Dacor DRZ30990RAP User Manual

Modernist Built-In Freezer
DRZ18/24/30/36*
User Manual
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 1 2017-03-20  5:35:31
Contents
Contents
Important Information 5
Safety Information 6
What’s included 17
Operations 19
Care and Maintenance 40
English2
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 2 2017-03-20  5:35:31
Troubleshooting 41
Warranty and Service 50
Regulatory Notice 54
Open Source Announcement 56
Contents
English 3
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 3 2017-03-20  5:35:31
To Our Valued Customer:
Congratulations on your purchase of the very latest in Dacor® products! Our unique combination of features, style and performance make us The Life of the Kitchen™, and a great addition to your home.
In order to familiarize yourself with the controls, functions and full potential of your new Dacor Appliance, read this use and care manual thoroughly, beginning with the Important Safety Instructions section.
All Dacor appliances are designed and manufactured with quality and pride, while working within the framework of our company value. Should you ever experience a problem with your product, please first check the Troubleshooting section of this manual for guidance. It provides useful suggestions and remedies prior to calling for service.
Valuable customer input helps us to continuously improve our products and services, so please feel free to contact our Customer Service Team for assistance with any of your product support needs.
Dacor Customer Service Team 14425 Clark Avenue City of Industry, CA 91745
Telephone: (800) 793-0093
Fax: (626) 403-3130
Hours of Operation: Monday through Friday 6:00 A.M. to 5:00 P.M. Pacific Time
Website: www.Dacor.com
Thank you for choosing Dacor for your home. We are a company built by families for families, and we are dedicated to serving yours. We are confident that your new Dacor product will deliver a high level of performance and enjoyment for many years to come.
Sincerely,
English4
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 4 2017-03-20  5:35:32

Important Information

Before You Begin

Installer
• Leave these Use and Care instructions with the appliance.
Important Information
Consumer
• Please read this Use and Care Manual completely before using your refrigerator. Save it for future reference.
• The overall design and/or accessories may differ with the model.
Retain your sales receipt or canceled check. Proof of original purchase date is required for warranty service.
Have the complete model and serial number identification for your appliance ready.
These numbers are found on the label located inside of the refrigerator wall. Record these numbers below for easy access.
Model Number Serial Number Date of Purchase
Since we continually improve the quality and performance of our products, we may make changes to the appliance without updating this manual. Visit www.dacor.com to download the latest version of this manual.
Dacor Customer Service Phone: (800) 793-0093 (U.S.A. and Canada) Monday — Friday 6:00 A.M. to 5:00 P.M. Pacific
Time
Website: www.dacor.com
English 5
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 5 2017-03-20  5:35:32

Safety Information

• Before using your new Dacor Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efficiently.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or those who lack experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.
• Because the following instructions cover various models, the characteristics of your refrigerator may differ slightly from the refrigerator described in this manual.
• It is hazardous for anyone other than an Authorised Service Person to service this appliance.
Safety Information
• Refrigerant squirting out of the pipes could ignite or cause an eye injury. When refrigerant leaks from the pipe, avoid any naked flames and move anything flammable away from the product and ventilate the room immediately.
- Failing to do so may result in fire or explosion.
WARNING
• R-600a is used as a refrigerant. This product contains flammable gas (Refrigerant R-600a), contact your local authority in regard to safe disposal of this product.
• In order to avoid the creation of a flammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used. The room must be 35.3 ft³ in size for every 8 g of R-600a refrigerant inside the appliance.
• The installation location should not be exposed to direct sunlight and not placed near any electric appliance or heat source, e.g. stove, oven or hob, radiator, etc.
• If you use two products side by side, for safety reason, be sure to use certified products in explosive gas atmospheres.
• Never start up an appliance showing any signs of damage. If in doubt, consult your dealer.
English6
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 6 2017-03-20  5:35:32

Important safety symbols and precautions:

Please follow all safety instructions in this manual. This manual uses the following safety symbols.
WARNING
Hazards or unsafe practices that may result in severe personal injury, property damage, and/or death.
CAUTION
Hazards or unsafe practices that may result in severe personal injury and/or property damage.
NOTE
Useful information that helps users understand or benefit from the refrigerator.
These warning signs are here to prevent injury to you and others. Please follow them carefully. After reading this section, keep it in a safe place for future reference.

