Daewoo AMI-829L, AMI-829LR Service Manual

P.C.B Pattern Layout

Model No:AMI-829L/R
Ass'y Name: MAIN

- 14 -

P.C.B Pattern Layout

Model No : AMI-829L/R
Ass'y Name : CD P.C.B

- 15 -

P.C.B Pattern Layout

Model No:AMI-829L/R
Ass'y Name: PT

- 16 -

P.C.B Pattern Layout

Model No:AMI-829L/R
Ass'y Name: CONTROL

- 17 -

PART-CODE PART-DESCNO ASS'Y LOCATION PART-NAME

18

Electrical Parts List

1 PCB MAIN AS 10000 PCB MAIN AS 9CDC057200AMI-829LF
2 PCB MAIN AS B000 PCB MAIN 9CD6580500330X197X1.6T
3 PCB MAIN AS CC001~004 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
4 PCB MAIN AS CC100 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
5 PCB MAIN AS CC101 C CERA CCXF1H104Z50V F 0.1MF Z
6 PCB MAIN AS CC102 C CERA CXCH1H180J50V CH 18PF J (TAPPING)
7 PCB MAIN AS CC103 C CERA CXCH1H470J50V CH 47PF J (TAPPING)
8 PCB MAIN AS CC200 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)

9 PCB MAIN AS CC201 C CERA CCXF1H473Z50V F 0.047MF Z (TAPPING)
10 PCB MAIN AS CC202 C CERA CCXF1H104Z50V F 0.1MF Z
11 PCB MAIN AS CC203 C CERA CCXF1H473Z50V F 0.047MF Z (TAPPING)
12 PCB MAIN AS CC204 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
13 PCB MAIN AS CC205 C CERA CCXF1H223Z50V F 0.022MF Z (TAPPING)
14 PCB MAIN AS CC206 C CERA CCXB1H821K50V B 820PF K (TAPPING)
15 PCB MAIN AS CC207 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
16 PCB MAIN AS CC209~211 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
17 PCB MAIN AS CC230 C CERA CXCH1H390J50V CH 39PF J (TAPPING)
18 PCB MAIN AS CC232 C CERA CXCH1H330J50V CH 33PF J (TAPPING)
19 PCB MAIN AS CC234~239 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
20 PCB MAIN AS CC260~262 C CERA CCXB1H331K50V B 330PF K (TAPPING)
21 PCB MAIN AS CC263 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
22 PCB MAIN AS CC264 C CERA CXCH1H820J50V CH 82PF J (TAPPING)
23 PCB MAIN AS CC265 C CERA CXCH1H470J50V CH 47PF J (TAPPING)
24 PCB MAIN AS CC266 C CERA CCXB1H331K50V B 330PF K (TAPPING)
25 PCB MAIN AS CC401 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
26 PCB MAIN AS CC430~431 C CERA CCXF1H104Z50V F 0.1MF Z
27 PCB MAIN AS CC432~434 C CERA CXCH1H101J50V CH 100PF J (TAPPING)
28 PCB MAIN AS CC435~440 C CERA CCXF1H104Z50V F 0.1MF Z
29 PCB MAIN AS CC441 C CERA CCXB1H472K50V B 4700PF K (TAPPING)
30 PCB MAIN AS CC442 C CERA CCXB1H122K50V B 1200PF K (TAPPING)
31 PCB MAIN AS CC443 C CERA CCXB1H222K50V B 2200PF K (TAPPING)
32 PCB MAIN AS CC444 C CERA CCXB1H562K50V B 5600PF K (TAPPING)
33 PCB MAIN AS CC445~446 C CERA CCXF1H104Z50V F 0.1MF Z
34 PCB MAIN AS CC447 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
35 PCB MAIN AS CC490~493 C CERA CXCH1H101J50V CH 100PF J (TAPPING)
36 PCB MAIN AS CC494 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
37 PCB MAIN AS CC600 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
38 PCB MAIN AS CC601 C CERA CCXF1H104Z50V F 0.1MF Z
39 PCB MAIN AS CC602 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
40 PCB MAIN AS CC603~604 C CERA CXCH1H470J50V CH 47PF J (TAPPING)
41 PCB MAIN AS CC609~611 C CERA CXCH1H101J50V CH 100PF J (TAPPING)
42 PCB MAIN AS CC612~615 C CERA CCXB1H221K50V B 220PF K (TAPPING)
43 PCB MAIN AS CC616~619 C CERA CCXB1H821K50V B 820PF K (TAPPING)
44 PCB MAIN AS CC620 C CERA CXCH1H101J50V CH 100PF J (TAPPING)
45 PCB MAIN AS CC621~622 C CERA CCXB1H331K50V B 330PF K (TAPPING)
46 PCB MAIN AS CC800~801 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
47 PCB MAIN AS CC804~805 C CERA CCXB1H221K50V B 220PF K (TAPPING)
48 PCB MAIN AS CC870~871 C CERA CCXF1H473Z50V F 0.047MF Z (TAPPING)
49 PCB MAIN AS CC872~873 C CERA CCXB1H221K50V B 220PF K (TAPPING)
50 PCB MAIN AS CC900~902 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
51 PCB MAIN AS CC904 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
52 PCB MAIN AS CC906 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
53 PCB MAIN AS CC908 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
54 PCB MAIN AS CE001 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
55 PCB MAIN AS CE201 C ELECTRO CEXF1H220V50V RSS 22MF (5X11) TP
56 PCB MAIN AS CE202~203 C ELECTRO CEXF1H100V50V RSS 10MF (5X11) TP
57 PCB MAIN AS CE205 C ELECTRO CEXF1H109V50V RSS 1MF (5X11) TP
58 PCB MAIN AS CE206 C ELECTRO CEXF1H478V50V RSS 0.47MF (5X11) TP
59 PCB MAIN AS CE207~208 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP
60 PCB MAIN AS CE209 C ELECTRO CEXF1H109V50V RSS 1MF (5X11) TP
61 PCB MAIN AS CE210 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
62 PCB MAIN AS CE230 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP
63 PCB MAIN AS CE231 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
64 PCB MAIN AS CE232 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP

PART-CODE PART-DESCNO ASS'Y LOCATION PART-NAME

19

Electrical Parts List

65 PCB MAIN AS CE260 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP
66 PCB MAIN AS CE261 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
67 PCB MAIN AS CE270 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
68 PCB MAIN AS CE271~272 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP
69 PCB MAIN AS CE400~402 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP
70 PCB MAIN AS CE404~406 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP
71 PCB MAIN AS CE408~411 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP
72 PCB MAIN AS CE412 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
73 PCB MAIN AS CE413 C ELECTRO CEXF1E101V25V RSS 100MF (6.3X11) TP
74 PCB MAIN AS CE414~415 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP
75 PCB MAIN AS CE430~431 C ELECTRO CEXF1H479V50V RSS 4.7MF (5X11) TP
76 PCB MAIN AS CE432~433 C ELECTRO CEXF1H100V50V RSS 10MF (5X11) TP
77 PCB MAIN AS CE434~435 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
78 PCB MAIN AS CE600~602 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
79 PCB MAIN AS CE603 C ELECTRO CEXF1H478V50V RSS 0.47MF (5X11) TP
80 PCB MAIN AS CE604 C ELECTRO CEXF1H109V50V RSS 1MF (5X11) TP
81 PCB MAIN AS CE605~606 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
82 PCB MAIN AS CE607 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP
83 PCB MAIN AS CE608 C ELECTRO CEXF1H109V50V RSS 1MF (5X11) TP
84 PCB MAIN AS CE609 C ELECTRO CEXF1H100V50V RSS 10MF (5X11) TP
85 PCB MAIN AS CE610~611 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP
86 PCB MAIN AS CE612~613 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
87 PCB MAIN AS CE614~615 C ELECTRO CEXF1H100V50V RSS 10MF (5X11) TP
88 PCB MAIN AS CE616~618 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
89 PCB MAIN AS CE619 C ELECTRO CEXF1H100V50V RSS 10MF (5X11) TP
90 PCB MAIN AS CE620 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
91 PCB MAIN AS CE800~801 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
92 PCB MAIN AS CE802 C ELECTRO CEXF1H100V50V RSS 10MF (5X11) TP
93 PCB MAIN AS CE803~804 C ELECTRO CEXF1H220V50V RSS 22MF (5X11) TP
94 PCB MAIN AS CE805~806 C ELECTRO CEXF1H470V50V RSS 47MF (6.3X11) TP
95 PCB MAIN AS CE807~808 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP
96 PCB MAIN AS CE870~871 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
97 PCB MAIN AS CE872~873 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP
98 PCB MAIN AS CE900~902 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
99 PCB MAIN AS CE903 C ELECTRO CEXF1H101V50V RSS 100MF (8X11.5) TP

