Daewoo DTL-2950 User Manual
GB
Colour Television
MANUAL INSTRUCTION
DMP3957100
DTL-2950
A1
A2
A17
A19
A20
A21
A18
A25
A24
A22
A4
A15
A26
A3
A5
A16
A14
A13
A11
A8
A9
A23
A12
A10
A7
A6
2
CONTENTS
REMOTE CONTROL & TV CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
START UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CONNECTING EXTERNAL EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . 5
DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
MENUS DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
TELETEXT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
REMOTE CONTROL & TV CONNECTIONS
REMOTE CONTROL UNIT
TELETEXT mode
A1 POWER
A2 SOUND MUTE
A3 NUMBER 0..9
A4 .
A5 .
A6 PAGE UP
A7 VOL/BRIGHT DOWN
A8 CANCEL
A9 PAGE HOLD
A10 SUBPAGE
A11 RED
A12 GREEN
A13 .
A14 .
A15 .
A16 .
A17 .
A18 INDEX
A19 VOL/BRIGHT UP
MENU SELECTION
A20 VOL/BRIGHT
A21 PAGE DOWN
A22 TELETEXT TV
A23 HEIGHT
A24 REVEAL
A25 CYAN
A26 YELLOW
TV mode
A1 POWER
A2 SOUND MUTE
A3 NUMBER 0..9
A4 SLEEP
A5 TV / AV
A6 PROGRAM UP
(CURSOR UP)
A7 VOLUME DOWN
(CURSOR LEFT)
A8 .
A9 .
A10 .
A11 SKIP
A12 MOVE
A13 3D(SOUND EFFECT)
A14 MODE
A15 ZOOM
A16 RECALL
A17 NORMAL
A18 OK/PRESET
A19 MENU
A20 VOLUME UP
(CURSOR RIGHT)
A21 PROGRAM DOWN
(CURSOR DOWN)
A22 TV TELETEXT
A23 .
A24 .
A25 .
A26 DELETE
B5
B6
B7
B8
B9
B10
B11
B12
C1
C2 C3
3
IMPORTANT SAFEGUARDS
Front
B1 MAIN POWER button
B2 STAND-BY indicator
B3 REMOTE sensor
B4 POWER indicator
B5 PROGRAM UP/DOWN buttons
B6 VOLUME UP/DOWN buttons
B7 TV / AV button
B8 MENU button
B9 SIDE VIDEO INPUT socket
B10 SIDE AUDIO INPUT (L + R) socket
B11 SIDE PANEL S-VIDEO jack
B12 HEADPHONE socket
Rear
C1 AERIAL jack
C2 SCART 1 socket
C3 SCART 2 socket
LOCAL CONTROL
WATER AND MOISTURE
The apparatus shall not be exposed to dripping or splashing water and no object filled with liquids, such as vases , should be
placed on the apparatus.
HEAT
Never place the set near heat sources.
Never put a naked flame, such as a candle, on the top of TV set.
B1 B2 B3 B4
Side
4
VENTILATION
Do not cover the ventilation openings in the cabinet and never place the set in a confined space such as in a bookcase
or built-in cabinet unless proper ventilation is provided. Leave a minimum 10 cm gap all around the unit.
OBJECT ENTRY
Do not insert foreign objects, such as needles and coins, in the ventilation openings.
LIGHTNING STRIKE
You should disconnect the set from the mains and the aerial system during thunderstorms.
CLEANING
Unplug the set from the mains while cleaning.
AFTER MOVING THE SET
If the set is moved or turned, the MAIN POWER button must be switched off for at least 15 minutes
in order to take out colour patches on the screen.
DISPOSAL OF USED ELECTRICAL & ELECTRONIC EQUIPMENT
The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household
waste. Please, dispose of this equipment at your applicable collection point for the recycling of electrical & electronic equipments
waste. In the European Union and Other European countries which there are separate collection systems for used electrical and
electronic product. By ensuring the correct disposal of this product, you will help prevent potentially hazardous to the environment
and to human health, which could otherwise be caused by unsuitable waste handling of this product. The recycling of materials
will help conserve natural resources. Please do not therefore dispose of your old electrical and electronic equipment with your
household waste. For more detailed information about recycling of this product, please contact your local city office, your household
waste disposal service or the shop where you purchased the product.
