F E ATURE CHART
Here are the features of your new refrigerator.
Take a moment to know all the features and convenience it was designed to
p rovide. Numbers match those in the illustration on page 1.
Ice tray
Fill tray 3/4 full to allow expansion of water during freezing. Place tray in freezer chest. To
release cubes, twist lid slightly.
Removable shelf
Shelves can be removed by pulling forw a rd. The shelf can be placed at your desirable
p o s i t i o n .
C r i s p e r
May be used for fruit and vegetable storage. Both the crisper and its cover shelf are
removable for easy cleaning. Simply slide forw a rd to re m o v e .
Egg Pocket
Egg supporter in this pocket can be turned upside down.
May be used for small size goods.
C o n v e rtible Function
This refrigerator is designed to convert the function.
Refrigerator can be converted to refrigerator of ‘function off’
ICE TRAY
FREEZER REMOVA B L E
S H E L F
FREEZER TEMPERAT U R E
CONTROL KNOB
ICE BOX
CHILLED CASE
R E F R I G E R ATO R
T E M P E R AT U R E
CONTROL KNOB
LAMP COVER
R E M O VABLE SHELF
GLASS SHELF
V E G E TABLE CASE
F POCKET (T)
F POCKET (U)
EGG CASE
EGG POCKET
R POCKET (MULT )
R POCKET (BG)
R POCKET (SM)
CAUTION: 1. Be sure to check with your voltage, before inserting the power
supply cord into the socket.
2. Contact the earthing conductor to this unit with an attachment earthing
screw.
3. Don’t make it spill to this unit.
4. Don’t work with flammable spray, such as paining, near this unit.
5. Don’t put ignitable materials, such as benzine, L.P. Gas, alcohol, etc., into
this unit.
6. Be careful of the leakage of any gas equipment near this unit.
7. Be sure not to hold to the door of this unit by children.
8. Be sure not to reinsert the power supply cord within 5 minutes after release
it from socket. If not, a trouble may be occured to compressor.
21
![](/html/2c/2c96/2c965e90eff93285cbbd9e09141c7afa1b2be721043161a9528e0b1015bc4d3d/bg2.png)
HOW TO INSTA L L
HOW TO OPERAT E
Location
Install refrigerator in a convenient location away from extreme heat and cold. Allow
s u fficient clearance between the refrigerator and side wall so it is easy for refrigerator to
radiate heat. Refrigerator is not designed for recessed installation.
Leveling
Level refrigerator so it rests solidly on the floor, without rocking. There are two
Adjustable foot, one at each front corn e r. Tu rn to the left to raise a corn e r, to the right to
lower it. Use shims under rear corners, if necessary.
If you want, the refrigerator door to close when not held open, adjust feets so that the
f ront of the refrigerator is raised. However, front corners must be level with each
o t h e r, and rear corners with each other.
N O T E :Make sure all packing meterial is removed. If the shipping tape has left a residue on
the door, clean it with isopropyl alcohol (most rubbing alcohol is this type).
Do not use a solvent, such as cleaning fluid, nor an abrasive cleanser.
HOW TO CLEAN
TEMPERATURE CONTROL
Te m p e r a t u re is controlled automatically. The TEMPERATURE CONTROL at the inside of the
refrigerator and freezer section control the degree of cooling of each compart m e n t .
F reezer temperature contro l
ECONOMIC FUNCTION
When you have small foods to stuff or the stuffed is already frozen enough, use this
function and you’ll save the electric power consumption.
OFF FUNCTION
When you want to use “FREEZER” only, set the “REFRIGERATOR CONTROL DIAL” at
“ O F F ”
Refrigerator temperature contro l
Starting your new refrigerator
To Avoid The Risk of Electrical Shock or Death unplug the
C A U T I O N
C l e a n e r s :Do not use harsh, abrasive cleaners, heavy-duty cleaners, or solvents on
any surface. These cleaners may cause cracking, discoloring or
scratching the surf a c e .
E x t e r i o r :Wash with warm, soapy water, rinse and dry.
Use appliance polish or wax periodically to keep the exterior looking like new.
Door gasket :Clean at least twice a year with mild soap and water. Rinse and
d ry. Apply a light film of petroleum jelly to the gaskets to keep
them soft.
I n t e r i o r :Wash the liner with warm, soapy water, rinse and dry.
power cord before replacing a burned out light bulb or
c l e a n i n g .
1. Clean the refrigerator thoroughly: Wipe the outside with a soft dry cloth, the inside with
a damp cloth.
2. Set TEMPERATURE CONTROL at MED.
3. Connect the power supply cord .
To change temperature
You may want to adjust the control according to the season and your needs. When
adjusting the temperature :
Tu rn TEMPERATURE CONTROL toward MAX for colder temperature in refrigerator and
f reezer sections, and toward MIN for warmer temperature in refrigerator and fre e z e r
s e c t i o n s .
Allow approximately 2 hours for temperature to stabilize. Then check to see if furt h e r
adjustments are needed.