100PCB MAIN AS CE904~905 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
101PCB MAIN AS CE906 C ELECTRO CEXF1H101V50V RSS 100MF (8X11.5) TP
102PCB MAIN AS CE907~908 C ELECTRO CEYF1E222V25V RSS 2200MF (16X25)
103PCB MAIN AS CE910 C ELECTRO CEXF1H101V50V RSS 100MF (8X11.5) TP
104PCB MAIN AS CE913~914 C ELECTRO CEYF1V332V35V RSS 3300MF (18X35.5)
105PCB MAIN AS CF001~002 FILTER CERA 5PE107MJA-SFE 10.7MHZ RED
106PCB MAIN AS CF200 FILTER 5PPCFAZ077PCFAZ077
107PCB MAIN AS CM200~201C MYLAR CMXM1H153J50V 0.015MF J (TP)
108PCB MAIN AS CM270~271C MYLAR CMXM1H103J50V 0.01MF J (TP)
109PCB MAIN AS CM400~403C MYLAR CMXM1H104J50V 0.1MF J
110PCB MAIN AS CM404~405C MYLAR CMXM1H562J50V 5600 PF J
111PCB MAIN AS CM600~601C MYLAR CMXM1H683J50V 0.068 MF J
112PCB MAIN AS CM602 C MYLAR CMXM1H103J50V 0.01MF J (TP)
113PCB MAIN AS CM603 C MYLAR CMXM1H332J50V 3300 PF J
114PCB MAIN AS CM605 C MYLAR CMXM1H392J50V 0.0039MF J
115PCB MAIN AS CM606~607C MYLAR CMXM1H123J50V 0.012 MF J
116PCB MAIN AS CM608 C MYLAR CMXM1H102J50V 0.001MF J (TP)
117PCB MAIN AS CM609~610C MYLAR CMXM1H682J50V 0.0068MF J
118PCB MAIN AS CM611~612C MYLAR CMXM1H223J50V 0.022MF J
119PCB MAIN AS CM613 C MYLAR CMXM1H102J50V 0.001MF J (TP)
120PCB MAIN AS CM800~801C MYLAR CMXM1H472J50V 0.0047MF J
121PCB MAIN AS CM802~803C MYLAR CMXM1H104J50V 0.1MF J
122PCB MAIN AS CM808~809C MYLAR CMXM1H392J50V 0.0039MF J
123PCB MAIN AS CM900~903C MYLAR CMXM1H104J50V 0.1MF J
124PCB MAIN AS CM904~906C MYLAR CMXM1H103J50V 0.01MF J (TP)
125PCB MAIN AS CN400 CONN AS 9736407600PIN BASE 53095-1310 13P
126PCB MAIN AS CN401 CONN PIN 973640780053095-1010 10PIN ANGLE
127PCB MAIN AS CN900 CONN WAFER 9728804100#22 10P P2.5 350 BOARD-IN
128PCB MAIN AS CW100 CONN WAFER 9CD62588002P S2B-XH-A

PART-CODE PART-DESCNO ASS'Y LOCATION PART-NAME

20

Electrical Parts List

129PCB MAIN AS CW400 CONN AS 97388321018P 250 P=2.5 BOARDIN
130PCB MAIN AS CW509 CONN AS 97388321018P 250 P=2.5 BOARDIN
131PCB MAIN AS CW600 CONN AS 9738833700#26 8P FLAT 220MM
132PCB MAIN AS CW601 CONN AS 9738835000UL 2851 #28X2C0 3P 260MM
133PCB MAIN AS CW602 CONN AS 9728804300#26 7P SHIELD 350MM
134PCB MAIN AS D400 DIODE DZN4148---1N4148 AUTO 52MM
135PCB MAIN AS D800 DIODE D1N4001---1N4001
136PCB MAIN AS D801~802 DIODE DZN4148---1N4148 AUTO 52MM
137PCB MAIN AS D870 DIODE DZN4148---1N4148 AUTO 52MM
138PCB MAIN AS D900~901 DIODE D1N4001---1N4001
139PCB MAIN AS D902~905 DIODE DRL202----RL202
140PCB MAIN AS D910~913 DIODE D1N5402---1N5402
141PCB MAIN AS DZ430 DIODE ZENER DZTZ5R6B--UZ-5.6B
142PCB MAIN AS DZ900 DIODE ZENER DZTZ6R2B--MTZ6.2B
143PCB MAIN AS DZ901 DIODE ZENER DZTZ12B---MTZ 12V 26MM TAPPING
144PCB MAIN AS DZ902 DIODE ZENER DZTZ33B---MTZ-33B
145PCB MAIN AS IC200 IC 1LA1833N--LA1833N
146PCB MAIN AS IC201 IC 1MC78L05--MC78L05AC
147PCB MAIN AS IC230 IC PLL 1LC72131--LC72131
148PCB MAIN AS IC260 IC 1TDA7479D-TDA7479D
149PCB MAIN AS IC400 IC 1TDA7440--TDA7440
150PCB MAIN AS IC430 IC 1M65849BFPM65849BFP(DIP32)
151PCB MAIN AS IC600 IC PORT 1BU4094B--BU4094B
152PCB MAIN AS IC601 IC AMSS 1LA2000---LA2000
153PCB MAIN AS IC602 IC 1TA8189N--TA8189N
154PCB MAIN AS IC603 IC 1BA3126N--BA3126N
155PCB MAIN AS IC800~801 IC 1TDA7295--TDA7295
156PCB MAIN AS IC870 IC 1BA4560N--BA4560N(H/P AMP)
157PCB MAIN AS IC900 IC 1L4959----L4959
158PCB MAIN AS J001 JACK ANT 9736321900PAT645
159PCB MAIN AS J490 JACK RCA 9CD6313700S-436P
160PCB MAIN AS J800 JACK SPEAKER 9736320500CJ-9007-040
161PCB MAIN AS J801 JACK RCA 9CD6313700S-436P
162PCB MAIN AS J870 JACK HEADPHONE 9766319501HTJ-064-05B GOLD
163PCB MAIN AS JW100 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
164PCB MAIN AS JW101 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
165PCB MAIN AS JW102 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
166PCB MAIN AS JW103 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
167PCB MAIN AS JW105 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
168PCB MAIN AS JW106 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
169PCB MAIN AS JW107 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
170PCB MAIN AS JW108 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
171PCB MAIN AS JW109 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
172PCB MAIN AS JW110~111 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
173PCB MAIN AS JW112 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
174PCB MAIN AS JW115~118 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
175PCB MAIN AS JW119 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
176PCB MAIN AS JW120~121 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
177PCB MAIN AS JW122 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
178PCB MAIN AS JW124~125 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
179PCB MAIN AS JW126 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
180PCB MAIN AS JW127 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
181PCB MAIN AS JW128~130 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
182PCB MAIN AS JW131 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
183PCB MAIN AS JW132~135 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
184PCB MAIN AS JW137 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
185PCB MAIN AS JW138~139 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
186PCB MAIN AS JW140 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
187PCB MAIN AS JW142 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
188PCB MAIN AS JW400 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
189PCB MAIN AS JW401~402 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
190PCB MAIN AS JW403 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
191PCB MAIN AS JW404 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
192PCB MAIN AS JW405~406 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO

PART-CODE PART-DESCNO ASS'Y LOCATION PART-NAME

21

Electrical Parts List

193PCB MAIN AS JW407 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
194PCB MAIN AS JW408 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
195PCB MAIN AS JW409~412 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
196PCB MAIN AS JW413~419 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
197PCB MAIN AS JW420~422 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
198PCB MAIN AS JW427~428 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
199PCB MAIN AS JW429 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
200PCB MAIN AS JW430 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
201PCB MAIN AS JW431~432 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
202PCB MAIN AS JW433~437 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
203PCB MAIN AS JW440 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
204PCB MAIN AS JW442 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
205PCB MAIN AS JW443~444 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
206PCB MAIN AS JW450 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
207PCB MAIN AS JW451 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
208PCB MAIN AS JW454~455 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
209PCB MAIN AS JW600 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
210PCB MAIN AS JW601 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
211PCB MAIN AS JW602 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
212PCB MAIN AS JW603 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
213PCB MAIN AS JW604 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
214PCB MAIN AS JW605 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
215PCB MAIN AS JW606~610 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
216PCB MAIN AS JW611 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
217PCB MAIN AS JW612~618 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
218PCB MAIN AS JW619~620 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
219PCB MAIN AS JW621~623 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
220PCB MAIN AS JW625~627 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
221PCB MAIN AS JW629 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
222PCB MAIN AS JW631~637 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
223PCB MAIN AS JW639~643 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
224PCB MAIN AS JW644 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
225PCB MAIN AS JW800~801 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
226PCB MAIN AS JW802~803 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
227PCB MAIN AS JW812~818 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
228PCB MAIN AS JW820~822 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
229PCB MAIN AS JW831 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
230PCB MAIN AS JW832 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
231PCB MAIN AS JW833~835 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
232PCB MAIN AS JW836~837 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
233PCB MAIN AS JW838 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
234PCB MAIN AS JW901~902 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
235PCB MAIN AS JW903 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
236PCB MAIN AS JW904 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
237PCB MAIN AS JW905~906 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
238PCB MAIN AS JW908 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
239PCB MAIN AS JW909~910 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
240PCB MAIN AS JW911~912 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
241PCB MAIN AS JW915~918 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
242PCB MAIN AS JW921~922 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
243PCB MAIN AS L001 COIL PEAKING 5CPZ100K0210UH K (AXIAL 3.5MM)
244PCB MAIN AS L100 COIL MW BLOCK 5LR0000833KSNT-213M
245PCB MAIN AS L102 COIL PEAKING 5CPZ100K0210UH K (AXIAL 3.5MM)
246PCB MAIN AS L270~271 COIL 5P076068--6068MPX
247PCB MAIN AS L600 COIL BIAS OSC 5L0503K643SM-10F 5.04MH
248PCB MAIN AS L601~602 COIL CHOKE 5LC333K80433MH K
249PCB MAIN AS Q001 TR TZTC3194Y-KTC3194Y
250PCB MAIN AS Q231 TR TZTA107M--KTA107M(AUTO)
251PCB MAIN AS Q270~271 TR TZTC3198Y-KTC3198Y-(1815Y) (AUTO)
252PCB MAIN AS Q600 TR TKRC111M--KRC111M (KSR1010)
253PCB MAIN AS Q601 TR TZTA107M--KTA107M(AUTO)
254PCB MAIN AS Q602 TR TKRC111M--KRC111M (KSR1010)
255PCB MAIN AS Q603~604 TR TZTA1266Y-KTA1266Y- (AUTO)(1015Y)
256PCB MAIN AS Q605~606 TR TKRC111M--KRC111M (KSR1010)

