S/M No:CN071N-010
Service Manual
TV / VCR Combination
CHASSIS : CN-071
MODEL :
DVQ-13H1FC
DVQ-19H1FC
DVQ-13H2FC
DVQ-19H2FC
DAEWOO ELECTRONICS CO., LTD
http : //svc.dwe.co.kr
Page 2
TABLE OF CONTENTS
SAFETY PRECAUTIONS .................................................................................................2
SPECIFICATION ..........................................................................................................5
BLOCK DIAGRAM .......................................................................................................6
IC DESCRIPTION .........................................................................................................8
SYSTEM FEATURE .............................................................................................................................. 9
PIN DESCRIPTION ............................................................................................................................. 10
TROUBLESHOOTING GUIDE .........................................................................................17
NO POWER ..................................................................................................................................... 17
TV PART ........................................................................................................................................... 18
VCR PART ........................................................................................................................................25
ELECTRICAL PARTS LIST ...............................................................................................34
EXPLODED VIEW .........................................................................................................44
1
Page 3
SAFETY PRECAUTIONS
CAUTION
NEVER PERFORM CUSTOMIZED INSTALLATIONS WITHOUT MANUFACTURER°ØS APPROVAL. UNAUTHORIZED MODIFICATIONS WILL NOT ONLY
VOID THE WARRANTY, BUT MAY LEAD TO YOUR BEING LIABLE FOR ANT
RESULTING PROPERTY DAMAGE OR USER INJURY.
SERVICE WORK SHOULD BE PERFORMED ONLY AFTER YOU ARE THOROUGHLY FAMILIAR WITH ALL OF THE FOLLOWING SAFETY CHECKS AND
SERVICING GUIDELINES. TO DO OTHERWISE, INCREASES THE RISK OF
POTENTIAL HAZARDS AND INJURY TO THE USER.
WHILE SERVICING, USE AN ISOLATION TRANSFORMER FOR PROTECTION
FROM A.C. LINE SHOCK.
: DO NOT ATTEMPT TO MODIFY THIS PRODUCT IN ANY WAY.
SAFETY CHECKS
AFTER THE ORIGINAL SERVICE PROBLEM HAS BEEN CORRECTED, A CHECK
SHOULD BE MADE OF THE FOLLOWING:
SUBJECT:FIRE & SHOCK HAZARD
1. BE SURE THAT ALL COMPONENTS ARE POSITIONED IN SUCH A WAY AS
TO AVOID POSSIBILITY OF ADJACENT COMPONENT SHORTS. THIS IS
ESPECIALLY IMPORTANT ON THOSE MODULES WHICH ARE TRANSPORTED TO AND FROM THE REPAIR SHOP.
2. NEVER RELEASE A REPAIR UNLESS ALL PROTECTIVE DEVICES SUCH AS
INSULATORS, BARRIERS, COVERS, SHIELDS, STRAIN RELIEFS, POWER
SUPPLY CORDS, AND OTHER HARDWARE HAVE BEEN REINSTALLED PER
ORIGINAL DESIGN. BE SURE, THAT THE SAFETY PURPOSE OF THE
POLARIZED LINE PLUG HAS NOT BEEN DEFEATED.
3. SOLDERING MUST BE INSPECTED TO DISCOVER POSSIBLE COLD SOLDER JOINTS, SOLDER SPLASHES OF SHARP SOLDER POINTS. BE CERTAIN TO REMOVE ALL LOOSE FOREIGN PARTICLES.
4. CHECK FOR PHYSICAL EVIDENCE OF DAMAGE OR DETERIORATION TO
PARTS AND COMPONENTS, FOR FRAYED LEADS, DAMAGED INSULATION
(INCLUDING A.C. CORD), AND REPLACE IF NECESSARY. FOLLOW ORIGINAL LAYOUT, LEAD LENGTH AND DRESS.
5. NO LEAD OR COMPONENT SHOULD TOUCH A RECEIVING TUBE OR A
RESISTOR RATED AT 1 WATT OR MORE. LEAD TENSION AROUND PROTRUDING METAL SURFACES MUST BE AVOIDED.
6. ALL CRITICAL COMPONENTS SUCH AS FUSES, FLAMEPROOF RESISTOR,
CAPACITORS, ETC. MUST BE REPLACED WITH EXACT FACTORY TYPES.
DO NOT USE REPLACEMENT COMPONENTS OTHER THAN THOSE SPECIFIED OR MAKE UNRECOMMENDED CIRCUIT MODIFICATIONS.
7. AFTER RE-ASSEMBLY OF THE STE ALWAYS PERFORM AN A.C. LEAKAGE
TEST ON ALL EXPOSED METALLIC PARTS OF THE CABINET. (THE CHANNEL SELECTOR KNOB, ANTENNA TERMINALS, HANDLE AND SCREWS) TO
BE SURE THE SET IS SAFE TO OPERATE WITHOUT DANGER OF ELECTRICAL SHOCK. DO NOT USE A LINE ISOLATION TRANSFORMER DURING
THIS TEST USE AN A.C. VOLTMETER, HAVING 5000 OHMS PER VOLT OR
MORE SENSITIVITY, IN THE FOLLOWING MANNER : CONNECT A 1500 OHM
10 WATT RESISTOR, PARALLELED BY A .15 MFD. 150V A.C. TYPE CAPACITOR BETWEEN A KNOWN GOOD EARTH GROUND (WATER POPE, CONDUIT, ETC.) AND THE EXPOSED METALLIC PARTS, ONE AT A TIME.
MEASURE THE A.C. VOLTAGE ACROSS THE COMBINATION OF 1500 OHM
RESISTOR AND .15 MFD CAPACITOR. REVERSE THE A.C. PLUG AND
REPEAT A.C. VOLTAGE MEASUREMENTS FOR EACH EXPOSED METALLIC
PART. VOLTAGE MEASURED MUST NOT EXCEED .75 VOLTS R.M.S THIS
CORRESPONDS TO 0.5 MILLIAMP A.C. NAY VALUE EXCEEDING THIS LIMIT
CONSTITUTES A POTENTIAL SHOCK HAZARD AND MUST BE CORRECTED
IMMEDIATELY.
A.C. VOLTMETER
0.15 uF
GOOD EARTH GROUND
SUCH AS THE WATER
PIPE, CONDUIT, ETC.
1500 OHM
10WATT
PLACE THIS PROBE
ON EACH EXPOSED
METAL PART
SUBJECT : GRAPHIC SYMBOLS
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL,
WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED
TO ALERT THE SERVICE PERSONNEL TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE”
THAT MAY BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL
TRIANGLE IS INTENDED TO ALERT THE SERVICE
PERSONNEL TO THE PRESENCE OF IMPORTANT
SAFETY INFORMATION ON SERVICE LITERATURE.
SUBJECT : X-RADIATION
1. BE SURE PROCEDURES AND INSTRUCTIONS TO ALL SERVICE PERSONNEL COVER THE SUBJECT OF X-RADIATION. THE ONLY POTENTIAL
SOURCE OF X-RAYS IN CURRENT T.V. RECEIVERS IS THE PICTURE TUBE.
HOWEVER, THIS TUBE DOES NOT EMIT X-RAYS WHEN THE HIGH VOLTAGE IS AT THE FACTORY SPECIFIED LEVEL. THE PROPER VALUE IS
GIVEN IN THE APPLICABLE SCHEMATIC. OPERATION AT HIGHER VOLTAGES MAY CAUSE A FAILURE OF THE PICTURE TUBE OR HIGH VOLTAGE
SUPPLY AND, UNDER CERTAIN CIRCUMSTANCES, AMY PRODUCE RADIATION IN EXCESS OF DESIRABLE LEVELS.
2. ONLY FACTORY SPECIFIED C.R.T ANODE CONNECTORS MUST BE USED.
DEGAUSSING SHIELDS ALSO SERVE AS X-RAY SHIELD IN COLOR SETS.
ALWAYS RE-INSTALL THEM.
3. IT IS ESSENTIAL THAT SERVICE PERSONNEL HAVE AVAILABLE AN ACCURATE AND RELIABLE HIGH VOLTAGE METER. THE CALIBRATION OF THE
METER SHOULD BE CHECKED PERIODICALLY AGAINST A REFERENCE
STANDARD. SUCH AS THE ONE AVAILABLE AT YOUR DISTRIBUTOR.
4. WHEN THE HIGH VOLTAGE CIRCUITRY IS OPERATING PROPERLY THERE
IS NO POSSIBILITY OF AN X-RADIATION PROBLEM. EVERY TIME A COLOR
CHASSIS IS SERVICED, THE BRIGHTNESS SHOULD BE RUN UP AND
DOWN WHILE MONITORING THE HIGH VOLTAGE WITH A METER TO BE
CERTAIN THAT THE HIGH VOLTAGE DOES NOT EXCEED THE SPECIFIED
VALUE AND THAT IT IS REGULATING CORRECTLY. WE SUGGEST THAT
YOU AND YOUR SERVICE ORGANIZATION REVIEW TEST PROCEDURES
SO THAT VOLTAGE REGULATION IS ALWAYS CHECKED AS A STANDARD
SERVICING PROCEDURE, AND THAT THE HIGH VOLTAGE READING BE
RECORDED ON EACH CUSTOMER°ØS INVOICE.
5. WHEN TROUBLESHOOTING AND MAKING TEST MEASUREMENTS IN A
PRODUCT WITH A PROBLEM OF EXCESSIVE HIGH VOLTAGE, AVOID
BEING UNNECESSARILY CLOSE TO THE PICTURE TUBE AND THE HIGH
VOLTAGE SUPPLY. DO NOT OPERATE THE PRODUCT LONGER THAN IS
NECESSARY TO LOCATE THE CAUSE OF EXCESSIVE VOLTAGE.
6. REFER TO HV, B+ AND SHUTDOWN ADJUSTMENT PROCEDURES
DESCRIBED IN THE APPROPRIATE SCHEMATIC AND DIAGRAMS (WHERE
USED).
SUBJECT : IMPLOSION
1. ALL DIRECT VIEWED PICTURE TUBES ARE EQUIPPED WITH AN INTEGRA
IMPLOSION PROTECTION SYSTEM. BUT CARE SHOULD BE TAKEN TO
AVOID DAMAGE DURING INSTALLATION. AVOID SCRATCHING THE
TUBE. OF SCRATCHED REPLACE IT.
2. USE ONLY RECOMMENDED FACTORY REPLACEMENT TUBES.
SUBJECT : TIPS ON PROPER INSTALLATION
1. NEVER INSTALL ANY PRODUCT IN A CLOSED-IN RECESS, CUBBYHOLE OR
CLOSELY FITTING SHELF SPACE, OVER OR CLOSE TO HEAT DUCT, OR IN
THE PATH OF HEATED AIR FLOW.
2. AVOID CONDITIONS OF HIGH HUMIDITY SUCH AS: OUTDOOR PATIO
INSTALLATIONS WHERE DEW IS A FACTOR, NEAR STEAM RADIATORS
WHERE STEAM LEAKAGE IS A FACTOR, ETC.
3. AVOID PLACEMENT WHERE DRAPERIES MAY OBSTRUCT REAR VENTING.
THE CUSTOMER SHOULD ALSO AVOID THE USE OF DECORATIVE
SCARVES OR OTHER COVERINGS WHICH MIGHT OBSTRUCT VENTILATION.
4. WALL AND SHELF MOUNTED INSTALLATIONS USING A COMMERCIAL
MOUNTING KIT, MUST FOLLOW THE FACTORY APPROVED MOUNTING
INSTRUCTIONS. A PRODUCT MOUNTED TO A SHELF OR PLATFORM MUST
RETAIN ITS ORIGINAL FEET (OR THE EQUIVALENT THICKNESS IN SPACERS)TO PROVIDE ADEQUATE AIR FLOW ACROSS THE BOTTOM, BOLTS
OR SCREWS USED FOR FASTENERS MUST NOT TOUCH ANY PARTS OR
WIRING. PERFORM LEAKAGE TEST ON CUSTOMIZED INSTALLATIONS.
