Daewoo DTS - 42 User Manual

PLASMA TELEVISION

USER MANUAL

DTS-42

Proper use guarantees

product life.

Before using the product, be advised
that you read this user manual well and
try to operate it.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol is lntended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric
shock to persons.

The symbol is intended to alert the user to the presence of important operating and
maintenance(servicing) instructions in the lierature accompanying the appliance.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.

CAUTION:

- TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

- THE STAND INTENDED FOR USE ONLY WITH THIS PDP TV. USE WITH OTHER APPARATUS IS
CAPABLE OF RESULTING IN INSTABILITY CAUSING POSSIBLE INJURY.

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a damp cloth.

7. Do not block any of the ventilation openings. Install in accordance with the
manufacturer's instructions.

8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus(including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding type plug. A
polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or
the third prong is provided for your safety. When the provided plug does not
fit into your outlet, consult an electrician for replacement of the obsolete
outlet.

10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.

11. Only use the attachments/accessories specified by the manufacturer.

12. Use only with a cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long
periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.

4

This User Manual presents safety precautions and how to use the product.
After reading it thoroughly, use the product safely.
Keep this manual where the user can see it easily.

Failure to comply with warnings and cautions for the safe use of electric
appliances may cause fire or human injury.

• 42” VGA wide Plasma Panel

•

Built in Analog Tuner

PDP has the analog tuner inside for watching terrestrial broadcasting without the need to purchase a
separate broadcasting receiver.

• DVD Direct Connection / Outstanding Picture Quality via a Digital
Broadcast Receiver

A DVD can be directly connected to the unit so that you can view clear digital images. You can enjoy even
higher quality images by connecting a digital broadcasting receiver with which digital broadcasts can be
viewed.

•A

PC Direct Connection

PC can be connected to the PDP without a separate device and can be used as a TV making it ideal for
presentation, various events and exhibitions.

•

160oWide-Angle Viewing Area

•

Flat Panel with No Distortion and Color Blurring

Since Plasma TV has no problems such as distortion, blurring, flickering unlike existing CRT type displays
you can enjoy Home Cinema picture quality and sound.

•

Various Control Functions

- 4 Languages OSD, 20 Step screen zoom function, Full-screen still function, Various aspect ratio,
Keypad lock fuction, Sleep timer, and so forth.

•

Free Volt (100-240V~, 50/60Hz)

•

DVI (Digital Visual Interface) Connection

When connected to a PC, you can receive DVI digital signals as well as the former analog signals by
using DVI input and D-Sub input. Furthermore, using the DVI Input, you can receive directly a digital
signal from the computer. Consequently, pictures on the screen are much more clear and fresh.

•

CCF(Capsulated Color Filter) Technology for natural color

CCF Technology makes the picture clearer by controlling of the brightness among three different color
filters.

•

MGDI (Meta Genuine Digital Image) Engine

MGDI is the image enhancement technology of Daewoo Electronics, which provides more clear, splendid,
and delicated images.

Features

Features

FCC RF INTERFERENCE ST

FCC RF INTERFERENCE STAA

TEMENT

TEMENT

NOTE :

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.

If this equipment does cause interference to radio or television reception
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures.

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.

- Consult authorized service centers for help.

- Only shielded interface cable should be used.

Finally, any changes or modifications to the equipment by the user not
expressly approved by the grantee or manufacturer could void the users
authority to operate such equipment,

Always obey all

safety messages.

•All the safety and
operating
instructions should
be read before the
product is operated.
If anything strange
happens, unplug
this product from
the wall outlet.

•Do not disassemble
or replace any parts
of the TV.
Refer to a qualified
service personnel
for repair.

Safety Precautions

6

W ARNING

You can be dead
or seriously
injured if you do
not follow
instructions.

During a lightning storm, or when it is left
unattended and unused for a long period
of time, unplug it from the wall outlet.

It can result in fire.

When unplugging your TV, always grip
plug firmly and pull straight out from the
receptacle.

It can result in fire or electric shock due to
damaged power cord.

This product must be properly grounded.

• Improper grounding may cause malfunction or
electric shock.

• When proper grounding is not possible, install
circuit breaker.

• Do not ground to gas pipe, water pipe, lightning
rod, or telephone line.

During a lightning storm, unplug the TV
from the wall outlet, and do not touch the
antenna.

It can cause fire or electric shock.

Power

Installation

Do not use this product in the
neighborhood of a bath or shower.

It can result in electric shock or fire.

Do not place this TV on an unstable cart,
stand, or table

It may cause the product and cart to overturn,
damaging equipment or causing possible injury.

7

Do not open the cover (or back)
because high voltage is present
within the TV enclosure.

It may cause electric shock.

Never push any kind of objects into
this product through openings at the
back of TV.

It may cause fire or electric shock.

The apparatus shall not be exposed to
dripping or splashing and that no objects
filled with liquids, such as vases, shall be
placed on the apparatus.

Spilled liquids may cause electric shock or
fire.

Do not allow children to play or hang
on the TV.

These actions may tip it over, causing
personal injury.

Do not place a candle or lighted
cigarette on the TV.

If these fall into the inside of the TV, it may
cause a fire or explosion.

Do not disassemble batteries, and
do not leave around in case children
swallow them.

Heavy metal may contaminate environment,
and can be harmful or detrimental to human
health. (If children swallow the batteries, go to
hospital and consult with a doctor.)
Batteries could explode if Fitted incorrectly.
Align the batteries according to the (+) and (-)
indication inside the case.

Do not spray water Onto the TV or
wipe with damp cloth.

It may cause an electric shock or fire.

Unplug the TV from the wall outlet
when smoke or a strange smell
occurs, then refer to a service
personnel.

Leaving the TV on in this condition, may
cause fire or electric shock.

During Use

8

Always obey all

safety messages.

• All the safety and
operating instructions
should be read before
the product is
operated.

Safety Precautions

Power

Installation

CAUTION

You can be injured,
or this product or
any other of your
property can be
damaged if you
don’t follow
instructions.

When moving your TV, remove the power
plug, antenna, and cables, and be sure to
move it by using two people..

Failure to follow this instruction can result in
electric shock or personal injury.

Do not touch the power plug with wet
hands when plugging or unplugging it
into the wall socket.

It can result in a risk of electric shock.

Do not install the product where it will be exposed to
the direct sunlight, and the product should not be
near heat sources such as radiators, stoves, etc.

It may cause malfunction.

Do not install the product where there is
oil, smog, moist, or dust

It may cause malfunction.

For proper ventilation, separate the product
from the wall, and keep a distance of more
than 10cm (4”).

Due to the increase of temperature inside the TV,
it may cause fire.

Minimum distances around the apparatus
for sufficient ventilation.

Due to the increase of temperature inside the TV,
it may cause fire.

If you wish to install this product on the
wall or ceiling, refer to a professional.

Failure to do so may cause damage to product
and injury to human.

When using an outside antenna system, do not
install it in the vicinity of overhead power lines.

If the antenna touches such power lines, it may
cause electric shock.

99

During Use

Do not wipe the TV using a cloth
damped with chemicals (benzene,
thinner, etc.).

TV appearance may be marred.
(Unplug the power plug and wipe with soft
cloth.)

Do not place any object or cover on
the TV.

In an event of improper ventilation, the TV
will be overheated causing fire.

Do not place heavy objects or heat
sources on the power cord.

It may damage the power cord, causing fire
or electric shock.

When watching the TV, the distance
between the TV screen and your eye
should be as 5~7 times as the
diagonal distance of the TV.

Watching the TV for a long time may hurt
your eye sight.

When cleaning of the inside of the
TV is required, consult to the
qualified service personnel.

When the TV is not cleaned for a long
period of time, dust in it may cause fire or
malfunction.

When the TV is placed on a cart or
table, the front side of the TV should
not project outward.

Unbalance may cause the TV to drop,
resulting in personal injury or equipment
malfunction and damage.

Do not grip speakers when moving
the TV attached with speakers.

When moving the TV while gripping
speakers, speakers may be fallen away
from the TV due to its weight, causing
personal injury.

Do not allow a still picture to be
displayed for an extended period, as
this can cause a permanent ghost
image to remain on the Wide Plasma
Television.

Examples of still pictures include logos,
video games, computer images, teletext
and images displayed in 4:3 mode.

Warranty does not cover any damage
caused by image retention.

The plasma television panel consists
of fine cells. Although the panels are
produced with more than 99.9
percent active cells, there may be
some cells that do not produce light
or remain lit.

10

VIDE

O/

DVD S

ATTV CATV

DISP

LAY

MU

LTIM

ED

IA

T

V/VIDEO

CH

CH

V
O

L

V
O

L

Z

O

O

M

+

Z

O

O

M

-

M

ENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

M

U

TE

C

APTIO

N

F.F/SLO

W

PLAYF.R

/SLOW

R

EC

S

TOP

PAU

SE

PR

EV

O

P

EN

/C

LO

SE

NEXT

PIC

TU

RE

MO

D

E

SO

UN

D

M

OD

E

STILL

P

O

W

E

R

M

T

S

A

D

D

/

E

R

A

S

E

S

L

E

E

P

Remote Control

1 UNIT

Component Cable

1UNIT

Coaxial Cable

1 UNIT

A/V Cable

2 UNITS

Note

Check to be sure that the following items are
packed with your Plasma panel.

Checking Accessories

Supplied Accessories

AC Cable 1 UNIT

Ferrite Core

2UNITS

Speaker(2 units)

Place the small ferrite
cores in the speaker
cables close to the
speaker terminals of
the PDP unit.

11

Note

The following items are optional accessories.
Refer purchasing optional accessories from

Daewoo Electronics Local retailer or the retailer
from where you purchased the unit.

