S/G No. : TCN207MEF0G1
Service Guide
Color Television
CHASSIS : CN-207a
Model : DTQ-25G4FS
DTQ-29G4FS
SPECIFICATIONS
MODEL
ITEM
TV STANDARD
POWER INPUT
POWER CONSUMPTION
TUNING SYSTEM
TUNING RANGES
SOUND OUTPUT
SPEAKER
ANTENNA INPUT IMPEDANCE
AUXILIARY INPUT TERMINAL
INTERMEDIATE FREQUENCIES
REMOTE CONTROL
DTH-25G4FS
NTST-M
120V / 220V 50/60HZ
120W 135W
F.S.REMOCON
VHF
UHF
CATV
6.5W + 6.5W (R+L)
8 10W + 8 10W (R+L)
75 ohm
Font : Video, Audio, R/L, 1EA
Rear : Video, Audio, R/L, 1EA
PIF : 45.75 MHZ
SIF : 41.25 MHZ
COLOR SUB : 3.579545 MHZ
R-35H13
VHF(L) : CH 2 ~ 6
(H) : CH 7 ~ 13
CH 14 ~ CH 69
CH 1 ~ CH 125
DTH-29G4FS
1) ICON MENU TYPE
SPECIAL FUNCTIONS
✔
Caution
2) 3-Language OSD
3) WITH CAPTION
4) CH LABEL
5) WITH CAPTION
6) CH LABEL, AUTO DEMO
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
http : //svc.dwe.co.kr Oct. 2000
DTQ-25G4FS
DTQ-29G4FS
The Different Part List
✔ Caution:In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
part_cd part_nm part_desc loc
DTQ-
part_cd part_nm part_desc loc
CEXF1H228V C ELECTRO 50V RSS 0.22MF (5X11) TP C306 1 0
CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP C306 0 1
CMYH3C822J C MYLAR 1.6KV BUP 8200PF J C404 0 1
CMYH3D752J C MYLAR 2KV BUP 7500PF J C404 1 0
CMYH3C692J C MYLAR 1.6KV BUP 6900PF J C405 1 0
CMYH3C912J C MYLAR 1.6KV BUP 9100PF J C405 0 1
CMXE2J273J C MYLAR 630V PU 0.027MF J (TP) C406 1 0
CMXE2J333J C MYLAR 630V PU 0.033MF J (TP) C406 0 1
CMXE2D683J C MYLAR 200V PU 0.068MF J (TP) C419 0 1
CMYE2D394J C MYLAR 200V PU 0.39MF J C420 1 0
CMYE2D514J C MYLAR 200V PU 0.51MF J C420 0 1
CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP C826 1 0
HCBH224KCA C CHIP CERA 25V X7R 0.22MF K 2012 CC723 0 1
HCBK223KCA C CHIP CERA 50V X7R 0.022MF K 2012 CC723 1 0
DRGP15J--- DIODE RGP15J D824 1 0
4856310600 EYE LET BSR T0.2 (R2.3) E034 0 1
4856310600 EYE LET BSR T0.2 (R2.3) E035 0 1
85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J019 1 0
85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J020 1 0
85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J200 0 1
85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J212 0 1
58H0000025 COIL H-LINEARITY TRL-330 L401 1 0
58H1600022 COIL H-LINEARITY TRL-2093 L401 0 1
58W0000018 COIL WIDTH TLN-2092 L402 0 1
4852066501 MASK FRONT HIPS BK M201 0 1
4852073303 MASK FRONT HIPS BK M201 1 0
4856015800 SCREW CRT FIX L=27 M201A 4 0
4856015820 SCREW CRT FIX SWRM+SK5 L=35 M201A 0 4
4856215402 WASHER RUBBER CR T2.0 M201B 4 0
4856215404 WASHER RUBBER CR T4.0 M201B 0 4
4852150741 COVER BACK HIPS BK M211 0 1
4852155321 COVER BACK HIPS BK M211 1 0
7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK M211A 8 0
7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK M211A 0 10
4852821201 DOOR ABS BK M281 0 1
4852821900 DOOR ABS BK M281 1 0
4853526600 HOLDER CORD NYLON6(DACB-183) M351 1 0
7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK M351A 1 0
7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK M381A 2 0
4854852501 BUTTON POWER ABS BK M481 0 1
4854856100 BUTTON POWER ABS BK M481 1 0
4855535401 DECO SENSOR PMMA CL M551 0 1
4855540800 DECO SENSOR PMMA M551 1 0
4855616100 MARK BRAND A1050P-H24 M561 1 0
48556174SD MARK BRAND SILVER DIA-CUTTING M561 0 1
4856812400 BAND 18MM X 3M M681 1 0
4856812400 BAND 18MM X 3M M681 0 1
4857820001 CLOTH BLACK CLOTH 320X12X0.5 M781 0 2
4857821103 CLOTH BLACK FELT 180X10X1.5 M781 2 0
4858053400 BOX CARTON DW-4 A TYPE M801 0 1
4858055500 BOX CARTON DW-2 M801 1 0
4858185900 PAD EPS 29G4 M811 0 1
4858192500 PAD EPS 25G4 M811 1 0
4858215100 BAG P.E PE FOAM t0.5x1430x1270 M821 1 0
4858215600 BAG P.E PE FOAM t0.5x1600x1270 M821 0 1
RS02Z220JS R M-OXIDE FILM 2W 22 0HM J SMALL R314 1 0
RS02Z620JS R M-OXIDE FILM 2W 62 OHM J SMALL R314 0 1
RF01Z159J- R FUSIBLE 1W 1.5 OHM J (TAPPING) R409 1 0
RF01Z399J- R FUSIBLE 1W 3.9 OHM J (TAPPING) R409 0 1
RF01Z518K- R FUSIBLE 1W 0.51 OHM K (TAPPING) R817 0 1
RF01Z688K- R FUSIBLE 1W 0.68 OHM K (TAPPING) R817 1 0
RF01Z518K- R FUSIBLE 1W 0.51 OHM K (TAPPING) R818 0 1
RF01Z688K- R FUSIBLE 1W 0.68 OHM K (TAPPING) R818 1 0
HRFT512JCA R CHIP 1/10 5.1K OHM J 2012 RC301 1 0
HRFT682JCA R CHIP 1/10 6.8K OHM J 2012 RC301 0 1
25G4FS
DTQ-
29G4FS
HRFT104JCA R CHIP 1/10 100K OHM J 2012 RC304 1 0
HRFT913JCA R CHIP 1/10 91K OHM J 2012 RC304 0 1
HRFT183JCA R CHIP 1/10 18K OHM J 2012 RC305 1 0
HRFT273JCA R CHIP 1/10 27K OHM J 2012 RC305 0 1
HRFT123JCA R CHIP 1/10 12K OHM J 2012 RC307 0 1
HRFT163JCA R CHIP 1/10 16K OHM J 2012 RC307 1 0
HRFT183JCA R CHIP 1/10 18K OHM J 2012 RC308 0 1
HRFT203JCA R CHIP 1/10 20K OHM J 2012 RC308 1 0
HRFT513JCA R CHIP 1/10 51K OHM J 2012 RC309 1 0
HRFT623JCA R CHIP 1/10 62K OHM J 2012 RC309 0 1
HRFT392JCA R CHIP 1/10 3.9K OHM J 2012 RC420 1 0
HRFT562JCA R CHIP 1/10 5.6K OHM J 2012 RC420 0 1
HRFT000-CA R CHIP 1/10 0 OHM 2012 RC426 1 0
HRFT479JCA R CHIP 1/10 4.7 OHM J 2012 RC426 0 1
HRFT273JCA R CHIP 1/10 27K OHM J 2012 RC428 1 0
HRFT393JCA R CHIP 1/10 39K OHM J 2012 RC428 0 1
HRFT561JCA R CHIP 1/10 560 OHM J 2012 RC570 1 0
HRFT911JCA R CHIP 1/10 910 OHM J 2012 RC570 0 1
HRFT112JCA R CHIP 1/10 1.1K OHM J 2012 RC571 0 1
HRFT182JCA R CHIP 1/10 1.8K OHM J 2012 RC571 1 0
HRFT102JCA R CHIP 1/10 1K OHM J 2012 RC725 0 1
HRFT103JCA R CHIP 1/10 10K OHM J 2012 RC725 1 0
HRFT334JCA R CHIP 1/10 330K OHM J 2012 RC820 1 0
HRFT434JCA R CHIP 1/10 430K OHM J 2012 RC820 0 1
HRFT184JCA R CHIP 1/10 180K OHM J 2012 RC822 1 0
HRFT684JCA R CHIP 1/10 680K OHM J 2012 RC822 0 1
HRFT161JCA R CHIP 1/10 160 OHM J 2012 RC905 1 0
HRFT181JCA R CHIP 1/10 180 OHM J 2012 RC905 0 1
HRFT181JCA R CHIP 1/10 180 OHM J 2012 RC911 0 1
HRFT201JCA R CHIP 1/10 200 OHM J 2012 RC911 1 0
HRFT161JCA R CHIP 1/10 160 OHM J 2012 RC917 1 0
HRFT181JCA R CHIP 1/10 180 OHM J 2012 RC917 0 1
7172401412 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK SP01A 0 4
7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK SP01A 4 0
4859629060 CRT A59KPR84X01(D) P38 V901 1 0
4859629160 CRT A68KTB259X001 P38 V901 0 1
48B3235H13 TRANSMITTER REMOCON R-35H13 ZZ100 1 0
48B3235H13 TRANSMITTER REMOCON R-35H13 ZZ100 0 1
PTACPWJ663 ACCESSORY AS DTQ-29G3FS ZZ110 1 0
PTACPWJ663 ACCESSORY AS DTQ-29G3FS ZZ110 0 1
PTBCSHJ752 COVER BACK AS DTQ-29G4FS ZZ120 0 1
PTBCSHJ793 COVER BACK AS DTQ-25G4FS ZZ120 1 0
PTPKCPJ752 PACKING AS DTQ-29G4FS ZZ130 0 1
PTPKCPJ793 PACKING AS DTQ-25G4FS ZZ130 1 0
48519A4010 CRT GROUND NET 2501H-1015-2P ZZ131 1 0
48519A4210 CRT GROUND NET 2901H-1015-2P ZZ131 0 1
58G0000148 COIL DEGAUSSING DC-25SF ZZ132 1 0
58G0000149 COIL DEGAUSSING DC-29SF ZZ132 0 1
PTCACAJ752 CABINET AS DTQ-29G4FS ZZ140 0 1
