Installation Instructions
Renaissance Wall Oven
Models:
EOR, MOR
Part No. 102579 Rev. G
All specifications are subject to change without notice. Dacor ® assumes no liability for changes to specifications.
© 2007 Dacor, all rights reserved.
Table of Contents
Before You Begin... ........................................................... 1
Important Safety Instructions .......................................... 1
Important Information About Safety Instructions .............. 1
Safety Symbols and Labels ............................................. 1
General Safety Precautions ............................................. 2
Customer Service Information ......................................... 3
If You Need Help... ........................................................... 3
Appliance Data Plate ....................................................... 3
Model Identification .......................................................... 3
Product Specifications ..................................................... 4
Power Supply Requirements ........................................... 4
Product Dimensions ......................................................... 4
Installation Specifications ................................................ 6
Installation Planning ......................................................... 6
Installation Instructions .................................................... 8
Verify the Package Contents ............................................ 8
Remove the oven door(s) ................................................ 8
Electrical Connection ....................................................... 9
Installing the Oven in the Cabinet .................................. 12
Installing the Exhaust Grill ............................................. 13
Reinstalling the Oven Doors .......................................... 13
Verifying Proper Operation ............................................. 14
Installation Checklist ...................................................... 15
Before You Begin...
Important:
Installer:• In the interest of safety and to minimize problems, read these installation instructions completely and care-
fully before you begin the installation process. Leave these installation instructions with the customer.
Customer:• Keep these installation instructions for future reference and the local electrical inspector’s use.
Important Safety Instructions
Important Information About
Safety Instructions
The • Important Safety Instructions and warnings in
these instructions are not meant to cover all possible
problems and conditions that can occur. Use common
sense and caution when installing, maintaining or operating this or any other appliance.
Always contact the Dacor Customer Service Team about •
problems and conditions that you don’t understand.
See Customer Service Information.
Safety Symbols and Labels
DANGER
Immediate hazards that WILL result in severe personal
injury or death.
WARNING
Hazards or unsafe practices that COULD result in severe
personal injury or death.
DANGER
IMPORTANT: Do not store or use combustible, flam-
mable, or explosive vapors and liquids (such as gasoline)
inside or in the vicinity of this or any other appliance. Also
keep items that could explode, such as aerosol cans,
away from the oven. Do not store flammable or explosive
materials in adjacent cabinets or areas.
WARNING
WARNING – NEVER use this appliance as a space
heater to heat or warm the room. Doing so may result in
carbon monoxide poisoning and overheating of the appliance.
WARNING
WARNING – NEVER cover any slots, holes or passages
in the oven bottom or cover an entire rack with materials
such as aluminum foil. Doing so blocks air flow through
the oven and may cause a fire hazard or carbon monoxide poisoning.
WARNING
CAUTION
Hazards or unsafe practices that COULD result in minor
personal injury or property damage.
READ AND SAVE
THESE INSTRUCTIONS
Do not install this appliance outdoors and/or near water,
for example, near a pool.
WARNING
When using the BROIL and CONVECTION BROIL settings, the oven door must be completely shut.
1
Important Safety Instructions
General Safety Precautions
To reduce the risk of fire, electric shock, serious injury or death when using your appliance, follow basic safety precautions, including the following:
WARNING
Read the accompanying use and care manual 1.
before operating this appliance.
Keep packaging materials away from children. 2.
Plastic sheets and bags can cause suffocation.
If you receive a damaged product, immediately con-3.
tact your dealer or builder. Do not install or use a
damaged appliance. Do not install or use the appliance if the conduit is damaged.
This oven must be properly installed and grounded 4.
by a qualified installer according to these installation instructions prior to use. The installer must
show the customer the location of the circuit breaker panel or fuse box so that they know where and
how to turn off electric power to the oven. Dacor
is not responsible for service required to correct a
faulty installation. The owner is responsible to make
sure this appliance is properly installed.
Do not use the door handle(s) to lift or move the 5.
oven.
A minimum of two people are required to safely 6.
install this appliance.
To avoid an electric shock hazard, do not install this 7.
appliance outside or near water. Do not install or
use this appliance if it has been exposed to water.
