Daewoo DLM-42U1 User Manual

48586701E101-R2

LCD TELEVISION

INSTRUCTION MANUAL

DLM-42U1(FH/FHM/GPB/GUB/UPB/UUB)

DLM-42U2(FH/FHM/GPB/GUB/UPB/UUB)

DLM-46U1(FH/FHM/GPB/GUB/UPB/UUB)

DLM-46U2(FH/FHM/GPB/GUB/UPB/UUB)

Caution

WARNING :

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE

THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION :

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral

triangle, is intended to alert the user to the presence of uninsulat-

ed “dangerous voltage” within the product’s enclosure that may

be of sufficient magnitude to constitute a risk electric shock.

The exclamation point within an equilateral triangle is intended to

alert the user to the presence of important operating and servic-

ing instructions in the literature accompanying the appliance.

Important

Safeguards

Please read the following safeguards for your TV and retain for future reference.

Always follow all warnings and instructions marked on the television.

1. Read, Retain and Follow All Instructions

Read all safety and operating instructions before operating the TV. Retain them safely

for future reference. Follow all operations and instructions accordingly.

2. Heed Warnings

Adhere to all warnings on the appliance and in the operating instructions.

3. Cleaning

Unplug the TV from the wall outlet before cleaning. Do not use liquid, abrasive, or aerosol cleaners.

Cleaners can permanently damage the cabinet and screen. Use a lightly dampened cloth for

cleaning.

4. Attachments and Equipment

Never add any attachment and/or equipment without approval of the manufacturer as such additions may

result in the risk of fire, electric shock or other personal injury.

5. Water and Moisture

The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,

such as vases, shall be placed on the apparatus.

6. Setting

Do not place this TV on an unstable cart, stand or table. Placing the TV on an unstable base can

cause the TV to fall, resulting in serious personal injuries as well as damage to the TV. Use only a

cart, stand, bracket or table recommended by the manufacturer or salesperson.

7. Ventilation

Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the TV and to

protect it from overheating. Do not cover the ventilations openings in the cabinet and never place the set in a confined

space such as built-in cabinet unless proper ventilation is provided. Leave a minimum 10 cm gap all around the unit.

8. Power Source

This TV should be operated only from the type of power source indicated on the marking label. If you are not

sure of the type of power supplied to your home, consult your appliance dealer or local power company.

9. Grounding or Polarization

This TV is equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This

plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into

the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete

outlet. Do not defeat the safety purpose of the polarized plug. A warning that an apparatus with CLASS I construction

shall be connected to a MAINS socket outlet with a protective earthing connection.

10. Power-Cord Protection

Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed

upon or against them, paying particular attention to cords at plugs, wall outlets, and the point

where they exit from the TV.

MAINS plug is used as the disconnect device, the disconnect device shall remain readily operable.

11. Lightning

For added protection for this TV during a lightning storm, or when it is left unattended and unused for long

periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent

damage to the TV due to lightning and power-line surges.

Important

Safeguards

12. Power Lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light

or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna

system, extreme care should be taken to keep from touching such power lines or circuits as contact with

them might be fatal.

13. Overloading

Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

14. Object and Liquid Entry

Never push objects of any kind into this TV through openings as they may touch dangerous voltage points or

short-out parts that could result in fire or electric shock. Never spill liquid of any kind on or into the TV.

15. Outdoor Antenna Grounding

If an outside antenna or cable system is connected to the TV, be

sure the antenna or cable system is grounded so as to provide

some protection against voltage surges and built-up static charges.

Section 810 of the National Electric Code, ANSI /NFPA No. 70-1984,

provides information with respect to proper grounding of the mast

and supporting structure, grounding of the lead in wire to an antenna

discharge unit, size of grounding conductors, location of

antenna discharge unit, connection to grounding electrodes, and

requirements for the grounding electrode.

