Daewoo GV-S42P User Manual
S
P
E
A
K
E
R
PLASMA MONITOR (DISPLAY)
SPEAKER
PLASMA MONITOR (DISPLAY)
OPTIONS INSTRUCTION MANUAL
PLASMA MONITOR(DISPLAY)
W ALL HANGER UNIT
PLASMA MONITOR (DISPLAY)
ST AND
S
T
A
N
D
HW
AA
NL
GL
E
R
U
N
I
T
GV -S42P
GV -H42G
GV -S42T
S
P
E
A
K
E
R
PLASMA MONITOR (DISPLAY)
SPEAKER
INSTRUCTION MANUAL
GV-S42P
Thank you for purchasing the Gold vision Plasma Display Speakers. These speakers are
specifically designed only for the Gold vision Plasma Display. To ensure the safe operation
of the unit, please read these instructions before installing.
1
TABLE OF CONTENTS
1. Check for enclosed parts
............................
2
2. Important Safety Instructions
......................
3
3. Assembly Instructions
.................................
5
1)
Using speakers when attached to the plasma display
2) Using speakers on its own stand
PLASMA DISPLAY SPEAKER
2
S
P
E
A
K
E
R
1. PLEASE CHECK THE
FOLLOWING ITEMS
SHOWN BELOW
(2) (16)
(2) (2)
(2)
M4 SCREWS
SPEAKER
VIBRA TION ABSORBENT SPONGE
SPEAKER WIRES
CLAMP WIRE
(4)
FIXED BRACKETS
A
B
C
3
2. IMPORTANT SAFETY INSTRUCTIONS
PLEASE KEEP THESE INSTRUCTIONS FOR YOUR SAFETY AND TO PREVENT ANY DAMAGE TO THIS UNIT.
PLEASE FOLLOW THESE INSTRUCTIONS FOR YOUR SAFETY
(Doing so may cause the unit to fall and break)
(Failing to do so may cause the unit to vibrate and to fall)
(Failing to do so may cause the unit to fall and break) (Failing to do so can damage the speaker circuits resulting in fire)
(It can cause electric shock or injury to the child)
Do not use any parts other than those
enclosed.
Do not leave out any part when assembling.
Please install all parts as indicated.
Do not alter or modify any parts
Do not use the speakers with other products.
These speakers are specifically manufactured to be
used with the Gold vision Plasma display to
enhance your listening pleasure.
Do not allow a child to cling from or climb unto
the speakers
Do not place the speakers on sloped or
unstable surfaces.
WARNING
CAUTION
WARNING : Disregarding these instructions can result in serious injury.
CAUTION : Disregarding these instructions will result in the mistreatment of
the unit and can result in injury or damage to the unit.
(Doing so may cause the speakers to fall off or
tip over causing injury and damage.)
PLASMA DISPLAY SPEAKER
4
S
P
E
A
K
E
R
Please be careful not to stain the speakers with
any gas or oil.
When assembling, be sure to use the enclosed
parts and make sure all parts are tightly
screwed as instructed.
Do not place the speakers in a humid or dusty
place.
Do not place the speakers near heating units.
Do not place speakers near a humidifier, or
cooking pots where speakers will be exposed
to steam or smoke.
Please be sure to connect (+) inputs and (-)
inputs correctly when connecting speakers to
plasma display.
*
PLEASE FOLLOW THESE SAFETY PRECAUTIONS WHEN INST ALLING OR HANDLING
(Failing to do so will cause the speakers to
vibrate and unable to produce clear sound.)
(Doing so will change the outer appearance)
(Failing to do so may alter the units)
(Failing to do so may cause discoloration or
damage to speakers)
(If not connected correctly, it may result in distorted sound)
(Failing to do so will damage the speakers)
5
3. ASSEMBLING INSTRUCTIONS
USING SPEAKERS WHEN ATTACHED TO THE PLASMA DISPLAY
ATTACHING VIBRATION ABSORBENT SPONGES TO SPEAKERS
INSTALLING FIXED BRACKETS TO SPEAKERS
.
Clean the surface with soft, lint-free cloth
where sponges will be attached.
.
Attach the sponge to the side of the
speaker that will be attached to the
plasma display.
Please leave a 5 mm space on the top
and bottom when attaching. Do not
cover the entire side with the sponge
as shown in the picture above.
5mm
(2 inch)
5mm
(2 inch)
.
Install fixed brackets to speakers before
attaching speakers to plasma display.
Please make sure which side the fixed
brackets will be screwed to,
considering the left and right side of
speakers as shown in the picture to
the left.
Fixed brackets
Sponge-attached side
1
2
Note
Note
Bracket (A)
Bracket (C)
Bracket (B)
Bracket (C)
PLASMA DISPLAY SPEAKER
6
S
P
E
A
K
E
R
INSTALLING SPEAKERS TO THE PLASMA DISPLAY
.
Place a protective covering over the surface you will be working on and lay
the plasma display as shown below.
.
Take the speakers with fixed brackets to the back of the plasma display. Place the hooks onto
the fixed brackets to the squared holes in the back of the plasma display.
.
Now tightly secure the
hooks with the M4 screws.
Hooks
3
Note
.
Please be sure to secure the screws to avoid
any shaking or looseness.
7
CONNECTING SPEAKER WIRES
.
Take the speaker wire(2) and use the red cord to connect to and fro (+) inputs,
and use the black cord to connect to and fro (-) inputs.
4
.
Please be sure to connect red cord with (+) and black with (-); otherwise,
speakers will not produce clear sounds.
.
Please retain the left over accessories.
.
Connecting Clamp Wires:
- It is used keeping a speaker wire (A speaker wire is connected the back
side of main body) as a ficture.
Note
