Dahua HDCVI Standalone DVR User’s Manual
Dahua HDCVI Standalone DVR User’s Manual
V1.8.2
i
Table of Contents
1 FEATURES AND SPECIFICATIONS ....................................................... 1
1.1 Overview ................................................................................................................................... 1
1.2 Features .................................................................................................................................... 1
1.3 Specifications ........................................................................................................................... 2
1.3.1 HCVR5104C Series ........................................................................................................... 2
1.3.2 HCVR51XXC-V2 Series .................................................................................................... 6
1.3.3 HCVR7104C-V2 Series ..................................................................................................... 8
1.3.4 HCVR410XC-S2 Series ..................................................................................................... 9
1.3.5 HCVR510XC-S2 Series ................................................................................................... 11
1.3.6 HCVR7104C-S2 Series ................................................................................................... 12
1.3.7 HCVR2108C-S2 Series ................................................................................................... 13
1.3.8 HCVR410XC-S3 Series ................................................................................................... 15
1.3.9 HCVR510XC-S3 Series ................................................................................................... 16
1.3.10 HCVR7104C-S3 Series............................................................................................... 18
1.3.11 HCVR51XXH Series .................................................................................................... 19
1.3.12 HCVR51XXH-V2 Series .............................................................................................. 23
1.3.13 HCVR51XXHC Series ................................................................................................. 25
1.3.14 HCVR51XXHC-V2 Series ........................................................................................... 29
1.3.15 HCVR51XXHE Series ................................................................................................. 30
1.3.16 HCVR51HE-V2 Series ................................................................................................ 34
1.3.17 HCVR71XXH-V2 Series .............................................................................................. 36
1.3.18 HCVR71XXHC-V2 Series ........................................................................................... 37
1.3.19 HCVR71XHE-V2 Series .............................................................................................. 38
1.3.20 HCVR41XXHE-S2 Series ........................................................................................... 40
1.3.21 HCVR51XXH-S2 Series .............................................................................................. 41
1.3.22 HCVR51XXHE-S2 Series ........................................................................................... 43
1.3.23 HCVR710XH-S2 Series .............................................................................................. 44
1.3.24 HCVR710XHE-S2 Series ........................................................................................... 45
1.3.25 HCVR41XXHE-S3 Series ........................................................................................... 47
1.3.26 HCVR51XXHE-S3 Series ........................................................................................... 48
1.3.27 HCVR71XXHE-S3 Series ........................................................................................... 50
1.3.28 HCVR71XXH-S3 Series .............................................................................................. 52
1.3.29 HCVR41XXHS-S2 Series ........................................................................................... 54
1.3.30 HCVR21XXHS-S2 Series ........................................................................................... 56
1.3.31 HCVR21XXHS-S3 Series ........................................................................................... 57
ii
1.3.32 HCVR41XXHS-S3 Series ........................................................................................... 58
1.3.33 HCVR51XXHS-S3 Series ........................................................................................... 60
1.3.34 HCVR71XXHS-S3 Series ........................................................................................... 62
1.3.35 HCVR52XXA-V2 Series .............................................................................................. 64
1.3.36 HCVR72XXA-V2 Series .............................................................................................. 65
1.3.37 HCVR42XXA-S2/4216AN-S2 Series ........................................................................ 66
1.3.38 HCVR4224/4232AN-S2 Series .................................................................................. 67
1.3.39 HCVR52XXA-S2/HCVR5216AN-S2 Series ............................................................. 69
1.3.40 HCVR720XA-S2 Series .............................................................................................. 70
1.3.41 HCVR42XXA-S3 Series .............................................................................................. 72
1.3.42 HCVR42XXAN-S3 Series ........................................................................................... 74
1.3.43 HCVR52XXA-S3 Series .............................................................................................. 76
1.3.44 HCVR52XXAN-S3 Series ........................................................................................... 78
1.3.45 HCVR72XXA-S3/HCVR7216AN-S3 Series ............................................................. 79
1.3.46 HCVR52XXL-V2 Series .............................................................................................. 82
1.3.47 HCVR54XXL-V2 Series .............................................................................................. 83
1.3.48 HCVR4224/32L-S2 Series .......................................................................................... 85
1.3.49 HCVR44XXL-S2 Series .............................................................................................. 86
1.3.50 HCVR48XXS-S2 Series .............................................................................................. 89
1.3.51 HCVR58XXS-V2 Series .............................................................................................. 92
1.3.52 HCVR71XXH-4M Series ............................................................................................. 93
1.3.53 HCVR72XXAN-4M Series .......................................................................................... 95
1.3.54 XVR410XC Series ....................................................................................................... 97
1.3.55 XVR510XC Series ....................................................................................................... 98
1.3.56 XVR7104C Series ...................................................................................................... 100
1.3.57 XVR41XXHE Series .................................................................................................. 101
1.3.58 XVR51XXH Series ..................................................................................................... 103
1.3.59 XVR51XXHE Series .................................................................................................. 105
1.3.60 XVR71XXHE Series .................................................................................................. 107
1.3.61 XVR71XXH Series ..................................................................................................... 109
1.3.62 XVR21XXHS Series .................................................................................................. 111
1.3.63 XVR41XXHS Series .................................................................................................. 113
1.3.64 XVR51XXHS Series .................................................................................................. 114
1.3.65 XVR7104HS Series ................................................................................................... 116
1.3.66 XVR42XXA Series ..................................................................................................... 118
1.3.67 XVR42XXAN Series .................................................................................................. 120
1.3.68 XVR52XXA Series ..................................................................................................... 122
1.3.69 XVR52XXAN Series .................................................................................................. 124
1.3.70 XVR72XXA Series ..................................................................................................... 126
1.3.71 XVR72XXAN Series .................................................................................................. 128
2 OVERVIEW AND CONTROLS ................................ ............................. 131
iii
2.1 Front Panel ........................................................................................................................... 131
2.1.1 HCVR5104C/HCVR51XXC-V2/HCVR71XXC-V2/ HCVR4104/4108C-S2/
HCVR5104 5108C-S2/ HCVR7104C-S2/ HCVR2108C-S2/
HCVR410XC-S3/HCVR510XC-S3/7104C-S3/ XVR410XC/XVR510XC/7104C Series ..... 131
2.1.2 HCVR51XXH/HCVR51XXHE/ HCVR51XXH-V2 /
HCVR51XXHE-V2/HCVR71XXH-V2 / HCVR71XXHE-V2 Series ......................................... 131
2.1.3 HCVR51XXHC/ HCVR51XXHC-V2/ HCVR71XXHC-V2 Series .............................. 132
2.1.4 HCVR41XXHE-S2/ HCVR51XXH-S2/ HCVR51XXHE-S2/ HCVR710XH-S2/
HCVR710XHE-S2/
HCVR41XXHE-S3/HCVR51XXHE-S3/HCVR71XXH-S3/HCVR71XXHE-S3
/HCVR41XXHS-S2/ HCVR21XXHS-S2/
HCVR21XXHS-S3/HCVR41XXHS-S3/51XXHS-S3/7104HS-S3/
XVR41XXHE/XVR51H/XVR51XXHE/XVR71XXH/XVR71XXHE /HCVR41XXHS-S2/
HCVR21XXHS-S2/ XVR21XXHS/XVR41XXHS/51XXHS/7104HS/HCVR71XX-4M Series
133
2.1.5 HCVR52XXA-V2/ HCVR72XXA-V2 Series ................................................................. 134
2.1.6 HCVR42XXA-S2/ HCVR42XXAN-S2/ HCVR52XXA-S2/
HCVR5216AN-S2/HCVR720XA-S2/
HCVR42XXA-S3/HCVR42XXAN-S3/HCVR52XXA-S3/HCVR52XXAN-S3/HCVR72XXA-S3
/HCVR7216AN-S3/XVR42XXA/XVR42XXAN/XVR52XXA/XVR52XXAN/XVR72XXA/XVR7
216AN/HCVR 72XXAN-4M Series ............................................................................................. 135
2.1.7 HCVR42XXL-S2/HCVR44XXL-S2 Series ................................................................... 136
2.1.8 HCVR52XXL-V2/ HCVR54XXL-V2 Series.................................................................. 137
2.1.9 HCVR58XXS-V2 Series ................................................................................................. 138
2.1.10 HCVR48XXS-S2 Series ............................................................................................ 141
2.2 Rear Panel ............................................................................................................................ 141
2.2.1 HCVR5104C Series ....................................................................................................... 141
2.2.2 HCVR5104C-V2/HCVR5108C-V2 Series ................................................................... 142
2.2.3 HCVR7104C-V2 Series ................................................................................................. 144
2.2.4 HCVR4104/HCVR4108C-S2/HCVR2108C-S2 Series .............................................. 145
2.2.5 HCVR5104/5108C-S2 Series ....................................................................................... 146
2.2.6 HCVR7104C-S2 Series ................................................................................................. 147
2.2.7 HCVR410XC-S3/HCVR510XC-S3/7104C-S3/XVR410XC/XVR510XC/7104C
Series 148
2.2.8 HCVR5104H/HCVR5108H Series ............................................................................... 150
2.2.9 HCVR5104H-V2/HCVR5108H-V2/HCVR5116H-V2 Series ..................................... 151
2.2.10 HCVR5104HC/HCVR5108HC Series ..................................................................... 153
2.2.11 HCVR5104HC-V2/HCVR5108HC-V2/HCVR5116HC-V2 Series........................ 154
2.2.12 HCVR5104HE/HCVR5108HE Series ..................................................................... 156
2.2.13 HCVR5104HE-V2/HCVR5108HE-V2/HCVR5116HE-V2 Series ........................ 157
2.2.14 HCVR7104H-V2/HCVR7108H-V2 Series .............................................................. 159
2.2.15 HCVR7104HC-V2/HCVR7108HC-V2 Series ......................................................... 161
iv
2.2.16 HCVR7104HE-V2/HCVR7108HE-V2 Series ......................................................... 162
2.2.17 HCVR4104/4108/4116HE-S2 Series ...................................................................... 164
2.2.18 HCVR5104/5108/5116H-S2 Series ......................................................................... 166
2.2.19 HCVR5104/5108/5116HE-S2 Series ...................................................................... 168
2.2.20 HCVR7104/7108H-S2 Series ................................................................................... 170
2.2.21 HCVR7104/7108HE-S2 Series ................................................................................ 172
2.2.22 HCVR41XXHE-S3/HCVR51XXHE-S3/HCVR71XXH-S3/HCVR71XXHE-S3
/XVR41XXHE/XVR51XXH/XVR51XXHE/XVR71XXH/XVR71XXHE Series ........................ 174
2.2.23 HCVR41XXHS-S2/ HCVR2108HS-S2/ HCVR2116HS-S2 Series ..................... 176
2.2.24 HCVR21XXHS-S3/HCVR41XXHS-S3/51XXHS-S3/7104HS-S3
/XVR21XXHS/XVR41XXHS/51XXHS/7104HS Series ............................................................ 178
2.2.25 HCVR52XXA-V2/ HCVR72XXA-V2 Series ............................................................ 180
2.2.26 HCVR42XXA-S2/ HCVR4216AN-S2 Series .......................................................... 181
2.2.27 HCVR4224/HCVR4232AN-S2 Series ..................................................................... 183
2.2.28 HCVR52XXA-S2/ HCVR5216AN-S2 Series .......................................................... 184
2.2.29 HCVR720XA-S2 Series ............................................................................................ 186
2.2.30
HCVR42XXA-S3/HCVR42XXAN-S3/HCVR52XXA-S3/HCVR52XXAN-S3/HCVR
72XXA-S3/HCVR7216AN-S3/XVR42XXA/XVR42XXAN/XVR52XXA/XVR52XXAN/XVR72X
XA/XVR7216AN Series ................................................................................................................ 188
2.2.31 HCVR52XXL-V2/ HCVR54XXL-V2/HCVR44L-S2 Series .................................... 190
2.2.32 HCVR42XXL-S2 Series ............................................................................................ 193
2.2.33 HCVR58XXS-V2/HCVR48XXS-S2 Series ............................................................. 195
2.2.34 HCVR71XXH-4M Series ........................................................................................... 198
2.2.35 HCVR72XXAN-4M Series ........................................................................................ 199
2.3 Connection Sample ............................................................................................................. 200
2.3.1 Smart Box Series ............................................................................................................ 200
2.3.2 Smart 1U Series .............................................................................................................. 201
2.3.3 Compact 1U Series ........................................................................................................ 202
2.3.4 Mini 1U Series ................................................................................................................. 203
2.3.5 1U Series ......................................................................................................................... 203
2.3.6 1.5U Series ................................................................ ................................ ...................... 204
2.3.7 2U Series ......................................................................................................................... 205
2.4 Remote Control .................................................................................................................... 206
2.5 Mouse Control ...................................................................................................................... 208
2.6 Virtual Keyboard & Front Panel ......................................................................................... 210
2.6.1 Virtual Keyboard ............................................................................................................. 210
v
2.6.2 Front Panel ...................................................................................................................... 210
3 INSTALLATION AND CONNECTIONS ................................................ 211
3.1 Check Unpacked DVR ........................................................................................................ 211
3.2 About Front Panel and Rear Panel ................................................................................... 211
3.3 HDD Installation ................................................................................................................... 211
3.3.1 Smart Box Series ............................................................................................................ 211
3.3.2 Smart 1U Series .............................................................................................................. 212
3.3.3 Compact 1U and Mini 1U Series .................................................................................. 213
3.3.4 The 1U Series ................................................................................................................. 214
3.3.5 The 1.5U Series .............................................................................................................. 215
3.3.6 The 2U Series ................................................................................................................. 216
3.3.7 Rack Installation .............................................................................................................. 216
3.4 Connecting Power Supply .................................................................................................. 217
3.5 Connecting Video Input and Output Devices .................................................................. 217
3.5.1 Connecting Video Input.................................................................................................. 217
3.5.2 Connecting Video Output .............................................................................................. 217
3.6 Connecting Audio Input & Output, Bidirectional Audio .................................................. 218
3.6.1 Audio Input ....................................................................................................................... 218
3.6.2 Audio Output .................................................................................................................... 218
3.7 Alarm Input and Output Connection ................................................................................. 218
3.7.1 Alarm Input and Output Details .................................................................................... 219