PTCACAJ793 CABINET AS DTQ-25G4FS ZZ140 1 0
PTFMSJJ752 MASK FRONT AS DTQ-29G4FS ZZ200 0 1
PTFMSJJ793 MASK FRONT AS DTQ-25G4FS ZZ200 1 0
PTMPJ0J752 PCB MAIN (RHU) AS DTQ-29G4FS ZZ200 0 1
PTMPJ0J793 PCB MAIN (RHU) AS DTQ-25G4FS ZZ200 1 0
PTMPJ2J752 PCB CHIP MOUNT B AS DTQ-29G4FS ZZ200 0 1
PTMPJ2J793 PCB CHIP MOUNT B AS DTQ-25G4FS ZZ200 1 0
PTMPJAJ752 PCB MAIN AXIAL AS DTQ-29G4FS ZZ200 0 1
PTMPJAJ793 PCB MAIN AXIAL AS DTQ-25G4FS ZZ200 1 0
PTMPJBJ752 PCB MAIN M-10 AS DTQ-29G4FS ZZ200 0 1
PTMPJBJ793 PCB MAIN M-10 AS DTQ-25G4FS ZZ200 1 0
PTMPJRJ752 PCB MAIN RADIAL AS DTQ-29G4FS ZZ200 0 1
PTMPJRJ793 PCB MAIN RADIAL AS DTQ-25G4FS ZZ200 1 0
PTMPMSJ752 PCB MAIN MANUAL AS DTQ-29G4FS ZZ290 0 1
PTMPMSJ793 PCB MAIN MANUAL AS DTQ-25G4FS ZZ290 1 0
DTQ-
25G4FS
DTQ-
29G4FS
Electrical Parts List
LOC PART CODE PART NAME PART DESCRIPTION
ZZ100 48B3235H13 TRANSMITTER REMOCON R-35H13
ZZ110 PTACPWJ663 ACCESSORY AS DTQ-29G3FS
30 4850Q00810 BATTERY R6P/LN
40 4.86E+09 MANUAL INSTRUCTION DTQ-29G4FS
M821 4858213800 BAG INSTRUCTION L.D.P.E T0.05X250X400
ZZ120 PTBCSHJ752 COVER BACK AS DTQ-29G4FS
M211 4852150741 COVER BACK HIPS BK
M541 4855415800 SPEC PLATE 150ART P/E FILM (C/TV)
M782 4857817630 CLOTH BLACK FELT 400X20X0.7
ZZ130 PTPKCPJ752 PACKING AS DTQ-29G4FS
M641 6520010100 STAPLE PIN 18M/M J D O
M681 4856812400 BAND 18MM X 3M
M801 4858053400 BOX CARTON DW-4 A TYPE
M811 4858185900 PAD EPS 29G4
M821 4858215600 BAG P.E PE FOAM t0.5x1600x1270
ZZ131 48519A4210 CRT GROUND NET 2901H-1015-2P
ZZ132 58G0000149 COIL DEGAUSSING DC-29SF
ZZ140 PTCACAJ752 CABINET AS DTQ-29G4FS
40 2TF01612CL TAPE FILAMENT 12MMX55ME CLEAR
AD001 4859000240 ADAPTER 2P15A 300V(D=4.0)
M201A 4856015820 SCREW CRT FIX SWRM+SK5 L=35
M201B 4856215404 WASHER RUBBER CR T4.0
M211A 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M211B 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M281 4852821201 DOOR ABS BK
M481 4854852501 BUTTON POWER ABS BK
M481A 4856716000 SPRING SWPA PIE0.5
M491 4854937711 BUTTON ABS BK
M491A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M501 4855058702 DECO CTRL PVC T0.25
M551 4855535401 DECO SENSOR PMMA CL
M551A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M561 48556174SD MARK BRAND SILVER DIA-CUTTING
M681 4856812001 TIE CABLE NYLON66 DA100
M685 4856816300 CLAMP WIRE NYLON 6 (V0)
M781 4857820001 CLOTH BLACK CLOTH 320X12X0.5
M791 4857923300 DOOR LOCK LA701(KIFCO)
SP01 48A8304800 SPEAKER SYSTEM SS-78128F04 10W 8 OHM
SP01A 7172401412 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
V901 4859629160 CRT A68KTB259X001 P38
ZZ200 PTFMSJJ752 MASK FRONT AS DTQ-29G4FS
M201 4852066501 MASK FRONT HIPS BK
ZZ203 PTCTMSJ752 PCB CONTROL MANUAL A DTQ-29G4FS
DF01 DKLR114L-- LED KLR114L
IL01 1TS0P1238W IC PREAMP TS0P1238WI1
JP01 4859102130 JACK EARPHONE YSC-1537
JP02 4859108450 JACK PIN BOARD YSC03P-4120-14A
M351 4853530901 HOLDER LED P.P
M381 4853816400 FRAME SUB PCB FR HIPS BK
M683 4856812001 TIE CABLE NYLON66 DA100
PA907 4850706S01 CONNECTOR YH025-
PA908 4850709S01 CONNECTOR YH025-
SW12 5S50101035 SW TACT KPT-1112 1C-1P
ZZ200 PTCTJRJ752 PCB CONTROL RADIAL A DTQ-29G4FS
C201 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C202 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C203 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C204 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C205 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
SW07 5S50101090 SW TACT THVH472GCA
SW08 5S50101090 SW TACT THVH472GCA
SW09 5S50101090 SW TACT THVH472GCA
SW10 5S50101090 SW TACT THVH472GCA
SW11 5S50101090 SW TACT THVH472GCA
ZZ200 PTCTJAJ752 PCB CONTROL AXIAL AS DTQ-29G4FS
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M
A001 4859833014 PCB CONTROL 56X246(246X246/1X4)
J298 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J299 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
R201 RD-4Z300J- R CARBON FILM 1/4 30 OHM J
06+YST025+ULW=200
09+YST025+ULW=200
LOC PART CODE PART NAME PART DESCRIPTION
R202 RD-4Z300J- R CARBON FILM 1/4 30 OHM J
R203 RD-4Z474J- R CARBON FILM 1/4 470K OHM J
R204 RD-4Z474J- R CARBON FILM 1/4 470K OHM J
R206 RD-4Z181J- R CARBON FILM 1/4 180 OHM J
R207 RD-2Z221J- R CARBON FILM 1/2 220 OHM J
R208 RD-2Z221J- R CARBON FILM 1/2 220 OHM J
R209 RD-4Z302J- R CARBON FILM 1/4 3K OHM J
R211 RD-4Z242J- R CARBON FILM 1/4 2.4K OHM J
R212 RD-4Z152J- R CARBON FILM 1/4 1.5K OHM J
R213 RD-4Z821J- R CARBON FILM 1/4 820 OHM J
R214 RD-4Z681J- R CARBON FILM 1/4 680 OHM J
R215 RD-4Z681J- R CARBON FILM 1/4 680 OHM J
R216 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R217 RD-4Z750J- R CARBON FILM 1/4 75 OHM J
ZZ290 PTMPMSJ752 PCB MAIN MANUAL AS DTQ-29G4FS
C307 CEYF1V332V C ELECTRO 35V RSS 3300MF (18X35.5)
C404 CMYH3C822J C MYLAR 1.6KV BUP 8200PF J
C405 CMYH3C912J C MYLAR 1.6KV BUP 9100PF J
C406 CMXE2J333J C MYLAR 630V PU 0.033MF J (TP)
C420 CMYE2D514J C MYLAR 200V PU 0.51MF J
C422 CEYD1H689W C ELECTRO 50V RHD 6.8MF (16X35.5)
C636 CEYF1V332V C ELECTRO 35V RSS 3300MF (18X35.5)
C801 CL1JB3104M C LINE ACROSS AC250V 0.1MF M ECQ-UV
C802 CEYD2G331D C ELECTRO 400V FHS 330MF (35X35)
C809 CEYN2D221T C ELECTRO 200V FWS 220MF (22X30)
C814 CBYB3D152K C CERA SEMI 2KV BL(N) 1500PF K
C815 CEYF1V222V C ELECTRO 35V RSS 2200MF (16X31.5)
C825 CH1AFE472M C CERA AC 4KV 4700PF M KX DE1610
C827 CH1BFB471K C CERA AC AC400V 470PF K SD
C831 CEYF1V332V C ELECTRO 35V RSS 3300MF (18X35.5)
C832 CCYR3D681K C CERA 2KV R 680PF K 125 DE1007
C910 4SG0D00103 SPARK GAP S-23 900V-1.5KV
C911 4SG0D00103 SPARK GAP S-23 900V-1.5KV
C912 4SG0D00103 SPARK GAP S-23 900V-1.5KV
COMB1 5PUGL349KN FILTER COMB UGL-349KNT
D401 DDG3------ DIODE DG3
D402 DRGP30J--- DIODE RGP30J
D406 DRGP30J--- DIODE RGP30J
D801 PTC1SW8902 HEAT SINK ASS`Y DPBS606GU- + 7174300811
D801 DPBS606GU- DIODE BRIDGE PBS606G
D801A 4857018902 HEAT SINK A1050P-H24
D801B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
D804 PTZ2SW5200 HEAT SINK ASS`Y DFMLG16S-- + 7174300811
1 DFMLG16S-- DIODE FML-G16S
0000A 4857025200 HEAT SINK SPCC T1.0 DG
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
D808 DEGP50D--- DIODE EGP50D (TAPPING)
F801 5FKGB6323L FUSE GLASS TUBE KS MF51 6.3A 125/250V TL
I301 PTE2SW8200 HEAT SINK ASS`Y 1LA7845N-- + 7174301011
I301 1LA7845N-- IC LA7845N
I301A 4857028200 HEAT SINK AL EX BK
I301B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I501 1LA76070A- IC VIDEO PROCESSOR LA76070A
I502 1LA7956--- IC LA7956
I503 1LA7956--- IC LA7956
I504 1TC4053BP- IC TC4053BP
I601 1TDA9852-- IC AUDIO PROCESSOR TDA9852
I602 PTA2SW3332 HEAT SINK ASS`Y 1LA4282--- + 7174301011
