm can activate external alarm or screen message prompt.

External

Alarm

Manual

Alarm Control

Alarm Input N/A

Alarm Output

Alarm Relay N/A

USB Interface

Network connection

RS485 N/A

RS232 N/A

Hard Disk Information

Data Stream

Statistics

Log statistics

Version

On-line user Display current on-line user

User Manageme nt

Password

Authenticati on

Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.

Various sensitivity levels.

Alarm can activate record or external alarm or screen message prompt.

N/A

2 USB 2.0 ports.

1 RJ45 10M/100M/1000M self-adaptable Ethernet port

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files.

Support various search engines such as time and type.

Display version information: channel amount, alarm input and output

amount, system version and release date.

Multi-lever user management; various management modes

Integrated management for local user, serial port user and network user.

Configurable user power.

Support user /group and its corresponding rights modification.

No limit to the user or group amount.

Password modification

Administrator can modify other user’s password.

Account lock strategy

Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout

/shutdown/ restart.

Standalone DVR User’s Manual

Right authentication when shut down to make sure only those proper

people can turn off DVR

General Parameter

Power DC 12V

Power Consumptio

Working Temperatur e

Working Humidity

Air Pressure

Dimension SMART 1U case. 270(W) x205 (D) x41mm(H)

Weight 1.0-1.5KG(Exclude HDD)

Installation Mode

≤

25W (With adapter, exclude HDD)

-10℃－＋55℃

10%－90%

86kpa－106kpa

Desktop installation

1.3.4 Enhanced 960H Smart 1U/ Enhanced 960H(V2) Smart 1U Series

System

Parameter

Main

Processor

4-ch Enhanced 960H

Smart 1U/ Enhanced

960H(V2) Smart 1U

Series

High-performance industrial embedded micro controller

8-ch Enhanced 960H Smart 1U

16-ch Enhanced 960H Smart 1U

Compression Standard

System Resources

Interface User-friendly graphical user interface

Input Devices

Input Method

Shortcut Function

Video Compression H.264

Audio Compression G711A, G711U , PCM

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback

and network operation simultaneously

Front panel, USB mouse, remote control

Arabic number, English character, donation and extension Chinese

(optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click

USB mouse to switch screen.

Standalone DVR User’s Manual

Video monitor

Video Input

Video Output

Video Standard

Record Speed

Video Partition

Monitor Touring

Resolution

(PAL/NTSC )

Image Quality

Privacy mask


Information

4-CH composite video

input: (NTSC/PAL)

BNC (1.0V

P- P,

75Ω)

8-CH composite video input: (NTSC/PAL) BNC (1.0V

P- P,

75Ω)

16-CH composite video input: (NTSC/PAL) BNC

(1.0V

75Ω)

P- P,

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output.

1-ch VGA output.

1-ch HDMI output

Support TV/VGA /HDMI video output at the same time.

Support PAL/NTSC.

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per

channel

1/4 windows(Optional) 1/4/8/9 windows 1/4/8/9 /16 windows

Support monitor tour functions such as alarm, motion detection, and

schedule auto control.

PAL(700 TVL 50f/s)/NTSC(700 TVL 60f/s)

Real-time monitor：

960H 960 ×576/960×480

Playback：

All-channel: 960H 960 ×576/960×480 D1 704×576/704×480, HD1

352×576/352×480, 2CIF 704×288/704×240, CIF 352×288/ 352×240 ,

QCIF 176×144/176×120

Support dual streams: extra stream resolution CIF 352×288/ 352×240,

QCIF 176×144/176×120.

6-level image quality (Adjustable)

Support one privacy mask of user-defined size in full screen.

Support max 4 zones.

Channel information, time information and privacy mask zone.

TV Adjust Adjust TV output zone suitable to anamorphic video.

Channel Lock

Channel Information

Color

Configuratio n

Audio N/A

Hard Disk 1 built-in SATA port. Support 1 HDD.

Cover secret channel with black screen though system is encoding

normally.

Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and

motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

Standalone DVR User’s Manual

Hard disk

Record and playback

Hard Disk Occupation

Recording

Mode

Storage Mode

Recording Length

Playback Repeat Way

Record Search

Playback

Mode

Various File

Switch Ways

Playback Way

Multi-chann el Playback

Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and

alarm recording

Priority: Manual recording> alarm recording>motion detection

recording>schedule recording.

Support channel record quota setup

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and

reverse play mode.

Can switch to previous or next file or any file in current play list.

Can switch to file on other channel of the same time. (If there is a file)

Support file continuous play, when a file is end system auto plays the next

file in the current channel

Support mark playback

There is 1/4/9/16-channel playback mode.

(It may vary due to different series.)

Backup function

Network Function

Window

Zoom

Partial Enlargemen t

Backup Mode

Network control

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone

to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk and

etc.)

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as motion detection and video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as

professional surveillance software (PSS)

Support zero-channel encoding function

Standalone DVR User’s Manual

Motion Detection and

Alarm

Interface

System Information

User Management

Upgrade Web browser, client-end and update tool.

Motion Detection

Video Loss Alarm can activate screen message prompt.

External

Alarm

Manual

Alarm Control

Alarm Input N/A

Alarm Output

Alarm Relay N/A

USB Interface

Network connection

RS485 N/A

RS232 N/A

Hard Disk Information

Data Stream

Statistics

Log statistics

Version

On-line user Display current on-line user

User Manageme nt

Password

Authenticati on

Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.

Various sensitivity levels.

Alarm can activate record or screen message prompt.

N/A

2 USB 2.0 ports.

1 RJ45 10M/100M/1000M self-adaptable Ethernet port

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files.

Support various search engines such as time and type.

Display version information: channel amount, alarm input and output

amount, system version and release date.

Multi-lever user management; various management modes

Integrated management for local user, serial port user and network user.

Configurable user power.

Support user /group and its corresponding rights modification.

No limit to the user or group amount.

Password modification

Administrator can modify other user’s password.

Account lock strategy

Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout

/shutdown/ restart.

Standalone DVR User’s Manual

Right authentication when shut down to make sure only those proper

people can turn off DVR

General Parameter

Power DC 12V

Power Consumptio

Working Temperatur e

Working Humidity

Air Pressure

Dimension

Weight 1.0-1.5KG(Exclude HDD)

Installation

Mode

≤

25W (With adapter, exclude HDD)

-10℃－＋55℃

10%－90%

86kpa－106kpa

SMART 1U case. 205(W) x205 (D) x41mm(H) SMART 1U case.

Desktop installation

270(W) x205 (D)

x41mm(H)

1.3.5 Enhanced 2CIF Smart 1U/4-ch 960H Smart 1U/ Enhanced 2CIF(V2) Smart 1U Series

System

Parameter

Main Processor

4-ch Enhanced 2CIF Smart 1U/960H smart 1U/ Enhanced 2CIF(V2) Smart 1U

High-performance industrial embedded micro controller

8-ch Enhanced 2CIF Smart 1U/ Enhanced 2CIF(V2) Smart 1U

16-ch Enhanced 2CIF Smart 1U/ Enhanced 2CIF(V2) Smart 1U

System

Resources

Interface User-friendly graphical user interface

Input

Devices

Input Method

Shortcut Function

Compression Standard

Video Compression H.264

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback

and network operation simultaneously

Front panel, USB mouse, remote control

Arabic number, English character, donation and extension Chinese (optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click USB mouse to switch screen.

Audio Compression N/A

Standalone DVR User’s Manual

Video monitor

Video Input

Video

Output

Video Standard

Record Speed

4-CH composite video

input: (NTSC/PAL) BNC (1.0V

P- P,

75Ω)

Enhanced 2CIF Smart 1U/960H smart 1U: 1-ch VGA output. 1-ch HDMI output

Support VGA /HDMI video output at the same time.

8-CH composite video

input: (NTSC/PAL) BNC (1.0V

P- P,

75Ω)

16-CH composite

video input: (NTSC/PAL) BNC (1.0V

75Ω)

P- P,

Enhanced 2CIF Smart 1U :

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output. 1-ch VGA output. 1-ch HDMI output

Support TV/VGA /HDMI video output at the same time.

Enhanced 2CIF(V2) smart 1U: 1-ch VGA output. 1-ch HDMI output 1-ch TV output

Support VGA /HDMI/TV video output at the same time.

Enhanced 2CIF(V2) smart 1U: 1-ch VGA output. 1-ch HDMI output

1-ch TV output Support VGA /HDMI/TV video output at the same time.

4-ch Enhanced 2CIF Smart 1U series/ Enhanced 2CIF(V2) smart 1U: PAL(625

TVL 50fps) /NTSC(525 TVL 60fps)

PAL(625 TVL 50fps) /NTSC(525 TVL 60fps)

960H smart 1U series : PAL(700TVL

, 50f/s)/NTSC(700TVL,

60f/s)

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per channel

Video

Partition

Monitor Touring

1/4/8/9 /16 windows

Support monitor tour functions such as alarm, motion detection, and schedule auto control.

Standalone DVR User’s Manual

CIF

Resolution (PAL/NTSC )


Quality

4-ch Enhanced 2CIF Smart 1U series/ Enhanced 2CIF(V2)

smart 1U:

PAL/NTSC

Real-time monitor： D1 704×576/704×480

960H smart 1U series:

PAL/NTSC

Real-time monitor： 960H

960×576/960×480

4-ch Enhanced 2CIF Smart 1U series/ Enhanced 2CIF(V2) smart 1U:

Playback： All-ch: 2CIF 704×288/704×240, CIF 352×288/ 352×240 , QCIF 176×144/176×120

704×576/704×480

960H smart 1U series:

Playback 960H

960×576/960×480. D1 704×576/704×480. HD1

352×576/352×480. 2CIF

704×288/704×240. CIF 352×288/ 352×240, QCIF 176×144/176×120

Support dual streams: extra stream resolution CIF 352×288/

352×240QCIF 176×144/176×120.

6-level image quality (Adjustable)

PAL/NTSC

Real-time monitor： D1 704×576/704×480

Playback： All-ch: 2CIF 704×288/704×240, 352×288/ 352×240 , QCIF 176×144/176×120

Standalone DVR User’s Manual

Privacy mask

Image Information

Channel

Lock

Channel Information

Color Configuratio n

Audio N/A

Hard disk

Record and playback

Hard Disk 1 built-in SATA port. Support 1 HDD.

Hard Disk Occupation

Recording Mode

Storage Mode

Recording Length

Playback Repeat Way

Record

Playback Mode

Various File Switch Ways

Playback Way

Multi-chann

el Playback

Support one privacy mask of user-defined size in full screen. Support max 4 zones.

Channel information, time information and privacy mask zone.

Cover secret channel with black screen though system is encoding

normally. Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and

alarm recording Priority: Manual recording> alarm recording>motion detection recording>schedule recording.

Support channel record quota setup

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and reverse play mode.

Can switch to previous or next file or any file in current play list. Can switch to file on other channel of the same time. (If there is a file) Support file continuous play, when a file is end system auto plays the next file in the current channel

Support mark playback

There is 1/4/9/16-channel playback mode.

(It may vary due to different series.)

Window Zoom

Partial Enlargemen t

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone to activate partial enlargement function.

Standalone DVR User’s Manual

Backup function

Network Function

Motion Detection and

Alarm

Interface

System Information

HDD backup

Backup Mode

Network control

Motion Detection

Video Loss Alarm can activate external alarm or screen message prompt.

External

Alarm

Manual Alarm Control

Alarm Input N/A

Alarm Output

Alarm Relay N/A

USB Interface

Network connection

RS485 N/A

RS232 N/A

Hard Disk Information

Data Stream

Statistics

Log statistics

Version

On-line user Display current on-line user

Support peripheral USB backup device. (Flash disk, portable disk and etc.)

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as professional surveillance software (PSS)

Support zero-channel encoding function

Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones. Various sensitivity levels. Alarm can activate record or external alarm or screen message prompt.

N/A

2 USB 2.0 ports.

1 RJ45 10M/100M self-adaptable Ethernet port

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files. Support various search engines such as time and type.

Display version information: channel amount, alarm input and output amount, system version and release date.

Standalone DVR User’s Manual

User Management

Upgrade Web browser, client-end and update tool.

General

Parameter

User Manageme

Password

Authenticati on

Power DC 12V

Power Consumptio n

Working Temperatur e

Working Humidity

Air Pressure

Dimension SMART 1U case. 270(W) x205 (D) x41mm(H)

Weight 1.0-1.5KG(Exclude HDD)

Installation Mode

Multi-lever user management; various management modes Integrated management for local user, serial port user and network user. Configurable user power.