5. CAUTION CUSTOMERS AGAINST THE MOUNTING OF A PRODUCT ON
SLOPING SHELF OR A TILTED POSITION, UNLESS THE PRODUCT IS
PROPERLY SECURED.
6. A PRODUCT ON A ROLL-ABOUT CART SHOULD BE STABLE ON ITS MOUNTING TO THE CART. CAUTION THE CUSTOMER ON THE HAZARDS OF TRYING TO ROLL A CART WITH SMALL CASTERS ACROSS THRESHOLDS OR
DEEP PILE CARPETS.
7. CAUTION CUSTOMERS AGAINST THE USE OF A CART OR STAND WHICH
HAS NOT BEEN LISTED BY UNDERWRITERS LABORATORIES. INC. FOR
USE WITH THEIR SPECIFIC MODEL OF TELEVISION RECEIVER OR
GENERICALLY APPROVED FOR USE WITH T.V.S OF THE SAME OR
LARGER SCREEN SIZE.
8. CAUTION CUSTOMERS AGAINST THE USE OF EXTENSION CORDS,
EXPLAIN THAT A FOREST OF EXTENSIONS SPROUTING FROM A SINGLE
OUTLET CAN LEAD TO DISASTROUS CONSEQUENCES TO HOME AND
FAMILY.
2
Page 4
SAFETY PRECAUTIONS
CAUTION : Do not attempt to modify this product in any way. Unauthorized modifications will not only void the warranty, but may lead to
your being liable for any resulting property damage or user injury.
Service work should be performed only after you are thoroughly
familiar with all of the following safety checks and servicing guidelines. To do otherwise, increases the risk of potential hazards and
injury to the user.
SAFETY CHECKS
After the original service problem has been corrected, a check should
be made of the following:
SUBJECT : FIRE & SHOCK HAZARD
1. Be sure that all components are positioned in such a way as to
avoid possibility of adjacent component shorts. This is especially
important on those chassis which are transported to and from the
repair shop.
2. Never release a repair unless all protective devices such as insulators, barriers, covers, shields, strain reliefs, and other hardware
have been reinstalled per original design.
3. Soldering must be inspected to discover possible cold solder joints,
frayed leads, damaged insulation (including A.C. cord), solder
splashes or sharp solder points. Be certain to remove all loose foreign particals.
4. Check for physical evidence of damage or deterioration to parts
and components, and replace if necessary follow original layout,
lead length and dress.
5. No leads or components should touch a receiving tube or a resistor
rated at 1 watt or more. Lead tension around protruding metal surfaces must be avoided.
6. All critical components such as fuses, flameproof resistors, capacitors, etc. must be replaced with exact factory types. Do not use
replacement components other than those specified or make
unrecommended circuit modifications.
7. After re-assembly of the set always perform an A.C. leakage test
on all exposed metallic parts of the cabinet, (the channel selector
knob, antenna terminals, handle and screws) to be sure the set is
safe to operate without danger of electrical shock. Do not use a
line isolation transformer during this test. Use an A.C. voltmeter,
having 5000 ohms per volt or more sensitivity, in the following
manner : connect a 1500 ohm 10 watt resistor, paralleled by a 15
mfd. 150V A.C. type capacitor between a known good earth
ground (9water pipe, conduit, etc.) and the exposed metallic parts,
one at a time. Measure the A.C. voltage across the combination of
1500 ohm resistor and 0.15 MFD capacitor. Reverse the A.C. plug
and repeat A.C. voltage measurements for each exposed metallic
part. Voltage measured must not exceed 0.75 volts R.M.S. This
corresponds to 0.5 milliamp A.C. Any value exceeding this limit
constitutes a potential shock hazard and must be corrected immediately.
A.C. VOLTMETER
GRAPHIC SYMBOLS :
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to alert
the service personnel to the presence of uninsulated “dangerous voltage” that may be of sufficienty magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral triangle is intended to alert the service personnel
to the presence of important safety information
in service literature.
Fuse symbol is printed on pcb adjacent to the
fuse, with “RISK OF FIRE REPLACE FUSE AS
MARKED”. The symbol is explained in the service manual with the following wording or equivalent.
“CAUTION :
FOR CONTINUED PROTECTION AGAINST FIRE
HAZARD, REPLACE ONLY WITH SAME TYPE (6.3A, 250V)” and
“
ATTENTION
: AFIN D’ASSU UNE PROTECTION PERMANENTE
CONTRE LES RISQUES D’INCENDIE, REMPLACER UNIQUEMENT PAR UN FUSIBLE DE MEME TYPE ET DE ”6.3A, 250V”.
SUBJECT : X-RADIATION
1. Be sure procedures and instructions to all service personnel cover
the subject of X-rays in current T.V. receivers is the picture tube.
However, this tube does not emit X-rays when the high voltage is
at the factory specified level. The proper value is given in the applicable schematic. Operation at higher voltages may cause a failure
of the picture tube or high voltage supply and, under certain circumstances, may produce radiation in excess of desirable levels.
2. Only factory specified C.R.T. anode connectors must be used.
Degaussing shields also serve as X-ray shield in color sets.
Always re-install them.
3. It is essential that the serviceman has available an accurate and
reliable high voltage meter. The calibration of the meter should be
checked perio - dically against a reference standard. Such as the
one available at your distributor.
4. When the high voltage circuitry is operating properly there is no
possibility of an X-radiation problem. Every time a color chassis is
serviced, the brightness should be run up and down while monitoring the high voltage with a meter to be certain that the high voltage
does not exceed the specified value and that it is regulating correctly. We suggest that you and your service organization review
test procedures so that voltage regulation is always checked as a
standard servicing procedure. And that the high voltage reading be
recorded on each customer’s invoice.
5. When troubleshooting and making test measurements in a
receiver with a problem of excessive high voltage, avoid being
unnecessarily close to the picture tube and the high voltage compartment.
Do not operate the chassis longer than is necessary to locate the
cause of excessive voltage.
6. Refer to HV, B+and Shutdown adjustment procedures described in
the appropriate schematic and diagrams(where used).
Good earth ground,
such as the water
pipe, conduit, etc.
0.15 uF
1500 OHM
10WATT
Place this probe
on each exposed
metal part.
3
Page 5
SAFETY PRECAUTIONS
SUBJECT : IMPLOSION
1. All direct viewed picture tubes are equipped with an integral implosion protection system, but care should be taken to avoid damage
during installation. Avoid scratching the tube. If scratched, replace
it.
2. Use only recommended factory replacement tubes.
SUBJECT : TIPS ON PROPER INSTALLATION
1. Never install any receiver in closed-in recess, cubbyhole or closely
fitting shelf space over, or close to heat duct, or in the path of
heated air flow.
2. Avoid conditions of high humidity such as : Outdoor patio installations where dew is a factor. Near steam radiators where steam
leakage is a factor, etc.
3. Avoid placement where draperies may obstruct rear venting. The
customer should also avoid the use of decorative scarves or other
coverings which might obstruct ventilation.
4. Wall and shelf mounted installations using a commercial mounting
kit, must follow the factory approved mounting instructions. A
receiver mounted to a shelf or platform must retain its original
feet(or the equivalent thickness in spacers) to provide adequate
are flow across the bottom, bolts or screws used for fasteners
must not touch and parts or wiring. Perform leakage test on customized installations.
5. Caution customers against the mounting of a receiver on sloping
shelf or a tilted position, unless the receiver is properly secured.
6. A receiver on a roll-about cart should be stable on its mounting to
the cart. Caution the customer on the hazards of trying to roll a cart
with small casters across thresholds or deep pile carpets.
7. Caution customers against the use of a cart or stand which has not
been listed by underwriters laboratories, inc. For use with their
specific model of television receiver or generically approved for
use with T.V.’s of the same or larger screen size.
4
Page 6
SPECIFICATION
ITEMS MODEL DVQ-13/19H1FC, DVQ-13/19H2FC REMARK
TV
SECTION
VIDEO
SECTION
GENERAL POWER INPUT AC 120V 60Hz
STANDARD NTSC-M
TUNING SYSTEM Frequency Synthesizer(FS) Tuning System
TUNING RANGE VHF : 2 - 13(12)
UHF : 14 -69(56)
CATV : 1-125(125)
ANTENNA INPUT IMPEDENCE 75 ohm Unbalanced
AUXILIARY INPUT TERMINAL Front : Video, Audio
FORMAT VHS NTSC Standard
VCR SYSTEM Rotary 2-Head Helical Scanning
Monaural System
AUDIO RECORDING SYSTEM Monaural
TAPE SPEED SP:33.35mm/sec; EP:11.12mm/sec
LP:16.67mm/sec PLAY ONLY
INPUT Video :1Vp-p,75 Ohm
Audio :3.8dBm, over 100K Ohm
TIMER PROGRAMING 6 Event/1 Month
POWER CONSUMPTION 13=60W
19=70W
SOUND OUTPUT 1.3W
SPEAKER 3W 8 OHM
OPRATING TEMPERATRE
5°C to 40
°C
REMOTE CONTROL R-39A02
SPECIAL FUNTION 3-Language OSD
With CAPTION
Parental Control
K-MECHA
One Touch Record
Repeat Play
Energy Star Power (Stand-By:2W Under)
5
Page 7
BLOCK DIAGRAM
6
Page 8
BLOCK DIAGRAM
PH01
7
Page 9
IC DESCRIPTION
ICS01
DW37760MCA-AA1(M37760) : IC TIMER / SYSCON / CTL PROCESSOR
KEY1
AGC IN
OPTION
DRUM SELECT
PATH ADJUST
VIDEO ENV
END SENSOR
START SENSOR
POWER SAFETY
AFT
CAPSTAN I LIMIT
QV SYNC
REMOCON INPUT
C ROTARY
HEAD AMP SW (4HD)
COMPARATOR ENV (4HD)
V HEAD SW
REC (H)
TRICK (H)
C/DOWN (H)
CAP F/R
CRT ON(L)
SOUND MUTE (H)
AUDIO MUTE (H)
REC LED (H)
T-LED (H)
MONITOR ON (H)
KEY 0
100
/AN9
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
P11(1)
P11(0)/AN8
P7(7)/AN7
P7(6)/AN6
P7(5)/AN5
P7(4)/AN4
P7(3)/AN3
P7(2)/AN2
P7(1)/AN1
P7(0)/AN0
P6(7)/AN10/AD
P6(6)/RTP11/DA1
P6(5)/RTP10/DA0
P6(4)/RTP03/V
P6(3)/RTP02/GEN
P6(2)/EXORout1 (CROT)
P6(1)/EXORout0 (HASW)
P6(0)/EXORin (ENVS)
P5(7)/RTP01(VHSW)
P5(6)/RTP00(AHSW)
P5(5)/RTP2
P5(4)/RTP2
P5(3)/RTP2
P5(2)/RTP2
P5(1)/RTP2
P5(0)/RTP2
P4(7)
P4(6)
P4(5)
P4(4)
P4(3)
(2)
P4
CAM A
CAM B
(4)/INT2
P8
CAM C
P8(6)
P8(5)
P9(1)/RLS
P9(2)/INT0
P9(3)/PWM0
P9(4)/PWM1
REC SAFETY (L)
CAP FG IN
AMP GND
DRUM FG IN
DRUM PG IN
AMP REF IN
AMP REF OUT
CTL (-)
CTL (+)
CTL AMP OUT
AMP Vcc
ANALOG Vcc
99
98 97 96 9495 93 92 91 8990 88 87 86 8485 83 82 81
IN
IN
IN
CC
CC
OUT
AV
AMPV
CTLAMP
CTL-
CTL+
AMPC
REFIN
REFOUT
P8(0)/C
AMPV
AMPV
SS
OUT
AMPV
/DRPFG
(1)/DRFG
IN
P8
DRPG
(3)/INT1
P8
/CPFGAMP
IN
P8(2)/CPFGAMP
CPFG
P9(5)/PWM2
P10(0)/T1/SDA
TRG
P10(2)/S
P10(1)/S
CLK
CLK
0B/DRFG
P10(3)/SIN0/DRPG
SYNC
P10(4)/S
OUT
0/CPFG
P10(5)/S
P10(6)/SIN1
M37760
5
4
3
2
1
0
P10(7)/S
P0(3)/OUT2
P0(4)/OUT1
P0(5)/V
P0(6)/H
SYNC/CSYNCIN
P0(7)/CVIN(EDS)
P1(0)/V
IN3
OUT3
IN2
OUT2
P4(1)
(0)/Xcout
P4(0)
RESET (L)
P3(1)/Xcin
P3
Vcc
Xin
(2)/OSC
Xout
(1)/OSC
Vss
P2
P2
CLK SELECT
P2(0)/OSC
(6)/LP
P1(7)/OSC
NUB
P1
P1(5)/FSCINOSD Vss
3231 33 34 35 3736 38 39 40 4241 43 44 45 4746 48 49 50
CAM D
P8(7)
P9(0)/RLT
P9(6)/T4
P9(7)/T5
0A/SCL
MON
MON
MON
CLK
OUT
P0(0)/R
P0(1)/G
P0(2)/B
SYNC
NUA
HOLD
P1(1)/HLP
OSD Vcc
IN
P1(2)
P1(3)
P1(4)/CV
80
79
78
77
76
RLT
RLS
P/W FAIL
DRUM PWM
CAP PWM
75
74
73
72
71
LD ON
LD F/R
MAIN DATA
MAIN CLK
70
69
68
67
1
Y/C SCLK
66
65
1
64
63
62
Y/C SDA
OSD R
OSD G
OSD B
61
60
59
58
57
56
55
54
53
OSD BLANK
V-SYNC
H-SYNC
CAPTION
C.V.S
SLD FILTER
FILTER
OSD Vcc
52
51
Xcin
Xcout
VCR ON
RESET
RELAY ON
Xout
GND
Xin
Vcc
IN2
OUT2
NUB
OSC
OSC
OSD GND
CLK SELECT
8
Page 10
1. SYSTEM FEATURE
1) The system for TV/VCR tuning is Frequency Synthesis type.
