Daewoo GTG080PANR, GTQ080PANR, GTV085PANR User Manual

F E ATURE CHART

ICE TRAY
FREEZER SHELF (MOVABLE)
FREEZER TEMPERATURE
CONTROL SWITCH
ICE BOX
LAMP COVER
REFRIGERATOR TEMPERATURE
CONTROL SWITCH
REFRIGERATOR SHELF
( M O V A B L E )

VEGETABLE CASE COVER
VEGETABLE CASE
FREEZER POCKET (SM)
FREEZER POCKET (SM)
EGG CASE
EGG POCKET
REFRIGERATOR POCKET (MULT)
REFRIGERATOR POCKET (BG)
REFRIGERATOR POCKET (SM)

1

Here are the features of your new refrigerator.

Take a moment to know all the features designed for the convenience of the user.

■ Ice tray

Fill 3/4 of the ice tray with water, as the volume expands when the water is frozen. Place
the tray in the freezer compartment. To release ice cubes, twist the ice tray slightly. Ice
cubes will be easier to remove if it is held for a short while under running water.

■ Movable refrigerator and freezer shelves

Storage shelves should be adjusted depending on the height of the food stored. To do this,
pull the shelves slightly forw a rd .

■ Vegetable case

May be used for fruit and vegetable storage. Both the vegetable case and its cover shelf
a re removable for easy cleaning. Simply slide forw a rd to re m o v e .

■ Utility Pocket (To p )

The Egg Case in this pocket can be turned upside down for the use of small size goods.

CAUTION: 1. Check your voltage before inserting the power supply cord into the socket.

2. Contact the earthing conductor to this unit with an attachment earthing screw.

3. Do not spill liquid on this unit.

4. Do not use flammable spray, such as painting, near this unit.

5. Do not place ignitable material, such as benzine, L.P. gas, alcohol etc., into this unit.

6. Take precautions against leakage of any gas equipment near this unit.

7. Keep chidren from hanging on the door of this unit.

8. Do not reinsert the power supply cord within 5 minutes after releasing it from the
socket. If not, there may be problems with the compressor.

9. Put food in the refrigerator after running the refrigerator for 2~3 hours.

HOW TO INSTA L L

Location

Install the refrigerator in a convenient location away from extreme heat and cold. Allow
at least 6cm clearance between the refrigerator and side wall so that the door may open
for a fully usable interior and the refrigerator may have good air circulation. The
refrigerator is not designed for recessed installation.

■ Select a strong and level floor.

■ Keep 6cm of space between the refrigerator and the walls.
