1 Megapixel HDCVI Pinhole Camera User's Manual
Version 1.0.0
i
Table of Contents
1 General Introduction .................................................................................................................. 1
1.1 Overview ........................................................................................................................ 1
1.2 Features ......................................................................................................................... 1
1.3 Functions ....................................................................................................................... 1
1.4 Specifications ................................................................................................................ 2
2 Framework and Dimensions ..................................................................................................... 3
HAC-HUM3100BP/N................................................................................................................. 3
3 Installation.................................................................................................................................... 5
4 Menu ............................................................................................................................................. 6
4.1 HDCVI Series DVR Settings ....................................................................................... 6
4.2 Menu List ....................................................................................................................... 7
Appendix Toxic or Hazardous Materials or Elements ................................................................. 8
ii
Welcome
Thank you for purchasing our HDCVI camera!
This user’s manual is designed to be a reference tool for your system.
Please read the following safeguard and warnings carefully before you use this series product!
Please keep this user’s manual well for future reference!
iii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited
power source is rated 12V DC (24V AC) in the IEC60950-1.
We assume no liability or responsibility for all the fires or electrical shock caused by improper handling
or installation.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation
Do not apply power to the camera before completing installation.
Please install the proper power cut-off device during the installation connection.
Always follow the instruction guide the manufacturer recommended.
If this product is installed in the ceiling, please make sure the installation position can sustain the min
50N.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
This series camera should be installed in a cool, dry place away from direct sunlight or strong light,
inflammable, explosive substances and etc.
This series camera shall work on the specified working temperature. Please keep it away from the
electromagnetic radiation object and environment.
Please keep the sound ventilation.
Do not allow the water and other liquid falling into the camera.
6. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
7. Daily Maintenance
Please shut down the device and then unplug the power cable before you begin daily maintenance
work.
iv
Use the dry soft cloth to clean the device.
If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean
the device. Finally use the dry cloth to clean the device.
Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.
1
1 General Introduction
1.1 Overview
This series megapixel HD camera conforms to the HDCVI standard. It supports video signal high-speed
long distance transmission without any delay. It can be controlled by the DVR conforming to the HDCVI.
1.2 Features
High-performance CMOS image sensor, megapixel definition.
Support HDCVI high definition video output.
Support video, audio, control coaxial transmission.
Support 75-3 coaxial cable transmission without any loss. Transmission distance is over 500m.
High speed, long distance real-time transmission.
Support auto exposure, auto white balance, auto electronic gain function.
High image color rendition, vivid image.
Support OSD menu.
Support DC12V power supplying.
1.3 Functions
HDCVI Specification
HDCVI（High Definition Composite Video Interface） is an over-coaxial –cable HD video transmission
standard. It’s a kind of HD video which adopts analog modulation technique to transfer with progressive
scanning.
OSD (On Screen Display)
Camera supports user-friendly screen menu function, making it convenient for users to select different
functions.
Auto gain function
To output the standard video signal in the different illumination environments, the amplifier needs to adjust
in a wide range. The system can enhance the camera sensitivity in low illumination and enhance the video
signal output to get the clear and high definition video.
Auto white balance
The white balance refers to the camera to restore the white object color. It allows the camera to
automatically adjust the color temperature in indoor and outdoor environment. Human eyes see white is
still white whether in indoor or outdoor environment because human eyes can adapt to the changes of
color temperature, while the camera can’t adapt to the changes as human eyes do. Therefore, white will
turn to other colors after the environment is changed, which can be fixed by AWB correctly.
Auto exposure
System can automatically set shutter speed and iris value according to the snapshot video exposure
condition.
2
1.4 Specifications
Model
Parameter
1 Megapixel HDCVI Pinhole Camera
HAC-HUM3100BP/N
Sensor Type
1/2.9" 1.0 Mega Pixels CMOS
Video Format
PAL/NTSC
Effective Pixel
1280（H）* 720（V）
Min Illumination
0.01Lux@（F1.2，AGC ON）
Electronic Shutter
PAL：1/50s~1/100,000s
NTSC：1/60s~1/100,000s
Video Standard
HDCVI compliance
Video Frame Rate
PAL：1280×720@25 fps
NTSC：1280×720@30 fps
Lens Port
M12
Lens Type
2.8/3.6 mm optional
Day/Night Switch
Auto
Video Output
1-channel HDCVI high definition video output
Video Input
1-channel audio input, receive audio signal from device like sound pickup
Audio Coaxial
Support audio and video coaxial transmission
Control Coaxial
Support menu control and video coaxial transmission
Menu
Control
Exposure
Shutter/AGC/brightness
White Balance
Mode/R gain /B gain
Day/Night Mode
Mode / D→N LEVEL / N→D LEVEL
Image Setup
Brightness/ contrast/ color gain/sharpness/NR/mirror/language
Function Setup
Flicker/OSD color/OSD BG
Reset
-
Save & Exit
-
Max Transmission
Distance
Over 500m via 75-3 coaxial cable.
