Dahua DH-IPC-HDBW3541R-ZS User Manual

| DH-IPC-HDBW3541R-ZS

DH-IPC-HDBW3541R-ZS

5MP IR Vari-focal Dome WizSense Network Camera

Launched by Dahua Technology, WizSense is a series of AI products

and soluons that adopt independent AI chip and deep learning

algorithm. It focuses on human and vehicle with high accuracy,

enabling users to fast act on dened targets. Based on Dahua's

advanced technologies, WizSense provides intelligent, simple

and inclusive products and soluons.

· 5MP, 1/2.7” CMOS image sensor, low illuminance, high image definition

· Outputs max. 5MP (2592 × 1944) @20 fps, and supports 4MP (2688 ×

1520) @25/30 fps

· H.265 codec, high compression rate, low bit rate

· Built-in IR LED, max. IR distance: 40 m

· ROI, SMART H.264+/H.265+, flexible coding, applicable to various

bandwidth and storage environments

· Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking,

applicable to various monitoring scenes

· Intelligent detecon: Intrusion, tripwire (support the classicaon and

accurate detecon of vehicle and human)

· Abnormality detecon: Moon detecon, video tempering, scene

changing, no SD card, SD card full, SD card error, network

disconnecon, IP conict, illegal access, voltage detecon

· Supports max. 256 G Micro SD card

· 12V DC/POE power supply

· IP67, IK10 protecon

· SMD Plus

Series Overview

With advanced deep learning algorithm, Dahua WizSense 3 Series

network camera supports intelligent funcons, such as perimeter
protecon and smart moon detecon. With starlight technology, this
series camera provides a beer image eect in the condion of low

illuminance.

Funcons

SMD Plus

With intelligent algorithm, Dahua Smart Moon Detecon technology
can categorize the targets that trigger moon detecon and lter the
moon detecon alarm triggered by non-concerned targets to realize
eecve and accurate alarm.

Smart H.265+ & Smart H.264+

With advanced scene-adapve rate control algorithm, Dahua smart
encoding technology realizes the higher encoding eciency than H.265

and H.264, provides high-quality video, and reduces the cost of storage
and transmission.

Perimeter Protecon

With deep learning algorithm, Dahua Perimeter Protecon technology

can recognize human and vehicle accurately. In restricted area (such
as pedestrian area and vehicle area), the false alarms of intelligent

detecon based on target type (such as tripwire, intrusion, fast moving,
parking detecon, loitering detecon and gathering detecon) are

largely reduced.

Starlight

Dahua Starlight technology mainly applies to the environment of

low illuminaon, and it can provide clear colorful video. Even in the
environment of min. illuminaon, the technology can guarantee the
good image eect.

WDR

With advanced Wide Dynamic Range (WDR) technology, Dahua network
camera provides clear details in the environment of strong brightness
contrast. The bright and dark area can get clear video even in high
brightness environment or with backlight shadow.

Protecon (IP67, IK10, wide voltage)

IP67: The camera passes a series of strict test on dust and soak. It has

dust-proof funcon, and the enclosure can works normal aer soaking

in 1 m deep water for 30 minutes.

IK10: The enclosure can stand the punch more than 5 mes from a 5 kg

hammer falling from a height of 40 cm (Impact energy is 20J).
Wide voltage: The camera allows ±30% input voltage tolerance (wide
voltage range), and it is widely applied to outdoor environment with
instable voltage.

www.dahuasecurity.com

| DH-IPC-HDBW3541R-ZS

Technical Specificaon

Camera

Image Sensor

Max. Resolution

ROM

RAM

Scanning System

Electronic Shutter Speed

Min. Illumination

S/N Ratio

Illumination Distance

Illuminator On/Off Control

Illuminator Number

Pan/Tilt/Rotation Range Pan: 0°–355°; Tilt: 0°–75°;Rotation: 0°–355°

1/2.7”5Megapixel progressive CMOS

2592 (H) ×1944 (V)

128 MB

512 MB

Progressive

Auto/Manual 1/3 s–1/100 000 s

0.005 Lux@F1.5

> 56 dB

40 m (131.23 ft)

Auto/Manual

2 (IR LED)

Lens

Lens

W

T

Motorized vari-focal

φ14

2.7 mm–13.5 mm

F1.5

Horizontal: 99°–26°
Vertical: 72° –20°
Diagonal: 133° –33°

Fixed

0.8 m (2.6 ft)

Detect Observe Recognize Idenfy

64.0 m

(210.0 )

222.0 m

(728.3 )

25.6 m

(84.0 )

88.8 m

(291.3 )

12.8 m

(42.0 )

44.4 m

(145.7 )