2) VCR SERVO Controller is interior designed.
3) Closed Caption function is interior designed.
4) Parental Control function is interior designed.
5) On Screen Display function is interior designed.
6) Package : 100PIN QFP
7) Tuner (Pre-scaler) : IIC BUS
/PLL IC : TAU 6014-S (SIEMENS)
8) REMOCON : The IC of transmission (MITSUBISHI M50560)
9) EEPROM : 24AT08 (IIC BUS)
10)10-Local Key : A/D input control
(KEY 0 : REC, REW, PLAY, FF, STOP/EJECT)
(KEY 1 : POWER, CH UP/DOWN, VOL UP/DOWN)
11)Option S/W : Port A/D input Option check
12)IF/V/C/D IC : DCT814B (LA76814B)
13)VCR Y/C/A IC : LA71550M
14)DECK MECHANISM : K-MECHA
IC DESCRIPTION
9
Page 11
IC DESCRIPTION
2. PIN DESCRIPTION
Pin Terminal Name Explanation Remarks
1 P11(0) KEY 1 IN Power, Ch up/down, Vol up/down
2 P7(7) AGC IN Connect this port to AGC of Tuner.
Default voltage :3.75V
Variable voltage : 3.25V, 3.5V, 3.75V
3 P7(6) OPTION H(5V) : Parental control
M(2.5V) : Child lock
L(0V) : None
4 P7(5) DRUM SELECT H(5V) : NTSC 4 head
L(0V) : NTSC 2 head
5 P7(4) PATH ADJUST Automatic PATH adjust
6 P7(3) VIDEO ENVELOPE IN Connect this port to 6 pin of IZ01.
Maximum point search DC ENVE input.
Auto tracking restart condition
(SP:2-5V, LP/SLP:1.5-5V)
7 P7(2) END SENSOR IN Tape END sensor detect input. H: Tape end.
8 P7(1) START SENSOR IN Tape START sensor detect input. H: Tape start.
9 P7(0) POWER SAFETY IN Connect this port to 26V of FBT.
FBT protect port.
Detect voltage: 3V under
10 P6(7) AFT IN DC voltage that comes from the 10 pin of
DCT814B
11 P6(6) CAPSTAN I LIMIT OUT Limit the current of CAPSTAN MOTOR
Set "L" during PAUSE/STILL
12 P6(5) Not used
13 P6(4) QV SYNC When special play, Quasi Vertical SYNC insert
V SYNC of C.V.S
14 P6(3) REMOCON INPUT Remote Controller pulse input
15 P6(2) COLOR ROTARY OUT When color MOD/DEMOD, phase shift pulse
16 P6(1) HEAD AMP SW PULSE 4 head option. When special play,
EP head switching pulse
17 P6(0) COMPARATOR ENV 4 head option.
18 P5(7) V HEAD SW PULSE Video head switching pulse(SP head).
19 P5(6) A HEAD SW PULSE 6 head option. Not used
20 P5(5) REC H When recording, set "H"
21 P5(4) TRICK H When special play, set "H"
22 P5(3) CASSETTE DOWN H When cassette insert, light up IR led.
23 P5(2) CAPSTAN F/R Switching forward(H) and reverse(L) of
CAPSTAN MOTOR
24 P5(1) CRT ON L When CRT off, set "H" during 1sec.
25 P5(0) SOUND MUTE H When stand by TV/VCR, set speaker sound mute.
Z
Hold down
Special play:
QUE,REV,
STILL,SLOW
10
Page 12
IC DESCRIPTION
Pin Terminal Name Explanation Remarks
26 P4(7) AUDIO MUTE H Connect this port to 95 pin of ICY01.
When special play, set audio mute.
27 P4(6) Not used
28 P4(5) REC LED H Light up LED(RED) when recording
29 P4(4) TIMER REC LED H Light up LED(GREEN) when ready to
programming record.
30 P4(3) MONITOR ON H When CRT on, set "H".
31 P4(2) VCR ON H Recording when CRT off, set "H"
32 P4(1) RELAY ON H When CRT on, relay on during 1sec.
33 P4(0) Not used
34 RESET RESET(L) RESET
35 P3(1) Xcin It uses 32.768KHz Crystal.
36 P3(0) Xcout
35 pin is input terminal for crystal oscillator
36 pin is output terminal for crystal oscillator
37 Vcc Vcc
38 Xin Xin It uses 16MHz Crystal.
39 Xout Xout
40 Vss Vss GND Negative power supply.
41 P2(2) OSCin3 Not used
42 P2(1) OSCout3 Not used
43 CLK SELECT When MICOM to start, decide to 32.768KHz or 16MHz.
44 P2(0) OSCin2 It uses LC oscillator.
45 P1(7) OSCout2
46 NUB NUB GND
47 P1(6) LP H Not used
48 P1(5) FSC IN Not used
49 Vcc OSD Vss GND
50 P1(4) CVS IN Not used
51 P1(3) LECHA Not used
52 P1(2) Not used
53 Vcc OSD Vcc
Ever +5V(±0.5V). Positive power supply
38 pin is input terminal for crystal oscillator
39 pin is output terminal for crystal oscillator
Set "L" : 32.768KHz
Set the OSD position.
38 pin is input terminal for LC oscillator
39 pin is output terminal for LC oscillator
Ever +5V (±0.5V).
54 P1(1) FILTER Filter terminal for PLL.
55 P1(0) SLD FILTER Filter terminal for SYNC separate.
56 P0(7) C.V.S IN For Caption and Parental control signal detect.
57 NUA NUA GND
58 P0(6) H SYNC IN For OSD horizontal SYNC input
59 P0(5) V SYNC IN For OSD vertical SYNC input
11
Page 13
IC DESCRIPTION
Pin Terminal Name Explanation Remarks
60 P0(4) OSD BLANK OUT Fast blanking control signal.
Switch TV image signal and
Caption/OSD image signal.
61 P0(3) Not used
62 P0(2) OSD B OUT Blue output terminal of OSD image.
63 P0(1) OSD G OUT Green output terminal of OSD image.
64 P0(0) OSD R OUT Red output terminal of OSD image.
65 P10(7) S DATA IIC data I/O.
Control VCR Y/C, TUNER, EEPROM
66 P10(6) Not used
67 P10(5) S CLOCK IIC clock output
68 P10(4) CAP PG mon Not used
69 P10(3) DRUM PG mon Not used
70 P10(2) DRUM FG mon Not used
71 P10(1) M CLOCK IIC clock output
72 P10(0) M DATA IIC data I/O. Control CHROMA IC
73 P9(7) LD F/R Loading Motor Forward(L)/Reverse(H)
74 P9(6) LD ON When operate Loading Motor, set "H"
75 P9(5) PWM2 Not used
76 P9(4) CAPSTAN PWM Control rotate speed of Capstan Motor.
Period of PWM : 23.4KHz
77 P9(3) DRUM PWM Control rotate speed of Drum Motor. Period of PWM :
23.4KHz
78 P9(2) POWER FAIL Input "L", MICOM is Hold mode.
Backup time approx. 30minute.
79 P9(1) RLS IN Supply reel/Take up reel pulse input terminal.
80 P9(0) RLT IN
81 P8(7) CAM D CAM detection input terminal.
82 P8(6) CAM C
83 P8(5) CAM B
84 P8(4) CAM A
Use to check the Tape remain or
high speed rewind and fast forward.
MODE A B C D
EJECT L H H H
STAND BY L H L H
REV H H L H
STOP H H H L
PLAY H H H L
FF/REW H L H L
85 P8(3) Not used
86 P8(2) REC SAFETY SW L Recordable tape insert, "L" input.
If "H" input when insert cassette tape,
then automatic play.
87 CAP PG IN Capstan Pulse Generator signal input.
Feed back Capstan rotation speed.
88 Vss AMPVss GND
12
Page 14
IC DESCRIPTION
Pin Terminal Name Explanation Remarks
89 P8(1) DRUM FG IN Drum Frequency Generator signal input.
Feed back Drum rotation speed.
90 DRUM PG IN Drum Pulse Generator signal input.
Feed back Drum rotation phase.
91 AMP REF IN Control pulse AMP reference input terminal.
92 AMP REF OUT Control pulse AMP reference output terminal.
93 P8(0) C AMP filter.
94 CTL- Input control pulse when playing.
95 CTL+ Output control pulse when recording.
96 AMP C AMP condenser.
97 CTL AMP OUT Check Control pulse.
98 Vcc AMP Vcc
Ever +5V (±0.5V).
99 Vcc ANALOG Vcc
Ever +5V (±0.5V).