Optional Accessories

Table Top Stand

Speakers

DTS-42SP

- Speaker Main Unit Dimension :
100(W) x 628(H) x 83(D) mm

39.37(W) x 24.72(H) x 3.27(D) inch

- Dimension Including Speaker Stand :
170(W) x 729(H) x 194(D) mm

6.69(W) x 28.7(H) x 7.64(D) inch

- Audio Amplifier : 10W + 10W

- Impedance : 8Ω

- Weight : 6.4kg(14.11 Lbs)

DTS-42ST

-

Dimension

: 667(W) x 212(H) x

320(D) mm

26.26(W) x 8.35(H) x

12.6(D) inch

- Weight : 7kg(15.43 Lbs)

Wall Mounting Unit

DSP/DP-HG10, DSP/DP-HG20,
DSP/DP-HG22

-

Variable Angles : 0o, 10o, 15o, 20

o

-

Dimension: 601(W) x 592(H) x 35(D) mm

23.66(W) x 23.31(H) x 1.9(D) inch

-

Weight

: 4.5kg(10 Lbs)

13

6 • Safety Precautions
10 • Checking Accessories
14 • Panel Controls
15 • Remote control
16 • Remote Control Setup

PREPARATION

CONNECTION

17 • Antenna Connection
20 • To Watch TV
22 • Channel Setup
28 • Watching Digital Broadcasts
30 • Watching Cable Broadcasts
32 • Watching Satellite Broadcasts
34 • Watching a DVD Image
36 • Watching a VCR Image
38 • Watching a Camcorder/Game Console Image
40 • Connecting PC(15Pin D-Sub)
42 • Connecting PC(DVI)

APPLICATION

MISC.

78 • Before Requesting Service
79 • SPECIFICATIONS

CONTENTS

45 • Selecting Picture Mode 61 •

MENU Background, Languages

46 • Customizing Picture

and Keypad Lock Settings

48 •

Adjusting Screen Size

63 •

MGDI (Meta Genuine

50 •

Adjusting Screen Size(PC, DVI)

Digital Image)
52 • Enlarging Screen Size 65 • Closed Caption Setting
54 • Watching a Still Image 67 • Time Setting
55 • Adjusting Auto Sound Mode 69 • Image Sticking
56 • Customizing Sound Mode Minimization(ISM)
58 • Selecting INPUT SIGNAL 71 • Parental Lock Setting
60 •

Checking the Current Input Signal

75 • Initialize Setting
77 • Setting Sleep Timer

Panel Controls

14

Front Panel, Back Panel, Remote Control

*

Items having same names on Plasma television and the remote control would function in exactly
the same way.

Front

Rear

ON/OFF

•

Power control sensor

•

Power Standby: Red - Standby

Green - ON

•

Power button

Select when adjusting volume or
select/adjust “MENU.”

Press when moving “MENU” or “Channel”

STAND BY/OPERATE

DVI-D INPUT ANT

Used when
manufacturing(For
manufacturer use
only)

PC INPUT(15 pin
D-sub)

DVI-D
INPUT

COMPONENT A/V jacks
(DTV/DVD INPUT jacks)

S-VIDEO,
A/V INPUT,
Cable
Receiver
INPUT
jacks

External
Speaker

Power

ANT

TV out

Right Speaker

Left Speaker

Position of

Ferrite Core

15

Remote Control

When Using Remote Control:

•

Be sure not to allow the Remote Control to drop or to become wet.

•

Keep it away from hot or moist locations.

Installing the Batteries in your Remote Control:

•

Push to open the cover of the remote controller

•

Set the batteries in the battery cell after checking the
electrode, and then shut the cover.

TV/VIDEO(DVD)/SAT/CATV

Use to select channel directly 0~9

Indicates the current state and resolution.

Use this function to make video input selection.

It changes in the following sequence

TV -> Video1 -> Video2 -> TV

Used to zoom the screen. To enlarge, press the(+)

button, and to return to the previous condition, press

the(-) button.(Zoom Mode : Zoom 0~20)

Used to display a desired menu.

Pressing the Power button of the TV allows
the Display to be standby. (Red light is
shown in the Remote Control Sensor.) At
this time, if you press the Power button of
the Remote Control, the Display is turned
ON (Green light in the Sensor).

Use it when selecting a channel number of
over 100

Use this function to make video input selection.
It changes in the following sequence PC -> DVI

-> Component 1-> Component 2 -> PC

Adjusts the size of the screen
(Normal, 16:9, etc.)

This feature allows you to choose the caption.

Display button

TV/VIDEO

ZOOM button

Menu button

Volume button / Adjusts the volume.

Screen Size button

Caption button

Power button

100

Channel number (0~9)

Multimedia

CH button

/ Adjusts the channel.

Note

• Use two “AAA” batteries.

• Be sure to use replacement batteries of the

same type as the original ones.

• The life of a battery depends on how much
it has been used.

*

The number in

()

indicates the page in which

the function of each button is explained in detail.

It returns to previous channel.

Previous Channel button

Mute sound.

Mute button

Every press of the button cycles through the

four different.

Normal -> Dynamic -> Cinema -> User.

Picture Mode button

This feature allows you to select the language and

stereo sound while broadcasting

MTS button

The feature either memorizes the current channel

or erases a channel that has previously

memorized.

CHANNEL ADD/ERASE

VIDEO/DVD Function

Used to view a still picture during watching
moving images.(Sound can be heard.)

Still button

Every press of the button cycles through the five different
modes: Normal -> Movie -> Music -> News -> User.

Sound Mode button

Each time you press this button, a different input mode
appears. The sequence is as follows: 15Min. -> 30Min. ->
60Min. -> 90Min. -> 120Min. -> OFF
After the time is selected, it automatically becomes stand­by state.

Sleep Timer button

20

58

65

48

54

55

77

21

60

58

52

22

20

57

24

45

V
O
L

DISPLAY

Z

P

R

E

MUTE


VIDEO/

DVD SATTV CATV

-

M

O

O

V

C

H

REC

PREV

OPEN/CLOSE

MODE

ADD/

MTS

ERASE

CH

MENU

CH

PLAYF.R/SLOW

STOP

SOUND

MODE

SLEEP

POWER

MULTIMEDIATV/VIDEO

Z

O

R

C

S

CAPTION

F.F/SLOW

PAUSE

NEXT

STILL

O

M

+

V
O
L

E

Z

I

S

N

E

E

16

Remote Control Setup

- The remote control provided is designed to operate the Daewoo PDP set.

- However, using the remote control, you can control the Cable Converter, VCR , DVD and Satellite Broadcasting
Receiver of other brands after setting up the remote control.

HOW TO SET UP THE REMOTE CONTROL FOR US ING OTHER DEVICES .

• Turn on the Device. (Cable Converter, VCR , DVD or Satellite Broadcasting Receiver)

• P ress the device selection button of remote control until it is flickering. It takes about 3 seconds.

• P ress the assigned three digits code of the device using number key button of the remote Control toward the

IR receiver of the device. The code number is provided below. Whenever pressing the number, the device
selection button will be flicked once.

• If the code is set properly, the device will turn off automatically. If not, repeat the process 3.

• As the device is turned off, press the flickering device selection button of the remote control once.

Then the lamp of the button will be turned off.

• Now, the setting-up of the device can be controlled by Daewoo PDP remote control.

Remote control supporting the multi brand devices.

Notices:

- All the preset codes are erased when replacing the battery. In this case, you must set the remote control again.

- S ome of the products may not be applied because of different signal system.

- This is only for the basic control of the devices.

Remote Control Setup Code

DAEWOO 004 012 014 017 068 069

094 096 097 098 102 103
104

JVC 018 037 039 048 052 054

059 064 111 130 132 206

MITSUBISHI 019 026 049 050 053 055

063 065 131 223

PANASONIC 070 074 078 086 114 125

224 225
PHILIPS 037 039 058 075 087
SAMSUNG 038 045 088 090 091 093

095 098 099 101 105 106

109 231
SHARP 037 058 129 221 228
SONY 003 016 037 056 060 061

062 080 081 082 129 214

DVD

DAEWOO 352 360
LG 350 368 369
PANASONIC 357 370
PHILIPS 355
SAMSUNG 351 363 364

DAEWOO 004
PANASONIC 066
PHILIPS 075
SAMSUNG 122 142

For more device codes, contact Daewoo
service center.

VCR (STANDARD : 004) SAT (STANDARD : 004)

Maker (Brand) Name Code Number (3 digit) List Maker (Brand) Name Code Number (3 digit) List

Antenna Connection

17

1. Connect the feeder cable of the antenna to the combining adapter.

2. Connect the combining adapter to the antenna input at the back of the TV set.

WHEN THE IMAGE IS NOT CLEAR

Unclear screen image and bad
reception may be a cause of wrong
antenna connection. Be sure to check
its direction and place when installing.

WHEN USING THE COMBINING ADAPTER

You may obtain the combining adapter
at your closest Service Center.

Antenna Input

Indoor Antenna Connection

CTV Antenna Connection

18

TV Antenna installation may be found in most.

When a coaxial cable is used

Plug the coaxial cable to the antenna socket, and fix it firmly.
It is recommended to use the provided coaxial cable.

When a feeder cable is used

ANT/CABLE 1

ANT/CABLE 1

Provided coaxial cable

19

Outdoor Antenna connection-such as VHF or/and UHF-may be necessary for installation at private

houses

Single Antenna Connection.

Separate Antenna Connection.

VHF Antenna

UHF Antenna

ANT/CABLE 1

ANT/CABLE 1

Outdoor Antenna Connection

To Watch TV

20

- The buttons on the keypad in the PDP unit, which have the same name as those on the remote controller,
perform the same function as the remote controller.

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O

L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

To Watch TV

Press the “ON/OFF” button of the
PDP unit.

•Power button of the remote control and the
keypad on the PDP unit would be operated
only when the "AC Power" of the PDP unit is
supplied. Otherwise, neither the remote
controller nor keypad of the PDP unit can
turn on the PDP.

To mute the sound

1. Press the “MUTE” button.

2. No sound is heard if “MUTE” is displayed

on the screen.

3. Sound is heard again if pressing the

“MUTE” button once again.
For example, you can use this button when
telephone rings or when guest comes while
watching TV.

Check of TV operation status

• If pressing the “DISPLAY” button, the status

of the Channel or broadcasting being
currently watched or entry status of video
component is displayed on the screen.

When pressing a Channel button

•Select two digits if using the number button
for Channel selection.
For example, to watch Channel No.9, press
the Nnmber buttons 0 and 9.
If pressing only number 9, it takes more time
than pressing two digits for selecting a
channel.

Auto Power Off

• If TV broadcast for the day is finished, the
TV will automatically turn off after about 30
minutes. However, if the Off-time or Sleep
time is operating, it takes precedence. This
Auto Power Off feature only operates in the
TV mode.

21

Press the “ON/OFF” button.

POWER

• Press the “ON/OFF” button of
the PDP set.

• The main power lamp turns on in
red color.

• Press the "POWER" button of
the remote control or any button
in the keypad of the main body.

• The LED of the PDP set turns on

in “green” color and the set turns
on.

Select Channel.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• Select the desired channel by
pressing the “

CH ” button or

the number button.