INSTALLATION
Open remote control battery compart-
ment (at the rear) and insert two 1.5V
type AAA batteries. Warning: be careful
to respect battery polarities.
Insert the main plug into a 230V 50Hz AC
power socket.
Connect aerial to aerial jack (C1).
SWITCHING ON AND OFF
Power on the TV set using front panel MAIN POWER button (B1).
Select your preferred language from the LANGUAGE menu (see section START UP on
page 5).
Press the remote control MENU button (A19) to enter the main menu.
Select Install menu to tune and memorise TV programs.
Batteries
5
The very first time that you turn on the TV, the LANGUAGE menu will appear on the screen. Its purpose is to enable you to select the language that will be
used for all the OSD (On Screen Display) menus. The user must enter a choice of language before proceeding further.
The language entered at this stage can still be modified at any later time, by entering the LANGUAGE menu (accessed from the FEATURES menu: see later
section under MENU DESCRIPTION).
The descriptions used in the menu are those of the country code (e.g. GB = English, NL = Holland etc).
START UP
LANGUAGE MENU
AUTOMATIC TUNING
CONNECTING EXTERNAL EQUIPMENT
The rear Scart1 (C2), Scart2 (C3) sockets, the side AV socket (B9) (B10), and the S-VIDEO socket (B11) are three dedicated sockets to con-
nect audio-video equipment.
Rear
REAR SCART 1 SOCKET (AV1)
This socket (C2) has video / audio inputs and outputs. It is recommended to
connect to this socket automatic AV switching equipment such as pay-TV de-
coders, video games, DVD players and most VCR’s.
In most cases, when connecting powered equipment to this socket, the TV set
switches automatically to AV mode. If not, then use the TV/AV buttons (A5) or
(B7) to select AV1.
REAR SCART 2 SOCKET (AV2)
This socket (C3) has video / audio inputs and outputs. Automatic AV switching
equipment(for example most VCR’s) can be connected to this socket.
In most cases, when connecting powered equipment to this socket, the TV set
switches automatically to AV mode. If not, then use the TV/AV buttons (A5) or
(B7) to select AV2.
You can also receive an S-VIDEO signal with REAR SCART2 socket, by selecting
S-VIDEO2 with the TV / AV buttons (A5) or (B7).
VCR / DVD / Video Game / Pay-TV decoder Important:
If your video equipment does not have SCART socket(s), or if you wish
to use only the aerial (RF) connection (not recommended), then you
should make use of PR 00 on the TV set for best performance.
Automatic Tuning System
If you have a satellite decoder: If your decoder is connected to the TV set by the aerial jack (C1), you must power on the demodulator and tune
Sky News before starting ATSS .
ATSS = Automatic Tuning and Sorting System. To start the ATSS function:
- Select „ATSS „ function.
- Adjust to the required country.
- Press and hold the OK button (A18) to start the automatic tuning.
The ATSS function has started when the phrase „Please Wait !” appears (in red characters ) in the help instructions box, below the Install menu.
When the ATSS function is finished, the stored programs are displayed on screen using Edit menu presentation (to Exit tuning before automatic
tuning is finished, press the remote control MENU button (A19) ).
LANGUAGE
LANGUAGE
BG CZ D DK E
F FIN GB GR H
I N NL P PL
RO RUS S
Selection is made by use of the remote control CURSOR UP (A6) / CURSOR DOWN (A21) keys and CURSOR RIGHT (A20) / LEFT (A7) keys.
Once you are satisfied with your selection, push the OK button (A18) to confirm your choice. The choice will briefly highlight in red, after which the menu
will disappear.
Note : The languages shown are subject to modification without prior notice.