100 P11(1) KEY 0 IN REC, REW, PLAY, FF, STOP/EJECT
13
Page 15
IC DESCRIPTION
IC501
DCT814B(LA76814B) : IC VIDEO PROCESSOR
14
Page 16
ICY01
LA71550M : IC VCR Y/C & AUDIO PROCESSOR
IC DESCRIPTION
15
Page 17
IC DESCRIPTION
I801
POWER CONTROL MODULE
DPM 001 TI
KSE
1234561011121314
PIN NO DESCRIPTION PIN NO DESCRIPTION
1 GATE DRIVE1 10 +12V INPUT
2 OCP 11 POWER CONTROL
3 SOURCE 12 +26 OUTPUT
4 GND1 13 GND2
5 GATE 14 +133V INPUT
6 GATE DRIVE2
16
Page 18
TROUBLESHOOTING GUIDE
1. NO POWER
F801(125V 4A)
PWC01
R803R804
Q801
R805
Check
Check
Waveform
L802
Q801 DRAIN
Check
R802(10W 2.2)
F801 R802
L801
T801
B+
L803C805
R807
I801
#1
#3
#5
#10
#14
#11
133V
45V
10V
12V
D801
D820
D821
D822
D823
10V
133V
VCR ON H
FROM U-COM
#31 ON/OFF
Check
D801(PBS208GU)
C804
R820
C821
R110
C822
L823
C823 C829
C824
Check
Voltage
Check
Voltage
Q821
L824
TUNER 33V
H/D TRANS
45V
K1A7805
PQ05RF11
PQ12RF11
STATUS
STAND BY
VCR ON
CRT ON
TO I501 #34
OCP
C826
133V
DS01
ICS01 #31
VCR ON
BACKUP 5V
DS02
EVER 5V
VCR 5V
MOTOR 12V
SOUND 12V
L
H
H
Check
Voltage
Check
Voltage
Check
Voltage
Check
Voltage
ICS01 #30
POWER ON
L
L
H
ST- BY VCR ON
17
Page 19
TROUBLESHOOTING GUIDE
2. TV PART
2-1) NO PICTURE
Check the waveform of I501 #46
a
33V 5V
U102
TUNER
Check
Reset
#65 #67
VCC
#34
#37
#35 #36 #38 #39
ICS01
TIMER/SYSCON
NG : GO to the figure
OK : GO to the figure
a
b
Check
Voltage
Check
IF Vcc(5V)
IF OUT
Z101
SAW FILT
Check
Signal
SCLKSDATA
#10
#71
#72
MCLK
MDATA
AFT
#5 #6
#10
#12
#11
I501
#8
#46
#44
#3
#4
Check
Voltage
Z502
4.5M
TRAP
XCS01
Check
the X-TAL
b
Check
Vcc(9V)
Check
RGB Signal
Z502
CC527
#44
#18
#19
#20
#21
XS02
Check
Signal
I501
#43
#25
#13
Check
Signal
CHROMA Vcc(5V)
Check
ABL current
Check
Check
HOR. Vcc(5V)
T402
FBT
Check
Waveform
Check
200V LINE
D401
R403
Check
Heater Vp-p
6.2Vrms
18
Page 20
2-2) NO SOUND
TROUBLESHOOTING GUIDE
Check the waveform of I501 #1
c
33V 5V
TUNER
Check
Reset
#65 #67
#34
TIMER/SYSCON
#37
VCC
#35 #36 #38 #39
U102
SCLKSDATA
ICS01
Check
Voltage
IF OUT
Check
Signal
#10
#71
#72
MCLK
MDATA
AFT
NG : GO to the figure
OK : GO to the figure
Z101
SAW FILT
#5 #6
#10
I501
#12
#11
#8
#54
#52
#9
#3
c
d
Check
IF Vcc(5V)
Check
AGC Voltage
Check
FM filter
circuit
XCS01
Check
the X-TAL
d
SOUND
12V
R604
CC602
Check
Voltage
C605
Check
AUDIO Signal
XS02
Check
Signal
Check
SIF Signal
If SIF no signal,
then change I501
Check
AUDIO OUT
C606
#1
I601
TDA7267A
#4
Check
#2
Check
Earphone
#3
C604
QC601
ICS01 #25
SOUND MUTE
H:Mute,L:Normal
3W
8 OHM
Insert:
No Sound
Mute
19
Page 21
TROUBLESHOOTING GUIDE
2-3) CHANNEL DON’T STOP
Check the input signal conditions.
NG : Loss of signal or weak signal
OK : GO to the figure
e
e
Check
SDA/SCL
IS02
EEPROM
#8
VCC
Reset
VCC
33V 5V
U102
TUNER
#6
#5
#65 #67
SCLKSDATA
#34
#37
#35 #36 #38 #39
ICS01
TIMER/SYSCON
AGC IN
#10
#10
#71
#72
#56
IF OUT
CC116
Check
AGC Voltage
Check
Signal
MCLK
MDATA
Caption CVS
Check
Voltage
AFT
SAW FILT
#5 #6
#3
#10
#12
#11
#40
Z101
I501
#8
#48
#49
Check
IF Vcc(5V)
L110
VCO COIL
XCS01
Check
the X-TAL
XS02
Check Waveform
CVS 2Vp-p
20
Check
VCO COIL
Page 22
2-4) NO COLOR
TROUBLESHOOTING GUIDE
Check
CVS waveform
Check
the voltage
RGB Vcc(9V)
R/G/B signal
R OUT
G OUT
B OUT
Check
CC527
R504
R505
R506
R507
#44
#18
#19
#20
#21
Check
the voltage
Chroma/DEF Vcc
#43
L502
X501
3.58MHz
#38
I501
DCT814B
Check
the crystal
21
Page 23
TROUBLESHOOTING GUIDE
2-5) NO VERTICAL DEFLECTION
Check
the voltage
CC508
CC507
Check
the voltage
(2.5V)
5V
Check
vertical output
signal
#43
I501
DCT814B
#24 X501
V RAMP
ALC filter
#23
#38
RC301
L502 Chroma/DEF Vcc
3.58MHz
Vertical IC Vcc(26V)
Invert RAMP
#5
IN
#2
OUTPUT
Check
the crystal
D404
LA7841
From
FBT
#6
I301
VERTICAL
D.Y
22
Check
the waveform
If no output
then change I301
Page 24
2-6) NO ON-SCREEN DISPLAY
TROUBLESHOOTING GUIDE
Check
the signal
(15,734Hz)
Vcc(5V)
Check
the signal
(60Hz)
H.SYNC V.SYNC
#58 #59
#34RESET
ICS01
TIMER/SYSCON
#37
#35 #36 #38 #39 #44 #45
XCS01
32KHz
XS02 LS01
16MHz
#72
#71
#64
#63
#62
#60
Check
data/clock signal
MDATA
MCLK
OSD R
OSD G
OSD B
BLANK
#11
#12
I501
DCT814B
#14
#15
#16
#17
Check
OSD R/G/B/BLK
signal
Check
the crystal
Check
the waveform
23
If OSD does not operate,
then change the ICS01
Page 25
TROUBLESHOOTING GUIDE
2-7) REMOTE CONTROL DOES NOT OPERATE
Check
the voltage
Vcc(5V)
#34RESET
ICS01
TIMER/SYSCON
#37
#35 #36 #38 #39
XCS01
32KHz
XS02
16MHz
Check
the crystal
#100
#14
#1
KEY 1
KEY 0
RT01
Vcc(5V)
IT01
REMOCON
PREAMP
Check
the waveform
24
Page 26
3. VCR PART
3-1) NO LOADING
TROUBLESHOOTING GUIDE
Check the loading conditions (VHS TAPE)
f
#34RESET
TIMER/SYSCON
Vcc(5V)
#37
#35 #36 #38 #39
XCS01
32KHz
XS02
16MHz
ICS01
RS90
EJECT : GO to the figure
UNLOADING : GO to the figure
f
g
Check
waveform
#80
#79
#7
#8
TAKE UP
SENSOR
SUPPLY
SENSOR
SS03
SS04
Check
the voltage
RS91
Vcc(5V)
g
Vcc(5V)
Check
the crystal
#34RESET
TIMER/SYSCON
#37
#35 #36 #38 #39
XCS01
32KHz
XS02
16MHz
Check
the crystal
ICS01
END
SENSOR
SS02
START
SENSOR
SS01
DS03
IR LED
Check
voltage
#74
#73
#81
#82
#83
Loading ON
Loading F/R
LM(-)
OUT
#84
Check
voltage
Check
voltage
PAS03
CAM DATA
A/B/C/D See the IC description
ICS01 SYSCON part
IS02
#6
LOADING
DRIVE
(BA6209)
#5
#2 #10
Loading Motor
LM(+)
OUT
25
Page 27
TROUBLESHOOTING GUIDE
3-2) NO ROTATING
Vcc(5V)
Vcc(5V)
Vcc(5V)
Check
the crystal
Check the Rotating
h
#34RESET
#37
#98
#99
#35 #36 #38 #39
#58 #59
TIMER/SYSCON
XCS01
32KHz
ICS01
XS02
16MHz
#77
#90
#89
Check
the voltage
D-PWM
D-PG Pulse
D-FG Pulse
DRUM : GO to the figure
CAPSTAN : GO to the figure
Vcc(12V)
#1
PS01
#2
DRUM
CONNECTOR
#3 & #4
#6
Check
D-PG/FG waveform
If PG/FG no signal,
then change the DRUM.
h
i
RESET
Vcc(5V)
Vcc(5V)
Vcc(5V)
Check
the crystal
i
#58 #59
#34
#37
#98
#99
#35 #36 #38 #39
XCS01
32KHz
ICS01
TIMER/SYSCON
XS02
16MHz
the voltage
#76
#11
#87
CAP-FG waveform
Check
CAP-PWM
CAP-I-LIMIT
CAP-FG Pulse
Check
Vcc(12V)
Vcc(5V)
Vref(2.5V) #4
If CAP-FG no signal,
then change the CAPSTAN.
#7
#1
#5
CAPSTAN
CONNECTOR
#6
#3
PS02
26
Page 28
3-3) NO PICTURE PLAYBACK
TROUBLESHOOTING GUIDE
Check the waveform of ICY01 #27
j
Check
the voltage
Vcc(5V)
Vcc(5V)
Vcc(5V)
Check
SCL/SDA signal
SDATA
SCLK
#34RESET
#37
#98
#99
#65 #67
#13
ICS01
TIMER/
SYSCON
#20#18
NG : GO to the figure
OK : GO to the figure k
#6
Video Envelope
REC H
#39
#38
#35
#36
j
Check
the crystal
XS02
16MHz
XCS01
32KHz
Check
the crystal
C Vcc
CCD Vcc
SW Vcc
Check
the voltage
(5V)
#16 #17
#58
#56
ICY01
VCR Y/C
#39
#11Y Vcc
LA71550M
#4 #6 #9 #10
waveform
Check
QV SYNC
#14
Check
the waveform
(30Hz)
C-SYNC
Check
the waveform
PB RF
Check
the waveform
If PB RF no signal,
then change the IZ01.
VH SW Pulse
#4 #11 #6
#5#19
IZ01
PREAMP
LA70001
#7#1
#19 #17 #16
2HEAD DRUM
#13
Check
the voltage
Check
voltage
Vcc
(5V)
27
Page 29
TROUBLESHOOTING GUIDE
k
Check
the crystal
Check
the voltage
Check
SCL/SDA signal
C Vcc
CCD Vcc
SW Vcc
#58
#56
#39
#16 #17
Vcc(5V)
Vcc(5V)
Vcc(5V)
SDATA
SCLK
ICY01
VCR Y/C
LA71550M
#34RESET
#37
#98
#99
#65 #67
Check
the waveform
ICS01
TIMER/
SYSCON
Caption
CVS
CVS
#40
#42#27
#39
#38
#35
#36
#72#71#56
MDATA
CHROMA
DCT814B
MCLK
I501
MCL/MDA signal
#12 #11
#19
#20
XS02
16MHz
Check
the crystal
XCS01
32KHz
Check
R OUT
G OUT
Check
the voltage
(5V)
#11Y Vcc
#21
B OUT
Check
the waveform
See the 2-1) TV NO
If CVS no signal,
then change the IY01.
28
Page 30
3-4) NO COLOR PLAYBACK
TROUBLESHOOTING GUIDE
Check
the crystal
Check
the voltage
Check
SCL/SDA signal
C Vcc
CCD Vcc
SW Vcc
#58
#56
#39
Vcc(5V)
Vcc(5V)
Vcc(5V)
#16 #17
#34RESET
#37
#98
#99
SDATA
SCLK
the waveform
#13 #12
ICY01
VCR Y/C
LA71550M
#65 #67
Check
#52 #63
CCD
BLOCK
ICS01
TIMER/
SYSCON
the waveform
Caption
CVS
CVS
Check
#40
#42#27
#39
#38
#35
#36
#72#71#56
MDATA
MCLK
CHROMA
DCT814B
I501
MCL/MDA signal
#12 #11
#19
#20
XS02
16MHz
Check
the crystal
XCS01
32KHz
Check
R OUT
G OUT
Check
the voltage
(5V)
#11Y Vcc
Check
the crystal
#66 #67
XY01
3.58MHz
Check
the waveform
If CVS no signal,
then change the ICY01.