Ex) Channel 09

Adjust volume.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

•Sound reduces if pressing the
“

VOL” button.

• Sound increases if pressing the

“VOL

” button.

3

1

2

Press the “POWER” button to turn off the PDP set.

POWER

• TV turns off and he LED of
the PDP set changes to red
color.

4

ON/OFF

CH 09

MONO PM 12 : 00

No Ratings

10Volume

Channel Setup

22

VIDEO

/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V

O

L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

M

UTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

P

O

W

E

R

- This is the function for the TV to memorize the broadcasting channels. If the Auto Setup is done, you can simply
find out channels with “

CH ” buttons and so need not to select channels by pressing each channel number.

Automatic Channel Memory

Press the “Menu” button.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• The menu screen appears as
follows.

• Press the “

CH ” button until

coming on the channel.

• Press the “

VOL ” to enter the

sub menu.

Select the Channel Mode.

• Select the [Ch Mode] by
pressing the “

CH ” button.

• Select “Air” to watch the general
broadcasting, and select “Cable”
to watch the cable TV by using
the “

VOL ” button.

1

2

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E


Sound

Screen

Features

Channel

Move

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.

Select

Normal

Normal

MENU

32
48
32
32
32

Exit


Sound

Screen

Features

Channel

Move

Ch Mode
Channel
Memory
Fine Tune
Auto Search

Adjust

Air
42

Add

0

MENU

Exit

23

Select the [Auto Search].

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• Select the “Auto Search” with
the “

CH ” button.

Press the “VOL ” button.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• By pressing the “VOL ” button
automatically searches OnAir
Channel as in the right.

• On Air TV, searches from 2
channels through 69 channels,
and on Cable TV, searches from 1
channels through 125 channels.

• In this case, if pressing the menu
button, the automatic Channel
search is stopped and channels
searched by that time are saved.

Auto Search is completed.

• If auto search is completed, first
momorized channel appears on
the screen.

5

3

4

Check by pressing the “ CH ” button.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• You can search only the
memorized channels.

6

Ch Mode


Channel
Memory

Sound

Fine Tune
Auto Search

Screen

Features

Channel

Move

Adjust

Air
42

Add

0

MENU

Exit

Auto Searching Air 42

Please wait ...

MENU

Exit

CH 09

MONO PM 12 : 00

No Ratings

15%

CH 09

MONO PM 12 : 00

No Ratings

Additional

Channel Memory

•

This is method for
additionally memorizing
channels not
memorized due to weak
broadcasting signal.

•

This function is
available even in the
[Menu] - [Channel] ­[ADD/ERASE].

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Additional Channel Memory

Select the Channel to memorize.

• Select the Channel by pressing the
number button.
Ex) “13” channel

Press the “ADD/ERASE” button.

ADD/

ERASE

• “ADD/ERASE” character alternatively appears
whenever pressing this button.

• Add appears in green color and Erase appears in
red color.

• Add 13 channel by pressing the "ADD/ERASE"
button.

Check the Channel by pressing the “ CH ” button.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• “13” is selected by pressing the “ CH ” button.

3

1

2

24

Add

CH 13

CH 13

MONO PM 12 : 00

No Ratings

CH 13

MONO PM 12 : 00

No Ratings

25

Erase of Memorized

Channel

•

This is function to
erase unnecessary
memorized channel.

•

This function is
available even in the
[Menu] - [Channel] ­[ADD/ERASE].

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Select the Channel to erase.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• Select the Channel to erase with the
“

CH ” button.

• You may select the Channel by pressing

the number button.

Ex) “13” channel

Press the “ADD/ERASE” button.

ADD/

ERASE

• After selecting the channel to want to
erase, press the "ADD/ERASE"

• “ADD/ERASE” character alternatively
appears whenever pressing this button.

• If pressing the “ADD/ERASE” button,
the Channel number changes from
green color to red color.

1

2

Erase of Memorized Channel

Notices:

• The OSD menu disappears if commands are NOT received for 20 sec.

• Press menu button to exit from the OSD menu or to go to previous step.

• Available commands for each OSD menu are displayed in the lower parts of

the menu.

26

Fine Tune

- If you are unable to get a good picture or sound because of a poor signal reception, it is possible to adjust it with
the Fine Tune feature..

VIDEO

/

DVD SATTV CATV

DISPLAY

M

ULTIMEDIA

TV/VIDEO

CH

CH

V

O

L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

M

UTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


M

ODE

SOUND

MODE

STILL

P

O

W

E

R

M

TS

ADD/

ER

ASE

SLEEP

Select the [Channel] with the “Menu” button and the “ VOL ” button.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• Enter the sub menu of [Channel]
by pressing the “

VOL ”

button.

1


Sound

Screen

Features

Channel

Move

Ch Mode
Channel
Memory
Fine Tune
Auto Search

Select

Air
42

Add

0

MENU

Exit

27

Select “Air/Cable” in [Ch Mode].

• This function is used for
selecting “Air TV” and “Cable
TV”

• The screen is changed to “Air
TV” and “Cable TV” whenever
pressing the “

VOL ” button.

2

Select Fine T une

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• Select [Fine Tune] by using the
“

CH ” button.

• Until the screen becomes best

condition, adjust the screen by
pressing the “

VOL ” button.

3

Note:

Fine Tune

• If original TV signal input is not good, fine-tuning may not improve screen
condition.

• For different Ch mode(Air or Cable), the fine-tuning of each channel is set
independently. For example, fine-tuning Ch13(Air) does not affect ch13(Cable)
tuning set.

CH

-

M

O

O

Z

V

MENU

O
L

P

R

E

V

C

H

CH

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S

Ch Mode


Channel
Memory

Sound

Fine Tune
Auto Search

Screen

Features

Channel

Move

Adjust

Air
42

Add

0

MENU

Exit

Adjust

Air

42

Add

0

MENU

Exit


Sound

Screen

Features

Channel

Move

Ch Mode
Channel
Memory
Fine Tune
Auto Search

Watching Digital

Broadcasts

• To watch digital
broadcasts:

- Purchase a separate

digital Broadcasting
Receiver(SET-TOP
BOX)

- Connect the PDP to a

Digital Broadcasting
Receiver as shown
right.

28

Watching Digital Broadcasts

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Press the Power Buttons

• T urn the PDP and the Receiver ON.

2

POWER

Connect a Digital Broadcasting Receiver to the
PDP

• Prepare supplied A/V cables.

• Connect the cables from the Digital TV Receiver output terminal to the

PDP(Component 1, 2) input terminal.

• When connecting the cables, be sure to match the cable colors.

1

Video

Digital Broadcasting Receiver

(Set-T op Box)

Audio

29

Input Select

MULTIMEDIA

• Select [Component 1 or Component 2] by
pressing the “Multimedia” button of the
Remote Control or the "INPUT SELECT"
Key in KeyPad of the pdp set.

• Each time you press the “Multimedia”
button, different input modes appear. The
sequence is as follows:

Select a Desired Channel and Function

• Select a desired channel and function by
using the Remote Control of Digital
Broadcasting Receiver.

3

4

NOTES:

1) You can select input using [INPUT SELECT] button in the keypad of
the pdp set. The used sequence is as follows:
TV -> PC -> DVI -> Component1 -> Component2 -> Video1 -> Video2

2) Possible Digital Broadcasting signals: 1080i, 720p, 480p.

3) Antenna Connection:
Apartment : Check if community antenna receives digital broadcasts.
Private Houses: Set the indoor/outdoor UHF antenna to the direction
of the digital broadcasting transmitting company.

4) For detailed connection method, refer to the Owner’s Manual of Digital
Broadcasting Receiver.

5) What is a component? : Signals with which brightness and color are
separated, producing a sharp picture.

6) If the Digital Broadcasting Receiver has PC Output terminal or DVI
Output terminal, connect to ‘PC INPUT’ or ‘DVI INPUT’ at the back
panel of the PDP.
When watching the PDP by PC or DVI Input, some undesired signals
may be seen at the top and bottom area of the screen. In this case,
select [Menu] -->[Screen] -->[V. Size] to adjust.

Component1

DVI

PC

Component2

Watching Cable

Broadcasts

• To watch cable
broadcasts,
subscribe to your
local Cable TV
Broadcasting, and
then connect a cable
Broadcasting
Receiver TV to the
PDP as shown right.

Watching Cable Broadcasts

30

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O

L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Press the Power Buttons

• T urn the PDP and the Receiver ON.

2

POWER

Connect a Cable Broadcasting Receiver to the
PDP.

• Prepare the A/V cable.

• Connect the receiver(Output) to PDP(V ideo Input) as shown below .

• When connecting to an external AV source, be sure to match the colors.

1

Video/Audio

Cable Broadcasting Receiver

S-Video

31

Input Select

TV/VIDEO

• Select [Video 1 or Video 2] by pressing
the TV/VIDEO button of the Remote
Control or the "INPUT SELECT" Key in
KeyPad of the pdp set.

• Each time you press the “TV/VIDEO”
button, different input modes appear. The
sequence is as follows:

Select a Desired Channel and Function

• Select a desired channel and function by
using the Remote Control of the Cable
Broadcasting Receiver.

3

4

NOTES:

1)

If your local cable company re-transmits digital broadcasts,
you may watch normal broadcasts or digital broadcasts
simultaneously. For detailed information, refer to your local
cable company.

Video1 Video2

TV

Watching Satellite

Broadcasts

• To watch satellite
broadcasting,
subscribe to Digital
Satellite
Broadcasting, then
connect satellite
Broadcasting
Receiver to the PDP
as shown right.

Watching Satellite Broadcasts

32

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Press the Power Buttons

• T urn the PDP and the Receiver ON.

2

POWER

Connect a Satellite Broadcasting Receiver to
the PDP.

• Prepare the A/V cable.

• Connect the receiver(Output) to PDP(V ideo Input) as shown below .

• When connecting to an external AV source, be sure to match the colors.

1

Video/Audio

Satellite Broadcasting Receiver

S-Video

33

Input Select

TV/VIDEO

• Select [Video 1 or Video 2] by pressing
the TV/VIDEO button of the Remote
Control or the "INPUT SELECT" Key in
KeyPad of the pdp set.

• Each time you press “TV/VIDEO” button,
a different input mode appears.

The sequence is as follows:

Select a Desired Channel and Function

• Select a desired channel and function by
using the Remote Control of the Satellite
Broadcasting Receiver.

3

4

Video1 Video2

TV

Watching a DVD


• Component Input is
set to 480i and 480p
mode.

