Dacor MMD30, MMD24 User Manual
Microwave In-A-Drawer
Use and Care Manual
Model MMDV30S
For Use With:
™
Table of Contents
Important Safety Instructions .................... 1-2
Information You Need to Know ................... 3-5
Part Names ................................................. 6
Before Operating ......................................... 7
To Set The Clock ..................................... 7
Timer .................................................... 7
Stop/Clear ............................................. 7
Open or Close Drawer ............................ 7
Microwave In-A-Drawer
Time Cooking ......................................... 8
To Set Power Level .................................. 8
Sensor Settings ...................................... 8
Sensor Popcorn / Sensor Reheat ............... 9
Sensor Cooking .....................................10
Defrost.................................................11
Manual Defrost ......................................11
Reheat .................................................12
™
Cooking ..............8-12
MMDV30S
MMD30
MMD24
Other Features ......................................13-14
Micro Warm ..........................................13
Help ....................................................13
More or Less Time Adjustment ................13
Multiple Sequence Cooking .....................13
Easy Minute ..........................................13
Setup/Help ...........................................13
Audible Signal Elimination .......................14
End of Cooking Reminder ........................14
Auto Start ............................................14
Demonstration Mode ..............................14
Control Lock .........................................14
Cleaning and Care ......................................15
Before You Call for Service ...........................16
Auto-Touch Guide ..................................17-18
Product Warranty .......................................19
Warranty Card ...............................Back Cover
Part No. 101590 Rev. D TINSEB494MRR1
Copyright © 2007 by Dacor Inc. All rights reserved.
Important Safety Instructions
Installer: Leave these instructions with the appliance.
Customer: Please read and keep this Use & Care Manual
for future reference. This guide provides proper use and
maintenance information. Keep this guide and the
sales receipt and/or cancelled check in a safe place
for future reference. Proof of original purchase date
is needed for warranty service.
If you have any questions, call:
Dacor® Customer Service
1-800-793-0093 (U.S.A. and Canada)
Monday — Friday 6:00 a m to 5:00 p m Pacic Time
website: www.Dacor.com
Have complete model and serial number identication
of your appliance ready. These numbers are found on a
serial plate, located on faceplate behind the drawer front.
Record these numbers below for easy access.
Model Number __________________________________
Serial Number __________________________________
Date of Purchase________________________________
For service and warranty information, see page 19.
At Dacor, we continuously improve the quality and perfor-
mance of all our products. We may need to make changes
to this appliance without updating these instructions.
(a) Do not attempt to operate this oven with the door
(b) Do not place any object between the oven front
(c) Do not operate the oven if it is damaged. It is par-
(d) The oven should not be adjusted or repaired by
Grounding Instructions
IMPORTANT INFORMATION ABOUT SAFETY
INSTRUCTIONS
WARNING
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY
open since open-door operation can result in harmful exposure to microwave energy. It is important
not to defeat or tamper with the safety interlocks.
face and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
ticularly important that the oven door close properly
and that there is no damage to the: (1) drawer
head (bent), (2) glides and latches (broken or loosened), (3) drawer seals and sealing surfaces.
anyone except properly qualied service personnel.
WARNING
The Important Safety Instructions and warnings in this
manual are not meant to cover all possible conditions and
situations that can occur. Use common sense and caution
when installing, maintaining or operating this or any other
appliance.
Always contact the Dacor Customer Service Team about
problems or situations that you do not understand.
SAFETY SYMBOLS AND LABELS
DANGER
Immediate hazards that WILL result in severe personal
injury or death.
WARNING
Hazards or unsafe practices that COULD result in severe
personal injury or death.
CAUTION
Hazards or unsafe practices that COULD result in minor
personal injury or property damage.
Improper use of the grounding plug can result in a risk
of electric shock.
This appliance is equipped with a three-prong grounding
plug for your protection against possible electric shock
hazards. It must be plugged into a grounded wall receptacle. If only a two-prong wall receptacle is available, it is
the responsibility of the customer to have it replaced with
a properly grounded three-prong wall receptacle. Do not
under any circumstances, cut or remove the third
(ground) prong from the power cord. Do not use an
adapter plug. Do not use an extension cord. If the power
supply cord is too short, have a qualied electrician or
serviceman install an outlet near the appliance. Do not
use a Ground Fault Circuit Interrupter.