PART-CODE PART-DESCNO ASS'Y LOCATION PART-NAME

22

Electrical Parts List

257PCB MAIN AS Q607 TR TZTC3205Y-KTC3205Y (2236Y)
258PCB MAIN AS Q608 TR TZTA1266Y-KTA1266Y- (AUTO)(1015Y)
259PCB MAIN AS Q609 TR TKRC111M--KRC111M (KSR1010)
260PCB MAIN AS Q610 TR TZTA1273Y-KTA1273Y(966Y)
261PCB MAIN AS Q612 TR TKRC111M--KRC111M (KSR1010)
262PCB MAIN AS Q614 TR TKRC111M--KRC111M (KSR1010)
263PCB MAIN AS Q616 TR TKRC111M--KRC111M (KSR1010)
264PCB MAIN AS Q800~802 TR TZTA107M--KTA107M(AUTO)
265PCB MAIN AS Q803 TR TKRC111M--KRC111M (KSR1010)
266PCB MAIN AS Q870~873 TR TKRC111M--KRC111M (KSR1010)
267PCB MAIN AS Q900 TR TZTA1273Y-KTA1273Y(966Y)
268PCB MAIN AS R001 R CARBON FILM RD-AZ475J-1/6 4.7M OHM J
269PCB MAIN AS R002 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
270PCB MAIN AS R003 R CARBON FILM RD-AZ331J-1/6 330 OHM J
271PCB MAIN AS R004 R CARBON FILM RD-AZ470J-1/6 47 OHM J
272PCB MAIN AS R005 R CARBON FILM RD-AZ332J-1/6 3.3K OHM J
273PCB MAIN AS R006 R CARBON FILM RD-AZ681J-1/6 680 OHM J
274PCB MAIN AS R007 R CARBON FILM RD-AZ331J-1/6 330 OHM J
275PCB MAIN AS R009 R CARBON FILM RD-AZ121J-1/6 120 OHM J
276PCB MAIN AS R010 R CARBON FILM RD-AZ100J-1/6 10 OHM J
277PCB MAIN AS R100 R CARBON FILM RD-AZ223J-1/6 22K OHM J
278PCB MAIN AS R101 R CARBON FILM RD-AZ104J-1/6 100K OHM J
279PCB MAIN AS R200 R CARBON FILM RD-AZ682J-1/6 6.8K OHM J
280PCB MAIN AS R201 R CARBON FILM RD-AZ333J-1/6 33K OHM J
281PCB MAIN AS R202 R CARBON FILM RD-AZ102J-1/6 1K OHM J
282PCB MAIN AS R203 R CARBON FILM RD-AZ273J-1/6 27K OHM J
283PCB MAIN AS R204 R CARBON FILM RD-AZ183J-1/6 18K OHM J
284PCB MAIN AS R205 R CARBON FILM RD-AZ102J-1/6 1K OHM J
285PCB MAIN AS R206 R CARBON FILM RD-AZ151J-1/6 150 OHM J
286PCB MAIN AS R207 R CARBON FILM RD-AZ332J-1/6 3.3K OHM J
287PCB MAIN AS R208 R CARBON FILM RD-AZ100J-1/6 10 OHM J
288PCB MAIN AS R209~210 R CARBON FILM RD-AZ122J-1/6 1.2K OHM J
289PCB MAIN AS R211~212 R CARBON FILM RD-AZ332J-1/6 3.3K OHM J
290PCB MAIN AS R213 R CARBON FILM RD-AZ563J-1/6 56K OHM J
291PCB MAIN AS R230~231 R CARBON FILM RD-AZ472J-1/6 4.7K OHM J
292PCB MAIN AS R232 R CARBON FILM RD-AZ470J-1/6 47 OHM J
293PCB MAIN AS R233 R CARBON FILM RD-AZ472J-1/6 4.7K OHM J
294PCB MAIN AS R234~237 R CARBON FILM RD-AZ102J-1/6 1K OHM J
295PCB MAIN AS R239 R CARBON FILM RD-AZ102J-1/6 1K OHM J
296PCB MAIN AS R241 R CARBON FILM RD-AZ102J-1/6 1K OHM J
297PCB MAIN AS R243~244 R CARBON FILM RD-AZ103J-1/6 10K OHM J
298PCB MAIN AS R245 R CARBON FILM RD-AZ472J-1/6 4.7K OHM J
299PCB MAIN AS R246 R CARBON FILM RD-AZ103J-1/6 10K OHM J
300PCB MAIN AS R253 R CARBON FILM RD-AZ221J-1/6 220 OHM J
301PCB MAIN AS R254 R CARBON FILM RD-AZ473J-1/6 47K OHM J
302PCB MAIN AS R260 R CARBON FILM RD-AZ100J-1/6 10 OHM J
303PCB MAIN AS R261~262 R CARBON FILM RD-AZ823J-1/6 82K OHM J
304PCB MAIN AS R270~271 R CARBON FILM RD-AZ222J-1/6 2.2K OHM J
305PCB MAIN AS R272 R CARBON FILM RD-AZ221J-1/6 220 OHM J
306PCB MAIN AS R273 R CARBON FILM RD-AZ474J-1/6 470K OHM J
307PCB MAIN AS R274 R CARBON FILM RD-AZ102J-1/6 1K OHM J
308PCB MAIN AS R275 R CARBON FILM RD-AZ474J-1/6 470K OHM J
309PCB MAIN AS R276 R CARBON FILM RD-AZ102J-1/6 1K OHM J
310PCB MAIN AS R277~278 R CARBON FILM RD-AZ272J-1/6 2.7K OHM J
311PCB MAIN AS R400~401 R CARBON FILM RD-AZ105J-1/6 1M OHM J
312PCB MAIN AS R402~405 R CARBON FILM RD-AZ104J-1/6 100K OHM J
313PCB MAIN AS R406~407 R CARBON FILM RD-AZ562J-1/6 5.6K OHM J
314PCB MAIN AS R408~409 R CARBON FILM RD-AZ103J-1/6 10K OHM J
315PCB MAIN AS R410 R CARBON FILM RD-AZ221J-1/6 220 OHM J
316PCB MAIN AS R411 R CARBON FILM RD-AZ102J-1/6 1K OHM J
317PCB MAIN AS R412~413 R CARBON FILM RD-AZ104J-1/6 100K OHM J
318PCB MAIN AS R414 R CARBON FILM RD-AZ102J-1/6 1K OHM J
319PCB MAIN AS R415~416 R CARBON FILM RD-AZ683J-1/6 68K OHM J
320PCB MAIN AS R430~431 R CARBON FILM RD-AZ103J-1/6 10K OHM J