3.7.2 Alarm Input Port .............................................................................................................. 220
3.7.3 Alarm Output Port ........................................................................................................... 220
3.8 RS485 ................................................................................................................................... 221
3.9 Other Interfaces ................................................................................................................... 221
vi
4 OVERVIEW OF NAVIGATION AND CONTROLS ................................ 222
4.1 Boot up and Shutdown ....................................................................................................... 222
4.1.1 Boot up ............................................................................................................................. 222
4.1.2 Shutdown ......................................................................................................................... 222
4.1.3 Auto Resume after Power Failure ................................................................................ 222
4.1.4 Replace Button Battery .................................................................................................. 222
4.2 Set/Reset Password............................................................................................................ 222
4.2.1 Set Password .................................................................................................................. 223
4.2.2 Reset Password .............................................................................................................. 224
4.3 Startup Wizard ..................................................................................................................... 224
4.4 Live Viewing ......................................................................................................................... 230
4.5 Right-Click Menu ................................................................................................................. 232
4.5.1 Window Switch ................................................................................................................ 233
4.5.2 Previous Screen/Next Screen ....................................................................................... 234
4.5.3 PTZ Control ..................................................................................................................... 234
4.5.4 Auto Focus ....................................................................................................................... 239
4.5.5 Color ................................................................................................................................. 239
4.5.6 Display ................................ ................................ ................................ .............................. 241
4.5.7 Face Search .................................................................................................................... 242
4.5.8 Search .............................................................................................................................. 242
4.5.9 Record Control ................................................................................................................ 242
4.5.10 Alarm Output ............................................................................................................... 242
4.5.11 Remote Device ........................................................................................................... 242
4.5.12 Video Matrix ................................................................................................................ 242
4.5.13 Main menu .................................................................................................................. 242
4.6 Navigation Bar ..................................................................................................................... 242
4.6.1 Main Menu ....................................................................................................................... 243
4.6.2 Output Screen ................................................................................................................. 243
4.6.3 Previous/Next Screen .................................................................................................... 243
4.6.4 Tour ................................................................................................................................... 243
4.6.5 Favorites .......................................................................................................................... 243
4.6.6 Channel ............................................................................................................................ 243
4.6.7 PTZ ................................................................................................................................... 243
vii
4.6.8 Color ................................................................................................................................. 243
4.6.9 Search .............................................................................................................................. 243
4.6.10 Alarm Status ............................................................................................................... 243
4.6.11 Channel Info ............................................................................................................... 244
4.6.12 Remote Device ........................................................................................................... 244
4.6.13 Network ....................................................................................................................... 244
4.6.14 HDD Manager ............................................................................................................. 244
4.6.15 USB Manager ............................................................................................................. 244
4.7 USB Device Auto Pop-up ................................................................................................... 245
4.8 Main Menu ............................................................................................................................ 245
4.9 Operation .............................................................................................................................. 246
4.9.1 Search .............................................................................................................................. 246
4.9.2 Human Face Search ...................................................................................................... 255
4.9.3 Backup.............................................................................................................................. 256
4.9.4 Shut Down ....................................................................................................................... 258
4.10 Information ............................................................................................................................ 259
4.10.1 System Info ................................................................................................................. 259
4.10.2 Event ............................................................................................................................ 265
4.10.3 Network ....................................................................................................................... 266
4.10.4 Log ............................................................................................................................... 268
4.11 Setting ................................................................................................................................... 270
4.11.1 Camera ........................................................................................................................ 270
4.11.2 Network ....................................................................................................................... 287
4.11.3 Event ............................................................................................................................ 306
4.11.4 Storage ........................................................................................................................ 333
4.11.5 System ......................................................................................................................... 346
5 WEB OPERATION ............................................................................... 372
5.1 Network Connection ............................................................................................................ 372
5.2 Login ...................................................................................................................................... 372
viii
5.3 LAN Mode ............................................................................................................................. 374
5.4 Real-time Monitor ................................................................................................................ 376
5.5 PTZ ........................................................................................................................................ 377
5.6 Image/Relay-out .................................................................................................................. 378
5.6.1 Image ................................................................................................................................ 378
5.6.2 Relay output .................................................................................................................... 379
5.7 WAN Login ........................................................................................................................... 379
5.8 Setup ..................................................................................................................................... 380
5.8.1 Camera ............................................................................................................................. 380
5.8.2 Network ............................................................................................................................ 389
5.8.3 Event ................................................................................................................................. 405
5.8.4 Storage ............................................................................................................................. 425
5.8.5 Setting .............................................................................................................................. 429
5.9 Information ............................................................................................................................ 447
5.9.1 Version ............................................................................................................................. 447
5.9.2 Log .................................................................................................................................... 448
5.9.3 Online User ...................................................................................................................... 449
5.9.4 HDD .................................................................................................................................. 449
5.10 Playback ............................................................................................................................... 449
5.10.1 Search Record............................................................................................................ 450
5.10.2 File List ........................................................................................................................ 451
5.10.3 Playback ...................................................................................................................... 452
5.10.4 Download .................................................................................................................... 452
5.10.5 Load more ................................................................................................ ................... 453
5.11 Face Search ......................................................................................................................... 455
5.12 Alarm ..................................................................................................................................... 456
ix
5.13 Log out .................................................................................................................................. 457
5.14 Un-install Web Control ........................................................................................................ 458
6 PROFESSIONAL SURVEILLANCE SYSTEM ...................................... 459
7 FAQ ...................................................................................................... 460
APPENDIX A HDD CAPACITY CALCULATION ....................................... 468
APPENDIX B COMPATIBLE BACKUP DEVICES ....................................... 470
Appendix B-1 Compatible USB list ............................................................................................... 470
Appendix B-2 Compatible SD Card list ....................................................................................... 471
Appendix B-3 Compatible Portable HDD list .............................................................................. 471
Appendix B-4 Compatible USB DVD List ................................................................................... 471
Appendix B-5 Compatible SATA DVD List .................................................................................. 471
Appendix B-6 Compatible SATA HDD List ................................................................................. 472
APPENDIX C COMPATIBLE CD/DVD BURNER LIST ............................. 476
APPENDIX D COMPATIBLE DISPLAYER LIST ....................................... 477
APPENDIX E COMPATIBLE SWITCHER ................................................... 478
x
APPENDIX F COMPATIBLE WIRELESS MOUSE LIST ........................... 479
APPENDIX G EARTHING ......................................................................... 480
xi
Welcome
Thank you for purchasing our HDCVI DVR!
This user’s manual is designed to be a reference tool for the installation and operation of
your system.
Here you can find information about this series standalone DVR features and functions, as
well as a detailed menu tree.
Before installation and operation please read the following safeguards and warnings
carefully!
xii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The product must be grounded to reduce the risk of electric shock.
We assume no liability or responsibility for all the fires or electrical shock caused by
improper handling or installation.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation,
storage and installation.
3．Installation
Keep upwards. Handle with care.
Do not apply power to the DVR before completing installation.
Do not place objects on the DVR.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted
repair.
5．Environment
The DVR should be installed in a cool, dry place away from direct sunlight, inflammable,
explosive substances and etc.
6. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
7. Lithium battery
Improper battery use may result in fire, explosion, or personal injury!
When replace the battery, please make sure you are using the same model!
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
CAUTION
FOR YOUR OWN SAFETY, PLEASE CHANGE SYSTEM DEFAULT PASSWORD
AFTER YOU FIRST LOGIN!
1
1 FEATURES AND SPECIFICATIONS
1.1 Overview
The standalone series DVR is an excellent digital monitor product designed for security
field.
It adopts embedded Linux OS to maintain reliable operation. Popular H.264 compression
algorithm and G.711 audio compression technology realize high quality, low bit stream.
Unique frame by frame play function is suitable for detailed analysis. It has various
functions such as record, playback, monitor at the same time and can guarantee audio
video synchronization. This series product has advanced technology and strong network
data transmission function.
This series device adopts embedded design to achieve high security and reliability. It can
work in the local end, and at the same time, when connecting it to the professional
surveillance software (PSS), it can connect to the security network to realize strong
network and remote monitor function.
This series product can be widely used in various areas such as banking,
telecommunication, electric power, interrogation, transportation, intelligent resident zone,
factory, warehouse, resources, and water conservancy.
1.2 Features
This series product has the following features:
Real-time surveillance
Support VGA port and HDMI port. Realize the surveillance through displayer. Support
HDMI, VGA, and TV output at the same time.
Storage function
Special data format to guarantee data security and can remove the risk of the vicious data
modification. Support digital watermark.
Compression format
Support multiple-channel audio and video. An independent hardware decodes the audio
and video signal from each channel to maintain video and audio synchronization.
Backup function
Support backup operation via USB port (such as U disk, portable HDD, burner)
Client-end user can download the file to local HDD to backup via network.
Record & playback function
2
Support each channel real-time record independently, and at the same time it can support
Parameter
HCVR5104C
System
Main
Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
System
Resources
Multiplex operations: Multiple-channel record, multiple-channel playback
and network operation simultaneously
Interface
User-friendly graphical user interface
search, forward play, network monitor, record search, download and etc.
Support various playback modes: slow play, fast play, backward play and frame by frame
play.
Support time title overlay so that you can view event accurate occurred time
Support customized zoom function during the preview.
Network operation
Support network remote real-time monitor, remote record search and remote PTZ control.
Alarm activation function
Several relay alarm outputs to realize alarm activation and on-site light control.
The alarm input port and output has the protection circuit to guarantee device safety.
Communication port
RS485 port can realize alarm input and PTZ control.
RS232 port can connect to keyboard to realize central control, and can also connect to PC
COM to upgrade system and realize maintenance, and matrix control.
Standard Ethernet port can realize network access function.
The dual-network port has the multiple-access, fault-tolerance, load-balance setup mode.
PTZ control
Support PTZ decoder via RS485.
Intelligent operation
Mouse operation function
In the menu, support copy and paste setup function
UPNP (Universal Plug and Play)
Establish mapping connection between LAN and WAN via UPNP protocol.
Slight function differences may be found due to different series.
1.3 Specifications
1.3.1 HCVR5104C Series
3
Input
Devices
USB mouse
Input
Method
Arabic number, English character, donation and extension Chinese
(optional)
Shortcut
Function
Copy/paste operation, USB mouse right-key shortcut menu, double click
USB mouse to switch screen.
Compression
Standard
Video
Compressio
n
H.264
Audio
Compressio
n
G711A, G711U, PCM
Video monitor
Video Input
4-CH composite video input: (NTSC/PAL) BNC (1.0VB
P- P,
B75Ω)
Video
Output
1-ch VGA output.
1-ch HDMI output.