• Connect the cable
from the DVD Video
Output (Y, Pb/Cb,
Pr/Cr) to the
Component Input at
the back of PDP, and
connect the cable
from DVD Audio
output (Left, Right)
to the Audio Input at
the back of PDP.

Watching a DVD Image

34

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Press the Power Buttons

• T urn the PDP and the DVD ON.

2

POWER

Connect a DVD Player to the PDP.

• Prepare the AV cable.

• Connect the DVD(Output) to the PDP(Component or V ideo Input) as shown below .

• When connecting to an external AV source, be sure to match the colors.

1

Video

DVD DVD

Video/
Audio

S-

Video

Audio

35

Input Select

MULTIMEDIA

• Select [Component 1 or Component 2,
Video1, Video2] by pressing the
“MULTIMEDIA” or “TV/VIDEO” button of
the Remote Control or the "INPUT
SELECT" Key in KeyPad of the PDP set.

• Each time you press the “MULTIMEDIA” or
“TV/VIDEO” button, a different input mode

appears. The sequence is as follows:

Select a Desired Title and Function

• Select a desired title and function by
using the Remote Control of the DVD.

3

4

NOTES:

1) Y/Cb/Cr, which stands for DVD Player’s Output Terminal, can
also be written as Y/B-Y/R-Y, Y/Pb/Pr depending on the kinds
of DVD devices.

2) The way of connecting the DVD to the PDP is as follows:

Y <--->Y Cb <---> Pb, B-Y, Cr <---> Pr, R-Y

3) The DVD output can be Video, S-Video and/or Component
Video depending on the DVD devices. There are various
output modes, so be sure to check when you purchase it.

4) When connecting S-Video and Video simultaneously, only S­Video will be displayed on the screen.

TV/VIDEO

Component1

DVI

PC

Component2

Video1 Video2

TV

•“

MULTIMEDIA button

•“

TV/VIDEO button

Watching a
VCR Image

• Video can use either
the video terminal or
the S-video terminal.

Watching a VCR Image

36

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Press the Power Buttons

• T urn the PDP and the VCR ON.

2

POWER

Connect a VCR to the PDP.

• Prepare the AV cable.

• Connect the Video(Output) to PDP(Video Input) as shown below.

1

S-Video

VCR

Video/Audio

37

Input Select

TV/VIDEO

• Select [Video 1 or Video 2] by pressing
the “TV/VIDEO” button of Remote
Control or the "INPUT SELECT" Key
in KeyPad of the pdp set.

• Each time you press the “TV/VIDEO”
button, a different input mode appears.
The sequence is as follows:

Select a Desired Title and Function

• Select a desired title and function by
using the Remote Control of the
VCR.

3

4

NOTES:

1) When connecting a Video, the S-Video terminal provides a
better image than the Video terminal.

2) When connecting to the Video terminal, connect 3 color AV
cables (video, left audio, right audio) to the PDP; for the S­Video terminal, connect the Audio terminal (Left, Right) in the
same way, and connect the S-Video cable (sold separately).

3) When connecting the Video terminal and the S-Video
simultaneously, the S-Video terminal is selected. This can be
checked by the “DISPLAY” button of the Remote Control.

Video1 Video2

TV

Watching a

Camcorder/Game

Console Image

• Enjoy images
recorded by
camcorder or the
game console after
connecting to the
PDP.

W atching a Camcorder/Game Console Image

38

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Press the Power Buttons

• Turn the PDP and the
Camcorder/Game Console ON.

2

Connect a Camcorder/Game Console to the
PDP.

• Prepare the AV cable.

• Connect the Video(Output) to the PDP(Video Input) as shown below.

• When connecting to an external AV source, be sure to match the colors.

1

Video/Audio

Game Console/Camcorder

S-Video

39

Input Select

TV/VIDEO

• Select [Video 1 or Video 2] by pressing
the “TV/VIDEO” button of the Remote
Control or the "INPUT SELECT" Key in
KeyPad of the pdp set.

• Each time you press the “TV/VIDEO”
button, a different input mode appears.
The sequence is as follows:

Select Function

• Select the Function by using the
Remote Control of Camcorder or
Game Console.

3

4

NOTES:

1) When connecting a Video, the S-Video terminal provides a
better image than the Video terminal.

2) When connecting to the Video terminal, connect 3 color AV
cables (video, left audio, right audio) to the PDP; for the S­Video terminal, connect the Audio terminal (Left, Right) in the
same way, and connect the S-Video cable(sold separately).

3) When connecting a component, refer to “Watching a DVD
Image” on page 34-35.

Video1 Video2

TV

Connecting PC

• This product
supports resolution
of VGA, SVGA,
XGA, and SXGA.

• Before connecting
a PC to the PDP,
be sure to adjust
the resolution of
PC.

Connecting PC(15pin D-sub)

40

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Connect the PC to the PDP.

• Prepare the PC cable (D-sub 15pin) and
the PC audio cable(Sold separately).

• Connect the PC(Output) to the
PDP(Input) as shown below.

2

Before connecting to the PDP, set the
resolution of the PC.

• Go to SETUP-CONTROL PANEL-DISPLAY PROPERTIES in Window Screen
of the PC.

• Choose the SETTINGS tab in the DISPLAY Menu.

•

In the SETTINGS Menu, select 640 x 480 or 800 x 600.

1

15 PIN D-subAudio

PC

41

Input Select

MULTIMEDIA

• Select [PC] by pressing the “MULTIMEDIA”
button of the Remote Control or PDP unit.

• Each time you press the “MULTIMEDIA”
button, a different input mode appears. The
sequence is as follows:

Enjoy Dynamic Ultra Screen TV by
Using PC’s Keyboard or Mouse.

4

5

Press the Power Buttons.

• Turn on the PDP and the PC.

3

NOTES:

1) The resolution of the PC TV is best at 640 x 480 (VGA).

2) If there is a [Vertical Frequency]setting menu in the [Display]
Menu of the PC, adjust the frequency to 60Hz.

3) If the PC resolution is too high, it may be hard to read letters.
Select a suitable resolution.

Component1 Component2

DVI

PC

Connecting PC

• This product
supports resolution
of VGA, SVGA,
XGA, SXGA.

• Before connecting a
PC to the PDP, be
sure to adjust the
resolution of PC.

• This product is
supported by Plug
and Play only at DVI.

Connecting PC(DVI)

42

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Connect the PC to the PDP.

• Prepare the DVI cable and the PC audio
cable(Sold separately).

• Connect the PC(Output) to the
PDP(Input) as shown below.

2

Before connecting to the PDP, set the
resolution of the PC.

• Go to SETUP-CONTROL PANEL-DISPLAY PROPERTIES in Window Screen
of the PC.

• Choose the SETTINGS tab in the DISPLAY Menu.

• In the SETTINGS Menu,

select 640 x 480 or 800 x 600.

1

DVI-D INPUT

DVIAudio

PC

43

Input Select

MULTIMEDIA

• Select [DVI] by pressing the
“MULTIMEDIA” button of the Remote

Control or PDP unit.

• Each time you press the “MULTIMEDIA”
button, a different input mode appears. The
sequence is as follows:

Enjoy Dynamic Ultra Screen TV by
Using PC’s Keyboard or Mouse.

4

5

Press the Power Buttons.

• Turn on the PDP and the PC.

3

NOTES:

1) The resolution of the PC monitor is best at 640 x 480 (VGA).

2) If there is a [Vertical Frequency]setting menu in the [Display]
Menu of the PC, adjust the frequency to 60Hz.

3) If the PC resolution is too high, it may be hard to read letters.
Select a suitable resolution.

4) DVI input port receives only Digital Signal.

5) Depending on the graphic card when plug & unplug the DVI

connection the screen may not display correctly.
Restart the computer if this happens.

Component1

PC

Component2

DVI

44

PC and DVI Input Resolution Available in PDP

• Depending on graphic card, problems like no signal detected or line noises can happen. If these
problems happen, contact the graphic card company for help.

Resolution H Freq. (KHz) V Freq. (Hz) Remark DVI PC

37.861

31.469

37.861

37.500

43.269

31.469

37.927

35.156

37.879

48.077

46.875

53.674

48.363

56.476

60.023

68.677

67.500

60.000

640x400

640x480

720x400

800x600

1024x768

1152x864

1280x960

85.080

59.940

72.809

75.000

85.061

70.087

85.039

56.250

60.317

72.188

75.000

85.061

60.004

70.069

75.029

84.997

75.000

60.000

VESA

DOS
VESA
VESA
VESA

IBM
VESA
VESA
VESA
VESA
VESA
VESA
VESA

HP&VESA

VESA
VESA
VESA
VESA

O
O
O
O
O

O
O
O
O
O
O
O
O

O
O

O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O

Selecting Picture

Mode

• Select the Picture mode
that is appropriately set
depending on the kinds
of pictures, and enjoy
them.

Selecting Picture Mode


MODE

• Press the [PICTURE MODE] on the
Remote Control.

• While pressing the [PICTURE MODE] for
the first time, the current PICTURE MODE
will be displayed.

Each Press of the Button Will Select
One of Four Picture Modes.

• Each time you press the button, a
different Picture mode appears. The
sequence used is as follows:

* Normal : For a highly defined image in a normally bright

room

* Dynamic: For a clear-cut image emphasizing high contrast

for sports viewing
* Cinema: For a movie
* User: Allows the user to customise settings as desired.

Menu on the Screen will disappear .

• After selecting a desired Picture mode, the
menu on the screen will disappear.

• Normal, Dynamic, and Cinema Modes are
factory preset values.

If you want to customise the Picture modes,
refer to the following page.

3

1

2

Selecting Picture Mode

45

NOTES:

1) Normal, Dynamic, and Cinema Modes are factory preset values.

2) When adjusting sub-menus while you are in Normal, Dynamic,
and Cinema Modes, the Picture Mode will be automatically
converted to User Mode, and the adjustments will be made.

3) Selecting [Initialise] in the [Features], Menu will allow the
Brightness, Contrast, etc. to return to the factory preset values.


MODE

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Normal Dynamic

Cinema User

Customizing


• You can adjust the
color tone and
brightness to your
preference.

Customizing Picture

46

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Press the “ CH ” Button.

• After selecting [Picture] by by pressing “ CH ” button,
press the “ VOL”button. Then the sub menu of

[Picture] will be displayed.

Select the User Mode.

• Select [User] by pressing the “ VOL”button.

3

Press the MENU Button.