Power supply cord with
three-prong grounding plug
Grounding type wall receptacle
(ground fault circuit not allowed)
E1
Important Safety Instructions
WARNING
When using the Appliance, basic safety precautions should be followed, including the following:
WARNING
1. Read all instructions before using the appliance.
2. Read and follow the specic “PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” on page 1.
3. This appliance must be properly grounded. See
page 1 and separate Installation Instructions for
grounding instructions .
4. Install or locate this appliance only in accordance
with the provided Installation Instructions.
5. Some products such as whole eggs and sealed containers - for example, closed glass jars—are able to
explode and should not be heated in the drawer.
6. Use this appliance only for its intended use as
described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This micro-
wave is specically designed to heat, cook or dry
food. It is not designed for industrial or laboratory
use.
7. As with any appliance, close supervision is neces-
sary when used by children.
8. Do not operate this appliance if it has a damaged
cord or plug, if it is not working properly or if it has
been damaged or dropped.
9. This appliance should be serviced only by qualied
service personnel. Contact nearest Dacor Autho-
rized Servicer for examination, repair or adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store or use this appliance outdoors. Do not
use this product near water—for example, near a
kitchen sink, in a wet basement, near a swimming
pool or similar locations.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. Do not climb or sit on the drawer.
15. Be sure that ngers or other objects or materials
are not around the drawer opening when the Appliance is closed.
16. Do not put ngers or clothes around the drawer
guides when the Appliance is opened or closed.
They could be caught in the guides when the
drawer is closed.
To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave
energy:
17. Be sure that the food and container are shorter
than the Appliance before closing it. You can refer
to the height of the side walls of the drawer.
18. When cleaning drawer sealing surfaces that come
together on closing the drawer, use only mild, nonabrasive soaps or detergents applied with a sponge
or soft cloth. See cleaning instructions on page 15.
19. To reduce the risk of re in the Appliance cavity:
a. Do not overcook food. Carefully attend appli-
ance when paper, plastic or other combustible
materials are placed inside the drawer to facilitate cooking.
b. Remove wire twist-ties from paper or plastic
bags before placing bag in Drawer.
c. If materials inside the Appliance ignite, keep
drawer door closed, turn microwave off and
shut off power at the fuse or circuit breaker
panel.
d. Do not use the drawer for storage purposes.
Do not leave paper products, cooking utensils,
or food in the Drawer when not in use.
20. Liquids, such as water, coffee or tea are able to
be overheated beyond the boiling point without
appearing to be boiling due to surface tension of
the liquid. Visible bubbling or boiling when the
container is removed from the Appliance is not
always present. THIS COULD RESULT IN VERY
HOT LIQUIDS SUDDENLY BOILING OVER WHEN
A SPOON OR OTHER UTENSIL IS INSERTED INTO
THE LIQUID.
To reduce the risk of injury to persons:
a. Do not overheat the liquid.
b. Stir the liquid both before and halfway through
heating it.
c. Do not use straight-sided containers with
narrow necks. Use a wide-mouthed container.
d. After heating, allow the container to stand
in the Drawer for at least 20 seconds before
removing the container.
e. Use extreme care when inserting a spoon or
other utensil into the container.
21. If the Appliance light fails, consult a DACOR
AUTHORIZED SERVICER.
READ AND SAvE ThESE INSTRucTIoNS
E2
Information You Need To Know
The Microwave In-A-Drawer™ is for food preparation only.
About Unpacking And Examining
Your Microwave In-A-Drawer
Remove all packing 1.
materials from inside
the Microwave InA-Drawer™. DO NOT
REMOVE THE WAVEGUIDE COVER, which
is located on the top of
the Microwave In-ADrawer™.
Remove the feature 2.
sticker, if there is one.
Check the drawer for
any damage, such as
misaligned or bent
drawer, damaged drawer seals and sealing surfaces, broken or loose drawer
guides and dents inside the cavity or on the front side
of the drawer. If there is any damage, do not operate
the Microwave In-A-Drawer™ and contact your dealer
or a DACOR AUTHORIZED SERVICER.
