Epicure® Cooktop
Models: EG366, EG486
Installation Instructions
Part No. 102025 Rev. N
THIS APPLIANCE HAS BEEN TESTED IN ACCORDANCE WITH THE LATEST
EDITION OF ANSI Z21.1 STANDARD FOR HOUSEHOLD GAS APPLIANCES.
Table of Contents
Important Safety Instructions .......................................... 1
Important Information About Safety Instructions .............. 1
General Safety Precautions ............................................. 2
Installation Requirements ................................................ 3
Electrical Requirements ................................................... 3
Gas Supply Requirements ............................................... 3
Product Dimensions ......................................................... 3
Cabinet and Countertop Layout ....................................... 4
Cabinet/Cutout Dimensions ............................................. 5
Installation Instructions .................................................... 8
Cooktop Installation .......................................................... 8
Gas Line Connection ....................................................... 9
Burner Component Installation ...................................... 10
Burner Knob Installation ..................................................11
Verifying Proper Operation ............................................. 12
Installation Checklist ...................................................... 13
Wiring Diagram ................................................................ 14
Notes................................................................................. 15
Before You Begin...
Important:
Installer:• In the interest of safety and to minimize problems, read these installation instructions completely and care-
fully before you begin the installation process. Leave these installation instructions with the customer.
Customer:• Keep these installation instructions for future reference and the local building inspector’s use.
Customer Service Information
If You Need Help...
Product Data Label
If you have questions or problems with installation, contact
your Dacor ® dealer or the Dacor Customer Service Team.
For repairs to Dacor appliances under warranty call the
Dacor Distinctive Service line. Whenever you call, have the
model and serial number of the appliance ready. The model
and serial number are printed on the appliance data plate.
Dacor Customer Service
Phone: (800) 793-0093 (U.S.A. and Canada)
Monday — Friday 6:00
Web site: www.Dacor.com
Dacor Distinctive Service (repairs under warranty only)
Phone: (877) 337-3226 (U.S.A. and Canada)
Monday — Friday 6:00
a.m. to 5:00 p.m. Pacific Time
a.m. to 4:00 p.m. Pacific Time
The product data label contains the model and serial •
number information and the electrical and gas supply
requirements.
It is attached to the bottom of the chassis.•
Model Identification
EG366SCH/NG/H
SIZE (in inches)
GAS TYPE
NG = Natural Gas
LP = Liquid Petroleum
(Propane)
ALTITUDE
H = High Altitude Model, 4000 ft.(1219 m) and up
No character = Equipped for low altitude operation
All specifications are subject to change without notice. Dacor assumes no liability for changes to specifications.
© 2007 Dacor, all rights reserved.
Important Safety Instructions
Important Information About
Safety Instructions
The • Important Safety Instructions and warnings in
this manual are not meant to cover all possible problems and conditions that can occur. Use common
sense and caution when installing, maintaining or operating this or any other appliance.
Always contact the Dacor Customer Service Team •
about problems and conditions that you don’t understand. See Customer Service Information.
Safety Symbols and Labels
DANGER
Immediate hazards that WILL result in severe personal
injury or death.
WARNING
Hazards or unsafe practices that COULD result in severe
personal injury or death.
CAUTION
Hazards or unsafe practices that COULD result in minor
personal injury or property damage.
DANGER
IMPORTANT: If you smell gas:
Do not use or light any appliance.•
Do not touch any electrical switch or use any electri-•
cal devices, including the telephone, in your building.
From a neighbor’s phone, immediately call the gas •
supplier. Follow the gas supplier’s instructions.
If you cannot contact the gas supplier, call the fire •
department.
DANGER
IMPORTANT: Do not store or use combustible, flammable
or explosive vapors and liquids (such as gasoline) on or
in the vicinity of this or any other appliance. Also keep
items that could explode, such as aerosol cans, away
from the cooktop. Do not store flammable or explosive
materials in adjacent cabinets or areas (including above
and below the cooktop).
