Daewoo DVQ-14H2FC User Manual
DVQ 14H1FC
DVQ 20H1FC
INSTRUCTION MANUAL
TV/VCR COMBINATION
DVQ 14H2FC
DVQ 20H2FC
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk electric
shock.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and servicing instructions in the literature
accompanying the appliance.
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION
CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE MANUFACTURER
COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
NOTE TO CATV SYSTEM INSTALLER
THIS REMINDER IS PROVIDED TO CALL THE CATV SYSTEM INSTALLER'S ATTENTION
TO ARTICLE 820-40 OF THE NEC THAT PROVIDES GUIDELINES FOR PROPER GROUNDING AND, IN PARTICULAR, SPECIFIES THAT THE CABLE GROUND SHALL BE CONNECTED TO THE GROUNDING SYSTEM OF THE BUILDING, AS CLOSE TO THE POINT OF
CABLE ENTRY AS PRACTICAL.
CAUTION
The AC power cord provided with this product is polarized (one blade wider than the other).
To provide power to the TV, insert the AC plug into a standard 120V 60Hz polarized outlet.
NOTE
Never connect the plug to an electrical source other than one providing 120V 60Hz power. Use only
the attached power cord. If the polarized AC cord does not fit into a non-polarized outlet, do not cut or
file the blade. You are responsible for having the obsolete outlet replaced with a polarized outlet.
If you feel a static discharge when touching the unit, and the unit does not function, simply unplug the
unit from the outlet. When you plug the unit back in, it should work normally.
Do not install power cords near any heating element or cooking appliances.
Precautions
LOCATION
For safe operation and satisfactory performance of your unit, keep the following in mind when
selecting a place for its installation :
• Shield it from direct sunlight and keep it away from sources of intense heat.
• Avoid dusty or humid places.
• Avoid places with insufficient ventilation for proper heat dissipatio. do not block the ventilation holes at the top and bottom of the unit.
do not place the unit on a carpet because this will block the ventilation holes.
• Install the unit in a horizontal position.
• Avoid locations subject to strong vibration.
• Do not place the unit near strong magnetic fields.
• Do not move the unit from a cold place to a hot place or vice versa (see the warning below).
AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE
• Do not handle the power cord with wet hands.
• Do not pull on the power cord when disconnecting it from an ac wall outlet. grasp it by plug.
• If, by accident, water is spilled on your unit, unplug the power cord immediately and take the
unit to an authorized daewoo service center for servicing.
• Do not put your fingers or objects into the TV/VCR cassette holder.
• Do not place anything directly on top of the unit.
WARNING
Mosture condensation may occur inside the unit when it is moved from a cold place to a warm
place, after heating in a cold room, or under conditions of high humidity. if a tape is played in
a TV/VCR that has moisture, it may damage the tape and TV/VCR. when condensation
occurs inside the unit, turn the power on and allow at least 2 hours for the unit to dry.
FCC WARNING
This equipment may generate or use radio frequency energy. changes or modifications to this
equipment may cause harmful interference unless the modifications to this equipment may
cause harmful interference unless the modifications are expressly approved in the instruction
manual.
The user could lose the authority to operate this equipment if an unauthorized change or modification is made.
IMPORTANT COPYRIGHT INFORMATION
Unauthorized recording or use of broadcast television programming, video tape, film, or other
copyrighted material may violate applicable copyright laws. we assume no responsibility for
the unauthorized duplication, use or other acts which infringe upon the rights of copyright
owners.
SAFETY
IMPORTANT SAFEGUARDS
PLEASE READ ALL THESE INSTRUCTIONS REGARDING YOUR TELEVISION EQUIPMENT
AND RETAIN FOR FUTURE REFERENCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS
MARKED ON THE TV RECEIVER.
1 Read all of these instructions.
2
Save these instructions for later use.