RADIO OR TV INTERFERENCE
Should there be any interference caused by the Microwave
In-A-Drawer™ to your radio or TV, check that the Drawer is
on a different electrical circuit, relocate the radio or TV as
far away from the drawer as feasible or check position and
signal of receiving antenna.
Sealing
Surface
Waveguide
Cover
™
Sealing
Surface
Oven
Cavity
About Your Microwave In-ADrawer
ALWAYS have food in the Drawer when it is on to absorb
the microwave energy.
The vent under the Microwave In-A-Drawer™ must not be
blocked. During microwaving, steam may come from the
right side of the vent.
When using the Microwave In-A-Drawer™ at power levels
below 100%, you may hear the magnetron cycling on and
off. It is normal for the exterior of the drawer to be warm
to the touch when cooking or reheating.
Condensation is a normal part of microwave cooking.
Room humidity and the moisture in food will inuence the
amount of moisture that condenses in the Drawer. Generally, covered foods will not cause as much condensation
as uncovered ones.
™
It should not be used to dry clothes or newspapers.
Your Microwave In-A-Drawer™ is rated 950 watts by using
the IEC Test Procedure. In using recipes or package directions, check food one or two minutes before the minimum
time and add time accordingly.
When opening or closing the Microwave In-A-Drawer
quickly, food in the Drawer may be spilled. To clean,
please refer to the Cleaning and Care section on page 15.
About Microwave Cooking
Doneness signs include:
- Food steams throughout, not just at edge.
- Poultry thigh joints move easily.
- Meat and poultry show no pinkness.
- Fish is opaque and akes easily with a fork.
™
Arrange food carefully. Place thickest areas towards •
outside of dish.
Watch cooking time. Cook for the shortest amount of •
time indicated and add more as needed. Food severely overcooked can smoke or ignite.
Cover foods while cooking. Check recipe or cookbook •
for suggestions: paper towels, wax paper, microwave
plastic wrap or a lid. Covers prevent spattering and
help foods to cook evenly.
Shield with small at pieces of aluminum foil any thin •
areas of meat or poultry to prevent overcooking before dense, thick areas are cooked thoroughly.
Stir foods from outside to center of dish once or twice •
during cooking, if possible.
Turn foods over once during microwaving to speed •
cooking of such foods as chicken and hamburgers.
Large items like roasts must be turned over at least
once.
Rearrange foods such as meatballs halfway through •
cooking both from top to bottom and from right to
left.
Add standing time. Remove food from Drawer and stir, •
if possible. Cover during standing time, allowing the
food to nish cooking without overcooking.
Check for doneness. Look for signs indicating that •
cooking temperatures have been reached.
E3
Information You Need To Know
About Utensils And Coverings
It is not necessary to buy all new cookware. Many pieces
already in your kitchen can be used successfully in your
new Microwave. Make sure the utensil does not touch the
interior walls during cooking.
Use these utensils for safe microwave cooking and
reheating:
glass ceramic (Pyroceram•
heat-resistant glass (Pyrex•
microwave-safe plastics•
microwave-safe paper plates•
microwave-safe pottery, stoneware and porcelain•
browning dish (Do not exceed recommended preheat-•
ing time Follow manufacturer’s directions.)
These items can be used for short time reheating of foods
that have little fat or sugar in them:
wood, straw, wicker•
®
), such as Corningware
®
)
DO NOT USE
metal pans and bakeware•
dishes with metallic trim•
non-heat-resistant glass•
non-microwave-safe plastics (margarine tubs)•
recycled paper products•
brown paper bags•
food storage bags•
metal twist-ties•
Should you wish to check if a dish is safe for microwaving, place the empty dish in the microwave on HIGH for
30 seconds. A dish which becomes very hot should not be
used.
THE FOLLOWING COVERINGS ARE IDEAL:
Paper towels are good for covering foods for reheating •
and absorbing fat while cooking bacon.
Wax paper can be used for cooking and reheating.•
Plastic wrap that is specially marked for microwave •
use can be used for cooking and reheating. DO NOT
allow plastic wrap to touch food. Vent so steam can
escape.
Lids that are microwave-safe are a good choice •
because heat is kept near the food to hasten cooking.
Oven cooking bags are good for large meats or foods •
that need tenderizing. DO NOT use metal twist ties.
