Dacor DRR30990RAP, DRR30990LAP User Manual

Modernist Built-In Fridge

DRR24/30/36*

User Manual

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 1 2017-03-20  5:36:15

Contents

Contents

Important Information 5

Before You Begin 5

Safety Information 6

Important safety symbols and precautions: 7
State of California Proposition 65 Warning (US only) 7
Severe warning signs for transportation and site 7
Critical installation warnings 8
Installation cautions 10
Critical usage warnings 11
Usage cautions 14
Cleaning cautions 15
Critical disposal warnings 16

What’s included 17

Inside Parts, Storage, and Shelving 17

Operations 19

Control panel 19
Dacor iQ Kitchen 25
SMART GRID Function (Demand Response) 27
Special features 31
Handle and care 34
Replacement 37

Care and Maintenance 40

Cleaning 40

English2

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 2 2017-03-20  5:36:15

Troubleshooting 41

General 41
Do you hear abnormal sounds from the refrigerator? 44
Auto Door Open (ADO) 46
Dacor iQ Kitchen 47
Smart Grid 48

Warranty and Service 50

Customer service 50
Warranty 50

Regulatory Notice 54

FCC Notice 54
IC Notice 55

Open Source Announcement 56

Contents

English 3

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 3 2017-03-20  5:36:15

To Our Valued Customer:

Congratulations on your purchase of the very latest in Dacor® products! Our unique
combination of features, style and performance make us The Life of the Kitchen™, and a
great addition to your home.

In order to familiarize yourself with the controls, functions and full potential of your new
Dacor Appliance, read this use and care manual thoroughly, beginning with the Important
Safety Instructions section.

All Dacor appliances are designed and manufactured with quality and pride, while working
within the framework of our company value. Should you ever experience a problem with
your product, please first check the Troubleshooting section of this manual for guidance. It
provides useful suggestions and remedies prior to calling for service.

Valuable customer input helps us to continuously improve our products and services, so
please feel free to contact our Customer Service Team for assistance with any of your
product support needs.

Dacor Customer Service Team
14425 Clark Avenue
City of Industry, CA 91745

Telephone: [phone]

Fax: [phone]

Hours of Operation: Monday through Friday 6:00 A.M. to 5:00 P.M. Pacific Time

Website: www.Dacor.com

Thank you for choosing Dacor for your home. We are a company built by families for
families, and we are dedicated to serving yours. We are confident that your new Dacor
product will deliver a high level of performance and enjoyment for many years to come.

Sincerely,

English4

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 4 2017-03-20  5:36:15

Important Information

Before You Begin

Installer

• Leave these Use and Care instructions
with the appliance.

Important Information

Consumer

• Please read this Use and Care
Manual completely before using
your refrigerator. Save it for future
reference.

• The overall design and/or accessories
may differ with the model.

Retain your sales receipt or canceled check. Proof of original purchase date is required for
warranty service.

Have the complete model and serial number identification for your appliance ready.

These numbers are found on the label located inside of the refrigerator wall. Record these
numbers below for easy access.

Model Number
Serial Number
Date of Purchase

Since we continually improve the quality and performance of our products, we may make
changes to the appliance without updating this manual. Visit www.dacor.com to download
the latest version of this manual.

Dacor Customer Service
Phone: [phone] (U.S.A. and Canada) Monday — Friday 6:00 A.M. to 5:00 P.M. Pacific

Time

Website: www.dacor.com

English 5

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 5 2017-03-20  5:36:15

Safety Information

• Before using your new Dacor Refrigerator, please read this manual thoroughly to
ensure that you know how to operate the features and functions that your new
appliance offers safely and efficiently.

• This appliance is not intended for use by persons (including children) with reduced
physical, sensory, or mental capabilities, or those who lack experience and knowledge,
unless they have been given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.

• Because the following instructions cover various models, the characteristics of your
refrigerator may differ slightly from the refrigerator described in this manual.

• It is hazardous for anyone other than an Authorised Service Person to service this
appliance.

Safety Information

• Refrigerant squirting out of the pipes could ignite or cause an eye injury. When
refrigerant leaks from the pipe, avoid any naked flames and move anything flammable
away from the product and ventilate the room immediately.

- Failing to do so may result in fire or explosion.

WARNING

• R-600a is used as a refrigerant. This product contains flammable gas (Refrigerant
R-600a), contact your local authority in regard to safe disposal of this product.