• The MENU shown below will display on the screen.

1

2

CH

-

M

O

O

Z

V

MENU

O
L

P

R

E

V

C

H

CH

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S

V
O
L

P

CH

-

M

O

O

Z

MENU

R

E

V

C

H

CH

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S

CH

-

M

O

O

Z

V

MENU

O
L

P

R

E

V

C

H

CH

Z

O

O

M

+

V
O

L

E

Z

I

S

N

E

E

R

C

S


Sound

Screen

Features

Channel

Features

Channel

Move


Sound

Screen

Features

Channel

Move

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.


Sound

Screen

Move

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.

Select

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.

Adjust

Adjust

Normal

Normal

User

Normal

MENU

MENU

Exit

Normal

Normal

Exit

32
48
32
32
32

MENU

32
48
32
32
32

Exit

30
60
40
32
48

Select User Mode Adjustments

Picture Condition Adjustments

• Press the “ VOL”buttons to adjust the picture at your
preference.

4

5

47

• While you are in [Picture Mode – User], press the “ CH ”
buttons to select a specific adjustment item.

NOTES:

1) While you are in the PC or DVI INPUT mode, you can only
adjust brightness, contrast, sharpness and color temperature.

2) When you adjust Brightness, Contrast, Color and Tint in DTV
mode or adjust Brightness and Contrast in PC or DVI mode,
the picture is adjusted finely.

3) The Tint control is used when the input signal is NTSC If input
signal is NTSC, Tint control is displayed in picture menu.

4) Selecting the Color Temperature makes the mood normal,
warm or cold.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

Adjust

User

Normal

MENU

30
60
40
32
48

Exit


Sound

Screen

Features

Channel

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.

Move

Mode


Brightness
Contrast

Sound

Color
Tint

Screen

Sharpness

Features

Color Temp.

User

30
60
40
32
48

Normal

Channel

MENU

Move

Select

Exit

Adjusting

Screen Size

• You can adjust
screen size or
aspect ratio as
desired.

Adjusting Screen Size

48

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Press the “SCREEN SIZE” Button.

• Each time you press the “SCREEN SIZE” button on the Remote
Control, a different “SCREEN SIZE” appears. The sequence
used is as follows:

• The current screen size will be displayed on the screen.

1

S

C

R

E

E

N

S

I

Z

E

Panorama

Enlarge LB

16:9 4:3

Enlarge LBS

NOTES:

1) When the INPUT SIGNAL is DTV [in Component 1 or
Component 2], only the aspect ratios of 16:9 and 4:3 are
available.

2) Displaying a picture in a 4:3 mode for a long time may cause
phosphor of the PDP to be burned. So avoid displaying a
picture in 4:3 screen size for a long time.

3) 16:9 : Theater-like 16:9 picture formats
4:3 : 4:3 picture formats like an Analog TV.
Enlarge LB : Enlarges the screen as to fill the black part of

up and down.

Enlarge LBS: Enlarges the screen, and shifts up as to see

the subtitles in case you are watching video
with subtitles.

Panorama : 16:9 picture formats with panorama effect.

4) If the picture shows unclear image in the 480p component
input source, try to toggle the resolution from the [MENU]­[Screen]-[DTV/DVD]. This menu appears only when the input
signal is component 480p.

49

Press the MENU Button.

• Press the [MENU] button on the Remote Control.

Select [Screen].

• Press the Channel “ CH ” button to select
[Screen].

Select the [Screen Size].

• Enter the sub menu by pressing “ VOL”button.

• Press the V olume “ VOL”buttons to select [Screen Size].

3

1

2

Adjusting from

MENU Screen

• Available Screen Mode

Input Available Mode
DVI H, V Size
PC H, V Size and

Position, Phase,

Frequency
Video 16:9,
Component 4:3,
(480i) Enlarge LB,

Enlarge LBS,

Panorama
Component 16:9
(480p or 4:3

above)

CH

-

M

O

O

Z

V

MENU

O
L

P

R

E

V

C

H

S

CH

Z

O

O

M

+

V

O

L

E

Z

I

S

N

E

E

R

C

CH

-

M

O

O

Z

V

MENU

O
L

P

R

E

V

C

H

CH

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S


Sound

Screen

Features

Channel

Move

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.


Sound

Screen

Select

Mode

Normal

Normal

MENU

Exit

16 : 9

32
48
32
32
32

V
O
L

CH

-

M

O

O

Z

MENU

P

R

E

V

C

H

CH

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S


Sound

Screen

Features

Channel

Move

Features

Channel

Mode

Move

Adjust

Select

16:9

MENU

Exit

MENU

Exit

Adjusting Screen
Position and Size

• You can adjust the
screen position and
size as desired.

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Press the MENU Button.

• The MENU screen as shown below will appear.

Press the “ CH ” button.

• Press the “ CH ” button to select [Screen].

1

2

50

Adjusting Screen Size(PC, DVI)

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E


Sound

Screen

Features

Channel

Move

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.

Select

Normal

Normal

MENU

32
48
32
32
32

Exit

Features


Sound

Screen

Channel

Move

H. Size
V. Size
H. Position
V. Position
Phase
Frequency

Select

MENU

32
32
32
32
32
32

Exit

51

Press the V olume “ VOL

”

button.

• Press the Volume “ VOL”button to enter the sub menu
of [Screen].

• While you are in [Screen] mode, press the “ CH ”
button to select a desired item, and then, adjust the

value by pressing the “ VOL”.

3

NOTES:

1) Horizontal/Vertical size and position values can be adjusted only in the
[PC] input mode and in the [DVI] input mode, only Horizontal/Vertical size
are available.

2) H. Size: As the value increases, the screen width increases

3) V. Size: As the value increases, the screen height increases.

4) H. Position: As the value increases, the screen moves to the right.

5) V. Position: As the value increases, the screen mores up.

6) Phase: When there is jitter or blurring of the image, adjust this value.

7) Frequency: When there is jitter or blurring of the image, adjust this value.

8) In case of DVI, only H and V size can be adjusted.

9) Using Screen Size button on the remote control, you can control the H
and V size directly in PC or DVI mode.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MENU

32
32
32
32
32
32

Exit


Sound

Screen

Features

Channel

Move

H. Size
V. Size
H. Position
V. Position
Phase
Frequency

Adjust

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Press the “ZOOM+” Button.

• Press the “ZOOM+” button to show currently selected
screen size.

• Each time you press the “ZOOM+” button, the screen size
will increase stepwise in 0 ~ 20 scale.

• To reduce the screen size, press the “ZOOM-” button.

1

52

Enlarging

Screen Size

• You can view
enlarged size of the
screen with this
function

Enlarging Screen Size

Zoom 0

Z

O

O

M

+

Z

O

O

M

-

Zoom 0

Zoom 5

Zoom 10

Zoom 15

Zoom 20

Move the Screen Position.

• While you are in the ‘Zoom’ mode, press the “ CH ” and
“ VOL” buttons to move screen stepwise up/down and

left/right, respectively .

2

53

NOTES:

1) When the screen is enlarged, the pixel of the screen can
become thick and dim.

2) When only subtitle of zoom level remains, you can scroll the
image.
If subtitle of zoom level disappears, press zoom key, and
scroll the image.

Zoom 6

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Press the “STILL” Button.

• If you wish to freeze a picture, press the “STILL” button.
Y ou can still hear the sound.

• Press “STILL” button to cancel the “STILL” function.

• To view the enlarged images, press the “ZOOM+” button.

1

STILL

54

Watching a

Still Image

• You can view still
images with this
function. However,
displaying the same
images such as still
images for a long
time may cause
image sticking.

Watching a STILL Image

NOTES:

1) Displaying the same images such as still images for a long
time may cause image sticking (after-image lagging).

2) In this case, such “image sticking” may become less
noticeable if moving images are later displayed for a long
time.

3) However, an image sticking may become a permanent one,
damaging the Plasma Display; therefore, avoid displaying
the same images for a long time.

4) Use the function [ISM], while displaying still images for a long

period of time to minimize this effect.

Still

Zoom 7

Move the Screen Position.

• While you are in still mode, press the “
CH ” and “ VOL”button to move

screen stepwise up/down and left/right.

2

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

Adjusting Auto

Sound Mode

• Enjoy various sound
modes by selecting
your favorite Sound
Mode depending on
the kinds of moving
pictures.

Adjusting Auto Sound Mode

55

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Select "SOUND MODE".

SOUND

MODE

• Press the "SOUND MODE" on the
Remote Control.

• Current sound mode will be
displayed.

Every Press of the Button Changes Modes.

SOUND

MODE

• Each time you press the button, a
different sound mode appears.

The sequence used is as follows:

* Normal : Suitable for watching any motion picture
* Movie : Select this mode to simulate being at a movie theater
* Music : Ideal for listening to music
* News : Allows human voice to be heard more clearly
* User : Allows the user to adjust as desired.

MENU will Disappear .

• After selecting a desired sound mode, on­screen menu will disappear in about 2~3
seconds.

• Normal, Movie, Music and News Modes
are factory preset values.

If you want to customize the sound modes
at your preference, refer to the following
page.

3

1

2

Normal Movie

Music UserNews

Customizing

Sound Mode

• This feature allows
the user to adjust at
his preference.

Customizing Sound Mode

56

Press the “ CH ” button.

• Select [Sound] by pressing the “ CH ” button, then
press the “ VOL”button to display the following.

Select SOUND BALANCE.

• Select Sound [Balance] by the “ VOL” button,
then adjust it.

• Sound Balance Function adjusts sound balance of left and
right speaker.

3

Press the MENU Button.

• The MENU Screen as below will be displayed.

1

2

POWER

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

V
O
L

P

-

M

O

O

Z

R

E

V

C

H

MUTE

REC

PREV


MODE

MTS

OPEN/CLOSE

ADD/

ERASE

MENU

CH

PLAYF.R/SLOW

STOP

SOUND

MODE

SLEEP

Z

O

E

R

C

S

CAPTION

F.F/SLOW

PAUSE

NEXT

STILL

O

M

+

V
O
L

E

Z

I

S

N

E

CH

-

M

O

O

Z

V

MENU

O
L

P

R

E

V

C

H

CH

-

M

O

O

Z

V
O
L

P

R

E

V

C

H

CH

-

M

O

O

Z

V

MENU

O
L

P

R

E

V

C

H

CH

Z

O

O

M

+

V

O

L

E

Z

I

S

N

E

E

R

C

S

CH

MENU

CH

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S


Sound

Screen

Features

Channel

Features

Channel


Sound

Screen

Move

Features

Channel

Move

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.