Remember to slit bag so steam can escape.
®
HOW TO USE ALUMINUM FOIL IN YOUR
DRAWER:
Should you have questions about utensils or coverings,
check a good microwave cookbook or follow recipe
suggestions.
ACCESSORIES:
There are many microwave accessories available for purchase. Evaluate carefully before you purchase so that they
meet your needs. A microwave-safe thermometer will assist you in determining correct doneness and assure you
that foods have been cooked to safe temperatures. Dacor
is not responsible for any damage to the Drawer when accessories are used.
Open Or Close Drawer
Always press the OPEN or CLOSE pad on the control panel
to open or close the Drawer.
Do not push or pull the Drawer by hand, except in
case of emergency, such as a power failure. If necessary, push or pull slowly.
About Children And The
Microwave
Children below the age of 7 should use the Microwave InA-Drawer™ with a supervising person very near to them.
Between the ages of 7 and 12, the supervising person
should be in the same room. The child must be able to
reach the drawer comfortably.
At no time should anyone be allowed to lean or sit on the
Microwave In-A-Drawer™.
Children should be taught all safety precautions: use potholders, remove coverings carefully, pay special attention
to packages that crisp food because they may be extra
hot.
Do not assume because a child has mastered one cooking
skill that he/she can cook everything.
Children need to learn that the Microwave In-A-Drawer™ is
not a toy. See page 13 for Control Lock feature.
Small at pieces of aluminum foil placed smoothly on •
the food can be used to shield areas that are either
defrosting or cooking too quickly.
Foil should not come closer than one inch to any sur-•
face of the Microwave In-A-Drawer™.
E4
Information You Need To Know
About Safety
Check foods to see that they are cooked to the United States Department of Agriculture’s recommended temperatures.
160˚F - For fresh pork, ground meat, boneless white poultry, sh, seafood, egg dishes and frozen prepared food.
165˚F - For leftovers, ready-to-reheat refrigerated; deli and carry-out “fresh” food.
170˚F - White meat of poultry.
180˚F - Dark meat of poultry.
™
To test for doneness, insert a meat thermometer in a
thick or dense area away from fat or bone. NEVER leave
the thermometer in the food during cooking, unless it is
approved for microwave use.
ALWAYS use potholders to prevent burns when •
handling utensils that are in contact with hot food.
Enough heat from the food can transfer through utensils to cause skin burns.
Avoid steam burns by directing steam away from •
the face and hands. Slowly lift the farthest edge of a
dish’s covering and carefully open popcorn and oven
cooking bags away from the face.
Stay near the Microwave In-A-Drawer•
and check cooking progress frequently so that there is
no chance of overcooking food.
NEVER use the Microwave In-A-Drawer•
cookbooks or other items.
Select, store and handle food carefully to preserve •
its high quality and minimize the spread of foodborne
bacteria.
Keep waveguide cover clean. Food residue can cause •
arcing and/or res. See page 15.
while it’s in use
™
for storing
About Foods
FOOD DO DON’T
Eggs, sausages,
fruits & vegetables
Popcorn Use specially bagged popcorn for the •
Baby food Transfer baby food to small dish and •
General Cut baked goods with lling after •
Puncture egg yolks before cooking to •
prevent “explosion”.
Pierce skins of potatoes, apples, •
squash, hot dogs and sausages so
that steam escapes.
microwave.
Listen while popping corn for the pop-•
ping to slow to 1 or 2 seconds or use
the special SENSOR POPCORN pad.
heat carefully, stirring often. Check
temperature before serving.
Put nipples on bottles after heating •
and shake thoroughly. “Wrist” test
before feeding.
heating to release steam and avoid
burns.
Stir liquids briskly before and after •
heating to avoid “eruption”.
Use deep bowl, when cooking liquids •
or cereals, to prevent boilovers.
Food should be shorter than the •
drawer. Please refer to the height of
side walls of the drawer.
Cook eggs in shells.•
Reheat whole eggs.•
Dry nuts or seeds in shells.•
Pop popcorn in regular brown bags or glass •
bowls.
Exceed maximum time on popcorn package.•
Heat disposable bottles.•
Heat bottles with nipples on.•
Heat baby food in original jars.•
Heat or cook in closed glass jars or airtight •
containers.