1 1LA4282--- IC LA4282
0000A 4857023332 HEAT SINK AL EX
0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I701 1DW8647DM1 IC MICOM DW864732V-DM1(5N74)
I702 1AT24C08PC IC AT24C08-10PC
I801 PTB2SW7900 HEAT SINK ASS`Y 1STRF6656- + 7174300811
I801 1STRF6656- IC POWER STR-F6656
I801A 4857027900 HEAT SINK AL EX BK
I801B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I802 1KA78R08-- IC REGULATOR KA78R08
I803 1PQ3RF23-- IC REGULATOR PQ3RF23
I804 TX0202DA-- THYRISTOR X0202DA1BA2
I805 1K1A7806P1 IC REGULATOR KIA7806API
I807 4850M04810 MODULE POWER DPM011 TI
IP01 1M65617SP- IC PIP M65617SP
WRL
LOC PART CODE PART NAME PART DESCRIPTION
JP03 4859109250 JACK PIN BOARD PH-JB-9614A
JP04 4859109250 JACK PIN BOARD PH-JB-9614A
L101 58C5580019 COIL CHOKE TRF-9225 (0.55UH)
L401 58H1600022 COIL H-LINEARITY TRL-2093
L402 58W0000018 COIL WIDTH TLN-2092
L403 58C7070085 COIL CHOKE TLN-3062A
L502 58N0000037 COIL VCO TRF-V004
L503 58S0000045 COIL SIF TRF-S001
L801 5PTLF3024- FILTER LINE TLF-3024
L807 58C0000107 COIL CHOKE L-680
M682 4856812001 TIE CABLE NYLON66 DA100
P901 4850703S20 CONNECTOR YH025-
P902 4850705S04 CONNECTOR YH025-
P903 4859238620 CONN WAFER YPW500-02
PWC1 PTWASW0910 CORD POWER ASS`Y 4859901111+ 4857417700
PW000 4859901111 CORD POWER KKP-419C KLCE-2F (2.1ME)
PW001 4857417700 TERM CLAMP PT-01-T3
Q401 PTK2SW7602 HEAT SINK ASS`Y T2SD1880-- + 7174300811
1 T2SD1880-- TR 2SD1880
0000A 4857027602 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
Q406 PTB2SW7602 HEAT SINK ASS`Y TKTD2058Y- + 7174301011
1 TKTD2058Y- TR KTD 2058-Y
0000A 4857027602 HEAT SINK AL EX
0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
0000D 4856215200 WASHER SPCC
Q901 TKTC3229-- TR KTC 3229
Q903 TKTC3229-- TR KTC 3229
Q905 TKTC3229-- TR KTC 3229
R400 RX10T402J- R CEMENT 10W 4K OHM J TRIPOD
R414 RF01Y478K- R FUSIBLE 1W 0.47 OHM K
R802 RX10T109KS R CEMENT 10W 1 OHM K TRIPOD
R803 RM02Y108K- R METAL FLAT 2W 0.1 OHM K
RP801 DDC7R0M290 POSISTOR ECPCD7R0M290
RS801 DSVC471D14 VARISTOR SVC471D14A
RTH01 DR320K---- THERMISTOR R-320K
SAW1 5PM1859M-- FILTER SAW M1859M
SCT1 4859302830 SOCKET CRT ISH-02S
T401 50H0000189 FBT FFA94048L
T401A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
T402 5TD0000018 TRANS DRIVE THD-120
T801 50M5345B4- TRANS SMPS TSM-5345B4
TU01 4859715630 TUNER VARACTOR TELH9-039A
TU03 4850M02910 MODULE RF PH-RF-9505B
UT01 4859003750 PLUG PHONE AS PLUG+CABLE
X502 4850L03110 RESONATOR CERA CSB503F44
X601 4850L03810 RESONATOR CERA CSB503F58
X701 5XYR03276C CRYSTAL QUARTZ C-001R 32.768000KHZ
XP01 5XJ14R31DE CRYSTAL QUARTZ HC49S 14.318MHZ 30PPM
Y801 5SC0101325 SW RELAY HR-CR7 DC12V
Z502 5PYXT4R5MB FILTER CERA XT 4.5MB
ZZ200 PTMPJ2J752 PCB CHIP MOUNT B AS DTQ-29G4FS
CC102 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC103 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC106 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC302 HCTBF479MB C CHIP TANTAL 16V 4.7MF M 3528
CC401 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC501 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC502 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC504 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC510 HCBK333KCA C CHIP CERA 50V X7R 0.033MF K 2012
CC512 HCQK130JCA C CHIP CERA 50V CH 13PF J 2012
CC515 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC516 HCBK333KCA C CHIP CERA 50V X7R 0.033MF K 2012
CC517 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC518 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC524 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC526 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC529 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC530 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
03+YST025+ULW=400
05+YST025+ULW=400
SMALL
1365AWG26=150B
20PPM
16P
LOC PART CODE PART NAME PART DESCRIPTION
CC535 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC538 HCQK561JCA C CHIP CERA 50V CH 560PF J 2012
CC548 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC549 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC550 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC553 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC602 HCTAF229MB C CHIP TANTAL 16V 2.2MF M 3216
CC603 HCBK822KCA C CHIP CERA 50V X7R 8200PF K 2012
CC604 HCTBF479MB C CHIP TANTAL 16V 4.7MF M 3528
CC606 HCTAF229MB C CHIP TANTAL 16V 2.2MF M 3216
CC607 HCTBF100MB C CHIP TANTAL 16V 10MF M 3528
CC608 HCTBF100MB C CHIP TANTAL 16V 10MF M 3528
CC609 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CC610 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CC612 HCTBF100MB C CHIP TANTAL 16V 10MF M 3528
CC614 HCTBF479MB C CHIP TANTAL 16V 4.7MF M 3528
CC617 HCTAF229MB C CHIP TANTAL 16V 2.2MF M 3216
CC618 HCBK822KCA C CHIP CERA 50V X7R 8200PF K 2012
CC622 HCTAF229MB C CHIP TANTAL 16V 2.2MF M 3216
CC623 HCTBF479MB C CHIP TANTAL 16V 4.7MF M 3528
CC624 HCTBF479MB C CHIP TANTAL 16V 4.7MF M 3528
CC625 HCTBF100MB C CHIP TANTAL 16V 10MF M 3528
CC628 HCTBF479MB C CHIP TANTAL 16V 4.7MF M 3528
CC632 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC637 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC701 HCQK180JCA C CHIP CERA 50V CH 18PF J 2012
CC702 HCQK180JCA C CHIP CERA 50V CH 18PF J 2012
CC703 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC705 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC707 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CC708 HCBK332KCA C CHIP CERA 50V X7R 3300PF K 2012
CC709 HCTAF229MB C CHIP TANTAL 16V 2.2MF M 3216
CC710 HCTAF109MB C CHIP TANTAL 16V 1MF M 3216
CC711 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC712 HCQK221JCA C CHIP CERA 50V CH 220PF J 2012
CC723 HCBH224KCA C CHIP CERA 25V X7R 0.22MF K 2012
CC816 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CC817 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC901 HCQK271JCA C CHIP CERA 50V CH 270PF J 2012
CC902 HCQK271JCA C CHIP CERA 50V CH 270PF J 2012
CC903 HCQK271JCA C CHIP CERA 50V CH 270PF J 2012
CCP01 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP02 HCQK120JCA C CHIP CERA 50V CH 12PF J 2012
CCP03 HCQK100DCA C CHIP CERA 50V CH 10PF D 2012