16. Servicing

Do not attempt to service this TV yourself as opening or removing covers may expose you to dangerous

voltage or other hazards. Refer all servicing to qualified service personnel.

17. Damage Requiring Service

Unplug the TV from the wall outlet and refer servicing to qualified service personnel under the following conditions:

(a) When the power-supply cord or plug is damaged.

(b) If liquid has been spilled, or objects have fallen into the TV.

(d) If the TV does not operate normally by following the operating instructions. Adjust only those controls

that are covered by the operating instructions as an improper adjustment of other controls may result in

damage and will often require extensive work by a qualified technician to restore the TV to its normal operation.

(e) If the TV has been dropped or the cabinet has been damaged.

(f) When the TV exhibits a distinct change in performance - this indicates a need for service.

18. Replacement Parts

When replacement parts are required, be sure the service technician has used replacement parts specified

by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may

result in fire, electric shock or other hazards.

19. Safety Check

Upon completion of any service or repair to the TV, ask the service technician to perform safety checks to

determine that the TV is in safe operating condition.

20. Heat

The product should be situated away from heat sources such as radiators, heat registers, stoves, or

other products (including amplifiers) that produce heat.

21. Disconnection

Please place the TV set in such a way that the main plug can be easily disconnected.

ANTENNA

LEAD IN WIRE

ANTENNA

DISCHARGE UNIT

(NEC SECTION 810-20)

GROUNDING

CONDUCTORS

(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)

GROUND CLAMP

ELECTRIC

SERVICE

EQUIPMENT

NEC — NATIONAL ELECTRICAL CODE

EXAMPLE OF ANTENNA GROUNDING

Warning

This section must be read carefully and followed by the user prior to the operation of the product.

The manual states important instructions for the user's own safety, and the proper operation of the product.

In case of an accident, please unplug the unit from the outlet immediately.

Hold the plug when unplugging the unit

from the outlet. The cord may cause fire

or electric shock if damaged.

Do not cause the product to lean or put it in

an unstable place since it may cause a

serious injury to a person, as well as damage

to the product if it falls.

Do not put any object that contains water -

such as flowerpot - near to the unit.

The water may penetrate into the unit, and

be a cause of fire or hazardous electric

shock.

To reduce the risk of electric shock, do

not remove cover or back. No user -

serviceable parts inside. Refer to qualified

service personnel for repair.

Do not put on or use the product near water

and moisture-such as in a bathroom,

washbowl, etc. It may be a cause of fire and

electric shock hazards.

To prevent fire and damages to the product,

unplug the unit from the outlet during

lightning storm, or when it is left unattended

and unused for a long period of time.

Do not let children hang on or climb on

the product since it may be a cause of

serious injury.

Slots and openings in the case are provided

for ventilation to ensure reliable operation of

the product. Never put in any item-such as a

coin, paper, match- through these openings

since it may touch dangerous voltage points

that could result in fire or shock hazard.

Do not put volatile substance-such as

benzene, naphtha- near the product since it

may cause a change in the product's colour.

Do not view the TV too closely since it

may cause damage in your eyesight.

Do not spill water or drop the remote

controller since it may be a cause of

malfunctioning.

Refer servicing to qualified service

personnel for cleaning at least once a year

since dust inside the TV set may be a result

or fire and malfunctioning of the product.

Warning

This section must be read carefully and followed by the user prior to the operation of the product.

The manual states important instructions for the user's own safety, and the proper operation of the product.

Please keep the user's manual in a safe place for future reference.

The product should be situated away from

any heat source-such as radiators, heat

registers, stoves, or other products that

produce heat.

Do not put on any heavy item on the

power cord since it may result in fire or

hazardous electric shock if the cord is

damaged.

Do not cover the top of the television set.

Ventilation will be prevented, and it may

be a cause of fire if the product is

internally overheated.

Unplug the power from the outlet and all the

related connections from the unit to prevent

electric shock. At least two people must work

together to move the TV set when transporting

to prevent the TV from falling, and

consequently, any serious injury or damage.