State of California Proposition 65 Warning (US only)

WARNING : This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Safety Information

Severe warning signs for transportation and site

WARNING
• When transporting and installing the appliance,care should be taken to ensure that no parts of the refrigerating circuit are damaged.
- Refrigerant leaking from the pipe work could ignite or cause an eye injury. If a leak
is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is standing for several minutes.
- This appliance contains a small amount of isobutane refrigerant (R-600a), a natural
gas with high environmental compatibility that is, however, also flammable. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.
English 7
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 7 2017-03-20  5:35:32
Safety Information

Critical installation warnings

WARNING
• Do not install the refrigerator in a damp location or place where it may come in contact with water.
- Deteriorated insulation on electrical parts may cause an electric shock or fire.
• Do not place this refrigerator in direct sunlight or expose it to the heat from stoves, room heaters, or other appliances.
• Do not plug several appliances into the same multiple power strip. The refrigerator
Safety Information
should always be plugged into its own individual electrical outlet which has a voltage rating that matches the voltage listed on the refrigerator’s rating plate.
- This provides the best performance and also prevents overloading of house wiring
circuits, which could overheat the wires and cause a fire hazard.
• If the wall socket is loose, do not insert the power plug.
- There is a risk of electric shock of fire.
• Do not use a power cord that has cracks or abrasion damage along its length or at either end.
• Do not bend the power cord excessively or place heavy objects on it.
• Do not pull or excessively bend the power cord.
• Do not twist or tie the power cord.
• Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance.
• Never unplug your refrigerator by pulling on the power cord. Always grip the plug firmly and pull straight out from the outlet.
- Damage to the cord may cause a short-circuit, fire, and/or electric shock.
• Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
• Do not install this appliance near a heater or flammable material.
• Do not install this appliance in a location where gas may leak.
- This may result in an electric shock or fire.
• This refrigerator must be properly located and installed in accordance with the instructions in this manual before you use it.
• Connect the power plug in the proper position with the cord hanging down.
- If you connect the power plug upside down, the wire can get cut off and cause a fire
or electric shock.
• Make sure that the power plug is not crushed or damaged by the back of the refrigerator.
English8
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 8 2017-03-20  5:35:32
• Keep the packing materials out of reach of children.
- There is a risk of death from suffocation if a child puts the packing materials on his or her head.
• The appliance must be positioned so that the plug is accessible after installation.
- Failing to do so may result in an electric shock or fire due to electric leakage.
• Do not install this appliance in a humid, oily or dusty location, or in a location exposed to direct sunlight or to water (rain drops).
- Deteriorated insulation on electrical parts may cause an electric shock or fire.
• If large amounts of dust or water enter the refrigerator, disconnect the power plug and contact your Dacor service center.
- Otherwise there is a risk of fire.
• You need to remove all the protective plastic film before you initially plug the product in.
• Children should be supervised to ensure that they do not play with the snap rings used for door adjustment or the water tube clips.
- There is risk of death by suffocation if a child swallows a snap ring or water tube
clip. Keep the snap rings and water tube clips out of children’s reach.
• The refrigerator must be safely grounded.
- Always make sure that you have grounded the refrigerator before attempting to
investigate or repair any part of the appliance. Power leakages can cause severe electric shock.
• Never use gas pipes, telephone lines, or other potential lightning attractors as an electrical ground.
- You must ground the refrigerator to prevent any power leakages or electric shocks
caused by current leakage from the refrigerator.
- This may result in an electric shock, fire, explosion, or problems with the product.
- Improper use of the grounding plug can result in a risk of electric shock. If it is
necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding plug and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extension cord should be AC 115-120 V, 10 A, or more. If a grounding adapter is used, make sure the receptacle box is fully grounded.
• Plug the power plug into the wall socket firmly. Do not use a damaged power plug, damaged power cord, or loose wall socket.
- This may result in an electric shock or fire.
• If the power cord is damaged, have it replaced immediately by the manufacturer or one of its service agents.
Safety Information
English 9
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 9 2017-03-20  5:35:32
Safety Information
• Only a qualified technician or service company should be allowed to change the fuse in the refrigerator.
- Failing to do so may result in an electric shock or personal injury.