CCP04 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP06 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP08 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP13 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCP14 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP15 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP16 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP18 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCP19 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP20 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP23 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP25 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP28 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP29 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP30 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCP32 HCQK510JCA C CHIP CERA 50V CH 51PF J 2012
CCP33 HCQK750JCA C CHIP CERA 50V CH 75PF J 2012
CCP34 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCP36 HCBK103KCA C CHIP CERA 50V X7R 0.01MF K 2012
CCP38 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CCP39 HCQK100DCA C CHIP CERA 50V CH 10PF D 2012
CCP41 HCQK470JCA C CHIP CERA 50V CH 47PF J 2012
CCV07 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
JC01 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC02 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC03 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC04 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC05 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC06 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC07 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC08 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC09 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC10 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC11 HRFT000-CA R CHIP 1/10 0 OHM 2012
LOC PART CODE PART NAME PART DESCRIPTION
JC12 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC14 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC15 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC16 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC17 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC18 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC19 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC20 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC22 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC23 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC24 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC25 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC26 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC27 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC28 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC29 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC30 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC31 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC32 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC33 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC34 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC35 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC36 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC37 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC39 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC40 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC41 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC42 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC44 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC45 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC46 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC47 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC48 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC49 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC50 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC51 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC52 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC53 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC54 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC55 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC56 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC57 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC58 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC60 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC61 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC62 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC63 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC65 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC66 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC67 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC68 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC70 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC71 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC72 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC73 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC74 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC75 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC76 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC77 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC78 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC79 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC80 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC81 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC83 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC84 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC85 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC86 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC87 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC88 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC89 HRF8000-EA R CHIP 1/8 0 OHM 3216
JC90 HRF8000-EA R CHIP 1/8 0 OHM 3216
QC501 T2SA1037KB TR CHIP 2SA1037AKT146-R
QC503 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC504 T2SA1037KB TR CHIP 2SA1037AKT146-R
QC505 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC506 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC507 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC508 T2SC2412KB TR CHIP 2SC2412K-T146-BR
LOC PART CODE PART NAME PART DESCRIPTION
QC601 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC602 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC603 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC701 T2SA1037KB TR CHIP 2SA1037AKT146-R
QC702 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC703 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC704 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC705 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC805 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC809 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC901 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC902 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC904 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC906 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QC907 T2SA1037KB TR CHIP 2SA1037AKT146-R
