Daewoo Q817 User Manual

Instruction manual

Hi-Fi Video recorder

Q817

English

DV-K869DY-AQ/I_cover 00.10.5 9:11 AM ˘`1

Precautions

WORTH

knowing

Please keep the video machine's guarantee card and receipt safe for warranty purposes.

◆ Read carefully through this manual to familiarize yourself with this

high-quality video recorder.

◆ Make sure the rating of your household electricity supply matches

that shown on the back of the video recorder.

◆ Refer to this chapter and the "Initial installation" chapter to help

you install and adjust your video recorder.

Do not ... ... expose the video recorder to high levels of humidity and heat, to

avoid the risk of fire and electric shock.

... open the video recorder. Have a qualified technician carry out

repairs.

... connect the video recorder to the power supply if you have just

moved it from a cold to warm environment. This can result in condensation inside the recorder and cause serious damage to the machine and cassettes. Wait around two hours to allow it to reach room temperature.

Make sure ... ... the recorder is placed on a steady, flat surface. ... you place the recorder where there is good ventilation all around. ... you clean the recorder only with a soft, lint-free cloth; do not use

aggressive or alcohol-based cleaning agents.

... you disconnect the power supply if the recorder appears to be

working incorrectly, is making an unusual sound, has a strange smell, has smoke emitting from it or liquids have got inside it. Have a qualified technician check the recorder.

... you disconnect the power supply and aerial if you will not be using

the recorder for a long period or during a thunderstorm.

For your own safety!

◆ There are no components in this video recorder you can

service or repair yourself.

◆ Do not open the case of the video recorder. Only allow

qualified personnel to repair or service your set.

◆ This video recorder is designed for continuous

operation. Switching it off does not disconnect it from the mains (stand-by). To disconnect it from the mains, you have to unplug it.

◆ Recording any copyright protected material may infringe

a copyright.

AUTO SET

CH.

OP EJECT

DV-K869DY-AQ/I_GB 00.10.4 5:29 PM ˘`b

Contents

knowing

WORTH

Before doing anything with the machine, please read the chapter "Initial installation".

◆ On the following pages, the pictures show the buttons you press on the remote control to

perform the function, and what you should see in the On Screen Display or machine display (if present).

◆ ShowView is a trademark applied for by Gemstar Development Corp.. The ShowView

system is manufactured under license from Gemstar Development Corporation.

Controls

The remote control unit .................................................................................... 2

The machine, On screen display ...................................................................... 3

Initial installation

Connecting up the video recorder, Fitting the remote control’s batteries ...... 4

Setting up the video recorder .......................................................................... 5

Playing cassettes

Playing back .......................................................................................................6

Still, Variable picture search, Variable slow motion,

Accessing new recordings (index scan) ........................................................... 7

16:9 Wide Screen Format Playing back /Recording, CM Skip......................... 8

Recording cassettes

Setting time and date.......................................................................................9

Simple recording, One touch recording (OTR) ............................................... 10

Timer recording using ShowView .................................................................. 11

More functions

Normal timer recording .................................................................................. 12

Timer Review – changing and erasing .......................................................... 13

Clock/Counter display, Remaining time and Cassette length,

Accessing counter zero position, Resetting the counter to zero ................. 14

Menu languages, Child lock, Cassettes, and ... ............................................ 15

The Hi-Fi system, What you can listen to........................................................16

Choice of sound output....................................................................................17

Tuning new stations

Tuning ............................................................................................................. 18

Station names ................................................................................................ 19

Sorting programme locations, Clearing programme locations ...................... 20

Connections and copying

To the TV via antenna cable (if you are not using a SCART cable) .............. 21

Copying, Assembling ...................................................................................... 22

Decoder/2nd SCART terminal, Canal+ Setting................................................23

Appendix

Before you ask a specialist ............................................................................ 24

Brief instruction for experienced users .................................................... 25/26

Index, Technical data ..................................................................................... 27

DV-K869DY-AQ/I_GB 00.10.4 5:29 PM ˘`1

The remote control unit

CONTROLS

◆

The remote control is the principle means of control, but the main playback and record functions are also available on the front of the machine.