Installation cautions

CAUTION
• Allow sufficient space around the refrigerator and install it on a flat surface.
Safety Information
- Keep the ventilation space in the appliance enclosure or mounting structure clear of
obstructions.
• After you have installed the refrigerator and turned it on, allow the appliance to stand for 2 hours before loading it with food.
• It is strongly recommended you have a qualified technician or service company install the refrigerator.
- Failing to do so may result in an electric shock, fire, explosion, problems with the
product, or injury.
• Overloading one door may make the refrigerator fall, causing physical injury.
English10
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 10 2017-03-20  5:35:32

Critical usage warnings

WARNING
• Do not insert the power plug into a wall socket with wet hands.
- This may result in an electric shock.
• Do not store articles on the top of the appliance.
- When you open or close the door, the articles may fall and cause personal injury and/or material damage.
• Do not insert hands, feet or metal objects (such as chopsticks, etc.) into the bottom or the back of the refrigerator.
- This may result in an electric shock or injury.
- Any sharp edges may cause a personal injury.
• Do not touch the inside walls of the freezer or products stored in the freezer with wet hands.
- This may cause frostbite.
• Do not put a container filled with water on the refrigerator.
- If spilled, there is a risk of fire or electric shock.
• Do not keep volatile or flammable objects or substances (benzene, thinner, propane gas, alcohol, ether, LP gas, and other such products) in the refrigerator.
- This refrigerator is for storing food only.
- This may result in fire or explosion.
• Children should be supervised to ensure that they do not play with the appliance.
- Keep fingers out of “pinch point” areas. Clearances between the doors and cabinet
are necessarily small. Be careful when you open the doors if children are in the area.
• Do not let children hang on the door or door bins. A serious injury may occur.
• Do not let children go inside the refrigerator. They could become trapped.
• Do not insert your hands into the area under the appliance.
- Any sharp edges may cause personal injury.
• Do not store pharmaceutical products, scientific materials, or temperature sensitive products in the refrigerator.
- Products that require strict temperature controls must not be stored in the
refrigerator.
• Do not place or use electrical appliances inside the refrigerator/freezer, unless they are of a type recommended by the manufacturer.
• If you smell smoke, turn off the power switch immediately, and then contact your Dacor service center.
• If large amounts of dust or water enter the refrigerator, turn off the power switch and contact your Dacor service center.
- Otherwise there is a risk of fire.
Safety Information
English 11
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 11 2017-03-20  5:35:32
Safety Information
• Do not let children step on a drawer.
- The drawer may break and cause them to slip.
• Do not leave the doors of the refrigerator open while the refrigerator is unattended and do not let children enter the refrigerator.
• Do not allow babies or children go into a drawer.
- It can cause death from suffocation by entrapment or personal injury.
• Do not overfill the refrigerator with food.
- When you open the door, an item may fall out and cause personal injury or material
damage.
Safety Information
• Do not spray volatile material such as insecticide onto the surface of the appliance.
- As well as being harmful to humans, it may also result in an electric shock, fire, or
problems with the product.
• Never put fingers or any objects into the water dispenser outlet, ice chute, or ice maker bucket.
- It may cause a personal injury or material damage.
• Do not use or place any substances sensitive to temperature such as flammable sprays, flammable objects, dry ice, medicine, or chemicals near or inside the refrigerator.
• Do not use a hair dryer to dry the inside of the refrigerator. Do not place a lighted candle in the refrigerator to remove bad odors.
- This may result in an electric shock or fire.
• Fill the water ice tray with potable water only (tap water, mineral water, or purified water).
• Do not use mechanical devices or any other means to accelerate the defrosting process, other than those recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not put a fridge shelf into the refrigerator upside down. The shelf stopper will not work.
- The glass shelf could fall and cause personal injury.
• If a gas leak is detected, avoid any naked flames or potential sources of ignition, and air the room in which the appliance is standing for several minutes.
- Do not touch the appliance or power cord.
- Do not use a ventilating fan.
- A spark may result in an explosion or fire.
• Use only the LED Lamps provided by the manufacturer or its service agents.
• Bottles should be stored tightly together so that they do not fall over or out.
• This product is intended only for the storage of food in a domestic environment.
• Never put fingers or any objects into the water dispenser outlet, ice chute, or ice maker bucket.
- This can cause a personal injury or material damage.
English12
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 12 2017-03-20  5:35:32
• Do not attempt to repair, disassemble, or modify the refrigerator yourself.
- Unauthorized modifications can cause safety problems. To reverse an unauthorized modification, we will charge the full cost of parts and labor.
• Do not use any fuse (such as cooper, steel wire, etc.) other than a standard fuse.
• If your refrigerator needs to be repaired or reinstalled, contact your nearest service center.
- Failing to do so may result in an electric shock, fire, problems with the product, or
injury.
• If the interior or exterior LED lamp has gone out, contact your nearest Dacor service center.
• If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact a Dacor service center.
- Failing to do so may result in an electric or fire hazards.
• Pull the power plug out of the socket before changing the interior lamps of the refrigerator.
- Otherwise, there is a risk of electric shock.
• If you experience difficulty changing a non-LED light, contact a Dacor service center.
• If the product is equipped with LED lamps, do not disassemble the Lamp Covers and LED lamps yourself.
- Contact a Dacor service center.
• Plug the power plug into the wall socket firmly.
• Do not use a damaged power plug, damaged power cord, or loose wall socket.
- This may result in an electric shock or fire.
• Do not expose the interior accessories, such as door bins, drawers, and shelves to direct sunlight for long.
Safety Information
English 13
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 13 2017-03-20  5:35:32
Safety Information