Support VGA/HDMI video output at the same time.
Video
Standard
Support PAL/NTSC.
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per
channel
Video
Partition
1/4 windows(Optional)
Monitor
Touring
Support monitor tour functions such as motion detection, and schedule
auto control.
Resolution
(PAL/NTSC)
PAL/NTSC
Real-time monitor：
720P 1280*720
Playback：
All-ch: 720P 1280*720, 960H 960 ×576/960×480, D1
704×576/704×480, HD1 352×576/352×480, 2CIF 704×288/704×240,
CIF 352×288/ 352×240 , QCIF 176×144/176×120
Support dual streams: extra stream resolution CIF 352×288/ 352×240,
QCIF 176×144/176×120.
Quality
6-level image quality (Adjustable)
Privacy
mask
Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Information
Channel information, time information and privacy mask zone.
TV Adjust
Adjust TV output zone suitable to anamorphic video.
4
Channel
Lock
Cover secret channel with black screen though system is encoding
normally.
Screen-lock function to prevent unauthorized user seeing secret video.
Channel
Information
Channel name, recording status, screen lock status, video loss status and
motion detection status are shown on the bottom left of display screen.
Color
Configuratio
n
Hue, brightness, contrast, saturation and gain setup for each channel.
Audio
Audio Input
N/A
Audio
Output
N/A
Bidirectional
Audio
N/A
Hard disk
Hard Disk
1 built-in SATA port. Support 1 HDD.
One HDD
Space
4T
Hard Disk
Occupation
Audio：PCM 28.8MByte/h
Video：56-900MByte/h
Record and
playback
Recording
Mode
Manual recording, motion detection recording, schedule recording and
alarm recording
Priority: Manual recording> alarm recording>motion detection
recording>schedule recording.
Storage
Mode
Support channel record quota setup
Recording
Length
1 to 120 minutes single record duration (Default setup is 60 minutes)
Playback
Repeat Way
When hard disk is full, system can overwrite previous video file.
Record
Search
Various search engines such as time, type and channel.
Playback
Mode
Various fast play, slow play speeds, manual frame by frame playback and
reverse play mode.
Various File
Switch
Ways
Can switch to previous or next file or any file in current play list.
Can switch to file on other channel of the same time. (If there is a file)
Support file continuous play, when a file is end system auto plays the next
file in the current channel
Playback
Way
Support mark playback
Multi-chann
el Playback
There is 1/4-channel playback mode.
Window
Zoom
Switch between self-adaptive screen/full screen when playback
5
Partial
Enlargemen
t
When in one-window full-screen playback mode, you can select any zone
to activate partial enlargement function.
Backup
function
Backup
Mode
HDD backup
Support peripheral USB backup device. (Flash disk, portable disk and
etc.)
Support peripheral USB burner.
Support network download and save
Network
Function
Network
control
View monitor channel remotely.
DVR configuration through client-end and web browser
Upgrade via client or browser to realize remote maintenance.
View alarm information such as motion detection and video loss via client.
Support network PTZ lens control
File download backup and playback
Multiple devices share information via corresponding software such as
professional surveillance software (PSS)
Duplex transparent COM
Network alarm input and output
Zero-channel encoding
Bidirectional audio.
Motion
Detection and
Alarm
Motion
Detection
Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.
Various sensitivity levels.
Alarm can activate record or external alarm or screen message prompt.
Video Loss
Alarm can activate screen message prompt.
External
Alarm
N/A
Manual
Alarm
Control
N/A
Alarm Input
N/A
Alarm
Output
N/A
Alarm Relay
N/A
Interface
USB
Interface
2 USB 2.0 port.
Network
connection
1 RJ45 10M/100M self-adaptable Ethernet port
RS485
N/A
RS232
N/A
System
Information
Hard Disk
Information
Display HDD current status
6
Data
Stream
Statistics
Data stream statistics for each channel (in wave mode)
Log
statistics
Backup to 1024 log files.
Support various search engines such as time and type.
Version
Display version information: channel amount, system version and release
date.
On-line user
Display current on-line user
User
Management
User
Manageme
nt
Multi-lever user management; various management modes
Integrated management for local user, serial port user and network user.
Configurable user power.
Support user /group and its corresponding rights modification.
No limit to the user or group amount.
Password
Authenticati
on
Password modification
Administrator can modify other user’s password.
Account lock strategy
Five times login failure in thirty minutes may result in account lock.
Upgrade
Web browser, client-end and update tool.
Login, Logout and Shutdown
Password login protection to guarantee safety
User-friendly interface when login. Provide the following options: Logout
/shutdown/ restart.
Right authentication when shut down to make sure only those proper
people can turn off DVR
General
Parameter
Power
DC 12V
Power
Consumptio
n
≤15W (With adapter, no HDD)
Working
Temperatur
e
-10℃－＋55℃
Working
Humidity
10%－90%
Air Pressure
86kpa－106kpa
Dimension
SMART 1U case 270(W) x205 (D) x41mm(H)
Weight
1.25KG(no HDD)
Installation
Mode
Desktop installation
Parameters
HCVR5104C-V2
HCVR5108C-V2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
1.3.2 HCVR51XXC-V2 Series
7
Parameters
HCVR5104C-V2
HCVR5108C-V2
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
1536Kbps-4096Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
Network Video
Input
N/A
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
N/A
Audio Output
N/A
Bidirectional
Talk Input
N/A
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Max 8-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
N/A
USB
2 USB ports
Others
Power
DC12V
Power
≤15W（With power adapter, no HDD）
8
Parameters
HCVR5104C-V2
HCVR5108C-V2
Consumption
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
SMART 1U case，270mm（W）×205mm（D）×41mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
Parameters
HCVR7104C-V2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P /720P/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
2048Kbps-6144Kbps，
For 1080P: default setup is 4Mbps，max supports 6Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
Network Video
Input
N/A
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
N/A
Audio Output
N/A
Bidirectional
N/A
1.3.3 HCVR7104C-V2 Series
9
Parameters
HCVR7104C-V2
Talk Input
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
N/A
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤20W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
SMART 1U case，270mm（W）×205mm（D）×41mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
Parameters
HCVR4104C-S2
HCVR4108C-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/HD1/
2CIF/CIF/QCIF
720P(1~15fps)/960H/D1/
HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI：1～25f/s（PAL）； 1~30f/s
（NTSC）
CVBS：1~25f/s（PAL）； 1~30f/s
（NTSC）
HDCVI ： 1 ～ 15f/s （ The 1st
channel supports 25/30f）
CVBS：1~25f/s（PAL）； 1~30f/s
（NTSC）
Video Bit Rate
2048Kbps-4096Kbps，
For 720P: default setup is
2Mbps，max supports 4Mbps.
For 960H: default setup is
1Mbps，max supports 3Mbps.
1024Kbps-4096Kbps，
For 720P: default setup is
1Mbps，max supports 4Mbps.
For 960H: default setup is
1Mbps，max supports 3Mbps.
Bit Stream Type
Video stream/composite stream
1.3.4 HCVR410XC-S2 Series
10
Parameters
HCVR4104C-S2
HCVR4108C-S2
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
Network Video
Input
Max 2-channel IPC connections (8M)
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Max 8-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
N/A
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤15W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
SMART 1U case，270mm（W）×205mm（D）×41mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
11
Parameters
HCVR5104C-S2
HCVR5108C-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P(1~15fps) /720P/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI：1～25f/s（PAL）； 1~30f/s（NTSC）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
2048Kbps-4096Kbps，
For 1080P/720P: default setup is 2Mbps，max supports 4Mbps.
For 960H: default setup is 1Mbps，max supports 3Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
Network Video
Input
Max 2-channel IPC connections (8M)
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Max 8-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
1.3.5 HCVR510XC-S2 Series
12
Parameters
HCVR5104C-S2
HCVR5108C-S2
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
N/A
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤15W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
SMART 1U case，270mm（W）×205mm（D）×41mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
Parameters
HCVR7104C-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI：1～25f/s（PAL）； 1~30f/s（NTSC）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
2048Kbps-6144Kbps，
For 1080P: default setup is 4Mbps，max supports 6Mbps.
For 720P: default setup is 2Mbps，max supports 4Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
Network Video
Input
Max 2-channel IPC connections (16M)
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
1.3.6 HCVR7104C-S2 Series
13
Parameters
HCVR7104C-S2
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
N/A
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤15W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
SMART 1U case，270mm（W）×205mm（D）×41mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
Parameters
HCVR2108C-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P(1~15fps) /960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI：1～12f/s
CVBS：1~20f/s（PAL）； 1~20f/s（NTSC）
Video Bit Rate
1024Kbps-4096Kbps，
1.3.7 HCVR2108C-S2 Series
14
Parameters
HCVR2108C-S2
For 720P: default setup is 1Mbps，max supports 4Mbps.
For 1080P: default setup is 1Mbps，max supports 2Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
8-channel，BNC port
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 8-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
N/A
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤15W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
SMART 1U case，270mm（W）×205mm（D）×41mm（H）
Weight
1.25KG（No HDD）
Installation
Desk
15
Parameters
HCVR2108C-S2
Mode
Parameters
HCVR4104C-S3
HCVR4108C-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080N/720P/960H/D1/HD1/2CIF/CIF
1080N@12f/720P(Non
realtime)/960H/D1/HD1/2C
IF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps-4096Kbps，
For 720P: default setup is 1.5Mbps，max supports 4Mbps.
For 1080P: default setup is 1.5Mbps，max supports 4Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port(HDCVI HD
video/general standard definition
video self-adaptive)
8-ch BNC port(HDCVI HD
video/general standard
definition video self-adaptive)
Network Video
Input
Max add 1 IP channel
connection
Analog/digital channel switch.
Max 5 IP channel
connections
Connection
bandwidth:4Mbps-20Mbps
Max add 2 IP channel
connections
Analog/digital channel
switch. Max 10 IP channel
connections
Connection
bandwidth:8Mbps-56Mbp
s
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
4-ch
8-ch
1.3.8 HCVR410XC-S3 Series
16
Parameters
HCVR4104C-S3
HCVR4108C-S3
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port of the 1st channel.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports( at the rear panel)
Others
Power
DC12V
Power
Consumption
(No HDD)
≤7W
≤8W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
SMART 1U case, 270mm（W）×205mm（D）×41mm（H）
Weight （ No
HDD）
≤0.5KG
≤0.55KG
Installation
Mode
Desk
Parameters
HCVR5104C-S3
HCVR5108C-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P@15f/1080N/720P/960H/D1/HD1/2CIF/CIF/
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps-6144Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps.
For 1080P: default setup is 2Mbps，max supports 6Mbps.
1.3.9 HCVR510XC-S3 Series
17
Parameters
HCVR5104C-S3
HCVR5108C-S3
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port(HDCVI HD
video/general standard definition
video self-adaptive)
8-ch BNC port(HDCVI HD
video/general standard
definition video self-adaptive)
Network Video
Input
Max add 1 IP channel
connection
Analog/digital channel switch.
Max 5 IP channel
connections
Connection
bandwidth:8Mbps-24Mbps
Max add 2 IP channel
connections
Analog/digital channel
switch. Max 10 IP channel
connections
Connection
bandwidth:16Mbps-48Mb
ps
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
4-ch
8-ch
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port of the 1st channel.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports( at the rear panel)
Others
Power
DC12V
18
Parameters
HCVR5104C-S3
HCVR5108C-S3
Power
Consumption
(No HDD)
≤7W
≤8W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
SMART 1U case, 270mm（W）×205mm（D）×41mm（H）
Weight （ No
HDD）
≤0.5KG
≤0.55KG
Installation
Mode
Desk
Parameters
HCVR7104C-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps-6144Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps.
For 1080P: default setup is 4Mbps，max supports 6Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port(HDCVI HD video/general standard definition video
self-adaptive)
Network Video
Input
Max add 2 IP channel connections.
Analog/digital channel switch. Max 6 IP channel connections.
Connection bandwidth:8Mbps-24Mbps
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
1.3.10 HCVR7104C-S3 Series
19
Parameters
HCVR7104C-S3
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
4-ch
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port of the 1st channel.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports( at the rear panel)
Others
Power
DC12V
Power
Consumption
(No HDD)
≤8W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
SMART 1U case, 270mm（W）×205mm（D）×41mm（H）
Weight （ No
HDD）
≤0.5KG
Installation
Mode
Desk
Parameter
HCVR5104H
HCVR5108H
System
Main
Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
System
Resources
Multiplex operations: Multiple-channel record, multiple-channel playback
and network operation simultaneously
Interface
User-friendly graphical user interface
1.3.11 HCVR51XXH Series
20
Input
Devices
USB mouse
Input
Method
Arabic number, English character, donation and extension Chinese
(optional)
Shortcut
Function
Copy/paste operation, USB mouse right-key shortcut menu, double click
USB mouse to switch screen.