PART-CODE PART-DESCNO ASS'Y LOCATION PART-NAME

23

Electrical Parts List

321PCB MAIN AS R432 R CARBON FILM RD-AZ223J-1/6 22K OHM J
322PCB MAIN AS R433 R CARBON FILM RD-AZ103J-1/6 10K OHM J
323PCB MAIN AS R434~437 R CARBON FILM RD-AZ102J-1/6 1K OHM J
324PCB MAIN AS R438~439 R CARBON FILM RD-AZ104J-1/6 100K OHM J
325PCB MAIN AS R440~441 R CARBON FILM RD-AZ820J-1/6 82 OHM J
326PCB MAIN AS R442 R CARBON FILM RD-AZ221J-1/6 220 OHM J
327PCB MAIN AS R490 R CARBON FILM RD-AZ392J-1/6 3.9K OHM J
328PCB MAIN AS R491~492 R CARBON FILM RD-AZ103J-1/6 10K OHM J
329PCB MAIN AS R493 R CARBON FILM RD-AZ392J-1/6 3.9K OHM J
330PCB MAIN AS R600 R CARBON FILM RD-AZ100J-1/6 10 OHM J
331PCB MAIN AS R601 R CARBON FILM RD-AZ561J-1/6 560 OHM J
332PCB MAIN AS R602 R CARBON FILM RD-AZ331J-1/6 330 OHM J
333PCB MAIN AS R603 R CARBON FILM RD-AZ472J-1/6 4.7K OHM J
334PCB MAIN AS R604 R CARBON FILM RD-AZ561J-1/6 560 OHM J
335PCB MAIN AS R606 R CARBON FILM RD-AZ561J-1/6 560 OHM J
336PCB MAIN AS R607 R CARBON FILM RD-AZ103J-1/6 10K OHM J
337PCB MAIN AS R608 R CARBON FILM RD-AZ104J-1/6 100K OHM J
338PCB MAIN AS R609 R CARBON FILM RD-AZ103J-1/6 10K OHM J
339PCB MAIN AS R610 R CARBON FILM RD-AZ473J-1/6 47K OHM J
340PCB MAIN AS R611 R CARBON FILM RD-AZ479J-1/6 4.7 OHM J
341PCB MAIN AS R612 R CARBON FILM RD-AZ101J-1/6 100 OHM J
342PCB MAIN AS R613~614 R CARBON FILM RD-AZ103J-1/6 10K OHM J
343PCB MAIN AS R615 R CARBON FILM RD-AZ333J-1/6 33K OHM J
344PCB MAIN AS R616 R CARBON FILM RD-AZ103J-1/6 10K OHM J
345PCB MAIN AS R617 R CARBON FILM RD-AZ472J-1/6 4.7K OHM J
346PCB MAIN AS R618 R CARBON FILM RD-AZ103J-1/6 10K OHM J
347PCB MAIN AS R619 R CARBON FILM RD-AZ102J-1/6 1K OHM J
348PCB MAIN AS R620 R CARBON FILM RD-AZ101J-1/6 100 OHM J
349PCB MAIN AS R621 R CARBON FILM RD-AZ472J-1/6 4.7K OHM J
350PCB MAIN AS R622~623 R CARBON FILM RD-AZ184J-1/6 180K OHM J
351PCB MAIN AS R624 R CARBON FILM RD-AZ103J-1/6 10K OHM J
352PCB MAIN AS R625 R CARBON FILM RD-AZ105J-1/6 1M OHM J
353PCB MAIN AS R626 R CARBON FILM RD-AZ221J-1/6 220 OHM J
354PCB MAIN AS R627 R CARBON FILM RD-AZ683J-1/6 68K OHM J
355PCB MAIN AS R628~629 R CARBON FILM RD-AZ823J-1/6 82K OHM J
356PCB MAIN AS R631 R CARBON FILM RD-AZ102J-1/6 1K OHM J
357PCB MAIN AS R633~635 R CARBON FILM RD-AZ103J-1/6 10K OHM J
358PCB MAIN AS R636 R CARBON FILM RD-AZ105J-1/6 1M OHM J
359PCB MAIN AS R637 R CARBON FILM RD-AZ271J-1/6 270 OHM J
360PCB MAIN AS R638~639 R CARBON FILM RD-AZ392J-1/6 3.9K OHM J
361PCB MAIN AS R640 R CARBON FILM RD-AZ271J-1/6 270 OHM J
362PCB MAIN AS R641~642 R CARBON FILM RD-AZ103J-1/6 10K OHM J
363PCB MAIN AS R643~644 R CARBON FILM RD-AZ184J-1/6 180K OHM J
364PCB MAIN AS R645 R CARBON FILM RD-AZ183J-1/6 18K OHM J
365PCB MAIN AS R646 R CARBON FILM RD-AZ103J-1/6 10K OHM J
366PCB MAIN AS R647 R CARBON FILM RD-AZ470J-1/6 47 OHM J
367PCB MAIN AS R648~649 R CARBON FILM RD-AZ334J-1/6 330K OHM J
368PCB MAIN AS R650~651 R CARBON FILM RD-AZ151J-1/6 150 OHM J
369PCB MAIN AS R652~653 R CARBON FILM RD-AZ103J-1/6 10K OHM J
370PCB MAIN AS R654~655 R CARBON FILM RD-AZ272J-1/6 2.7K OHM J
371PCB MAIN AS R656 R CARBON FILM RD-AZ102J-1/6 1K OHM J
372PCB MAIN AS R658 R CARBON FILM RD-AZ102J-1/6 1K OHM J
373PCB MAIN AS R659~660 R CARBON FILM RD-AZ682J-1/6 6.8K OHM J
374PCB MAIN AS R662~663 R CARBON FILM RD-AZ683J-1/6 68K OHM J
375PCB MAIN AS R664~665 R CARBON FILM RD-AZ820J-1/6 82 OHM J
376PCB MAIN AS R666~669 R CARBON FILM RD-AZ102J-1/6 1K OHM J
377PCB MAIN AS R670 R CARBON FILM RD-AZ183J-1/6 18K OHM J
378PCB MAIN AS R671 R CARBON FILM RD-AZ103J-1/6 10K OHM J
379PCB MAIN AS R800 R CARBON FILM RD-AZ475J-1/6 4.7M OHM J
380PCB MAIN AS R801 R CARBON FILM RD-AZ101J-1/6 100 OHM J
381PCB MAIN AS R802~805 R CARBON FILM RD-AZ100J-1/6 10 OHM J
382PCB MAIN AS R806 R CARBON FILM RD-AZ103J-1/6 10K OHM J
383PCB MAIN AS R808 R CARBON FILM RD-AZ103J-1/6 10K OHM J
384PCB MAIN AS R809 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO

PART-CODE PART-DESCNO ASS'Y LOCATION PART-NAME

24

Electrical Parts List

385PCB MAIN AS R810 R CARBON FILM RD-AZ103J-1/6 10K OHM J
386PCB MAIN AS R811~812 R CARBON FILM RD-AZ473J-1/6 47K OHM J
387PCB MAIN AS R813~814 R CARBON FILM RD-AZ681J-1/6 680 OHM J
388PCB MAIN AS R815~816 R CARBON FILM RD-AZ223J-1/6 22K OHM J
389PCB MAIN AS R817~818 R CARBON FILM RD-AZ104J-1/6 100K OHM J
390PCB MAIN AS R870 R CARBON FILM RD-AZ102J-1/6 1K OHM J
391PCB MAIN AS R871 R CARBON FILM RD-AZ101J-1/6 100 OHM J
392PCB MAIN AS R872 R CARBON FILM RD-AZ563J-1/6 56K OHM J
393PCB MAIN AS R874 R CARBON FILM RD-AZ101J-1/6 100 OHM J
394PCB MAIN AS R876 R CARBON FILM RD-AZ183J-1/6 18K OHM J
395PCB MAIN AS R877 R CARBON FILM RD-AZ101J-1/6 100 OHM J
396PCB MAIN AS R878 R CARBON FILM RD-AZ183J-1/6 18K OHM J
397PCB MAIN AS R879 R CARBON FILM RD-AZ101J-1/6 100 OHM J
398PCB MAIN AS R880 R CARBON FILM RD-AZ102J-1/6 1K OHM J
399PCB MAIN AS R881 R CARBON FILM RD-AZ333J-1/6 33K OHM J
400PCB MAIN AS R882 R CARBON FILM RD-AZ563J-1/6 56K OHM J
401PCB MAIN AS R883 R CARBON FILM RD-AZ333J-1/6 33K OHM J
402PCB MAIN AS R900~901 R CARBON FILM RD-AZ109J-1/6 1 OHM J
403PCB MAIN AS R902~903 R CARBON FILM RD-AZ221J-1/6 220 OHM J
404PCB MAIN AS R904 R CARBON FILM RD-4Z271J-1/4 270 OHM J
405PCB MAIN AS R905 R CARBON FILM RD-AZ562J-1/6 5.6K OHM J
406PCB MAIN AS R906~908 R CARBON FILM RD-AZ103J-1/6 10K OHM J
407PCB MAIN AS R909 R CARBON FILM RD-AZ562J-1/6 5.6K OHM J
408PCB MAIN AS R910 R CARBON FILM RD-AZ102J-1/6 1K OHM J
409PCB MAIN AS R911 R CARBON FILM RD-AZ100J-1/6 10 OHM J
410PCB MAIN AS R912 R CARBON FILM RD-AZ562J-1/6 5.6K OHM J
411PCB MAIN AS R913 R CARBON FILM RD-AZ103J-1/6 10K OHM J
412PCB MAIN AS RV600 R SEMI FIXED RV1417222-1/10 2.2K OHM B V6EK-PV1S
413PCB MAIN AS RY800 SW RELAY 5SC2001A01SDT-S-105LMR
414PCB MAIN AS TU001 TUNER PACK 9737613100FTE4-401T/KST-F401VA-1
415PCB MAIN AS XC200 C DISCRIMINATOR 5P107MG86CCDA10.7MG86N-C
416PCB MAIN AS XC230 X-TAL 5XA7R200007.2M
417PCB MAIN AS XC260 X-TAL 5XA4R332M-4.332M
418PCB FRONT AS 12000 PCB FRONT AS 9CDC057300AMI-829LF
419PCB FRONT AS B701 PCB FRONT 9CD6580300247X139X1.6T
420PCB FRONT AS CC701 C CERA CCXF1H223Z50V F 0.022MF Z (TAPPING)
421PCB FRONT AS CC702 C CERA CCXF1H104Z50V F 0.1MF Z
422PCB FRONT AS CC703 C CERA CCXF1H223Z50V F 0.022MF Z (TAPPING)
423PCB FRONT AS CC704~705 C CERA CCXF1H104Z50V F 0.1MF Z
424PCB FRONT AS CC709~710 C CERA CZCH1E101JCH 25V 100PF J AXL 52MM
425PCB FRONT AS CC711 C CERA CCXF1H223Z50V F 0.022MF Z (TAPPING)
426PCB FRONT AS CC712~713 C CERA CCXF1H104Z50V F 0.1MF Z
427PCB FRONT AS CC714 C CERA CZCH1E150JCH 25V 15PF J (AXIAL)
428PCB FRONT AS CC715 C CERA CZCH1E180JCH 25V 18PF J (AXIAL)
429PCB FRONT AS CC716~717 C CERA CZCH1E330JCH 25V 33PF J AXIAL 52MM
430PCB FRONT AS CC718 C CERA CCXF1H223Z50V F 0.022MF Z (TAPPING)
431PCB FRONT AS CC719 C CERA CZCH1E330JCH 25V 33PF J AXIAL 52MM
432PCB FRONT AS CC720 C CERA CCXF1H223Z50V F 0.022MF Z (TAPPING)
433PCB FRONT AS CC721 C CERA CCXF1H104Z50V F 0.1MF Z
434PCB FRONT AS CC722 C CERA CCXF1H223Z50V F 0.022MF Z (TAPPING)
435PCB FRONT AS CC723 C CERA CZCH1E101JCH 25V 100PF J AXL 52MM
436PCB FRONT AS CC724 C CERA CCZB1E221K25V B 220PF K (AXIAL)
437PCB FRONT AS CC725~726 C CERA CCXF1H104Z50V F 0.1MF Z
438PCB FRONT AS CE701~702 C ELECTRO CEXF1H479V50V RSS 4.7MF (5X11) TP
439PCB FRONT AS CE703 C ELECTRO CEYF1A102V10V 1000MF RSS 10X16
440PCB FRONT AS CE704 C ELECTRO CEXF1E101V25V RSS 100MF (6.3X11) TP
441PCB FRONT AS CE705 C ELECTRO CEXF1H109V50V RSS 1MF (5X11) TP
442PCB FRONT AS CE706 C ELECTRO CEXF1H100V50V RSS 10MF (5X11) TP
443PCB FRONT AS CN701 CONN AS 9738833700#26 8P FLAT 220MM
444PCB FRONT AS CN703 CONN AS 9738834100#26 13P FLAT 100MM
445PCB FRONT AS CN704 CONN AS 9738834000#26 2.0PITCH 11P FLAT 150
446PCB FRONT AS CN707 CONN AS 9728804600FFC 23P P=1.25 150MM
447PCB FRONT AS CW401 PIN WAFER 973640770052084-1310 13P BOTTOM
448PCB FRONT AS CW402 CONN WAFER 973640790052084-1010 10P BOTTOM