Usage cautions

CAUTION
• Do not re-freeze frozen foods that have thawed completely. Do not place carbonated or fizzy drinks in the freezer compartment. Do not put bottles or glass containers in the freezer.
- When the contents freeze, the glass may break and cause personal injury.
• Use only the ice maker provided with the refrigerator.
• To get the best performance from the product:
Safety Information
- Do not place food too close to the vents at the rear of the refrigerator as this can
obstruct free air circulation in the refrigerator compartment.
- Wrap food up properly or place it in airtight containers before putting it into the
refrigerator.
- Do not put glass bottles or carbonated beverages into the freezer. They can freeze
and break. Broken beverage containers can cause injury.
- Please observe maximum storage times and expiration dates of frozen goods.
• Do not put glass containers or bottles or carbonated beverages into the freezer.
- The container may freeze and break, and this may result in injury.
• Service Warranty and Modification.
- Any changes or modifications performed by a 3rd party on this finished appliance
are not covered under Dacor warranty service, nor is Dacor responsible for safety issues that result from 3rd party modifications.
• Do not block the air vents inside the refrigerator.
- If the air vents are blocked, especially with a plastic bag, the refrigerator can be
over cooled.
• If the refrigerator is disconnected from the power supply, you should wait for at least five minutes before plugging it back in.
• If large amounts of water enter the refrigerator, turn off the power switch and contact a Dacor service center.
• Do not strike or apply excessive force to any glass surface.
- Broken glass may result in a personal injury and/or property damage.
• Fill the water tank and ice cube trays with potable water only (tap water, mineral water, or purified water).
- Do not fill the tank with tea, juice, or a sports drink. They can damage the
refrigerator.
• If the refrigerator is flooded, shut off the power to the refrigerator and contact your nearest Dacor service center.
- There is a risk of electric shock or fire.
English14
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 14 2017-03-20  5:35:32

Cleaning cautions

CAUTION
• Do not spray water directly on the inside or outside the refrigerator.
- There is a risk of fire or electric shock.
• Do not use a hair dryer to dry the inside of the refrigerator.
• Do not place a lighted candle in the refrigerator to remove bad odors.
- This may result in an electric shock or fire.
• Do not spray cleaning products directly on the display.
- Printed letters on the display may come off.
• If any foreign substance such as water has entered the appliance, unplug the power plug and contact your nearest service center.
- Failing to do so may result in an electric shock or fire.
• Use a clean, dry cloth to remove any foreign matter or dust from the power plug blades. Do not use a wet or damp cloth when cleaning the plug.
- Otherwise, there is a risk of fire or electric shock.
• Do not clean the appliance by spraying water directly onto it.
• Do not use benzene, thinner, or Clorox (bleach) to clean the refrigerator.
- They may damage the surface of the appliance and may cause a fire.
• Never put fingers or any objects into the dispenser outlet.
- This can cause a personal injury or material damage.
• Before cleaning or performing maintenance, unplug the appliance from the wall socket.
- Failing to do so may result in an electric shock or fire.
Safety Information
English 15
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 15 2017-03-20  5:35:32
Safety Information

Critical disposal warnings

WARNING
• DANGER : Risk of child entrapment. Before you throw away your old refrigerator or freezer:
- Take off the doors and door latch.
- Leave the shelves in place so that children cannot easily climb inside.
- Children trapped inside a refrigerator can hurt themselves or suffocate to death.
• Please dispose of the packaging material from this product in an environmentally
Safety Information
friendly manner.
• Ensure that none of the pipes on the back of the refrigerator are damaged prior to disposal.
• R-600a is used as a refrigerant. This product contains flammable gas (Refrigerant R-600a), contact your local authority in regard to safe disposal of this product.
• When disposing of this refrigerator, remove the door/door seals and door latch so that small children or animals cannot become trapped inside. Children should be supervised to ensure that they do not play with the appliance.
- If trapped inside, the child could be injured or suffocate to death.
• Cyclopentane is used in the insulation. The gases in the insulation material require a special disposal procedure. Please contact your local authorities in regard to the environmentally safe disposal of this product.
• Keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children.
- If a child places a bag over his or her head, the child could suffocate.
English16
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 16 2017-03-20  5:35:32