Support user /group and its corresponding rights modification.

No limit to the user or group amount.

Password modification Administrator can modify other user’s password.

Account lock strategy Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout /shutdown/ restart.

Right authentication when shut down to make sure only those proper people can turn off DVR

≤

15W (With adapter, exclude HDD)

-10℃－＋55℃

10%－90%

86kpa－106kpa

Desktop installation/wall mount installation Desktop installation

1.3.6 General 2CIF Mini 1U Series/ General 960H Mini 1U/ General 2CIF(V2) Mini 1U Series

System

Parameter

Main Processor

4-ch General 2CIF mini 1U / General 960H mini 1U/ General 2CIF(V2) mini 1U

High-performance industrial embedded micro controller

General 2CIF mini 1U/ General 2CIF(V2) mini 1U

≤

25W (With adapter,

exclude HDD)

General 2CIF mini 1U/ General 2CIF(V2) mini 1U

System Resources

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback and network operation simultaneously

Compression

Standard

Standalone DVR User’s Manual

Interface User-friendly graphical user interface

Input

Front panel, USB mouse, remote control. Devices

Input Method

Shortcut Function

Arabic number, English character, donation and extension Chinese

(optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click

USB mouse to switch screen.

Video

Compression H.264

Audio Compression G711A, G711U, PCM

Video monitor

Video Input

Video Output

Video Standard

Record Speed

4-CH composite video

input: (NTSC/PAL)

BNC (1.0V

P- P,

75Ω)

8-CH composite video input: (NTSC/PAL)

BNC (1.0V

P- P,

75Ω)

16-CH composite video input:

(NTSC/PAL) BNC (1.0V

75Ω)

P- P,

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output.

1-ch VGA output.

1-ch HDMI output.

Support TV/VGA/HDMI video output at the same time.

General 2CIF mini 1U

series/ General

2CIF(V2) mini

1U: PAL(625 TVL

50fps) /NTSC(525 TVL

60fps)

PAL(625 TVL 50fps) /NTSC(525 TVL 60fps)

General 960H mini

series: PAL(700TVL,

50f/s)/NTSC(700TVL,

60f/s)

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per

channel

Video Partition

Monitor Touring

Resolution (PAL/NTSC)

1/4/8/9 /16 windows

Support monitor tour functions such as alarm, motion detection, and

schedule auto control.

PAL/NTSC

Real-time monitor：

D1 704×576/704×480

Standalone DVR User’s Manual

Playback

Max 1-channel

960H+1-channel

D1+2-channel CIF.

Support dual streams: extra stream resolution QCIF 176×144/176×120.


Quality

Privacy mask

Image Information

TV Adjust Adjust TV output zone suitable to anamorphic video.

Channel

Lock

Channel Information

Color Configuratio n

Audio Audio Input 1-ch 200-2000mv 10KΩ(RCA)

Audio Output

Bidirectional

Audio

Hard disk

Record and playback

Hard Disk 1 built-in SATA port. Support 1 HDD.

Hard Disk

Occupation

Recording Mode

Storage Mode

Recording Length

Playback

Repeat Way

Record Search

Playback Mode

6-level image quality (Adjustable)

Support one privacy mask of user-defined size in full screen.

Support max 4 zones.

Channel information, time information and privacy mask zone.

Cover secret channel with black screen though system is encoding

normally.

Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and

motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

1-ch audio output 200-3000mv 5KΩ(RCA)

Reuse the first audio input channel.

Reuse audio output channel.

Audio：PCM 28.8MByte/h

Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and

alarm recording

Priority: Manual recording> alarm recording>motion detection

recording>schedule recording.

Support channel record quota setup

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and

reverse play mode.

Playback Max 2-channel 960H+6-channel CIF

Playback Max 4-channel 960H+12-channel CIF.

Standalone DVR User’s Manual

Backup

function

Network Function

Motion Detection and Alarm

Interface

Various File Switch Ways

Multi-chann el Playback

Window Zoom

Partial Enlargemen t

Backup

Mode

Network control

Motion

Detection

Video Loss Alarm can activate screen message prompt.

External Alarm

Manual Alarm Control

Alarm Input N/A

Alarm Output

Alarm Relay N/A

USB Interface

Can switch to previous or next file or any file in current play list.

Can switch to file on other channel of the same time. (If there is a file)

Support file continuous play, when a file is end system auto plays the next

file in the current channel

There is 1/4/9/16-channel playback mode.

(It may vary due to different series.)

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone

to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk and

etc.)

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and

video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as

professional surveillance software (PSS)

Duplex transparent COM

Network alarm input and output

Bidirectional audio.

Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.

Various sensitivity levels.

Alarm can activate record or external alarm or screen message prompt.

N/A

Two USB 2.0 ports.

Standalone DVR User’s Manual

Network connection

RS485

RS232 N/A

System Information

User Management

Upgrade Web browser, client-end and update tool.

General

Parameter

Hard Disk Information

Data

Stream Statistics

Log statistics

Version

On-line user Display current on-line user

User Manageme nt

Password

Authenticati on

Power DC 12V

Power Consumptio n

Working Temperatur e

Working Humidity

Air Pressure

Dimension 325(W) x242 (D) x55mm(H)

Weight 1.25KG KG(Exclude HDD)

One RJ45 10M/100M self-adaptable Ethernet port

PTZ control port

Support various PTZ control protocols.

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files.

Support various search engines such as time and type.

Display version information: channel amount, alarm input and output

amount, system version and release date.

Multi-lever user management; various management modes

Integrated management for local user, serial port user and network user.

Configurable user power.

Support user /group and its corresponding rights modification.

No limit to the user or group amount.

Password modification

Administrator can modify other user’s password.

Account lock strategy

Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout

/shutdown/ restart.

Right authentication when shut down to make sure only those proper

people can turn off DVR

≤

15W (With adapter, exclude HDD)

-10℃－＋55℃

10%－90%

86kpa－106kpa

Standalone DVR User’s Manual

Installation

Desktop installation Mode

1.3.7 Enhanced 2CIF Mini 1U / Enhanced 960H Mini 1U/ Enhanced 2CIF(V2) Mini 1U Series

System

Compression Standard

Parameter

Main

Processor

System Resources

Interface User-friendly graphical user interface

Input Devices

Input Method

Shortcut Function

Video Compression H.264

4-ch Enhanced 2CIF mini 1U / Enhanced 960H mini 1U

8-ch Enhanced 2CIF mini 1U/ Enhanced 2CIF(V2) mini 1U

High-performance industrial embedded micro controller

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback and network operation simultaneously

Front panel, USB mouse, remote control.

Arabic number, English character, donation and extension Chinese (optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click USB mouse to switch screen.

16-ch Enhanced 2CIF mini 1U/ Enhanced 2CIF(V2) mini 1U

Video monitor

Audio Compression G711A, G711U, PCM

4-CH composite video

Video Input

input: (NTSC/PAL) BNC (1.0V

P- P,

75Ω)

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output.

Video Output

1-ch VGA output. 1-ch HDMI output. Support TV/VGA/HDMI video output at the same time.

Enhanced 2CIF mini 1U series:

PAL(625 TVL 50fps)

Video Standard

/NTSC(525 TVL 60fps)

Enhanced 960H mini 1U series:

PAL

(700TVL, 50f/s)/NTSC (700TVL, 60f/s)

8-CH composite video input: (NTSC/PAL) BNC (1.0V

P- P,

75Ω)

16-CH composite video input: (NTSC/PAL) BNC

(1.0V

75Ω)

P- P,

PAL(625 TVL 50fps) /NTSC(525 TVL 60fps)

Standalone DVR User’s Manual

960H

CIF

Record Speed

Video

Partition

Monitor Touring

Resolution (PAL/NTSC)

Image Quality

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per channel

1/4/8/9 /16 windows

Support monitor tour functions such as alarm, motion detection, and schedule auto control.

Enhanced 2CIF mini 1U series:

PAL/NTSC

Real-time monitor： D1 704×576/704×480

Enhanced 960H mini 1U series:

PAL/NTSC

Real-time monitor： 960H 960×576/960×480

Enhanced 2CIF mini 1U series:

Playback： All-channel: 2CIF

704×288/704×240, CIF 352×288/ 352×240 , QCIF 176×144/176×120

Enhanced 960H mini 1U series:

Playback： All-channel: 960×576/960×480, D1

704×576/704×480, HD 1352×576/352×480, 2CIF 704×288/704×240,

CIF 352×288/ 352×240, QCIF 176×144/176×120

Support dual streams: extra stream resolution QCIF 176×144/176×120.

6-level image quality (Adjustable)

PAL/NTSC

Real-time monitor： D1 704×576/704×480

Playback： All-channel: 2CIF 704×288/704×240, 352×288/ 352×240 , QCIF 176×144/176×120

Standalone DVR User’s Manual

Audio

Hard disk

Record and playback

Privacy mask

Image Information

TV Adjust Adjust TV output zone suitable to anamorphic video.

Channel Lock

Channel Information

Color Configuratio

Audio Input

Audio Output

Bidirectional Audio

Hard Disk 1 built-in SATA port. Support 1 HDD.

Hard Disk Occupation

Recording Mode

Storage Mode

Recording Length

Playback Repeat Way

Record

Playback

Mode

Various File Switch Ways

Support one privacy mask of user-defined size in full screen. Support max 4 zones.

Channel information, time information and privacy mask zone.

Cover secret channel with black screen though system is encoding normally. Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

Enhanced 2CIF mini 1U / Enhanced 960H mini 1U :4-ch 200-2000mv 10KΩ(RCA)

8-ch Enhanced 2CIF(V2) mini 1U: 8-ch 200-2000mv 10KΩ(RCA) 16-ch Enhanced 2CIF(V2) mini 1U: 16-ch 200-2000mv 10KΩ(RCA)

1-ch audio output 200-3000mv 5KΩ(RCA)

Reuse the first audio input channel. Reuse audio output channel.

Audio：PCM 28.8MByte/h Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and

alarm recording Priority: Manual recording> alarm recording>motion detection recording>schedule recording.

Support channel record quota setup

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and

reverse play mode.

Standalone DVR User’s Manual

Backup function

Network

Function

Motion Detection and Alarm

Interface

Multi-chann el Playback

Window

Zoom

Partial

Enlargemen t

Backup Mode

Network control

Motion Detection

Video Loss Alarm can activate screen message prompt.

External Alarm

Manual Alarm

Control

Alarm Input

Alarm Output

Alarm Relay

USB Interface

Network connection

RS485

There is 1/4/9/16-channel playback mode. (It may vary due to different series.)

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone

to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk and etc.)

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as professional surveillance software (PSS)

Duplex transparent COM

Network alarm input and output

Bidirectional audio.

Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones. Various sensitivity levels. Alarm can activate record or external alarm or screen message prompt.

Support record activation function or activate external alarm or screen message in specified period.

Enable or disable alarm input channel Support analog alarm signal to specific alarm output channel.

4-ch alarm input

（

NO/NC ）

3-channel relay output.

30VDC 2A，125VAC 1A (Activation output)

One USB 2.0 port.

One RJ45 10M/100M/1000M self-adaptable Ethernet port

PTZ control port Support various PTZ control protocols.

8-ch alarm input

（

NO/NC ）

16-ch alarm input

（

NO/NC ）

Standalone DVR User’s Manual

RS232 N/A

System Information

User Management

Upgrade Web browser, client-end and update tool.

General Parameter

Hard Disk Information

Data Stream

Statistics

Log

statistics

Version

On-line user Display current on-line user

User Manageme nt

Password Authenticati

Power DC 12V

Power Consumptio n

Working Temperatur

Working Humidity

Air Pressure

Dimension

Weight 1.25KG(Exclude HDD)

Installation Mode

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files.

Support various search engines such as time and type.

Display version information: channel amount, alarm input and output amount, system version and release date.

Multi-lever user management; various management modes Integrated management for local user, serial port user and network user. Configurable user power.

Support user /group and its corresponding rights modification. No limit to the user or group amount.

Password modification Administrator can modify other user’s password.

Account lock strategy

Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout

/shutdown/ restart.