Compression
Standard
Video
Compressio
n
H.264
Audio
Compressio
n
G711A, G711U, PCM
Video monitor
Video Input
4-CH composite video input:
(NTSC/PAL) BNC (1.0VB
P- P,
B75Ω)
8-CH composite video input:
(NTSC/PAL) BNC (1.0VB
P- P,
B75Ω)
Video
Output
1-ch VGA output.
1-ch HDMI output.
Support VGA/HDMI video output at the same time.
Video
Standard
Support PAL/NTSC.
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per
channel
Video
Partition
1/4 windows(Optional)
1/4/8/9 windows
Monitor
Touring
Support monitor tour functions such as motion detection, and schedule
auto control.
Resolution
(PAL/NTSC)
PAL/NTSC
Real-time monitor：
720P 1280*720
Playback：
All-ch: 720P 1280*720, 960H 960 ×576/960×480, D1
704×576/704×480, HD1 352×576/352×480, 2CIF 704×288/704×240,
CIF 352×288/ 352×240 , QCIF 176×144/176×120
Support dual streams: extra stream resolution CIF 352×288/ 352×240,
QCIF 176×144/176×120.
Quality
6-level image quality (Adjustable)
Privacy
mask
Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Information
Channel information, time information and privacy mask zone.
TV Adjust
Adjust TV output zone suitable to anamorphic video.
21
Channel
Lock
Cover secret channel with black screen though system is encoding
normally.
Screen-lock function to prevent unauthorized user seeing secret video.
Channel
Information
Channel name, recording status, screen lock status, video loss status and
motion detection status are shown on the bottom left of display screen.
Color
Configuratio
n
Hue, brightness, contrast, saturation and gain setup for each channel.
Audio
Audio Input
1-ch 200-2000mv 10KΩ(RCA)
Audio
Output
1-ch audio output 200-3000mv 5KΩ(RCA)
Bidirectional
Audio
Reuse the audio input/output channel.
Hard disk
Hard Disk
1 built-in SATA port. Support 1 HDD.
One HDD
Space
4T
Hard Disk
Occupation
Audio：PCM 28.8MByte/h
Video：56-900MByte/h
Record and
playback
Recording
Mode
Manual recording, motion detection recording, schedule recording and
alarm recording
Priority: Manual recording> alarm recording>motion detection
recording>schedule recording.
Storage
Mode
Support channel record quota setup
Recording
Length
1 to 120 minutes single record duration (Default setup is 60 minutes)
Playback
Repeat Way
When hard disk is full, system can overwrite previous video file.
Record
Search
Various search engines such as time, type and channel.
Playback
Mode
Various fast play, slow play speeds, manual frame by frame playback and
reverse play mode.
Various File
Switch
Ways
Can switch to previous or next file or any file in current play list.
Can switch to file on other channel of the same time. (If there is a file)
Support file continuous play, when a file is end system auto plays the next
file in the current channel
Playback
Way
Support mark playback
Multi-chann
el Playback
There is 1/4-channel playback mode.
Window
Zoom
Switch between self-adaptive screen/full screen when playback
22
Partial
Enlargemen
t
When in one-window full-screen playback mode, you can select any zone
to activate partial enlargement function.
Backup
function
Backup
Mode
HDD backup
Support peripheral USB backup device. (Flash disk, portable disk and
etc.)
Support network download and save
Network
Function
Network
control
View monitor channel remotely.
DVR configuration through client-end and web browser
Upgrade via client or browser to realize remote maintenance.
View alarm information such as motion detection and video loss via client.
Support network PTZ lens control
File download backup and playback
Multiple devices share information via corresponding software such as
professional surveillance software (PSS)
Duplex transparent COM
Network alarm input and output
Zero-channel encoding.
Bidirectional audio.
Motion
Detection and
Alarm
Motion
Detection
Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.
Various sensitivity levels.
Alarm can activate record or external alarm or screen message prompt.
Video Loss
Alarm can activate screen message prompt.
External
Alarm
N/A
Manual
Alarm
Control
N/A
Alarm Input
N/A
Alarm
Output
N/A
Alarm Relay
N/A
Interface
USB
Interface
2 USB 2.0 ports.
Network
connection
1 RJ45 10M/100M self-adaptable Ethernet port
RS485
PTZ control port
Support various PTZ control protocols.
RS232
N/A
System
Information
Hard Disk
Information
Display HDD current status
23
Data
Stream
Statistics
Data stream statistics for each channel (in wave mode)
Log
statistics
Backup to 1024 log files.
Support various search engines such as time and type.
Version
Display version information: channel amount, system version and release
date.
On-line user
Display current on-line user
User
Management
User
Manageme
nt
Multi-lever user management; various management modes
Integrated management for local user, serial port user and network user.
Configurable user power.
Support user /group and its corresponding rights modification.
No limit to the user or group amount.
Password
Authenticati
on
Password modification
Administrator can modify other user’s password.
Account lock strategy
Five times login failure in thirty minutes may result in account lock.
Upgrade
Web browser, client-end and update tool.
Login, Logout and Shutdown
Password login protection to guarantee safety
User-friendly interface when login. Provide the following options: Logout
/shutdown/ restart.
Right authentication when shut down to make sure only those proper
people can turn off DVR
General
Parameter
Power
DC 12V
Power
Consumptio
n
≤15W (With adapter, exclude HDD)
Working
Temperatur
e
-10℃－＋55℃
Working
Humidity
10%－90%
Air Pressure
86kpa－106kpa
Dimension
325(W) x245 (D) x45mm(H)
Weight
1.25KG(Exclude HDD)
Installation
Mode
Desktop installation
Parameters
HCVR5104H-V2
HCVR5108H-V2
HCVR5116H-V2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
1.3.12 HCVR51XXH-V2 Series
24
Parameters
HCVR5104H-V2
HCVR5108H-V2
HCVR5116H-V2
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
1536Kbps-4096Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
16-channel ， BNC
port
Network Video
Input
N/A
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA
Audio Output
1-channel RCA
Bidirectional
Talk Input
Support (reuse the audio port)
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
≤30W（With power adapter, no HDD）
25
Parameters
HCVR5104H-V2
HCVR5108H-V2
HCVR5116H-V2
Consumption
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
Parameter
HCVR5104HC
HCVR5108HC
System
Main
Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
System
Resources
Multiplex operations: Multiple-channel record, multiple-channel playback
and network operation simultaneously
Interface
User-friendly graphical user interface
Input
Devices
USB mouse
Input
Method
Arabic number, English character, donation and extension Chinese
(optional)
Shortcut
Function
Copy/paste operation, USB mouse right-key shortcut menu, double click
USB mouse to switch screen.
Compression
Standard
Video
Compressio
n
H.264
Audio
Compressio
n
N/A
Video monitor
Video Input
4-CH composite video input:
(NTSC/PAL) BNC (1.0VB
P- P,
B75Ω)
8-CH composite video input:
(NTSC/PAL) BNC (1.0VB
P- P,
B75Ω)
Video
Output
1-ch VGA output.
1-ch HDMI output.
Support VGA/HDMI video output at the same time.
Video
Standard
Support PAL/NTSC.
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per
channel
Video
Partition
1/4 windows(Optional)
1/4/8/9 windows
1.3.13 HCVR51XXHC Series
26
Monitor
Touring
Support monitor tour functions such as motion detection, and schedule
auto control.
Resolution
(PAL/NTSC)
PAL/NTSC
Real-time monitor：
720P 1280*720
Playback：
All-ch: 720P 1280*720, 960H 960 ×576/960×480, D1
704×576/704×480, HD1 352×576/352×480, 2CIF 704×288/704×240,
CIF 352×288/ 352×240 , QCIF 176×144/176×120
Support dual streams: extra stream resolution CIF 352×288/ 352×240,
QCIF 176×144/176×120.
Quality
6-level image quality (Adjustable)
Privacy
mask
Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Information
Channel information, time information and privacy mask zone.
TV Adjust
Adjust TV output zone suitable to anamorphic video.
Channel
Lock
Cover secret channel with black screen though system is encoding
normally.
Screen-lock function to prevent unauthorized user seeing secret video.
Channel
Information
Channel name, recording status, screen lock status, video loss status and
motion detection status are shown on the bottom left of display screen.
Color
Configuratio
n
Hue, brightness, contrast, saturation and gain setup for each channel.
Audio
Audio Input
N/A
Audio
Output
N/A
Bidirectional
Audio
N/A
Hard disk
Hard Disk
1 built-in SATA port. Support 1 HDD.
One HDD
Space
4T
Hard Disk
Occupation
Audio：PCM 28.8MByte/h
Video：56-900MByte/h
Record and
Recording
Mode
Manual recording, motion detection recording, schedule recording and
alarm recording
Priority: Manual recording> alarm recording>motion detection
recording>schedule recording.
27
playback
Storage
Mode
Support channel record quota setup
Recording
Length
1 to 120 minutes single record duration (Default setup is 60 minutes)
Playback
Repeat Way
When hard disk is full, system can overwrite previous video file.
Record
Search
Various search engines such as time, type and channel.
Playback
Mode
Various fast play, slow play speeds, manual frame by frame playback and
reverse play mode.
Various File
Switch
Ways
Can switch to previous or next file or any file in current play list.
Can switch to file on other channel of the same time. (If there is a file)
Support file continuous play, when a file is end system auto plays the next
file in the current channel
Playback
Way
Support mark playback
Multi-chann
el Playback
There is 1/4-channel playback mode.
Window
Zoom
Switch between self-adaptive screen/full screen when playback
Partial
Enlargemen
t
When in one-window full-screen playback mode, you can select any zone
to activate partial enlargement function.
Backup
function
Backup
Mode
HDD backup
Support peripheral USB backup device. (Flash disk, portable disk and
etc.)
Support network download and save
Network
Function
Network
control
View monitor channel remotely.
DVR configuration through client-end and web browser
Upgrade via client or browser to realize remote maintenance.
View alarm information such as motion detection and video loss via client.
Support network PTZ lens control
File download backup and playback
Multiple devices share information via corresponding software such as
professional surveillance software (PSS)
Duplex transparent COM
Network alarm input and output
Zero-channel encoding.
Bidirectional audio.
Motion
Detection and
Alarm
Motion
Detection
Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.
Various sensitivity levels.
Alarm can activate record or external alarm or screen message prompt.
Video Loss
Alarm can activate screen message prompt.
28
External
Alarm
N/A
Manual
Alarm
Control
N/A
Alarm Input
N/A
Alarm
Output
N/A
Alarm Relay
N/A
Interface
USB
Interface
2 USB 2.0 port.
Network
connection
1 RJ45 10M/100M self-adaptable Ethernet port
RS485
N/A
RS232
N/A
System
Information
Hard Disk
Information
Display HDD current status
Data
Stream
Statistics
Data stream statistics for each channel (in wave mode)
Log
statistics
Backup to 1024 log files.
Support various search engines such as time and type.
Version
Display version information: channel amount, system version and release
date.
On-line user
Display current on-line user
User
Management
User
Manageme
nt
Multi-lever user management; various management modes
Integrated management for local user, serial port user and network user.
Configurable user power.
Support user /group and its corresponding rights modification.
No limit to the user or group amount.
Password
Authenticati
on
Password modification
Administrator can modify other user’s password.
Account lock strategy
Five times login failure in thirty minutes may result in account lock.
Upgrade
Web browser, client-end and update tool.
Login, Logout and Shutdown
Password login protection to guarantee safety
User-friendly interface when login. Provide the following options: Logout
/shutdown/ restart.