29
#21
See the 2-4) TV NO
COLOR
B OUT
Page 31
TROUBLESHOOTING GUIDE
3-5) NO SOUND PLAYBACK
Check
the crystal
Check
the voltage
Check
SCL/SDA signal
SW Vcc
#39
#16 #17
Vcc(5V)
Vcc(5V)
Vcc(5V)
SDATA
SCLK
#95
ICY01
VCR Y/C
LA71550M
#34RESET
#37
#98
#99
#65 #67
A.MUTE
#81
#26
AUDIO OUT
ICS01
TIMER/
SYSCON
Check
the voltage
H : QUE/REV/STILL
L : NORMAL PLAY
#71
#51
#39
#38
#35
#36
#72
MDATA
MCLK
I501
CHROMA
DCT814B
XS02
16MHz
Check
the crystal
XCS01
32KHz
Check
MCL/MDA signal
#12 #11
Check
the voltage
(5V)
#75A Vcc
AUDIO HEAD
CCU12
#90#86
#88
Check
#1
the waveform
AUTO
BIAS
QCU02
Invert PB H
from ICS01#20
REC H,PB L
If no signal,
then change the ICY01.
SOUND
AMP
See the 2-2) TV NO
SOUND
30
Page 32
3-6) NO RECORD PICTURE
TROUBLESHOOTING GUIDE
Check the waveform of ICY01 #40
CTL
m
Check
the voltage
SCL/SDA signal
HEAD
Vcc(5V)
Vcc(5V)
Vcc(5V)
Check
SDATA
SCLK
CTL(+)
CTL(-)
#34RESET
#37
#98
#99
#65 #67
C-rotary pulse
VH SW Pulse
#94 #95
#15 #20#18
waveform(30Hz)
ICS01
TIMER/
SYSCON
Check
NG : GO to the figure
Check
the waveform
(30Hz)
REC H
VH SW Pulse
2-1 (TV PART)
OK : GO to the figure m
the crystal
#39
#38
#35
#36
the crystal
Check
XS02
16MHz
XCS01
32KHz
Check
Check
voltage
C Vcc
CCD Vcc
SW Vcc
Check
the voltage
(5V)
#16 #17
#58
#56
#39
#11Y Vcc
#31 #32 #9 #10
Check
waveform
ICY01
VCR Y/C
LA71550M
If REC Y/C no signal,
then change the ICY01.
#99#97
C-SYNC
Check
the waveform
REC Y
#2 #10
REC C
#4 #11
#5#19
PREAMP
LA70001
#9#5
#19 #17 #16
IZ01
#13
Vcc
Check
Check
the waveform
Check
the waveform
2HEAD DRUM
If REC no signal,
then change the IZ01.
the voltage
(5V)
31
Page 33
TROUBLESHOOTING GUIDE
3-7) NO RECORD SOUND
Check the waveform of ICY01 #74
n
Check
the voltage
Vcc(5V)
Vcc(5V)
Vcc(5V)
Check
SCL/SDA signal
SDATA
SCLK
#34RESET
#37
#98
#99
#65 #67
A.MUTE
#26
ICS01
TIMER/
SYSCON
Check
the voltage
H : QUE/REV/STILL
L : NORMAL PLAY
NG : GO to the figure
OK : GO to the figure n
#39
#38
#35
#36
#72
#71
AUDIO
HEAD
2-2 (TV PART)
Check
the crystal
XS02
16MHz
Check
the crystal
XCS01
32KHz
AUDIO
ERASE
HEAD
FULL
ERASE
HEAD
SW Vcc
Check
the voltage
(5V)
#39
#75A Vcc
#16 #17
#95
ICY01
VCR Y/C
LA71550M
#83#81
#85
Check
the waveform
#86
AUTO
BIAS
#86
#88
70V
32
TU01
3 6
2
4
Invert REC H
from ICS01#20
REC H,PB L
Check
the waveform
70KHz
If SINE wave no signal,
then change TU01
Page 34
3-8) NO EXTERNAL VIDEO / AUDIO
TROUBLESHOOTING GUIDE
Check
the crystal
Check
the voltage
Check
SCL/SDA signal
SW Vcc
#39
Vcc(5V)
Vcc(5V)
Vcc(5V)
#16 #17
SDATA
SCLK
ICY01
VCR Y/C
LA71550M
#34RESET
#37
#98
#99
#65 #67
#27
CVS OUT
ICS01
TIMER/
SYSCON
#42
#39
#38
#35
#36
#72#71
MDATA
MCLK
I501
CHROMA
DCT814B
XS02
16MHz
Check
the crystal
XCS01
32KHz
Check
MCL/MDA signal
#12 #11
IF Vcc
Check
the voltage
(5V)
JP01
EXT INPUT
#75A Vcc
#36
#78
#81
AUDIO OUT
#2
Check
the voltage
(5V)
CVS
IN
Check
the waveform
Check
the waveform
AUDIO IN
33
Page 35
ELECTRICAL PARTS LIST
CAUTION
“I“ is safety component, so it must be used the same component.
r
DVQ-19H1FC
LOC PART CODE PART NAME DESCRITION
ZZ100 48B4139A02 TRANSMITTER REMOCON R-39A02
ZZ110 PTACPWJ690 ACCESSORY AS DVQ-20H1FC
20 486A716200 BATTERY AAAM 1.5V
40 485860710 MANUAL INSTRUCTION DVQ-14/20H1FC
M821 4858213800 BAG INSTRUCTION L.D.P.E T0.05X250X400
ZZ120 PTBCSHJ690 COVER BACK AS DVQ-20H1FC
M211 4852153100 COVER BACK FR HIPS BK
M541 4855415800 SPEC PLATE 150ART P/E FILM (C/TV)
M781 4857817610 CLOTH BLACK FELT 300X20X0.7
M782 4857817630 CLOTH BLACK FELT 400X20X0.7
M783 4857817621 CLOTH BLACK CLOTH T0.7 L=60
ZZ130 PTPKCPJ690 PACKING AS DVQ-20H1FC
M801 4858038300 BOX CARTON DW-3 2086
M801A 6520010100 STAPLE PIN 18M/M J D O
M811 4858189500 PAD EPS 20H1
M822 4858215000 BAG P.E FOAM LEX 0.5T*1200*1150
ZZ131 48519A5110 CRT GROUND NET 2001S-1015-1P
I
ZZ132 58G0000122 COIL DEGAUSSING DC-2030
CRT1 PTRTPWJ690 CRT AS NTSC 20"" ITC CRT AS
I
V01 58D0000083 COIL DY ODY-M2050
I
V02 2233030001 PAINT LOCK 3B-1401B
V03 2TC26019BE TAPE CLOTH 19X30 BEIGE
V04 2224050025 BOND SILICON RTV 122 TUBE
V05 4850PM001- MAGNET CP NY-225 (MINI NECK)
V06 48A96R004- RUBBER WEDGE HMR 28 SR (|0X54)
V901 48A96420N1 CRT BARE A48JLL40X(W)
M193 4851936800 BUTTON CTRL 4942001+5538301
M193A 7128301212 SCREW TAPPING T2S WAS 3X12 MFZN BK
M201A 4856013300 SCREW CRT FIXING 30X80 BK
M201B 4856013302 SCREW CRT FIXING 30X190 BK
M201C 4856215402 WASHER RUBBER CR T2.0
M211A 7122401611 SCREW TAPPING T2S TRS 4X16 MFZN
M281 4852817720 DOOR F/L ABS BK SILK
M481 4854854701 BUTTON POWER ABS BK
M671 4856723400 SPRING SWPB 0.4
M672 4856715600 SPRING SWPA PIE 0.4
M681 97P4602700 CLAMP CORD NYLON 66 BLK 5280N
ZZ200 PTFMSJJ690 MASK FRONT AS DVQ-20H1FC
LOC PART CODE PART NAME DESCRITION
M201 4852070100 MASK FRONT FR HIPS BK
ZZ202 PTSPPWJ690 SPEAKER AS DVQ-20H1FC
PA601 4850703S50 CONNECTOR YH025-03+35098+ULW=200
SP01 4858314310 SPEAKER SP-5070A01 3W 8 OHM
SP01A 4851935501 SPKR BRKT AS 3951901+3952500
SP01B 4856013600 SCREW SPKR FIX SWRM+SECC
ZZ290 PTMPMSJ690 PCB MAIN MANUAL AS DVQ-20H1FC
A001 4859812892 PCB MAIN 330X246 S1B
C101 CMXB1H103J C MYLAR 50V EU 0.01MF J (TP)
C102 CMXB1H333J C MYLAR 50V EU 0.033MF J (TP)
C105 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
C117 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C121 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
C301 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C302 CEXF1V101V C ELECTRO 35V RSS 100MF (8X11.5) TP
C303 CXSL2H100D C CERA 500V SL 10PF D (TAPPING)
C304 CMXB1H103J C MYLAR 50V EU 0.01MF J (TP)
C305 CMXB1H104J C MYLAR 50V EU 0.1MF J (TP)
C308 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C309 CMXL1H105J C MYLAR 50V MEU 1MF J
C310 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C401 CEYF2D101V C ELECTRO 200V RSS 100MF (16X31.5)
C402 CMYH3C622J C MYLAR 1.6KV BUP 6200PF J
C403 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C404 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP
C405 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C406 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C407 CEXF1C222V C ELECTRO 16V RSS 2200MF (13X25) TP
C408 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C409 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C410 CEXF1V471C C ELECTRO 35V RUS 470MF (10X20) TP
C411 CEXF1C100A C ELECTRO 16V RSM 10MF 5X7
C412 CCYB2H103K C CERA 500V B 0.01MF K
C413 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C415 CEXF2C109V C ELECTRO 160V RSS 1MF (6.3X11) TP
C416 CMYF2D624J C MYLAR 200V MPP 0.62MF J
C505 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C509 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
34
Page 36
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRITION
C512 CMXB1H333J C MYLAR 50V EU 0.033MF J (TP)
C518 CMXB1H473J C MYLAR 50V 0.047MF J (TP)
C525 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
C604 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
C605 CEXF1E331V C ELECTRO 25V RSS 330MF (10X12.5)TP
C606 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP
C801 CL1JB3474K C LINE ACROSS AC250V 0.47MF U/C/SNDF/SV
I
C802 CCXB2H222K C CERA 500V B 2200PF K (TAPPING)
I
C803 CCXB2H222K C CERA 500V B 2200PF K (TAPPING)
I
C804 CEYN2E221P C ELECTRO 250V LHS 220MF (22X30)
C805 CMYU3A472J C MYLAR 1KV BCP 4700PF J
C820 CCXB3D471K C CERA 2KV B 470PF K (TAPPING)
C821 CEYF2D101V C ELECTRO 200V RSS 100MF (16X31.5)
C822 CEXF2A100V C ELECTRO 100V RSS 10MF (6.3X11) TP
C823 CEXF1C102C C ELECTRO 16V RUS 1000MF (10X20) TP
C824 CEXE1E102E C ELECTRO 25V RM 1000MF (10X20) TP
C825 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C826 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C827 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
C828 CEXE1A222E C ELECTRO 10V RM 2200MF (10X20) TP
C829 CEXF1C222V C ELECTRO 16V RSS 2200MF (13X25) TP
C830 CEXF1C102C C ELECTRO 16V RUS 1000MF (10X20) TP
C831 CCXB3A471K C CERA 1KV B 470PF K (T)
C832 CCXB3A471K C CERA 1KV B 470PF K (T)
C833 CCXB3A471K C CERA 1KV B 470PF K (T)
C834 CMXB1H104J C MYLAR 50V EU 0.1MF J (TP)
C835 CEXF1C470A C ELECTRO 16V RSM 47MF (5X7) TP
C888 CH1BFE472M C CERA AC AC400V 4700PF M U/C/V
I
C901 CMXL2E104K C MYLAR 250V MEU 0.1MF K
C902 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
C965 CCYB3D102K C CERA 2KV B 1000PF K
CC103 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC104 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC106 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CC107 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC108 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC109 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC110 HCTAJ478MB C CHIP TANTAL 35V 0.47MF M 3216
CC111 HCTAJ108MB C CHIP TANTAL 35V 0.1MF M 3216
CC112 HCTAF229MB C CHIP TANTAL 16V 2.2MF M 3216
CC113 HCQK809DCA C CHIP CERA 50V CH 8PF D 2012
CC114 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC115 HCBK152KCA C CHIP CERA 50V X7R 1500PF K 2012
CC116 HCTAF229MB C CHIP TANTAL 16V 2.2MF M 3216
LOC PART CODE PART NAME DESCRITION
CC118 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC119 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC120 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC122 HCTAJ228MB C CHIP TANTAL 35V 0.22MF M 3216
CC123 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC130 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC131 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC501 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC502 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC503 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC506 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC507 HCTAJ228MB C CHIP TANTAL 35V 0.22MF M 3216
CC508 HCTAJ228MB C CHIP TANTAL 35V 0.22MF M 3216
CC510 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC511 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CC513 HCQK181JCA C CHIP CERA 50V CH 180PF J 2012
CC516 HCTAD100MB C CHIP TANTAL 10V 10MF M 3216
CC517 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CC519 HCTAJ478MB C CHIP TANTAL 35V 0.47MF M 3216
CC521 HCQK180JCA C CHIP CERA 50V CH 18PF J 2012
CC522 HCTAD100MB C CHIP TANTAL 10V 10MF M 3216
CC524 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC526 HCTAF229MB C CHIP TANTAL 16V 2.2MF M 3216
CC527 HCTAD100MB C CHIP TANTAL 10V 10MF M 3216
CC528 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CC529 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CC532 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CC551 HCQK221JCA C CHIP CERA 50V CH 220PF J 2012
CC553 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC601 HCBK153KCA C CHIP CERA 50V X7R 0.015MF K 2012
CC602 HCTAJ108MB C CHIP TANTAL 35V 0.1MF M 3216
CC603 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC836 HCTAD479MB C CHIP TANTAL 10V 4.7MF M 3216
CCS01 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS02 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS03 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS04 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCS05 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS06 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS07 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS08 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS09 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS10 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS11 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