WARNING
WARNING – NEVER use this appliance as a space
heater to heat or warm the room. Doing so may result
in carbon monoxide poisoning and overheating of the
appliance.
WARNING
WARNING
TO REDUCE THE RISK OF INJURY TO PERSONS IN
THE EVENT OF A RANGE TOP GREASE FIRE:
SMOTHER FLAMES with a close-fitting lid, cookie a.
sheet or metal tray, then turn off the burner. BE
CAREFUL TO PREVENT BURNS. If the flames do
not go out immediately, EVACUATE AND CALL THE
FIRE DEPARTMENT.
NEVER PICK UP A FLAMING PAN - you may be b.
burned.
DO NOT USE WATER, including wet dish cloths or c.
towels - a violent steam explosion may result.
Use a fire extinguisher ONLY if:d.
You have a Class ABC extinguisher, and you ◊
already know how to operate it.
The fire is small and contained in the area where ◊
it started.
The fire department is being called.◊
You can fight the fire with your back to an exit.◊
WARNING – NEVER cover any slots, holes or passages
on the cooktop and cooktop chassis. Doing so blocks
air flow through the cooktop and may cause carbon
monoxide poisoning. Aluminum foil linings may also trap
heat, causing a fire hazard. Keep all slots, holes and
passages clear of grease and grime.
CALIFORNIA PROPOSITION 65 WARNING
The burning of gas cooking fuel generates some
by-products that are on the list of substances which
are known by the State of California to cause cancer or
reproductive harm. California law requires businesses
to warn customers of potential exposure to such
substances. To minimize exposure to these substances,
always operate this unit according to the use and care
manual, ensuring you provide good ventilation when
cooking with gas.
READ AND SAVE THESE INSTRUCTIONS
1
Important Safety Instructions
General Safety Precautions
To reduce the risk of fire, electric shock, serious injury or death when using your appliance, follow basic safety precautions, including the following:
WARNING
Read the accompanying use and care manual com-•
pletely before operating this appliance.
Keep packaging materials away from children. •
Plastic sheets and bags can cause suffocation.
If you receive a damaged product, immediately con-•
tact your dealer or builder. Do not install or use a
damaged appliance.
This cooktop must be properly installed and ground-•
ed by a qualified installer according to these installation instructions prior to use. The installer should
show the customer the location of the gas shut off
valve and the power cord so that they know where
and how to turn off the gas supply and disconnect
power to the cooktop. Proper installation is the
responsibility of the customer.
Installations with less than 2 1/2” (64 mm) from the •
rear of the cooktop to a combustible material must
use Dacor backguard model AEB3609, AEB3612,
(for model EG366) AEB4809, AEB4812 (for model
EG586) or a non-combustible material. See the latest version of ANSI Z223.1.
Do not use this appliance in combination with a sur-•
face (countertop) ventilation system. Dacor strongly
recommends the installation of a range hood or
raised vent in conjunction with this appliance.
Do not install, repair or replace any part of the •
cooktop unless specifically recommended in the literature accompanying it. A qualified service technician
should perform all other service. Do not tamper with
the controls. Do not operate the cooktop without the
knobs and trim rings in place.
Before servicing or installing this cooktop, make sure •
that the gas supply is turned off at the gas supply
valve and that the power plug is disconnected from
the electrical outlet.
Do not connect this cooktop to the gas supply with-•
out the supplied gas pressure regulator installed.
Disconnect the power plug from the electrical outlet •
before cleaning. Clean this appliance only in the
manner specified in the use and care manual.
Only use the cooktop for cooking tasks expected of •
a home appliance as outlined in the literature accompanying it. This cooktop is not intended for commercial or laboratory use.
DO NOT TOUCH THE SURFACES OF THE •
COOKTOP OR THE SURROUNDING AREAS
DURING OR IMMEDIATELY AFTER USE
.