Do not install, repair or replace any part of the oven 8.
unless specifically recommended in the literature
accompanying it. A qualified service technician
should perform all other service.
Before performing any type of service or installa-9.
tion, make sure that the electric power to the oven
is turned off at the circuit breaker or fuse box.
Only use the oven for cooking tasks expected of a 10.
home appliance as outlined in the literature accompanying it. This oven is not intended for commercial
use.
Do not climb on any part of the appliance.11.
Do not leave children alone or unattended in the 12.
area around the oven. Do not allow children to play
with the controls, pull on the handle or touch other
parts of the oven.
Do not store items of interest to children above the 13.
oven. Children could be burned or injured while
climbing on the appliance.
Do not tamper with the controls. Do not adjust 14.
or alter any part of the oven unless specifically
instructed to do so in this manual.
WARNING
To prevent injury due to the unit from tipping for-15.
ward, secure the oven to the cabinet using the supplied mounting screws.
Keep flammable items, such as paper, cardboard, 16.
plastic and cloth away from hot surfaces. Do not put
such items in the oven. Do not allow pot holders to
touch hot surfaces.
Do not wear loose or hanging apparel while using 17.
the oven. Do not allow clothing to come into contact
with the interior of the oven and the surrounding
areas during and immediately after use.
Do not use the oven for storage.18.
Do not touch the interior surfaces of the oven during 19.
use. After use, make sure these surfaces have had
sufficient time to cool before touching them.
Do not touch the outside surfaces of the oven dur-20.
ing the self-clean cycle. They will be hot. Venting
from the oven may cause the trim to become hot.
For your safety, do not use the oven to cook without 21.
the convection filter installed. When the filter is not
installed, the spinning fan blades at the back of the
oven are exposed.
Non-stick coatings, when heated, can be harmful to 22.
birds. Remove birds to a separate, well-ventilated
room during cooking.
To prevent damage, remove the meat probe from 23.
the oven when it is not being used.
Do not line the oven with aluminum foil or other 24.
materials. These items can melt or burn up during
self-cleaning and cause permanent damage to the
oven.
Do not leave metal objects, such as aluminum foil, 25.
the meat probe, cookie sheets, etc. on the bottom
of the oven. Objects left on the bottom of the oven
could damage the bake element. In addition, the
objects themselves could be damaged.
Do not allow heating elements in the top and bot-26.
tom of the oven chamber to become covered up
by cookie sheets, aluminum foil, pots, pans, etc.
Covering the heating elements could cause them
to over-heat, damaging the oven. On some models
the heating elements are behind glass panels.
Always ensure that the light fixture lens covers are 27.
in place when using the oven. The lens covers protect the light bulbs from breakage caused by high
oven temperatures or mechanical shock.
2
Customer Service Information
If You Need Help...
If you have questions or problems with installation, con-•
tact your Dacor dealer or the Dacor Customer Service
Team. When you call, have the model and serial number of the appliance ready. The model and serial number are printed on the appliance data plate.
Dacor Customer Service Team
Phone: (800) 793-0093
E-mail: customerservice@Dacor.com
Web site: www.Dacor.com
Appliance Data Plate
The appliance data plate contains the model and serial •
number information and the electrical and gas supply
requirements.
It can be seen through the grill located below the control •
panel. Open the door to expose the grill. On double
ovens, the plate is located behind the top grill.
Model Identification
EORS227SCH
A BC D E
A MODEL:
EOR = Epicure Renaissance
MOR = Millennia Renaissance
B NUMBER OF CONVECTION OVENS:
S = Single
D = Double
C NUMBER OF OVENS:
1 = Single
2 = Double
D WIDTH:
27 = 27 Inch
30 = 30 Inch
36 = 36 Inch
E TRIM:
SCH = Stainless Steel with Chrome Trim
B = Black Handle, Black Trim
BK = Black Handle, Stainless Trim
S = Stainless Handle (Millennia Style)
View data plate
through grate
3
Product Specifications
Power Supply Requirements
It is the owner’s responsibility to ensure that a licensed •
electrician performs the installation of the electrical supply for this appliance. The electrical installation, including minimum supply wire size, must comply with the
National Electric Code ANSI/NFPA 70 (latest revision)
and local codes and ordinances.
