Daewoo KOR-3000 User Manual

Before operating this oven, please read these instructions completely.
OPERA TING INSTRUCTIONS
MICROWAVE OVEN
KOR-3000
Helpline number: 01189 252627
1
PRECAUTIONS
..................................................................................................................................
1
IMPORTANT SAFETY INSTRUCTIONS
..........................................................................................
2
EARTHING INSTRUCTIONS
.............................................................................................................
3
INSTALLATION
...................................................................................................................................
3
SPECIFICATIONS
..............................................................................................................................
4
IMPORTANT
........................................................................................................................................
4
FEATURES DIAGRAM
.......................................................................................................................
5
OPERATION PROCEDURE
..............................................................................................................
7
CONTROLS
.........................................................................................................................................
8
SETTING THE CLOCK
.................................................................................................................
8
WEIGHT DEFROSTING
...............................................................................................................
8
TIME DEFROSTING
.....................................................................................................................
9
COOKING IN ONE STAGE
........................................................................................................
10
COOKING IN TWO STAGES
.....................................................................................................
10
EASY COOK
................................................................................................................................
11
AUTO COOK
...............................................................................................................................
11
CHILD SAFETY LOCK
................................................................................................................
12
TO STOP THE OVEN WHILE THE OVEN IS OPERATING
...................................................
12
COOKING UTENSILS
......................................................................................................................
13
CARE AND CLEANING
....................................................................................................................
13
DEFROSTING FROZEN FOODS CHART
.....................................................................................
14
COOKING CHART
............................................................................................................................
15
REHEATING CHART
........................................................................................................................
16
BEFORE YOU CALL FOR SERVICE
..............................................................................................
18
QUESTIONS AND ANSWERS
........................................................................................................
18
PRECAUTIONS TO A VOID POSSIBLE EXPOSURE TO EXCESSIVE MICROW A VE ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can
result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
(c) WARNING : If the door or door seals are damaged, the oven must not be operated until it
has been repaired by a trained person : (1) door (bent), (2) hinges and latches(broken or loosened), (3) door seals and sealing surfaces.
(d) WARNING : It is hazardous for anyone other than a trained person to carry out any service
or repair operation which involves the removal of any cover which gives protection against exposure to microwave energy.
(e) WARNING : Liquids or other foods must not be heated in sealed containers since they are
liable to explode.
TABLE OF CONTENTS
2
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING : To prevent fire, burns, electric shock and other warnings: Listed below are, as with all appliances, certain rules to follow and safeguards to assure high performance from this oven:
1. Do not use the oven for any reason other than food preparation, such as for drying clothes, paper, or any other nonfood items or for sterilizing purposes.
2. Do not use the oven when empty, this could damage the oven.
3. Do not use the oven cavity for any type of storage, such as papers, cookbook, cookware, etc.
4. Do not operate the oven without the glass tray in place. Be sure it is properly sitting on the rotating base.
5. Make sure you remove caps or lids prior to cooking when you cook food sealed in bottles.
6. Do not put foreign material between the oven surface and door. It could result in excessive leakage of microwave energy.
7. Do not use recycled paper products for cooking. They may contain impurities which could cause sparks and/or fires when used during cooking.
8. Do not pop popcorn unless popped in a microwave approved popcorn popper or unless it's commercially packaged and recommended especially for microwave ovens. Microwave popped corn produces a lower yield than conventional popping; there will be a number of unpopped kernels. Do not use oil unless specified by the manufacturer.
9. Do not cook any food surrounded by a membrane, such as egg yolks, potatoes, chicken livers, etc., without first piercing them several times with a fork.
10. Do not pop popcorn longer than the manufacturer's directions. (popping time is generally below 3 minutes).
Longer cooking does not yield more popped corn, it can cause scorchings and fire. Also, the cooking tray can become too hot to handle or may break.
11. If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
12. When heating food in plastic or paper containers, check the oven frequently due to the possibility of ignition.
13. The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature is to be
checked before consumption, in order to avoid burns.
14. Always test the temperature of food or drink which has been heated in a microwave oven before you give it to
somebody, especially to children or elderly people. This is important because things which have been heated in a microwave oven carry on getting hotter even though the microwave oven cooking has stopped.
15. Eggs in their shell and whole hard-boiled eggs shall not be heated in microwave ovens since they may
explode.
16. Keep the waveguide cover clean at all times. Wipe the oven interior with a soft damp cloth after each use. If
you leave grease or fat anywhere in the cavity it may overheat, smoke or even catch fire when next using the oven.
17. Never heat oil or fat for deep frying as you cannot control the temperature and doing so may lead to
overheating and fire.
18. Microwave heating of beverages can result in delayed eruptive boiling, therefore care has to be taken when
handling the container.