WARNING
Do not climb on any part of the appliance.•
To avoid a fire hazard, do not hang flammable or •
heat sensitive objects over the cooktop.
Do not leave children alone or unattended in the •
area around the cooktop. Do not allow children to
play with the controls or touch other parts of the
cooktop. Do not store items of interest to children
on top of or above the cooktop. Children could be
burned or injured while climbing on the appliance.
Clean the cooktop thoroughly before operating it for •
the first time. Make sure that all the cooktop parts
are dry before lighting a burner.
Keep flammable items, such as paper, cardboard, •
plastic and cloth away from the burners and other
hot surfaces. Do not place such items on the
cooktop. Do not allow pot holders to touch hot surfaces or gas burners.
Do not wear loose or hanging apparel while using •
the cooktop. Do not allow clothing to come into contact with the cooktop and surrounding areas during
and immediately after use. Do not use towels or
bulky cloth as pot holders.
If the cooktop is near a window, do not use long cur-•
tains as window treatment. The curtains could blow
over the cooktop and create a fire hazard.
Non-stick coatings, when heated, can be harmful to •
birds. Remove birds to a separate, well-ventilated
room when operating the cooktop.
IMPORTANT - This appliance is equipped with a
three prong grounding plug for your protection against
possible electric shock hazards.
Plug it only into a dedicated,
grounded three prong electrical
outlet. It is the responsibility
of the customer to make sure
the proper type of outlet is
installed. Do not under any
circumstances:
Cut or remove the third (ground) prong from the •
power cord.
Use an adapter plug.•
Use an extension cord.•
Use a power cord that is frayed or damaged. •
Connect to an electrical outlet with a ground fault •
interrupter (GFI).
2
Installation Requirements
A
4” (102 mm)
5/8”
(16 mm)
7 3/4”
(197 mm)
Trim:
7/16”
(11 mm)
thick
26” (660 mm)
1 1/2” (38 mm) cooking surface
height (grate level) above
countertop
3/4” gas inlet, connects to regulator from
bottom or rear of unit, end is recessed
2” (51 mm) from chassis bottom
27” (686 mm)
28” (711 mm)
Power cord
32” long
WARNING
Observe all governing codes and ordinances during •
planning and installation. Contact your local building
department for further information.
To prevent an electric shock hazard, the power sup-•
ply must meet the specifications stated below.
The electrical and gas supply data on this page is for reference only. If the requirements below do not agree with the
product data label, use the data on the product data label.
Electrical Requirements
The electrical installation, including minimum supply •
wire size and grounding, must be done in accordance
with National Electric Code ANSI/NFPA 70 and local
codes and ordinances. A copy of this standard may be
obtained from:
National Fire Protection Association
1 Batterymarch Park
Quincy, MA 02269-9101
The correct voltage, frequency and amperage must be •
supplied to the electrical outlet according to the product
data label located on the bottom of the chassis.
The electrical outlet must be installed by a licensed •
electrician.
ELECTRIC CIRCUIT REQUIREMENTS
Circuit Required Total Connected Load
120 Vac 60 Hz,
15 Amp. (3 wire)
0.25 Amp @ 120 Vac, 60 Hz
Gas Supply Requirements
Check your local building codes for the proper method •
of installation. In the absence of local codes, this
appliance should be installed in accordance with the
National Fuel Gas Code ANSI Z223.1/NFPA 54. The
gas service must be installed by a qualified professional
Be certain that the cooktop being installed is correct for •
the gas service being provided (natural gas or LP gas).
Also, if operating the cooktop at an altitude above 4000
ft. (1219 m) make sure it is equipped for high altitude
operation. See the inside cover for more information.
An external manual shut-off valve must be installed •
between the gas inlet and the cooktop for the purpose
of turning on or shutting off gas to the appliance.
