Dahua DH-HAC-HDW1500TQ-A-POC User Manual

Lite Series | DH-HAC-HDW1500TQ-A-POC

DC 12V

IP67

Series

Lite

Audio

40

m IR

Starlight

DH-HAC-HDW1500TQ-A-POC

5MP Starlight HDCVI POC IR Quick-to-install Eyeball Camera

* The parameters and datasheets below can only be applied to 1500-S2 series.

· Max 25 fps@5MP (16:9 video output)

· Quick-to-install eyeball saves installaon me

· CVI/CVBS/AHD/TVI switchable

· 3.6 mm xed lens (2.8 mm, 6 mm oponal)

· Built-in mic

· Max. IR length 40 m, Smart IR

· IP67, PoC (only CVI)/12V±30% DC

System Overview

Experience 5MP full HD video and the simplicity of using exisng cabling

infrastructure with HDCVI. The Lite series 5MP HDCVI camera features a

compact design and oers a high quality image at a friendly price. It of­fers various motorized/xed lens models with a mul-language OSD and
HD/SD switchable output. Its structural exibility and high cost-perfor­mance make the camera an ideal choice for SMB soluons.Besides, this
model is a PoC camera which can be powered by PoC XVR over a single
coaxial cable with video, requiring no separate power supplies. PoC
reduces me and cost for users, making it an ideal choice for applicaons
with complex deployment but a ght budget.

Funcons

4 Signals over 1 Coaxial Cable

HDCVI technology supports 4 signals to be transmied over 1 coaxial
cable simultaneously, i.e. video, audio*, data and power. Dual-way data
transmission allows the HDCVI camera to interact with the XVR, such as
sending control signal or triggering alarm. Moreover, HDCVI technology
supports PoC for construcon exibility.

* Audio input is available for some models of HDCVI cameras.

Easy Installaon

HDCVI Quick-to-install eyeball adopts quick-to-install pedestal, which
can achieve easier installaon than convenonal eyeball. Quick-to-install
camera reduces me and labor costs.

Long Distance Transmission

HDCVI technology guarantees real-me transmission at long distance

without any loss. It supports up to 700 m for 5MP HD video through

coaxial cable, and up to 300 m through UTP cable.*

*Actual results veried by real-scene tesng in Dahua's test laboratory.

Simplicity

HDCVI technology inherits the born feature of simplicity from tradional
analog surveillance system, making itself a best choice for investment

protecon. HDCVI system can seamlessly upgrade the tradional analog
system without replacing exisng coaxial cabling. The plug and play ap­proach enables full HD video surveillance without the hassle of congur-

ing a network.

Smart IR

The camera is designed with IR LED illuminaon for best lowlight perfor­mance. Smart IR is a technology to ensure brightness uniformity in B/W
image under low illuminaon. Dahua's unique Smart IR adjusts to the
intensity of camera's infrared LEDs to compensate for the distance of
an object, and prevents IR LEDs from overexposing images as the object

comes closer to the camera.

Mul-formats

The camera supports mulple video formats including HDCVI, CVBS and

other two common HD analog formats in the market. The four formats

can be switched over through OSD menu. This feature makes the cam­era to be compable with most end users' exisng HD/SD DVRs.

Starlight

With the adopon of large sized high performance sensor and large
aperture lens, the camera is able to provide incomparable performance

even under extreme lowlight environment. The starlight feature allows

more details to be captured and accurate color to be recognized at night
or in scenes with limited illuminaon.

Protecon

The camera's outstanding reliability is unsurpassed due to its rugged de­sign. The camera is protected against water and dust with IP67 ranking,
making it suitable for indoor or outdoor environments.

With working temperature range of –40 °C to +60 °C (–40 °F to +140 °F),
the camera is designed for extreme temperature environments.