PART-CODE PART-DESCNO ASS'Y LOCATION PART-NAME

25

Electrical Parts List

449PCB FRONT AS CW508 CONN WAFER 973640830052492-1920 19P BOTTOM
450PCB FRONT AS CW77A CONN WAFER 9CD626050052044-2345
451PCB FRONT AS CW77B CONN WAFER 9CD626060052492-2320
452PCB FRONT AS D701~706 DIODE D1N4148---1N4148 (TAPPING)
453PCB FRONT AS FD701 VFD DBJ703GNK-BJ703GNK
454PCB FRONT AS IC701 IC 1M24C04---M24C04-BN6
455PCB FRONT AS IC702 IC 138199829LMICOM 1M38199-829L
456PCB FRONT AS IC703 IC 1MSGEQ5A--MSGEQ5A
457PCB FRONT AS IC704 IC 1BU4094BCFBU4094BCF(SOP16)
458PCB FRONT AS IC705 IC PRE AMP 1TM97CT38PLTM97CT-38P
459PCB FRONT AS JW701~702 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
460PCB FRONT AS JW704 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
461PCB FRONT AS JW705~706 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
462PCB FRONT AS JW707 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
463PCB FRONT AS JW708 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
464PCB FRONT AS JW709~713 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
465PCB FRONT AS JW714 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
466PCB FRONT AS JW715 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
467PCB FRONT AS JW716 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
468PCB FRONT AS JW717~719 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
469PCB FRONT AS JW720 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
470PCB FRONT AS JW721 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
471PCB FRONT AS JW722 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
472PCB FRONT AS JW723~724 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
473PCB FRONT AS JW725~727 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
474PCB FRONT AS JW728 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
475PCB FRONT AS JW729~731 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
476PCB FRONT AS JW732 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
477PCB FRONT AS JW733~736 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
478PCB FRONT AS JW739 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
479PCB FRONT AS JW740 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
480PCB FRONT AS JW741 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
481PCB FRONT AS JW742 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
482PCB FRONT AS JW743~744 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
483PCB FRONT AS JW745~746 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
484PCB FRONT AS JW747 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
485PCB FRONT AS JW748 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
486PCB FRONT AS JW749 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
487PCB FRONT AS JW750 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
488PCB FRONT AS JW751~752 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
489PCB FRONT AS JW753 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
490PCB FRONT AS JW754 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
491PCB FRONT AS JW755~756 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
492PCB FRONT AS JW757~758 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
493PCB FRONT AS JW759 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
494PCB FRONT AS JW760 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
495PCB FRONT AS JW761 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
496PCB FRONT AS JW762~763 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
497PCB FRONT AS JW764 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
498PCB FRONT AS JW765 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
499PCB FRONT AS JW766 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
500PCB FRONT AS JW767~768 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
501PCB FRONT AS JW769 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
502PCB FRONT AS JW770 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
503PCB FRONT AS JW771 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
504PCB FRONT AS JW772 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
505PCB FRONT AS JW773~774 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
506PCB FRONT AS JW775 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
507PCB FRONT AS JW776 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
508PCB FRONT AS JW777 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
509PCB FRONT AS JW778 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
510PCB FRONT AS JW779 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
511PCB FRONT AS LD701~702 LED DLTL16KGE-LTL-16KGE(GREEN)PI3.1
512PCB FRONT AS LD703 LED DLTL16KEE-LTL-16KEE(RED)PI3.1

