Dahua DH-IPC-HFW2230S-S-S2 User Manual

Lite Series | DH-IPC-HFW2230S-S-S2

2

Mp

IP67

H.265+

Starlight

IVS

DH-IPC-HFW2230S-S-S2

2MP IR Bullet Network Camera

· 2MP, 1/2.7” CMOS image sensor, low illuminance, high image denion

· Outputs 2MP (1920 × 1080)@25/30 fps

· H.265 codec, high compression rate, ultra-low bit rate

· Built-in IR LED, max IR distance: 30 m

· ROI, SMART H.264/H.265, exible coding, applicable to various

bandwidth and storage environments

· Rotaon mode, DWDR, 3D DNR, HLC, BLC, digital watermarking,

applicable to various monitoring scenes

· Intelligent detecon: Intrusion, tripwire

· Abnormality detecon: Moon detecon, video tampering, no SD card,

SD card full, SD card error, network disconnected, IP conict, illegal

access, voltage detecon

· Supports max. 256 GB Micro SD card

· 12 V D C/ PO E p ower support

· IP67 protecon

System Overview

With upgraded H.265 encoding technology, Dahua Lite series camera has

ecient video encoding capacity, which saves bandwidth and storage

space. This camera adopts the latest starlight technology and displays

beer colorful image in the environment of low illuminaon. It supports
SD card storage, waterproof funcon, dust-proof funcon, complying to
the standards of IP67.

Funcons

Smart ( H.265+ & H.264+ )

Adopng advanced algorithm of auto stream control according to the
environment, Dahua smart encoding technology realizes the higher e­ciency than (H.265 & H.264 ), providing high-quality video, and reducing
the cost of storage and transmission.

Starlight

Dahua Starlight technology mainly applies to the environment of low
illuminaon, and it can provide clear colorful video. Even in the envi­ronment of min. illuminaon, the technology can guarantee the good
image eect.

Intelligent Video Analysis (IVS)

With advanced video algorithm, Dahua camera supports intelligent
detecon, such as tripwire and intrusion and so on.

Protecon (IP67, wide voltage)

IP67: The camera passes a series of strict test on dust and soak. It
has dust-proof funcon, and the enclosure can works normal aer
soaking in 1 m deep water for 30 minutes.
Wide voltage: The camera allows ±30% input voltage tolerance (wide
voltage range), and it is widely applied to outdoor environment with
instable voltage.

www.dahuasecurity.com

Lite Series | DH-IPC-HFW2230S-S-S2

Technical Specificaon

Camera

Image Sensor

Effective Pixels

ROM

RAM

Scanning System

Electronic Shutter Speed

Min. Illumination

IR Distance

IR On/Off Control

IR LEDs Number

Pan/Tilt/Rotation Range

Lens

Lens Ty pe

Mount Type

Focal Length

Max. Aper ture

Field of View

Iris Ty pe

Close Focus Distance

Lens

DORI

Distance

2.8 mm

3.6 mm

Smart event

General IVS Analytic s

1/2.7”2Megapixel progressive CMOS

1920 (H) × 1080 (V)

128 MB

128 MB

Progressive

Auto/Manual 1/3 s–1/100000 s

0.005 Lux@F1.6

30 m (98.43 ft)

Auto/Manual

1

Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°

Fixed-focal

M12

2.8 mm

3.6 mm

F1.6
F1.6

2.8 mm:
Pan: 110.0°
Tilt: 59.0°
Diagonal: 132.0°

3.6 mm:
Pan: 91.0°
Tilt: 48.0°
Diagonal: 109.0°

Fixed aperture

2.8 mm: 0.6 m (1.97 ft)

3.6 mm: 1.1 m (3.61 ft)

Detect Observe Recognize Identify

37.3 m
(122.38 ft)

53.3 m

(174.87 ft)

Tripwire; intrusion

14.9 m
(48.88 f t)

21.3 m

(96.88 f t)

7.5 m
(24.61 ft)

10.7 m
(35.10 ft)

3.7 m
(12.14 ft)

5.3 m

(17. 39 ft)

Resolution

Bit Rate Control

Video Bit Rate

Day/Night

BLC

HLC

WDR

White Balance

Gain Control

Noise Reduction

Motion Detection

Region of Interest(RoI)

Smart IR

Image Rotation

Mirror

Privacy Masking

Network

Network

Protocol

Interoperability

Use r/Host

Edge Storage

Browser

Management Software

Mobile Phone

1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 ×

720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF
(352 × 288/352 × 240)

CBR/VBR

H.264: 32 Kbps–6144 Kbps
H.265: 12 Kbps–6144 Kbps

Auto(ICR)/Color/B/W

Yes

Yes

DWDR

Auto/natural/street lamp/outdoor/manual/regional
custom

Auto/Manual

3D DNR

OFF/ON (4 areas, rectangular)

Yes (4 areas)

Yes

0°/90°/180°/270° (Supports 90°/270° with 1080p

resolution and lower.)

Yes

4 areas

RJ- 45 (10/100 Base-T)

IPv4; IPv6; HTTP; HT TPS; TCP; UDP; ARP; RTP ; RTSP;

RTCP; RTMP; SMTP; FTP; SF TP; DHCP; DNS; DDNS;

QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE;

802.1x; Bonjour

ONVIF(Profile S/Prof ile G/Profile T);CGI; P2P;
Milestone; Genetec

20

Dahua Cloud; FTP; SFTP; Micro SD Card (suppor t max.
256 GB); NAS

IE

Chrome

Firefox

Smart PSS; DSS; DMSS

IOS; Android

Video

Video Compression

Smart Codec

Video Frame Rate

Stream Capability

H.265; H.264; H.26 4B; MJPEG

Yes

Main stream:
1920 × 1080 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps)

2 streams

Certification

Certifications

Power

Power Supply

Power Consumption

www.dahuasecurity.com

CE-LVD: EN60 950-1
CE-EMC: Ele ctromagnetic Compatibility Dire ctive
2014/3 0/EU
FCC: 47 CFR FCC Par t 15, Subpar t B
UL/CUL: UL60950 -1 CAN/CSA C22.2 No.60950 -1-07

12V DC/PoE (802.3af)

< 4.6W