Right authentication when shut down to make sure only those proper people can turn off DVR

≤

15W (With adapter, exclude HDD)

-10

℃－＋55℃

10%－90%

86kpa－106kpa

325(W) x242 (D) x55mm(H) (Including feet)

Desktop installation

≤

25W (With adapter,

exclude HDD)

1U standard case 375mm(W) 280mm(D)×50mm(H)

1.5

～

2.5KG(Exclude

HDD)

， ×

1.3.8 Economic 2CIF Mini 1U Series

System

Parameter

Main Processor

4-ch 8-ch 16-ch

High-performance industrial embedded micro controller

Standalone DVR User’s Manual

Compression

Standard

Video monitor

System Resources

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback and network operation simultaneously

Interface User-friendly graphical user interface

Input

Front panel, USB mouse, remote control. Devices

Input Method

Shortcut Function

Arabic number, English character, donation and extension Chinese

(optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click

USB mouse to switch screen.

Video

Compression H.264

Audio Compression G711A, G711U, PCM

Video Input

Video Output

Video Standard

Record Speed

4-CH composite video

input: (NTSC/PAL)

BNC (1.0V

P- P,

75Ω)

1-ch VGA output.

1-ch HDMI output.

Support VGA/HDMI video output at the same time.

Support PAL(625 TVL 50fps) /NTSC(525 TVL 60fps)

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per

channel

8-CH composite video input: (NTSC/PAL) BNC (1.0V

P- P,

75Ω)

16-CH composite video input: (NTSC/PAL) BNC

(1.0V

75Ω)

P- P,

Video Partition

Monitor Touring

Resolution (PAL/NTSC)

1/4/8/9 /16 windows

Support monitor tour functions such as alarm, motion detection, and

schedule auto control.

PAL/NTSC

Real-time monitor：

D1 704×576/704×480

Playback：

All-channel: 2CIF 704×288/704×240, CIF 352×288/ 352×240 , QCIF

176×144/176×120

Support dual streams: extra stream resolution QCIF 176×144/176×120.

Standalone DVR User’s Manual

Image Quality

Privacy mask


Information

Channel

Lock

Channel Information

Color Configuratio n

Audio Audio Input N/A

Audio Output

Bidirectional

Audio

Hard disk

Record and playback

Hard Disk 1 built-in SATA port. Support 1 HDD.

Hard Disk Occupation

Recording Mode

Storage Mode

Recording

Length

Playback Repeat Way

Record Search

Playback Mode

Various File Switch Ways

Multi-chann el Playback

6-level image quality (Adjustable)

Support one privacy mask of user-defined size in full screen.

Support max 4 zones.

Channel information, time information and privacy mask zone.

Cover secret channel with black screen though system is encoding

normally.

Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and

motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

N/A

Audio：PCM 28.8MByte/h

Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and

alarm recording

Priority: Manual recording> alarm recording>motion detection

recording>schedule recording.

Support channel record quota setup

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and

reverse play mode.

Can switch to previous or next file or any file in current play list.

Can switch to file on other channel of the same time. (If there is a file)

Support file continuous play, when a file is end system auto plays the next

file in the current channel

There is 1/4/9/16-channel playback mode.

(It may vary due to different series.)

Standalone DVR User’s Manual

Backup function

Network Function

Motion Detection and Alarm

Interface

System Information

Window Zoom

Partial Enlargemen

Backup

Mode

Network

control

Motion

Detection

Video Loss Alarm can activate screen message prompt.

External Alarm

Manual Alarm Control

Alarm Input N/A

Alarm Output

Alarm Relay N/A

USB

Interface

Network

connection

RS485 N/A

RS232 N/A

Hard Disk Information

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone

to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk and

etc.)

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and

video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as

professional surveillance software (PSS)

Duplex transparent COM

Network alarm input and output

Bidirectional audio.

Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.

Various sensitivity levels.

Alarm can activate record or external alarm or screen message prompt.

N/A

2 USB 2.0 ports.

One RJ45 10M/100M self-adaptable Ethernet port

Display HDD current status

Standalone DVR User’s Manual

Data Stream Statistics

Log

statistics

Version

On-line user Display current on-line user

User Management

Upgrade Web browser, client-end and update tool.

General Parameter

User Manageme nt

Password Authenticati

Power DC 12V

Power Consumptio n

Working Temperatur

Working

Humidity

Air Pressure

Dimension 325(W) x242 (D) x55mm(H)

Weight 1.25KG KG(Exclude HDD)

Installation

Mode

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files.

Support various search engines such as time and type.

Display version information: channel amount, alarm input and output

amount, system version and release date.

Multi-lever user management; various management modes

Integrated management for local user, serial port user and network user.

Configurable user power.

Support user /group and its corresponding rights modification.

No limit to the user or group amount.

Password modification

Administrator can modify other user’s password.

Account lock strategy

Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout

/shutdown/ restart.

Right authentication when shut down to make sure only those proper

people can turn off DVR

≤

15W (With adapter, exclude HDD)

-10℃－＋55℃

10%－90%

86kpa－106kpa

Desktop installation

1.3.9 General 960H Mini 1U/ General 960H (V2) Mini 1U Series

Parameter

4-ch General 960H mini

1U /General 960H (V2)

mini 1U

8-ch General 960H mini 1U

16-ch General 960H mini 1U

Standalone DVR User’s Manual

System

Compression

Standard

Video monitor

Main

High-performance industrial embedded micro controller

Processor

System Resources

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback

and network operation simultaneously

Interface User-friendly graphical user interface

Input

USB mouse Devices

Input Method

Shortcut Function

Arabic number, English character, donation and extension Chinese

(optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click

USB mouse to switch screen.

Video

Compression H.264

Audio Compression G711A, G711U, PCM

Video Input

4-CH composite video

input: (NTSC/PAL)

BNC (1.0V

P- P,

75Ω)

8-CH composite video input: (NTSC/PAL)

BNC (1.0V

P- P,

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output. Video Output

1-ch VGA output.

1-ch HDMI output.

Support TV/VGA/HDMI video output at the same time.

Video Standard

Record Speed

Support PAL(625 TVL 50fps) /NTSC(525 TVL 60fps)

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per

channel

75Ω)

16-CH composite video input:

(NTSC/PAL) BNC (1.0V

75Ω)

P- P,

Video Partition

Monitor Touring

Resolution (PAL/NTSC)

1/4 windows(Optional) 1/4/8/9 windows 1/4/8/9 /16 windows

Support monitor tour functions such as alarm, motion detection, and

schedule auto control.

PAL/NTSC

Real-time monitor：

960H 960 ×576/960×480

Playback：

All-ch: 960H (960 ×576/960×480) D1 704×576/704×480, H

352×576/352×480, 2CIF 704×288/704×240, CIF 352×288/ 352×240 ,

QCIF 176×144/176×120

Support dual streams: extra stream resolution CIF 352×288/ 352×240,

QCIF 176×144/176×120.

Standalone DVR User’s Manual

Audio

Hard disk

Record and playback

Image Quality

Privacy mask


Information

TV Adjust Adjust TV output zone suitable to anamorphic video.

Channel Lock

Channel Information

Color

Configuratio n

Audio Input

Audio Output

Bidirectional Audio

Hard Disk 1 built-in SATA port. Support 1 HDD.

Hard Disk Occupation

Recording Mode

Recording Length

Playback Repeat Way

Record Search

Playback

Mode

Various File

Switch Ways

Multi-chann el Playback

6-level image quality (Adjustable)

Support one privacy mask of user-defined size in full screen.

Support max 4 zones.

Channel information, time information and privacy mask zone.

Cover secret channel with black screen though system is encoding

normally.

Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and

motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

1-ch 200-2000mv 10KΩ(RCA)

1-ch audio output 200-3000mv 5KΩ(RCA)

Reuse the first audio input channel.

Reuse audio output channel.

Audio：PCM 28.8MByte/h

Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and

alarm recording

Priority: Manual recording> alarm recording>motion detection

recording>schedule recording.

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and

reverse play mode.

Can switch to previous or next file or any file in current play list.

Can switch to file on other channel of the same time. (If there is a file)

Support file continuous play, when a file is end system auto plays the next

file in the current channel

There is 1/4/9/16-channel playback mode.

(It may vary due to different series.)

Standalone DVR User’s Manual

Backup function

Network Function

Motion Detection and Alarm

Interface

Window Zoom

Partial Enlargemen

Backup

Mode

Network

control

Motion

Detection

Video Loss Alarm can activate external alarm or screen message prompt.

External Alarm

Manual Alarm Control

Alarm Input N/A

Alarm Output

Alarm Relay N/A

USB Interface

Network

connection

RS485

RS232 N/A

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone

to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk and

etc.)

Support peripheral USB burner.

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and

video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as

professional surveillance software (PSS)

Duplex transparent COM

Network alarm input and output

Bidirectional audio.

Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.

Various sensitivity levels.

Alarm can activate record or external alarm or screen message prompt.

N/A

2 USB 2.0 ports.

One RJ45 10M/100M self-adaptable Ethernet port

PTZ control port

Support various PTZ control protocols.

Standalone DVR User’s Manual

System Information

User Management

Upgrade Web browser, client-end and update tool.

General Parameter

Hard Disk Information

Data Stream

Statistics

Log statistics

Version

On-line user Display current on-line user

User Manageme nt

Password Authenticati

Power DC 12V

Power Consumptio n

Working Temperatur

Working Humidity

Air Pressure

Dimension 325(W) x242 (D) x55mm(H)

Weight 1.25KG(Exclude HDD)

Installation Mode

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files.

Support various search engines such as time and type.

Display version information: channel amount, alarm input and output

amount, system version and release date.

Multi-lever user management; various management modes

Integrated management for local user, serial port user and network user.

Configurable user power.

Support user /group and its corresponding rights modification.

No limit to the user or group amount.

Password modification

Administrator can modify other user’s password.

Account lock strategy

Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout

/shutdown/ restart.

Right authentication when shut down to make sure only those proper

people can turn off DVR

≤

15W

(With adapter, exclude HDD)

-10

℃－＋55℃

10%－90%

86kpa－106kpa

Desktop installation

1.3.10 Enhanced 960H Mini 1U Series

Parameter

4-ch 8-ch 16-ch

Standalone DVR User’s Manual

System

Compression

Standard

Video monitor

Main

High-performance industrial embedded micro controller

Processor

System Resources

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback

and network operation simultaneously

Interface User-friendly graphical user interface

Input

Front panel, USB mouse, remote control. Devices

Input Method

Shortcut Function

Arabic number, English character, donation and extension Chinese

(optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click

USB mouse to switch screen.

Video

Compression H.264

Audio Compression G711A, G711U, PCM

Video Input

4-CH composite video

input: (NTSC/PAL)

BNC (1.0V

P- P,

75Ω)

8-CH composite video input: (NTSC/PAL)

BNC (1.0V

P- P,

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output. Video Output

1-ch VGA output.

1-ch HDMI output.

Support TV/VGA/HDMI video output at the same time.

Video Standard

Record Speed

Support PAL(625 TVL 50fps) /NTSC(525 TVL 60fps)

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per

channel

75Ω)

16-CH composite video input:

(NTSC/PAL) BNC (1.0V

75Ω)

P- P,

Video Partition

Monitor Touring

Resolution

(PAL/NTSC )

1/4 windows(Optional) 1/4/8/9 windows 1/4/8/9 /16 windows

Support monitor tour functions such as alarm, motion detection, and

schedule auto control.

PAL/NTSC

Real-time monitor：

960H 960 ×576/960×480

Playback：

All-ch: 960H (960 ×576/960×480) D1 704×576/704×480, H

352×576/352×480, 2CIF 704×288/704×240, CIF 352×288/ 352×240 ,

QCIF 176×144/176×120

Support dual streams: extra stream resolution CIF 352×288/ 352×240,

QCIF 176×144/176×120.

Standalone DVR User’s Manual

Image Quality

Privacy mask


Information

TV Adjust Adjust TV output zone suitable to anamorphic video.

Channel Lock

Channel Information

Color

Configuratio n

Audio Audio Input 4-ch 200-2000mv 10KΩ(RCA)

Audio Output

Bidirectional Audio

Hard disk

Record and playback

Hard Disk 1 built-in SATA port. Support 1 HDD.

Hard Disk Occupation

Recording

Mode

Storage Mode

Recording Length

Playback Repeat Way

Record Search

Playback Mode

Various File

Switch Ways

6-level image quality (Adjustable)

Support one privacy mask of user-defined size in full screen.

Support max 4 zones.

Channel information, time information and privacy mask zone.

Cover secret channel with black screen though system is encoding

normally.

Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and

motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

1-ch audio output 200-3000mv 5KΩ(RCA)

Reuse the first audio input channel.

Reuse audio output channel.