3
Unplug this television equipment from the
wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
4
Do not use attachments not recommended by
the television equipment manufacturer as
they may result in the risk of fire, electric
shock or other personal injury.
5
Do not use this television equipment near
water, for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool, or the
like.
6
Do not place this television equipment on an
unstable cart, stand, or table. The television
equipment may fall, causing serious injury to
a child or adult, and serious damage to the
equipment. Use only with a cart or stand recommended by the manufacturer, or sold with
the television equipment. Wall or shelf
mounting should follow the manufacturer's
instructions, and should use a mounting kit
approved by the manufacturer.
6A
An appliance and cart combination should be
moved with care. Quick stops, excessive
force, and uneven surfaces may cause the
appliance and cart combination to overturn.
7
Slots and openings in the cabinet and the
back or bottom are provided for ventilation
and to ensure reliable operation of the television equipment; and to protect it from overheating, these opening, must not be blocked
or covered. The opening should never be
blocked by placing the television equipment
on a bed, sofa, rug, or other similar surface.
(This equipment should never be placed near
or over a radiator or heat register.) This television equipment should not be placed in a
built-in installation such as a bookcase
unless proper ventilation is provided.
8
This television equipment should be operated only from the type of power source indicated on the marking label. If you are not
sure of the type of power supplied to your
home, consult your television dealer or local
power company.
9
This television equipment is equipped with a
polarized alternating current line plug (a plug
having one blade wider than the other). This
plug will fit into the power outlet only one
way. This is a safety feature. If you are
unable to insert the plug fully into the outlet,
try reversing the plug. If the plug should still
fail to fit, contact your electrician to replace
your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
10
Do not allow anything to rest on the power
cord. Do not locate this television equipment
where the cord will be abused by persons
walking on it.
11
Follow all warnings and instructions marked
on the television equipment.
12
For added protection for this television
equipment during a lightning storm, or when
it is left unattended and unused for long periods of time, unplug it from the wall outlet
and disconnect the antenna or cable system.
This will prevent damage to the equipment
due to lightning and power-line surges.
13
An outside antenna system should not be
located in the vicinity of overhead power
lines or other electric light or power circuits,
or where it can fall into such power lines or
circuits. When installing an outside antenna
system, extreme care should be taken to
keep from touching such power lines or circuits as contact with them might be fatal.
14
Do not overload wall outlets and extension
cords as this can result in fire or electric
shock.
15
Never push objects of any kind into this television equipment through openings as they
may touch dangerous voltage points or
short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind
on the television equipment.
16
Do not attempt to service this television
equipment yourself as opening or removing
covers may expose you to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
17
Unplug this television equipment from the
wall outlet and refer servicing to qualified
service personnel under the following conditions:
(a) When the power-supply cord or plug is
damaged or frayed.
(b) If liquid has been spilled, or objects have
fallen into the television equipment.
(c) If the television equipment has been exposed
to rain or water.
(d) If the television equipment does not operate
normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an
improper adjustment of other controls may
result in damage and will often require extensive work by a qualified technician to restore
the TV receiver to its normal operation.
(e) If the television equipment has been dropped or
the cabinet has been damaged.
(f) When the television equipment exhibits a
distinct change in performance - this indicates a need for service.
18
When replacement parts are required, be
sure the service technician has used replacement parts specified by the manufacturer
that have the same characteristics as the
original part. Unauthorized substitutions
may result in fire, electric shock or other
hazards.
19
Upon completion of any service or repairs to
this television equipment, ask the service
technician to perform safety checks to determine that the television is in a safe operating
condition.
20
If an outside antenna or cable system is connected to the television receiver, be sure the
antenna or cable system is grounded so as to
provided some protection against voltage
surges and built-up static charges.
Section 810 of the National Electrical Code,
ANSI/NFPA N0.70-1984, provides information with respect to proper grounding of the
mast and supporting structure, grounding of
the lead-in wire to an antenna discharge unit,
size of grounding conductors, location of
antenna-discharge unit, connection to
grounding electrodes, and requirements for
the grounding electrode.