A copy of this standard may be obtained from:
National Fire Protection Association
1 Batterymarch Park
Quincy, Massachusetts 02269-9101
The correct voltage, frequency and amperage must be •
supplied to the appliance from a dedicated, grounded,
single phase circuit that is protected by a properly sized
circuit breaker or time-delay fuse. If a time-delay fuse is
utilized, fuse both sides of the line (L1 and L2).
The required voltage, frequency and amperage ratings •
are listed on the appliance data plate (see page 3) and
in the table for reference.
Preheat times and cavity temperature recovery times will •
be increased slightly if operating the unit with less than
a 240 Vac circuit.
This appliance is provided with electrical wiring in a flex-•
ible metal conduit.
Model
Number
EORS127
MORS127
EORS130
MORS130
EORS136 5.3 kW (22 Amp.)
EORS227
MORS227
EORS230
MORS230
EORD227
MORD227
EORD230
MORD230
* The above specifications are for reference only. See the
appliance data plate (page 3) for exact specifications.
Dedicated Circuit
Requirements*
240 Vac 60 Hz,
30 Amp.
240 Vac 60 Hz,
40 Amp.
240 Vac 60 Hz,
50 Amp.
Total Connected
Load
5.0 kW (21 Amp.)
7.8 kW (33 Amp.)
10.0 kW (42 Amp.)
Product Dimensions
All tolerances: +1/16 (1.6 mm). -0, unless otherwise stated.
All Models
Model
Number
EORS127/
MORS127
EORS130/
MORS130
EORS136
EORX227/
MORX227
EORX230/
MORX230
X = Number of convection ovens, see page 3
* Width at light covers on sides
** To top of chassis notch behind control panel
Utility
Cutout
Width (F)
5”
(12.7 cm)
Overall
Width (A)
26 7/8”
(68.3 cm)
29 7/8”
(75.9 cm)
35 7/8”
(91.1 cm)
26 7/8”
(68.3 cm)
29 7/8”
(75.9 cm)
Utility
Cutout
Height (G)
5 ¼”
(13.3 cm)
Chassis
Width (B)*
25 3/8”
(64.5 cm)
28 3/8”
(72.1 cm)
34 3/8”
(87.3 cm)
25 3/8”
(64.5 cm)
28 3/8”
(72.1 cm)
Utility
Cutout
Depth (H)
6”
(15.2 cm)
Overall
Height (C)
28 7/16”
(72.2 cm)
28 5/8”
(72.7 cm)
49 15/16”
(127.0 cm)
Control
Panel
Depth (J)
1”
(2.54 cm)
Chassis
Height (D)**
27 1/2”
(69.9 cm)
27 5/8”
(70.2 cm)
49 1/16”
(124.6 cm)
Notch
Depth (K)
1 1/8”
(2.9 cm)
Control Panel
Overlay (E)
15/16”
(23.8 cm)
1” (2.5 cm)
7/8”
(2.2 cm)
Chassis
Depth (L)
24”
(61.0 cm)
Notch
Height (M)
1”
(2.5 cm)
4
C
J
B
H
G
F
A
Chassis Notch
Side View
Control Panel
Front
Top of
Chassis
Top of
Chassis
Conduit:
60” (152 cm)
Long
K
L
M
E
D
C
J
B
H
G
F
A
K
L
M
E
Chassis Notch
Side View
Control Panel
Front
Top of
Chassis
Top of
Chassis
Conduit:
60” (152 cm)
Long
D
Design Specifications
3 3/8”
(8.6 cm)
1”
(2.5 cm)
1”
(2.5 cm)
21 1/8”
Product Dimensions
All tolerances: +1/16 (1.6 mm). -0, unless otherwise stated.
*
Light
Cover
Single Oven
* Width at light
covers on both sides
Light Covers
*
Epicure Millennia -
Handle Dimensions
Handle is integral
Double Oven
5
Installation Specifications
Installation Planning
WARNING
Observe all governing codes and ordinances during planning and installation. Contact your local building department for further information.