Supporng ±30% input voltage tolerance, this camera suits even the
most unstable power supply condions. Its 4kV lightning rang provides
protecon against the camera and its structure from the eects of

lightning.

www.dahuasecurity.com

Lite Series | DH-HAC-HDW1500TQ-A-POC

Technical Specificaon

Camera

Image Sensor

Max. Resolution

Pixel

Scanning System

Electronic Shutter Speed

S/N Ratio

Min. Illumination

Illumination Distance

Illuminator On/Off Control

Illuminator Number

Pan/Tilt/Rotation Range

Lens

Lens Typ e

Moun t Ty pe

Focal Length

Max. Aperture

Field of View

Iris Type

Close Focus Distance

Lens

DORI
Distance

2.8 mm

3.6 mm

6 mm

1/2.7 inch CMOS

2880 (H) × 1620 (V)

5MP

Progressive

PAL: 1/25 s–1/10 0,00 0 s
NTSC: 1/30 s–1/100,000 s

> 65 dB

0.005 Lux/F1.6, 30IRE, 0 Lux IR on

40 m (131.2 ft)

Auto; manual

1

Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°

Fixed-focal

M12

2.8 mm; 3.6 mm; 6 mm

F1.6

2.8 mm: 132° × 111° × 58°
(diagonal × horizontal × ver tical)

3.6 mm: 109° × 92° × 48°
(diagonal × horizontal × ver tical)
6 mm: 65° × 57° × 30°
(diagonal × horizontal × ver tical)

Fixed iris

2.8 mm: 0.9 m (3.0 ft)

3.6 mm: 1.6 m (5.2 ft)
6 mm: 3.1 m (10.2 ft)

Detect Observe Recognize Identify

63.6 m
(208.7 )

80 m
(262.5 ft)

120 m
(393.7 )

25.4 m
(83.3 )

32 m

(105.0 ft)

48 m
(157.5 )

12.7 m
(41.7 )

16 m

(52.5 ft)

24m
(78.7 )

6.4 m

(21.0)

8 m
(26.2 ft)

12m
(39.4 )

BLC

WDR

White Balance

Gain Control

Noise Reduction

Smart IR

Mirror

Privacy Masking

Certifications

Certifications

Port

Audio Interface

Video Output

Power

Power Supply

Power Consumption

Environment

Operating Temperature

Storage Temperature

Protection Grade

Structure

Casing

Camera Dimensions

Net Weight

Gross Weight

BLC/HLC/DWDR

DWDR

Auto; manual

Auto; manual

2D NR

Yes

Off/On

Off/On (8 areas, rectangle)

CE (EN55032:2015, EN 6100 0-3-2:2014, EN
61000 -3-3:2013, EN55024:2010+A1:2015, EN
55035:2017, EN50130- 4:2011+A1:2014, EN 62368­1:2014+A11:2017)
FCC (CFR 47 FCC Part 15 subpar tB, ANSI C63.4-2014)
UL (UL6095 0-1+CAN/C SA C22.2 No.60950 -1)

One channel built-in mic

Video output choices of CVI/T VI/AHD/CVBS by one

BNC por t

PoC (only CVI)/12V±30% DC

Max 3.5W (12V DC, IR on); PoC (AF)

–40°C to +60°C (–40°F to 140°F); < 95% (non-

condensation)

–40°C to +60°C (–40°F to 140°F); < 95% (non-

condensation)

IP67

Metal inner core+plastic cover+plastic pedestal

φ109.9 mm × 100.9 mm (φ4.33" × 3.97")

0.32 kg (0.71 lb)

0.49 kg (1.08 lb)

Video

Frame Rate

Resolution

Day/Night

CVI:

PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps;
NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps

AHD:

PAL: 4M@25 fps;
NTSC: 4M@30 fps

TVI:

PAL: 4M@25 fps;
NTSC: 4M@30 fps

CVBS:
PAL: 96 0H;
NTSC: 960H

5M (2880 × 1620); 4M (2560 × 144 0); 1080P (1920 ×

1080); 960 H (96 0 × 576/960 × 48 0)

Auto switch by ICR
