MICROWAVE OVEN
N230S
OPERATING
INSTRUCTIONS
Before operating this oven, please read these instructions completely.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
(a)Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.
(b)Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.
(c)WARNING : If the door or door seals are damaged, the oven must not be operated until it has been repaired by a trained person : (1) door (bent), (2) hinges and latches(broken or loosened), (3) door seals and sealing surfaces.
(d)WARNING : It is hazardous for anyone other than a trained person to carry out any service or repair operation which involves the removal of any cover which gives protection against exposure to microwave energy.
(e)WARNING : Liquids or other foods must not be heated in sealed containers since they are liable to explode.
(f)WARNING : The appliance is not intended for use by young children or infirm person without supervision. Young children should be supervised to ensure that they do not play with the appliance. It is not recommended for use in an environment where excessive vibration could be experienced.
TABLE OF CONTENTS
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY ............................................................................................ 1 IMPORTANT SAFETY INSTRUCTIONS ........................................................................................ 2 EARTHING INSTRUCTIONS .......................................................................................................... 3 INSTALLATION ............................................................................................................................... 3 FEATURES DIAGRAM ................................................................................................................ 4~5 OPERATION PROCEDURE ........................................................................................................... 6 HOW TO SET THE OVEN CONTROLS
CARE OF YOUR MICROWAVE OVEN
BEFORE YOU CALL FOR SERVICE ............................................................................................ 15 QUESTIONS AND ANSWERS ................................................................................................ 15~16 SPECIFICATIONS ......................................................................................................................... 17 COOKING INSTRUCTIONS .......................................................................................................... 18 USE YOUR MICROWAVE OVEN SAFELY ............................................................................... 19 ARCING ...................................................................................................................................... 19 MICROWAVING PRINCIPLES ................................................................................................... 20 HOW MICROWAVES COOK FOOD .......................................................................................... 20 CONVERSION CHARTS ............................................................................................................ 20 COOKING TECHNIQUES .......................................................................................................... 21 GENERAL DEFROSTING GUIDE ............................................................................................. 22 DEFROSTING CHART ............................................................................................................... 23 COOKING & REHEATING CHART ............................................................................................ 24 VEGETABLE CHART ................................................................................................................. 25 RECIPES .............................................................................................................................. 27~29
1
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
WARNING-To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy:
1.Read all instructions before using the appliance.
2.Read and follow the specific “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY” found on page 1.
3.This appliance must be grounded. Connect only to properly grounded outlet. See “EARTHING INSTRUCTIONS” found on page 3.
4.Install or locate this appliance only in accordance with the provided installation instructions.
5.Some products such as whole eggs and sealed containers - for example, closed glass jars-may explode and should not be heated in this oven.
6.Do not put foreign material between the oven surface and door. It could result in excessive leakage of microwave energy.
7.As with any appliance, close supervision is necessary when used by children.
8.Do not operate this appliance if it has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped.
9.This appliance should be serviced only by qualified service personnel.
Contact nearest authorised service facility for examination, repair or adjustment.
10.Do not cover or block any openings on the appliance.
11.Do not store this appliance outdoors. Do not use this product near water — for example, near a kitchen sink, in a wet basement, or near a swimming pool, and the like.
12.Do not immerse cord or plug in water.
13.Keep cord away from heated surfaces.
14.Do not let cord hang over edge of table or counter.
15.Either:
a)When cleaning surfaces of door and oven use only mild, non-abrasive soaps or detergents applied with a sponge or soft cloth , or
b)When separate cleaning instructions are provided, See door surface cleaning instructions on (page 14).
16.To reduce the risk of fire in the oven cavity:
a)Do not overcook food. Carefully attend appliance if paper, plastic, or other combustible materials are placed inside the oven to facilitate cooking.
b)Remove wire twist-ties from paper or plastic bags before placing bag in oven.
c)If materials inside the oven should ignite, keep oven door closed, turn oven off, and disconnect the power cord, or shut off power at the fuse or circuit breaker panel.
d)Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils, or food in the cavity when not in use.
17.Do not use this microwave oven to heat corrosive chemicals (for example, sulfides and chlorides). Vapours from such corrosive chemicals may interact with the contact and springs of the safety interlock switches thereby rendering them inoperable.
18.Keep the waveguide cover clean at all times. Wipe the oven interior with a soft damp cloth after each use. If you leave grease or fat anywhere in the cavity it may overheat, causing smoke, or even catch fire when next using the oven.