Sound

Screen

Move

Balance
Effect
MTS
AVC
Mode
120Hz
500Hz

1.5kHz
5kHz
10kHz

Select

Balance
Effect
MTS
AVC
Mode
120Hz
500Hz

1.5kHz
5kHz
10kHz

Adjust

Normal

Normal

Select

Normal

MENU

Off

Mono

Off

MENU

Exit

Off

Mono

Off

Normal

Exit

32
48
32
32
32

MENU

0

0
0
0
0
0

Exit

0

0
0
0
0
0

Select the Effect Mode.

• Select [Effect] by pressing the “ CH ” buttons, then
select ON/OFF by pressing the “ VOL”button.

• [Effect]: Used to emphasize stereo ef fect.

Select the Sound Mode.

4

5

57

• Select the Sound Mode by pressing the “ CH ” button,
then adjust it by pressing the “ VOL”button.

* Normal : Suitable for watching any motion picture
* Movie : Select this mode to simulate being at a movie

theater
* Music : Suitable for listening to music
* News : Allows human voice to be heard more clearly
* User : Allows the user to adjust as desired.

NOTES:

1) User Mode : Used as an Equalizer with which the user can adjust the sound frequency as desired.

2) If you modify the sound frequency in auto Sound Mode (News, Movie, Music, etc.), it is automatically switched to the User Mode.

3) For the realistic sound effect, lower than 120Hz frequency sound and greater than 10kHz frequency sound are emphasized.

4) If you make connection to the Left Audio Input as input is MONO you can hear from both speakers.

5) AVC function : This function adjusts volume to the set level automatically. However, depend on the sources, it may have different
volume level because the sound sources have their own initially set up levels.

6) MTS function can control the sound output according to the current state of sound.

Pressing “DISPLAY” button displays current state of sound in the OSD located upper right comer of the screen.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

Normal Movie

Music UserNews

MTS Function

If a channel is
received in two
languages(dual
language) and stereo,
you can switch to
MONO, STEREO or
SAP by the MTS
menu or pressing the
MTS button of the
remote control
repeatedly.

MONO

MONO sends the
mono sound to the

loudspeakers.

STEREO

STEREO sends the
stereo sound to the

loudspeakers.

SAP

SAP sends the
secondary broadcaste
language to the
loudspeakers.


Sound

Screen

Features

Channel


Sound

Screen

Features

Channel

Move

Move

Balance
Effect
MTS
AVC
Mode
120Hz
500Hz

1.5kHz
5kHz
10kHz

Balance
Effect
MTS
AVC
Mode
120Hz
500Hz

1.5kHz
5kHz
10kHz

Adjust

Adjust

Off

Mono

Off

Normal

Off

Mono

Off

Normal

MENU

MENU

Exit

Exit

0

0
0
0
0
0

0

0
0
0
0
0

Selecting INPUT SIGNAL

58

Press the INPUT SELECT Button.

MULTIMEDIA

TV/VIDEO

• Press the “TV/VIDEO” and “MULTIMEDIA” button on the
Remote Control or the PDP Display to select desired
input signal.

• Each time you press the “TV/VIDEO” or “MULTIMEDIA”

button, a different screen mode appears. The sequence used is
as follows:

1

VID

E

O

/

D

VD

SA

T

TV C

A

TV

D

IS

P

LA

Y

M

U

LTIM

ED

IA

TV/V

ID

E

O

C

H

C

H

V

O

L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

M

EN

U

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

M

U

TE

C

A

P

TIO

N

F.F /S

LO

W

P

LA

Y

F.R

/SLO

W

R

EC

STO

P

P

A

U

SE

P

R

E

V

O

P

EN

/C

LO

S

E

N

EX

T

PIC

TU

R

E

M

O

D

E

S

O

U

N

D

M

O

D

E

S

TILL

POWER

MTS

ADD/

ERASE

INPUT SIGNAL

• Used to select
INPUT signal of
external device
connected to the
PDP.

59

NOTES:

1) If an external device is not connected or INPUT signal is not
applied, Warning Message (“No Signal”) would be displayed.

2) In this case, check if external device is connected and/or
terminal connection is properly done.

3) Also, you can select input using [INPUT SELECT] button in

the keypad of the pdp set.
The used sequence is as follows:
TV -> PC -> DVI -> Component1 -> Component2 -> Video1

-> Video2

Component 1

1920 x 1080

Component1

PC

DVI

Component2

Video1 Video2

TV

•“

MULTIMEDIA” button

•“

TV/VIDEO” button

Checking the

Current Input Signal

• Used to check the
INPUT signal mode,
resolution,
frequency(video
only), etc. of the
current screen.

Checking the Current Input Signal

60

Press the “DISPLAY” Button.

DISPLAY

• Press the “DISPLA Y” button on the Remote Control.

1

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Component 1

1920 x 1080

1. If you watch Component, PC or DVI :

Displays which input terminal is used, and indicates the input signal mode.
Indicates the horizontal and vertical resolution of the current INPUT signal.

Component 1

1920 x 1080

2. If you watch TV:

Displays the Channel Mode and its number.

Indicates the current sound state and time.

Ch Mode Ch No.

MONO/STEREO/

SAP/st. SAP Time

3. If you watch VCR image:

Displays which input terminal is used, and indicates the signal mode.
Indicates the mode and frequency of the current INPUT signal.

Video 1

NTSC 60 Hz

NOTES:

1) DAEWOO PLASMA can receive NTSC, PAL, SECAM, etc.

2) “1920 x 1080” displayed in the INPUT signal is not the
resolution of the TV. The displayed resolution is sent by Digital
Broadcastion Receiver.

Menu Background

and Language

Settings

• Used to select
transparent of
MENU background
and language used
in MENU.

Press the MENU Button.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• The MENU screen will be displayed as below .

Press the “ CH ” Button.

• Select [Features] by Pressing the
“ CH ” button.

Select the menu Background.

• Select the MENU [Background] by pressing the “ VOL ”
button.

• Every press of the “ VOL ” button while you are in
the[Background] would switch between Transparent and
Opaque.

3

1

2

MENU Background, Language and Key pad Lock Settings

6161

CH

-

M

O

O

Z

V
O

L

P

R

E

V

C

H

MENU

CH

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S

Select

Normal

Normal

MENU

32
48
32
32
32

Exit


Sound

Screen

Features

Channel

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.

Move

Select

Opaque
English

Off
On
Off

MENU

Exit


Sound

Screen

Features

Channel

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

Move

CH

-

M

O

O

Z

V

MENU

O

L

P

R

E

V

C

H

CH

Z

O

O

M

+

V

O

L

E

Z

I

S

N

E

E

R

C

S

Features

Channel


Sound

Screen

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

Move

Adjust

Opaque

English

Off
On
Off

MENU

Exit

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

MENU Background, Language and Key pad Lock Settings

Select LANGUAGE by using the “ CH ” Button.

• Select LANGUAGE by using the “ CH ” button.

• Every press of the

“ VOL ”

button while you are in the
[LANGUAGE] mode would cycle through the different
languages.

Keypad Lock Setting

• Select [Keypad Lock] by the “ CH ” buttons, then
press the

“ VOL ”

button to set Keypad Lock ON.

4

5

62

Keypad Lock

1) If Keypad Lock is set to On, pdp can be turned on only using the
remote controller.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

NOTES:

*

When Power is turned ON first time, ‘SELECT
LANGUAGE’ Mode will be displayed, then, select a

desired language by using

“ VOL ”

button. (Displayed

only once)

Adjust

Opaque
English

Off
On
Off

MENU

Exit


Sound

Screen

Features

Channel

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

Move


Sound

Screen

Features

Channel

Move

Adjust

Opaque
English

Off
On
Off

MENU

Exit

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

63

MGDI

Demo

• When [MGDI] is set to
Demo mode, Half of
screen is [MGDI] ON
and the other half is
[MGDI] OFF.

• As [MGDI] is off, the
sharpness of the
Picture mode cannot
be controlled.

Press the MENU Button.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• The MENU screen will be displayed as below .

Select Features

• Select [Features] by the “ CH ” button.

MGDI Setting

• Enter the sub Menu by using the “VOL ”button.

• Select the [MGDI] by pressing the

“ CH ”

button.

• You can select [MGDI] On, Off, and Demo mode by using
the

“ VOL ”

button.

3

1

2

MGDI (Meta Genuine Digital Image)

*

MGDI Demo Mode

MGDI MGDI
ON OFF

MGDI is the image enhancement technology of Daewoo Electronics, which provides more clear,

splendid, and delicated images.

CH

-

M

O

O

Z

V
O

L

P

R

E

V

C

H

MENU

CH

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S

Select

Normal

Normal

MENU

32
48
32
32
32

Exit


Sound

Screen

Features

Channel

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.

Move

Select

Opaque
English

Off
On
Off

MENU

Exit


Sound

Screen

Features

Channel

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

Move

CH

-

M

O

O

Z

V

MENU

O
L

P

R

E

V

C

H

CH

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S


Sound

Screen

Features

Channel

Move

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

Adjust

Opaque

English

Off
On
Off

MENU

Exit

POWER/STANDBY

Indicator

Front panel LED lights

• When the AC power
is on : Green.

• When the AC power
is in the standby
mode : Red.

64

Auto Power Setting

Auto Power Setting

• Select the [Auto Power] by pressing the “ CH ” button

from [Features].

• You can select [Auto Power] ON and OFF mode by using
the

“ VOL ”

button.

4

Auto Power

1) ON : When the AC power is ON, the TV will by turned on
automatically without pressing the power button on the remote
control.

2) OFF : When the AC power is ON, the TV will by turned on by

pressing the power button on the remote control or the keypad
of front panel.

AC POWER ON

PDP SET ON

Automatically

AC POWER ON

PDP SET ON

With the remote control or
the keypad of front panel.

STANDBY MODE

POWER

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

-

M

O

O

Z

Z

O

O

M

+

CH

-

M

O

O

Z

V

O

L

P

R

E

V

C

H

MENU

CH

Z

O

O

M

+

V
O

L

E

Z

I

S

N

E

E

R

C

S

Background
Language


Keypad Lock
MGDI

Sound

Auto Power
Closed Caption

Screen

Time Setting

Channel

ISM
Parental Lock
Initialize

Move

Features

Adjust

Opaque
English

Off
On
Off

MENU

Exit

V
O
L

P

R

E

V

C

H

MUTE

REC

PREV


MODE

MTS

MENU

CH

PLAYF.R/SLOW

STOP

OPEN/CLOSE

SOUND

MODE

ADD/

ERASE

SLEEP

E

R

C

S

CAPTION

F.F/SLOW

PAUSE

NEXT

STILL

V

O

L

E

Z

I

S

N

E

Closed Caption Setting

CAPTION

• Press the “CAPTION” button on the Remote
Control.