• In order to avoid the creation of a flammable gas-air mixture if a leak in the
refrigerating circuit occurs, the size of the room in which the appliance may be sited
depends on the amount of refrigerant used. The room must be 35.3 ft³ in size for
every 8 g of R-600a refrigerant inside the appliance.

• The installation location should not be exposed to direct sunlight and not placed near
any electric appliance or heat source, e.g. stove, oven or hob, radiator, etc.

• If you use two products side by side, for safety reason, be sure to use certified
products in explosive gas atmospheres.

• Never start up an appliance showing any signs of damage. If in doubt, consult your
dealer.

English6

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 6 2017-03-20  5:36:15

Important safety symbols and precautions:

Please follow all safety instructions in this manual. This manual uses the following safety
symbols.

WARNING

Hazards or unsafe practices that may result in severe personal injury, property damage,
and/or death.

CAUTION

Hazards or unsafe practices that may result in severe personal injury and/or property
damage.

NOTE

Useful information that helps users understand or benefit from the refrigerator.

These warning signs are here to prevent injury to you and others.
Please follow them carefully.
After reading this section, keep it in a safe place for future reference.

State of California Proposition 65 Warning (US only)

WARNING : This product contains chemicals known to the State of California to cause
cancer and birth defects or other reproductive harm.

Safety Information

Severe warning signs for transportation and site

WARNING

• When transporting and installing the appliance,care should be taken to ensure that no
parts of the refrigerating circuit are damaged.

- Refrigerant leaking from the pipe work could ignite or cause an eye injury. If a leak

is detected, avoid any naked flames or potential sources of ignition and air the room
in which the appliance is standing for several minutes.

- This appliance contains a small amount of isobutane refrigerant (R-600a), a natural

gas with high environmental compatibility that is, however, also flammable. When
transporting and installing the appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.

English 7

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 7 2017-03-20  5:36:16

Safety Information

Critical installation warnings

WARNING

• Do not install the refrigerator in a damp location or place where it may come in contact
with water.

- Deteriorated insulation on electrical parts may cause an electric shock or fire.

• Do not place this refrigerator in direct sunlight or expose it to the heat from stoves,
room heaters, or other appliances.

• Do not plug several appliances into the same multiple power strip. The refrigerator

Safety Information

should always be plugged into its own individual electrical outlet which has a voltage
rating that matches the voltage listed on the refrigerator’s rating plate.

- This provides the best performance and also prevents overloading of house wiring

circuits, which could overheat the wires and cause a fire hazard.

• If the wall socket is loose, do not insert the power plug.

- There is a risk of electric shock of fire.

• Do not use a power cord that has cracks or abrasion damage along its length or at
either end.

• Do not bend the power cord excessively or place heavy objects on it.

• Do not pull or excessively bend the power cord.

• Do not twist or tie the power cord.

• Do not hook the power cord over a metal object, place a heavy object on the power
cord, insert the power cord between objects, or push the power cord into the space
behind the appliance.

• Never unplug your refrigerator by pulling on the power cord. Always grip the plug
firmly and pull straight out from the outlet.

- Damage to the cord may cause a short-circuit, fire, and/or electric shock.

• Do not store explosive substances such as aerosol cans with a flammable propellant in
this appliance.

• Do not install this appliance near a heater or flammable material.

• Do not install this appliance in a location where gas may leak.

- This may result in an electric shock or fire.

• This refrigerator must be properly located and installed in accordance with the
instructions in this manual before you use it.

• Connect the power plug in the proper position with the cord hanging down.

- If you connect the power plug upside down, the wire can get cut off and cause a fire

or electric shock.

• Make sure that the power plug is not crushed or damaged by the back of the
refrigerator.

English8

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 8 2017-03-20  5:36:16

• Keep the packing materials out of reach of children.

- There is a risk of death from suffocation if a child puts the packing materials on his
or her head.

• The appliance must be positioned so that the plug is accessible after installation.

- Failing to do so may result in an electric shock or fire due to electric leakage.

• Do not install this appliance in a humid, oily or dusty location, or in a location exposed
to direct sunlight or to water (rain drops).

- Deteriorated insulation on electrical parts may cause an electric shock or fire.

• If large amounts of dust or water enter the refrigerator, turn off the power switch and
contact your Dacor service center.

- Otherwise there is a risk of fire.

• You need to remove all the protective plastic film before you initially plug the product
in.

• Children should be supervised to ensure that they do not play with the snap rings used
for door adjustment or the water tube clips.

- There is risk of death by suffocation if a child swallows a snap ring or water tube

clip. Keep the snap rings and water tube clips out of children’s reach.