1
Table of Contents
Table of Contents
Preface : Your New TV/VCR
⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯
2
Features ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯2
Unpacking Your TV/VCR ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 3
Chapter 1 : Overview of Your Equipment
⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯
4
Your TV/VCR’s Front Panel ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯4
Your TV/VCR’s Back Panel ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯5
Your Remote Controller⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯6
Chapter 2 : Connecting an Antenna or Cable to Your TV/VCR
⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯
9
Connecting an Antenna ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯9
Connecting a Cable System ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯11
Connecting Other Pieces of Equipment ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯12
Safety Notes⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯12
Chapter 3 : Operating Your TV
⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯
13
Turning Your TV/VCR On ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯13
Programming Your TV/VCR’s Channel Memory ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 13
Changing channels ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯14
Changing the Volume ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯14
Changing the TV/VCR’s Channel Memory ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯15
Displaying the TV/VCR’s Status during TV operation⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯15
Adjusting Video Settings ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯16
Chapter 4 : Operating Your VCR
⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯
18
Video Cassette Tapes ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯18
Playing a Tape ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯19
Basic Recording ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯20
One Touch Recording (OTR) ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯21
Displaying the TV/VCR’s Status during VCR Operation⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯22
Using the Counter (Zero Stop) ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯23
Chapter 5 : Using Timer Functions
⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯
24
Setting the Clock Automatically ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯24
Setting the Clock Manually ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯25
Setting the On Time ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯26
Setting the Off Time⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯26
Canceling the On Time or Off Time⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯27
Setting the Sleep Timer ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯28
Chapter 6 : Additional TV Features
⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯
29
Changing the Language of the On-Screen Menus ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯29
Captioning ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 29
CC on Mute ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯30
Power Restore ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯30
Parental Control Settings ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯31
Description of Parental Control Settings ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯32
Mini Glossary ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯33
Chapter 7 : Additional VCR Features
⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯
34
Programming to Record at a Later Time ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯34
Setting the Program Recording⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯35
Canceling the Program Record Settings ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯37
Displaying the Tape Counter ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯38
Auto Repeat PlayBack ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯39
Rental Play ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯39
Index Search (VISS)⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯40
Duplicating a Video Tape⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯41
Chapter 8 : Troubleshooting
⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯
42
Mainternance and specifications
⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯
43
Warranty
⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯
44
CONTENTS
2
Preface : Your New TV/VCR
PREFACE
Your New TV/VCR
Congratulations on your purchase of a new Daewoo TV/VCR. We hope you find that your
new TV/VCR provides you with years of reliable performance.
Your new TV/VCR is designed and engineered to provide you with the latest in features for
your convenience. Listed below are just a few of the many features of your equipment.
Features
• Auto Power On
This feature automatically turns the TV/VCR on when you insert a cassette.
• On-screen Programming
You can use simple on-screen menus to perform all of the major operating features of your
TV/VCR, including programming to record.
• Tri-lingual Menus
You can choose to display the on-screen menus in English, French or Spanish.
• Auto Clock Setting
Your TV/VCR can automatically set its internal clock based on a signal from local PBS stations.
• Infrared Remote Control
The remote control included with your TV/VCR allows you to complete almost all operations from the comfort of your easy chair.
• 181 Channel Capability
Your TV/VCR has a advanced tuner that can receive up to 181 channels.
• Closed Caption Decoder
Your TV/VCR can decode the hidden text and captions that are broadcast with many shows
and are included on many videotapes.
• Record/Playback Speeds
Your TV/VCR can recording to two speeds(SP, EP), playback to three speeds (SP, LP, EP).
SP(Standard Play), LP(Long Play), EP (Extend Play)
• Automatic Playback Speed Selection
Your TV/VCR will automatically play a pre-recorded tape at the correct speed.