Can in the microwave as harmful bacteria may •
not be destroyed.
Deep fat fry.•
Dry wood, gourds, herbs or wet papers.•
E5
Part Names
Microwave In-A-Drawer
1
2
3
Control Panel1.
Waveguide Cover DO NOT REMOVE 2.
Menu Label 3.
Drawer Sealing Surfaces4.
Drawer Light 5.
Vent7.
Rating Label for models MMDV30 and MMD308.
Rating Label for model MMD24: Open the 9.
Microwave Drawer fully. The label is slightly
beyond the back wall of the microwave cavity,
facing up from the at surface.
™
9
4
5
8
6
7
Drawer Guides6.
KEYSHEET
9 13 7914 13 11 10 12
13 7 8 7
Numbers next to the keysheet illustration indicate pages on
which there are feature descriptions and usage information.
E6
Before Operating
Before operating your new Microwave In-A-Drawer™ make
sure you read and understand this operation manual
completely.
Before the Microwave In-A-Drawer•
follow these steps:
Plug in the Microwave In-A-Drawer1.
MICRO-
CLOCK
Touch the 2. STOP/CLEAR pad.
Set clock.3.
WAVE TOUCH CLEAR AND TOUCH
will appear.
To Set The Clock
Touch the 1. TIMER/CLOCK pad and number 2.
Touch the number pads for correct time of day and 2.
touch the TIMER/CLOCK pad again.
This is a 12 hour clock. If you attempt to enter an incorrect
clock time,
STOP/CLEAR pad and re-enter the time.
ERROR
will appear in the display. Touch the
™
can be used,
™
ENJOY YOUR
.
:
will appear.
Timer
Touch the 1. TIMER/CLOCK pad and number 1.
Enter time.2.
Touch the 3. TIMER/CLOCK pad again.
To cancel timer, touch the4. STOP/CLEAR.
Stop/Clear
Touch the STOP/CLEAR pad to:
Erase if you make a mistake during programming.1.
Cancel timer.2.
Stop the Microwave In-A-Drawer3.
timed cooking.
Return the time of day to the display.4.
Cancel a program during cooking, touch twice for 5.
timed cooking.
™
temporarily during
If the electrical power supply to your Microwave •
In-A-Drawer™ should be interrupted, the display will
intermittently show
TOUCH CLEAR
power is reinstated. If this occurs during cooking, the
program will be erased. The time of day will also be
erased. Simply touch the STOP/CLEAR pad and reset
the clock for the correct time of day.
NOTE:
The Microwave In-A-Drawer•
the drawer open except for START/EASY MINUTE.
ENJOY YOUR
AND TOUCH CLOCK
™
can be programmed with
MICRO-
WAVE
after the
Open Or Close Drawer
Always press the OPEN or CLOSE pad on the control
panel to open or close the Drawer.
Do not push or pull the Drawer by hand, except in case of
emergency, such as a power failure. If necessary, push or
pull slowly.
E7
Microwave In-A-Drawer
™
Cooking
Time Cooking
Your Microwave In-A-Drawer™ can be programmed for
99 minutes 99 seconds (99.99). Always enter the seconds
after the minutes, even if they are both zeros.
Suppose you want to cook for 5 minutes at 100%.•
Enter cooking time 1.
OR TOUCH
To cook at 100% power (High), touch the 2. START/
EASY MINUTE pad.
5 0 0
POWER
5.00 TOUCH START
.
LEVEL
Sensor Settings
Dacor's Sensor is a semi-conductor device that detects
the vapor (moisture and humidity) emitted from the food
as it heats. The sensor adjusts the cooking times and
power levels for various foods and quantities.
USING SENSOR SETTINGS:
To Set Power Level
There are eleven preset power levels.
Using lower power levels increases the cooking time,
which is recommended for foods such as cheese, milk and
long slow cooked meats. Consult a microwave cookbook
or recipes for specic recommendations.
Suppose you want to defrost for 5 minutes at 30%.•
Enter defrost time 1.
Touch the 2. POWER LEVEL pad 8 times.
Touch the 3. START/EASY MINUTE pad.