• The refrigerator must be safely grounded.

- Always make sure that you have grounded the refrigerator before attempting to

investigate or repair any part of the appliance. Power leakages can cause severe
electric shock.

• Never use gas pipes, telephone lines, or other potential lightning attractors as an
electrical ground.

- You must ground the refrigerator to prevent any power leakages or electric shocks

caused by current leakage from the refrigerator.

- This may result in an electric shock, fire, explosion, or problems with the product.

- Improper use of the grounding plug can result in a risk of electric shock. If it is

necessary to use an extension cord, use only a 3-wire extension cord that has a
3-blade grounding plug and a 3-slot receptacle that will accept the plug on the
appliance. The marked rating of the extension cord should be AC 115-120 V, 10
A, or more. If a grounding adapter is used, make sure the receptacle box is fully
grounded.

• Plug the power plug into the wall socket firmly. Do not use a damaged power plug,
damaged power cord, or loose wall socket.

- This may result in an electric shock or fire.

• If the power cord is damaged, have it replaced immediately by the manufacturer or
one of its service agents.

Safety Information

English 9

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 9 2017-03-20  5:36:16

Safety Information

• Only a qualified technician or service company should be allowed to change the fuse in
the refrigerator.

- Failing to do so may result in an electric shock or personal injury.

Installation cautions

CAUTION

• Allow sufficient space around the refrigerator and install it on a flat surface.

Safety Information

- Keep the ventilation space in the appliance enclosure or mounting structure clear of

obstructions.

• After you have installed the refrigerator and turned it on, allow the appliance to stand
for 2 hours before loading it with food.

• It is strongly recommended you have a qualified technician or service company install
the refrigerator.

- Failing to do so may result in an electric shock, fire, explosion, problems with the

product, or injury.

• Overloading one door may make the refrigerator fall, causing physical injury.

English10

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 10 2017-03-20  5:36:16

Critical usage warnings

WARNING

• Do not insert the power plug into a wall socket with wet hands.

- This may result in an electric shock.

• Do not store articles on the top of the appliance.

- When you open or close the door, the articles may fall and cause personal injury
and/or material damage.

• Do not insert hands, feet or metal objects (such as chopsticks, etc.) into the bottom or
the back of the refrigerator.

- This may result in an electric shock or injury.

- Any sharp edges may cause a personal injury.

• Do not put a container filled with water on the refrigerator.

- If spilled, there is a risk of fire or electric shock.

• Do not keep volatile or flammable objects or substances (benzene, thinner, propane
gas, alcohol, ether, LP gas, and other such products) in the refrigerator.

- This refrigerator is for storing food only.

- This may result in fire or explosion.

• Children should be supervised to ensure that they do not play with the appliance.

- Keep fingers out of “pinch point” areas. Clearances between the doors and cabinet

are necessarily small. Be careful when you open the doors if children are in the area.

• Do not let children hang on the door or door bins. A serious injury may occur.

• Do not let children go inside the refrigerator. They could become trapped.

• Do not insert your hands into the area under the appliance.

- Any sharp edges may cause personal injury.

• Do not store pharmaceutical products, scientific materials, or temperature sensitive
products in the refrigerator.

- Products that require strict temperature controls must not be stored in the

refrigerator.

• Do not place or use electrical appliances inside the refrigerator/freezer, unless they are
of a type recommended by the manufacturer.

• If you smell smoke, turn off the power switch immediately, and then contact your
Dacor service center.

• If large amounts of dust or water enter the refrigerator, disconnect the power plug and
contact your Dacor service center.

- Otherwise there is a risk of fire.

• Do not let children step on a drawer.

- The drawer may break and cause them to slip.

Safety Information

English 11

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 11 2017-03-20  5:36:16

Safety Information

• Do not leave the doors of the refrigerator open while the refrigerator is unattended
and do not let children enter the refrigerator.

• Do not allow babies or children go into a drawer.

- It can cause death from suffocation by entrapment or personal injury.

• Do not overfill the refrigerator with food.

- When you open the door, an item may fall out and cause personal injury or material

damage.

• Do not spray volatile material such as insecticide onto the surface of the appliance.

- As well as being harmful to humans, it may also result in an electric shock, fire, or

Safety Information

problems with the product.

• Never put fingers or any objects into the water dispenser outlet, ice chute, or ice maker
bucket.

- It may cause a personal injury or material damage.

• Do not use or place any substances sensitive to temperature such as flammable sprays,
flammable objects, dry ice, medicine, or chemicals near or inside the refrigerator.

