DH-IPC-HFW2230S-AS-S2
Build-in Mic 2MP IR Bullet Network Camera
Lite Series | DH-IPC-HFW2230S-AS-S2
2
Mp
H.265+
IVS
IP67
· 2MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
· Outputs 2MP (1920 × 1080)@25/30 fps
· H.265 codec, high compression rate, ultra-low bit rate
· Built-in IR LED, max IR distance: 30 m
· ROI, SMART H.264/H.265, flexible coding, applicable to various
bandwidth and storageenvironments
· Rotation mode, DWDR, 3D DNR, HLC, BLC, digital watermarking,
applicable to various monitoring scenes
· Intelligent detection: Intrusion, tripwire
· Abnormality detection: Motion detection, video tampering, no SD card,
SD card full, SD card error, network disconnected, IP conflict, illegal
access, voltage detection
· Supports max. 256 GB Micro SD card
· Build-in Mic
· 12V DC/POE power support
· IP67 protection
System Overview
With upgraded H.265 encoding technology, Dahua Lite series camera has
efficient video encoding capacity, which saves bandwidth and storage
space. This camera adopts the latest starlight technology and displays
better colorful image in the environment of low illumination. It supports
SD card storage, waterproof function, dust-proof function, complying to
the standards of IP67.
Functions
Smart ( H.265+ & H.264+ )
Adopting advanced algorithm of auto stream control according to the
environment, Dahua smart encoding technology realizes the higher efficiency than (H.265 & H.264 ), providing high-quality video, and reducing
the cost of storage and transmission.
Intelligent Video Analysis (IVS)
With advanced video algorithm, Dahua camera supports intelligent
detection, such as tripwire and intrusion and so on.
Protection (IP67, wide voltage)
IP67: The camera passes a series of strict test on dust and soak. It
has dust-proof function, and the enclosure can works normal after
soaking in 1 m deep water for 30minutes.
Wide voltage: The camera allows ±30% input voltage tolerance (wide
voltage range), and it is widely applied to outdoor environment with
instable voltage.
Starlight
Dahua Starlight technology mainly applies to the environment of low
illumination, and it can provide clear colorful video. Even in the environment of min. illumination, the technology can guarantee the good
image effect.
Lite Series | DH-IPC-HFW2230S-AS-S2
www.d ahuasecurit y.com
Technical Specification
Camera
Resolution
1080p (192 0 × 108 0); 1.3M (1 280 × 960 ); 720 p (128 0 ×
720); D 1 (704 × 576/704 × 48 0); VG A (640 × 480); CIF
(352 × 288/352 × 240)
Bit Rate Control
CBR/V BR
Video Bit Rate
H.264: 32 Kb ps–6144 K bps
H.265: 12 Kb ps–6144 K bps
Day/Night
Auto(I CR)/Color/B/W
BLC
Yes
HLC
Yes
WDR
DWD R
White Balance
Auto/n atur al/stre et lamp/o utdoor/manual/regiona l
custom
Gain Control
Auto/M anual
Noise Reduction
3D DNR
Motion Detection
OFF/ ON (4 areas, recta ngular)
Region of Interest(RoI)
Yes (4 areas)
Smart IR
Yes
Image Rotation
0°/90°/180 °/2 70° (Su pports 90°/270 ° with 1080p
resolut ion.)
Mirror
Yes
Privacy Masking
4 are as
Video Compression
H.265; H.26 4; H.2 64B; MJPEG
Smart Codec
Yes
Video Frame Rate
Main strea m:
1920 × 1080 (1 fp s-25/30 fps)
Sub st ream:
704 × 5 76 (1 fps-25 fps)
704 × 4 80 (1 fps-30 fps)
Stream Capability
2 strea ms
Image Sensor
1/2.7” 2Megapixel pro gressive CMOS
Effective Pixels
1920 (H) × 1080 (V)
ROM
128 M B
RAM
128 M B
Scanning System
Progress ive
Electronic Shutter Speed
Auto/M anual 1/3 s–1/ 10000 0 s
Min. Illumination
0.005 Lux@F 1.6
IR Distance
30 m (98.4 3 ft)
IR On/Off Control
Auto/M anual
IR LEDs Number
1
Pan/Tilt/Rotation Range
Horiz onal: 0°– 360°
Vertical: 0°–90°
Rotatio n: 0°–360°
Lens
Lens Type
Fixed
Mount Type
M12
Focal Length
2.8 mm
3.6 mm
Max. Aperture
F1.6
F1.6
Field of View
2.8 mm:
Horiz onal: 110.0°
Vertical: 59. 0°
Diagon al: 132.0°
3.6 mm:
Horiz onal: 91.0°
Vertical: 48. 0°
Diagon al: 109.0°
Iris Type
Fixed apertu re
Close Focus Distance
2.8 mm: 0.6 m (1 .97 ft)
3.6 mm: 1.1 m (3 .61 ft)
DORI
Distance
Lens
Detect
Observe
Recognize
Identi fy
2.8 mm
37.3 m
(122.38 ft)
14.9 m
(48.88 ft)
7.5 m
(24.61 ft)
3.7 m
(12.14 ft)
3.6 mm
53.3 m
(174.87 ft)
21.3 m
(96.88 ft)
10.7 m
(35.10 ft)
5.3 m
(17.39 ft)
Smart event
General IVS Analytics
Intrusio n; tripwire
Network
RJ-45 (10 /100 Base -T)
Protocol
HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP;
DHCP; DNS; DDNS; PP PoE; IP v4/v6; QoS; UPnP; NT P;
RTMP; Multicast; HTTPS; SF TP; 802.1x; ICMP; IGM P
Interoperability
ONVIF (Profile S/Profile G);CGI;P2P; Milestone;Genetec
User/Host
20
Edge Storage
Dahua Cloud; FTP; Micro SD Card (supp ort m ax. 256
GB); NAS
Browser
IE
Chrom e
Firefox
Management Software
Smart PSS; D SS; D MSS
Mobile Phone
IOS; An droid
Certification
Certifications
CE-LVD: EN60 950 -1
CE-EMC: Ele ctromagneti c Com patibility Directive
2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CU L: UL60950 -1 CAN/C SA C22.2 No.609 50-1 -07
Power
Power Supply
12V D C/PoE (802 .3af)
Power Consumption
< 4.6 W
Environment
Operating Conditions
-40°C to +60°C (-40°F t o +140°F)/l ess than ≤ 95%