Audio：PCM 28.8MByte/h

Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and

alarm recording

Priority: Manual recording> alarm recording>motion detection

recording>schedule recording.

Support channel record quota setup

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and

reverse play mode.

Can switch to previous or next file or any file in current play list.

Can switch to file on other channel of the same time. (If there is a file)

Support file continuous play, when a file is end system auto plays the next

file in the current channel

Standalone DVR User’s Manual

Backup function

Network

Function

Motion Detection and Alarm

Interface

Multi-chann el Playback

Window

Zoom

Partial

Enlargemen t

Backup Mode

Network control

Motion Detection

Video Loss Alarm can activate external alarm or screen message prompt.

External Alarm

Manual Alarm

Control

Alarm Input

Alarm Output

Alarm Relay

USB Interface

Network connection

RS485

There is 1/4/9/16-channel playback mode.

(It may vary due to different series.)

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone

to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk and

etc.)

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and

video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as

professional surveillance software (PSS)

Duplex transparent COM

Network alarm input and output

Bidirectional audio.

Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.

Various sensitivity levels.

Alarm can activate record or external alarm or screen message prompt.

Support record activation function or activate external alarm or screen

message in specified period.

Enable or disable alarm input channel

Support analog alarm signal to specific alarm output channel.

4-ch alarm input

（

NO/NC. ）

3-channel relay output.

30VDC 2A，125VAC 1A (Activation output)

2 USB 2.0 ports.

One RJ45 10M/100M/1000M self-adaptable Ethernet port

PTZ control port

Support various PTZ control protocols.

8-ch alarm input

（

NO/NC ）

16-ch alarm input

（

NO/NC ）

Standalone DVR User’s Manual

RS232 N/A

System Information

User Management

Upgrade Web browser, client-end and update tool.

General Parameter

Hard Disk Information

Data Stream

Statistics

Log

statistics

Version

On-line user Display current on-line user

User Manageme nt

Password Authenticati

Power DC 12V

Power Consumptio n

Working Temperatur

Working Humidity

Air Pressure

Dimension 325(W) x242 (D) x55mm(H)

Weight 1.25KG(Exclude HDD)

Installation Mode

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files.

Support various search engines such as time and type.

Display version information: channel amount, alarm input and output

amount, system version and release date.

Multi-lever user management; various management modes

Integrated management for local user, serial port user and network user.

Configurable user power.

Support user /group and its corresponding rights modification.

No limit to the user or group amount.

Password modification

Administrator can modify other user’s password.

Account lock strategy

Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout

/shutdown/ restart.

Right authentication when shut down to make sure only those proper

people can turn off DVR

≤

25W (With adapter, exclude HDD)

-10℃－＋55℃

10%－90%

86kpa－106kpa

Desktop installation

1.3.11 2CIF Small Mini 1U Series

Standalone DVR User’s Manual

System

Compression Standard

Parameter

Main

4-ch 8-ch 16-ch

High-performance industrial embedded micro controller

Processor

System Resources

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback

and network operation simultaneously

Interface User-friendly graphical user interface

Input

Remote control. Devices

Input Method

Shortcut Function

Arabic number, English character, donation and extension Chinese

(optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click

USB mouse to switch screen.

Video Compression H.264

Audio Compression G711A, G711U, PCM

Video monitor

Video Input

Video Output

Video Standard

Record Speed

Video Partition

Monitor Touring

Resolution (PAL/NTSC )

4-CH composite video

input: (NTSC/PAL)

BNC (1.0V

P- P,

75Ω)

8-CH composite video input: (NTSC/PAL) BNC (1.0V

P- P,

75Ω)

16-CH composite video input: (NTSC/PAL) BNC (1.0V

75Ω)

P- P,

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output.

1-ch VGA output.

1-ch HDMI output.

Support TV/VGA/HDMI video output at the same time.

Support PAL(625 TVL 50fps) /NTSC(525 TVL 60fps)

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per

channel

1/4 windows(Optional) 1/4/8/9 windows 1/4/8/9 /16 windows

Support monitor tour functions such as alarm, motion detection, and

schedule auto control.

PAL/NTSC

Real-time monitor：

D1 704×576/704×480

Playback

Max 1-channel

960H+1-channel

Playback Max 2-channel

960H+6-channel CIF

Playback Max 4-channel

960H+12-channel CIF. D1+2-channel CIF.

Support dual streams: extra stream resolution QCIF 176×144/176×120.

Standalone DVR User’s Manual

Image Quality

Privacy mask


Information

TV Adjust Adjust TV output zone suitable to anamorphic video.

Channel Lock

Channel Information

Color

Configuratio n

Audio Audio Input 1-ch 200-2000mv 10KΩ(RCA)

Audio Output

Bidirectional Audio

Hard disk

Record and playback

Hard Disk 1 built-in SATA port. Support 1 HDD.

Hard Disk Occupation

Recording

Mode

Storage Mode

Recording Length

Playback Repeat Way

Record Search

Playback Mode

Various File

Switch Ways

6-level image quality (Adjustable)

Support one privacy mask of user-defined size in full screen. Support max 4 zones.

Channel information, time information and privacy mask zone.

Cover secret channel with black screen though system is encoding normally. Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

1-ch audio output 200-3000mv 5KΩ(RCA)

Reuse the first audio input channel. Reuse audio output channel.

Audio：PCM 28.8MByte/h Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and alarm recording

Priority: Manual recording> alarm recording>motion detection recording>schedule recording.

Support channel record quota setup

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and reverse play mode.

Can switch to previous or next file or any file in current play list.

Can switch to file on other channel of the same time. (If there is a file) Support file continuous play, when a file is end system auto plays the next file in the current channel

Standalone DVR User’s Manual

Backup function

Network

Function

Motion Detection and Alarm

Interface

Multi-chann el Playback

Window

Zoom

Partial

Enlargemen t

Backup Mode

Network control

Motion Detection

Video Loss Alarm can activate external alarm or screen message prompt.

External Alarm

Manual Alarm

Control

Alarm Input N/A

Alarm Output

Alarm Relay

USB Interface

Network connection

RS485

RS232 N/A

There is 1/4/9/16-channel playback mode. (It may vary due to different series.)

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone

to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk and etc.)

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as professional surveillance software (PSS)

Duplex transparent COM

Network alarm input and output

Bidirectional audio.

Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones. Various sensitivity levels. Alarm can activate record or external alarm or screen message prompt.

N/A

30VDC 2A，125VAC 1A (Activation output)

2 USB 2.0 ports.

One RJ45 10M/100M/1000M self-adaptable Ethernet port

PTZ control port Support various PTZ control protocols.

Standalone DVR User’s Manual

System Information

User Management

Upgrade Web browser, client-end and update tool.

General Parameter

Hard Disk Information

Data Stream

Statistics

Log statistics

Version

On-line user Display current on-line user

User Manageme nt

Password Authenticati

Power DC 12V

Power Consumptio n

Working Temperatur

Working Humidity

Air Pressure

Dimension 325(W) x242 (D) x55mm(H)

Weight

Installation Mode

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files. Support various search engines such as time and type.

Display version information: channel amount, alarm input and output amount, system version and release date.

Multi-lever user management; various management modes Integrated management for local user, serial port user and network user. Configurable user power.

Support user /group and its corresponding rights modification. No limit to the user or group amount.

Password modification Administrator can modify other user’s password.

Account lock strategy

Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout

/shutdown/ restart.

Right authentication when shut down to make sure only those proper people can turn off DVR

≤

15W (With adapter, exclude HDD)

-10

℃－＋55℃

10%－90%

86kpa－106kpa

SMALL MINI 1U, 260mm（W）×220mm（D）×44mm（H）

Desktop installation

1.3.12 2HDD 2CIF 1U Series

Parameter

4-ch 8-ch 16-ch

≤

25W (With adapter,

exclude HDD)

Standalone DVR User’s Manual

channel

System

Compression Standard

Video monitor

Main

High-performance industrial embedded micro controller

Processor

System Resources

Embedded LINUX

Multiplex operations: Multiple-channel record, multipleplayback and network operation simultaneously

Interface User-friendly graphical user interface

Input Devices Front panel, USB mouse, remote control

Input Method

Shortcut Function

Video Compression

Audio Compression

Video Input

Arabic number, English character, donation and extension Chinese (optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click USB mouse to switch screen.

H.264

G711A, G711U, PCM

4-CH composite

video input: (NTSC/PAL) BNC (1.0VB

P- P, B

75Ω)

8-CH composite

video input: (NTSC/PAL) BNC (1.0VB

P- P, B

75Ω)

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output. 1-ch VGA output.

Video Output

1-ch HDMI output. 1-ch matrix output(Support multiple-window output mode)

Support TV/VGA/HDMI video output at the same time.

Video Standard

Support PAL/NTSC.

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s

Record Speed

per channel

16-CH composite

video input: (NTSC/PAL) BNC (1.0VB

P- P, B

75Ω)

Video Partition 1/4 windows 1/4/8/9 windows 1/4/8/9 /16 windows

Monitor Touring

Resolution (PAL/NTSC)

Image Quality 6-level image quality (Adjustable)

Privacy mask Support one privacy mask of user-defined size in full screen.

Support monitor tour functions such as alarm, motion detection, and schedule auto control.

PAL(625TVL, 50f/s)/NTSC(525TVL, 60f/s)

Real-time monitor： 960H 704×576/704×480

Playback：All-channel: 2CIF 704×288/704×240, CIF 352×288/ 352×240 , QCIF 176×144/176×120

Support dual streams. Extra stream resolution: QCIF 176×144/176×120

Support max 4 zones.

Standalone DVR User’s Manual

Audio

Hard disk

Record and playback

Image Information

TV Adjust Adjust TV output zone suitable to anamorphic video.

Channel Lock Cover secret channel with black screen though system is encoding

Channel Information

Color

Configuration

Audio Input

Audio Output

Bidirectional Audio

Hard Disk 2 built-in SATA port. Support 2 HDDs.

Hard Disk

Occupation

Recording Mode

Storage Mode Support channel record quota setup

Channel information, time information and privacy mask zone.

normally. Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

4-ch 200-2000mv 10KΩ(RCA) 1-ch audio output 200-3000mv 5KΩ(RCA)

1-ch audio talk input 200-3000mv 10KΩ（RCA）

Audio：PCM 28.8MByte/h Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and alarm recording Priority: Manual recording> alarm recording>motion detection recording>schedule recording.

8-ch 200-2000mv 10KΩ(RCA)

16-ch 200-2000mv 10KΩ(RCA)

Recording Length

Playback Repeat Way When hard disk is full, system can overwrite previous video file.

Record Search Various search engines such as time, type and channel.

Playback Mode

Various File Switch Ways

Playback Way Support mark playback

Multi-channel

Playback

Window Zoom

1 to 120 minutes single record duration (Default setup is 60 minutes)

Various fast play, slow play speeds, manual frame by frame playback and reverse play mode.

Can switch to previous or next file or any file in current play list. Can switch to file on other channel of the same time. (If there is a file)

Support file continuous play, when a file is end system auto plays the next file in the current channel.

There is 1/4/9/16-channel playback mode.

(It may vary due to different series.)

Switch between self-adaptive screen/full screen when playback

Standalone DVR User’s Manual

Alarm can activate record or external alarm or screen message prompt.

Backup function

Network Function

Motion Detection and Alarm

Interface

System Information

Partial Enlargement

Backup Mode

Network control

Motion

Detection

Video Loss Alarm can activate external alarm or screen message prompt.

External Alarm Support record activation function or activate external alarm or screen

Manual Alarm Control

Alarm Input

Alarm Output 3-channel relay output (Including one controllable 12V output)

Alarm Relay

USB Interface 2 USB 2.0 ports.

Network

connection

RS485

RS232

Hard Disk Information

Data Stream Statistics

When in one-window full-screen playback mode, you can select any zone to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk, USB burner and etc.)

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as professional surveillance software (PSS)

Duplex transparent COM

Network alarm input and output

Support zero-channel encoding function

Bidirectional audio.

Zone setup: support 396/330((PAL 22×18, NTSC 22×15)) detection

zones. Various sensitivity levels.

message in specified period.

Enable or disable alarm input channel Support analog alarm signal to specific alarm output channel.

4-ch alarm input (NO/NC.)

30V DC 2A，125V AC 1A（activation alarm ）

1 RJ45 10M/100M self-adaptable Ethernet port

PTZ control port

Support various PTZ control protocols.