◆

Press any button to turn on the power.

power on/off the controls for timer recording using the ShowView codes

via On Screen Display

TV or video viewing selection (with the SCART connection, page 4)

a button for selecting input sources for recording: TV stations – input sockets

clock/counter on-screen display this button is not available for this set

this button is not available for this set CM skip button to cue the tape for 30 seconds

to eject the cassette

the variable slow motion button

this button is not available for this set

to search the beginnings of records (index)

a button that doubles the maximum recording time for very long recordings

the record or OTR button (One Touch Recording means: each time you press the

button recording is extended by 30 minutes)

pause (record), still (playback) playback start

playback stop rewinding/fast forwarding a cassette from stop, or

picture search backwards/forwards from playback mode

number buttons to select programmes (stations) or to type in numbers

the menu controls, programme (station) selection (PR +/–)

max. 7 m.

30°

SV/V+

PAL/SEC

Q. S

The buttons to use are marked on the following pages.

to select the sound output (if available)

Q.S

A.D

EJECT

A.SEL

INDEX

–

DV-K869DY-AQ/I_GB 00.10.4 5:29 PM ˘`2

SV/V+

TV/VCR

SP/LP

–

INDEX

TV/VCR

A.D

EJECT

–

A.SEL

SP/LP

PAL/SEC

The machine

On screen display

CONTROLS

◆

Press any button to turn on the power.

power on/off

playback stop and ejecting the cassette

MAIN MENU

Timer Program PR Preset VCR Setup Tape Control

PR+/-:select OK:confirm MENU:end

VCR SETUP

Clock Set Language Set RF Output Set 2nd Scart Set 16:9 Set

PR+/-:select OK:confirm MENU:end

example

“Tape Control” Menu appears only when a tape is in the VCR.

The menus show you which button to press for the next step.

In addition, some other functions appear on screen temporarily.

REW SP PR04 EURO

programme (station) selection

recording or OTR

(One Touch Recording means: each time you press the button recording is extended by 30 minutes)

rewinding / fast forwarding a cassette from Stop, or picture search backwards / forwards from playback mode.

playback start

The video’s menu system gives you easy-tounderstand access to the less used functions such as tuning to stations, clock setting and more.

STEREO ON

DV-K869DY-AQ/I_GB 00.10.4 5:30 PM ˘`3

–

Connecting up the video recorder

Fitting the remote control's batteries

INSTALLATION

Initial

Place your video

◆

horizontally on a flat, steady base so that air can circulate around it for ventilation.

◆

away from humidity and heat, magnetic fields, such as those from loudspeakers etc., and with no heavy objects placed on top.

Switch off all components when connecting or disconnecting cables.

◆ Unplug the aerial cable from your TV and plug it into the "ANT.

IN" socket of the video. Plug the short coaxial cable provided into the "ANT.OUT" socket

of the video and the aerial socket of the TV.

◆ Plug an EURO AV (SCART) cable into the "EURO AV1” socket of

the video and the AV socket on the TV if available.

This connection will provide best picture and sound quality. Ask your dealer for an appropriate cable if you do not have one. Without a SCART cable, you need to follow the steps described under "If

you are not using a SCART cable" (right page and page 21).

◆ Make sure the rating of the household mains supply matches the rating

shown on the back of the video.

Now plug in the mains lead. The display of the video should now light.

◆

Plug a phone cable into “Audio L, R” jack on the rear panel and into the Audio jack on any audio amplifier, if needed.

Fit the batteries as shown by the pictures in the bay.

EURO AV2 /DECODER

AUDIO

1.5 V (AAA)

AC 230 V~ , 50 Hz

◆ Protect your environment by returning used batteries to your dealer. Since

batteries contain toxic substances they require special disposal methods.

◆ Make sure the batteries are always of the same type and age, and remove them

from the remote control if you are not using it for a long period.

The buttons to use are marked on the following pages.

SV/V+

PAL/SEC

Q. S

DV-K869DY-AQ/I_GB 00.10.4 5:30 PM ˘`4

TV/VCR

SP/LP

–

INDEX

A.D

EJECT

–

A.SEL

ANT. IN

ANT. OUT

EURO AV1

Setting up the video recorder

INSTALLATION

Initial

◆

Switch the TV on.

◆

You can also start "Auto Set" in the menu "PR Preset" "Auto Set".

◆

To tune in new stations (manual tuning) and to enter station names see page 18-20.