35
Page 37
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRITION
CCS12 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS13 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS14 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CCS16 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS18 HCQK180JCA C CHIP CERA 50V CH 18PF J 2012
CCS19 HCQK180JCA C CHIP CERA 50V CH 18PF J 2012
CCS20 HCQK240JCA C CHIP CERA 50V CH 24PF J 2012
CCS21 HCQK240JCA C CHIP CERA 50V CH 24PF J 2012
CCS24 HCQK240JCA C CHIP CERA 50V CH 24PF J 2012
CCS25 HCQK240JCA C CHIP CERA 50V CH 24PF J 2012
CCS27 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS29 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS30 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CCS31 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CCS32 HCQK201JCA C CHIP CERA 50V CH 200PF J 2012
CCS34 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CCS35 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CCS36 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CCS37 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CCS38 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS40 HCBK223KCA C CHIP CERA 50V X7R 0.022MF K 2012
CCS41 HCBK223KCA C CHIP CERA 50V X7R 0.022MF K 2012
CCS42 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CCS43 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS44 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS45 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS46 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS47 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS48 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CCS49 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CCS50 HCBK102KCA C CHIP CERA 50V X7R 1000PF K 2012
CCS51 HCTBC470MB C CHIP TANTAL 6.3V 47MF M 3528
CCS52 HCTBC470MB C CHIP TANTAL 6.3V 47MF M 3528
CCS53 HCQK391JCA C CHIP CERA 50V CH 390PF J 2012
CCS54 HCQK391JCA C CHIP CERA 50V CH 390PF J 2012
CCS57 HCTAD100MB C CHIP TANTAL 10V 10MF M 3216
CCS59 HCTBC470MB C CHIP TANTAL 6.3V 47MF M 3528
CCS60 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS61 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS63 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS64 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCS70 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CCU01 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCU02 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
LOC PART CODE PART NAME DESCRITION
CCU04 HCTAD100MB C CHIP TANTAL 10V 10MF M 3216
CCU05 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCU06 HCTBC470MB C CHIP TANTAL 6.3V 47MF M 3528
CCU07 HCTAD100MB C CHIP TANTAL 10V 10MF M 3216
CCU09 HCBK153KCA C CHIP CERA 50V X7R 0.015MF K 2012
CCU10 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCU11 HCQK821JCA C CHIP CERA 50V CH 820PF J 2012
CCU12 HCTAD100MB C CHIP TANTAL 10V 10MF M 3216
CCU13 HCBK152KCA C CHIP CERA 50V X7R 1500PF K 2012
CCU19 HCTAD100MB C CHIP TANTAL 10V 10MF M 3216
CCU20 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCU21 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCU22 HCBK153KCA C CHIP CERA 50V X7R 0.015MF K 2012
CCU24 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCU25 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCU26 HCBK223KCA C CHIP CERA 50V X7R 0.022MF K 2012
CCY01 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY02 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY03 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CCY04 HCQK270JCA C CHIP CERA 50V CH 27PF J 2012
CCY05 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY06 HCBK473KCA C CHIP CERA 50V X7R 0.047MF K 2012
CCY07 HCQK390JCA C CHIP CERA 50V CH 39PF J 2012
CCY08 HCQK201JCA C CHIP CERA 50V CH 200PF J 2012
CCY09 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CCY10 HCTBC470MB C CHIP TANTAL 6.3V 47MF M 3528
CCY11 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCY12 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY13 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCY14 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CCY15 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CCY16 HCQK391JCA C CHIP CERA 50V CH 390PF J 2012
CCY17 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCY18 HCTAD100MB C CHIP TANTAL 10V 10MF M 3216
CCY19 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CCY20 HCTAD100MB C CHIP TANTAL 10V 10MF M 3216
CCY21 HCTAD100MB C CHIP TANTAL 10V 10MF M 3216
CCY22 HCTBC470MB C CHIP TANTAL 6.3V 47MF M 3528
CCY23 HCTBC470MB C CHIP TANTAL 6.3V 47MF M 3528
CCY24 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY25 HCTAD100MB C CHIP TANTAL 10V 10MF M 3216
CCY26 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY27 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CCY28 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
36
Page 38
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRITION
CCY29 HCTAD100MB C CHIP TANTAL 10V 10MF M 3216
CCY30 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CCY31 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCY32 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY33 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY34 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY35 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY36 HCTBC470MB C CHIP TANTAL 6.3V 47MF M 3528
CCY38 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY39 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY40 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CCY41 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY42 HCBK223KCA C CHIP CERA 50V X7R 0.022MF K 2012
CCY43 HCTAF339MB C CHIP TANTAL 16V 3.3MF M 3216
CCY44 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCY45 HCBK473KCA C CHIP CERA 50V X7R 0.047MF K 2012
CCY46 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CCY47 HCBK473KCA C CHIP CERA 50V X7R 0.047MF K 2012
CCY48 HCBK472KCA C CHIP CERA 50V X7R 4700PF K 2012
CCY49 HCQK330JCA C CHIP CERA 50V CH 33PF J 2012
CCY50 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY51 HCQK509DCA C CHIP CERA 50V CH 5PF D 2012
CCY52 HCQK100DCA C CHIP CERA 50V CH 10PF D 2012
CCY53 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCY54 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCZ02 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCZ03 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCZ04 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCZ05 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCZ07 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCZ08 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CCZ09 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCZ10 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CS15 CDYE0H104A C SUPER 5.5V 0.1F DA
CS17 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CS28 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CS33 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
CS39 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CS62 CEXF1E331V C ELECTRO 25V RSS 330MF (10X12.5)TP
CS65 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
CS66 CEXF1E331V C ELECTRO 25V RSS 330MF (10X12.5)TP
CT01 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
CU03 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CU14 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
LOC PART CODE PART NAME DESCRITION
CU15 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
CU16 CMXM2A333J C MYLAR 100V 0.033MF J (TP)
CU17 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
CU18 CMXM2A223J C MYLAR 100V 0.022MF J TP
CY37 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
CZ06 CEXF1C101A C ELECTRO 16V RSM 100MF (6.3X7) TP
D101 DUZ33B---- DIODE ZENER UZ-33B
D301 D1N4003--- DIODE 1N4003 (TAPPING)
D302 DUZ33B---- DIODE ZENER UZ-33B
D303 DUZ33B---- DIODE ZENER UZ-33B
D401 D1N4937G-- DIODE 1N4937G
D402 D1N4937G-- DIODE 1N4937G
D403 D1N4937G-- DIODE 1N4937G
D404 D1N4937G-- DIODE 1N4937G
D406 D1N4937G-- DIODE 1N4937G
D501 D1N4148--- DIODE 1N4148 (TAPPING)
D504 DUZ9R1BM-- DIODE ZENER UZ-9.1BM 9.1V
D551 D1N4148--- DIODE 1N4148 (TAPPING)
D552 D1N4148--- DIODE 1N4148 (TAPPING)
D553 D1N4148--- DIODE 1N4148 (TAPPING)
D801 DPBS208GUF DIODE BRIDGE PBS208GU-CA (FORMING)
I
D820 DRGP30J--- DIODE RGP30J
D821 D1N4937G-- DIODE 1N4937G
D822 DD2S4M---- DIODE D2S4M
D823 DD2S4M---- DIODE D2S4M
D824 DUZ9R1BM-- DIODE ZENER UZ-9.1BM 9.1V
D825 DRZ1175V1- DIODE RZ1175V1
D826 D1N4148--- DIODE 1N4148 (TAPPING)
D827 DUZ15BM--- DIODE ZENER UZ-15BM
D828 D1N4148--- DIODE 1N4148 (TAPPING)
D829 D1N4003--- DIODE 1N4003 (TAPPING)
DS01 D1N4003--- DIODE 1N4003 (TAPPING)
DS02 D1N4003--- DIODE 1N4003 (TAPPING)
DS03 DS15312H-- LED IR SI5312-H
DS03A 97P2339600 HOLDER IR ABS
DS04 DUZ6R2BM-- DIODE ZENER UZ-6.2BM 6.2V
DS05 DUZ5R1BM-- DIODE ZENER UZ-5.1BM
DS07 D1N4148--- DIODE 1N4148 (TAPPING)
DT01 DKLR114L-- LED KLR114L
DT02 DSR54MVW3- LED SPR54 MVW RED/GREEN
DT03 DUZ5R6BM-- DIODE ZENER UZ-5.6BM(TAPPING)
DT04 DUZ5R6BM-- DIODE ZENER UZ-5.6BM(TAPPING)
F801 5F1GB4021L FUSE GLASS TUBE UL/CSA TL 4A 125V MF51
I
F801A 4857415001 CLIP FUSE PFC5000-0702
37
Page 39
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRITION
F801B 4857415001 CLIP FUSE PFC5000-0702
I301 1LA7841--- IC VERTICAL LA7841
I301 PTB2SW7100 HEAT SINK ASS`Y 1LA7841--- + 7174300811
I301A 4857027100 HEAT SINK SPCC T1.0+SN
I301B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I501 1DCT814B-- IC CHROMA DCT814B
I601 1TDA7267A- IC AMP TDA7267A
I801 4850M04310 MODULE POWER DPM001T1
I
I803 PTX2SW6900 HEAT SINK ASS`Y 1K1A7805P1 + 7174301011
I803 1K1A7805P1 IC REGULATOR KIA7805PI
I803A 4857026900 HEAT SINK AL EX
I803B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I804 PTB2SW4617 HEAT SINK ASS`Y 1PQ05RF11/12 + 7174300811
I804 1PQ05RF11- IC REGULATOR PQ05RF11
I804A 4857024617 HEAT SINK AL EX
I804B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I805 1PQ12RF11- IC REGULATOR PQ12RF11
I805A 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I901 PTG1SW8902 HEAT SINK ASS`Y 1TDA6103Q- + 7174300811
I901 1TDA6103Q- IC VIDEO TDA6103Q
I901A 4857018902 HEAT SINK A1050P-H24
I901B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
ICS01 1DW760AA1Q IC CHIP MICOM DW37760MCA-AA1
ICY01 1LA71550-Q IC CHIP Y/C LA71550
IS02 1BA6209--- IC BA6209(ROHM)
IS03 1AT24C08PC IC AT24C08-10PC
IS04 1MN1380L-- IC COMPARATOR(RESET) MN1380-L(RESET IC)
IS05 1MN1280R-- IC MN1280R
IT01 1KRT30---- IC PREAMP KRT30
IZ01 1LA70001-- IC PREAMP LA70001 (2HD)
J001-J079 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J081-J099 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J103-J113 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J115-J188 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JG01-JG02 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JG04 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
JC01-JC02 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC04 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC05-JC09 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC10 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC11 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC12-JC13 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC14 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC15 HRFT000-CA R CHIP 1/10 0 OHM 2012