Right authentication when shut down to make sure only those proper
people can turn off DVR
Power
DC 12V
29
General
Parameter
Power
Consumptio
n
≤15W (With adapter, exclude HDD)
Working
Temperatur
e
-10℃－＋55℃
Working
Humidity
10%－90%
Air Pressure
86kpa－106kpa
Dimension
325(W) x245 (D) x45mm(H)
Weight
1.25KG(Exclude HDD)
Installation
Mode
Desktop installation
1.3.14 HCVR51XXHC-V2 Series
Parameters
HCVR5104HC-V2
HCVR5108HC-V2
HCVR5116HC-V2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
1536Kbps-4096Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
16-channel ， BNC
port
Network Video
Input
N/A
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
N/A
Audio Output
N/A
30
Parameters
HCVR5104HC-V2
HCVR5108HC-V2
HCVR5116HC-V2
Bidirectional
Talk Input
N/A
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤30W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
Parameter
HCVR5104HE
HCVR5108HE
System
Main
Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
System
Resources
Multiplex operations: Multiple-channel record, multiple-channel playback
and network operation simultaneously
Interface
User-friendly graphical user interface
Input
Devices
USB mouse
Input
Method
Arabic number, English character, donation and extension Chinese
(optional)
Shortcut
Function
Copy/paste operation, USB mouse right-key shortcut menu, double click
USB mouse to switch screen.
1.3.15 HCVR51XXHE Series
31
Compression
Standard
Video
Compressio
n
H.264
Audio
Compressio
n
G711A, G711U, PCM
Video monitor
Video Input
4-CH composite video input:
(NTSC/PAL) BNC (1.0VB
P- P,
B75Ω)
8-CH composite video input:
(NTSC/PAL) BNC (1.0VB
P- P,
B75Ω)
Video
Output
1-ch VGA output.
1-ch HDMI output.
Support VGA/HDMI video output at the same time.
Video
Standard
Support PAL/NTSC.
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per
channel
Video
Partition
1/4 windows(Optional)
1/4/8/9 windows
Monitor
Touring
Support monitor tour functions such as motion detection, and schedule
auto control.
Resolution
(PAL/NTSC)
PAL/NTSC
Real-time monitor：
720P 1280*720
Playback：
All-ch: 720P 1280*720, 960H 960 ×576/960×480, D1
704×576/704×480, HD1 352×576/352×480, 2CIF 704×288/704×240,
CIF 352×288/ 352×240 , QCIF 176×144/176×120
Support dual streams: extra stream resolution CIF 352×288/ 352×240,
QCIF 176×144/176×120.
Quality
6-level image quality (Adjustable)
Privacy
mask
Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Information
Channel information, time information and privacy mask zone.
TV Adjust
Adjust TV output zone suitable to anamorphic video.
Channel
Lock
Cover secret channel with black screen though system is encoding
normally.
Screen-lock function to prevent unauthorized user seeing secret video.
Channel
Information
Channel name, recording status, screen lock status, video loss status and
motion detection status are shown on the bottom left of display screen.
32
Color
Configuratio
n
Hue, brightness, contrast, saturation and gain setup for each channel.
Audio
Audio Input
1-ch 200-2000mv 10KΩ(RCA)
Audio
Output
1-ch audio output 200-3000mv 5KΩ(RCA)
Bidirectional
Audio
Reuse the audio input/output channel.
Hard disk
Hard Disk
1 built-in SATA port. Support 1 HDD.
One HDD
Space
4T
Hard Disk
Occupation
Audio：PCM 28.8MByte/h
Video：56-900MByte/h
Record and
playback
Recording
Mode
Manual recording, motion detection recording, schedule recording and
alarm recording
Priority: Manual recording> alarm recording>motion detection
recording>schedule recording.
Storage
Mode
Support channel record quota setup
Recording
Length
1 to 120 minutes single record duration (Default setup is 60 minutes)
Playback
Repeat Way
When hard disk is full, system can overwrite previous video file.
Record
Search
Various search engines such as time, type and channel.
Playback
Mode
Various fast play, slow play speeds, manual frame by frame playback and
reverse play mode.
Various File
Switch
Ways
Can switch to previous or next file or any file in current play list.
Can switch to file on other channel of the same time. (If there is a file)
Support file continuous play, when a file is end system auto plays the next
file in the current channel
Playback
Way
Support mark playback
Multi-chann
el Playback
There is 1/4-channel playback mode.
Window
Zoom
Switch between self-adaptive screen/full screen when playback
Partial
Enlargemen
t
When in one-window full-screen playback mode, you can select any zone
to activate partial enlargement function.
33
Backup
function
Backup
Mode
HDD backup
Support peripheral USB backup device. (Flash disk, portable disk and
etc.)
Support network download and save
Network
Function
Network
control
View monitor channel remotely.
DVR configuration through client-end and web browser
Upgrade via client or browser to realize remote maintenance.
View alarm information such as motion detection and video loss via client.
Support network PTZ lens control
File download backup and playback
Multiple devices share information via corresponding software such as
professional surveillance software (PSS)
Duplex transparent COM
Network alarm input and output
Bidirectional audio.
Motion
Detection and
Alarm
Motion
Detection
Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.
Various sensitivity levels.
Alarm can activate record or external alarm or screen message prompt.
Video Loss
Alarm can activate screen message prompt.
External
Alarm
Support record activation function or activate external alarm or screen
message in specified period.
Manual
Alarm
Control
Enable or disable alarm input channel
Support analog alarm signal to specific alarm output channel.
Alarm Input
4-ch alarm input（NO/NC）
8-ch alarm input（NO/NC ）
Alarm
Output
3-channel relay output.
Alarm Relay
30V DC 2A，125VAC 1A（activation alarm ）
Interface
USB
Interface
2 USB 2.0 ports.
Network
connection
One RJ45 10M/100M self-adaptable Ethernet port
RS485
PTZ control port
Support various PTZ control protocols.
RS232
N/A
System
Information
Hard Disk
Information
Display HDD current status
Data
Stream
Statistics
Data stream statistics for each channel (in wave mode)
Log
statistics
Backup to 1024 log files.
Support various search engines such as time and type.
34
Version
Display version information: channel amount, system version and release
date.
On-line user
Display current on-line user
User
Management
User
Manageme
nt
Multi-lever user management; various management modes
Integrated management for local user, serial port user and network user.
Configurable user power.
Support user /group and its corresponding rights modification.
No limit to the user or group amount.
Password
Authenticati
on
Password modification
Administrator can modify other user’s password.
Account lock strategy
Five times login failure in thirty minutes may result in account lock.
Upgrade
Web browser, client-end and update tool.
Login, Logout and Shutdown
Password login protection to guarantee safety
User-friendly interface when login. Provide the following options: Logout
/shutdown/ restart.
Right authentication when shut down to make sure only those proper
people can turn off DVR
General
Parameter
Power
DC 12V
Power
Consumptio
n
≤15W (With adapter, exclude HDD)
Working
Temperatur
e
-10℃－＋55℃
Working
Humidity
10%－90%
Air Pressure
86kpa－106kpa
Dimension
325(W) x245 (D) x45mm(H)
Weight
1.25KG(Exclude HDD)
Installation
Mode
Desktop installation
Parameters
HCVR5104HE-V2
HCVR5108HE-V2
HCVR5116HE-V2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P/D1/HD1/2CIF/CIF/QCIF
Video Frame
PAL:1~25f/s；NTSC：1~30f/s
1.3.16 HCVR51HE-V2 Series
35
Parameters
HCVR5104HE-V2
HCVR5108HE-V2
HCVR5116HE-V2
Rate
Video Bit Rate
1536Kbps-4096Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
16-channel ， BNC
port
Network Video
Input
N/A
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-channel RCA
Audio Output
1-channel RCA
Bidirectional
Talk Input
Support (reuse the audio port)
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
4-channel alarm
input
8-channel alarm
input
16-channel alarm
input
Alarm Output
3-channel alarm output
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤30W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
10%~90%
36
Parameters
HCVR5104HE-V2
HCVR5108HE-V2
HCVR5116HE-V2
Humidity
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
Parameters
HCVR7104H-V2
HCVR7108H-V2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P /720P/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
2048Kbps-6144Kbps，
For 1080P: default setup is 4Mbps，max supports 6Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
Network Video
Input
N/A
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA
Audio Output
1-channel RCA
Bidirectional
Talk Input
Support (reuse the audio port)
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Max 8-channel playback
1.3.17 HCVR71XXH-V2 Series
37
Parameters
HCVR7104H-V2
HCVR7108H-V2
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
N/A
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤30W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
Parameters
HCVR7104HC-V2
HCVR7108HC-V2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P/720P/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
2048Kbps-6144Kbps，
For 1080P: default setup is 4Mbps，max supports 6Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
1.3.18 HCVR71XXHC-V2 Series
38
Parameters
HCVR7104HC-V2
HCVR7108HC-V2
Network Video
Input
N/A
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
N/A
Audio Output
N/A
Bidirectional
Talk Input
N/A
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Max 8-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤30W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
Parameters
HCVR7104HE-V2
HCVR7108HE-V2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
1080P/720P/D1/HD1/2CIF/CIF/QCIF
1.3.19 HCVR71XHE-V2 Series
39
Parameters
HCVR7104HE-V2
HCVR7108HE-V2
Resolution
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
2048Kbps-6144Kbps，
For 1080P: default setup is 4Mbps，max supports 6Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
Network Video
Input
N/A
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-channel RCA
Audio Output
1-channel RCA
Bidirectional
Talk Input
Support (reuse the audio port)
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Max 8-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
4-channel alarm input
16-channel alarm input
Alarm Output
3-channel alarm output
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤30W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
40
Parameters
HCVR7104HE-V2
HCVR7108HE-V2
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
Parameters
HCVR4104HE-S2
HCVR4108HE-S2
HCVR4116HE-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/
HD1/2CIF/CIF/QCIF
720P(1~15fps)/960H/
D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI ： 1 ～ 25f/s
（ PAL ）； 1~30f/s
（NTSC）
CVBS：1~25f/s（PAL）；
1~30f/s（NTSC）
HDCVI ： 1 ～ 15f/s （ The 1st channel
supports 25/30f）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
2048Kbps-4096Kbps，
For 720P: default setup
is 2Mbps ， max
supports 4Mbps.
For 960H: default
setup is 1Mbps，max
supports 3Mbps.
1024Kbps-4096Kbps，
For 720P: default setup is 1Mbps，max
supports 4Mbps.
For 960H: default setup is 1Mbps，max
supports 3Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
16-channel，
BNC port
Network Video
Input
Max 2-channel IPC connections (8M)
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
1.3.20 HCVR41XXHE-S2 Series
41
Parameters
HCVR4104HE-S2
HCVR4108HE-S2
HCVR4116HE-S2
Matrix Output
N/A
Audio Port
Audio Input
4-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
4-channel input
8-channel input
16-channel input
Alarm Output
3-channel output
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤15W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
1.3.21 HCVR51XXH-S2 Series
Parameters
HCVR5104H-S2
HCVR5108H-S2
HCVR5116H-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P(1~15fps)/720P/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI：1～25f/s（PAL）； 1~30f/s（NTSC）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
2048Kbps-4096Kbps，
For 1080P/720P: default setup is 2Mbps，max supports 4Mbps.
For 960H: default setup is 1Mbps，max supports 3Mbps.
Bit Stream Type
Video stream/composite stream
42
Parameters
HCVR5104H-S2
HCVR5108H-S2
HCVR5116H-S2
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
16-channel，
BNC port
Network Video
Input
Max 2-channel IPC connections (8M)
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤15W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
43
1.3.22 HCVR51XXHE-S2 Series
Parameters
HCVR5104HE-S2
HCVR5108HE-S2
HCVR5116HE-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P(1~15fps)/720P/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI：1～25f/s（PAL）； 1~30f/s（NTSC）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
2048Kbps-4096Kbps，
For 1080P/720P: default setup is 2Mbps，max supports 4Mbps.
For 960H: default setup is 1Mbps，max supports 3Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
16-channel，
BNC port
Network Video
Input
Max 2-channel IPC connections (8M)
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
4-channel input
8-channel input
16-channel input
Alarm Output
3-channel output
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Network
1 RJ45 port, 100Mbps Ethernet port
44
Parameters
HCVR5104HE-S2
HCVR5108HE-S2
HCVR5116HE-S2
Port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤15W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
1.3.23 HCVR710XH-S2 Series
Parameters
HCVR7104H-S2
HCVR7108H-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI：1～25f/s（PAL）； 1~30f/s（NTSC）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
2048Kbps-6144Kbps，
For 1080P: default setup is 4Mbps，max supports 6Mbps.
For 720P: default setup is 2Mbps，max supports 4Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
Network Video
Input
Max 2-channel IPC connections (16M)
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
45
Parameters
HCVR7104H-S2
HCVR7108H-S2
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Max 8-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤15W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
1.3.24 HCVR710XHE-S2 Series
Parameters
HCVR7104HE-S2
HCVR7108HE-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI：1～25f/s（PAL）； 1~30f/s（NTSC）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
2048Kbps-6144Kbps，
For 1080P: default setup is 4Mbps，max supports 6Mbps.