QCP01 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QCP02 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QCP03 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QCP04 T2SC2412KB TR CHIP 2SC2412K-T146-BR
QCV01 T2SC2412KB TR CHIP 2SC2412K-T146-BR
RC102 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC103 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC104 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC301 HRFT682JCA R CHIP 1/10 6.8K OHM J 2012
RC303 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC304 HRFT913JCA R CHIP 1/10 91K OHM J 2012
RC305 HRFT273JCA R CHIP 1/10 27K OHM J 2012
RC307 HRFT123JCA R CHIP 1/10 12K OHM J 2012
RC308 HRFT183JCA R CHIP 1/10 18K OHM J 2012
RC309 HRFT623JCA R CHIP 1/10 62K OHM J 2012
RC404 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RC405 HRFT511JCA R CHIP 1/10 510 OHM J 2012
RC412 HRFT363JCA R CHIP 1/10 36K OHM J 2012
RC413 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RC415 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC416 HRFT203JCA R CHIP 1/10 20K OHM J 2012
RC417 HRFT822JCA R CHIP 1/10 8.2K OHM J 2012
RC420 HRFT562JCA R CHIP 1/10 5.6K OHM J 2012
RC422 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC423 HRFT244JCA R CHIP 1/10 240K OHM J 2012
RC424 HRFT823JCA R CHIP 1/10 82K OHM J 2012
RC425 HRFT752JCA R CHIP 1/10 7.5K OHM J 2012
RC426 HRFT479JCA R CHIP 1/10 4.7 OHM J 2012
RC428 HRFT393JCA R CHIP 1/10 39K OHM J 2012
RC429 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC432 HRFT362JCA R CHIP 1/10 3.6K OHM J 2012
RC433 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RC434 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC502 HRFT303JCA R CHIP 1/10 30K OHM J 2012
RC503 HRFT124JCA R CHIP 1/10 120K OHM J 2012
RC504 HRFT393JCA R CHIP 1/10 39K OHM J 2012
RC505 HRFT823JCA R CHIP 1/10 82K OHM J 2012
RC506 HRFT622JCA R CHIP 1/10 6.2K OHM J 2012
RC507 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RC508 HRFT824JCA R CHIP 1/10 820K OHM J 2012
RC510 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012
RC512 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC513 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RC514 HRFT183JCA R CHIP 1/10 18K OHM J 2012
RC515 HRFT333JCA R CHIP 1/10 33K OHM J 2012
RC516 HRFT363JCA R CHIP 1/10 36K OHM J 2012
RC517 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RC519 HRFT151JCA R CHIP 1/10 150 OHM J 2012
RC520 HRFT681JCA R CHIP 1/10 680 OHM J 2012
RC521 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RC522 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC523 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC524 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC525 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC526 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC528 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC529 HRFT684JCA R CHIP 1/10 680K OHM J 2012
RC530 HRFT394JCA R CHIP 1/10 390K OHM J 2012
RC532 HRFT561JCA R CHIP 1/10 560 OHM J 2012
RC533 HRFT564JCA R CHIP 1/10 560K OHM J 2012
RC535 HRFT304JCA R CHIP 1/10 300K OHM J 2012
RC537 HRFT000-CA R CHIP 1/10 0 OHM 2012
RC538 HRFT331JCA R CHIP 1/10 330 OHM J 2012
LOC PART CODE PART NAME PART DESCRIPTION
RC539 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RC540 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RC543 HRFT824JCA R CHIP 1/10 820K OHM J 2012
RC546 HRFT824JCA R CHIP 1/10 820K OHM J 2012
RC547 HRFT131JCA R CHIP 1/10 130 OHM J 2012
RC548 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC549 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC553 HRFT561JCA R CHIP 1/10 560 OHM J 2012
RC554 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC555 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC556 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC557 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC558 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC559 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC560 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC561 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC562 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC563 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC564 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC565 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC566 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC567 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC570 HRFT911JCA R CHIP 1/10 910 OHM J 2012
RC571 HRFT112JCA R CHIP 1/10 1.1K OHM J 2012
RC601 HRFT203JCA R CHIP 1/10 20K OHM J 2012
RC602 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC603 HRFT822FCA R CHIP 1/10 8.2K OHM F 2012
RC604 HRFT161FCA R CHIP 1/10 160 OHM F 2012
RC605 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC606 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC607 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC608 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC610 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC612 HRFT203JCA R CHIP 1/10 20K OHM J 2012
RC613 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC614 HRFT752JCA R CHIP 1/10 7.5K OHM J 2012
RC620 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC621 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC622 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC623 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC624 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC626 HRFT162JCA R CHIP 1/10 1.6K OHM J 2012
RC627 HRFT162JCA R CHIP 1/10 1.6K OHM J 2012
RC701 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC702 HRFT150JCA R CHIP 1/10 15 OHM J 2012
RC703 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC704 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC705 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC706 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC707 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC709 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC710 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC711 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC712 HRFT821JCA R CHIP 1/10 820 OHM J 2012
RC713 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC714 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC715 HRFT514JCA R CHIP 1/10 510K OHM J 2012