PART-CODE PART-DESCNO ASS'Y LOCATION PART-NAME

26

Electrical Parts List

513PCB FRONT AS LD704~705 LED DLTL16KGE-LTL-16KGE(GREEN)PI3.1
514PCB FRONT AS LD706 LED DLTL16KEE-LTL-16KEE(RED)PI3.1
515PCB FRONT AS LD707~708 LED DLTL16KGE-LTL-16KGE(GREEN)PI3.1
516PCB FRONT AS LD709 LED DLTL16KEE-LTL-16KEE(RED)PI3.1
517PCB FRONT AS LD710~711 LED DLTL16KGE-LTL-16KGE(GREEN)PI3.1
518PCB FRONT AS LD712 LED DLTL16KEE-LTL-16KEE(RED)PI3.1
519PCB FRONT AS LD713~714 LED DLTL307EE-LTL-307EE(RED)PI5
520PCB FRONT AS Q701 TR TKRC107M--KRC107-M TAPPING(KSR1006)
521PCB FRONT AS Q702~703 TR TKRC111M--KRC111M (KSR1010)
522PCB FRONT AS Q704 TR TZTC3198Y-KTC3198Y-(1815Y) (AUTO)
523PCB FRONT AS Q705 TR TZTA1273Y-KTA1273Y(966Y)
524PCB FRONT AS Q706 TR TKRC107M--KRC107-M TAPPING(KSR1006)
525PCB FRONT AS Q707 TR TZTA1273Y-KTA1273Y(966Y)
526PCB FRONT AS Q708 TR TKRC107M--KRC107-M TAPPING(KSR1006)
527PCB FRONT AS Q709 TR TZTA1273Y-KTA1273Y(966Y)
528PCB FRONT AS Q710 TR TKRC107M--KRC107-M TAPPING(KSR1006)
529PCB FRONT AS Q711 TR TKRA111M--KRA111-M TAPPING(KSR2010)
530PCB FRONT AS Q712 TR TKRC107M--KRC107-M TAPPING(KSR1006)
531PCB FRONT AS Q713~716 TR TKRA111M--KRA111-M TAPPING(KSR2010)
532PCB FRONT AS Q717 TR TKRC107M--KRC107-M TAPPING(KSR1006)
533PCB FRONT AS R301 R CARBON FILM RD-AZ101J-1/6 100 OHM J
534PCB FRONT AS R302 R CARBON FILM RD-AZ151J-1/6 150 OHM J
535PCB FRONT AS R303 R CARBON FILM RD-AZ181J-1/6 180 OHM J
536PCB FRONT AS R304 R CARBON FILM RD-AZ271J-1/6 270 OHM J
537PCB FRONT AS R305 R CARBON FILM RD-AZ331J-1/6 330 OHM J
538PCB FRONT AS R306 R CARBON FILM RD-AZ391J-1/6 390 OHM J
539PCB FRONT AS R307 R CARBON FILM RD-AZ471J-1/6 470 OHM J
540PCB FRONT AS R308 R CARBON FILM RD-AZ561J-1/6 560 OHM J
541PCB FRONT AS R309 R CARBON FILM RD-AZ821J-1/6 820 OHM J
542PCB FRONT AS R310 R CARBON FILM RD-AZ152J-1/6 1.5K OHM J
543PCB FRONT AS R311 R CARBON FILM RD-AZ272J-1/6 2.7K OHM J
544PCB FRONT AS R312 R CARBON FILM RD-AZ682J-1/6 6.8K OHM J
545PCB FRONT AS R313 R CARBON FILM RD-AZ101J-1/6 100 OHM J
546PCB FRONT AS R314 R CARBON FILM RD-AZ151J-1/6 150 OHM J
547PCB FRONT AS R315 R CARBON FILM RD-AZ181J-1/6 180 OHM J
548PCB FRONT AS R316 R CARBON FILM RD-AZ271J-1/6 270 OHM J
549PCB FRONT AS R317 R CARBON FILM RD-AZ331J-1/6 330 OHM J
550PCB FRONT AS R318 R CARBON FILM RD-AZ391J-1/6 390 OHM J
551PCB FRONT AS R319 R CARBON FILM RD-AZ471J-1/6 470 OHM J
552PCB FRONT AS R320 R CARBON FILM RD-AZ561J-1/6 560 OHM J
553PCB FRONT AS R321 R CARBON FILM RD-AZ821J-1/6 820 OHM J
554PCB FRONT AS R322 R CARBON FILM RD-AZ101J-1/6 100 OHM J
555PCB FRONT AS R323 R CARBON FILM RD-AZ151J-1/6 150 OHM J
556PCB FRONT AS R324 R CARBON FILM RD-AZ181J-1/6 180 OHM J
557PCB FRONT AS R325 R CARBON FILM RD-AZ271J-1/6 270 OHM J
558PCB FRONT AS R326 R CARBON FILM RD-AZ331J-1/6 330 OHM J
559PCB FRONT AS R327 R CARBON FILM RD-AZ391J-1/6 390 OHM J
560PCB FRONT AS R328 R CARBON FILM RD-AZ471J-1/6 470 OHM J
561PCB FRONT AS R329 R CARBON FILM RD-AZ681J-1/6 680 OHM J
562PCB FRONT AS R701~704 R CARBON FILM RD-AZ103J-1/6 10K OHM J
563PCB FRONT AS R705~707 R CARBON FILM RD-AZ104J-1/6 100K OHM J
564PCB FRONT AS R708 R CARBON FILM RD-AZ103J-1/6 10K OHM J
565PCB FRONT AS R712 R CARBON FILM RD-AZ392J-1/6 3.9K OHM J
566PCB FRONT AS R713~714 R CARBON FILM RD-AZ473J-1/6 47K OHM J
567PCB FRONT AS R715 R CARBON FILM RD-AZ333J-1/6 33K OHM J
568PCB FRONT AS R716 R CARBON FILM RD-AZ393J-1/6 39K OHM J
569PCB FRONT AS R717 R CARBON FILM RD-AZ683J-1/6 68K OHM J
570PCB FRONT AS R718~720 R CARBON FILM RD-AZ152J-1/6 1.5K OHM J
571PCB FRONT AS R721 R CARBON FILM RD-AZ681J-1/6 680 OHM J
572PCB FRONT AS R722 R CARBON FILM RD-AZ472J-1/6 4.7K OHM J
573PCB FRONT AS R723~724 R CARBON FILM RD-AZ103J-1/6 10K OHM J
574PCB FRONT AS R725 R CARBON FILM RD-AZ472J-1/6 4.7K OHM J
575PCB FRONT AS R726 R CARBON FILM RD-AZ331J-1/6 330 OHM J
576PCB FRONT AS R727 R CARBON FILM RD-AZ102J-1/6 1K OHM J

PART-CODE PART-DESCNO ASS'Y LOCATION PART-NAME

27

Electrical Parts List

577PCB FRONT AS R728 R CARBON FILM RD-AZ103J-1/6 10K OHM J
578PCB FRONT AS R729~730 R CARBON FILM RD-AZ102J-1/6 1K OHM J
579PCB FRONT AS R731 R CARBON FILM RD-AZ103J-1/6 10K OHM J
580PCB FRONT AS R732~733 R CARBON FILM RD-AZ102J-1/6 1K OHM J
581PCB FRONT AS R734 R CARBON FILM RD-AZ182J-1/6 1.8K OHM J
582PCB FRONT AS R735 R CARBON FILM RD-AZ102J-1/6 1K OHM J
583PCB FRONT AS R736 R CARBON FILM RD-4Z689J-1/4 6.8 OHM J
584PCB FRONT AS R737~738 R CARBON FILM RD-AZ102J-1/6 1K OHM J
585PCB FRONT AS R739 R CARBON FILM RD-4Z689J-1/4 6.8 OHM J
586PCB FRONT AS R740~742 R CARBON FILM RD-AZ222J-1/6 2.2K OHM J
587PCB FRONT AS R743 R CARBON FILM RD-AZ472J-1/6 4.7K OHM J
588PCB FRONT AS R745 R CARBON FILM RD-AZ223J-1/6 22K OHM J
589PCB FRONT AS R747 R CARBON FILM RD-AZ391J-1/6 390 OHM J
590PCB FRONT AS R748 R CARBON FILM RD-AZ271J-1/6 270 OHM J
591PCB FRONT AS R749 R CARBON FILM RD-AZ391J-1/6 390 OHM J
592PCB FRONT AS R750 R CARBON FILM RD-AZ271J-1/6 270 OHM J
593PCB FRONT AS R751 R CARBON FILM RD-AZ391J-1/6 390 OHM J
594PCB FRONT AS R752 R CARBON FILM RD-AZ271J-1/6 270 OHM J
595PCB FRONT AS R753 R CARBON FILM RD-AZ391J-1/6 390 OHM J
596PCB FRONT AS R754 R CARBON FILM RD-AZ271J-1/6 270 OHM J
597PCB FRONT AS R755 R CARBON FILM RD-AZ390J-1/6 39 OHM J
598PCB FRONT AS R756 R CARBON FILM RD-AZ104J-1/6 100K OHM J
599PCB FRONT AS R757 R CARBON FILM RD-AZ334J-1/6 330K OHM J
600PCB FRONT AS R758 R CARBON FILM RD-AZ334J-1/6 330K OHM J
601PCB FRONT AS R759 R CARBON FILM RD-AZ104J-1/6 100K OHM J
602PCB FRONT AS R760 R CARBON FILM RD-AZ103J-1/6 10K OHM J
603PCB FRONT AS R761 R CARBON FILM RD-AZ106J-1/6 10M OHM J
604PCB FRONT AS R762 R CARBON FILM RD-AZ334J-1/6 330K OHM J
605PCB FRONT AS R763 R CARBON FILM RD-AZ101J-1/6 100 OHM J
606PCB FRONT AS R764 R CARBON FILM RD-AZ100J-1/6 10 OHM J
607PCB FRONT AS R765 R CARBON FILM RD-AZ184J-1/6 180K OHM J
608PCB FRONT AS R766 R CARBON FILM RD-AZ102J-1/6 1K OHM J
609PCB FRONT AS R768~769 R CARBON FILM RD-AZ101J-1/6 100 OHM J
610PCB FRONT AS R770 R CARBON FILM RD-AZ102J-1/6 1K OHM J
611PCB FRONT AS R771 R CARBON FILM RD-AZ224J-1/6 220K OHM J
612PCB FRONT AS R772 R CARBON FILM RD-AZ103J-1/6 10K OHM J
613PCB FRONT AS R774 R CARBON FILM RD-AZ103J-1/6 10K OHM J
614PCB FRONT AS R775 R CARBON FILM RD-AZ222J-1/6 2.2K OHM J
615PCB FRONT AS R776 R CARBON FILM RD-AZ101J-1/6 100 OHM J
616PCB FRONT AS R778 R CARBON FILM RD-AZ103J-1/6 10K OHM J
617PCB FRONT AS R779 R CARBON FILM RD-AZ153J-1/6 15K OHM J
618PCB FRONT AS R780 R CARBON FILM RD-AZ103J-1/6 10K OHM J
619PCB FRONT AS R781 R CARBON FILM RD-AZ333J-1/6 33K OHM J
620PCB FRONT AS R782 R CARBON FILM RD-AZ103J-1/6 10K OHM J
621PCB FRONT AS R783 R CARBON FILM RD-AZ333J-1/6 33K OHM J
622PCB FRONT AS R784~787 R CARBON FILM RD-AZ103J-1/6 10K OHM J
623PCB FRONT AS SW701~707SW TACT 5S50101001KPT-1105A 1C-1P
624PCB FRONT AS SW709~717SW TACT 5S50101001KPT-1105A 1C-1P
625PCB FRONT AS SW719~731SW TACT 5S50101001KPT-1105A 1C-1P
626PCB FRONT AS VR701 SW ENCORDER 5SH162401-EC16B24204 24P W/DETENT
627PCB FRONT AS XC701 RESONATOR 5PCSA8MTZ-CSA8MTZ, 8MHZ
628PCB FRONT AS XC702 X-TAL 5XA32R768-DT-38 32.768KHZ 20PPM
629PCB OPTICAL JACK AS14000 PCB OPTICAL JACK AS9CDC050700AMI-710R0F(OM MECHA)
630PCB OPTICAL JACK ASB001 PCB OPTICAL 9CD657780029X21X1.6T
631PCB OPTICAL JACK ASBD501 CORE BEAD 9768602000H.B-T15X25X13ON
632PCB OPTICAL JACK ASCC561 C CERA CCXF1H104Z50V F 0.1MF Z
633PCB OPTICAL JACK ASCN510 CONN AS 9738841800#26 400MM 3P 2.5P
634PCB OPTICAL JACK ASIC507 IC 1T0TX178--T0TX178
635PCB OPTICAL JACK ASL502 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
636PCB P/T AS 13000 PCB P/T AS 9CDC057400AMI-829LF
637PCB P/T AS B000 PCB P/T 9CD6580501108X123X1.6T
638PCB P/T AS CC980 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
639PCB P/T AS CD900 CORD AC 9736900200KKP419C,KLCE-2F,0.75SQURE
640PCB P/T AS CE980 C ELECTRO CEYF1E102V25V RSS 1000MF (13X20)