The factory provided regulator shipped with the appli-•
ance must be installed in the gas line that runs from the
gas shut off valve to the cooktop gas inlet. Use only the
regulator provided. The regulator inlet accommodates
a 3/4” gas supply line and is also compatible with a
1/2” house gas supply. The inlet to the cooktop itself is
equipped with a 3/4” male NPT fitting.
GAS SUPPLY PRESSURE REQUIREMENTS*
Gas Type
Natural Gas 5” Water Column 6” Water Column
Propane (LP)
* Maximum gas supply pressure for all models is 1/2 p.s.i.
Manifold
Pressure
10” Water
Column
Minimum Gas
Supply Pressure
11” Water Column
Product Dimensions
COOKTOP WIDTH (A)
EG366 35 7/8” (911 mm)
EG486 47 7/8” (1216 mm)
SIDE VIEW
Product tolerances: ±1/16” (±1.6 mm) unless otherwise
noted.
3
Installation Requirements
Combustible
rear wall
Backguard mandatory if
gap from back of cooktop
to combustible wall is less
than 2 1/2”
Combustible
rear wall
2 1/2” (64 mm) Min. to
combustible rear wall
Cabinet and Countertop Layout
WARNING
To avoid the risk of fire or personal injury, all minimum
and maximum specified clearances on this and the
following pages must be maintained or exceeded.
General Considerations
The minimum distance from the back of the cooktop •
to a combustible rear wall is 2 1/2” (64 mm) minimum
(Figure 1).
Installation of a non-combustible material* (up to the •
hood) or a backsplash is always recommended, and
mandatory if the distance to the back wall from the
cooktop is less than 2 1/2” (Figure 2). When installing a
backguard, use only Dacor model numbers AEB3609,
AEB3612 (EG366), AEB4809 or AEB4812 (EG486).
* Consult local codes and ordinances for acceptable
non-combustible materials.
FIGURE 1
FIGURE 2
Carefully check the location where the cooktop is to be •
installed. For best performance, the cooktop should be
installed away from drafts caused by doors, windows
and heating and air conditioning outlets. To reduce the
risk of personal injury from reaching over a hot appliance, avoid cabinet installations directly above.
To reduce the risk of personal injury and to reduce •
accumulated smoke in the room, Dacor strongly recommends installing a range hood. A hood should project
horizontally a minimum of five (5) inches beyond the
face of the cabinets.
The installation must allow access to the underside •
of the cooktop for service and inspection purposes,
including the ability to turn off the cooktop gas supply
valve and electrical outlet.
All contact surfaces between the cooktop and the coun-•
ter must be solid and level.
The countertop overhang on the sides of the cutout •
shown on the following pages covers the recessed portions of the cooktop behind the control panel and creates a seamless look for the installation.
IMPORTANT: • When installing the cooktop into a lami-
nated or synthetic countertop, radius the corners of the
cutout to help avoid cracking. Consult the countertop
manufacturer’s instructions for minimum corner radius,
reinforcement and heat protection requirements.
For installations with a raised vent, install this appliance •
only with the approved Dacor raised vent models listed
on page 6.
Gas and Electric Service Location
The gas supply piping, gas shut-off valve and the elec-•
trical outlet must be located so they do not interfere
with the cooktop when it is installed. If installing another
appliance in the cabinet below, allow for the routing of
gas and electrical service out the back of the unit.
The shaded area on the facing page shows the rec-•
ommended location of the gas inlet and the electrical
outlet. For replacement purposes, the location of the
existing utilities may be utilized provided they do not
interfere with the sides or rear of the cooktop. Check
local building codes for permissible utility locations.
For best performance and to minimize gas pressure •
loss, attach the gas supply regulator as close as possible to the cooktop gas inlet.
The installation must:
Allow for access to the gas shut-off valve and regulator •
when the unit is installed.
Allow for access to the electrical outlet, when the •
cooktop is in place so that the power cord may be easily disconnected if the unit needs service.
Allow for connection of the (32”) power cord to the •
electrical outlet.
If a raised vent is to be installed, allow for access to the •
gas supply valve and electrical outlet when the raised
vent is in place.