Working Temperature
/Humidity
-30℃~+60℃. Humidity is less than 95%(no condensation)
Power
DC 12V±10%
Power Consumption
1.44W MAX (Input: 12V 0.12A)
Dimension(mm)
30*30*15.9
Weight
50g
3
2 Framework and Dimensions
HAC-HUM3100BP/N
Please refer to the following figures for dimension information. The unit is mm. See
Figure 2-1 and Figure 2-2.
Figure 2-1
Figure 2-2
SN
Name
Function
1
Lens
Receive optical signal in the environment
2
Bracket
Used to fix camera
3
Front Cover
-
4
Reserved Audio Input Port
Can be connected to external pick-up
5
Rear Cover
-
4
SN
Name
Function
6
Power Input Port
Connect DC+12V power, input power
7
Video Output Port
BNC port, output HDCVI HD video signal, rear-end needs
to connect HDCVI series DVR to control.
5
3 Installation
Important
Please make sure the installation surface can min support the 3X weight of the camera and the
bracket.
Figure 3-1
壳体锁紧螺钉: Housing Lock Screw
固定面：Fixed Surface
安装螺钉：Installation Screw
镜头紧固螺钉：Lens Fastening Screw
Step1
Install the camera and the bracket on the fixed surface and secure the installation screw.
Step 2
Adjust the camera angle and secure the housing lock screw.
Step 3
Connect the video output port of device cable with rear-end HDVR device and connect the power port of
device cable to power supply.
Step 4
Adjust camera’s focal length after the rear-end HCVR displays image and secure the lens fastening screw
(Generally it has been set before delivery, can be ignored)
So far, the installation is completed.
6
4 Menu
4.1 HDCVI Series DVR Settings
Note
The following operation and interfaces for reference only. Please refer to the HDCVI series DVR user’s
manual for detailed information.
This HDCVI camera series can adjust OSD menu by coaxial control. After connected the camera to the
HDCVI series DVR from” Main Menu-->System->PTZ”, you need to set as follows: select the access
channel and select “control mode” as “HDCVI” and the “protocol” as “DH-SD1”.
Figure 4-1
After you saved settings, right click mouse and select “PTZ Control”, then click to enter the menu. See
Figure 4-2.
Figure 4-2
Single click to enter 4-direction button menu control interface.
7
Click up/down button to view all the items on the left pane of the following list. Click left/right button to set
the corresponding values on the right pane of the following list. If there is “ ”, click confirm button to go to
the 2nd menu. Repeat the previous steps to set detailed value. Click Return button to go back to the
previous menu interface.
4.2 Menu List
The First Menu
The Second Menu
EXPOSURE
SHUTTER
AUTO，1/100,1/120,1/250，
1/500,1/1000,1/2000,1/4000,1/10000,1/100000
AGC
OFF/LOW/MIDDLE/HIGH
BRIGHTNESS
1-10
RETURN
WHITE
BALANCE
MODE
INDOOR/OUTDOOR/USER/AUTO
R GAIN
B GAIN
RETURN
DAY&NIGHT
MODE
AUTO/SMART/COLOR/BW
D→N LEVEL
1-5
N→D LEVEL
1-5
RETURN
IMAGE SETUP
BRIGHTNESS
1-10
CONTRAST
1-10
COLOR GAIN
1-10
SHARPNESS
1-10
NR
OFF/LOW/MIDDLE/HIGH
MIRROR
NONE/H/V/HV
LANGUAGE
ENGLISH
RETURN
FUNC.SETUP
FLICKER
50Hz/60Hz
OSD COLOR
WHITE/YELLOW/RED/GREEN
OSD BG
OFF/ON
RETURN
RESET
SAVE&EXIT
8
Appendix Toxic or Hazardous Materials or Elements
Component
Name
Toxic or Hazardous Materials or Elements
Pb
Hg
Cd
Cr VI
PBB
PBDE
Circuit Board
Component
○ ○ ○ ○ ○
○
Device
Construction
Material
○ ○ ○ ○ ○ ○
Wire and Cable
○ ○ ○ ○ ○ ○
Packing
Components
○ ○ ○ ○ ○
○
Accessories
○ ○ ○ ○ ○
○
O: Indicates that the concentration of the hazardous substance in all homogeneous materials in the parts
is below the relevant threshold of the SJ/T11363-2006 standard.
X: Indicates that the concentration of the hazardous substance of at least one of all homogeneous
materials in the parts is above the relevant threshold of the SJ/T11363-2006 standard. During the
environmental-friendly use period (EFUP) period, the toxic or hazardous substance or elements contained
in products will not leak or mutate so that the use of these (substances or elements) will not result in any
severe environmental pollution, any bodily injury or damage to any assets. The consumer is not authorized
to process such kind of substances or elements, please return to the corresponding local authorities to
process according to your local government statutes.
Note
This manual is for reference only. Slight difference may be found in the user interface.
All the designs and software here are subject to change without prior written notice.
All trademarks and registered trademarks mentioned are the properties of their respective
owners.
If there is any uncertainty or controversy, please refer to the final explanation of us.
Please visit our website or contact your local service engineer for more information.