RC716 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RC717 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC718 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC719 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC720 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC721 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC722 HRFT105JCA R CHIP 1/10 1M OHM J 2012
RC723 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC725 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC726 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC727 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC728 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC729 HRFT623JCA R CHIP 1/10 62K OHM J 2012
RC730 HRFT163JCA R CHIP 1/10 16K OHM J 2012
RC731 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC732 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC733 HRFT131JCA R CHIP 1/10 130 OHM J 2012
RC734 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC735 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC736 HRFT131JCA R CHIP 1/10 130 OHM J 2012
RC737 HRFT102JCA R CHIP 1/10 1K OHM J 2012
LOC PART CODE PART NAME PART DESCRIPTION
RC738 HRFT131JCA R CHIP 1/10 130 OHM J 2012
RC745 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC746 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC747 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC819 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC820 HRFT434JCA R CHIP 1/10 430K OHM J 2012
RC822 HRFT684JCA R CHIP 1/10 680K OHM J 2012
RC830 HRFT303JCA R CHIP 1/10 30K OHM J 2012
RC832 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC833 HRFT431JCA R CHIP 1/10 430 OHM J 2012
RC834 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC842 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC901 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC903 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RC904 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RC905 HRFT181JCA R CHIP 1/10 180 OHM J 2012
RC906 HRFT121JCA R CHIP 1/10 120 OHM J 2012
RC909 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RC910 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RC911 HRFT181JCA R CHIP 1/10 180 OHM J 2012
RC912 HRFT121JCA R CHIP 1/10 120 OHM J 2012
RC915 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RC916 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RC917 HRFT181JCA R CHIP 1/10 180 OHM J 2012
RC918 HRFT121JCA R CHIP 1/10 120 OHM J 2012
RC919 HRFT561JCA R CHIP 1/10 560 OHM J 2012
RC920 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RC921 HRFT221JCA R CHIP 1/10 220 OHM J 2012
RCA01 HRFT474JCA R CHIP 1/10 470K OHM J 2012
RCA02 HRFT474JCA R CHIP 1/10 470K OHM J 2012
RCA03 HRFT300JCA R CHIP 1/10 30 OHM J 2012
RCA04 HRFT300JCA R CHIP 1/10 30 OHM J 2012
RCA05 HRFT224JCA R CHIP 1/10 220K OHM J 2012
RCA06 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RCA07 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RCA08 HRFT224JCA R CHIP 1/10 220K OHM J 2012
RCP01 HRFT301JCA R CHIP 1/10 300 OHM J 2012
RCP02 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RCP03 HRFT202JCA R CHIP 1/10 2K OHM J 2012
RCP04 HRFT824JCA R CHIP 1/10 820K OHM J 2012
RCP05 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RCP06 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RCP07 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RCP08 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RCP09 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RCP10 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RCP12 HRFT123JCA R CHIP 1/10 12K OHM J 2012
RCP13 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RCP14 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCP15 HRFT202JCA R CHIP 1/10 2K OHM J 2012
RCP16 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCP17 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RCP18 HRFT202JCA R CHIP 1/10 2K OHM J 2012
RCP19 HRFT202JCA R CHIP 1/10 2K OHM J 2012
RCP20 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RCP21 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RCP22 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCP23 HRFT511JCA R CHIP 1/10 510 OHM J 2012
RCP24 HRFT304JCA R CHIP 1/10 300K OHM J 2012
RCP25 HRFT304JCA R CHIP 1/10 300K OHM J 2012
RCP26 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCP40 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCP41 HRFT681JCA R CHIP 1/10 680 OHM J 2012
RCV01 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RCV02 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RCV03 HRFT680JCA R CHIP 1/10 68 OHM J 2012
RCV05 HRFT512JCA R CHIP 1/10 5.1K OHM J 2012
RCV06 HRFT302JCA R CHIP 1/10 3K OHM J 2012
RCV07 HRFT100JCA R CHIP 1/10 10 OHM J 2012
ZZ200 PTMPJ0J752 PCB MAIN (RHU) AS DTQ-29G4FS
C104 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C311 CEXF1V471V C ELECTRO 35V RSS 470MF (10X20) TP
C409 CEXF2E479V C ELECTRO 250V RSS 4.7MF (10X16)TP
C413 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C415 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C419 CMXE2D683J C MYLAR 200V PU 0.068MF J (TP)
C503 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C525 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
LOC PART CODE PART NAME PART DESCRIPTION
C614 CEXF1V102V C ELECTRO 35V RSS 1000MF (13X25) TP
C615 CEXF1V102V C ELECTRO 35V RSS 1000MF (13X25) TP
C803 CH1BEE472M C CERA AC U/C/V 2.5KV 4700PF TP
C804 CH1BEE472M C CERA AC U/C/V 2.5KV 4700PF TP
C811 CBXB3D471K C CERA SEMI 2KV BL(N) 470PF K (T)
C823 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C828 CEXF2C101C C ELECTRO 160V RUS 100MF (16X25) TP
C908 CCXB3D102K C CERA 2KV B 1000PF K (TAPPING)
ZZ200 PTMPJBJ752 PCB MAIN M-10 AS DTQ-29G4FS
10 2TM18006BE TAPE MASKING 6.2X500
E001 4856310600 EYE LET BSR T0.2 (R2.3)
E002 4856310300 EYE LET BSR T0.2 (R1.6)
E003 4856310600 EYE LET BSR T0.2 (R2.3)
E004 4856310600 EYE LET BSR T0.2 (R2.3)
E005 4856310600 EYE LET BSR T0.2 (R2.3)
E006 4856310600 EYE LET BSR T0.2 (R2.3)
E007 4856310600 EYE LET BSR T0.2 (R2.3)
E008 4856310600 EYE LET BSR T0.2 (R2.3)
E009 4856310600 EYE LET BSR T0.2 (R2.3)
E010 4856310600 EYE LET BSR T0.2 (R2.3)
E011 4856310300 EYE LET BSR T0.2 (R1.6)
E012 4856310600 EYE LET BSR T0.2 (R2.3)
E013 4856310600 EYE LET BSR T0.2 (R2.3)
E014 4856310600 EYE LET BSR T0.2 (R2.3)
E015 4856310600 EYE LET BSR T0.2 (R2.3)
E016 4856310600 EYE LET BSR T0.2 (R2.3)
E017 4856310600 EYE LET BSR T0.2 (R2.3)
E018 4856310600 EYE LET BSR T0.2 (R2.3)
E019 4856310600 EYE LET BSR T0.2 (R2.3)