4
Recommended
gas and electrical
service location,
consult local code
B
10” (254 mm) to
combustible side
wall Min. both sides
1/2” (13 mm)
overhang,
both sides
1 1/2” (38 mm)
typical countertop
thickness
7 3/4”
(197 mm)
36” (914 mm)
typical
Cooktop platform
1” (25 mm) Min.
thickness
Installation Requirements
See note 2
2
See Cabinet/Countertop Dimensions - Top View
3
Not applicable for cabinets more than a horizontal
distance of 10” (254mm) from the edge of the cooktop.
1
Vertical to combustible surface from cooktop grate level;
if installing an overhead vent hood, also check the hood
specifications for minimum required clearances.
C
13” (330 mm)
max.
3
Top of
finished
counter
18” (457 mm)
Min.
1, 3
30” (762 mm)
Min.
1
Cutout for
utility access
Hood
Cabinet/Cutout Dimensions
Cabinet/Countertop Dimensions - Front View
Cabinet tolerances +1/16” -0 (+1.6 mm, 0) unless otherwise noted.
Cooktop
Model
EG366 36” (914 mm)
EG486 48” (1219 mm)
Cabinet/Countertop Dimensions -
B C
36” (914mm)*
42” (1067 mm)**
48” (1219 mm)*
54” (1372 mm)**
* Minimum ** Recommended
ISO View
Continued on following
pages...
5
Installation Requirements
Non-combustible
rear wall, rear of
mounting platform
10” (254 mm) min.
to combustible wall
above countertop,
both sides
Cabinet face
below countertop
overhang
Increase countertop and overhang
additional 2 1/2” (64 mm) Min. for
combustible rear wall above
countertop
3/8” (13 mm)
countertop overhang
Hole 1/2” dia. (13 mm),
2 places, through platform
for hold down bolts
Gas/electrical utility cut-out in right rear corner of
mounting platform 8” W X 6” D (203 mm X 152 mm),
if gas and electrical are routed through bottom
1/2” (13 mm)
countertop
overhang
1” thick mounting platform Min.
Countertop
Countertop
1/2” (13 mm)
countertop
overhang
2” (51 mm)
1” (25 mm)
11 7/16”
(291 mm)
24 5/8”
(625 mm)
C
L
D D
B
C
L
C
L
C
L
Gas connection and power cord may be
routed through bottom or back of chassis
Gas and electrical connections at
right rear section of chassis
Cabinet/Countertop Dimensions (cont.)
Cutout tolerances +1/16” -0 (+1.6 mm, 0) unless otherwise noted.
Cabinet/Countertop Cutout Dimensions without Raised Vent - Top View
Cooktop
Model
EG366
EG486
IMPORTANT: Use only the raised vent models specified.
B - Cutout
Width
36”
(914 mm)
48”
(1219 mm)
D - Hole
Offset
16 5/8”
(422 mm)
20 13/16”
(529 mm)
E - Raised
Vent Cutout
33 1/2”
(851 mm)
43 1/2”
(1105 mm)
Approved Raised
Vent Models
ERV36, PRV36
ERV48, PRV48
6
Installation Requirements
Non combustible rear
wall recommended
10” (254 mm) Min. to
combustible wall
above countertop,
both sides
Cabinet face
below countertop
overhang
3/8” (10 mm) Min.
countertop overhang
2 5/8”
(67 mm)
Hole 1/2” dia. (13 mm),
2 places, through platform
for hold down bolts
1/2” (13 mm)
countertop
overhang
1” thick mounting platform Min.