Do not touch the power cord with

moisturized or wet hands when plugging

to or unplugging from the outlet since it

may be a cause of electric shock.

Please be advised of electric wires and cables

when installing the antenna. It may be a cause of

hazardous electric shock and fire if the antenna

touches or falls on the electric wire; thus, it must be

installed firmly, and far away from the cables.

Do not expose the product to a dusty or

moisturized place since it may be a cause

of malfunctioning.

The screen case of the product is

scratched easily.

When cleaning, use the micro fiber

sheet which enclosed.

When a force to give it cleans strongly,

it will be scratched and the product's

colour will be changed. If foreign

material gets in the fiber, the product

will be scratched. Shake off the fiber

cleanly and use.

Please place the TV set in such a way that

the main plug can be easily disconnected.

Table of

Contents

Installation and Maintenance

Antenna Connection 9

Video Connection 12

Camcorder & Video Game Connection 13

DVD Player Connection 14

STB(Set Top Box) Connection 14

PC Connection 15

Flash Memory Card Connection(Option) 17

Cable TV Broadcasting Connection 18

Connect with the Dolby Digital AMP 19

Name of Each Part 20

Basic Guide

Parts of the Remote Controller 22

Method To Use Basic Menu 24

To Watch TV 25

Setting Up TV Stations 27

Selection of AV and Multimedia Input Signal 31

Application Guide

Screen Adjustment 33

POP Mode 37

Sound Adjustment 38

Selection of Language 41

Adjustment of Time 42

Other Functions 44

MMP(Multimedia Player)(Option) 45

Teletext 52

Troubleshooting 53

Standard of Product 55

Supplied

Accessories

Make sure that the following accessories are provided with the product.

AC cord

Instruction manual

Remote controller

Batteries

AC cord

Indoor Antenna Connection

Not recommended unless very close to the transmitter

Not recommended unless very close to the transmitter.

1. Connect the feeder cable of the antenna to the combining adapter.

WHEN THE IMAGE IS NOT CLEAR : Unclear screen image and bad reception may be a cause of wrong

antenna connection. Be sure to check its direction and place when

installing.

INDOOR AERIAL

LEFT SIDE OF THE TV SET

Antenna

Connection

2. Connect the combining adapter to the antenna input at the left side of the TV set.

WHEN USING THE COMBINING ADAPTER : You may obtain the combining adapter at your closest

Service Center.

ANTENNA INPUT

Antenna

Connection

Antenna socket at the left side of the TV set

ANT/CABLE

CTV Antenna Connection

Such community TV Antenna installation may be found in most of co-op apartments.

When a coaxial cable is used : Plug the coaxial cable to the antenna socket, and fix it firmly by turning it to

the right.

Antenna

Connection

Outdoor Antenna Connection

Outdoor Antenna connection-such as VHF or/and UHF-may be necessary for installation at private houses

Single Antenna Connection

Separate Antenna Connection.

VHF Antenna

UHF Antenna

ANT/CABLE

LEFT SIDE OF THE TV SET

ANT/CABLE

Video

Connection

AV 2

S-VIDEOVIDEOR - AUDIO - L

Note : If S-video and RCA jack are connected the same time, The TV set will only detect the S-Video mode.

• If your AV device has both Video OUT terminal and S-Video OUT terminal, the S-Video connection is

recommended for better picture quality.

Connecting with an External Source

You may connect an S-Video input to enjoy clearer and brighter picture images. You can make the

connection with the AV2 input.

BACK OF THE TV SET

Camcorder & Video

Game Connection

Note : If S-video and RCA jack are connected at the same time, the TV set only detects the S-Video mode.

* If your AV device has both Video OUT terminal and S-Video OUT terminal, the S-Video connection is

recommended for better picture quality.