Ordinary COM (Debug),keyboard connection and transparent serial port(COM input and output via network )

Display HDD current status

Data stream statistics for each channel (in wave mode)

8-ch alarm input (NO/NC.)

16-ch alarm input

（

NO/NC）

Standalone DVR User’s Manual

channel

Log statistics

Version

On-line user Display current on-line user

User Management

Password Authentication

Upgrade Web browser, client-end and update tool.

General Parameter

Power DC 12V

Power

Consumption ≤25W (With adapter, exclude HDD)

Working Temperature

Working Humidity

Air Pressure

Dimension 1U standard industrial case. 375(W) x280 (D) x50mm(H)

Weight 1.5-2.5KG(Exclude HDD)

Installation Mode

Backup to 1024 log files. Support various search engines such as time and type.

Display version information: channel amount, alarm input and output amount, system version and release date.

Multi-lever user management; various management modes Integrated management for local user, serial port user and network

user. Configurable user power.

Support user /group and its corresponding rights modification. No limit to the user or group amount.

Password modification Administrator can modify other user’s password.

Account lock strategy Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout /shutdown/ restart.

Right authentication when shut down to make sure only those proper

people can turn off DVR

℃－＋55℃

10%－90%

86kpa－106kpa

Desktop installation

1.3.13 2HDD 1U Entry-level Series

System

Parameter

Main Processor

4-ch 8-ch 16-ch

High-performance industrial embedded micro controller

System Resources

Interface User-friendly graphical user interface

Embedded LINUX

Multiplex operations: Multiple-channel record, multipleplayback and network operation simultaneously

Compression Standard

Video monitor

Standalone DVR User’s Manual

Input Devices Front panel, USB mouse, remote control

Input Method

Shortcut Function

Video Compression

Audio Compression

Video Input

Arabic number, English character, donation and extension Chinese (optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click USB mouse to switch screen.

H.264

G711A, G711U, PCM

4-CH composite

video input: (NTSC/PAL) BNC (1.0VB

P- P, B

75Ω)

8-CH composite video

input: (NTSC/PAL) BNC (1.0VB

P- P, B

75Ω)

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output. 1-ch VGA output.

Video Output

1-ch HDMI output.

1-ch matrix output 1-ch matrix output(Support multiple-window output mode) Support TV/VGA/HDMI video output at the same time.

Video Standard

Support PAL/NTSC.

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s

Record Speed

per channel

16-CH composite

video input:

(NTSC/PAL) BNC

(1.0VB

P- P, B

75Ω)

Video Partition

Monitor Touring

1/4

windows(Optional)

Support monitor tour functions such as alarm, motion detection, and schedule auto control.

1/4/8/9 windows 1/4/8/9 /16 windows

PAL(625TVL, 50f/s)/NTSC(525TVL, 60f/s)

Real-time monitor： 960H 704×576/704×480

Playback：

Resolution

(PAL/NTSC)

All-channel: 960H(704×576/704×480) D1 (704×576/704×480), HD1 (352×576/352×480), 2CIF (704×288/704×240), CIF (52×288/

352×240), QCIF (176×144/176×120)

Support dual streams. Extra stream resolution: CIF 352×288/ 352×240 QCIF 176×144/176×120

Image Quality 6-level image quality (Adjustable)

Privacy mask Support one privacy mask of user-defined size in full screen.

Support max 4 zones.

Image Information

Channel information, time information and privacy mask zone.

Standalone DVR User’s Manual

TV Adjust Adjust TV output zone suitable to anamorphic video.

Channel Lock Cover secret channel with black screen though system is encoding

normally. Screen-lock function to prevent unauthorized user seeing secret video.

Channel Information

Color Configuration

Audio Audio Input 4-ch 200-2000mv 10KΩ(RCA)

Audio Output

Channel name, recording status, screen lock status, video loss status and motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

1-ch audio output 200-3000mv 5KΩ(RCA)

Hard disk

Record and playback

Bidirectional Audio

Hard Disk 2 built-in SATA port. Support 2 HDDs.

Hard Disk Occupation

Recording Mode

Storage Mode Support channel record quota setup

Recording Length

Playback

Repeat Way When hard disk is full, system can overwrite previous video file.

Record Search Various search engines such as time, type and channel.

Playback Mode

Various File Switch Ways

Playback Way Support mark playback

1-ch audio talk input 200-3000mv 10KΩ（RCA）

Audio：PCM 28.8MByte/h Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and alarm recording

Priority: Manual recording> alarm recording>motion detection recording>schedule recording.

1 to 120 minutes single record duration (Default setup is 60 minutes)

Various fast play, slow play speeds, manual frame by frame playback and reverse play mode.

Multi-channel Playback

Window

Zoom

Partial Enlargement

Backup Backup Mode HDD backup

There is 1/4/9/16-channel playback mode. (It may vary due to different series.)

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone to activate partial enlargement function.

Standalone DVR User’s Manual

Alarm can activate record or external alarm or screen message prompt.

channel relay output

function Support peripheral USB backup device. (Flash disk, portable disk, USB

burner and etc.)

Support network download and save

Network Function

Network control

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as professional surveillance software (PSS)

Duplex transparent COM

Network alarm input and output

Support zero-channel encoding function

Bidirectional audio.

Motion Detection and Alarm

Interface

System Information

Motion

Detection

Video Loss Alarm can activate external alarm or screen message prompt.

External Alarm Support record activation function or activate external alarm or screen

Manual Alarm Control

Alarm Input

Alarm Output 3-

Alarm Relay

USB Interface 2 USB 2.0 ports.

Network connection

RS485

RS232

Hard Disk Information

Data Stream Statistics

Log statistics

Zone setup: support 396/330((PAL 22×18, NTSC 22×15)) detection

zones. Various sensitivity levels.

message in specified period.

Enable or disable alarm input channel Support analog alarm signal to specific alarm output channel.

4-ch alarm input

（

NO/NC ）

30V DC 2A，125V AC 1A（activation alarm ）

1 RJ45 10M/100M/1000M self-adaptable Ethernet port

PTZ control port

Support various PTZ control protocols.

Ordinary COM (Debug),keyboard connection and transparent serial port(COM input and output via network )

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files. Support various search engines such as time and type.

8-ch alarm input

（

NO/NC ）

16-ch alarm input

（

NO/NC ）

Standalone DVR User’s Manual

Version

On-line user Display current on-line user

User Management

User

Management

Password Authentication

Upgrade Web browser, client-end and update tool.

General Parameter

Power DC 12V

Power Consumption ≤25W (With adapter, exclude HDD)

Working Temperature

Working Humidity

Air Pressure

Dimension 1U standard industrial case. 375(W) x280 (D) x50mm(H)

Weight 1.5-2.5KG(Exclude HDD)

Installation Mode

Display version information: channel amount, alarm input and output amount, system version and release date.

Multi-lever user management; various management modes Integrated management for local user, serial port user and network

user. Configurable user power.

Support user /group and its corresponding rights modification. No limit to the user or group amount.

Password modification Administrator can modify other user’s password.

Account lock strategy Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout /shutdown/ restart.

Right authentication when shut down to make sure only those proper people can turn off DVR

℃－＋55℃

10%－90%

86kpa－106kpa

Desktop installation

1.3.14 2HDD 2CIF 1.5U Series

System

Parameter

Main

Processor

4-ch 8-ch 16-ch

High-performance industrial embedded micro controller

System Resources

Interface User-friendly graphical user interface

Input Devices

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback and network operation simultaneously

Front panel, USB mouse

Standalone DVR User’s Manual

Compression

Standard

Video monitor

Input Method

Shortcut Function

Arabic number, English character, donation and extension Chinese (optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click USB mouse to switch screen.

Video

Compression H.264

Audio Compression G711A, G711U, PCM

4-CH composite video

Video Input

input: (NTSC/PAL) BNC (1.0V

P- P,

75Ω)

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output.

Video Output

1-ch VGA output. 1-ch HDMI output. 1-ch matrix output.(Support multiple-window display mode) Support TV/VGA/HDMI video output at the same time.

Video

Standard

Record Speed

Support PAL/NTSC.

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per

channel

8-CH composite video input: (NTSC/PAL) BNC (1.0V

P- P,

75Ω)

16-CH composite

video input:

(NTSC/PAL) BNC

(1.0V

75Ω)

P- P,

Video Partition

Monitor Touring

Resolution (PAL/NTSC)

1/4 windows(Optional) 1/4/8/9 windows 1/4/8/9 /16 windows

Support monitor tour functions such as alarm, motion detection, and schedule auto control.

PAL/NTSC

Real-time monitor： D1 704×576/704×480

Standalone DVR User’s Manual

: D1

QCIF

: D1

QCIF

Image Quality

Privacy mask

Image Information

Playback： 1/2-ch 704×576/704×480,

HD1 352×576/352×480, 2CIF 704×288/704×240, CIF 352×288/

352×240, 176×144/176×120

3/4-ch: 2CIF 704×288/704×240,

CIF 352×288/ 352×240, 176×144/176×120

Note: When the main stream is D1, the extra stream can not be 2CIF.

Support dual streams: extra stream resolution QCIF 176×144/176×120.

6-level image quality (Adjustable)

Support one privacy mask of user-defined size in full screen. Support max 4 zones.

Channel information, time information and privacy mask zone.

Playback： D1 704×576/704×480,

HD1 352×576/352×480, 2CIF 704×288/704×240, CIF 352×288/

352×240, 176×144/176×120

3-8-ch: 2CIF 704×288/704×240,

CIF 352×288/ 352×240, QCI 176×144/176×120

Note: When the main stream is D1, the extra stream can not be 2CIF.

Playback：

1/2-ch

704×576/704×480,

HD1

352×576/352×480,

2CIF

704×288/704×240,

CIF 352×288/

352×240,

176×144/176×120

3-16-ch: 2CIF

704×288/704×240,

CIF 352×288/

352×240,

176×144/176×120

Note: When the main

stream is D1, the

extra stream can not

be 2CIF.

TV Adjust Adjust TV output zone suitable to anamorphic video.

Channel Lock

Channel Information

Color Configuratio n

Audio Audio Input 4-ch 200-2000mv 10KΩ(RCA)

Audio

Output

Bidirectional Audio

Hard Disk 2 built-in SATA port. Support 2 HDDs.

Cover secret channel with black screen though system is encoding normally. Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

1-ch audio output 200-3000mv 5KΩ(RCA)

1-ch audio talk input 200-3000mv 10KΩ(RCA) Reuse audio output channel

Standalone DVR User’s Manual

Hard disk

Record and playback

Hard Disk Occupation

Recording

Mode

Storage Mode

Recording Length

Playback Repeat Way

Record Search

Playback

Mode

Various File

Switch Ways

Playback Way

Multi-chann el Playback

Audio：PCM 28.8MByte/h Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and alarm recording

Priority: Manual recording> alarm recording>motion detection recording>schedule recording.

Support channel record quota setup

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and

reverse play mode.

Can switch to previous or next file or any file in current play list.

Can switch to file on other channel of the same time. (If there is a file) Support file continuous play, when a file is end system auto plays the next file in the current channel

Support mark playback

There is 1/4/9/16-channel playback mode. (It may vary due to different series.)

Backup function

Network Function

Window

Zoom

Partial Enlargemen t

Backup Mode

Network control

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk, USB burner and etc.)

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as professional surveillance software (PSS)

Duplex transparent COM

Motion Detection and Alarm

Interface

System Information

User

Management

Standalone DVR User’s Manual

Network alarm input and output

Support zero-channel encoding function

Bidirectional audio.

Motion Detection

Video Loss Alarm can activate external alarm or screen message prompt.

External

Alarm

Manual Alarm Control

Alarm Input

Alarm Output

Alarm Relay

USB Interface

Network connection

RS485

RS232

Hard Disk Information

Data Stream Statistics

Log statistics

Version

On-line user Display current on-line user

User Manageme nt

Password Authenticati

Zone setup: support 396/330((PAL 22×18, NTSC 22×15)) detection zones. Various sensitivity levels. Alarm can activate record or external alarm or screen message prompt.

Support record activation function or activate external alarm or screen

message in specified period.

Enable or disable alarm input channel Support analog alarm signal to specific alarm output channel.

4-ch alarm input

（

NO/NC ）

3-channel relay output, including one controllable DC +12V output port.

30V DC 2A，125V AC 1A（activation alarm ）

2 USB 2.0 ports.

1 RJ45 10M/100M/1000M self-adaptable Ethernet port

PTZ control port

Support various PTZ control protocols.