What’s included

02
01
03
04 05
06
07

Inside Parts, Storage, and Shelving

01 Power switch, Auto Door Open switch 02 Shelves 03 Door bins 04 Ice Maker 05 Drawers 06 Control Panel 07 Water filter (cover)
What's included
• The overall design and/or accessories may differ with the model.
English 17
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 17 2017-03-20  5:35:33
What's included
Switch box
What's included
• Use a flat head screwdriver to open the switch box cover.
• The black one is the Power switch while the Auto Door Open switch is red next to it.
• Close the switch box cover.
English18
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 18 2017-03-20  5:35:33

Operations

02 04 06
03 05 0701 0909
10 10
1008

Control Panel

01 Freezer / Power Freeze 02 Cocktail Ice
03 Filter Reset 04 Standard Ice
05 Door Alarm / °C °F 06 Override
07 Control Lock 08 Network connection
09 Sabbath Mode 10 Cooling off
NOTE
• When you change the temperature on the panel, the panel displays the actual temperature inside the refrigerator until the temperature matches the temperature you set. Then, the panel displays the new set temperature. Note that it will take time for the refrigerator to reach the new temperature. This is normal. During this time, you need not set the temperature again.
• If no button is input for 10 seconds after Control Lock is deactivated, the display will turn off except for the Control Lock button. To turn the display on, press Control Lock again.
• If the control panel moisture or liquid on its surface, it may fail. Wipe the moisture or liquid using a dry cloth, and then try again.
Operations
English 19
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 19 2017-03-20  5:35:33
Operations
01 Freezer / Power Freeze (3 sec)
Freezer
Power Freeze
Operations
You can use the Freezer button to set the freezer temperature or to activate/deactivate Power Freeze. To set the freezer temperature, press Freezer repeatedly. Available temperatures are between 5 °F (-15 °C) and -8 °F (-23 °C).
Power Freeze lowers the freezer temperature and speeds up the freezing process. In Power Freeze mode, the freezer runs at full power for several hours and then returns to normal operation and the previous temperature setting.
• To activate Power Freeze, press and hold Freezer for 3 seconds. The corresponding indicator ( speeds up the freezing process for you.
• To deactivate, press and hold Freezer for 3 seconds again.
NOTE
Using Power Freeze increases power consumption. If you do not need the Power Freeze function on, make sure you turn it off so that the refrigerator can return to normal operation and the previous temperature setting.
) lights up, and the refrigerator
02 Cocktail Ice (3 sec)
Press and hold Cocktail Ice for more than 3 seconds to turn the
Cocktail Ice
Cocktail ice on or off. If the Ice Maker Indicator indicates OFF mode, ice making is disabled.
You must change the indicator to ON mode.
English20
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 20 2017-03-20  5:35:34
03 Filter Reset (3 sec)
After about 6 months of using the original water filter (which typically amounts to about 300 gallons (1136 liters) of water), the Filter indicator blinks red to remind you that the filter needs to be replaced.
When this happens, replace the filter, and then press and hold Filter Reset for 3 seconds. This resets the filter lifecycle detector and turns off the Filter indicator.
Filter Reset
NOTE
• Some areas have relatively large amounts of lime in their water. This may reduce the lifecycle of the filter. In these areas, you will have to replace the water filter more often than specified above.
• If water is not dispensing properly, the water filter is most likely clogged. Even if the Filter indicator is not blinking, replace the water filter.
04 Standard Ice (3 sec)
Press and hold Standard Ice for more than 3 seconds to turn the
Standard Ice
Standard ice on or off. If the Ice Maker Indicator indicates OFF mode, ice making is disabled.
You must change the indicator to ON mode.
05 Door Alarm / °C  °F (3 sec)
You can enable or disable the door alarm by pressing Door Alarm.
Door Alarm
When Door Alarm is enabled and a door is left open for more than 2 minutes, the alarm will sound and the alarm indicator will blink. The Door Alarm function is enabled by factory default.
You can use the Door Alarm button to switch the temperature scale
°C °F
between Celsius and Fahrenheit. To switch the temperature scale, press and hold Door Alarm for
3 seconds.
06 Override (3 sec)
Override
The Override function activates/deactivates Smart Grid. Press Override for 3 seconds to set/clear the Override function.
Operations
English 21
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 21 2017-03-20  5:35:34
Operations
07 Control Lock (3 sec)
Control Lock
Device authentication
08 Network connection
You can control and monitor your refrigerator through the Dacor Smart Home app. For more information, see the Dacor Smart Home section.
Operations
• Recommended encryption systems include WPA/TKIP and WPA2/AES. Any newer or
• Wireless networks may be affected by the surrounding wireless communication
• If your Internet service provider has registered the MAC address of your PC or modem
• The firewall settings of your network system may prevent your Dacor Smart
• To configure the wireless access point (AP) settings, see the user manual of the AP.
• Dacor Smart Refrigerators support both Wi-Fi 2.4 GHz with IEEE 802.11 b/g/n and
• Unauthorized Wi-Fi wireless routers may fail to connect to applicable Dacor Smart
To prevent accidental setting changes, press and hold Control Lock for 3 seconds. All controls will be disabled and the Lock indicator ( turn on.
If you press and hold the button again for more than 3 seconds, Control Lock will be deactivated. However, Control Lock will be reactivated if no button is input for the next 1 minute.
To authenticate your device, press and hold Control Lock for 5 seconds. A chime sounds with a message of ‘on’ on the temperature display for 5 seconds.
Authorized devices can be used with Samsung Smart TV apps where the privacy information on the refrigerator can be shared to the TV. Availability of this function depends on the device model.
NOTE
unstandardized Wi-Fi authentication protocols are not supported.
environment.
for identification, your Dacor Smart Refrigerator may fail to connect to the Internet. If this happens, contact your Internet service provider for technical assistance.
Refrigerator from accessing the Internet. Contact your Internet service provider for technical assistance. If this symptom continues, contact a local Dacor service center or retailer.
Soft-AP protocols (IEEE 802.11 n is recommended).
Refrigerators.
) will
English22
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 22 2017-03-20  5:35:34
09 Sabbath Mode
The Sabbath mode stays active for 85 hours once it is activated. After that, it will be deactivated automatically.
• To activate, press and hold Freezer and Door Alarm simultaneously for 5 seconds to enter Sabbath mode. Then the refrigerator operates in Sabbath mode where the buttons, the display, and the room lamps are all under control.
• To deactivate, press and hold the buttons again for 5 seconds to exit Sabbath mode.
NOTE
• If the Control Lock indicator turns on, you must first cancel Control Lock.
• Even after the refrigerator powers off and restarts, the Sabbath mode remains active. To exit, you must deactivate it first.
• If two refrigerator units are installed in pairs, you must set or change the settings of Sabbath mode for each refrigerator respectively.
10 Cooling Off
Cooling Off mode (also called Shop mode) is designed for use by retailers when they are displaying refrigerators on a retail floor.
In Cooling Off mode, the fan motor and lights operate normally, but the compressors do not run so the freezer does not get cold.
• To enter Cooling Off mode, press and hold Cocktail Ice, Standard Ice, and Filter Reset simultaneously for 5 seconds. The freezer chime sounds and the temperature display shows “oF”.
• To exit Cooling Off mode, press and hold Cocktail Ice, Standard Ice, and Filter Reset simultaneously for 5 seconds again. The freezer chime sounds and the temperature display shows the current temperature.
Operations
NOTE
If the Control Lock indicator turns on, you must first deactivate Control Lock.
English 23
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 23 2017-03-20  5:35:34
Operations