IMPORTANT
Locate the junction box so that the oven may be easily •
disconnected in the event that it needs to be removed
from the wall completely for service.
If the oven is not installed level it may deliver poor or •
inconsistent baking results.
A qualified technician must complete the installation of •
this built-in appliance. Proper installation is the responsibility of the customer.
Carefully check the location where the oven is to be •
installed. The oven should be placed for convenient
access. Make certain that electrical power, meeting
the specifications on page 4, can be provided in the
selected location.
Dacor recommends installing the electrical junction box •
in the one of the locations shown.
Install the junction box in a location that allows the oven •
to be removed from the the cut out for service without
being disconnected.
Plan the installation so that all minimum clearances are •
met or exceeded. Dimensions shown provide minimum clearances, unless otherwise noted. Be certain
that proper clearance is provided for the oven door
when it is in the open position according the Product
Dimensions.
Cabinet cutout dimensions must be used as indicated.•
The specified minimum cabinet depth and width must
be provided. The cabinet depth and width must completely enclose the recessed portion of the oven.
All contact surfaces between the appliance and the cabi-•
net must be solid and level.
Provide a platform within the cabinet to support the •
oven. It must be installed level and straight. The top
edge of the platform must be flush with the cut out at
the front of the cabinet. There are no provisions to level
the oven after it has been installed. 3/4” (1.9 cm) thick
plywood is recommended.
Cabinet Dimensions
Model
Number
EORS127/
MORS127
EORS130/
MOCS130
EORS136 36” (91.4 cm) 34 ½” (87.6 cm) 27 ¾” (70.5 cm)
EORX227/
MORX227
EORX230/
MORX230
X = Number of convection ovens, see page 3
Minimum Cabinet
Width (N)
27” (68.6 cm) 25 ½” (64.8 cm)
30” (76.2 cm) 28 ½” (72.4 cm))
27” (68.6 cm) 25 ½” (64.8 cm)
30” (76.2 cm) 28 ½” (72.4 cm)
Minimum Interior Cabinet Depth: 24” (61.0 cm)
Minimum Cut Out
Width (P)
Minimum Cut out
Height (R)
27 5/8” (70.2 cm)
49 1/8” (124.8 cm)
6
4” Typical Toe Kick
Recommended
Electrical
Location
N
P
R
3/4” (1.9 cm)
Support Platform
1” (2.5 cm) min.
to bottom of
cabinet door
1” (2.5 cm) min.
to top of
drawer face
9 5/8” (24.4 cm)
Recommended
Recommended
Electrical
Location
Alternate
Electrical
Location
4” Typical Toe Kick
N
P
R
3/4” (1.9 cm)
Support Platform
31 1/4” (79.4 cm)
Recommended
1” (2.5 cm) min.
to bottom of
cabinet door
1” (2.5 cm) min.
to top of
cabinet door
1 1/2”
(3.8 cm)
Typical Counter
1“ (2.5 cm) min.
to combustible floor
3/4” (1.9 cm)
Support Platform
1“ (25mm) min. to combustibles
Recommended
Electrical
Location
4” Typical Toe Kick
36”
(91.4 cm)
P
R
Cabinet Dimensions
Installation Specifications
Single Wall Oven - Cut Out Dimensions Double Wall Oven - Cut Out Dimensions
Single Wall Oven - Installed Under Counter
7
Installation Instructions
30º
Verify the Package Contents
Verify that all the components below have been provided. If any item is missing or damaged, please contact your dealer
immediately. Do not install a damaged or incomplete appliance. Make sure that you have everything necessary to ensure
proper installation before proceeding.
Use and care manual•
Mounting screws (Wood, #6 X ¾, Dacor PN 83331, 4 for •
single ovens, 6 for double ovens)
Standard oven racks (single ovens come with 2, double •
ovens come with either 4 or 5)
GlideRack™• oven rack (1)
Broil grill and pan•
Remove the oven door(s)
Remove the door(s) to reduce weight and make the
oven easier to lift:
WARNING
Do not attempt to disengage the hinge catches with •
the door removed from the oven. The hinge springs
could release, causing personal injury.