Ordinary COM (Debug),keyboard connection and transparent serial port(COM input and output via network )

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files. Support various search engines such as time and type.

Display version information: channel amount, alarm input and output

amount, system version and release date.

Multi-lever user management; various management modes

Integrated management for local user, serial port user and network user. Configurable user power.

Support user /group and its corresponding rights modification. No limit to the user or group amount.

Password modification Administrator can modify other user’s password.

8-ch alarm input

（

NO/NC ）

16-ch alarm input

（

NO/NC ）

Standalone DVR User’s Manual

on Account lock strategy

Five times login failure in thirty minutes may result in account lock.

Upgrade Web browser, client-end and update tool.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout

General Parameter

Power DC 12V

Power

Consumptio n

Working Temperatur e

Working Humidity

Air Pressure

Dimension 1.5U standard industrial case. 440(W) x410 (D) x70mm(H)

Weight 3.5-4.5KG(Exclude HDD)

Installation Mode

/shutdown/ restart.

Right authentication when shut down to make sure only those proper people can turn off DVR

≤25W (With adapter, exclude HDD)

℃－＋55℃

10%－90%

86kpa－106kpa

Desktop/rack installation

1.3.15 2HDD 960H 1.5U Entry-level Series

System

Parameter

Main Processor

4-ch 8-ch 16-ch

High-performance industrial embedded micro controller

Compression

Standard

System Resources

Interface User-friendly graphical user interface

Input Devices

Input Method

Shortcut

Function

Video

Compression H.264

Audio Compression G711A, G711U, PCM

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback and network operation simultaneously

Front panel, USB mouse

Arabic number, English character, donation and extension Chinese (optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click

USB mouse to switch screen.

Standalone DVR User’s Manual

Video monitor

Video Input

Video Output

Video

Standard

Record Speed

Video Partition

Monitor Touring

Resolution (PAL/NTSC)

Image Quality

Privacy

mask

Image Information

4-CH composite video input: (NTSC/PAL) BNC (1.0V

P- P,

75Ω)

8-CH composite video input: (NTSC/PAL) BNC (1.0V

P- P,

75Ω)

16-CH composite

video input:

(NTSC/PAL) BNC

(1.0V

75Ω)

P- P,

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output. 1-ch VGA output. 1-ch HDMI output. 1-ch matrix output(Support multiple-window output mode) Support TV/VGA/HDMI video output at the same time.

Support PAL/NTSC.

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per

channel

1/4 windows(Optional) 1/4/8/9 windows 1/4/8/9 /16 windows

Support monitor tour functions such as alarm, motion detection, and schedule auto control.

PAL/NTSC

Real-time monitor： 960H 960 ×576/960×480

Playback： All-channel: 960H (960 ×576/960×480) D1 704×576/704×480 , HD1 352×576/352×480, 2CIF 704×288/704×240, CIF 352×288/ 352×240 , QCIF 176×144/176×120

Support dual streams: extra stream resolution CIF 352×288/ 352×240, QCIF 176×144/176×120.

6-level image quality (Adjustable)

Support one privacy mask of user-defined size in full screen.

Support max 4 zones.

Channel information, time information and privacy mask zone.

TV Adjust Adjust TV output zone suitable to anamorphic video.

Channel Lock

Channel

Information

Color Configuratio n

Audio Audio Input 4-ch 200-2000mv 10KΩ(RCA)

Cover secret channel with black screen though system is encoding normally.

Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and

motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

Standalone DVR User’s Manual

Hard disk

Record and playback

Audio Output

Bidirectional Audio

Hard Disk 2 built-in SATA port. Support 2 HDDs.

Hard Disk Occupation

Recording Mode

Storage Mode

Recording Length

Playback Repeat Way

Record

Playback Mode

Various File Switch Ways

Playback Way

Multi-chann

el Playback

1-ch audio output 200-3000mv 5KΩ(RCA)

1-ch audio talk input 200-3000mv 10KΩ(RCA)

Audio：PCM 28.8MByte/h Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and

alarm recording Priority: Manual recording> alarm recording>motion detection recording>schedule recording.

Support channel record quota setup

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and reverse play mode.

Support mark playback

There is 1/4/9/16-channel playback mode.

(It may vary due to different series.)

Window Zoom

Partial Enlargemen t

Backup function

Network Function

Backup Mode

Network control

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk, USB burner and etc.)

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and video loss via client.

relay output

Motion Detection and Alarm

Interface

System Information

Standalone DVR User’s Manual

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as professional surveillance software (PSS)

Duplex transparent COM

Network alarm input and output

Support zero-channel encoding function

Bidirectional audio.

Motion Detection

Video Loss Alarm can activate external alarm or screen message prompt.

External

Alarm

Manual Alarm Control

Alarm Input

Alarm Output

Alarm Relay

USB Interface

Network connection

RS485

RS232

Hard Disk Information

Data Stream Statistics

Log statistics

Version

On-line user Display current on-line user

Zone setup: support 396/330((PAL 22×18, NTSC 22×15)) detection zones. Various sensitivity levels. Alarm can activate record or external alarm or screen message prompt.

Support record activation function or activate external alarm or screen

message in specified period.

Enable or disable alarm input channel Support analog alarm signal to specific alarm output channel.

4-ch alarm input

（

NO/NC ）

3-channel

30V DC 2A，125V AC 1A（activation alarm ）

2 USB 2.0 ports.

1 RJ45 10M/100M/1000M self-adaptable Ethernet port

PTZ control port

Support various PTZ control protocols.

Ordinary COM (Debug),keyboard connection and transparent serial port(COM input and output via network )

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files. Support various search engines such as time and type.

Display version information: channel amount, alarm input and output

amount, system version and release date.

8-ch alarm input

（

NO/NC ）

16-ch alarm input

（

NO/NC ）

Standalone DVR User’s Manual

User Management

Upgrade Web browser, client-end and update tool.

General

Parameter

User Manageme

Password

Authenticati on

Power DC 12V

Power Consumptio n

Working

Temperatur e

Working Humidity

Air Pressure

Dimension 1.5U standard industrial case. 440(W) x410 (D) x70mm(H)

Weight 3.5-4.5KG(Exclude HDD)

Installation Mode

Multi-lever user management; various management modes Integrated management for local user, serial port user and network user. Configurable user power.

Support user /group and its corresponding rights modification.

No limit to the user or group amount.

Password modification Administrator can modify other user’s password.

Account lock strategy Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout /shutdown/ restart.

Right authentication when shut down to make sure only those proper people can turn off DVR

≤25W (With adapter, exclude HDD)

℃－＋55℃

10%－90%

86kpa－106kpa

Desktop/rack installation

1.3.16 4HDD 960H 1.5U Entry-level Series

System

Parameter

Main Processor

4-ch series 8-ch series 16-ch series Special 16-ch

High-performance industrial embedded micro controller

(Support 16-channel loop)

System

Resources

Interface User-friendly graphical user interface

Input

Devices

Embedded LINUX

Multiplex operations: Multiple-channel record, multiple-channel playback

and network operation simultaneously

Front panel, USB mouse

Standalone DVR User’s Manual

Compression

Standard

Video monitor

Input Method

Shortcut Function

Arabic number, English character, donation and extension Chinese (optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click USB mouse to switch screen.

Video

Compression H.264

Audio Compression G711A, G711U, PCM

Video Input

4-CH composite video input: (NTSC/PAL)

BNC (1.0V

75Ω)

8-CH composite video input: (NTSC/PAL)

BNC (1.0V

P- P,

75Ω)

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output. 1-ch VGA output.

Video

Output

1-ch HDMI output.

1-ch matrix output(Support multiple-window output mode) Support TV/VGA/HDMI video output at the same time. The special 16-channel product supports 16-channel loop output.

Video Standard

Record Speed

Support PAL/NTSC.

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per channel

16-CH composite video input:

(NTSC/PAL)

P- P,

BNC (1.0V

75Ω)

16-CH composite video input:

(NTSC/PAL)

BNC (1.0V

P- P,

75Ω)

P- P,

Video Partition

Monitor Touring

1/4

windows(Option al)

Support monitor tour functions such as alarm, motion detection, and schedule auto control.

1/4/8/9 windows 1/4/8/9 /16

windows

1/4/8/9 /16

windows

PAL/NTSC

Real-time monitor： D1 704×576/704×480

Resolution

(PAL/NTSC)

Playback： All-channel: D1 704×576/704×480 , HD1 352×576/352×480, 2CIF 704×288/704×240, CIF 352×288/ 352×240 , QCIF 176×144/176×120

Support dual streams: extra stream resolution CIF 352×288/ 352×240, QCIF 176×144/176×120.


6-level image quality (Adjustable)

Quality

Privacy mask

Support one privacy mask of user-defined size in full screen. Support max 4 zones.

Standalone DVR User’s Manual

Image Information

TV Adjust Adjust TV output zone suitable to anamorphic video.

Channel Lock

Channel Information

Color Configuratio

Audio Audio Input 4-ch 200-2000mv 10KΩ(BNC)

Audio

Output

Bidirectional Audio

Hard disk

Record and

playback

Hard Disk 4 built-in SATA port. Support 4 HDDs.

Hard Disk Occupation

Recording Mode

Storage

Mode

Recording Length

Playback Repeat Way

Record Search

Playback Mode

Various File Switch

Ways

Playback Way

Multi-chann el Playback

Channel information, time information and privacy mask zone.

Cover secret channel with black screen though system is encoding normally. Screen-lock function to prevent unauthorized user seeing secret video.

Channel name, recording status, screen lock status, video loss status and motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

1-ch audio output 200-3000mv 5KΩ(BNC)

1-ch audio talk input 200-3000mv 10KΩ(BNC)

Audio：PCM 28.8MByte/h Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and alarm recording Priority: Manual recording> alarm recording>motion detection recording>schedule recording.

Support channel record quota setup

1 to 120 minutes single record duration (Default setup is 60 minutes)

When hard disk is full, system can overwrite previous video file.

Various search engines such as time, type and channel.

Various fast play, slow play speeds, manual frame by frame playback and reverse play mode.

Can switch to previous or next file or any file in current play list. Can switch to file on other channel of the same time. (If there is a file)

Support file continuous play, when a file is end system auto plays the next file in the current channel

Support mark playback

There is 1/4/9/16-channel playback mode. (It may vary due to different series.)

Standalone DVR User’s Manual

Backup function

Network Function

Motion Detection and Alarm

Interface

Window Zoom

Partial Enlargemen

Backup

Mode

Network

control

Motion

Detection

Video Loss Alarm can activate external alarm or screen message prompt.

External Alarm

Manual Alarm Control

Alarm Input

Alarm Output

Alarm Relay

USB Interface

Network connection

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk, USB

burner and etc.)

Support peripheral eSATA. Does not support disk array enclosure.

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and

video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as

professional surveillance software (PSS)

Duplex transparent COM

Network alarm input and output

Support zero-channel encoding function

Bidirectional audio.

Zone setup: support 396/330((PAL 22×18, NTSC 22×15)) detection

zones. Various sensitivity levels. Alarm can activate record or external alarm or screen message prompt.

Support record activation function or activate external alarm or screen message in specified period.

Enable or disable alarm input channel Support analog alarm signal to specific alarm output channel.

4-ch alarm input

（

NO/NC ）

3-channel relay output

30V DC 2A，125V AC 1A（activation alarm ）

2 USB 2.0 ports.

1 RJ45 10M/100M/1000M self-adaptable Ethernet port

8-ch alarm input

（

NO/NC ）

16-ch alarm

input（NO/NC

16-ch alarm

）

input（NO/NC

）

Standalone DVR User’s Manual

RS485

RS232

System

Information

User Management

Upgrade Web browser, client-end and update tool.

General

Parameter

Hard Disk

Information

Data

Stream Statistics

Log statistics

Version

On-line user Display current on-line user

User Manageme

Password Authenticati on

Power

Power Consumptio n

Working

Temperatur e

Working Humidity

Air Pressure

Dimension 1.5U standard industrial case. 440(W) x410 (D) x70mm(H)

Weight 4.5-5.5KG(Exclude HDD)

Installation Mode

PTZ control port Support various PTZ control protocols.

Ordinary COM (Debug),keyboard connection and transparent serial port(COM input and output via network )

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files. Support various search engines such as time and type.

Display version information: channel amount, alarm input and output amount, system version and release date.

Multi-lever user management; various management modes Integrated management for local user, serial port user and network user. Configurable user power.