Watching a Camcorder Recording on TV or playing a Video Game

1. Prepare the S-video and RCA connector.

2. These connectors connect to S-video or AV2 as shown in the picture below.

3. Turn on the TV set and camcorder/video game.

Select AV2/S-video mode, using the

”AV/COMP/MMP”

button of the Remote controller or

“

”

button

of the TV set.

Video game

AV 2

S-VIDEOVIDEOR - AUDIO - L

BACK OF THE TV SET

DVD Player/STB(Set

Top Box) Connection

AV 2

S-VIDEOVIDEOR - AUDIO - L

BACK OF THE TV SET

Note :

If S-video and RCA jack are connected at the same time, the TV set will only detect the S-Video mode.

• If your AV device has both Video OUT terminal and S-Video OUT terminal, the S-Video connection is

recommended for better picture quality.

HDMI 1

INPUT

HDMI 2

INPUT

AV1

MONITOR OUT

PC INPUT PC AUDIO

VIDEOR - AUDIO - L

COMPONENT

Pr Pb Y

R L

OPTICAL UP-GRADE PORT

Set Top Box

BACK OF THE TV SET

When connecting with a S-VHS cable and RCA cable

When connecting with a component cable

Connection

HDMI 1

INPUT

HDMI 2

INPUT

AV1

MONITOR OUT

PC INPUT PC AUDIO

VIDEOR - AUDIO - L

COMPONENT

Pr Pb Y

R L

OPTICAL UP-GRADE PORT

1. First adjust resolution of the PC (640 x 480, 800 x 600, 1024 x 768, 1360 x 768, 1280 x 1024, 1920 x

1080).

2. Then disconnect your monitor from your PC and connect between PC and TV set using the D-sub and Audio

cable as shown in the picture below.

3. Turn on the PC and TV set.

4. Select PC mode by pressing “HDMI/PC” button on the remote control or

” ” button of the TV set.

HDMI 1

INPUT

HDMI 2

INPUT

AV1

MONITOR OUT

PC INPUT PC AUDIO

VIDEOR - AUDIO - L

COMPONENT

Pr Pb Y

R L

OPTICAL UP-GRADE PORT

1. First adjust resolution of the PC (640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1920 x 1080).

2. Then disconnect your monitor from your PC and connect between PC and TV set using the HDMI and Audio

cable as shown in the picture below, if necessary. See note below.

3. Turn on the PC and TV set.

4. select HDMI mode by pressing “HDMI/PC” button on the remote control or

” ” button of the TV set.

BACK OF THE TV SET

When connecting with PC(D-Sub) cable.

When connecting with a HDMI cable.

Note : If the graphic card of the PC only supports a DVI signal, you must connect the Audio cable as shown in the

picture above.

Connection

PC CONNECTION NOTES:

1) If there is a [Vertical Frequency] setting menu in the [Display] Menu of the PC, adjust the frequency to

60Hz.

2) If the PC resolution is too high, it may be hard to read letters. Select a suitable resolution.

3) HDMI input port receives only Digital Signals.

4) Depending on the graphic card when you plug & unplug the HDMI connection the screen may not display

correctly. Restart the computer if this happens.

Multi input resolution available in LCD TV(Full HD).

Resolution V-freq HDMI PC(D-Sub) Component Standard

640 X 480

60Hz o o x

75Hz o o x VESA Standard

800 X 600

60Hz o o x VESA Standard

75Hz o o x

1024 X 768

60Hz o o x VESA Standard

75Hz o o x VESA Standard

1280 x 1024

60Hz o o x VESA Standard

75Hz o o x VESA Standard

1360 x 768 60Hz x o x

480P 60Hz o x o

576P 50Hz o o o

720P

50Hz o x o

60Hz o o o

1080i

50Hz o x o

60Hz o o o

1920 X 1080

50Hz o o o

60Hz o o o

480i 60Hz x x o

576i 50Hz x x o

Note : • When you connect with component, D-Sub, and HDMI, you must check the input resolution of

external devices.

+ 39 hidden pages