TOUCH POWER
LEVEL PAD NUMBER
OF TIMES FOR
5 0 0
APPROXIMATE
PERCENTAGE
OF POWER
DESIRED POWER
Power Level x 1 100% High
Power Level x 2 90%
Power Level x 3 80%
Power Level x 4 70% Medium High
Power Level x 5 60%
Power Level x 6 50% Medium
Power Level x 7 40%
Power Level x 8 30% Med Low/Defrost
Power Level x 9 20%
Power Level x 10 10% Low
Power Level x 11 0%
.
5.00
COMMON
WORDS FOR
POWER LEVELS
When the sensor detects the vapor emitted from the
After the Microwave In-A-Drawer1.
2 minutes before using any sensor setting.
Be sure the exterior of the cooking container and the 2.
interior of the Microwave In-A-Drawer™ are dry. Wipe
off any moisture with a dry cloth or paper towel.
The sensor works with foods at normal storage tem-3.
perature. For example, popcorn would be at room
temperature.
Any sensor selection can be programmed with More or 4.
Less Time Adjustment. See page 13.
More or less food than the quantity listed in the charts 5.
should be cooked following the guidelines in any microwave cookbook.
During the rst part of sensor use, the food name will 6.
appear on the display. Do not open the Microwave
In-A-Drawer™ or touch STOP/CLEAR during this part
of the cycle. The measurement of vapor will be interrupted. If this occurs, an error message will appear.
To continue cooking, touch the STOP/CLEAR pad and
cook manually.
food, the remainder of cooking/reheating time will
appear. The Microwave In-A-Drawer™ may be opened
when the remaining time appears on the display. At
this time, you may stir or season food, as desired.
If the sensor does not detect vapor properly when 7.
popping popcorn, the Microwave In-A-Drawer™ will
turn off, and the time of day will be displayed. If the
sensor does not detect vapor properly when cooking
other foods,
wave will turn off.
Check food temperature after cooking. If additional 8.
time is needed, continue to cook manually.
ERROR
will be displayed, and the micro-
™
is plugged in, wait
E8
Each food has a cooking hint. Touch the 9. SET UP/
HELP pad when the HELP indicator is lighted in the
display.
Microwave In-A-Drawer
™
Cooking
COVERING FOODS:
Some foods work best when covered. Use the cover recommended in the charts for these foods. You may refer to
the hints by touching the SET UP/HELP pad.
Casserole lid.1.
Plastic wrap: Use plastic wrap recommended for 2.
microwave cooking. Cover dish loosely; allow approximately 1/2 inch to remain uncovered to allow steam
to escape. Plastic wrap should not touch food.
Wax paper: Cover dish completely; fold excess wrap 3.
under dish to secure. If dish is wider than paper, overlap two pieces at least one inch to cover.
Be careful when removing any covering to allow steam to
escape away from you.
Sensor Popcorn / Sensor Reheat
You can pop popcorn and reheat many foods without calculating the cooking time or power level.
Touch the SENSOR REHEAT or SENSOR POPCORN
and the START/EASY MINUTE pad.
When the sensor detects the vapor emitted from the food,
the remainder of cooking/reheating time will appear.
NOTE:
The Sensor Popcorn setting has 2 choices. Follow •
directions in the display to choose desired option.
SENSOR POPCORN / SENSOR REHEAT CHART
FOOD AMOUNT PROCEDURE
Sensor Popcorn Only 1 package at a time Use only popcorn packaged for the microwave. Try several brands to
decide which you like. Do not try to pop unpopped kernels.
2.85 - 3.5 oz.
(Regular / Regular light)
Touch the SENSOR POPCORN pad once.
1.2 - 1.75 oz.
(Mini / Snack)
Sensor Reheat 4 - 36 oz. Place food to be reheated in a dish or casserole slightly larger than
Touch the SENSOR POPCORN pad twice.
the amount. Flatten, if possible. Cover with lid, plastic wrap or wax
paper. Use covers such as plastic wrap or lids, with larger quantities
of more dense foods such as stews. After reheating, stir well, if possible. Re-cover and allow to stand 2 to 3 minutes. Foods should be
very hot. If not, continue to heat with variable power and time.
E9
Microwave In-A-Drawer
Sensor Cooking
™
Cooking
Touch the 3. START/EASY MINUTE pad.