3
EARTHING INSTRUCTIONS
This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a earthing wire with a earthing plug. The plug must be plugged into an outlet that is properly installed and earthed.
INSTALLATION
1 Steady, flat location
This oven should be set on a steady, flat surface. This oven is designed for counter top use only.
2 Leave space behind and side
All air vents should be kept a clearance. If all vents are covered during operation, the oven may overheat and, eventually, oven failure.
3 Away from radio and TV sets
Poor television reception and radio interference may result if the oven is located close to a TV, Radio antenna, feeder and so on. Position the oven as far from them as possible.
4 Away from heating appliance and water taps
Keep the oven away from hot air, steam or splash when choosing a place to position it, or the insulation might be adversely affected and breakdowns occur.
5 Power supply
• Check your local power source. This oven requires a current of approximately 6 amperes, 230V 50Hz.
• Power supply cord is about 0.8 meters long.
• The voltage used must be the same as specified on this oven. Using a higher voltage may result in a fire or other accident causing oven damage. Using low voltage will cause slow cooking. We are not responsible for damage resulting from use of this oven with a voltage of ampere fuse other than those specified.
• If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
6 Examine the oven after unpacking for any damage such as:
A misaligned door, Broken door, A dent in cavity. If any of the above are visible, DO NOT INSTALL, and notify dealer immediately.
7 Do not operate the oven if it is colder than room temperature.
(This may occur during delivery in cold weather.) Allow the oven to become room temperature before
operating.
8 The minimum height of free space necessary above the top surface of the oven is 100mm.
WARNING : Improper use of the earthing plug can result in a risk of electric shock. Consult a qualified
electrician or serviceman if the earthing instructions are not completely understood, or if doubt exists as to whether the appliance is properly earthed. If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade earthing plug, and a 3­slot receptacle that will accept the plug on the appliance. The marked rating of the extension cord should be equal to or greater than the electrical rating of the appliance.
4
WARNING: This appliance must be earthed.
SPECIFICATIONS
IMPORTANT
The wires in this mains lead fitted to this appliance are coloured in accordance with the following code.
Green-and-yellow : Earth Blue : Neutral
Brown : Live As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: the wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked with the letter 'E', the earth symbol or coloured green-and-yellow. The wire which is coloured blue must be connected to the terminal which is marked with the letter ‘N’ or coloured black. The wire which is coloured brown must be connected to the terminal which is marked with the letter 'L' or coloured red.
* Specifications are subject to change without notice.
POWER SUPPLY 230V~ / 50Hz, SINGLE PHASE WITH EARTHING
POWER CONSUMPTION 1200 W
MICROWAVE OUTPUT POWER 800 W
FREQUENCY 2450 MHz OUTSIDE DIMENSIONS (W X H X D) 465 X 279 X 360 mm CAVITY DIMENSIONS (W X H X D) 290 X 220 X 306 mm NET WEIGHT APPROX. 13KG TIMER 59 min. 00sec. POWER LEVELS 5 LEVELS
E
L
N
GREEN/YELLOW
Earth
BLUE
Neutral
FUSE
13 Amps
Cord Clamp
BROWN
Live
5
11
Door latch-When the door is closed it will
automatically shut off. If the door is opened while the oven is operating, the magnetron will automatically shut off.
22
Door seal-The door seal surfaces prevent
microwaves escaping from the oven cavity.
33
Oven cavity
44
Spatter shield-Protects the microwave outlet
from splashes of cooking foods.
55
Safety interlock system-Prevents the oven
from operating while the door is opened. The oven will only operate with the door fully closed. When the door is open, the oven turns off and will only start again after the door is closed.
66
Glass cooking tray-Made of special heat
resistant glass. The tray can be easily removed for cleaning. Make sure it is correctly positioned (indentation) before operating. Place food in a suitable container (dish) on the tray.
77
Roller guide-Supports the glass cooking tray.
88
Door screen-Allows viewing of food.
The screen is transparent to light, but prevents microwaves escaping.
FEATURES DIAGRAM
6
00
DISPLAY- Cooking time, power level,
indicators and present time are displayed.
qq
POWER- Used to set power level.
ww
CLOCK- Used to set clock.
ee
DEFROST- Used to defrost foods by weight or
time.
rr
AUTO COOK- Used to cook using a program
or to reheat.
tt
DIAL KNOB- Used to set the time and weight.
yy
STOP/CLEAR- Used to stop the oven
operation or to erase all entries.
uu
START/EASY COOK-Used to start the oven
operation and also increase the reheat time by 30 seconds.
FEATURES DIAGRAM ( continued )
POWER
M/W DEF. LOCK g
1. Dinner Plate
2. Soup
3. Beverage
4. Fresh Vegetable
Time/Weight Quantity
CLOCK DEFROST
AUTO COOK
START/EASY COOKSTOP/CLEAR
0
eq
w
y
r
t
u