Support user /group and its corresponding rights modification.

No limit to the user or group amount.

Password modification Administrator can modify other user’s password.

Account lock strategy Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout /shutdown/ restart.

Right authentication when shut down to make sure only those proper people can turn off DVR

AC90~264V 50+2% Hz （Max 75W）

≤25W (Exclude HDD)

℃－＋55℃

10%－90%

86kpa－106kpa

Desktop/rack installation

1.3.17 8HDD 960H 2U Entry-level Series

channel

System

Parameter

Main

Processor

4-ch series 8-ch series 16-ch series Special 16-ch

High-performance industrial embedded micro controller

Standalone DVR User’s Manual

(Support 16-channel loop)

Compression Standard

Video monitor

System Resources

Embedded LINUX

Multiplex operations: Multiple-channel record, multipleplayback and network operation simultaneously

Interface User-friendly graphical user interface

Input Devices Front panel, USB mouse

Input Method

Shortcut Function

Video

Compression

Audio Compression

Video Input

Arabic number, English character, donation and extension Chinese (optional)

Copy/paste operation, USB mouse right-key shortcut menu, double click USB mouse to switch screen.

H.264

G711A, G711U, PCM

4-CH composite video input:

(NTSC/PAL) BNC (1.0V

75Ω)

8-CH composite video input:

(NTSC/PAL)

BNC (1.0V

P- P,

75Ω)

16-CH composite video input:

(NTSC/PAL)

BNC (1.0V

P- P,

75Ω)

1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output. 1-ch VGA output.

Video Output

1-ch HDMI output.

1-ch matrix output (Support multiple-window output mode). Support TV/VGA/HDMI video output at the same time. The special 16-channel product supports 16-channel loop output.

Video Standard

Support PAL/NTSC.

Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s

Record Speed

per channel

16-CH composite video input:

(NTSC/PAL)

BNC (1.0V

P- P,

75Ω)

P- P,

Video Partition

Monitor Touring

1/4 windows(Optio

1/4/8/9 windows

1/4/8/9 /16 windows

1/4/8/9 /16

windows nal)

Support monitor tour functions such as alarm, motion detection, and schedule auto control.

Standalone DVR User’s Manual

QCIF

PAL(625TVL, 50f/s)/NTSC(525TVL, 60f/s)

Real-time monitor：

D1 704×576/704×480

Playback ： All-channel

Resolution (PAL/NTSC)

Image Quality 6-level image quality (Adjustable)

Privacy mask Support one privacy mask of user-defined size in full screen.

Image Information

TV Adjust Adjust TV output zone suitable to anamorphic video.

D1 704×576/704×480, HD1 352×576/352×480, 2CIF 704×288/704×240, CIF 352×288/ 352×240 , 176×144/176×120

Support dual streams. Extra stream resolution:

CIF 352×288/ 352×240 QCIF 176×144/176×120

Support max 4 zones.

Channel information, time information and privacy mask zone.

Channel Lock Cover secret channel with black screen though system is encoding

normally. Screen-lock function to prevent unauthorized user seeing secret video.

Channel Information

Color Configuration

Audio Audio Input 4-ch 200-2000mv 10KΩ(BNC)

Audio Output

Bidirectional Audio

Hard disk

Record and playback

Hard Disk 8 built-in SATA port. Support 8 HDDs.

Hard Disk Occupation

Recording Mode

Storage Mode Support channel record quota setup

Channel name, recording status, screen lock status, video loss status and motion detection status are shown on the bottom left of display screen.

Hue, brightness, contrast, saturation and gain setup for each channel.

1-ch audio output 200-3000mv 5KΩ(BNC)

1-ch audio talk input 200-3000mv 10KΩ（BNC）

Audio：PCM 28.8MByte/h Video：56-900MByte/h

Manual recording, motion detection recording, schedule recording and alarm recording Priority: Manual recording> alarm recording>motion detection

recording>schedule recording.

Recording

Length

1 to 120 minutes single record duration (Default setup is 60 minutes)

Standalone DVR User’s Manual

e prompt.

Playback Repeat Way When hard disk is full, system can overwrite previous video file.

Record Search Various search engines such as time, type and channel.

Playback

Mode

Various File

Switch Ways

Playback Way Support mark playback

Various fast play, slow play speeds, manual frame by frame playback

and reverse play mode.

Can switch to previous or next file or any file in current play list.

Can switch to file on other channel of the same time. (If there is a file) Support file continuous play, when a file is end system auto plays the next file in the current channel

Backup function

Network Function

Motion

Detection and Alarm

Multi-channel Playback

Window Zoom

Partial Enlargement

Backup Mode

Network control

Motion Detection

Video Loss Alarm can activate external alarm or screen message prompt.

External Alarm Support record activation function or activate external alarm or screen

There is 1/4/9/16-channel playback mode. (It may vary due to different series.)

Switch between self-adaptive screen/full screen when playback

When in one-window full-screen playback mode, you can select any zone to activate partial enlargement function.

HDD backup

Support peripheral USB backup device. (Flash disk, portable disk, USB burner and etc.)

Support peripheral eSATA. Does not support disk array enclosure.

Support network download and save

View monitor channel remotely.

DVR configuration through client-end and web browser

Upgrade via client or browser to realize remote maintenance.

View alarm information such as external alarm, motion detection and video loss via client.

Support network PTZ lens control

File download backup and playback

Multiple devices share information via corresponding software such as professional surveillance software (PSS)

Duplex transparent COM

Network alarm input and output

Support zero-channel encoding function

Bidirectional audio.

Zone setup: support 396/330((PAL 22×18, NTSC 22×15)) detection zones.

Various sensitivity levels. Alarm can activate record or external alarm or screen messag

message in specified period.

Standalone DVR User’s Manual

Manual Alarm Control

Alarm Input

Alarm Output 3-channel relay output

Alarm Relay

Interface

System Information

User Management

Upgrade Web browser, client-end and update tool.

General Parameter

USB Interface 4 USB 2.0 ports.

Network connection

RS485

RS232

Hard Disk Information

Data Stream Statistics

Log statistics

Version

On-line user Display current on-line user

User

Management

Password Authentication

Power

Consumption 25W (Exclude HDD)

Enable or disable alarm input channel Support analog alarm signal to specific alarm output channel.

4-ch alarm

input（NO/NC

30V DC 2A，125V AC 1A（activation alarm ）

1 RJ45 10M/100M/1000M self-adaptable Ethernet port

PTZ control port

Support various PTZ control protocols.

Ordinary COM (Debug),keyboard connection and transparent serial

port(COM input and output via network )

Display HDD current status

Data stream statistics for each channel (in wave mode)

Backup to 1024 log files. Support various search engines such as time and type.

Display version information: channel amount, alarm input and output amount, system version and release date.

Multi-lever user management; various management modes Integrated management for local user, serial port user and network

user. Configurable user power.

Support user /group and its corresponding rights modification. No limit to the user or group amount.

Password modification Administrator can modify other user’s password.

Account lock strategy Five times login failure in thirty minutes may result in account lock.

Password login protection to guarantee safety

User-friendly interface when login. Provide the following options: Logout /shutdown/ restart.

Right authentication when shut down to make sure only those proper people can turn off DVR

AC90~264V 50+2% Hz （Max 150W）

8-ch alarm

）

input（NO/NC

16-ch alarm

）

input（NO/NC

16-ch alarm

）

input（NO/NC

）

Standalone DVR User’s Manual

Working Temperature

Working Humidity

Air Pressure

Dimension 2U standard industrial case. 440(W) x460 (D) x89mm(H)

Weight 6.5-7.5KG(Exclude HDD)

Installation Mode

℃－＋55℃

10%－90%

86kpa－106kpa

Desktop/rack installation

Standalone DVR User’s Manual

2222 Overview and Controls

Overview and Controls

Overview and ControlsOverview and Controls

This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first.

2.1

2.1 Front Panel

Front Panel

2.12.1

Front PanelFront Panel

There is no button on the front panel of the Smart Box. There is no need to introduce the

front panel.

2.1.1 Smart 1U Series

The smart 1U series product has two kinds of panels. One front panel is shown as below. See Figure 2-1.

Figure 2-1

Please refer to the following sheet for detailed information.

SN Name Function

1 HDD status indictor light The red light becomes on when HDD is abnormal.

2 Power indicator light

The other front panel is shown as below. See Figure 2-2

Network status indicator

light

The red light becomes on when the power connection is OK.

The red light becomes on when the network

connection is abnormal.

Figure 2-2

Please refer to the following sheet for detailed information.

SN Name Function

Standalone DVR User’s Manual

2 Power indicator light

3 HDD status indictor light The red light becomes on when HDD is abnormal.

4 USB USB port

Network status indicator light

The red light becomes on when the network connection is abnormal.

The red light becomes on when the power

connection is OK.

2.1.2 Mini 1U Series

The mini 1U series product has three kinds of front panels. One front panel is shown as in Figure 2-3.

Figure 2-3

Please refer to the following sheet for front panel button information.

Name Icon Function

Power button

Up/

Down

Left/

Right

ESC ESC Go to previous menu, or cancel current operation.

Enter ENTER Confirm current operation

、

⊳ 

Power button, press this button for three seconds to boot up or shut down DVR.

Activate current control, modify setup, and then move up and

down.

Increase/decrease numeral.

Assistant function such as PTZ menu.

Shift current activated control,

When playback, click these buttons to control playback bar.

When playback, click it to restore real-time monitor mode.

Go to default button

Go to menu

Standalone DVR User’s Manual

Assistant Fn One-window monitor mode, click this button to display

assistant function: PTZ control and image color.

Backspace function: in numeral control or text control, press

it for 1.5seconds to delete the previous character before the cursor. In motion detection setup, working with Fn and direction keys to realize setup.

In text mode, click it to switch between numeral, English character(small/capitalized) and etc.

Realize other special functions.

USB port

Network abnormal indication light HDD abnormal indication light

IR Receiver IR It is to receive the signal from the remote control.

Alarm indication light

One front panel is shown as below. See Figure 2-4.

Net Network error occurs or there is no network connection, the

HDD HDD error occurs or HDD capacity is below specified

Alarm Here you can view there is external alarm input or not. The

To connect USB storage device, USB mouse.

light becomes red to alert you.

threshold value, the light becomes red to alert you.

light becomes on when there is an external alarm. The light become off when the external alarm stops.

Please refer to the following sheet for front panel button information.

Name Icon Function

Power button

Figure 2-4

Power button, press this button for three seconds to boot up or shut down DVR.

Up Down

Left Right

ESC ESC

、

⊳ 

Standalone DVR User’s Manual

Activate current control, modify setup, and then move up and down.

Increase/decrease numeral.

Assistant function such as PTZ menu.

Shift current activated control,

When playback, click these buttons to control playback bar..

Go to previous menu, or cancel current operation.

When playback, click it to restore real-time monitor mode.

Confirm current operation

Enter ENTER

Slow play

Assistant Fn

USB port

Network

abnormal indication light

Net

Go to default button

Go to menu

Multiple slow play speeds or normal playback.

One-window monitor mode, click this button to display assistant function: PTZ control and image color.

Backspace function: in numeral control or text control, press it for 1.5seconds to delete the previous character before the

In motion detection setup, working with Fn and direction keys to realize setup.

In text mode, click it to switch between numeral, English character(small/capitalized) and etc.

Realize other special functions.

To connect USB storage device, USB mouse.

Network error occurs or there is no network connection, the light becomes red to alert you.

HDD

abnormal indication light

IR Receiver IR

One front panel is shown as in Figure 2-5.

HDD

HDD error occurs or HDD capacity is below specified threshold value, the light becomes red to alert you.

It is to receive the signal from the remote control.

Standalone DVR User’s Manual

SN I

con Name

Function

SN Name

Function

indicator

Figure 2-5

Please refer to the following sheet for detailed information.

Network status indication light Power status indication light HDD status indication light

The red light becomes on when the network connection is not proper. The red light is on when the power connection is proper. The red light is on when the HDD malfunction occurred.

2.1.3 Small Mini 1U Series

The front panel is shown as in Figure 2-6.

Figure 2-6

Please refer to the following sheet for detailed information.

1 Network status

indicator light

2 Power status

light

3 HDD status

light

The red light becomes on when the network connection is not proper. The red light is on when the power connection is proper. The red light is on when the HDD malfunction occurred.

4 USB port Connect to peripheral USB mouse and etc.

2.1.4 1U Series

One front panel is shown as below. See Figure 2-7.