Open to below to allow for raised
vent, gas and electrical connections
Countertop
Countertop
1/2” (13 mm)
countertop
overhang
2” (51 mm)
1” (25 mm)
11 7/16”
(291 mm)
15”
(381 mm)
24 5/8”
(625 mm)
C
L
D
D
E
B
C
L
C
L
C
L
Stiffener
Cabinet face
Control panel
Countertop
Dacor approved
raised vent
IMPORTANT: See raised vent
installation instructions for
duct system layout/planning
EG366 or EG486 cooktop
3/8” Min. (10 mm)
space behind
raised vent
chassis to clear
stiffener
3/8” Min. (10 mm)
flat countertop overhang
required behind cutout
Minimum
countertop
height:
30 1/4"
(768 mm)
Cabinet/Countertop Cutout Dimensions with Raised Vent - Top View
Cabinet/Countertop with Raised Vent - Side View
NOTE: Gas and electrical connections may only be routed through
the bottom of the cooktop when installed with a raised vent.
7
Installation Instructions
Unpack the Cooktop
WARNING
If the gas and electric service provided does not •
meet the product specifications, do not proceed with
the installation. Call the dealer, the gas supplier or a
licensed electrician.
The cooktop is heavy. A minimum of two people are •
required to safely install it.
Unpack the parts box and verify that all required components have been provided. If any item is missing or damaged, please contact your dealer immediately. Do not install
a damaged or incomplete appliance. The customer must
report cosmetic issues within 30 days of installation.
Grates (3) •
Stack burner caps (2 large, 2 small)•
Stack burner rings (2 large, 2 small)•
Crown burner caps (2)•
Crown burner rings (2)•
Crown burner heads (2)•
Knobs (4 standard, 2 • MAX GRIDDLE)
Dacor Stainless Steel Cleaner•
WOK ring•
Griddle•
Hold down bolts/washers (2 sets)•
Regulator•
Product literature•
*
Cooktop Installation
WARNING
To prevent damage to the gas pressure regulator, •
install it only after the cooktop is mounted in its permanent position.
Do not over-tighten the hold down bolts. Over tight-•
ening the hold down bolts may result in improper
operation of the dual gas burners.
IMPORTANT
Do not use a hardening compound or caulk to
permanently seal the cooktop into place. The cooktop
must be readily removable if service is required. Removal
of sealant to service the unit will be performed at the
customer’s expense.
Lower the cooktop into the cutout while feeding the 1.
electrical cord into the utility cutout. Center the cooktop
in the cutout.
Secure the cooktop to the countertop using the two (2) 2.
provided hold-down bolts and washers provided. Do
not overtighten the bolts.
* Model EG486 comes with (3) 14 inch grates. Model
EG366 comes with (2) 10-inch grates and (1) 14-inch grate.
8
Installation Instructions
Gas Line Connection
WARNING
Verify that the gas supply meets specifications before connection. See page 3.•
The maximum gas supply pressure to the regulator must never exceed ½ pounds per square inch (psi) or 3.5 kPa.•
Do not install or use the cooktop without the included gas regulator installed.•
Ensure that the arrow on the regulator points in the direction of the gas flow, towards the cooktop.•
Do not apply excessive pressure when tightening gas connections and fittings.•
Do not use Teflon tape or plumber’s putty on flexible gas line connections.•
Test the gas lines for leaks as instructed before use. Do not use a flame to check for leaks. •
The gas supply pressure for testing the regulator setting shall be at least 1 inch water column (249Pa) above the •
specified manifold pressure. See page 3.
The cooktop and shut-off valve must be disconnected from the gas supply piping system during any pressure test-•
ing exceeding ½ psi (3.5 kPa).
The cooktop must be isolated from the gas supply piping system by closing the shut-off valve to the cooktop during •
any gas supply piping system pressure testing equal to or less than ½ psi (3.5 kPa).
For LP gas installations, the LP gas tank must have its own high-pressure regulator in addition to the pressure regu-•
lator supplied with the cooktop.
IMPORTANT
Within the Commonwealth of Massachusetts, this appliance must be installed by a licensed plumber or gas fitter.