• Still Frame Capability
Your TV/VCR can display a single frame from a video tape.
• Rental Play Mode
This special setting improves the playback quality of worn tapes, especially rental tapes.
• Repeat Playback
You can set your TV/VCR to automatically repeat an entire video tape, or to repeat the
recorded part of a videotape.
3
Preface : Your New TV/VCR
• Video Index Search System (VISS)
This feature allows you to find index marks on your tape quickly. Your TV/VCR places
index marks at the beginning of each new recording.
• One Touch Recording (OTR)
You can quickly begin recording and set the length of time to record using just one button.
• 6 Events / 1 Month Timer Recording
You can program up to six different recording sessions up to a month in advance.
• Daily / Weekly Recording
You can easily set your VCR to record every day at the same time, or to record every week
at the same time.
• Sleep Timer
You can set your TV/VCR to turn off after a certain amount of time passes, from 15 minutes to 120 minutes.
• On Timer
You can set your TV/VCR to turn on at a certain time.
• Parental Control
Parental control is on the 31 page.
Unpacking Y our TV/VCR
The following items are included with your TV/VCR. If these items are missing, please contact your Daewoo dealer immediately.
1 A remote control
2 A 300-ohm/75-ohm adaptor -> (13” only)
3 A rod antenna (“rabbit ears”) -> (13” only)
4
Chapter 1 : Overview of Your Equipment
CHAPTER
1
Overview of Your Equipment
Your TV/VCR’s comes with a remote control. The section below summarizes the buttons,
controls, and terminals that will use with your TV/VCR’s.
Y our TV/VCR's Front Panel
Below you will find short description of the buttons and indicators on the front panel. These
are use following functions.
1 VIDEO in jack
Use this jack to receive a video signal from another A/V component.
2 AUDIO in jack
Use this jack to receive a audio signal from another A/V component.
3 EAR PHONE jack
Use this jack to the earphone (not supplied). The sound from the speaker is turned off.
4 Remote control receiver
This receiver receives a signal from your remote control. Do not block it.
5 STAND-BY(red) indicator
This indicator light up when the power is off.
6 REC (red/green) indicator
This indicator light up red when recording and light up green when timer program operating.
7 REC button
Press this button to begin recording. Press repeatedly to set a recoding time using
One-Touch Recording (OTR).
8 REW button
Press this button to rewind the tape.
9 PLAY button
Press this button to begin normal palyback of the tape
10 FF button (Fast Forward)
Press this button to fast forward the tape.
5
Chapter 1 : Overview of Your Equipment
11 STOP/EJECT button
Press this button when the tape is moving to stop the tape. Press this button when the tape
is stopped to eject it.
12CCVOLBBbuttons (volume)
Press these buttons to change your TV/VCR’s volume.
13yyCHxxbuttons (channel)
Press these buttons to change channels on your TV/VCR. You will also use these buttons
to adjust the tracking.
14 POWER button
Press this button to turn your TV/VCR on or off.
Y our TV/VCR’s Back Panel
1 Antenna terminal
Use this terminal to attach an antenna or cable
system to your TV/VCR.
1
Y our Remote Controller
1. POWER
Press this button to turn your TV/VCR on or off.
2. RECALL
Press this button to display the current time, the
counter, channel number and other status items.
3. TV/LINE
Press this button to select between viewing the
signal coming from the antenna terminal (TV) or
the signal coming from the A/V jack (LINE).
4. FAVORITE CH
Press this button to return to the previous channel
you were watching.
5. CANCEL
Press this button to erase timer program recording
settings.
6. C-RESET
Press this button to reset the counter to 0:00:00.
7. MUTE
Press to turn the TV/VCR’s sound on and off.
8.yyCHxx(TRK)
Press these buttons to change channels on your
TV/VCR, or select items in the menu system, or
to adjust the tracking of a video tape during playback.