E020 4856310600 EYE LET BSR T0.2 (R2.3)
E021 4856310600 EYE LET BSR T0.2 (R2.3)
E022 4856310300 EYE LET BSR T0.2 (R1.6)
E023 4856310300 EYE LET BSR T0.2 (R1.6)
E024 4856310300 EYE LET BSR T0.2 (R1.6)
E025 4856310600 EYE LET BSR T0.2 (R2.3)
E026 4856310300 EYE LET BSR T0.2 (R1.6)
E027 4856310300 EYE LET BSR T0.2 (R1.6)
E028 4856310300 EYE LET BSR T0.2 (R1.6)
E029 4856310300 EYE LET BSR T0.2 (R1.6)
E030 4856310600 EYE LET BSR T0.2 (R2.3)
E031 4856310300 EYE LET BSR T0.2 (R1.6)
E032 4856310300 EYE LET BSR T0.2 (R1.6)
E033 4856310600 EYE LET BSR T0.2 (R2.3)
E034 4856310600 EYE LET BSR T0.2 (R2.3)
E035 4856310600 EYE LET BSR T0.2 (R2.3)
E036 4856310300 EYE LET BSR T0.2 (R1.6)
E037 4856310300 EYE LET BSR T0.2 (R1.6)
E038 4856310300 EYE LET BSR T0.2 (R1.6)
E039 4856310300 EYE LET BSR T0.2 (R1.6)
E040 4856310300 EYE LET BSR T0.2 (R1.6)
E041 4856310300 EYE LET BSR T0.2 (R1.6)
E042 4856310300 EYE LET BSR T0.2 (R1.6)
E043 4856310300 EYE LET BSR T0.2 (R1.6)
E044 4856310300 EYE LET BSR T0.2 (R1.6)
E045 4856310300 EYE LET BSR T0.2 (R1.6)
E046 4856310300 EYE LET BSR T0.2 (R1.6)
E047 4856310300 EYE LET BSR T0.2 (R1.6)
E049 4856310300 EYE LET BSR T0.2 (R1.6)
E050 4856310600 EYE LET BSR T0.2 (R2.3)
E051 4856310300 EYE LET BSR T0.2 (R1.6)
E052 4856310600 EYE LET BSR T0.2 (R2.3)
E053 4856310300 EYE LET BSR T0.2 (R1.6)
E054 4856310600 EYE LET BSR T0.2 (R2.3)
E055 4856310600 EYE LET BSR T0.2 (R2.3)
E056 4856310300 EYE LET BSR T0.2 (R1.6)
E057 4856310600 EYE LET BSR T0.2 (R2.3)
E058 4856310600 EYE LET BSR T0.2 (R2.3)
E059 4856310600 EYE LET BSR T0.2 (R2.3)
E060 4856310600 EYE LET BSR T0.2 (R2.3)
N001 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N002 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N003 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N004 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N006 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N007 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
P101 485923522S CONN WAFER YW025-09 (STICK)
P102 485923162S CONN WAFER YW025-03 (STICK)
P601 485923172S CONN WAFER YW025-04 (STICK)
LOC PART CODE PART NAME PART DESCRIPTION
P907 485923192S CONN WAFER YW025-06 (STICK)
P908 485923522S CONN WAFER YW025-09 (STICK)
PA901 485923162S CONN WAFER YW025-03 (STICK)
PA902 485923182S CONN WAFER YW025-05 (STICK)
R302 RS02Z109JS R M-OXIDE FILM 2W 1 OHM J SMALL
R306 RS02Z109JS R M-OXIDE FILM 2W 1 OHM J SMALL
R314 RS02Z620JS R M-OXIDE FILM 2W 62 OHM J SMALL
R315 RS02Z561JS R M-OXIDE FILM 2W 560 OHM J SMALL
R316 RF01Z229J- R FUSIBLE 1W 2.2 OHM J (TAPPING)
R407 RF01Z100J- R FUSIBLE 1W 10 OHM J (TAPPING)
R408 RF01Z241J- R FUSIBLE 1W 240 OHM J (TAPPING)
R409 RF01Z399J- R FUSIBLE 1W 3.9 OHM J (TAPPING)
R415 RS02Z103JS R M-OXIDE FILM 2W 10K OHM J SMALL
R430 RS02Z102JS R M-OXIDE FILM 2W 1K OHM J SMALL
R435 RS02Z100JS R M-OXIDE FILM 2W 10 OHM J SMALL
R601 RS02Z209JS R M-OXIDE FILM 2W 2 OHM J SMALL
R602 RS02Z209JS R M-OXIDE FILM 2W 2 OHM J SMALL
R810 RF01Z228K- R FUSIBLE 1W 0.22 OHM K (TAPPING)
R817 RF01Z518K- R FUSIBLE 1W 0.51 OHM K (TAPPING)
R818 RF01Z518K- R FUSIBLE 1W 0.51 OHM K (TAPPING)
R836 RS02Z279JS R M-OXIDE FILM 2W 2.7 OHM J SMALL
R902 RS02Z123JS R M-OXIDE FILM 2W 12K 0HM J SMALL
R908 RS02Z123JS R M-OXIDE FILM 2W 12K 0HM J SMALL
R914 RS02Z123JS R M-OXIDE FILM 2W 12K 0HM J SMALL
ZZ200 PTMPJRJ752 PCB MAIN RADIAL AS DTQ-29G4FS
C101 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C105 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C107 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C301 CMXB1H103J C MYLAR 50V EU 0.01MF J (TP)
C303 CEXF1H101V C ELECTRO 50V RSS 100MF (8X11.5) TP
C304 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
C305 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C306 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C308 CMXB1H473J C MYLAR 50V 0.047MF J (TP)
C309 CXSL2H100D C CERA 500V SL 10PF D (TAPPING)
C310 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C312 CEXD1H109Q C ELECTRO 50V RT 1MF (6.3X11) TP
C402 CEXF2C109V C ELECTRO 160V RSS 1MF (6.3X11) TP
C403 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C408 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C410 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C411 CEXF2C109V C ELECTRO 160V RSS 1MF (6.3X11) TP
C412 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C414 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C417 CMXB1H104J C MYLAR 50V EU 0.1MF J (TP)
C418 CMXB1H104J C MYLAR 50V EU 0.1MF J (TP)
C421 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C506 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C507 CMXB1H473J C MYLAR 50V 0.047MF J (TP)
C509 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C513 CEXF1H228V C ELECTRO 50V RSS 0.22MF (5X11) TP
C514 CEXF1H228V C ELECTRO 50V RSS 0.22MF (5X11) TP
C515 CEXF1H108V C ELECTRO 50V RSS 0.1MF (5X11) TP
C517 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C519 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C523 CEXF1H339V C ELECTRO 50V RSS 3.3MF (5X11) TP
C527 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C528 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C534 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C536 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C537 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C541 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C542 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
C544 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C545 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C547 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
C549 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C550 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C552 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C601 CMXL1J154J C MYLAR 63V MEU 0.15MF J
C605 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C610 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C611 CMXB1H473J C MYLAR 50V 0.047MF J (TP)
C613 CMXB1H104J C MYLAR 50V EU 0.1MF J (TP)
C616 CMXL1J154J C MYLAR 63V MEU 0.15MF J
C617 CMXB1H104J C MYLAR 50V EU 0.1MF J (TP)
C618 CMXB1H104J C MYLAR 50V EU 0.1MF J (TP)
C619 CMXB1H153J C MYLAR 50V EU 0.015MF J (TP)
LOC PART CODE PART NAME PART DESCRIPTION
C620 CMXB1H153J C MYLAR 50V EU 0.015MF J (TP)
C621 CMXB1H103J C MYLAR 50V EU 0.01MF J (TP)
C622 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C623 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C624 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C625 CMXB1H103J C MYLAR 50V EU 0.01MF J (TP)