• Do not use a hair dryer to dry the inside of the refrigerator. Do not place a lighted
candle in the refrigerator to remove bad odors.

- This may result in an electric shock or fire.

• Fill the water tank with potable water only (tap water, mineral water, or purified
water).

- Do not fill the tank with tea, juice, or a sports drink. They can damage the

refrigerator.

• Do not use mechanical devices or any other means to accelerate the defrosting process,
other than those recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Do not put a fridge shelf into the refrigerator upside down. The shelf stopper will not
work.

- The glass shelf could fall and cause personal injury.

• If a gas leak is detected, avoid any naked flames or potential sources of ignition, and
air the room in which the appliance is standing for several minutes.

- Do not touch the appliance or power cord.

- Do not use a ventilating fan.

- A spark may result in an explosion or fire.

• Use only the LED Lamps provided by the manufacturer or its service agents.

• Bottles should be stored tightly together so that they do not fall over or out.

• This product is intended only for the storage of food in a domestic environment.

• Do not attempt to repair, disassemble, or modify the refrigerator yourself.

- Unauthorized modifications can cause safety problems. To reverse an unauthorized

modification, we will charge the full cost of parts and labor.

English12

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 12 2017-03-20  5:36:16

• Do not use any fuse (such as cooper, steel wire, etc.) other than a standard fuse.

• If your refrigerator needs to be repaired or reinstalled, contact your nearest service
center.

- Failing to do so may result in an electric shock, fire, problems with the product, or

injury.

• If the interior or exterior LED lamp has gone out, contact your nearest Dacor service
center.

• If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately
and contact a Dacor service center.

- Failing to do so may result in an electric or fire hazards.

• Pull the power plug out of the socket before changing the interior lamps of the
refrigerator.

- Otherwise, there is a risk of electric shock.

• If you experience difficulty changing a non-LED light, contact a Dacor service center.

• If the product is equipped with LED lamps, do not disassemble the Lamp Covers and
LED lamps yourself.

- Contact a Dacor service center.

• Plug the power plug into the wall socket firmly.

• Do not use a damaged power plug, damaged power cord, or loose wall socket.

- This may result in an electric shock or fire.

• Do not expose the interior accessories, such as door bins, drawers, and shelves to
direct sunlight for long.

Safety Information

English 13

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 13 2017-03-20  5:36:16

Safety Information

Usage cautions

CAUTION

• To get the best performance from the product:

- Do not place food too close to the vents at the rear of the refrigerator as this can
obstruct free air circulation in the refrigerator compartment.

- Wrap food up properly or place it in airtight containers before putting it into the
refrigerator.

• Service Warranty and Modification.

Safety Information

- Any changes or modifications performed by a 3rd party on this finished appliance
are not covered under Dacor warranty service, nor is Dacor responsible for safety
issues that result from 3rd party modifications.

• Do not block the air vents inside the refrigerator.

- If the air vents are blocked, especially with a plastic bag, the refrigerator can be
over cooled.

• If the refrigerator is disconnected from the power supply, you should wait for at least
five minutes before plugging it back in.

• If large amounts of water enter the refrigerator, turn off the power switch and contact
a Dacor service center.

• Do not strike or apply excessive force to any glass surface.

- Broken glass may result in a personal injury and/or property damage.

• Fill the water tank and ice cube trays with potable water only (tap water, mineral
water, or purified water).

- Do not fill the tank with tea, juice, or a sports drink. They can damage the

refrigerator.

• If the refrigerator is flooded, shut off the power to the refrigerator and contact your
nearest Dacor service center.

- There is a risk of electric shock or fire.

English14

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 14 2017-03-20  5:36:16

Cleaning cautions

CAUTION

• Do not spray water directly on the inside or outside the refrigerator.

- There is a risk of fire or electric shock.

• Do not use a hair dryer to dry the inside of the refrigerator.

• Do not place a lighted candle in the refrigerator to remove bad odors.

- This may result in an electric shock or fire.

• Do not spray cleaning products directly on the display.

- Printed letters on the display may come off.

• If any foreign substance such as water has entered the appliance, unplug the power
plug and contact your nearest service center.

- Failing to do so may result in an electric shock or fire.

• Use a clean, dry cloth to remove any foreign matter or dust from the power plug
blades. Do not use a wet or damp cloth when cleaning the plug.

- Otherwise, there is a risk of fire or electric shock.

• Do not clean the appliance by spraying water directly onto it.