Attach the gas pressure regulator (included with the 1.
cooktop) to the 3/4” (19 mm) male NPT gas inlet on
the cooktop. The inlet is located on the bottom, at the
right rear portion of the chassis. For tight installations,
the regulator may be installed upstream from the pipe
nipple, anywhere between the shut-off valve and the
cooktop. For best performance, minimize gas pressure
loss by attaching the regulator as close as possible to
the cooktop gas inlet.
Complete connection of the gas supply to the cooktop 2.
by installing a minimum ½” flexible gas line (not included) between the pressure regulator and the shut-off
valve.
Check for gas leaks:3.
Turn all cooktop control valves to the ◊ OFF position.
Turn on the gas supply valve and check all lines ◊
and connections for leaks using a soap and water
solution or a gas leak detector.
Turn the gas supply valve off.◊
9
Installation Instructions
Burner Component Installation
WARNING
Never attempt to operate the cooktop with any of the •
burner parts removed.
Do not attempt to adjust the burner air mixture set-•
tings. All adjustments are preset at the factory.
Remove the burner parts and grates from their shipping •
packages.
Install the burners as shown. When installing the burn-•
er components, twist each piece back and forth slightly
until it drops completely into place. The burners will
not operate properly unless all of the burner pieces are
properly seated.
Gently set the grates on top of the spill trays. Make •
sure that the rubber feet are positioned in the dimples.
On model EG366, the center grate is larger than the
other two.
Ridge on bottom
of burner cap
Crown
burner
Spill tray
Stack
burner
STEP 3: Install
burner cap.
Ridge on cap
must surround
top of ring.
STEP 2: Install
burner ring. Line
up ring tabs
with head slots.
Twist back and
forth to assure
proper seating.
STEP 1: Install
burner head.
Put locating
tap into keyed
hole.
Burner cap
Burner ring
Burner head
Ridge on bottom
of burner cap
STEP 3: Install
burner cap. Ridge
on cap must surround top of ring.
STEP 2: Turn
ring until it drops
into place. Twist
back and forth
to assure proper
seating.
STEP 1: Put
burner ring on
top of the head.
Burner cap
Burner ring
10
Burner base
Burner base
Keyed hole
Crown Burner Assembly Stack Burner Assembly
Installation Instructions
Burner Knob Installation
CAUTION
Installing the cooktop knobs in the wrong position may
result in damage to the cooktop griddle. The knobs for
the center burners are marked with the maximum griddle
settings.
There are two (2) different types of knobs supplied with the
cooktop. The knobs for the center burners have the words
MAX GRIDDLE on them.
Put the knobs with the words • MAX GRIDDLE on them
onto the inner (center burner) valve shafts.
Put the remaining knobs on the outer valve shafts .•
When installing the knobs, align the “D-shaped” open-•
ing on the back of the knob with the end of the valve
shaft. Carefully push the knob on until it stops.
Icons on outer burner knobs
Icons on center burner knobs
Icons on outer burner knobs
11
Installation Instructions
Verifying Proper Operation
WARNING
Make sure that power to the electrical outlet is turned •
off at the circuit breaker or fuse box and that the gas
is turned off at the gas supply valve before proceeding.
The cooktop must be properly grounded at all times •
when electrical power is applied.
Prior to operating the cooktop, read the accompanying use
and care manual carefully.
Make sure all the 1.
cooktop burner controls are in the OFF
position.
Connect the power 2.
cord to the electrical outlet.
Turn on power to the electrical outlet at the circuit 3.
breaker or fuse box.
Gently push in and turn one burner control knob at a 4.
time counterclockwise to the HIGH position. Verify that
the associated burner igniter sparks, then return the
knob to the OFF position. Repeat for all of the remaining control knobs.
Turn on the gas supply valve.5.
Perform the following ignition test for all of the burners:6.
Push in and turn one of the control knobs counter-•
clockwise to the HIGH position. Only the igniter for
the selected burner will spark. It may take up to four
seconds for the gas to ignite, at which time the igniter will stop sparking. If ignition does not occur within
four seconds, turn the knob to the OFF position, wait
for at least five minutes to allow any gas to dissipate,
then repeat the test.