NOTE:
Touch the 1. SENSOR COOK pad once.
SEE LABEL
See Menu Label. Select desired food by touching 2.
number pad. Ex: Touch 5 for baked potatoes.
SELECT
FOOD
NUMBER
SENSOR COOK CHART
FOOD AMOUNT PROCEDURE
1. Fresh vegetables: soft
Broccoli
Brussels sprouts
Cabbage
Cauliower (owerets)
Cauliower (whole)
Spinach
Zucchini
Baked apples
2. Fresh vegetables: hard
Carrots, sliced
Corn on the cob
Green beans
Winter squash:
diced
halves
.25 - 2.0 lb.
.25 - 2.0 lb.
.25 - 2.0 lb.
.25 - 2.0 lb.
1 med.
.25 - 1.0 lb.
.25 - 2.0 lb.
2 - 4 med.
.25 - 1.5 lb.
2 - 4
.25 - 1.5 lb.
.25 - 1.5 lb.
1 - 2
To heat or cook other foods or foods above or below •
Wash and place in casserole. Add no water if vegetables have just been
washed. Cover with lid for tender vegetables. Use plastic wrap for tendercrisp vegetables. After cooking, stir, if possible. Let stand, covered, for 2 to
5 minutes.
Place in casserole. Add 1 - 4 tablespoons water. Cover with lid for tender
vegetables. Use plastic wrap cover for tender-crisp vegetables. After cooking, stir, if possible. Let stand, covered, for 2 to 5 minutes.
the quantity allowed on the SENSOR COOK CHART,
cook manually.
3. Frozen vegetables .25 - 1.25
lb.
4. Frozen entrees 6 - 17 oz. Use this pad for frozen convenience foods. It will give satisfactory results
5. Baked potatoes 1 - 6 med. Pierce. Place on paper-towel-lined Drawer. After cooking, remove from
6. Ground meat .25 - 2.0 lb. Use this setting to cook ground beef or turkey as patties or in a casserole
7. Fish/seafood .25 - 2.0 lb. Arrange in ring around shallow glass dish (roll llet with edges under-
8. Rice .5 - 2.0 cup Place rice into a deep casserole and add double quantity of water. Cover
Add no water. Cover with lid or plastic wrap. After cooking, stir and let
stand, covered, for 3 minutes.
for most brands. You may wish to try several and choose your favorite.
Remove package from outer wrapping and follow package directions for
covering. After cooking, let stand, covered, for 1-3 minutes.
microwave, wrap in aluminum foil and let stand 5 to 10 minutes.
to be added to other ingredients. Place patties on a microwave-safe rack
and cover with wax paper. Place ground meat in a casserole and cover with
wax paper or plastic wrap. When microwave stops, turn patties over or stir
meat in casserole to break up large pieces. Re-cover and touch START/
EASY MINUTE. After cooking, let stand, covered, for 2 to 3 minutes.
neath). Cover with vented plastic wrap. After cooking, let stand, covered
for 3 minutes.
with lid or plastic wrap. After cooking, stir, cover and let stand 3 to 5 minutes or until all liquid has been absorbed.
Rice Water Size of casserole
.5 cup 1 cup 1.5 quart
1 cup 2 cups 2 quart
1.5 cups 3 cups 2.5 or 3 quart
2 cups 4 cups 3 quart or larger
E10
Microwave In-A-Drawer
Defrost
Use this feature to defrost the foods shown in the DEFROST
CHART below.
Touch the 1. DEFROST pad.
FOOD
See Menu Label. Select desired food by touching the 2.
number pad. Ex: Touch 2 for steaks/chops.
CHOPS
Enter weight by touching 3.
Touch the 4. START/EASY MINUTE pad.
The Microwave In-A-Drawer5.
can be checked.
After the rst stage, open the Drawer. Turn steak 6.
over and shield any warm portions. Close the Drawer.
Touch the START/EASY MINUTE pad.
NUMBER
ENTER
WEIGHT
SEE LABEL
100
1.0
.
™
will stop so that the food
SELECT
STEAKS
™
Cooking
After the second stage, open the Drawer. Shield any 7.
warm portions. Close the Drawer. Touch the START/
EASY MINUTE pad.