PART-CODE PART-DESCNO ASS'Y LOCATION PART-NAME

28

Electrical Parts List

641PCB P/T AS CW900 CONN WAFER 9728804100#22 10P P2.5 350 BOARD-IN
642PCB P/T AS D980~985 DIODE D1N4001---1N4001
643PCB P/T AS F981 FUSE GLASS TUBE5FSGB1222R1.25A 250V QCK ACT 179020
644PCB P/T AS FC901~902 CLIP FUSE 9734600700FC-5N
645PCB P/T AS IC980 IC 1MC78L05--MC78L05AC
646PCB P/T AS JW980~981 WIRE JUMPER W581GY17J5AWG22 1/0.65 SN 17.5 AUTO
647PCB P/T AS JW987 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
648PCB P/T AS JW989 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
649PCB P/T AS PT901 TRANS POWER 5TP8028829EI=28X12 230V 50HZ
650PCB P/T AS PT902 TRANS POWER 5TP8074846EI=74X42 230V 50HZ
651PCB P/T AS Q981 TR TZTC3205Y-KTC3205Y (2236Y)
652PCB P/T AS R980 R METAL FILM RN-2Y475J-1/2 4.7M OHM J
653PCB P/T AS R981 R CARBON FILM RD-4Z101J-1/4 100 OHM J
654PCB P/T AS R982 R CARBON FILM RD-AZ103J-1/6 10K OHM J
655PCB P/T AS R983 R CARBON FILM RD-AZ472J-1/6 4.7K OHM J
656PCB P/T AS RF980 R FUSIBLE RF01F4780J0.47OHM 1W
657PCB P/T AS RF982~983 R FUSIBLE RF01F4780J0.47OHM 1W
658PCB P/T AS RY980 SW RELAY 5SC2001A01SDT-S-105LMR
659PCB P/T AS TP980~981 PIN WRAPPING 97135504001.0X2.5X15
660PCB CD AS 11000 PCB CD AS 9CDC05340DAMI-829LF
661PCB CD AS B501 PCB CD 9CD6579500197X247X1.6T
662PCB CD AS CC500 C CERA CXCH1H309C50V CH 3PF C
663PCB CD AS CC501 C CERA CCXF1H103Z50V F 0.01MF Z (TAPPING)
664PCB CD AS CC502 C CERA CCXF1H223Z50V F 0.022MF Z (TAPPING)
665PCB CD AS CC503 C CERA CCXB1H102K50V B 1000PF K (TAPPING)
666PCB CD AS CC504~505 C CERA CXCH1H330J50V CH 33PF J (TAPPING)
667PCB CD AS CC506 C CERA CCXF1H223Z50V F 0.022MF Z (TAPPING)
668PCB CD AS CC508 C CERA CXCH1H330J50V CH 33PF J (TAPPING)
669PCB CD AS CC509 C CERA CCXB1H102K50V B 1000PF K (TAPPING)
670PCB CD AS CC511 C CERA CCXF1H223Z50V F 0.022MF Z (TAPPING)
671PCB CD AS CC512 C CERA CCXB1H151K50V B 150PF K (TAPPING)
672PCB CD AS CC513 C CERA CCXB1H331K50V B 330PF K (TAPPING)
673PCB CD AS CC514 C CERA CCXB1H151K50V B 150PF K (TAPPING)
674PCB CD AS CC515 C CERA CCXB1H331K50V B 330PF K (TAPPING)
675PCB CD AS CC516 C CERA CXCH1H101J50V CH 100PF J (TAPPING)
676PCB CD AS CC517~526 C CERA CCXF1H104Z50V F 0.1MF Z
677PCB CD AS CC527~528 C CERA CCXB1H222K50V B 2200PF K (TAPPING)
678PCB CD AS CE501 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
679PCB CD AS CE502 C ELECTRO CEYF1C102V16V RSS 1000MF (10X20)
680PCB CD AS CE503~505 C ELECTRO CEXF1E101V25V RSS 100MF (6.3X11) TP
681PCB CD AS CE506 C ELECTRO CEXF1H100V50V RSS 10MF (5X11) TP
682PCB CD AS CE507 C ELECTRO CEXF1E101V25V RSS 100MF (6.3X11) TP
683PCB CD AS CE508~509 C ELECTRO CEXF1H478V50V RSS 0.47MF (5X11) TP
684PCB CD AS CE510 C ELECTRO CEXF1H100V50V RSS 10MF (5X11) TP
685PCB CD AS CE511 C ELECTRO CEXF1H229V50V RSS 2.2MF (5X11) TP
686PCB CD AS CE512 C ELECTRO CEXF1H338V50V RSS 0.33MF (5X11) TP
687PCB CD AS CE513~514 C ELECTRO CEXF1E101V25V RSS 100MF (6.3X11) TP
688PCB CD AS CE515 C ELECTRO CEXF1H109V50V RSS 1MF (5X11) TP
689PCB CD AS CE516 C ELECTRO CEXF1E101V25V RSS 100MF (6.3X11) TP
690PCB CD AS CE517 C ELECTRO CEXF1H479V50V RSS 4.7MF (5X11) TP
691PCB CD AS CE518 C ELECTRO CEXF1E470V25V RSS 47MF (5X11) TP
692PCB CD AS CE519~520 C ELECTRO CEXF1H479V50V RSS 4.7MF (5X11) TP
693PCB CD AS CE521 C ELECTRO CEXF1E101V25V RSS 100MF (6.3X11) TP
694PCB CD AS CE522~523 C ELECTRO CEXF1H479V50V RSS 4.7MF (5X11) TP
695PCB CD AS CE524~525 C ELECTRO CEXF1E101V25V RSS 100MF (6.3X11) TP
696PCB CD AS CM501 C MYLAR CMXM1H473J50V 0.047MF J
697PCB CD AS CM502 C MYLAR CMXM1H103J50V 0.01MF J (TP)
698PCB CD AS CM503~504C MYLAR CMXM1H104J50V 0.1MF J
699PCB CD AS CM505~506C MYLAR CMXM1H103J50V 0.01MF J (TP)
700PCB CD AS CM507 C MYLAR CMXM1H333J50V 0.033MF J (TP)
701PCB CD AS CM508~509C MYLAR CMXM1H472J50V 0.0047MF J
702PCB CD AS CM510 C MYLAR CMXM1H103J50V 0.01MF J (TP)
703PCB CD AS CM511 C MYLAR CMXM1H104J50V 0.1MF J
704PCB CD AS CM512 C MYLAR CMXM1H222J50V 2200PF J