For 720P: default setup is 2Mbps，max supports 4Mbps.
Bit Stream Type
Video stream/composite stream
46
Parameters
HCVR7104HE-S2
HCVR7108HE-S2
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
Network Video
Input
Max 2-channel IPC connection (16M)
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Max 8-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
8-channel input
16-channel input
Alarm Output
3-channel output
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤15W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
47
Parameters
HCVR4104HE-S3
HCVR4108HE-S3
HCVR4116HE-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080N/720P/960H/
D1/HD1/2CIF/CIF
1080N@12f/720P@15f/960H/D1/HD1/2CIF
/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps-4096Kbps，
For 720P: default setup is 1.5Mbps，max supports 4Mbps.
For 1080P: default setup is 1.5Mbps，max supports 4Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(HDCVI HD
video/general
standard definition
video self-adaptive)
8-ch BNC port(HDCVI
HD video/general
standard definition
video self-adaptive)
16-ch BNC
port(HDCVI HD
video/general
standard definition
video
self-adaptive)
Network Video
Input
Max add 1 IP
channel
Connection.
Analog
/digital channel
switch. Max 5 IP
channel
connections
Connection
bandwidth:4Mbp
s-20Mbps
Max add 2 IP
channel
connections
Analog
/digital channel
switch. Max 10 IP
channel
connections
Connection
bandwidth:8Mbp
s-40Mbps
Max add 2 IP
channel
connections
Analog
/digital
channel
switch. Max
18 IP channel
connections
Connection
bandwidth:8
Mbps-56Mbp
s
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
1.3.25 HCVR41XXHE-S3 Series
48
Parameters
HCVR4104HE-S3
HCVR4108HE-S3
HCVR4116HE-S3
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-channel RCA port.
8-channel RCA port.
16-channel RCA
port.
Coaxial Audio
Input
4-ch
8-ch-
16-ch
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Support（Reuse the audio port of the 1st channel）
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
8-channel input
8-channel input
16-channel input
Alarm Output
3-channel output
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Others
Power
DC12V
Power
Consumption
≤7W
≤8W
≤10W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
≤1.1KG
≤1.25KG
≤1.45KG
Installation
Mode
Desk
Parameters
HCVR5104HE-S3
HCVR5108HE-S3
HCVR5116HE-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
1080P@12f/720P@15f/960H/D1/HD1/2CIF/CIF
1.3.26 HCVR51XXHE-S3 Series
49
Parameters
HCVR5104HE-S3
HCVR5108HE-S3
HCVR5116HE-S3
Resolution
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps-6144Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps.
For 1080P: default setup is 2Mbps，max supports 6Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(HDCVI HD
video/general
standard definition
video self-adaptive)
8-ch BNC port(HDCVI
HD video/general
standard definition
video self-adaptive)
16-ch BNC
port(HDCVI HD
video/general
standard definition
video
self-adaptive)
Network Video
Input
Max add 2 IP
channel
Connection.
Analog
/digital channel
switch. Max 6 IP
channel
connections
Connection
bandwidth:8Mbp
s-24Mbps
Max add 4 IP
channel
connections
Analog
/digital channel
switch. Max 12IP
channel
connections
Connection
bandwidth:16Mb
ps-48Mbps
Max add 8 IP
channel
connections
Analog
/digital
channel
switch. Max
24 IP channel
connections
Connection
bandwidth:32
Mbps-96Mbp
s
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-channel RCA port.
8-channel RCA port.
16-channel RCA
port.
Coaxial Audio
Input
4-ch
8-ch-
16-ch
Audio Output
1-channel RCA port.
50
Parameters
HCVR5104HE-S3
HCVR5108HE-S3
HCVR5116HE-S3
Bidirectional
Talk Input
Support（Reuse the audio port of the 1st channel）
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
8-channel input
8-channel input
16-channel input
Alarm Output
3-channel output
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Others
Power
DC12V
Power
Consumption
≤7W
≤8W
≤10W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
≤1.1KG
≤1.25KG
≤1.45KG
Installation
Mode
Desk
Parameters
HCVR7104HE-S3
HCVR7108HE-S3
HCVR7116HE-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps-6144Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps.
For 1080P: default setup is 4Mbps，max supports 6Mbps.
Bit Stream Type
Video stream/composite stream
1.3.27 HCVR71XXHE-S3 Series
51
Parameters
HCVR7104HE-S3
HCVR7108HE-S3
HCVR7116HE-S3
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(HDCVI HD
video/general
standard definition
video self-adaptive)
8-ch BNC port(HDCVI
HD video/general
standard definition
video self-adaptive)
16-ch BNC
port(HDCVI HD
video/general
standard definition
video
self-adaptive)
Network Video
Input
Max add 2 IP
channel
Connection.
Analog
/digital channel
switch. Max 6 IP
channel
connections
Connection
bandwidth:8Mbp
s-24Mbps
Max add 4 IP
channel
connections
Analog
/digital channel
switch. Max 12IP
channel
connections
Connection
bandwidth:16Mb
ps-48Mbps
Max add 8 IP
channel
connections
Analog
/digital
channel
switch. Max
24 IP channel
connections
Connection
bandwidth:32
Mbps-96Mbp
s
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-channel RCA port.
8-channel RCA port.
16-channel RCA
port.
Coaxial Audio
Input
4-ch
8-ch-
16-ch
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Support（Reuse the audio port of the 1st channel）
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
52
Parameters
HCVR7104HE-S3
HCVR7108HE-S3
HCVR7116HE-S3
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
8-channel input
8-channel input
16-channel input
Alarm Output
3-channel output
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One
at the front panel and
one at the rear panel)
1 USB2.0 port at the
front panel and one
USB3.0 port at the
rear panel
1 USB2.0 port at
the front panel
and one USB3.0
port at the rear
panel
Others
Power
DC12V
Power
Consumption
≤8W
≤10W
≤15W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
≤1.1KG
≤1.25KG
≤1.45KG
Installation
Mode
Desk
Parameters
HCVR7104HS3
HCVR7108H-S3
HCVR7116H-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps-6144Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps.
For 1080P: default setup is 4Mbps，max supports 6Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
1.3.28 HCVR71XXH-S3 Series
53
Parameters
HCVR7104HS3
HCVR7108H-S3
HCVR7116H-S3
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(HDCVI HD
video/general
standard definition
video self-adaptive)
8-ch BNC port(HDCVI
HD video/general
standard definition
video self-adaptive)
16-ch BNC
port(HDCVI HD
video/general
standard definition
video
self-adaptive)
Network Video
Input
Max add 2 IP
channel
Connection.
Analog
/digital channel
switch. Max 6 IP
channel
connections
Connection
bandwidth:8Mbp
s-24Mbps
Max add 4 IP
channel
connections
Analog
/digital channel
switch. Max 12IP
channel
connections
Connection
bandwidth:16Mb
ps-48Mbps
Max add 8 IP
channel
connections
Analog
/digital
channel
switch. Max
24 IP channel
connections
Connection
bandwidth:32
Mbps-96Mbp
s
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-channel RCA port.
8-channel RCA port.
16-channel RCA
port.
Coaxial Audio
Input
4-ch
8-ch-
16-ch
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Support（Reuse the audio port of the 1st channel）
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
8-channel input
8-channel input
16-channel input
Alarm Output
3-channel output
54
Parameters
HCVR7104HS3
HCVR7108H-S3
HCVR7116H-S3
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One
at the front panel and
one at the rear panel)
1 USB2.0 port at the
front panel and one
USB3.0 port at the
rear panel
1 USB2.0 port at
the front panel
and one USB3.0
port at the rear
panel
Others
Power
DC12V
Power
Consumption
≤8W
≤10W
≤15W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
≤1.1KG
≤1.25KG
≤1.45KG
Installation
Mode
Desk
Parameters
HCVR4104HS-S2
HCVR4108HS-S2
HCVR4116HS-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/HD1/
2CIF/CIF/QCIF
720P(1-15f/s)/960H/D1/HD1/
2CIF/CIF/QCIF
Video Frame
Rate
HDCVI ： 1 ～ 25f/s
（ PAL ）； 1~30f/s
（NTSC）
CVBS：1~25f/s（PAL）；
1~30f/s（NTSC）
HDCVI ： 1 ～ 15f/s (The 1st channel
supports 25/30fps/)
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
2048Kbps-4096Kbps，
For 720P: default setup
is 2Mbps ， max
supports 4Mbps.
For 960H: default
setup is 1Mbps，max
supports 3Mbps.
1024Kbps-4096Kbps，
For 720P: default setup is 1Mbps，max
supports 4Mbps.
For 960H: default setup is 1Mbps，max
supports 3Mbps.
Bit Stream Type
Video stream/composite stream
1.3.29 HCVR41XXHS-S2 Series
55
Parameters
HCVR4104HS-S2
HCVR4108HS-S2
HCVR4116HS-S2
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
16-channel，
BNC port
Network Video
Input
Max 2-channel IPC connections (8M)
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consumption
≤15W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Compact 1U case, 260mm（W）×220mm（D）×44mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
56
1.3.30 HCVR21XXHS-S2 Series
Parameters
HCVR2108HS-S2
HCVR2116HS-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P(1-15f/s)/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI：1～12f/s
CVBS：1~20f/s（PAL）； 1~20f/s（NTSC）
Video Bit Rate
1024Kbps-4096Kbps，
For 720P: default setup is 1Mbps，max supports 4Mbps.
For 960H: default setup is 1Mbps，max supports 3Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
8-channel，BNC port
16-channel，BNC port
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
960H: Max 4-channel playback
720P: Max 1-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
57
Parameters
HCVR2108HS-S2
HCVR2116HS-S2
Others
Power
DC12V
Power
Consumption
≤15W（With power adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Compact 1U case, 260mm（W）×220mm（D）×44mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
Parameters
2104HS-S3
2108HS-S3
2116HS-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080N@12f/720P@15f/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps-4096Kbps，
For 720P: default setup is 1.5Mbps，max supports 4Mbps.
For 1080N: default setup is 1.5Mbps，max supports 4Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port(HDCVI
HD video/general
standard definition
video self-adaptive)
8-ch BNC port(HDCVI
HD video/general
standard definition
video self-adaptive)
16-ch BNC
port(HDCVI HD
video/general
standard definition
video
self-adaptive)
Network Video
Input
Analog/digital channel switch. Max 2 IP channel connections
Connection bandwidth:8Mbps
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
1.3.31 HCVR21XXHS-S3 Series
58
Parameters
2104HS-S3
2108HS-S3
2116HS-S3
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
4-ch
8-ch
16-ch
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port of the 1st channel.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Others
Power
DC12V
Power
Consumption
(No HDD)
≤10W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Compact 1U case, 260mm（W）×220mm（D）×44mm（H）
Weight （ No
HDD）
≤1.25KG
≤1.35KG
≤1.45KG
Installation
Mode
Desk
Parameters
HCVR4104HS-S3
HCVR4108HS-S3
HCVR4116HS-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
1080N/720P/960H/D1
1080N@12f/720P@15f/960H/D1/HD1/2CI
1.3.32 HCVR41XXHS-S3 Series
59
Parameters
HCVR4104HS-S3
HCVR4108HS-S3
HCVR4116HS-S3
Resolution
/HD1/2CIF/CIF/
F/CIF/
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps-4096Kbps，
For 720P: default setup is 1.5Mbps，max supports 4Mbps.
For 1080P: default setup is 1.5Mbps，max supports 4Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(HDCVI HD
video/general
standard definition
video self-adaptive)
8-ch BNC port(HDCVI
HD video/general
standard definition
video self-adaptive)
16-ch BNC
port(HDCVI HD
video/general
standard definition
video
self-adaptive)
Network Video
Input
Max add 1 IP
channel
connection
Analog
/digital channel
switch. Max 5 IP
channel
connections
Connection
bandwidth:4Mbp
s-20Mbps
Max add 1 IP
channel
connection
Analog
/digital channel
switch. Max 9 IP
channel
connections
Connection
bandwidth:8Mbp
s-40Mbps
Max add 2 IP
channel
connections
Analog
/digital
channel
switch. Max
18 IP channel
connections
Connection
bandwidth:8
Mbps-56Mbp
s
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
4-ch
8-ch-
16-ch
Audio Output
1-channel RCA port.
Bidirectional
Reuse the audio input/output port.