You should see this picture the first time you switch on the TV and video.

Choose your language.

OK for "Auto Set!".

"AUTO SET" tunes in all the stations you can receive in your country and ...

... sorts them in an order common for your country. Clock is automatically set.

Should you wish the stations to have the same numbers as those used on the TV, follow the instructions in "Sorting programme locations" on page 20. Else ...

exit the basic installation function and enjoy your video recorder.

◆ If you don´t see this picture, because you don´t use a SCART cable, search this picture

now (CH 52) with the station tuning functions of your TV set (see its user manual).

◆ In case of interference problems on CH 52, type in an other

transmission channel between 21 and 69 using the number buttons.

LANGUAGE SET

English Deutsch Italiano Español Français Nederlands PYCCK SVENSKA

PR+/-:select OK:confirm MENU:end

Auto Set!

OK:confirm MENU:end

AUTO SET

MENU:end

PR03

V-L - - - - - - - - - - - - - -

76%

Setting

Please wait...

MANUAL SET

PR01 ARD PR08 P-08 PR02 ZDF PR09 P-09 PR03 P-03 PR10 P-10 PR04 P-04 PR11 P-11 PR05 MTV PR12 ---PR06 P-06 PR13 ---PR07 P-07 PR14 ----

PR+/-:select OK:confirm MENU:end

AUTO SET

–

DV-K869DY-AQ/I_GB 00.10.4 5:30 PM ˘`5

Playing back

cassettes

PLAYING

◆

Your TV and your video recorder are switched on.

◆

To see the picture from your video, press the station button on the TV reserved for video input or the AV (Audio/Video) button.

Load the cassette by pushing it smoothly and squarely into the cassette bay, with its windows pointing up.

Start playback.

Stop playback.

Eject the cassette.

Fast forward or rewind the cassette from stop.

◆ Press the TV/VCR button to see TV's or the video's (VCR) picture on

the screen (with the SCART connection to the TV).

◆ When you load a protected cassette (e.g. pre-recorded film,

see page 15) playback starts automatically.

◆ PLAY switches back to normal playback.

◆ During still, slow or search, you don’t hear the sound.

◆ If the still picture is jittering, you can steady it by using the PR +/–

buttons.

◆ You can reduce horizontal interference stripesresulting from

inaccurate tracking (when playing tapes of poor quality or recorded on other machines) by using the PR +/– buttons during playback.

◆ After approx. 5 minutes in still, the cassette plays back

automatically.

◆ NTSC PLAYBACK on PAL TV ; If you playback the tapes, which have

been recorded on NTSC color system, on this VCR, you can watch the pictures on a PAL TV.

◆ Clock / Counter / Remaining time – page 14.

SV/V+

PAL/SEC

Q. S

AUTO SET

20 : 10

VHS

If you hear an unintelligible, mixed sound output (bilingual sound), select one of the sound options.

PLAY SP Hi-Fi

L+R

VCR

L R

DV-K869DY-AQ/I_GB 00.10.4 5:30 PM ˘`6

SP/LP

–

INDEX

A.SEL

TV/VCR

A.D

EJECT

–

A.SEL

EJECT

Still

Variable picture search

Variable slow motion

Accessing new recordings (index scan)

PLAYING

cassettes

Still picture from playback. Each press of the button advances the picture

one frame.

“PLAY” blinks during still. PLAY switches back to normal playback.

Starting from playback you can control search speed in 2 steps either forwards

()

backwards

()

. Press repeatedly.

PLAY switches back to normal playback.

Starting from playback you can control slow motion speed in 6 steps (1/15, 1/10, 1/5, 1/30, 1/25, 1/20, 1/15, ...). Press repeatedly.

PLAY switches back to normal playback.

Select INDEX + or INDEX – to search forwards or backwards.

The video will now wind to the beginning of the first recording, play it for about 6 seconds then wind on to the next one.

When you see the recording you want, press PLAY.

Access the beginning of recordings in the middle of the tape using the Index + / – function. The video recorder automatically sets an electronic marker (index) at the beginning of each

recording. It is these markers which the Index + / – function detects.

FF SP INDEX 01

0:11:09

VCR

DV-K869DY-AQ/I_GB 00.10.4 5:30 PM ˘`7

–

INDEX

+ 21 hidden pages