PART-CODE PART-DESCNO ASS'Y LOCATION PART-NAME

29

Electrical Parts List

705PCB CD AS CM513~514C MYLAR CMXM1H104J50V 0.1MF J
706PCB CD AS CM515 C MYLAR CMXM1H333J50V 0.033MF J (TP)
707PCB CD AS CM516 C MYLAR CMXM1H472J50V 0.0047MF J
708PCB CD AS CM517 C MYLAR CMXM1H103J50V 0.01MF J (TP)
709PCB CD AS CM518 C MYLAR CMXM1H152J50V 1500PF J
710PCB CD AS CM519 C MYLAR CMXM1H103J50V 0.01MF J (TP)
711PCB CD AS CM520 C MYLAR CMXM1H333J50V 0.033MF J (TP)
712PCB CD AS CM521 C MYLAR CMXM1H103J50V 0.01MF J (TP)
713PCB CD AS CM522 C MYLAR CMXM1H333J50V 0.033MF J (TP)
714PCB CD AS CM523 C MYLAR CMXM1H152J50V 1500PF J
715PCB CD AS CM525 C MYLAR CMXM1H152J50V 1500PF J
716PCB CD AS CN501 CONN AS 9738840800FFC 16P P1.0X250MM R
717PCB CD AS CN508 CONN AS 9738840900FFC 19P P1.25X110MM K
718PCB CD AS CN509 CONN AS 97388321018P 250 P=2.5 BOARDIN
719PCB CD AS CW501 CONN WAFER 9CD625930052807-1610
720PCB CD AS CW502 CONN WAFER 9CD62596002503-WS-2P
721PCB CD AS CW507 CONN WAFER 9CD62594002001-WS-12P
722PCB CD AS CW508 CONN WAFER 973640840052045-1945 19P
723PCB CD AS CW510 CONN AS 9738841800#26 400MM 3P 2.5P
724PCB CD AS D501 DIODE DZN4148---1N4148 AUTO 52MM
725PCB CD AS DZ501~502 DIODE ZENER DZTZ5R6A--MTZ-5.6 52MM TAPPING
726PCB CD AS DZ503 DIODE ZENER DZTZ3R9B--MTZ3.9B
727PCB CD AS DZ504 DIODE ZENER DZTZ5R6A--MTZ-5.6 52MM TAPPING
728PCB CD AS IC501 IC CHIP DSP 1KS9286B--KS9286B DSP+DAC
729PCB CD AS IC502 IC CHIP RF 1KB9223---KB9223 RF+SSP+AF
730PCB CD AS IC503 IC CHIP 1KA9258D--KA9258D
731PCB CD AS IC504~505 IC 1DBL2084--DBL2084(D/W)
732PCB CD AS JW501~502 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
733PCB CD AS JW503 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
734PCB CD AS JW504~510 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
735PCB CD AS JW511 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
736PCB CD AS JW512 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
737PCB CD AS JW513 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
738PCB CD AS JW514~516 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
739PCB CD AS JW517~519 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
740PCB CD AS JW520 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
741PCB CD AS JW521~523 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
742PCB CD AS JW524 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
743PCB CD AS JW525 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
744PCB CD AS JW526 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
745PCB CD AS JW527 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
746PCB CD AS JW528~529 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
747PCB CD AS JW530~534 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
748PCB CD AS JW535 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
749PCB CD AS JW536~538 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
750PCB CD AS JW539 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
751PCB CD AS JW540 R CARBON FILM RD-AZ102J-1/6 1K OHM J
752PCB CD AS JW541 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
753PCB CD AS JW542 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
754PCB CD AS JW543 R CARBON FILM RD-AZ472J-1/6 4.7K OHM J
755PCB CD AS JW544~545 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
756PCB CD AS JW546 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
757PCB CD AS JW547 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
758PCB CD AS JW548 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
759PCB CD AS JW549~554 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
760PCB CD AS JW555 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
761PCB CD AS JW556 WIRE JUMPER W581GY12J5AWG22 1/0.65 SN 12.5 AUTO
762PCB CD AS JW557 WIRE JUMPER W581GY1005AWG22 1/0.65 SN 10 AUTO
763PCB CD AS JW558~559 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
764PCB CD AS JW560 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
765PCB CD AS JW561~562 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
766PCB CD AS JW563~564 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO
767PCB CD AS JW565~575 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
768PCB CD AS JW576 WIRE JUMPER W581GY7595AWG22 1/0.65 SN 7.5 AUTO

PART-CODE PART-DESCNO ASS'Y LOCATION PART-NAME

30

Electrical Parts List

769PCB CD AS JW577 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
770PCB CD AS JW578 WIRE JUMPER W581GY1505AWG22 1/0.65 GY 15 AUTO
771PCB CD AS L501~502 COIL PEAKING 5CPZ101K02100UH K (AXIAL 3.5MM)
772PCB CD AS Q501 TR TZTC3198Y-KTC3198Y-(1815Y) (AUTO)
773PCB CD AS Q502 TR TKSC2331Y-KSC2331Y
774PCB CD AS Q503~504 TR TKSA928AY-KSA928A-Y
775PCB CD AS R501 R CARBON FILM RD-AZ100J-1/6 10 OHM J
776PCB CD AS R502 R CARBON FILM RD-AZ561J-1/6 560 OHM J
777PCB CD AS R503 R CARBON FILM RD-AZ121J-1/6 120 OHM J
778PCB CD AS R504 R CARBON FILM RD-AZ102J-1/6 1K OHM J
779PCB CD AS R505~506 R CARBON FILM RD-AZ332J-1/6 3.3K OHM J
780PCB CD AS R507 R CARBON FILM RD-AZ273J-1/6 27K OHM J
781PCB CD AS R508 R CARBON FILM RD-AZ105J-1/6 1M OHM J
782PCB CD AS R509 R CARBON FILM RD-AZ822J-1/6 8.2K OHM J
783PCB CD AS R510 R CARBON FILM RD-AZ154J-1/6 150K OHM J
784PCB CD AS R511 R CARBON FILM RD-AZ104J-1/6 100K OHM J
785PCB CD AS R512 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
786PCB CD AS R513 R CARBON FILM RD-AZ123J-1/6 12K OHM J
787PCB CD AS R514 R CARBON FILM RD-AZ124J-1/6 120K OHM J
788PCB CD AS R515 R CARBON FILM RD-AZ473J-1/6 47K OHM J
789PCB CD AS R516 R CARBON FILM RD-AZ683J-1/6 68K OHM J
790PCB CD AS R517 R CARBON FILM RD-AZ153J-1/6 15K OHM J
791PCB CD AS R518 R CARBON FILM RD-AZ683J-1/6 68K OHM J
792PCB CD AS R519 R CARBON FILM RD-AZ563J-1/6 56K OHM J
793PCB CD AS R520 R CARBON FILM RD-AZ823J-1/6 82K OHM J
794PCB CD AS R521 R CARBON FILM RD-AZ393J-1/6 39K OHM J
795PCB CD AS R522 R CARBON FILM RD-AZ474J-1/6 470K OHM J
796PCB CD AS R523 R CARBON FILM RD-AZ102J-1/6 1K OHM J
797PCB CD AS R524 R CARBON FILM RD-AZ104J-1/6 100K OHM J
798PCB CD AS R525 R CARBON FILM RD-AZ154J-1/6 150K OHM J
799PCB CD AS R526 R CARBON FILM RD-AZ153J-1/6 15K OHM J
800PCB CD AS R527 R CARBON FILM RD-AZ682J-1/6 6.8K OHM J
801PCB CD AS R528 R CARBON FILM RD-AZ220J-1/6 22 OHM J
802PCB CD AS R529 R CARBON FILM RD-AZ124J-1/6 120K OHM J
803PCB CD AS R530~533 R CARBON FILM RD-AZ683J-1/6 68K OHM J
804PCB CD AS R534 R CARBON FILM RD-AZ124J-1/6 120K OHM J
805PCB CD AS R536~537 R CARBON FILM RD-AZ123J-1/6 12K OHM J
806PCB CD AS R538 R CARBON FILM RD-AZ824J-1/6 820K OHM J
807PCB CD AS R539 R CARBON FILM RD-AZ474J-1/6 470K OHM J
808PCB CD AS R540 R CARBON FILM RD-AZ273J-1/6 27K OHM J
809PCB CD AS R541~543 R CARBON FILM RD-AZ562J-1/6 5.6K OHM J
810PCB CD AS R544 R CARBON FILM RD-AZ273J-1/6 27K OHM J
811PCB CD AS R546~548 R CARBON FILM RD-AZ562J-1/6 5.6K OHM J
812PCB CD AS R549 R CARBON FILM RD-AZ273J-1/6 27K OHM J
813PCB CD AS R550 R CARBON FILM RD-AZ273J-1/6 27K OHM J
814PCB CD AS R551 R CARBON FILM RD-AZ184J-1/6 180K OHM J
815PCB CD AS R552 R CARBON FILM RD-2Y229J-1/2 2.2 OHM J
816PCB CD AS R554~555 R CARBON FILM RD-4Z100J-1/4 10 OHM J
817PCB CD AS R556~561 R CARBON FILM RD-AZ472J-1/6 4.7K OHM J
818PCB CD AS R562 R CARBON FILM RD-AZ103J-1/6 10K OHM J
819PCB CD AS R563~566 R CARBON FILM RD-AZ104J-1/6 100K OHM J
820PCB CD AS R567 R CARBON FILM RD-AZ472J-1/6 4.7K OHM J
821PCB CD AS R568 R CARBON FILM RD-AZ221J-1/6 220 OHM J
822PCB CD AS R569 R CARBON FILM RD-AZ102J-1/6 1K OHM J
823PCB CD AS R574 WIRE JUMPER W581GY6095AWG22 1/0.65 SN 6 AUTO
824PCB CD AS R575 R CARBON FILM RD-AZ104J-1/6 100K OHM J
825PCB CD AS R576 R CARBON FILM RD-AZ103J-1/6 10K OHM J
826PCB CD AS XC501 RESONATOR CERA5PCSA16R93CSA16.93MXZ04