LOC PART CODE PART NAME DESCRITION
JC16-JC17 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC19-JC21 HRF8000-EA R CHIP 1/8 0 OHM 3216
JP01 4859109950 JACK PIN BOARD PH-JB-9710A
L101 5CPX560J-- COIL PEAKING 56UH J (RADIAL)
L102 58C5580019 COIL CHOKE TRF-9225 (0.55UH)
L103 5CPZ220K02 COIL PEAKING 22UH K (AXIAL 3.5MM)
L110 58N0000042 COIL VCO TRF-V008
L401 58C0000026 COIL BEAD HC-4035
L501 5CPZ220K02 COIL PEAKING 22UH K (AXIAL 3.5MM)
L502 5CPZ470K04 COIL PEAKING 47UH 10.5MM K (LAL04TB)
L503 5CPZ150K02 COIL PEAKING 15UH K (AXIAL 3.5MM)
L801 5PLF24A1-- FILTER LINE LF-24A1
I
L802 5MC0000100 COIL BEAD HC-3550
L803 5MC0000100 COIL BEAD HC-3550
L804 58Q0000093 COIL DELAY LINE RS208
L820 5MC0000100 COIL BEAD HC-3550
L821 5MC0000100 COIL BEAD HC-3550
L823 58CX430599 COIL CHOKE AZ-9004Y 940K TP
L824 58CX430599 COIL CHOKE AZ-9004Y 940K TP
LS01 5CPZ159M02 COIL PEAKING 1.5UH 3.5MM M (LAL02TB)
LS02 5CPZ220K02 COIL PEAKING 22UH K (AXIAL 3.5MM)
LS03 5CPZ220K02 COIL PEAKING 22UH K (AXIAL 3.5MM)
LU01 5CPZ220K02 COIL PEAKING 22UH K (AXIAL 3.5MM)
LU02 5CPX101J-- COIL PEAKING PL 100UH J (TAPPING)
LU03 5CPX103J-- COIL PEAKING 10MH 5MM J RADIAL
LY01 5CPZ220K02 COIL PEAKING 22UH K (AXIAL 3.5MM)
LY02 5CPZ560K02 COIL PEAKING 56UH K (AXIAL 3.5MM)
LY03 5CPZ220K02 COIL PEAKING 22UH K (AXIAL 3.5MM)
LY04 5CPZ220K02 COIL PEAKING 22UH K (AXIAL 3.5MM)
LY05 5CPZ220K02 COIL PEAKING 22UH K (AXIAL 3.5MM)
LZ01 5CPZ220K02 COIL PEAKING 22UH K (AXIAL 3.5MM)
M191 4851931700 DECK AS DRN-7203
M192 4851923500 SHIELD CASE AS DVN-14F7JA
M194 4851937000 SHIELD TOP AS 7246200+7246300
M231 97P2316600 HOLDER AC CORD NYLON66 UL/CSA
M351 4853535200 HOLDER LED FR HIPS BK
M381 4853817200 FRAME MAIN PCB FR HIPS BK
M381A 7122401611 SCREW TAPPING T2S TRS 4X16 MFZN
M381B 7128301212 SCREW TAPPING T2S WAS 3X12 MFZN BK
M381C 7121301212 SCREW TAPPING T2S PAN 3X12 MFZN BK
M381D 7122401612 SCREW TAPPING T2S TRS 4X16 MFZN BK
M682 4856814900 CLAMP WIRE NYLON 66
M683 4856812001 TIE CABLE NYLON66 DA100
P401 4859240020 CONN WAFER YFW500-05
38
Page 40
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRITION
P601 485923162S CONN WAFER YW025-03 (STICK)
P802A 4859242220 CONN WAFER YFW800-02
P803 4850701S06 CONNECTOR YFH800-01+YPT018+ULW=300
P804 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
PA501 4850708N08 CONNECTOR BIC-08T-25T+C-20T+ULW=400
PAS03 4850707V03 CONNECTOR 60-8283-3078-45+ULW=100
PAU01 4850706N07 CONNECTOR 60-8283-3068-45+USW=250
PS01 4859278120 CONN WAFER TKC-G06P-A1
PS02 4859278220 CONN WAFER TKC-G10P-A1
PS04 485923182S CONN WAFER YW025-05 (STICK)
PWC01 4859907910 CORD POWER AS ME301P+TER=1830
I
PZ01 4859245710 CONN HOUSING 00-8370-041-000-800
Q401 TKTC3207-- TR KTC3207 (TP)
Q402 PTA2SW7200 HEAT SINK ASS`Y T2SD2499-- + 7174301011
Q402 T2SD2499-- TR 2SD2499
Q402A 4857027200 HEAT SINK AL T1.0
Q402B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
Q402C 4856215201 WASHER SPCC
Q801 PTQ2SW4500 HEAT SINK ASS`Y T2SK2564-- + 7174300811
I
Q801 T2SK2564-- FET 2SK2564
Q801A 4857024500 HEAT SINK AL EX B/K
Q801B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
Q820 TKSA1013Y- TR KSA1013Y (TP)
Q821 TKSA1013Y- TR KSA1013Y (TP)
Q823 TKSA1013Y- TR KSA1013Y (TP)
QC501 T2SA1037KB TR CHIP 2SA1037AKT146-R
QC502 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC503 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC551 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC601 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC822 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC824 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC825 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC826 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QCS01 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QCS02 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QCS03 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QCT01 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QCT02 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QCT03 T2SA1037KB TR CHIP 2SA1037AKT146-R
QCU01 T2SA1037KB TR CHIP 2SA1037AKT146-R
QCU02 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QCU03 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QCY01 T2SC2412KB TR CHIP 2SC2412K-T146-BR
LOC PART CODE PART NAME DESCRITION
QCY02 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QCY03 T2SA1037KB TR CHIP 2SA1037AKT146-R
QCY04 T2SA1037KB TR CHIP 2SA1037AKT146-R
QU04 TKTC3202Y- TR KTC3202Y (TP)
QU05 TKTA1266Y- TR KTA1266Y (TP)
R110 RD-4Z392J- R CARBON FILM 1/4 3.9K OHM J
R302 RN01B331JS R METAL FILM 1W 330 OHM J SMALL
R305 RN01B471JS R METAL FILM 1W 470 OHM J SMALL
R306 RN01B561JS R METAL FILM 1W 560 OHM J SMALL
R307 RN01B129JS R METAL FILM 1W 1.2 OHM J SMALL
R308 RD-4Z273J- R CARBON FILM 1/4 27K OHM J
R312 RN-4Z1502F R METAL FILM 1/4 15K OHM F
R313 RN-4Z1603F R METAL FILM 1/4 160K OHM F
R401 RN02B101JS R METAL FILM 2W 100 OHM J SMALL
R402 RN01B229JS R METAL FILM 1W 2.2 OHM J SMALL
R403 RN01B479JS R METAL FILM 1W 4.7 OHM J SMALL
R404 RN01B229JS R METAL FILM 1W 2.2 OHM J SMALL
R409 RD-4Z472J- R CARBON FILM 1/4 4.7K OHM J
R410 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R414 RN01B562JS R METAL FILM 1W 5.6K OHM J SMALL
R415 RD-4Z100J- R CARBON FILM 1/4 10 OHM J
R417 RN02B101JS R METAL FILM 2W 100 OHM J SMALL
R503 RD-4Z824J- R CARBON FILM 1/4 820K OHM J
R504 RD-4Z121J- R CARBON FILM 1/4 120 OHM J
R505 RD-4Z201J- R CARBON FILM 1/4 200 OHM J
R506 RD-4Z201J- R CARBON FILM 1/4 200 OHM J
R507 RD-4Z201J- R CARBON FILM 1/4 200 OHM J
R511 RD-4Z151J- R CARBON FILM 1/4 150 OHM J
R533 RD-4Z103J- R CARBON FILM 1/4 10K OHM J
R604 RN02B339JS R METAL FILM 2W 3.3 OHM J SMALL
R605 RD-2Z331J- R CARBON FILM 1/2 330 OHM J
R801 DSVC471D14 VARISTOR SVC471D14A
I
R802 RX10B229JN R CEMENT 10W 2.2 OHM J BENCH 4P
I
R803 RD-4Z394J- R CARBON FILM 1/4 390K OHM J
R804 RD-4Z394J- R CARBON FILM 1/4 390K OHM J
R805 RD-4Z333J- R CARBON FILM 1/4 33K OHM J
R806 RD-4Z432J- R CARBON FILM 1/4 4.3K OHM J
R807 RF02Z228J- R FUSIBLE 2W 0.22 OHM J (TAPPING)
R816 DEC7R0M140 POSISTOR ECPAC7R0M140
I
R820 RS02Z828JS R M-OXIDE FILM 2W 0.82 OHM J SMALL
R821 RD-4Z363J- R CARBON FILM 1/4 36K OHM J
R826 RD-4Z100J- R CARBON FILM 1/4 10 OHM J
R827 RD-4Z472J- R CARBON FILM 1/4 4.7K OHM J
R831 RD-4Z472J- R CARBON FILM 1/4 4.7K OHM J
39
Page 41
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRITION
R833 RD-4Z472J- R CARBON FILM 1/4 4.7K OHM J
R836 RN01B124JS R METAL FILM 1W 120K OHM J SMALL
R889 RC-2Z565KP R CARBON COMP 1/2 5.6M OHM K
I
R902 RN01B152JS R METAL FILM 1W 1.5K OHM J SMALL
R903 RN01B152JS R METAL FILM 1W 1.5K OHM J SMALL
R904 RN01B152JS R METAL FILM 1W 1.5K OHM J SMALL
R905 RN01B124JS R METAL FILM 1W 120K OHM J SMALL
R906 RN01B124JS R METAL FILM 1W 120K OHM J SMALL
R907 RN01B124JS R METAL FILM 1W 120K OHM J SMALL
RC101 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC102 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RC103 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC104 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC105 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC106 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC107 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC108 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RC109 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC110 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC112 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC113 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC301 HRFT682JCA R CHIP 1/10 6.8K OHM J 2012
RC309 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC310 HRFT333JCA R CHIP 1/10 33K OHM J 2012
RC311 HRFT113JCA R CHIP 1/10 11K OHM J 2012
RC314 HRFT000-CA R CHIP 1/10 0 OHM 2012
RC405 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC406 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC407 HRFT433JCA R CHIP 1/10 43K OHM J 2012
RC408 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC411 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RC412 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC501 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC502 HRFT682JCA R CHIP 1/10 6.8K OHM J 2012
RC508 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC509 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RC510 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012
RC512 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC513 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RC514 HRFT472FCA R CHIP 1/10 4.7K OHM F 2012
RC515 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC517 HRFT123JCA R CHIP 1/10 12K OHM J 2012
RC518 HRFT123JCA R CHIP 1/10 12K OHM J 2012
RC519 HRFT102JCA R CHIP 1/10 1K OHM J 2012
LOC PART CODE PART NAME DESCRITION
RC520 HRFT390JCA R CHIP 1/10 39 OHM J 2012
RC521 HRFT914JCA R CHIP 1/10 910KOHM J 2012
RC522 HRFT511JCA R CHIP 1/10 510 OHM J 2012
RC523 HRFT511JCA R CHIP 1/10 510 OHM J 2012
RC524 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC527 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RC528 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RC529 HRFT822JCA R CHIP 1/10 8.2K OHM J 2012
RC530 HRFT362JCA R CHIP 1/10 3.6K OHM J 2012
RC531 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC532 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC534 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC541 HRFT205JCA R CHIP 1/10 2M OHM J 2012
RC542 HRFT564JCA R CHIP 1/10 560K OHM J 2012
RC551 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC552 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC553 HRFT910JCA R CHIP 1/10 91 OHM J 2012
RC601 HRFT622JCA R CHIP 1/10 6.2K OHM J 2012
RC602 HRFT242JCA R CHIP 1/10 2.4K OHM J 2012
RC603 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC607 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RC608 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC609 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC822 HRFT363JCA R CHIP 1/10 36K OHM J 2012
RC823 HRFT273JCA R CHIP 1/10 27K OHM J 2012
RC824 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RC825 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RC828 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC829 HRFT304JCA R CHIP 1/10 300K OHM J 2012
RC830 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RC832 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC834 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC835 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC837 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC908 HRFT202JCA R CHIP 1/10 2K OHM J 2012
RC909 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RC910 HRFT202JCA R CHIP 1/10 2K OHM J 2012
RC911 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RC912 HRFT202JCA R CHIP 1/10 2K OHM J 2012
RC913 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RCA01 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RCA02 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RCS01 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS02 HRFT103JCA R CHIP 1/10 10K OHM J 2012
40
Page 42
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRITION
RCS03 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS06 HRFT000-CA R CHIP 1/10 0 OHM 2012
RCS07 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS08 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RCS09 HRFT393JCA R CHIP 1/10 39K OHM J 2012