• Whenever pressing the “CAPTION” button,
caption mode is changed as follow.

Closed Caption Setting in the Menu.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• Press the Menu Button.

• The MENU screen will be displayed as

below.

1

2

Closed Caption Setting

65

Off

XDS

CC1

Text4

CC2

Text3

CC3

Text2

Off

Mode


Brightness
Contrast

Sound

Color
Tint

Screen

Sharpness

Features

Color Temp.

Normal

Normal

32
48
32
32
32

CC4

Text1

V
O

L

DISPLAY

Z

P

R

E

MUTE


MTS

VIDEO/

DVD SATTV CATV

-

M

O

O

V

C

H

REC

PREV

OPEN/CLOSE

SOUND

MODE

ADD/

ERASE

CH

MENU

CH

PLAYF.R/SLOW

STOP

MODE

SLEEP

POWER

MULTIMEDIATV/VIDEO

Z

O

E

R

C

S

CAPTION

F.F/SLOW

PAUSE

NEXT

STILL

O

M

+

V

O

L

E

Z

I

S

N

E

Channel

MENU

Move

Select

Exit

Caption Box

Setting

• Black : Background of
the caption box is
black.

• Transparent :
Background of the
caption box is
Transparent.

66

Closed Caption Setting

Select Features

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• Select [Features] by pressing the “ CH ” button.

Select Closed Caption

• Enter the sub menu by using the “ VOL ” button.

• Select the [Closed Caption] by pressing the “ CH ”

button.

•You can select [Closed Caption] by using the

“ VOL

”

button.

3

4

• Caption Mode (Off -> CC1 -> CC2 -> CC3 -> CC4 ->
Text1 -> Text2 -> Text3 -> Text4 -> XDS -> Off), caption
box(black and trasparent) and CC on Mute can be set.

CC on Mute function : Display “CC1” automatically
when sound is “MUTE”.

POWER

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

V
O
L

P

-

M

O

O

Z

R

E

V

C

H

MUTE

REC

PREV


MODE

MTS

OPEN/CLOSE

ADD/

ERASE

MENU

CH

PLAYF.R/SLOW

STOP

SOUND

MODE

SLEEP

Z

O

E

R

C

S

CAPTION

F.F/SLOW

PAUSE

NEXT

STILL

O

M

+

V

O

L

E

Z

I

S

N

E

-

M

O

O

Z

V
O
L

P

R

E

V

C

H

Select

Opaque

English

Off
On
Off

MENU

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

Select

Exit

CH

MENU

CH

Background
Language


Keypad Lock
MGDI

Sound

Auto Power
Closed Caption

Screen

Time Setting

Features

Channel

ISM
Parental Lock
Initialize

Move

Z

O

E

R

C

S

O

M

+

V
O

L

E

Z

I

S

N

E


Sound

Screen

Features

Channel

Move

Closed Caption
Caption Mode


Caption Box
CC on Mute

Sound

Opaque

English

Off
On
Off

MENU

Off

Black

Off

Exit

Screen

Features

Channel

Move

Adjust

MENU

Exit

Press the MENU Button.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• The MENU screen will be displayed as below .

Select Features

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• Select [Features] by the “ CH ”
button.

Select Time Setting

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• Enter the sub menu by using the “ VOL”button.

• Select the [Time setting] by pressing the “ CH ” button.

• You can select [Time setting] by using the “ VOL

”

button.

3

1

2

Time Setting

67

Select

Normal

Normal

MENU

32
48
32
32
32

Exit


Sound

Screen

Features

Channel

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.

Move

Select

Opaque

English

Off
On
Off

MENU

Exit


Sound

Screen

Features

Channel

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

Move

POWER

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

-

M

O

O

Z

V

O

L

P

R

E

V

C

H

MUTE

REC

PREV

OPEN/CLOSE


MODE

MTS

ADD/

ERASE

MENU

CH

PLAYF.R/SLOW

STOP

SOUND

MODE

SLEEP

Z

O

E

R

C

S

CAPTION

F.F/SLOW

PAUSE

NEXT

STILL

O

M

+

V
O
L

E

Z

I

S

N

E

Select

Opaque

English

Off

Normal

Off

MENU

Exit

Background
Language


Keypad Lock
MGDI

Sound

Auto Power
Closed Caption

Screen

Time Setting

Channel

ISM
Parental Lock
Initialize

Move

Features

Clock(current

time) Setting

• The “Current time”
must be set up ahead
of setting up other time
memories.

68

Time Setting

Off Time and W ake Time settings.

• Select Functions by pressing the

“ CH ”

button.
First, set [Clock]- current time, and then You can
setup off-time and wake time.

• [Clock] : Enter clock setting menu by pressing the
“VOL ” button. then adjust the desired hour and

minute with

“ CH ” button.

• [Off Time] and [Wake Time] Setting methods are

same as [Clock] setting method.

• [Off Timer] and [Wake Timer] : Setting [On] and

[Off] of each Timer.

• [Wake Ch. ] and [Wake Vol. ] : Setting channel and
volume when TV is turned on by [Wake Timer].

4

Time Setting Functions

1) This time memory function automatically turns the

TV set “On” of “Off”at a desired time. Once set up,
this function works every day unless the set time is
canceled or the TV set is unplugged. Therefore, this
function could be used for a “Get up” alarm (Morning
Call) by setting up the time for “On” in the morning.

2) However, if you once power off with ON/OFF in the

PDP unit, the Time Setting will be reset.

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

CH

-

M

O

O

Z

V

MENU

O

L

P

R

E

V

C

H

CH

Z

O

O

M

+

V
O

L

E

Z

I

S

N

E

E

R

C

S


Sound

Screen

Features

Channel

Move

Time Setting
Clock
Off Timer
Off Time
Wake Timer
Wake Time
Wake Ch.
Wake Vol.

AM 11 : 50

AM 12 : 00

AM 12 : 00

Select

Off

Off

2

19

MENU

Exit

ISM

• Image sticking
minimization.

• Displaying a still
image like PC input
for a long time
causes part image
sticking in the panel

• The ISM function
minimize this effect.

Image Sticking Minimization(ISM)

69

Press the MENU Button.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• The MENU screen will be displayed as below .

Press the “ CH ” Button.

• Select [Features] by pressing the “ CH ”
button.

Select ISM.

• Enter the sub menu by using the “ VOL” button.

• Select the [ISM] by pressing the “ CH ”button.

• Press of the

“ VOL

”

button while you are in the

ISM.

3

1

2

CH

-

M

O

O

Z

V

O

L

P

R

E

V

C

H

MENU

CH

Z

O

O

M

+

V

O

L

E

Z

I

S

N

E

E

R

C

S

VIDEO/

DVD SATTV CATV

DISPLAY

CH

-

M

O

O

Z

Select

Normal

Normal

MENU

32
48
32
32
32

Exit


Sound

Screen

Features

Channel

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.

Move

Select

Opaque
English

Off
On
Off

MENU

Exit


Sound

Screen

Features

Channel

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

Move

POWER

MULTIMEDIATV/VIDEO

Z

O

O

M

+

V

O

CH

-

M

O

O

Z

V

MENU

O

L

P

R

E

V

C

H

CH

Z

O

O

M

+

V
O

E

Z

I

S

N

E

E

R

C

S

L


Sound

Screen

Features

Channel

Move

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

Select

Opaque

English

Off
On
Off

MENU

Exit

L

P

R

E

V

C

MUTE

REC

PREV


MODE

MTS

H

OPEN/CLOSE

ADD/

ERASE

MENU

CH

PLAYF.R/SLOW

STOP

SOUND

MODE

SLEEP

E

R

C

S

CAPTION

F.F/SLOW

PAUSE

NEXT

STILL

V
O
L

E

Z

I

S

N

E

70

Image Sticking Minimization(ISM)

Select Functions.

• Every press of the “ VOL”button after select function
by the “ CH ” button would switch between
ON/OFF .

4

NOTES:

*

Pixel Shift : The whole screen shifts up/down,

left/right at 20sec interval to minimise
image sticking.

*

Low Bright : When displaying a still picture or a

fixed pattern for a long time, the
brightness level decreases to
minimise image sticking.

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

CH

-

M

O

O

Z

V

MENU

O
L

P

R

E

V

C

H

CH

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S


Sound

Screen

Features

Channel

Move

ISM
Pixel Shift
Low Bright

Adjust

Off
Off

MENU

Exit

Parental Lock

• When “Parental
Lock” is on, the
locked channels are
not available on the
screen.

Parental Lock Setting

71

Press the MENU Button.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• The MENU screen will be displayed as below .

Select Features

• Select [Features] by pressing the “ CH ” button.

Select the Parental Lock

• Enter the sub menu by using the

“ VOL

”

button.

• Select the [Parental Lock] by pressing the “ CH ”
button.

•You can select [Parental Lock] by using the

“ VOL

”

button.

3

1

2

CH

-

M

O

O

Z

V

MENU

O

L

P

R

E

V

C

H

CH

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S

CH

-

M

O

O

Z

V

MENU

O

L

P

R

E

V

C

H

CH


Sound

Screen

Features

Channel


Sound

Screen

Features

Channel


Sound

Screen

Features

Channel

Move

Move

Move

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.

Select

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

Select

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

Select

Normal

Normal

MENU

Opaque
English

Off
On
Off

MENU

Opaque
English

Off

Normal

Off

MENU

Exit

Exit

Exit

32
48
32
32
32

POWER

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

-

M

O

O

Z

V

O

L

P

R

E

V

C

H

MUTE

REC

PREV

OPEN/CLOSE


MODE

MTS

ADD/

ERASE

MENU

CH

PLAYF.R/SLOW

STOP

SOUND

MODE

SLEEP

Z

O

E

R

C

S

CAPTION

F.F/SLOW

PAUSE

NEXT

STILL

O

M

+

V
O
L

E

Z

I

S

N

E

New Password

setting

New Password setting
menu is displayed at
first use.
Set New Password for
using Parental Lock
menu.

72

Parental Lock Setting

Press “Password”.