Dacor iQ Kitchen

Installation
Visit the Google Play Store, Galaxy Apps, or Apple App Store and search for “Dacor iQ Kitchen”. Download and install the Dacor iQ Kitchen app to your smart device.
• The Dacor iQ Kitchen app is designed for Android 4.0 (ICS) or higher, or iOS 8.0 or
• For improved performance, the Dacor iQ Kitchen app is subject to change without
Samsung account
You are required to register your Samsung account to use the app. If you don’t have a Samsung account, follow the app’s onscreen instructions to create a free Samsung account.
Getting started
1. Run the Dacor iQ Kitchen app and log in with your Samsung account. iPhone users are
2. Select Add Device and then tap Refrigerator.
Operations
3. Follow the onscreen instructions to provide the necessary information about the
4. Press and hold Freezer for more than 5 seconds until the “AP” message appears on the
5. When device registration is complete, the refrigerator icon will appear on the Dacor iQ
6. Tap the refrigerator icon to open the refrigerator page.
7. When a network connection is established, the Wi-Fi icon lights up on your refrigerator.
NOTE
higher.
notice, or discontinued support according to the manufacturer’s policy.
required to provide the login information each time they access the app.
router, and then tap Next.
freezer display. Your refrigerator will be registered with the app.
Kitchen app.
Refrigerator app
Integrated control
You can monitor and control your refrigerator at home and on the go.
• Tap the refrigerator icon in the Dacor iQ Kitchen to open the refrigerator page.
• Check the operation status or notifications related to your refrigerator, and change options or settings if necessary.
NOTE
Some options or settings of the refrigerator may not be available for remote control.
English24
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 24 2017-03-20  5:35:34
Category Item Description
Displays the current temperature setting of the freezer.
Checks the accumulated power consumption of the refrigerator for the last 180 days.
Monitoring
Freezer temperature
Self Check Detects abnormal operations of the refrigerator.
Energy monitoring
You can turn the ice making function on or off, and check the current settings of the function.
You can also check the status and progress of ice making.
You can turn Power Freeze on or off, and check the current settings.
This alarm is triggered when the freezer has abnormally high temperatures.
This alarm is triggered if the freezer door is left open for a specific time.
This alarm reminds you that the water filter must be replaced.
Functions
Alarms
Ice making (Cocktail / Standard Ice)
Power Freeze
Abnormally high temperature
Door opening
Water filter replacement
Operations
English 25
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 25 2017-03-20  5:35:34
Operations

SMART GRID Function (Demand Response)