Do not lift or carry oven door by the door handle.•
On double ovens, remove the bottom door first to •
reduce the chance of damage.
Exhaust grill with 2 mounting screws (2, #8 X 3/8”, color •
should match exhaust grill: Silver Dacor PN 83571,
Black Dacor PN 83263)
Light Lens Pry Stick•
Dacor Stainless Steel Cleaner (stainless steel models •
only)
Meat probe•
Removing the Oven Door(s): All Models
Except EORS136
See facing page for removing door from model
EORS136.
Open the door to its fully opened position.1.
Rotate the catch over the retaining arm on 2. both hinges.
Lifttheovendoortoabouta30˚anglefromthehorizon-3.
tal.
Pull the door away from the oven while continuing to lift.4.
Catch
Grab both sides of the
Step 2
door and pull out at a 30°
angle to remove.
Gripping
point
Steps 3 and 4
Gripping
point
8
Installation Instructions
Removing the Oven Door on Model
EORS136:
Open the door to its fully opened position.1.
Rotate the catch over the retaining arm on each hinge.2.
Retaining
Catch
arm
angle to remove.
Lift the oven door to about a 15° angle from the vertical 3.
position.
Hold the door with both hands just below the handle and 4.
pull it away from the oven while continuing to lift.
Gripping
point
Gripping
point
Steps 1 and 2
Electrical Connection
WARNING
If the electrical service provided does not meet the •
Product Specifications (see page 4), do not proceed
with the installation. Call a licensed electrician to cor-
rectly install the required wiring.
Failure to disconnect power prior to installation may •
result in an electrical shock or fire hazard.
Do not turn on power to the appliance until the oven is •
properly grounded according to these instructions.
The installer must connect the ground terminal (or •
lead) on the appliance to a grounded, metallic, permanent wiring system or grounding conductor. Failure to
do so may result in an electric shock hazard.
Do not use an extension cord with this appliance. Such •
use may result in fire, electric shock or personal injury.
Do not install a fuse in the neutral or ground circuit. A •
fuse in the neutral or ground circuit may result in an
electric shock hazard.
The appliance must be connected to the power supply •
with copper wire only. The use of aluminum wire may
result in unsatisfactory conditions.
IMPORTANT
Steps 3 and 4
NOTE
The electrical connection leads from the supplied appliance conduit may be a smaller gage than the standard
household wiring of the dedicated supply circuit. They
are suitable for connection to household wiring under the
jurisdiction of the National Electric Code, and/or the local
inspection authority.
Before proceeding, turn off power to the circuit to which 1.
the oven will be connected at the circuit breaker or fuse
box.
Position the oven directly in front of the cabinet cut out.2.
Feed the appliance conduit into the electrical junction 3.
box and attach it using a UL approved strain relief.
Depending upon local codes, utilize one of three meth-4.
ods to connect the appliance to the electrical power:
Connect to a four wire electrical system◊
Connect to a three wire electrical system, where ◊
local codes permit
Connect to a three wire electrical system with ◊
external ground, according to local codes.
See the instructions on the following pages for detailed
directions.
Provide slack in the conduit to allow the oven to slide forward for servicing.
9
Installation Instructions
Electrical Connection - (continued)
Connecting to a Four Wire Electrical
System
Separate the wires coming out of the appliance conduit.1.
Connect the white wire from the appliance conduit to the 2.
white (neutral) supply wire in the junction box.
Connect the black wire from the appliance conduit to the 3.
black (L1) supply wire in the junction box.
Connect the red wire from the appliance conduit to the 4.
red (L2) supply wire in the junction box.
Connect the green wire from the appliance conduit to the 5.
green (ground) wire in the junction box.
Incoming power
Junction box
Wire nut,
4 places
Connecting to a Three Wire Electrical
System - Where Local Codes Permit
WARNING
Do not connect the green appliance conduit wire to the
neutral (white) junction box wire unless local building
codes permit.