RCS10 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS11 HRFT154JCA R CHIP 1/10 150K OHM J 2012
RCS12 HRFT154JCA R CHIP 1/10 150K OHM J 2012
RCS14 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS15 HRFT362JCA R CHIP 1/10 3.6K OHM J 2012
RCS16 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RCS17 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS18 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS19 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS22 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS23 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS24 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS25 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS28 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RCS29 HRFT000-CA R CHIP 1/10 0 OHM 2012
RCS30 HRFT106JCA R CHIP 1/10 10M OHM J 2012
RCS31 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RCS32 HRFT105JCA R CHIP 1/10 1M OHM J 2012
RCS33 HRFT511JCA R CHIP 1/10 510 OHM J 2012
RCS35 HRFT751JCA R CHIP 1/10 750 OHM J 2012
RCS36 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RCS37 HRFT105JCA R CHIP 1/10 1M OHM J 2012
RCS38 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS39 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RCS40 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS46 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS47 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS48 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS49 HRFT392JCA R CHIP 1/10 3.9K OHM J 2012
RCS50 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS51 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS52 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RCS53 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RCS54 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS55 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS56 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RCS57 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RCS60 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS61 HRFT103JCA R CHIP 1/10 10K OHM J 2012
LOC PART CODE PART NAME DESCRITION
RCS62 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS63 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RCS64 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS65 HRFT273JCA R CHIP 1/10 27K OHM J 2012
RCS66 HRFT201JCA R CHIP 1/10 200 OHM J 2012
RCS67 HRFT273JCA R CHIP 1/10 27K OHM J 2012
RCS68 HRFT201JCA R CHIP 1/10 200 OHM J 2012
RCS69 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS70 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCS71 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS72 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS73 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS74 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS75 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS76 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS77 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS78 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RCS79 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RCS81 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012
RCS82 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012
RCS84 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RCS85 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RCS86 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCS87 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RCT02 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RCT03 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RCT04 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RCT05 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RCT06 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RCT08 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RCT09 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RCT11 HRFT911JCA R CHIP 1/10 910 OHM J 2012
RCT12 HRFT132JCA R CHIP 1/10 1.3K OHM J 2012
RCT13 HRFT202JCA R CHIP 1/10 2K OHM J 2012
RCT14 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RCT15 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RCT17 HRFT911JCA R CHIP 1/10 910 OHM J 2012
RCT18 HRFT132JCA R CHIP 1/10 1.3K OHM J 2012
RCT19 HRFT202JCA R CHIP 1/10 2K OHM J 2012
RCT20 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RCU01 HRFT683JCA R CHIP 1/10 68K OHM J 2012
RCU02 HRFT562JCA R CHIP 1/10 5.6K OHM J 2012
RCU03 HRFT105JCA R CHIP 1/10 1M OHM J 2012
RCU04 HRFT392JCA R CHIP 1/10 3.9K OHM J 2012
41
Page 43
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRITION
RCU07 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RCU08 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RCU09 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RCU10 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RCU11 HRFT273JCA R CHIP 1/10 27K OHM J 2012
RCU12 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RCU13 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RCU14 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCU15 HRFT512JCA R CHIP 1/10 5.1K OHM J 2012
RCU16 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCU19 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RCU20 HRFT229JCA R CHIP 1/10 2.2 OHM J 2012
RCU21 HRFT229JCA R CHIP 1/10 2.2 OHM J 2012
RCU22 HRFT334JCA R CHIP 1/10 330K OHM J 2012
RCU23 HRFT123JCA R CHIP 1/10 12K OHM J 2012
RCU24 HRFT221JCA R CHIP 1/10 220 OHM J 2012
RCU25 HRFT822JCA R CHIP 1/10 8.2K OHM J 2012
RCU26 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RCU27 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RCU28 HRFT512JCA R CHIP 1/10 5.1K OHM J 2012
RCU29 HRFT683JCA R CHIP 1/10 68K OHM J 2012
RCU30 HRFT512JCA R CHIP 1/10 5.1K OHM J 2012
RCV01 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RCV02 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RCY01 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RCY02 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RCY03 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RCY04 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RCY05 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RCY06 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RCY07 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RCY08 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCY11 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCY12 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCY13 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RCY14 HRFT511JCA R CHIP 1/10 510 OHM J 2012
RCY15 HRFT201JCA R CHIP 1/10 200 OHM J 2012
RCY16 HRFT201JCA R CHIP 1/10 200 OHM J 2012
RCY17 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012
RCY18 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCY19 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012
RCY20 HRFT822JCA R CHIP 1/10 8.2K OHM J 2012
RCY21 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012
RCY24 HRFT102JCA R CHIP 1/10 1K OHM J 2012
LOC PART CODE PART NAME DESCRITION
RCY25 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RCY26 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RCZ01 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RCZ02 HRFT183JCA R CHIP 1/10 18K OHM J 2012
RCZ03 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCZ04 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RCZ06 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RCZ09 HRFT220JCA R CHIP 1/10 22 OHM J 2012
RCZ10 HRFT751JCA R CHIP 1/10 750 OHM J 2012
RLY01 5SC0101338 SW RELAY DQ5D1-O(M)/GJ-SS-105LM
I
RS13 RD-4Z121J- R CARBON FILM 1/4 120 OHM J
RS26 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
RS27 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RS41 RD-4Z472J- R CARBON FILM 1/4 4.7K OHM J
RS42 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RS43 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RS44 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RS45 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RS58 RD-4Z471J- R CARBON FILM 1/4 470 OHM J
RS59 RD-4Z471J- R CARBON FILM 1/4 470 OHM J
RS83 RN02B339JS R METAL FILM 2W 3.3 OHM J SMALL
RS88 RD-4Z103J- R CARBON FILM 1/4 10K OHM J
RS90 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RS91 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RT01 RD-4Z240J- R CARBON FILM 1/4 24 OHM J
RT10 RD-4Z681J- R CARBON FILM 1/4 680 OHM J
RT16 RD-4Z681J- R CARBON FILM 1/4 680 OHM J
RU17 RD-4Z561J- R CARBON FILM 1/4 560 OHM J
RU18 RD-4Z470J- R CARBON FILM 1/4 47 OHM J
SCT01 4859303430 SOCKET CRT PCS633A
I
SS01 TST5811--- TR PHOTO ST-5811
SS01A 97P2343500 HOLDER TR ABS FR
SS02 TST5811--- TR PHOTO ST-5811
SS02A 97P2343500 HOLDER TR ABS FR
SS03 1SG239S--- IC SENSOR SG-239S
SS04 1SG239S--- IC SENSOR SG-239S
SWS01 5SN0101Z20 SW DETECT JDS1105-6X
SWT01 5S50101090 SW TACT SKHV17910A
SWT02 5S50202002 SW TACT KPT-2105A 2C-2P
SWT03 5S50202002 SW TACT KPT-2105A 2C-2P
SWT04 5S50101090 SW TACT SKHV17910A
SWT05 5S50101090 SW TACT SKHV17910A
SWT06 5S50101090 SW TACT SKHV17910A
SWT07 5S50101090 SW TACT SKHV17910A
42
Page 44
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRITION
SWT08 5S50101090 SW TACT SKHV17910A
T401 50D0000022 TRANS DRIVE HD-15D
T402 50H0000198 FBT FSA37012M
I
T802 50M3541T3- TRANS SMPS TSM-3541T3
I
TU01 5800000032 COIL OSC DE0-006
U102 4859719130 TUNER VARACTOR DT5-NF20F
I
r
OPTION PARTS LIST
LOC PART CODE PART NAME DESCRITION
X501 5XE3R5795C CRYSTAL QUARTZ HC-49/U 3.579545MHZ 20PPM
XCS01 HXA32R768C CRYSTAL CHIP QUARTZ 32.768KHZ 20PPM 8038
XS02 5XJ16R000E CRYSTAL QUARTZ HC-49S 16.000000MHZ 30PPM
XY01 5XE3R5795B CRYSTAL QUARTZ HC-49/U 3.579545MHZ 15PPM
Z101 5PTSF5221P FILTER SAW TSF5221P
Z102 5PXPS45MB- FILTER CERA TPS-4.5MB TRAP (TAPPING)
1. CN-071 13" / 19" DIFFERENT PARTS LIST
LOC PART NAME
0001 ANT ROD 4850A02510 S3BW216B (L=600 MM) X OPTION
0003 TRANS ANT MATCHING 4850A00250 IMT-06 X OPTION
C402 C MYLAR CMYH3C692J 1.6KV BUP 6900PF J CMYH3C622J 1.6KV BUP 6200PF J RETRACE
PA601 CONNECTOR 4850703S53 YH025-03+35098+ULW=500 4850703S50 YH025-03+35098+ULW=200
Q402A HEAT SINK X 4857027200 AL T1.0
Q402B SCREW TAPPTITE X 7174301011 TT2 RND 3X10 MFZN
Q402C WASHER X 4856215201 SPCC
R306 R METAL FILM RN01B471JS 1W 470 OHM J SMALL RN01B561JS 1W 560 OHM J SMALL V CENTER
R403 R METAL FILM RN01B369JS 1W 3.6 OHM J SMALL RN01B479JS 1W 4.7 OHM J SMALL HEATER
RC406 R CHIP HRFT113JCA 1/10 11K OHM J 2012 HRFT103JCA 1/10 10K OHM J 2012 X-RAY
RC502 R CHIP HRFT822JCA 1/10 8.2K OHM J 2012 HRFT682JCA 1/10 6.8K OHM J 2012 ABL
RC823 R CHIP HRFT363JCA 1/10 36K OHM J 2012 HRFT273JCA 1/10 27K OHM J 2012 OCP
V01 COIL DY 58D0000082 ODY-M1489 58D0000083 ODY-M2050
V901 CRT BARE 48A96414N1 A34JLL40X 48A96420N1 A48JLL40X(W)
ZZ131 CRT GROUND NET 48519A4710 1401S-1015-1P 48519A5110 2001S-1015-1P
ZZ132 COIL DEGAUSSING 58G0000078 DC-1400 58G0000122 DC-2030
PART CODE DESCRIPTION PART CODE DESCRIPTION
DVQ-13H1FC DVQ-19H1FC
REMARK
43
Page 45
EXPLODED VIEW
1. DVQ-19H2FC
44
Page 46
EXPLODED VIEW
2. DVQ-19H1FC
45
Page 47
3. DVQ-13H2FC
EXPLODED VIEW
46
Page 48
EXPLODED VIEW
4. DVQ-13H1FC
47
Page 49
DAEWOO ELECTRONICS CO., LTD
PRINTED DATE : JUNE 1999
686, AHYEON-DONG MAPO-GU
SEOUL, KOREA
C.P.O. BOX 8003 SEOUL, KOREA
TELEX : DWELEC K28177-8
CABLE : “DAEW OOELE C”
E-mail : G7F00E@web.dwe.co.kr
TEL : 82-2-360-8179
FAX : 82-2-360-8184
Loading...