After defrost cycle ends, cover and let stand as indi-8.
cated in the chart below.
NOTE:
Defrost can be programmed with More or Less Time •
Adjustment. See page 13.
To defrost other foods or foods above or below the •
weights allowed on the DEFROST CHART, see MANUAL
DEFROST below.
Do not defrost until all ice crystals are thawed.•
Check foods when • Microwave In-A-Drawer™ signals.
After nal stage, small sections may still be icy. Let
stand to continue thawing.
Shielding prevents cooking from occurring before the •
center of the food is defrosted. Use small smooth
strips of aluminum foil to cover edges and thinner
sections of the food.
DEFROST CHART
FOOD AMOUNT PROCEDURE
1. Ground meat .5 - 2.0 lb Remove any thawed pieces after each audible signal. Let stand, covered, for 5 to
10 minutes.
2. Steaks/chops .5 - 3.0 lb After each audible signal, rearrange and if there are warm or thawed portions,
shield with small at pieces of aluminum foil. Remove any meat or sh that is
almost defrosted. Let stand, covered, for 10 to 20 minutes.
3. Boneless
poultry
4. Bone-in poultry .5 - 3.0 lb After each audible signal, rearrange pieces or remove portions should they become
5. Casserole/soup 1 - 6 cups After each audible signal, break apart and remove any defrosted part. At end, stir
Manual Defrost
If the food that you wish to defrost is not listed on the
DEFROST CHART or is above or below the limits in the
AMOUNT column on the DEFROST CHART, you need to
defrost manually.
You can defrost any frozen food, either raw or previously
cooked, by using Power Level at 30%. Follow the exact
3-step procedure found under TO SET POWER LEVEL on
page 8. Estimate defrosting time and press POWER LEVEL
pad eight times for 30% power.
.5 - 2.0 lb After each audible signal, if there are warm or thawed portions, rearrange or
remove. Let stand, covered, for 10 to 20 minutes.
warm or thawed. Let stand, covered, for 10 to 20 minutes.
well and let stand, covered, for 5 to 10 minutes.
For either raw or previously cooked frozen food, the rule
of thumb is approximately 4 minutes per pound. For
example, defrost 4 minutes for 1 pound of frozen spaghetti sauce.
™
Always stop the Microwave In-A-Drawer
to remove or separate the portions that are defrosted.
If food is not defrosted at the end of the estimated
defrosting time, program the Microwave In-A-Drawer™
in 1 minute increments on Power Level 30% until totally
defrosted.
When using plastic containers from the freezer, defrost
only long enough to remove from the plastic in order to
place in a microwave-safe dish.
periodically
E11
Microwave In-A-Drawer
Reheat
Reheat automatically computes the correct warming time
and microwave power level for foods shown in the chart
below.
Touch1. the REHEAT pad once.
SELECT
See Menu Label. Select desired food by touching 2. the
number pad. Ex: Touch 2 for frozen rolls or mufns.
FOOD
NUMBER
SEE LABEL
™
Cooking
NOTE:
• Reheat can be programmed with More or Less Time
Adjustment. See page 13.
• To reheat other foods or foods above or below the
quantity allowed on the REHEAT CHART, heat manually.
Touch the number pad to select quantity. Ex: Touch 3.
for 2 rolls or mufns.
Touch4. the START/EASY MINUTE pad.
2
REHEAT CHART
FOOD AMOUNT PROCEDURE
1. Fresh rolls/
mufns
2. Frozen rolls/
mufns
3. Beverage .5 - 2.0 cups This setting is good for restoring cooled beverage to a better drinking temperature.
1 - 8 pcs Use this pad to warm rolls, mufns, biscuits, bagels etc. Large items should be
considered as 2 or 3 regular size. Arrange on plate; cover with paper towel. For
refrigerated rolls or mufns, it may be necessary to double the entered amount
to ensure the proper serving temperature. For example, enter quantity of 2 for 1
refrigerated mufn.
1 - 8 pcs Use this pad to warm frozen rolls, mufns, biscuits, bagels etc. Large items should
be considered as 2 or 3 regular size. Arrange on plate; cover with paper towel.
Stir liquid briskly before and after heating to avoid "eruption".
E12
Loading...