Once the burner lights, the control knob can be rotat-•
ed counterclockwise from HIGH to LOW to adjust the
flame height progressively.
When the unit is installed properly, the flame will be •
steady. It will also have a sharp, blue inner cone that
will vary in length proportional to the burner
size. The flame will be
reduced by the Smart
Flame™ feature under
the grate fingers to
increase grate life.
OFF HIGH LOW
NOTE: If the cooktop does not operate properly, follow
these troubleshooting steps:
Verify that power and gas are supplied to the cooktop.•
Check to make sure that the power plug is connected •
to the electrical outlet and that power is turned on at
the circuit breaker or fuse box.
Check to make sure that all burner parts are properly •
seated.
If the burner continues to spark after ignition without •
stopping, have a licensed electrician check the electrical outlet for proper grounding or reversed polarity.
Repeat the burner ignition test.•
If the appliance still does not work, contact Dacor
Distinctive Service at (877) 337-3226. Do not attempt to
repair the appliance yourself. Be sure to have the model
and serial numbers available when you call. See the inside
cover for location.
Dacor is not responsible for the cost of correcting problems
caused by a faulty installation.
12
Normal Flame
Appearance
Installation Instructions
Installation Checklist
WARNING
To ensure a safe and proper installation, the follow-•
ing checklist should be completed by the installer to
ensure that no part of the installation has been overlooked.
Proper installation is the responsibility of the hom-•
eowner. The importance of proper installation of your
Dacor cooktop cannot be overemphasized.
Is the electrical outlet for the cooktop grounded and
□
located according to these instructions and in accordance with all applicable electrical codes? See pages 3
and 4.
□
Is the gas service for the cooktop located and installed
according to these instructions and in accordance with
all applicable codes? See pages 3 and 4.
□
Has the gas supply inlet pressure been measured to
ensure that it does not exceed the maximums stated in
these instructions? See page 3.
□
Is the cooktop secured using the provided hold-down
bolts and washers? See page 8.
Is the cooktop connected to the gas supply according □
to these instructions and in accordance with all applicable codes? Did the installer check the gas supply for
leaks? See page 9.
Are all burner parts and grates properly installed □
according to these instructions? See page 10.
Are the knobs installed in the proper positions? See □
page 11.
Has proper operation been verified? □
Has the warranty been activated on-line or the warranty □
card filled out completely and mailed?
13
Wiring Diagram
AFTER SERVICING
VERIFY PROPER OPERATION
120V, 60Hz, 0.25A
POWER SUPPLY
CAUSE IMPROPER AND DANGEROUS OPERATION.
WHEN SERVICING CONTROLS. WIRING ERRORS CAN
CAUTION: LABEL ALL WIRES PRIOR TO DISCONNECTION
WIRING DIAGRAM
EG366/EG486
RR LED HARNESS
O
O
O
O
O
O
B
B
B
B
B
B
B
B
RL BURNER
IGNITOR, IGNITOR,
RC BURNER
RR BURNER
IGNITOR,
IGNITOR,
FR BURNER
IGNITOR,
FL BURNER
FC BURNER
IGNITOR,
S1
S2
S3
S4
S6
S5
B
B B
B
BLACK
WHITE
FR LED HARNESS
W
W
W
W
FL LED HARNESS
Single Point
Spark Module
W
W
W
W
W
Single Point
Spark Module
Single Point
Spark Module
W
W
Single Point
Spark Module
W
W
Single Point
Spark Module
FC LED HARNESS
W
W
W
W
W
RL LED HARNESS
RC LED HARNESS
W
W
Single Point
Spark Module
W
W
14
Notes
15
Notes
16
Dacor●600AntonBlvd.Suite1000CostaMesa,CA92626●Phone:(800)793-0093●Fax:(626)403-3130●www.Dacor.com
Loading...