60
Parameters
HCVR4104HS-S3
HCVR4108HS-S3
HCVR4116HS-S3
Talk Input
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Others
Power
DC12V
Power
Consumption
(No HDD)
≤7W
≤8W
≤10W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Compact 1U case, 260mm（W）×220mm（D）×44mm（H）
Weight (No
HDD)
≤0.85KG
≤0.95KG
≤1.05KG
Installation
Mode
Desk
Parameters
HCVR5104HS-S3
HCVR5108HS-S3
HCVR5116HS-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P@15f/1080N/720P/960H/D1/HD1/2CIF/CIF/1080P@15f/720
P@15f/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps-6144Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps.
For 1080P: default setup is 2Mbps，max supports 6Mbps.
1.3.33 HCVR51XXHS-S3 Series
61
Parameters
HCVR5104HS-S3
HCVR5108HS-S3
HCVR5116HS-S3
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(HDCVI HD
video/general
standard definition
video self-adaptive)
8-ch BNC port(HDCVI
HD video/general
standard definition
video self-adaptive)
16-ch BNC
port(HDCVI HD
video/general
standard definition
video
self-adaptive)
Network Video
Input
Max add 2 IP
channel
connections
Analog
/digital channel
switch. Max 6 IP
channel
connections
Connection
bandwidth:8Mbp
s-24Mbps
Max add 4 IP
channel
connection
Analog
/digital channel
switch. Max 12 IP
channel
connections
Connection
bandwidth:16Mb
ps-48Mbps
Max add 8 IP
channel
connections
Analog
/digital
channel
switch. Max
24 IP channel
connections
Connection
bandwidth:32
Mbps-96Mbp
s
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
4-ch
8-ch-
16-ch
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port of the 1st channel.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
62
Parameters
HCVR5104HS-S3
HCVR5108HS-S3
HCVR5116HS-S3
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Others
Power
DC12V
Power
Consumption
(No HDD)
≤7W
≤8W
≤10W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Compact 1U case, 260mm（W）×220mm（D）×44mm（H）
Weight (No
HDD)
≤0.85KG
≤0.95KG
≤1.05KG
Installation
Mode
Desk
Parameters
HCVR7104HS-S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps-6144Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps.
For 1080P: default setup is 4Mbps，max supports 6Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
1.3.34 HCVR71XXHS-S3 Series
63
Parameters
HCVR7104HS-S3
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port(HDCVI HD video/general standard definition video
self-adaptive)
Network Video
Input
Max add 2 IP channel connections
Analog/digital channel switch. Max 6 IP channel connections
Connection bandwidth:8Mbps-24Mbps
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
4-ch
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port of the 1st channel.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Others
Power
DC12V
Power
Consumption
(No HDD)
≤8W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Compact 1U case, 260mm（W）×220mm（D）×44mm（H）
Weight （ No
HDD）
0.85KG
Installation
Mode
Desk
64
Model
Parameters
HCVR5204A-V2
HCVR5208A-V2
HCVR5216A-V2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode Resolution
720P/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
1536Kbps-4096Kbps，
For 720P:default value is 2Mbps，max value is 4Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode Standard
G.711A, G.711U, PCM
Audio Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video Input
4-ch, BNC port
8-ch, BNC port
16-ch, BNC port
Network Video Input
Switch 2 analog channels to the IP channels（8Mbps）
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the
same video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch，RCA port, audio via coaxial cable
Audio Output
1-ch，RCA port
Bidirectional Talk
Input
Support（Reuse the audio port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm
record
Record Playback
Max 4-ch playback
Max 8-ch
playback
Max 16-ch
playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
4-ch alarm input
8-ch alarm input
16-ch alarm input
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Other
Power
DC12V
Power Consumption
≤30W（exclude HDD）
1.3.35 HCVR52XXA-V2 Series
65
Model
Parameters
HCVR5204A-V2
HCVR5208A-V2
HCVR5216A-V2
Working Temperature
-10℃－＋55℃
Working Humidity
10%~90%
Dimension
1U case，375mm（W）×280mm（D）×50mm（H）
Weight
1.5kg～2.5kg（exclude HDD）
Installation Mode
Desk installation
Model
Parameters
HCVR7204A-V2
HCVR7208A-V2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode Resolution
1080P /720P/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream
only)
Video Frame Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
2048Kbps-6144Kbps Kbps-4096Kbps，
For 1080P:default value is 4Mbps，max value is 6Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode Standard
G.711A, G.711U, PCM
Audio Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video Input
4-ch, BNC port
8-ch, BNC port
Network Video Input
Switch 2 analog channels to the IP channels（16Mbps）
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the
same video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch，RCA port, audio via coaxial cable
Audio Output
1-ch，RCA port
Bidirectional Talk
Input
Support（Reuse the audio port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm
record
Record Playback
Max 4-ch playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
4-ch alarm input
16-ch alarm input
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
1.3.36 HCVR72XXA-V2 Series
66
Model
Parameters
HCVR7204A-V2
HCVR7208A-V2
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Other
Power
DC12V
Power Consumption
≤30W（exclude HDD）
Working Temperature
-10℃－＋55℃
Working Humidity
10%~90%
Dimension
1U case，375mm（W）×280mm（D）×50mm（H）
Weight
1.5kg～2.5kg（exclude HDD）
Installation Mode
Desk installation
Model
Parameters
HCVR4204AS2
HCVR4208AS2
HCVR4216AS2
HCVR4216AN
-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
720P(1-15fps)/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
HDCVI：1～15f/s（The 1st channel supports 25/30f/s）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
1024Kbps-4096Kbps，
For 720P:default value is 1Mbps，max value is 4Mbps
For 960H:default value is 1Mbps，max value is 3Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch, BNC port
8-ch, BNC port
16-ch, BNC
port
16-ch, BNC
port
Network Video
Input
Max 2 IPC connections（8Mbps）
1.3.37 HCVR42XXA-S2/4216AN-S2 Series
67
Model
Parameters
HCVR4204AS2
HCVR4208AS2
HCVR4216AS2
HCVR4216AN
-S2
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same
video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch，RCA port,
1-ch ，
RCA
port
Audio Output
1-ch，RCA port
Bidirectional
Talk Input
Support（Reuse the audio port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch
playback
Max 8-ch
playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm input
N/A
Alarm Output
3-ch alarm output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Other
Power
DC12V/4A
Power
Consumption
≤30W（No HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1U case，375mm（W）×280mm（D）×50mm（H）
Weight
1.5-2.5kg（no HDD）
Installation
Mode
Desk installation
Model
Parameters
HCVR4224AN-S2
HCVR4232AN-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
1.3.38 HCVR4224/4232AN-S2 Series
68
Model
Parameters
HCVR4224AN-S2
HCVR4232AN-S2
Video
Video Encode
Standard
H.264
Encode
Resolution
720P(1-15fps)/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
HDCVI：1～15f/s（The 1st/ 2nd channel supports 25/30f/s）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
1024Kbps～4096Kbps，
For 720P realtime (The first two channels):default value is 2Mbps，
max value is 4Mbps.
For 720P non-realtime: default value is 1Mbps， max value is
2Mbps.
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
24-ch, BNC port
32-ch, BNC port
Network Video
Input
Max 4 IPC connections（16Mbps）
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same
video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-ch，RCA port, Coaxibale audio
1-ch，RCA port. Coaxibale
audio
Audio Output
1-ch，RCA port
Bidirectional
Talk Input
Support（Reuse the audio port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
69
Model
Parameters
HCVR4224AN-S2
HCVR4232AN-S2
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
1 RS485 port
USB
2 USB ports
Other
Power
DC12V/5A
Power
Consumption
≤30W（With adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1U case，375mm（W）×280mm（D）×50mm（H）
Weight
1.5-2.5kg（no HDD）
Installation
Mode
Desk installation
Model
Parameters
HCVR5204AS2
HCVR5208AS2
HCVR5216AS2
HCVR5216AN
-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
1080P(1-15fps) /720P/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI：1~25f/s（PAL）； 1~30f/s（NTSC）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
2048Kbps-4096Kbps
For 1080P/720P:default value is 2Mbps，max value is 4Mbps
For 960H:default value is 1Mbps，max value is 3Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch, BNC port
8-ch, BNC port
16-ch, BNC
port
16-ch,
BNC
port
Network Video
Input
Max 2 IPC connections（8Mbps）
1.3.39 HCVR52XXA-S2/HCVR5216AN-S2 Series
70
Model
Parameters
HCVR5204AS2
HCVR5208AS2
HCVR5216AS2
HCVR5216AN
-S2
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same
video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch，RCA port, audio via coaxial cable
Audio Output
1-ch，RCA port
Bidirectional
Talk Input
Support（Reuse the audio port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch
playback
Max 8-ch
playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm
input
N/A
Alarm Output
3-ch alarm output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Other
Power
DC12V/4A
DC12V/
5A
Power
Consumption
≤30W（No HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1U case，375mm（W）×280mm（D）×50mm（H）
Weight
1.5-2.5kg（No HDD）
Installation
Mode
Desk installation
Model
Parameters
HCVR7204A-S2
HCVR7208A-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
1.3.40 HCVR720XA-S2 Series
71
Model
Parameters
HCVR7204A-S2
HCVR7208A-S2
Video
Video Encode
Standard
H.264
Encode
Resolution
1080P /720P/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI：1~25f/s（PAL）； 1~30f/s（NTSC）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
2048Kbps-6144Kbps
For 1080P:default value is 4Mbps，max value is 6Mbps
For 720P:default value is 2Mbps，max value is 4Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch, BNC port
8-ch, BNC port
Network Video
Input
Max 2 IPC connections 16Mbps）
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same
video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch，RCA port, audio via coaxial cable
Audio Output
1-ch，RCA port
Bidirectional
Talk Input
Support（Reuse the audio port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch playback
Max 8-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
16-ch alarm input
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
72
Model
Parameters
HCVR7204A-S2
HCVR7208A-S2
USB
2 USB ports
Other
Power
DC12V/4A
DC12V/5A
Power
Consumption
≤30W（No HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1U case，375mm（W）×280mm（D）×50mm（H）
Weight
1.5-2.5kg（No HDD）
Installation
Mode
Desk installation
Model
Parameters
HCVR4204A-S3
HCVR4208A-S3
HCVR4216A-S3
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
1080N/720P/
960H/D1/HD1/
2CIF/CIF/
1080N@12f/720P@15f/960H/D1/HD1/2
CIF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps～4096Kbps，
For 720P:default value is 1.5Mbps，max value is 4Mbps.
For 1080P:default value is 1.5Mbps，max value is 4Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port (HDCVI
HD video/general
standard definition
video self-adaptive)
8-ch BNC port(HDCVI
HD video/general
standard definition
video self-adaptive)
16-ch BNC
port(HDCVI
HD
video/general
standard
definition video
self-adaptive)
1.3.41 HCVR42XXA-S3 Series
73
Model
Parameters
HCVR4204A-S3
HCVR4208A-S3
HCVR4216A-S3
Network Video
Input
Max add 1 IP
channel
connection
Analog
/digital channel
switch. Max 5 IP
channel
connections
Connection
bandwidth:4Mbps20Mbps
Max add 2 IP
channel
connections
Analog
/digital channel
switch. Max 10 IP
channel
connections
Connection
bandwidth:8Mbps40Mbps
Max add 2
IP channel
connectio
ns
Analog
/digital
channel
switch.
Max 18 IP
channel
connectio
ns
Connectio
n
bandwidth
:8Mbps-56
Mbps
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same
video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
External
Audio Input
4-ch，RCA port,
Coaxial Audio
Input
4-ch
8-ch
16-ch
Audio Output
1-ch RCA port
Bidirectional
Talk Input
Support（Reuse the audio port of the 1st channel）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch
playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm
input
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
6T
Communication
Network
1 RJ45 port, 100Mbps Ethernet port
74
Model
Parameters
HCVR4204A-S3
HCVR4208A-S3
HCVR4216A-S3
Port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Other
Power
DC12V
Power
Consumption
（No HDD）
≤7W
≤8W
≤10W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1U case，375mm（W）×280mm（D）×50mm（H）
Weight
（No HDD）
≤1.5KG
≤1.65KG
≤1.8KG
Installation
Mode
Desk installation
Model
Parameters
HCVR4216AN-S3
HCVR4232AN-S3
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
1080N@12f/720P@15f/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps～4096Kbps，
For 720P:default value is 1.5Mbps，max value is 4Mbps.
