Dahua DH-IPC-HF7442F User Manual

| DH-IPC-HF7442F

DH-IPC-HF7442F

4MP BOX WizMind Network Camera

Launched by Dahua Technology, Dahua WizMind is a full porolio of
soluons composed of project-oriented products including IPC, NVR,
PTZ, XVR, Thermal and soware plaorm which adopts industry-leading

deep learning algorithms. Focusing on customer’s requirements,

WizMind provides precise, reliable and comprehensive AI soluons for
vercals.

· 4MP, 1/1.8" CMOS image sensor, low illuminance, high image denion

· Max outputs 4MP (2688×1520) @50 fps/60 fps

· H.264&H.265 coding, high compression raon · Wide dynamic, day/

night, 3D NR, AWB, HLC, BLC

· ROI, SVC, SMART H.264+/H.265+, exible coding, applicable to various

bandwidth and storage environments

· With deep learning algorithm, it supports people counng, face detec

on, perimeter protecon etc

· Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485; BNC; supports max. 256 G

SD card

· 24V AC/PoE/12V DC power support

· Five streams for three-channel HD video

· 12V DC power output, max. current 165mA , easy for installaon

Series Overview

With advanced deep learning algorithm, Dahua WizMind 7 Series

network camera supports various intelligent funcons and sases the
requirements in dierent scenes. The camera can accurately recognize
person, vehicle, and non-motor vehicle, face, ANPR, and liveness. This
series camera has ultra starlight night version eect, and works with
ultra-low stream. It supports dust-proof funcon, waterproof funcon
and vandal-proof funcon, complying with the standards of IP67 and

IK10 (Supported by some select models).

Funcons

Face Detecon

Dahua Face Detecon technology can detect the face in the image.
With deep learning algorithm, the technology supports detecng, track­ing, capturing and selecng the best face image, and then outputs face

snapshot.

People Counng

With deep learning algorithm, Dahua People Counng technology can

track and process moving human body targets to realize the accurate

stascs of enter No., leave No., and In Area No. Working with manage­ment plaorm, it outputs reports to meet your requirements.

Video Metadata

With deep learning algorithm, Dahua Video Metadata technology can

detect, track, capture vehicle, non-motor vehicle and people, and select

the best images, and extract aributes.

Smart H.265+ & Smart H.264+

With advanced scene-adapve rate control algorithm, Dahua smart
encoding technology realizes the higher encoding eciency than H.265
and H.264, provides high-quality video, and reduces the cost of storage

and transmission.

ePoE

Dahua ePoE technology provides a new way to accomplish long distance
transmission between IP camera and network switch. It allows more

exible surveillance system design, improves reliability and saves con­strucon and wiring cost.

Perimeter Protecon

With deep learning algorithm, Dahua Perimeter Protecon technology

can recognize human and vehicle accurately. In restricted area (such as
pedestrian area and vehicle area), the false alarms of intelligent detec-

on based on target type (such as tripwire, intrusion, fast moving, park­ing detecon, loitering detecon and gathering detecon) are largely

reduced.

Privacy Protecon

Dahua Privacy Protecon technology can mask the detected face and

human body to protect the privacy of some special targets.

ANPR

With high-performance GPU chip, deep learning algorithm, and lots of

sample training learning, Dahua ANPR technology can automacally col­lect and recognize the vehicle informaon, including license plate, logo,

vehicle type, and vehicle color.

www.dahuasecurity.com

| DH-IPC-HF7442F

Technical Specificaon

Camera

Image Sensor

Effective Pixels

ROM

RAM

Scanning System

Electronic Shutter Speed

Min. Illumination

S/N Ratio

Lens

Lens Typ e

Mount Type

Smart event

IVS

Professional, intelligent

IVS (Perimeter Protection)

Face Detection

ANPR

Video Metadata

People Counting

Intelligent Search

Video

Video Compression

Smart Codec

1/1.8” 4Megapixel progressive CMOS

2688 (H) × 1520 (V)

4 GB

2 GB

Progressive

Auto/Manual 1/3 s–1/10000 0 s

0.001 Lux@F1.5

> 56 dB

Manual vari-focal

C/CS

Abandoned objec t, moving object

Tripwire, intrusion, fast moving (the three functions
suppor t the classification and accurate detection
of vehicle and human); parking detection, loitering
detection, and people gathering.