9.CCVOL
BB
Press these buttons to change your TV/VCR’s
volume, to activate selections in the menu system,
or to change audio and video settings.
6
Chapter 1 : Overview of Your Equipment
7
Chapter 1 : Overview of Your Equipment
10. MENU
Press this button to turn the TV/VCR’s menu system on and off.
11. 0-9
Press these buttons to change channels.
12. SPEED
Press this button to select the SP, EP tape speed when the tape recording.
13. C-
O
STOP
Press this button to find the counter zero.
14. 0(ATK)
Press this button to automatically set tracking point when the tape playback.
15. REW
Press this button to rewind the tape.
17. FF button (Fast Forward)
Press this button to fast forward the tape.
18. PAUSE/STILL
Press to temporarily stop the tape during recording or playback.
19. REC/OTR
Press this button to begin recording. Press repeatedly to set a recording time using
One-Touch Recording (OTR)
20. STOP/EJECT
Press this button when the tape is moving to stop the tape. Press this button when the tape
is stopped to eject it.
21. VISS -
Press this button to find the most recent index mark on tape and begin playing.
22. VISS +
Press this button to find the next index mark on tape and begin playing.
8
Chapter 1 : Overview of Your Equipment
Installing Y our Remote Control Batteries
1.
Open the battery compartment on the back of the remote control.
2.
Install two AAA-size batteries (not included) as shown. Make sure the “+” and “-” terminals
are oriented correctly.
3.
Replace the cover.
Notes
Do not mix different types of batteries, or mix an old and a new battery.
Remove and replace weak batteries. Weak batteries can leak and damage your controller.
Dispose of batteries properly; never throw them into a fire.
Point your remote at the receiver on the center of the front of the TV/VCR. Make sure the
receiver is not blocked.
The remote control can operate up to 30 feet away from the TV/VCR, if you are directly fac-
ing the front of the TV/VCR. Operating distance diminishes as you move to the sides of the
TV/VCR.
CHAPTER
2
9
Chapter 2 : Connecting an Antenna or Cable to Your TV/VCR
Connecting an Antenna or Cable to Y our TV/VCR
Your TV/VCR will provide you with the best performance if you connect it to an external
antenna or cable system. Follow the directions below make this connection. Please note that
you will normally only have to make one of the connections shown below, not all of them.
All connections will be made to the antenna terminal on the back of your TV/VCR. The
antenna terminal is a silver metal post partially surrounded by two plastic tabs. For help in
locating the antenna terminal, see “Your TV/VCR's Back Panel” on page 5.
There is no antenna provided with your TV/VCR.
Connecting an Antenna
If your antenna ends in a single coaxial lead,
simply press or screw the cable onto the antenna
terminal on the back of your TV/VCR.
If your antenna ends in a pair of 300 ohm twin leads, you must use a 300-ohm/75-ohm
adaptor. (An adaptor is included with your 13” TV/VCR.) Place the leads underneath the
screws on the adaptor, tighten the screws, then press the adaptor onto the antenna terminal on
the back of the TV/VCR.
10
Chapter 2 : Connecting an Antenna or Cable to Your TV/VCR
Antennas with two sets of leads
You might have two sets of leads from your antenna system, especially if you have one antenna for VHF signals and one antenna for UHF signals.
If your antenna system has both a coaxial lead and twin 300-ohm leads
, you must obtain a com-
biner (available at your local electronics store). Press or screw the coaxial lead onto the combiner; place the twin leads underneath the screws on the combiner and tighten the screws.
Press the cable from combiner onto the antenna terminal on the back of the TV/VCR.
If your antenna system has two sets of twin 300-ohm leads, you must obtain a combiner
(available at your local electronics store). Place one set of twin leads underneath the screws on
the combiner and tighten the screws. Do the same with the other set of twin leads. Press the
cable from the combiner onto the antenna terminal on the back of your TV/VCR.
Loading...