Separate the wires coming out of the 1. appliance conduit.
Connect the 2. green and white wires from the appliance
conduit to the white (neutral) supply wire in the junction
box.
Connect the black wire from the appliance conduit to the 3.
black (L1) supply wire in the junction box.
Connect the red wire from the 4. appliance conduit to the
red (L2) supply wire in the junction box.
Incoming power
Junction box
Wire nut,
3 places
10
Conduit to
oven
Four Wire Connection
Conduit to
oven
Three Wire Connection
Installation Instructions
Connecting to a Three Wire Electrical
System with External Ground - Where Local
Codes Permit
WARNING
Do not ground the appliance to a gas supply pipe or •
hot water pipe.
If connecting the ground wire to a grounded cold water •
pipe, connect using a separate copper grounding
wire (No. 10 minimum) and a clamp with an external
grounding screw. The grounded cold water pipe must
have metal continuity to electrical ground and must not
be interrupted by insulating materials. Any insulating
materials must be jumped, with a minimum, 4 AWG
wire to establish continuity to ground.
NOTE
If the junction box has been properly grounded by a
licensed electrician, the green (ground) wire from the
appliance conduit may be connected to the junction box
using a loop terminal.
Incoming
Power
4 AWG wire
(minimum)
Insulating device
Clamps
Bare metal
Insulated Pipe Jumper
To connect the green appliance conduit wire to a
grounded cold water pipe:
Separate the wires coming out of the 1. appliance conduit.
Connect the white wire2. from the appliance conduit to the
white (neutral) supply wire in the junction box.
Connect the black wire from the appliance conduit to the 3.
black (L1) supply wire in the junction box.
Connect the red wire from the 4. appliance conduit to the
red (L2) supply wire in the junction box.
Connect the green wire from the 5. appliance conduit to a
grounded cold water pipe as shown. Jumper any insulating materials as shown above with a length of No. 4
copper wire. Securely clamp the wire to bare metal at
both ends.
Junction Box
Wire Nut,
4 Places
Separate 10 AWG
Wire Minimum
Clamp wire tightly
to pipe
Conduit to
oven
Three Wire Connection with External Ground
11
Installation Instructions
Installing the Oven in the Cabinet
WARNING
Failure to properly install the mounting screws may •
result in movement or tipping of the oven during use
resulting in personal injury.
Do not block the oven air exhaust located at the bot-•
tom of the oven. Blocking the intake may result in a
fire hazard, cabinet damage or poor performance.
The wall oven is heavy. Do not attempt to install it in •
the cabinet with less than two people.
Lift the wall oven up to the cabinet cut out, using the 1.
upper edge of the cavity opening and the bottom of the
oven case side as gripping points. Be certain to take all
necessary safety precautions due to the weight of the
appliance.
Locate the mounting holes in the trim on both sides of 3.
the oven. There are four (4) holes, two (2) on each
side, for single oven models and six (6) holes for double oven models.
Use a 1/16” drill bit to drill pilot holes in the cabinet 4.
through all of the trim mounting holes.
Install all of the provided #6 screws through the oven 5.
trim into the cabinet to secure the oven. Do not overtighten the screws.
Gripping
point
Gripping point:
case bottom
both sides
Resting the oven on the cabinet-mounting platform, slide 2.
the oven into the recessed area until the rear edge of
the oven frame is flush with the cabinet face and the
oven is centered within the cut out. Ensure that the
electrical conduit slides through the opening in the
cabinet platform or coils above the oven chassis as the
oven is slid into place. The cable must be placed into
the recessed area located along the rear vertical edge
of the oven or coiled above the oven chassis. Do not
trap the appliance cable between the oven case back
and the rear wall.
12
Mounting Screws:
Four (4) for single oven
Six (6) for double oven
Installation Instructions
30º
Installing the Exhaust Grill
With the oven secured to the cabinet, install the exhaust
grill by mounting it to the oven with the two (2) provided
screws.
Reinstalling the Oven Doors
WARNING
Failure to fully rotate the hinge catches will result in a
safety hazard and may cause personal injury due to the
door falling off its hinges. Also damage to the oven and/or
improper door alignment may occur.