When the refrigerator operates in SMART GRID (Demand Response) mode, the Energy Management Refrigerator function can control energy usage or delay the operation of some functions to save money when energy prices or demand are the highest.
• You can deactivate the SMART GRID (Demand Response) function at any time using the
• To use the SMART GRID (Demand Response) function, you need a separate contract with
In addition, to use the Smart Grid (Demand Response) function, you must register for the service with your electric company. The company must have an EMS (Energy Management System) that supports SEP (Smart Energy profile).
Using the SMART GRID (Demand Response) Function
This feature monitors energy prices and demand information from your utility company and sends notifications to the refrigerator to run high energy consuming tasks during off­peak times when electricity costs and demand are lower.
Operations
If the refrigerator receives a control signal from the utility company, the refrigerator will display the DAL (L3) ~ TALR (L4) levels on the refrigerator display and control the power consumption according to the level.
[Exception condition] The DAL and TALR control signals from a utility company work as long as product performance is maintained.
If the refrigerator receives the SMART GRID (Demand Response) signal (DAL or TALR), the refrigerator will operate in Delay Appliance Load (Display: Turn on “DAL” icon) or Temporary Appliance Load Reduction (Display: Turn on “TALR” icon) mode.
• Delay Appliance Load (L3): The refrigerator responds to a DAL signal by providing a
NOTE
Override On/Off function.)
your electric utility company.
moderate load reduction for the duration of the delay period. This function controls functions that consume a lot of energy such as adjusting the Cooling system, running the defrost cycle, and making ice.
- When the refrigerator operates in DAL (L3) mode, turn on the “DAL” icon on the
refrigerator display.
- DAL mode is automatically deactivated after it lasts for the amount of time
stipulated by the DAL signal (max. 4.5 hours) or when the Override key is pressed.
English26
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 26 2017-03-20  5:35:34
• Temporary Appliance Load Reduction (L4): The refrigerator responds to a TALR signal by aggressively reducing the load for a short time period. This function reduces energy consumption by stopping the compressor and controlling the functions that consume a lot of energy such as the defrost cycle and making ice.
- When the refrigerator operates in TALR (L4) mode, turn on the “TALR” icon on the
refrigerator display.
- TALR (L4) mode is automatically deactivated after it lasts for the received duration
(max. 15 minutes), or when the Override key is pressed. The mode is immediately deactivated and the refrigerator returns to the normal state when the door is opened or closed, or the dispenser is used.
To check the MAC address
1. In this mode, the MAC address appears on the temperature panel sequentially for
1 minute. Press and hold both Freezer and Filter Reset for 6 seconds. The temperature display blinks. Then, press Control Lock to display the MAC address. The freezer beeps.
2. For example, if the MAC address is “11-22-33-44-55-66”, the temperature panel displays the address for 1 minute in this sequence: “--” “11” “22” “33” “44” “55” “66” “--”. After the 1 minute, the MAC address disappears and the temperature panel returns to the normal state.
Operations
NOTE
The temperature panel displays “-- / --” for an unknown MAC address or if a Wi-Fi connection is not established or is lost.
Override Mode
When you want the refrigerator to ignore the SMART GRID (Demand Response) signal from the utility company, you can activate OVERRIDE mode.
When you activate OVERRIDE mode, the refrigerator ignores the SMART GRID (Demand Response) signal and is not controlled by the utility company.
Activating and deactivating Override mode
1. Press and hold Override for 3 seconds.
2. A beep sounds with a message of ‘Or’ on the temperature display for 5 seconds. The
Override indicator (
3. If the refrigerator receives a SMART GRID (Demand Response) signal from the utility company, `Or’ is displayed in the freezer temperature display.