Face detection, track, priority, snapshot,Upload
Optimized snapshot picture; face
enhancement, face e xposure, face attribute extract,

6 attributes and 8 expressions: Gender, age, glasses,

expressions (anger, sadness, disgust, fear, surprise,
calm, happiness and confusion), Mouth mask, beard;
Face matting setting: face, single inch photo Three
snapshot;
methods: real-time snapshot, priority snapshot, quality
priority;
Face angle f ilter Priority time set ting;
Support Duration Optimal,Non-living Filtering;

ANPR, track, priority, snapshot
Vehicle attributes: license plate, vehicle type, vehicle

color,vehicle brand
Other at tributes: sun visor, seat belt, smoking,
phoning, in-car accessories, annual vehicle inspection
mark

Suppor t human body, human face, motor vehicle
and non-motor vehicle image capture and attributes
extraction.

Support tripwire number counting, people counting in
area, and displaying and outputting yearly/monthly/
daily reports.Support queue management, and
displaying and outputting monthly/daily reports.
Support 4 tripwire rules configuration, people
counting in 4 areas, and 4 queue management
functions

Work together with Smar t NVR to per form ref ine

intelligent search, event extraction and merging to
event videos.

H.265, H.264, H.264H, H.26 4B, MJPEG(only suppor ted

by sub stream)

Smart H.265+/ Smart H.264+

Video Frame Rate

Stream Capability

Resolution

Bit Rate Control

Video Bit Rate

Day/Night

BLC

HLC

WDR

Scene Self-adaptation

White Balance

Gain Control

Noise Reduction

Motion Detection

Region of Interest(RoI)

Electronic Image
Stabilization(EIS)

Defog

Image Rotation

Mirror

Privacy Masking

Audio

Built-in MIC

Audio Compression

Alarm

Alarm Event

Network

Network

SDK and API

Protocol

Interoperability

Main Stream: 2688 × 1520 (1–50/60 fps)
Sub stream: 70 4 × 576 (1–25fps);704 × 480 (1–30fps)
Third stream: 1920 × 1080 (1–25/30 fps)
Fourth stream: 1920 × 1080 (1–25/30 fps)
Fifth stream: 704 × 576 (1–25fps);704 × 480 (1–30fps)

5 streams

4M (2688 × 1520), 3M (2304 × 1296), 1080p (1920 ×

1080), 1.3M (1280 × 960), 720P (1280 × 720),
D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 x
288/352 x 240)

CBR/VBR

H.264: 32 kbps–10240 kbps
H.265: 12 kbps–10240 kbps

Auto (ICR)/Color/B/W

Yes

Yes

140 dB

Yes

Auto/natural/street lamp/outdoor/manual/regional
custom

Auto/Manual

3D NR

OFF/ON (4 areas, rectangular)

Yes (4 areas)

Yes

Yes

0°/ 90°/180°/270° (Support 90°/270° with 1080 p
resolution or below.)

Yes

4 areas

Yes

G.711a; G.711Mu; G726; AAC; G.723

No SD card; SD card full; SD card error; networ k
disconnection; IP conflict; illegal access; motion
detection; video tampering; tripwire; intrusion; fast

moving; abandoned object; missing object; loi tering

detection; people gathering; parking detection; scene
changing; audio detectio n; defocus detection; external
alarm; face detection; people counting in area; stay
alarm; people counting; people counting exception
detection; safet y exception, Queue Management

RJ- 45 (10/100/100 0 Base-T)

Yes

HTT P; Https; 802.1x; TCP; ARP; RTSP; RTP; UDP; RTCP;
SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP;
QoS; UPnP; NTP; SFTP; RTMP; Genetec;B onjour ;

Multicast

ONVIF (Prof ile S/Profile G/Profile T); CGI; Milestone;
Genetec; P2P;RTMP