For 1080P:default value is 1.5Mbps，max value is 4Mbps.
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
16-ch BNC port(HDCVI HD
video/general standard definition
video self-adaptive)
32-ch BNC port(HDCVI HD
video/general standard definition
video self-adaptive)
1.3.42 HCVR42XXAN-S3 Series
75
Model
Parameters
HCVR4216AN-S3
HCVR4232AN-S3
Network Video
Input
Max add 2 IP channel
connections
Analog
/digital channel
switch. Max 18 IP channel
connections
Connection
bandwidth:8Mbps-56Mbps
Analog
/digital channel
switch. Max 16 IP channel
connections
Connection bandwidth: Max
64Mbps
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same video
source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
External
Audio Input
1-ch，RCA port
Coaxial Audio
Input
16-ch
32-ch
Audio Output
1-ch RCA port
Bidirectional
Talk Input
Support（Reuse the audio port of the 1st channel）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback, smart
playback
Record
Playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
6T
8T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Other
Power
DC12V
Power
Consumption
（No HDD）
≤10
≤20W
Working
Temperature
-10℃－＋55℃
76
Model
Parameters
HCVR4216AN-S3
HCVR4232AN-S3
Working
Humidity
10%~90%
Dimension
1U case，375mm（W）×280mm（D）×50mm（H）
Weight
（No HDD）
≤1.8KG
≤3.3KG
Installation
Mode
Desk installation
Model
Parameters
HCVR5204A-S3
HCVR5208A-S3
HCVR5216A-S3
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
1080P@15f/1080N/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps～6144Kbps，
For 720P:default value is 2Mbps，max value is 4Mbps
For 1080P:default value is 2Mbps，max value is 6Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port (HDCVI
HD video/general
standard definition
video self-adaptive)
8-ch BNC port(HDCVI
HD video/general
standard definition
video self-adaptive)
16-ch BNC
port(HDCVI HD
video/general
standard definition
video self-adaptive)
1.3.43 HCVR52XXA-S3 Series
77
Model
Parameters
HCVR5204A-S3
HCVR5208A-S3
HCVR5216A-S3
Network Video
Input
Max add 2 IP
channel
connections
Analog
/digital channel
switch. Max 6 IP
channel
connections
Connection
bandwidth:8Mbps-
24Mbps
Max add 4 IP
channel
connections
Analog
/digital channel
switch. Max 12 IP
channel
connections
Connection
bandwidth:16Mbp
s-48Mbps
Max add 8 IP
channel
connections
Analog
/digital channel
switch. Max 24
IP channel
connections
Connection
bandwidth:32Mb
ps-96Mbps
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same video
source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
External
Audio Input
4-ch，RCA port,
Coaxial Audio
Input
4-ch
8-ch-
16-ch
Audio Output
1-ch RCA port
Bidirectional
Talk Input
Support（Reuse the audio port of the 1st channel）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback, smart
playback
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm input
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Other
Power
DC12V
Power
Consumption
（No HDD）
≤7W
≤8W
≤10W
78
Model
Parameters
HCVR5204A-S3
HCVR5208A-S3
HCVR5216A-S3
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1U case，375mm（W）×280mm（D）×50mm（H）
Weight
（no HDD）
≤1.5KG
≤1.65KG
≤1.8KG
Installation
Mode
Desk installation
1.3.44 HCVR52XXAN-S3 Series
Model
Parameters
HCVR5216AN-S3
HCVR5232AN-S3
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
1080P@15f/1080N/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps～6144Kbps，
For 720P:default value is 2Mbps，max value is 4Mbps
For 1080P:default value is 2Mbps，max value is 6Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
16-ch BNC port(HDCVI HD
video/general standard definition
video self-adaptive)
32-ch BNC port(HDCVI HD
video/general standard definition
video self-adaptive)
Network Video
Input
Max add 8 IP channel
connections
Analog
/digital channel
switch. Max 24 IP channel
connections
Connection
bandwidth:32Mbps-96Mbps
Analog
/digital channel
switch. Max 16 IP channel
connections
Connection bandwidth: Max
64Mbps
79
Model
Parameters
HCVR5216AN-S3
HCVR5232AN-S3
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same video
source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
External
Audio Input
1-ch，RCA port
Coaxial Audio
Input
16-ch
32-ch
Audio Output
1-ch RCA port
Bidirectional
Talk Input
Support（Reuse the audio port of the 1st channel）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback, smart
playback
Record
Playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
6T
8T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Other
Power
DC12V
Power
Consumption
（No HDD）
≤10W
≤25W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1U case，375mm（W）×280mm（D）×50mm（H）
Weight
（no HDD）
≤1.8KG
Installation
Mode
Desk installation
1.3.45 HCVR72XXA-S3/HCVR7216AN-S3 Series
80
Model
Parameters
HCVR7204A-S3
HCVR7208A-S3
HCVR7216A-S3
HCVR7216ANS3
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
1080P@15f/1080N/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps～6144Kbps，
For 720P:default value is 2Mbps，max value is 4Mbps
For 1080P:default value is 2Mbps，max value is 6Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(HDCVI HD
video/general
standard
definition video
self-adaptive)
8-ch BNC
port(HDCVI HD
video/general
standard
definition video
self-adaptive)
16-ch BNC
port(HDCVI HD
video/general
standard
definition video
self-adaptive)
16-ch BNC
port(HDCVI HD
video/general
standard
definition video
self-adaptive)
81
Model
Parameters
HCVR7204A-S3
HCVR7208A-S3
HCVR7216A-S3
HCVR7216ANS3
Network Video
Input
Max add 2
IP channel
connections
Analog
/digital
channel
switch. Max
6 IP channel
connections
Connection
bandwidth:8
Mbps-24Mb
ps
Max add 4
IP channel
connection
s
Analog
/digital
channel
switch.
Max 12 IP
channel
connection
s
Connectio
n
bandwidth:
16Mbps-48
Mbps
Max add 8
IP channel
connections
Analog
/digital
channel
switch. Max
24 IP
channel
connections
Connection
bandwidth:3
2Mbps-96M
bps
Max add 8
IP channel
connection
s
Analog
/digital
channel
switch.
Max 24 IP
channel
connection
s
Connection
bandwidth:
32Mbps-96
Mbps
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same video
source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
External
Audio Input
4-ch，RCA port,
1-ch，RCA port
Coaxial Audio
Input
4-ch
8-ch-
16-ch
16-ch
Audio Output
1-ch RCA port
Bidirectional
Talk Input
Support（Reuse the audio port of the 1st channel）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback, smart
playback
Record
Playback
Max 4-ch
playback
Max 8-ch
playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm input
N/A
Alarm Output
3-ch alarm output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
6T
Communication
Network
1 RJ45 port, 100Mbps Ethernet port
82
Model
Parameters
HCVR7204A-S3
HCVR7208A-S3
HCVR7216A-S3
HCVR7216ANS3
Port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Other
Power
DC12V
Power
Consumption
（No HDD）
≤8W
≤10W
≤15W
≤15W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1U case，375mm（W）×280mm（D）×50mm（H）
Weight
（no HDD）
≤1.5KG
≤1.65KG
≤1.8KG
≤1.8KG
Installation
Mode
Desk installation
Model
Parameters
HCVR5204L-V2
HCVR5208L-V2
HCVR5216L-V2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
1536Kbps-4096Kbps，
For 720P:default value is 2Mbps，max value is 4Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch, BNC port
8-ch, BNC port
16-ch, BNC port
Network Video
Input
Switch 2 analog channels to the IP channels（8Mbps）
1.3.46 HCVR52XXL-V2 Series
83
Model
Parameters
HCVR5204L-V2
HCVR5208L-V2
HCVR5216L-V2
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same video
source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch，RCA port, audio via coaxial cable
Audio Output
1-ch，RCA port
Bidirectional
Talk Input
Support（Reuse the audio port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch
playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
4-ch alarm input
8-ch alarm input
16-ch alarm input
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Other
Power
DC12V
Power
Consumption
≤30W（exclude HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1.5U case，440mm（W）×410mm（D）×70mm（H）
Weight
3.0kg～3.5kg（exclude HDD）
Installation
Mode
Desk installation
1.3.47 HCVR54XXL-V2 Series
Model
Parameters
HCVR5404L-V2
HCVR5408L-V2
HCVR5416L-V2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
84
Model
Parameters
HCVR5404L-V2
HCVR5408L-V2
HCVR5416L-V2
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
1536Kbps-4096Kbps，
For 720P:default value is 2Mbps，max value is 4Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch, BNC port
8-ch, BNC port
16-ch, BNC port
Network Video
Input
Switch 2 analog channels to the IP channels（8Mbps）
Video Output
1-ch VGA output,
1-ch HDMI output，
1-ch TV output,
HDMI/ VGA/TV video output at the same time (VGA/HDMI/TV of the
same video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch，BNC port, audio via coaxial cable
Audio Output
1-ch，BNC port
Bidirectional
Talk Input
Support（Independent bidirectional talk port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch
playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm input
Alarm Output
6-ch alarm output
HDD
HDD Port
4 SATA ports. Does not support eSATA port
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
1 RS232 port, 1 RS422 port, 1 RS485 port
USB
3 USB ports (One at the front panel and two at the rear panel)
Other
Power
AC90~264V 50+2% Hz (4/8-ch max 75W)
Power
Consumption
≤35W（exclude HDD）
85
Model
Parameters
HCVR5404L-V2
HCVR5408L-V2
HCVR5416L-V2
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1.5U case，440mm（W）×410mm（D）×70mm（H）
Weight
4.5kg～5.5kg（exclude HDD）
Installation
Mode
Desk/rack installation
Model
Parameters
HCVR4224L-S2
HCVR4232L-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
720P(1-15fps)/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
HDCVI：1～15f/s（The 1st/ 2nd channel supports 25/30f/s）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
1024Kbps～4096Kbps，
For 720P realtime (The first two channels):default value is 2Mbps，max
value is 4Mbps.
For 720P non-realtime: default value is 1Mbps，max value is 2Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
24-ch, BNC port
32-ch, BNC port
Network Video
Input
Max 4 IPC connections（16Mbps）
Video Output
1-ch VGA output,
1-ch HDMI output，
HDMI/ VGA video output at the same time (VGA/HDMI of the same video
source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch，RCA port, Coaxible audio
4-ch， RCA port. Coaxible
audio
1.3.48 HCVR4224/32L-S2 Series
86
Model
Parameters
HCVR4224L-S2
HCVR4232L-S2
Audio Output
1-ch，RCA port
Bidirectional
Talk Input
Support（Reuse the audio port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
16-channel alarm input
Alarm Output
3-channel alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
1 RS232 port, 1 RS485 port
USB
2 USB ports
Other
Power
DC12V/5A
Power
Consumption
≤30W（With adapter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1.5U case，440mm（W）×410mm（D）×70mm（H）
Weight
4.5-5.5kg（no HDD）
Installation
Mode
Desk/rack installation
Model
Parameters
HCVR4404L-S2
HCVR4408L-S2
HCVR4416L-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
HDCVI：1～15f/s（The 1st channel supports 25/30f/s）
CVBS：1~25f/s（PAL）； 1~30f/s（NTSC）
Video Bit Rate
1536Kbps-4096Kbps，
For 720P:default value is 2Mbps，max value is 4Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
1.3.49 HCVR44XXL-S2 Series
87
Model
Parameters
HCVR4404L-S2
HCVR4408L-S2
HCVR4416L-S2
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch, BNC port
8-ch, BNC port
16-ch, BNC port
Network Video
Input
Switch 2 analog channels to the IP channels（8Mbps）
Video Output
1-ch VGA output,
1-ch HDMI output，
1-ch TV output,
HDMI/ VGA/TV video output at the same time (VGA/HDMI/TV of the
same video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch，BNC port, audio via coaxial cable
Audio Output
1-ch，BNC port
Bidirectional
Talk Input
Support（Independent bidirectional talk port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch
playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm input
Alarm Output
6-ch alarm output
HDD
HDD Port
4 SATA ports. Does not support eSATA port
Space/HDD
6T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
1 RS232 port, 1 RS422 port, 1 RS485 port
USB
3 USB ports (One at the front panel and two at the rear panel)
Other
Power
AC90~264V 50+2% Hz (4/8-ch max 75W)
Power
Consumption
≤35W（exclude HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1.5U case，440mm（W）×410mm（D）×70mm（H）
Weight
4.5kg～5.5kg（exclude HDD）