• Press Password by
using number 0~9.

Caution) If using your

password,
remember it.
It is needed
for continuous
use of this
function
hereafter.

On – Off of the
Parental Control is
repeated whenever
pressing the “

VOL ”

button.

4

• The “ CH ” and
“ VOL ” button

select items and the
“MUTE” button sets up
or cancels each item.

• A guideline of TV is
setup in all the TV
programs including
sports, news.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP

Eenter Password

_ _ _ _

MENU

Exit


Sound

Screen

Features

Channel

Move


Sound

Screen

Features

Channel

Move


Sound

Screen

Features

Channel

Move

Parental Control
Parental Lock
TV GuidLines
Movie Retings
No Ratings
Ext. Sources
Change Password

Parental Control
Parental Lock
TV GuidLines
Movie Retings
No Ratings
Ext. Sources
Change Password

TV GuidLines
Rating

MA

PG

Y7

Adjust

Select

Parental Control

All FV D L S V

14

G

Y

Select

Unblock

Block

Unblock

Block

Off

MENU

Exit

Off

MENU

Exit

MENUMUTE

Exit

73

• Rating of movie is
setup even in movie,
videotape and other
media objects
including TV program.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• The “ CH ” and
“

VOL ”button
select items and the
“ ” button sets
up or cancels each
item.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• Interrupts program

without rating.

• Interrupts program of the

input terminal for the
outside video (Video 1, 2)

• Sets up the Unblock or

the Block with the

“

VOL ” button.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP


Sound

Screen

Features

Channel

Move

Parental Control
Parental Lock
TV GuidLines
Movie Retings
No Ratings
Ext. Sources
Change Password

Select

Unblock

Block

Off

MENU

Exit

MUTE


Sound

Screen

Features

Channel

Move


Sound

Screen

Features

Channel

Move

Parental Control

Movie Ratings

X

NC-17

R

PG-13

PG

G

NR

Select

Parental Control
Parental Lock
TV GuidLines
Movie Retings
No Ratings
Ext. Sources
Change Password

Adjust

Unblock

Block

MENUMUTE

Exit

Off

MENU

Exit

74

Parental Lock Setting

“Change Password”.

• In the initial purchase of TV set, password is
set to blank.
In continuous use of Parental Control, you
need to change your password.

• If pressing the “ VOL ” button after
selecting password, the second screen of
below drawing appears. Here, newly enter
your unique password by using number of 0
through 9. Enter your password in the same
manner once again.

5

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

Exit from the “Parental Control” menu.

• The main menu appears if pressing the menu

button once.

• The OSD of the menu disappears if pressing

the menu button until it disappears.

6

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

CH

V
O
L

V

O

L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

MUTE

CAPTION

F.F/SLOW

PLAYF.R/SLOW

REC

STOP

PAUSE

PREV

OPEN/CLOSE

NEXT


MODE

SOUND

MODE

STILL

POWER

MTS

ADD/

ERASE

SLEEP


Sound

Screen

Features

Channel

Move

Parental Control
Parental Lock
TV GuidLines
Movie Retings
No Ratings
Ext. Sources
Change Password

Select

Off

Unblock

Block

MENU

Exit

New Password

_ _ _ _

MENU

Exit

Repeat Password

_ _ _ _

MENU

Exit

75

Back to

Initialization

• You can restore the
values of the
adjustment setting
made in the MENU
to factory settings.

Initialize Setting

Press the MENU Button.

CH

CH

V
O
L

V
O
L

Z

O

O

M

+

Z

O

O

M

-

MENU

P

R

E

V

C

H

S

C

R

E

E

N

S

I

Z

E

• The MENU screen will be displayed as below .

Select Features

• Select [Features] by the “ CH ” button.

1

2

CH

-

M

O

O

Z

V

MENU

O

L

P

R

E

V

C

H

CH

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S


Sound

Screen

Features

Channel


Sound

Screen

Features

Channel

Move

Move

Mode
Brightness
Contrast
Color
Tint
Sharpness
Color Temp.

Select

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

Select

Normal

Normal

Opaque
English

Off
On
Off

MENU

MENU

Exit

Exit

32
48
32
32
32

POWER

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

V

O

L

M

O

O

Z

P

R

E

V

C

MUTE

REC

PREV


MODE

-

H

OPEN/CLOSE

MENU

CH

PLAYF.R/SLOW

STOP

SOUND

MODE

Z

O

O

E

R

C

S

CAPTION

F.F/SLOW

PAUSE

NEXT

STILL

M

+

Z

I

S

N

E

V
O
L

E

ADD/

SLEEP

MTS

ERASE

76

When [INITIALIZA TION] is completed:

1) When [INITIALIZATION] is completed, those values that have been
set in the User Mode of [SCREEN MODE] and [SOUND MODE] will
be returned to the factory preset values.

2) Once initialized, you can not undo.

3) The items in the [SCREEN] Menu in PC or DVI INPUT are also
initialized (i.e., H. Size, V. Size, H. Position, V. Position, Phase,
Frequency, etc.)

4) Language, channel, time, volume, input mode are not initialized.

INITIALIZATION

• Enter the sub menu by using the

“ VOL ”

button.

• Select the [Initialize] by pressing the “ CH ”
button, then press the

“ VOL ”

button.

• A confirmation message will be displayed.

• To perform initialization, press the “

VOL ”

button
after selecting [YES] by pressing the “ CH ”
button.

• To return to MENU, press "MENU" button.

3

Initialize Setting

V

O

L

CH

-

M

O

O

Z

MENU

P

R

E

V

C

H

CH

Z

O

O

M

+

V
O
L

E

Z

I

S

N

E

E

R

C

S

Select

Opaque

English

Off
On
Off

MENU

Are you Sure?

No
Yes

MENU

Move

Exit

Select

Exit


Sound

Screen

Features

Channel

Move

Background
Language
Keypad Lock
MGDI
Auto Power
Closed Caption
Time Setting
ISM
Parental Lock
Initialize

77

Setting

Sleep Timer

• SLEEP TIMER turns
the PDP off after a
preset time.

Press the “SLEEP” Button.

SLEEP

• Press the “SLEEP” button on the Remote Control.

• Pressing the “SLEEP” button first time will display the

current setting for SLEEP TIMER.

• To cancel the SLEEP TIMER, press the “SLEEP” button
to select ‘OFF’.

1

Setting Sleep Timer

NOTES:

1) On-screen information disappears if you do not
take any action for about two seconds after
pressing the SLEEP button.

2) If you turn the PDP off after setting SLEEP, the
setting is erased.

Sleep off

Sleep 15

Sleep 30

Sleep 120

Sleep 90

Sleep 60

Sleep Off

POWER

VIDEO/

DVD SATTV CATV

DISPLAY

MULTIMEDIATV/VIDEO

CH

V

O

L

M

O

O

Z

P

R

E

V

C

MUTE

REC

PREV


MODE

-

H

OPEN/CLOSE

MENU

CH

PLAYF.R/SLOW

STOP

SOUND

MODE

Z

O

E

R

C

S

CAPTION

F.F/SLOW

PAUSE

NEXT

STILL

O

M

+

V
O
L

E

Z

I

S

N

E

MTS

ADD/

ERASE

SLEEP

Before Requesting Service

78

Before

Requesting for

Service

St
yo
mm

ps

C

h
e
c
k
s

A

c

t

i
o
n

• There are empty spots at the top
and the bottom area of the screen.

• Check if the screen size of an image
is wider than 16:9 aspect ratio
(theater screen size).

• When video screen is wider than
16:9 aspect ratio, you may see dark
areas at the top and the bottom of
the screen.

• The Display makes a snapping
sound.

• Check if the pictures and sound are

normal.

• This sound is produced due to

variations in room temperature.

• This sound does not indicate that the

Display has a problem if the pictures
and sound can be viewed and heard
properly.

• Remote control does not
function properly.

• Check for any obstacle between the

Remote Control and the Display.

• Check for dead batteries and

incorrect battery orientation.

• Check if the Remote Control is the

right one.

• Remove any obstacle between the

Remote Control and the Display.

• Replace batteries and use the correct

polarity (+) or (-) of the batteries.

• Use the correct Remote Control

proper to the model.

St
yo
mm

ps

C

h
e
c
k
s

A

c

t

i
o
n

• Screen size is suddenly
changed.

• The screen size of a video image

may not be matched to the size of
the dark initial screen.

• Check by using other video tape.

• There are spots on the screen
or screen rolls.

• Check if your product is affected by

any interference from automobiles,
high-voltage transmission lines, neon
signs or other potential sources.

Before requesting for service, check the following points once again.

79

SPECIFICA TIONS

In the event that the product has been submerged in the water
in rainy season:

Immediately wash it with clean water, and dry it in a shadow place,
then call for service from the nearest Daewoo Service Center.
Never plug the Power Cord since there is risk of electric shock and
damage of the product.

*

Appearance and specifications of this product are subject to change for improving the product without prior notice.

DISPLAY UNIT

INPUT/OUTPUT TERMINAL

Diagonal Size 106cm (42 )
Screen Aspect Ratio 16 : 9
Display Resolution 853(H) 480(V) dots
Pixel Pitch 1.08(H) 1.08(V) mm
Video Signal

NTSC, P AL, SECAM, PAL-M/N, NTSC4.43

Dimension 1044(W) 631(H) 89(D)mm

41.10(W) 24.84(H) 3.50(D)inch
Weight 30 kg (66.14Lbs)
Power Requirement 100-240V~, 50/60Hz

ITEMS VIDEO AUDIO

DVI INPUT DVI-D Digital Only Jack (LEFT/RIGHT)
PC INPUT one 15 pin D-sub jack (LEFT/RIGHT)
Component INPUT Y, Pb/Cb, Pr/Cr RCA Jack 2sets

2sets (LEFT/RIGHT)

Video INPUT RCA and S-Video Jack 2 sets each 2sets (LEFT/RIGHT

EXTERNAL TV Standard : NTSC-M

INPUT Receiving Channel :

VHF : CH02 ~ 13 (55.25MHz ~ 211.25MHz)
UHF : CH14 ~ 69 (471.25MHz ~ 801.25MHz)
CATV : CH1(73.25MHz), 14 ~ 125 (121.25MHz ~ 799.25MHz)

EXTERNAL

VIDEO OUTPUT RCA jack

OUTPUT (LEFT/RIGHT)
AUDIO OUTPUT SPEAKER OUTPUT (8 Ohm) 20W (10W + 10W)