CAUTION
On double ovens, install the top door first to reduce the
chance of damaging the lower door during installation.
NOTE: To re-install the oven door on model EORS136,
see page 14.
Grasp the oven door on opposite sides and lift it until the 1.
door hinges are aligned with the openings in the oven
frame.
Holdingthedooratabouta30˚anglefromthehorizon-2.
tal, slide the hinges into the openings until the bottom
hinge arms drop fully into the hinge receptacles.
Insert door at
30° angle
Lower the door to the fully opened position. Rotate 3. both
hinge catches toward the oven. Open and close the
door slowly and completely to ensure that it is properly
installed.
Catch
13
Installation Instructions
Reinstalling the Oven Door (Cont)
To re-install the oven door on model EORS136:
WARNING
To avoid personal injury or damage to the door from
it falling off its hinges:
Make sure that the notch on the bottom of each hinge •
rests on top of the lower lip of each hinge receptacle
before attempting to open the oven door.
Rotate the hinge locks toward the front of the range •
immediately after installation of the door.
Grasp the oven door on opposite sides and hold it at a 1.
15° angle from the front of the oven. Slide the hinges
into the hinge openings, resting the bottom of the hinge
arms on the hinge receptacles. Continue to hold the
door at a 15° angle with one hand while pushing in on
each of the bottom corners of the door. Push until the
notch on the bottom of each hinge slips over the lower
lip of each hinge receptacle.
Lower the door to the fully opened position.2.
Rotate the two hinge locks toward the oven.3.
Slowly and carefully open and close the door completely 4.
to ensure that it is properly installed.
Verifying Proper Operation
For stainless steel ovens, peel off the protective layer of 1.
plastic that covers the stainless steel surfaces.
Remove any packaging from inside the oven(s).2.
Slide the oven racks onto the supports inside the oven 3.
chamber(s) according to the use and care manual.
Turn on power to the oven at the circuit breaker or fuse 4.
box.
Set the clock according to the use and care manual.5.
NOTE
For double ovens, test oven operation for both the upper
and lower ovens.
Press the 6. BAKE key on the control panel. The default
bake temperature should appear on the display.
Press 7. START. After approximately three (3) minutes,
the lower heating element should glow red through the
glass.
Press 8. CANCEL/SECURE.
Press the 9. BROIL key on the control panel. The default
broil temperature should appear on the display.
Press 10. START. After approximately three (3) minutes,
the upper heating element should glow red. On some
ovens the element is behind the glass panel on the
ceiling of the oven.
If the oven does not operate properly, follow these 11.
troubleshooting steps:
Verify that power is being supplied to the oven.•
If power is being properly supplied, turn off power at the •
circuit breaker or fuse box an check the electrical connections.
Turn on power and repeat the above heating test.•
If the appliance still does not work, contact an authorized •
Dacor service company. If you are unable to locate
a service representative, please contact the Dacor
Customer Service Team at (800) 793-0093, or visit us
on the web at www.Dacor.com.
Do not attempt to repair the appliance yourself. If you •
need service, be sure to have the model and serial
numbers available when you call. See page 3.
Notch on bottom
of hinge
14
Lower lip of
hinge receptacle
Installation Instructions
Installation Checklist
WARNING
To ensure proper installation, the installer must complete
the checklist below to make sure that no part of the installation has been overlooked.
□
Is the oven mount on a level platform?
Is the oven wired and grounded according to these □
instructions and in accordance with all applicable electrical codes? (See Pages 4 and 9-11.)
□
Is the oven secured into the cabinet with all the mount-
ing screws [four (4) on single oven models, six (6) on
double ovens.] See Page 12.
□
Is/are the oven door(s) properly installed according to
these instructions. (See page 13.)
Has proper operation been verified? □
Has the warranty been activated on-line or the warranty □
card been filled out completely and mailed?
15
Notes
16
Dacor ● 1440 Bridge Gate Drive, Diamond Bar, CA 91765 ● Tel: (800) 793-0093 ● FAX: (626) 403-3130 ● www.Dacor.com
Loading...