C626 CMXL1J474J C MYLAR 63V MEU 0.47MF J
C627 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
C628 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C629 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C630 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C633 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C637 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C706 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
C805 CEXF2A479V C ELECTRO 100V RSS 4.7MF (5X11) TP
C806 CEXF1H470C C ELECTRO 50V RUS 47MF (6.3X11) TP
C810 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C817 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C818 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C820 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C824 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C833 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C834 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C835 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
CA01 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CA02 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
CA03 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CA04 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CP04 CMXL1J154J C MYLAR 63V MEU 0.15MF J
CP05 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
CP22 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CP37 CEXF1H108V C ELECTRO 50V RSS 0.1MF (5X11) TP
CP38 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CP39 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CP40 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CP42 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CV01 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
CV02 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
CV03 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
CV04 CEXF1C331V C ELECTRO 16V RSS 330MF (8X11.5) TP
CV06 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
F801A 4857415001 CLIP FUSE PFC5000-0702
F801B 4857415001 CLIP FUSE PFC5000-0702
ID01 1UPC574J-- IC UPC574J
L602 58C0000116 COIL BEAD HC-3550R
L603 58C0000116 COIL BEAD HC-3550R
L604 58C0000096 COIL CHOKE 610G0233(470K)
L803 58C0000116 COIL BEAD HC-3550R
L806 58C0000116 COIL BEAD HC-3550R
L808 58C0000116 COIL BEAD HC-3550R
Q403 TKTC3207-- TR KTC3207 (TP)
Q404 TKTC3198Y- TR KTC3198Y
Q405 TKTA1266Y- TR KTA1266Y (TP)
Q601 TKTC3198Y- TR KTC3198Y
Q801 TKSA1013Y- TR KSA1013Y (TP)
Q806 TKTC3205Y- TR KTC3205Y (TP)
R106 RN02B473JS R METAL FILM 2W 47K OHM J SMALL
R108 RN02B360JS R METAL FILM 2W 36 OHM J SMALL
R109 RN02B360JS R METAL FILM 2W 36 OHM J SMALL
R110 RN02B391JS R METAL FILM 2W 390 OHM J SMALL
R312 RN02B221JS R METAL FILM 2W 220 OHM J SMALL
R805 RN02B473JS R METAL FILM 2W 47K OHM J SMALL
R807 RN02B752JS R METAL FILM 2W 7.5K OHM J SMALL
R808 RN02B222JS R METAL FILM 2W 2.2K OHM J SMALL
R830 RN01B301JS R METAL FILM 1W 300 OHM J SMALL
R834 RN02B200JS R METAL FILM 2W 20 OHM J SMALL
R835 RN02B200JS R METAL FILM 2W 20 OHM J SMALL
R838 RN02B100JS R METAL FILM 2W 10 OHM J SMALL
R839 RN02B470JS R METAL FILM 2W 47 OHM J SMALL
RV401 RV5426203P R SEMI FIXED EVN-DJA A03 20K OHM B
RV402 RV5426203P R SEMI FIXED EVN-DJA A03 20K OHM B
X501 5XEX3R579C CRYSTAL QUARTZ HC-49U 3.579545M (TP)
Z501 5PXLT4R5MH FILTER CERA LT 4.5MH
ZZ200 PTMPJAJ752 PCB MAIN AXIAL AS DTQ-29G4FS
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M
A001 4859814292 PCB MAIN 330X246
C555 CCZF1H103Z C CERA 50V F 0.01MF Z
LOC PART CODE PART NAME PART DESCRIPTION
C556 CCZF1H103Z C CERA 50V F 0.01MF Z
D101 DUZ9R1BM-- DIODE ZENER UZ-9.1BM
D102 DUZ5R6BM-- DIODE ZENER UZ-5.6BM
D301 D1N4004S-- DIODE 1N4004S
D302 D1N4937G-- DIODE 1N4937G (TAPPING)
D403 D1N4148--- DIODE 1N4148 (TAPPING)
D404 D1N4937G-- DIODE 1N4937G (TAPPING)
D405 D1N4937G-- DIODE 1N4937G (TAPPING)
D407 DRGP15J--- DIODE RGP15J
D501 DUZ9R1BM-- DIODE ZENER UZ-9.1BM
D504 D1N4148--- DIODE 1N4148 (TAPPING)
D505 D1N4148--- DIODE 1N4148 (TAPPING)
D602 D1N4148--- DIODE 1N4148 (TAPPING)
D605 D1N4148--- DIODE 1N4148 (TAPPING)
D701 DUZ3R9B--- DIODE ZENER UZ-3.9B
D702 D1N4148--- DIODE 1N4148 (TAPPING)
D802 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
D803 DRGP15J--- DIODE RGP15J
D805 DRGP15J--- DIODE RGP15J
D809 DRGP15J--- DIODE RGP15J
D810 D1N4148--- DIODE 1N4148 (TAPPING)
D812 D1N4148--- DIODE 1N4148 (TAPPING)
D813 DUZ9R1BM-- DIODE ZENER UZ-9.1BM
D814 D1N4148--- DIODE 1N4148 (TAPPING)
D815 DUZ7R5BM-- DIODE ZENER UZ-7.5BM
D816 DRGP15J--- DIODE RGP15J
D818 D1N4148--- DIODE 1N4148 (TAPPING)
D819 D1N4148--- DIODE 1N4148 (TAPPING)
J001~017 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J018 RD-4Z473J- R CARBON FILM 1/4 47K OHM J
J021~227 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
L405 5MC0000100 COIL BEAD HC-3550
L501 5CPZ560K02 COIL PEAKING 56UH K (AXIAL 3.5MM)
L505 5CPZ560K03 COIL PEAKING 56UH K (AXIAL 7MM)
L506 5CPZ560K03 COIL PEAKING 56UH K (AXIAL 7MM)
L508 5CPZ180K02 COIL PEAKING 18UH K (AXIAL 3.5MM)
L601 5CPZ560K02 COIL PEAKING 56UH K (AXIAL 3.5MM)
L701 5CPZ560K03 COIL PEAKING 56UH K (AXIAL 7MM)
L802 5MC0000100 COIL BEAD HC-3550
L804 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
L901 5CPZ101K04 COIL PEAKING 100UH K (AXIAL 10.5MM)
LP01 5CPZ229M02 COIL PEAKING 2.2UH M (AXIAL 3.5MM)
LP02 5CPZ159M02 COIL PEAKING 1.5UH 3.5MM M (LAL02TB)
LP03 5CPZ150K02 COIL PEAKING 15UH K (AXIAL 3.5MM)
LP04 5CPZ560K03 COIL PEAKING 56UH K (AXIAL 7MM)
LP05 5CPZ560K03 COIL PEAKING 56UH K (AXIAL 7MM)
R406 RD-2Z472J- R CARBON FILM 1/2 4.7K OHM J
R410 RD-4Z100J- R CARBON FILM 1/4 10 OHM J
R411 RD-4Z684J- R CARBON FILM 1/4 680K OHM J
R437 RD-4Z330J- R CARBON FILM 1/4 33 OHM J
R501 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R537 RD-AZ303J- R CARBON FILM 1/6 30K OHM J
R617 RD-AZ752J- R CARBON FILM 1/6 7.5K OHM J
R629 RD-4Z471J- R CARBON FILM 1/4 470 OHM J
R630 RD-4Z229J- R CARBON FILM 1/4 2.2 OHM J
R640 RD-4Z229J- R CARBON FILM 1/4 2.2 OHM J
R724 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R742 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R801 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
R814 RD-4Z241J- R CARBON FILM 1/4 240 OHM J
R820 RD-AZ681J- R CARBON FILM 1/6 680 OHM J
R831 RD-4Z271J- R CARBON FILM 1/4 270 OHM J
R843 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R844 RC-2Z565KP R CARBON COMP 1/2 5.6M OHM K
R901 RD-2Z202J- R CARBON FILM 1/2 2K OHM J
R907 RD-2Z202J- R CARBON FILM 1/2 2K OHM J
R913 RD-2Z202J- R CARBON FILM 1/2 2K OHM J
RV04 RD-4Z201J- R CARBON FILM 1/4 200 OHM J
CN207a.sch-1 - Fri Oct 20 09:14:42 2000
Loading...