19.Never heat oil or fat for deep frying as you cannot control the temperature and doing so may lead to overheating and fire.
20.Do not operate the oven when empty or with an empty utensil to avoid damage to the oven and danger of fire.
SAVE THESE INSTRUCTIONS
2
EARTHING INSTRUCTIONS
This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a earthing wire with a earthing plug. The plug must be plugged into an outlet that is properly installed and earthed.
WARNING : Improper use of the earthing plug can result in a risk of electric shock. Consult a qualified electrician or serviceman if the earthing instructions are not completely understood, or if doubt exists as to whether the appliance is properly earthed. If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3- blade earthing plug, and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extension cord should be equal to or greater than the electrical rating of the appliance.
INSTALLATION
1.Ventilation
Do not block air vents. If they are blocked during operation, the oven may overheat and eventually cause a failure. For proper ventilation, allow above 50mm of space between oven sides, rear and the minimum height of free space necesary above the top surface of the oven is 100mm.
2.Steady, flat location
This oven should be set on a steady, flat surface. This oven is designed for counter top use only.
3.Leave space behind and side
All air vents should be kept clear. If all vents are covered during operation, the oven may overheat and, eventually, fail.
4.Away from radio and TV sets
Poor television reception and radio interference may result if the oven is located close to a TV, Radio antenna, feeder and so on. Position the oven as far from them as possible.
5.Away from heating appliance and water taps
Keep the oven away from hot air, steam or Splashing water when choosing a place to position it, or the insulation might be adversely affected and breakdowns occur.
6.Power supply
•Check your local power source. This oven requires a current of approximately 10 amperes, 230V~240V 50Hz.
•Power supply cord is about 1.8 meters long.
•The voltage used must be the same as specified on this oven. Using a higher voltage may result in a fire or other accident causing oven damage. Using low voltage will cause slow cooking. We are not responsible for damage resulting from use of this oven with a voltage or ampere fuse other than those specified.
•If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
7.Examine the oven after unpacking for any damage such as:
A misaligned door, broken door, a dent in cavity. If any of the above are visible, DO NOT INSTALL, and notify dealer immediately.
8.Do not operate the oven if it is colder than room temperature.
(This may occur during delivery in cold weather.) Allow the oven to become room temperature before operating.
3
FEATURES DIAGRAM
1 2 |
3 |
4 5 |
6
9
7
8
1Door latch - If the door is opened while the oven is operating, the magnetron will automatically shut off.
2Door seal - The door seal maintains the microwave within the oven cavity and prevents microwave leakage.
3Oven cavity
4Spatter shield - Protects the microwave outlet from splashes of cooking foods.
5Safety interlock system - Prevents the oven from operating while the door is opened.
6Door release button - Pushing this button stops oven operation and opens the door.
7Glass cooking tray - Made of specical heat resistant glass. The tray must always be in proper position before operating.
8Roller guide - Supports the glass cooking tray.
9Door screen - Allows viewing of food. The screen is designed so that light can pass through, but not the microwaves.
4
FEATURES DIAGRAM (continued)
q
w
e
r y
u
p
0
o t
i
0Time set pad - Used to set the cooking time and the clock.
qDisplay - Cooking time, power level, indicators and clock are displayed.
wOne touch - Used to cook or reheat specific quantities of food.
eCook - Used to cook or reheat.
rAuto defrost - Used to defrost foods.(for weight)
tPower Level - Used to set power level.
yTime Defrost - Used to defrost foods.(for time)
uKitchen Timer - Used as a minute timer, delay cooking, hold setting after cooking.
iClock - Used to set clock.
oPause/Clear - Used to stop the oven operation or to delete the cooking data.
pStart / Express cook- Used to start the oven and also used to set a reheat time.
5
OPERATION PROCEDURE
This section includes useful information about oven operation.
1.Plug power supply cord into 230V~240V, 50Hz power outlet.
2.After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking.
3.Shut the door. Make sure that it is firmly closed.
1
2
3
4
5
6
The oven light is on when the microwave oven is operating or the door is opened.
The oven door can be opened at any time during operation by touching the door release button on the control panel. The oven will automatically shut off.
Each time a pad is touched, a BEEP will sound to acknowledge the touch.
The oven automatically cooks on full power unless set to a lower power level.