4. To deactivate OVERRIDE mode, press and hold Override for 3 seconds.
5. A beep sounds with a message of ‘Or’ on the temperature display for 5 seconds. The
Override indicator (
) turns on.
) turns off.
English 27
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 27 2017-03-20  5:35:34
Operations
• Alternatively, you can activate or deactivate OVERRIDE mode using the Dacor iQ
Using the Energy Management Function
The Energy Management function enables you to control and monitor your Energy Management refrigerator using the Dacor iQ Kitchen app for your convenience.
• To use the Energy Management refrigerator functions, you have to install the
1. Operational Status, User Settings & Messages
2. Remote Management
Operations
3. Energy Consumption Reporting
NOTE
Kitchen app and the Energy Management function. See the next page.
NOTE
corresponding app first.
- You can view the freezer temperature settings.
- You can receive an alarm when the freezer door is open for 2 minutes.
- You can check the DR and Override status.
- You can check the operational condition of the ice maker in the freezer.
- Power Freeze Setting: You can remotely activate the Power Freeze function.
- Ice On/Off Setting: You can remotely set up the Ice On/Off Setting function. You can only control the Ice maker in the freezer remotely.
- Shows the accumulated power consumption. Power consumption data is updated every 10 minutes.
NOTE
The energy consumption report may differ from the power consumption specifications of the product depending on the operating environment and the stored food.
4. Delay Defrost Capability
- The Delay Defrost Capability function saves energy by delaying the defrost operation to a time specified by the user. You can configure the time. and this function will save energy during the specified period in a 24 hour cycle. If the time is not set, the function works with the default time settings. The default time settings are below:
- 6 am to 10 am: 1st. November ~ 30th. April
- 3 pm to 7 pm: 1st. May ~ 31th. October
To change the time setting for the Delay Defrost Capability
You can change the time setting for the Delay Defrost Capability on the app.
English28
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 28 2017-03-20  5:35:34
Provision for Open Access to the Connected Product Requirements
1. SGIP Open Standards (Smart Energy Profile 2.0 - http://www.csep.org/)
- Energy Consumption Reporting
- Demand Response
2. OPEN API
- Operational Status, User Settings & Messages
- ICE Maker Status: GET /devices/0/Fridge/iceMaker
- Door Open Alarm: GET /devices/0/Door/<<id>>/openState
- DR Status: GET /devices/0/drlc
- Delay Defrost Capability
- Set Schedule of the Defrost Delay: PUT /devices/0/fridge/<<id>>/DefrostReservation
- Get Schedule of the Defrost Delay: GET /devices/0/fridge/<<id>>/DefrostReservation
- Delete Schedule of the Defrost Delay: DELETE /devices/0/fridge/<<id>>/ DefrostReservation
- Defrost Delay On/OFF: PUT /devices/0/Fridge/delayDefrost
Operations
English 29
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 29 2017-03-20  5:35:34
Operations

Special features

Ice maker
The refrigerator has a built-in ice maker that automatically dispenses ice.
• The overall design and/or accessories may differ with the model.
Ice making
After you have installed your refrigerator and plugged it in, follow these instructions to
Operations
ensure proper ice making and to keep the ice bucket full of ice:
For first-time use
• Let the ice maker make ice for 1-2 days.
• Discard the first 1-2 buckets of ice to remove impurities in the water supply system.
Cocktail Ice
Standard Ice
• This product has two types of ice makers.
• On the left is the cocktail ice maker. The cocktail ice maker makes denser, larger sized ice which melts slower to keep beverages chilled for a longer time.
• Because the cocktail ice maker makes denser and larger ice, it takes longer than a regular ice maker to make ice.
Diagnosis
• The overall design and/or accessories may differ with the model.
If ice does not dispense, first check the status of the ice maker using the blue­siliconized Test button on the side of the ice maker.
1. Slightly lift to remove the drawer cover (shelf).
English30
Dacor_BRR9000M_FRE_DA68-03607A-02_EN.indd 30 2017-03-20  5:35:35