Standalone DVR User’s Manual

Figure 2-7

Please refer to the following sheet for front panel button information.

Name Icon Function

Power button

Shift Shift In textbox, click this button to switch between numeral,

Up/1

Down/4

Left/2 Right/3

ESC ESC Go to previous menu, or cancel current operation.

Enter ENTER Confirm current operation



、



⊳ 

Power button, press this button for three seconds to boot up or shut down DVR.

English(Small/Capitalized),donation and etc.

Activate current control, modify setup, and then move up and

down.

Increase/decrease numeral.

Assistant function such as PTZ menu.

In text mode, input number 1/4 (English character G/H/I) Shift current activated control,

When playback, click these buttons to control playback bar. In text mode, input number 2(English character A/B/C)

/3(English character D/E/F)

When playback, click it to restore real-time monitor mode.

Go to default button

Go to menu

Record REC Manually stop/start recording, working with direction keys

or numeral keys to select the recording channel.

Slow play/8

Assistant Fn One-window monitor mode, click this button to display

Multiple slow play speeds or normal playback. In text mode, input number 8 (English character T/U/V).

assistant function: PTZ control and image color.

Backspace function: in numeral control or text control, press it for 1.5seconds to delete the previous character before the cursor.

In motion detection setup, working with Fn and direction keys to realize setup.

In text mode, click it to switch between numeral, English character(small/capitalized) and etc.

Realize other special functions.

Standalone DVR User’s Manual

Fast play/7

Play

previous/0

Reverse/Pau se/6

Play Next/9 

Play/Pause /5

USB port

Network abnormal indication light





⊳



Net Network error occurs or there is no network connection, the

Various fast speeds and normal playback. In text mode, input number 7 (English character P/Q/R/S).

In playback mode, playback the previous video

In text mode, input number 0.

In normal playback or pause mode, click this button to reverse playback In reverse playback, click this button to pause playback. In text mode, input number 6 (English character M/N/O)

In playback mode, playback the next video In menu setup, go to down ward of the dropdown list. In text mode, input number 9 (English character W/X/Y/Z)

In normal playback click this button to pause playback In pause mode, click this button to resume playback. In text mode, input number 5(English character J/K/L).

To connect USB storage device, USB mouse.

light becomes red to alert you.

HDD abnormal indication

light

Record light 1-16 System is recording or not. It becomes on when system is

IR Receiver IR It is to receive the signal from the remote control.

The other front panel is shown as in Figure 2-8.

HDD HDD error occurs or HDD capacity is below specified

threshold value, the light becomes red to alert you.

recording.

Figure 2-8

Please refer to the following sheet for front panel button information.

Name Icon Function

Power button

Power button, press this button for three seconds to boot up or shut down DVR.

Standalone DVR User’s Manual

Shift Shift

Up/1 Down/4

Left/2 Right/3

ESC ESC

Enter ENTER

、

⊳ 

In textbox, click this button to switch between numeral,

English(Small/Capitalized),donation and etc.

Activate current control, modify setup, and then move up and down.

Increase/decrease numeral.

Assistant function such as PTZ menu.

In text mode, input number 1/4 (English character G/H/I)

Shift current activated control,

When playback, click these buttons to control playback bar. In text mode, input number 2(English character A/B/C) /3(English character D/E/F)

Go to previous menu, or cancel current operation.

When playback, click it to restore real-time monitor mode.

Confirm current operation

Go to default button

Record REC

Slow play/8

Assistant Fn

Fast play/7

Play previous/0





Go to menu

Manually stop/start recording, working with direction keys

or numeral keys to select the recording channel.

Click this button for at least 1.5 seconds, system can go to the Record interface.

Multiple slow play speeds or normal playback. In text mode, input number 8 (English character T/U/V).

One-window monitor mode, click this button to display assistant function: PTZ control and image color.

Backspace function: in numeral control or text control, press it for 1.5seconds to delete the previous character before the

In motion detection setup, working with Fn and direction keys to realize setup.

In text mode, click it to switch between numeral, English

character(small/capitalized) and etc.

Realize other special functions.

Various fast speeds and normal playback. In text mode, input number 7 (English character P/Q/R/S).

In playback mode, playback the previous video In text mode, input number 0.

Reverse/Pau se/6

Play Next/9

Play/Pause /5

⊳





Standalone DVR User’s Manual

In normal playback or pause mode, click this button to reverse playback

In reverse playback, click this button to pause playback.

In playback mode, playback the next video In menu setup, go to down ward of the dropdown list. In text mode, input number 9 (English character W/X/Y/Z)

In normal playback click this button to pause playback In pause mode, click this button to resume playback. In text mode, input number 5(English character J/K/L).

USB port

Network abnormal

indication light

HDD abnormal indication light

Record light 1-16

IR Receiver IR

Alarm indication

light

Net

HDD

Alarm

To connect USB storage device, USB mouse.

Network error occurs or there is no network connection, the

light becomes red to alert you.

HDD error occurs or HDD capacity is below specified threshold value, the light becomes red to alert you.

System is recording or not. It becomes on when system is recording.

It is to receive the signal from the remote control.

Here you can view there is external alarm input or not. The light becomes on when there is an external alarm. The light

become off when the external alarm stops.

2.1.5 1.5U Series

The front panel is shown as in Figure 2-9.

Please refer to the following sheet for front panel button information.

Name Icon Function

Figure 2-9

Standalone DVR User’s Manual

Power button

Shift Shift In textbox, click this button to switch between numeral,

Up/1 Down/4

Left/2

Right/3

ESC ESC Go to previous menu, or cancel current operation.

、

⊳ 

Power button, press this button for three seconds to boot up or shut down DVR.

English(Small/Capitalized),donation and etc.

Activate current control, modify setup, and then move up and down.

Increase/decrease numeral.

Assistant function such as PTZ menu.

In text mode, input number 1/4 (English character G/H/I) Shift current activated control,

When playback, click these buttons to control playback bar. In text mode, input number 2(English character A/B/C) /3(English character D/E/F)

When playback, click it to restore real-time monitor mode.

Enter ENTER Confirm current operation

Go to default button

Go to menu

Record REC Manually stop/start recording, working with direction keys

or numeral keys to select the recording channel.

Slow play/8

Assistant Fn One-window monitor mode, click this button to display

Fast play/7



Multiple slow play speeds or normal playback. In text mode, input number 8 (English character T/U/V).

assistant function: PTZ control and image color.

Backspace function: in numeral control or text control, press it for 1.5seconds to delete the previous character before the

In motion detection setup, working with Fn and direction keys

to realize setup. In text mode, click it to switch between numeral, English

character(small/capitalized) and etc.

Realize other special functions.

Various fast speeds and normal playback. In text mode, input number 7 (English character P/Q/R/S).

Play previous/0 |⊳ In playback mode, playback the previous video

In text mode, input number 0.

Standalone DVR User’s Manual

Reverse/Pause/6 ||⊳ In normal playback or pause mode, click this button to

reverse playback

In reverse playback, click this button to pause playback.

Play Next/9 ►│ In playback mode, playback the next video

In menu setup, go to down ward of the dropdown list. In text mode, input number 9 (English character W/X/Y/Z)

Play/Pause /5 ►|| In normal playback click this button to pause playback

In pause mode, click this button to resume playback. In text mode, input number 5(English character J/K/L).

USB port

Network abnormal indication light

HDD abnormal indication light

Record light 1-16 System is recording or not. It becomes on when system is

Net Network error occurs or there is no network connection, the

HDD HDD error occurs or HDD capacity is below specified

To connect USB storage device, USB mouse.

light becomes red to alert you.

threshold value, the light becomes red to alert you.

recording.

2.1.6 2U Series

This series products’ front panel is shown as below. See Figure 2-10.

Figure 2-10

Please refer to the following sheet for front panel button information.

Name Icon Function

Power button 

Number button 0-9

Input number more than 10

Shift

-/--



Power button, press this button for three seconds to boot up or

shut down DVR.

Input Arabic number Switch channel

If you want to input a number more than 10, please click this button and then input.

In textbox, click this button to switch between numeral, English(Small/Capitalized),donation and etc.

Enable or disable tour.

Standalone DVR User’s Manual

Fast play

Slow play

Play/Pause

Reverse/Pause

Play previous |⊳

Play Next |

Up/ Down

Left/ Right





⊳⊳⊳⊳

、

⊳ 

Various fast speeds and normal playback.

Multiple slow play speeds or normal playback.

In normal playback click this button to pause playback In pause mode, click this button to resume playback.

In normal playback or pause mode, click this button to reverse

playback In reverse playback, click this button to pause playback.

In playback mode, playback the previous video

In playback mode, playback the next video In menu setup, go to down ward of the dropdown list.

Activate current control, modify setup, and then move up and down.

Increase/decrease numeral.

Assistant function such as PTZ menu.

Shift current activated control, and then move left and right.

When playback, click these buttons to control playback bar.

ESC ESC

Enter ENTER

Assistant Fn

Go to previous menu, or cancel current operation.

When playback, click it to restore real-time monitor mode.

Confirm current operation

Go to default button

Go to menu

One-window monitor mode, click this button to display assistant

function: PTZ control and image color.

Backspace function: in numeral control or text control, press it for

1.5 seconds to delete the previous character before the cursor.

In motion detection setup, working with Fn and direction keys to

realize setup.

In text mode, click it to switch between numeral, English character(small/capitalized) and etc.

In HDD management interface, you can click it to switch HDD record information and other information (Menu prompt)

Realize other special functions.

Standalone DVR User’s Manual

Record REC

Window switch

Shuttle(outer

ring)

Jog(inner dial)

USB port

Record light 1-32

Mult

Manually stop/start recording, working with direction keys or numeral keys to select the recording channel.

Click it to switch one-window/multiple-window.

In real-time monitor mode it works as left/right direction key.

Playback mode, counter clockwise to forward and clock wise to backward.

Up/down direction key. Playback mode, turn the inner dial to realized frame by frame playback. (Only applies to some special versions.)

To connect USB storage device, USB mouse, burner and etc.

For 4/8/16 channel device: indication light on means that the channel is in recording.

For 32 channel device:

Indication Light on: 1-16 channel is in recording Indication Light flashes: 17-32 channel is in recording Indication Light normally on: the corresponding channels are in recording

Remote control

indication light

Status indication light

Power indication light

IR Receiver IR It is to receive the signal from the remote control.

2.2

2.2 Rear Panel

Rear Panel

2.22.2

Rear PanelRear Panel

ACT Remote control indication light

Status The light is on if device operates properly.

PWR Power indication light

2.2.1 Smart Box Series

The rear panel is shown as below. See Figure 2-11.

Standalone DVR User’s Manual

Figure 2-11

Please refer to the following sheet for detailed information.

1 Video input

2 USB port

3 Network port

4 HDMI port

5 Video VGA output

6 Power socket

7 Audio input

8 Audio/Video output

2.2.2 General 2CIF Mini 1U / General 960H Mini 1U Series

The 4-channel series rear panel is shown as below. See Figure 2-12.

The 8-channel general 2CIF mini 1U series rear panel is shown as below. See Figure 2-13.

Figure 2-12

Standalone DVR User’s Manual

Figure 2-13

The 16-channel general 2CIF mini 1U series rear panel is shown as below. See Figure

2-14.

Figure 2-14

Please refer to the following sheet for detailed information.

1 Video input

2 Video output

3 Audio output

4 Audio input

5 Video VGA output

6 HDMI port

7 USB port

8 Network port

9 RS-485 port

10 Power socket

11 On/off button

12 GND port

2.2.3 Enhanced 2CIF Mini 1U / Enhanced 960H Mini 1U Series

The 4-channel series rear panel is shown as in Figure 2-15.

The 8-channel enhanced 2CIF mini 1U series rear panel is shown as in Figure 2-16.

Figure 2-15

Standalone DVR User’s Manual

Figure 2-16

Please refer to the following sheet for detailed information.

1 Video input

2 Audio input

3 Audio output

4 Video output

5 Video VGA output

6 HDMI port

7 USB port

8 Network port

9 RS-485 port

10 Power socket

11 On/off button

12 Alarm input/alarm output

13 GND port

The 16-channel enhanced 2CIF mini 1U series rear panel is shown as in Figure 2-17.

Figure 2-17

Please refer to the following sheet for detailed information.

1 Video input

2 Audio input

3 Audio output

4 Video output

5 Alarm input/alarm output

6 Video VGA output

7 HDMI port

8 USB port

Dahua JRC-27F User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