The display will show ":0" when the oven is plugged in.
Time clock returns to the present time when the cooking time ends.
7 When the PAUSE/CLEAR pad is touched during the operation, the oven stops cooking and all information is retained.
To erase all information (except the present time), touch the PAUSE/CLEAR pad once more. If the oven door is opened during the oven operation, all information is retained.
8 If the START pad is touched and the oven does not operate, check the area between the door and door seal for obstructions and make sure the door is closed securely.
The oven will not start cooking until the door is completely closed or the program has been reset.
Make sure the oven is properly installed and plugged into the electrical outlet.
WATTAGE OUTPUT CHART
•The power-level is set by pressing the POWER LEVEL pad. The chart shows the display, the power level and the percentage of power.
Touch POWER LEVEL pad |
Power Level (Display) |
Approximate Percentage of Power |
|
|
|
once |
P-HI |
100% |
|
|
|
twice |
P-90 |
90% |
|
|
|
3 times |
P-80 |
80% |
|
|
|
4 times |
P-70 |
70% |
|
|
|
5 times |
P-60 |
60% |
|
|
|
6 times |
P-50 |
50% |
|
|
|
7 times |
P-40 |
40% |
|
|
|
8 times |
P-30 |
30% |
|
|
|
9 times |
P-20 |
20% |
|
|
|
10 times |
P-10 |
10% |
|
|
|
11 times |
P-00 |
0% |
|
|
|
6
CONTROLS
SETTING THE CLOCK
When the oven is first plugged in, the display will flash ":0" and a tone will sound. If the AC power ever goes off, the display shows ":0" when the power comes back on.
|
1. Touch CLOCK pad. |
CLOCK |
This is a 12 hour clock system. |
2. Touch CLOCK pad once more.
This is a 24hour clock system.
NOTE: This oven has a multiple clock system, omit this step.
3.Enter the correct time of day by touching the numbers in sequence.
4.Touch CLOCK pad.
CLOCK
The display stops blinking, and the colon starts blinking. If you selected 12 hour clock system, this digital clock allows you to set from 1:00 to 12:59. If you selected 24 hour clock system, this digital clock allows you to set from 0:00 to 23:59.
5. Touch PAUSE/CLEAR pad.
NOTE: If you attempt to enter an incorrect time, the time will not be set and a error signal tone will sound. Touch the CLOCK pad and re-enter the time.
TIME DEFROSTING
When TIME DEFROST is selected, the automatic cycle divides the defrosting time into periods of alternating defrost and stand times by cycling on and off.
1. Touch TIME DEFROST pad.
TIME
DEFROST
2.Touch number pads for the desired defrosting time.
3.Touch START pad.
The DEFROST indicator lights and " : 0" is displayed.
The display will show the numbers you pressed in the order you touched.
NOTE: Your oven can be programmed for 99 minutes 99 seconds.(99:99)
When you touch START pad, the DEFROST indicator starts blinking to show the oven is in the DEFROST mode. The display counts down the time to show you how much defrosting time is left in the DEFROST mode. The oven beeps during the defrosting cycle to signal that the food needs to be turned or rearranged. When the defrosting time ends, you will hear 3 beeps.
7
AUTO DEFROSTING
AUTO DEFROSTING lets you easily defrost food by eliminating guesswork in determining defrosting time. Follow the steps below for easy defrosting.
AUTO
DEFROST
1. Touch AUTO DEFROST pad. When you touch AUTO DEFROST pad once, The g indicator light and “500” is displayed. By repeatedly touching this pad, you can select other weight as shown in the chart below.
* WEIGHT DEFROST CHART |
|
|||
|
|
|
|
|
Touch pad |
|
MEAT |
|
|
|
|
|
|
|
once |
|
500 g |
|
|
|
|
|
|
|
twice |
|
800 g |
|
|
|
|
|
|
|
3 times |
|
1000 g |
|
|
|
|
|
|
|
4 times |
|
1200 g |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1. Touch START pad. |
When you touch START pad, the |
|
|
|
|||
START |
|
|
|
display changes into cooking time and the |
|
|
|
|
oven starts cooking. |
The defrosting time is automatically determined by the weight selected.
The g indicator goes off and the DEFROST indicator blinks and the defrosting time counts down in the display window. The oven beeps during the defrosting cycle to signal that the food needs to be turned or rearranged. When the defrosting time ends, you will hear 3 beeps.