Lens Ty pe

Mount Type

Focal Length

Max. Aperture

Field of View

Iris Type

Close Focus Distance

DORI Distance

Professional, Intelligent

Perimeter Protection

Intelligent Search

Tripwire; intrusion (Recognition of human and vehicle)

Work together with Smart NVR to perform refine
intelligent search, event extraction and merging to event
videos

Video

Video Compression

Smart Codec

Video Frame Rate

Stream Capability

Resolution

H.265; H.264; H.264H; H.264B; MJPEG(only supported
by sub stream)

Smart H.265+/ Smart H.264+

Main stream (2592 × 1944@1–20 fps)
(2688 × 1520@1–25/30 fps)
sub stream (704 × 576@1–25 fps/704 × 480@1–30 fps)
third stream (1280 × 720@1–25/30 fps)

3 streams

5M (2592 × 1944); 4M (2688 × 1520); 3M (2304 × 1296);
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280
× 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF
(352 × 288/352 × 240)

6.4 m

(21.0 )

22.2 m

(72.8 )

Bit Rate Control

Video Bit Rate

Day/Night

BLC

HLC

WDR

White Balance

Gain Control

Noise Reduction

Motion Detection

Region of Interest(RoI)

Smart Illumination

Image Rotation

Mirror

Privacy Masking

Alarm

Alarm Event

Network

Network

SDK and API

Protocol

Interoperability

Scene Self-adaptation

User/Host

Storage

Browser

Management Software

Mobile Phone

Certification

Certifications

Power

Power Supply

Power Consumption

CBR/VBR

H.264: 3 Kbps–8192 Kbps
H.265: 3 Kbps–8192 Kbps

Auto(ICR)/Color/B/W

Yes

Yes

120 dB

Auto/natural/street lamp/outdoor/manual/regional
custom

Auto/Manual

3D DNR

OFF/ON (4 areas, rectangular)

Yes (4 areas)

Yes

0°/90°/180°/270° (Support 90°/270° with 1920 × 1080
resolution and lower.)

Yes

4 areas

No SD card; SD card full; SD card error; less service time
of SD card (smart card supports); network disconnection;
IP conflict; illegal access; voltage detection; security
exception; motion detection;scene changing; intensity
change; tripwire; intrusion; SMD

RJ-45 (10/100 Base-T)

Yes

IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;
RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;
Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP

ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec

Yes

20 (Total bandwidth: 64 M)

FTP; SFTP; Micro SD Card (support max. 256 G); Dahua
Cloud; NAS

IE: IE8, IE9, IE11
Chrome
Firefox

Smart PSS, DSS, DMSS

IOS; Android

CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

12V DC/PoE (802.3af)

<8.5W

www.dahuasecurity.com

Environment

Operating Conditions

| DH-IPC-HDBW3541R-ZS

-30°C to +60°C (-22°F to +140°F)/less than 95%

Storage Conditions

Protection Grade

-40°C to +60°C (-40°F to +140°F)

IP67; IK10

Structure

Casing

Dimensions

Net Weight

Gross Weight

Metal

Φ122 mm × 88.9 mm (Φ4.8" × 3.5")

492 g (1.1 lb)

663 g (1.5 lb)

Ordering Informaon

Typ e Part Number Description

5MP IR Vari-focal Dome WizSense
Network Camera,PAL

5MP IR Vari-focal Dome WizSense
Network Camera,NTSC

5MP
Camera

DH-IPC-HDBW3541RP-ZS

DH-IPC-HDBW3541RN-ZS

PFA137 Junction Box

PFB203W Wall Mount

PFA152-E Pole Mount

PFA200W Rain Shade

PFB200C

In-Celling Mount

PFM321D

DC12V1A Power

Adapter

PFM900-E

Integrated Mount

PFM114

TLC SD card

tester

Juncon Mount Wall Mount

PFA137 PFB203W

Ceiling Mount

PFA106+PFB220C

PFA137+PFA200W

In-Ceiling Mount

PFB200C

LR1002-1ET/1EC

Single-port long

reach ethernet over

coax extender

Wall Mount

Pole Mount

PFB203W+PFA152-E

Accessories
(optional)

Accessories

Oponal:

PFA137

Juncon Box

PFA106 Mount Adapter

PFB220C Celling Mount

PFB200C In-Celling Mount

PFM321D DC12V1A Power Adapter

LR1002-1ET/1EC

PFM900 -E Integrated Mount Tester

PFM114 TLC SD Card

PFB203W

Wall Mount

Single-port Long Reach Ethernet
over Coax Extender

PFA152-E

Pole Mount

Dimensions (mm[inch])

PFA200W

Rain Shade

Rev 001.001 © 2020 Dahua . All rights reserved. Design and specifications are subject to change without notice.

Pictures in the document are for reference only, and the actual product shall prevail.

PFA106

Mount Adapter

PFB220C

Celling Mount

www.dahuasecurity.com