• Do not use benzene, thinner, or Clorox (bleach) to clean the refrigerator.

- They may damage the surface of the appliance and may cause a fire.

• Never put fingers or any objects into the dispenser outlet.

- This can cause a personal injury or material damage.

• Before cleaning or performing maintenance, unplug the appliance from the wall socket.

- Failing to do so may result in an electric shock or fire.

Safety Information

English 15

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 15 2017-03-20  5:36:16

Safety Information

Critical disposal warnings

WARNING

• DANGER : Risk of child entrapment. Before you throw away your old refrigerator or
freezer:

- Take off the doors and door latch.

- Leave the shelves in place so that children cannot easily climb inside.

- Children trapped inside a refrigerator can hurt themselves or suffocate to death.

• Please dispose of the packaging material from this product in an environmentally

Safety Information

friendly manner.

• Ensure that none of the pipes on the back of the refrigerator are damaged prior to
disposal.

• R-600a is used as a refrigerant. This product contains flammable gas (Refrigerant
R-600a), contact your local authority in regard to safe disposal of this product.

• When disposing of this refrigerator, remove the door/door seals and door latch so that
small children or animals cannot become trapped inside. Children should be supervised
to ensure that they do not play with the appliance.

- If trapped inside, the child could be injured or suffocate to death.

• Cyclopentane is used in the insulation. The gases in the insulation material require
a special disposal procedure. Please contact your local authorities in regard to the
environmentally safe disposal of this product.

• Keep all packaging materials well out of the reach of children, as packaging materials
can be dangerous to children.

- If a child places a bag over his or her head, the child could suffocate.

English16

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 16 2017-03-20  5:36:16

What’s included

02

01

05

06

08

03

07

04

Inside Parts, Storage, and Shelving

01 Power switch, Auto Door Open switch
02 Shelves
03 Door bins
04 Camera
05 Water dispenser
06 FreshZone
07 Control panel
08 Water filter (cover)

What’s included

English 17

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 17 2017-03-20  5:36:16

What’s included

Switch box

What’s included

• Use a flat head screwdriver to open the
switch box cover.

• The black one is the Power switch while
the Auto Door Open switch is red next
to it.

• Close the switch box cover.

English18

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 18 2017-03-20  5:36:17

Operations

03 05

04 06 0701 0209

10

10

10

0908

Control panel

01 Fridge / Power Cool 02 FreshZone

03 Deodorizer Reset 04 Filter Reset

05 Override 06 Door Alarm / °C  °F

07 Control Lock 08 Network connection

09 Sabbath mode 10 Cooling off

NOTE

• When you change the temperature on the panel, the panel displays the actual
temperature inside the refrigerator until the temperature matches the temperature you
set. Then, the panel displays the new set temperature. Note that it will take time for the
refrigerator to reach the new temperature. This is normal. During this time, you need
not set the temperature again.

• If no button is input for 10 seconds after Control Lock is deactivated, the display will
turn off except for the Control Lock button. To turn the display on, press Control Lock
again.

• If the control panel moisture or liquid on its surface, it may fail. Wipe the moisture or
liquid using a dry cloth, and then try again.

Operations

English 19

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 19 2017-03-20  5:36:17

Operations

01 Fridge / Power Cool (3 sec)

Fridge

Power Cool

Operations

The Fridge button can be used to set the fridge temperature, or to
activate/deactivate Power Cool.

You can manually adjust the cooling temperature for the fridge.
The temperature indicator informs you of the currently set or selected

temperature. Keep pressing Fridge to select a desired temperature
between 34 °F (1 °C) and 44 °F (7 °C).

Power Cool speeds up the cooling process at maximum fan speed. The
fridge keeps running at full speed for several hours and then returns
to the previous temperature.

• To activate Power Cool, press and hold Fridge for 3 seconds. The
corresponding indicator (
speed up the cooling process for you.

• To deactivate Power Cool, press and hold Fridge again for
3 seconds. The fridge returns to the previous temperature setting.

NOTE

Using Power Cool increases power consumption. Make sure you turn it
off and return to the previous temperature if you don’t intend to use it.

) lights up, and the refrigerator will

02 FreshZone

The FreshZone is a full-width drawer featuring temperature control. It has a temperature
sensor that adjusts the amount of cold air allowed into the zone.

• Press FreshZone repeatedly to select a desired mode. By default, Cheese is selected.

• The refrigerator adjusts the temperature in the FreshZone according to the selected
mode.

Mode Description Examples

Cheese

Cold Drinks

Chill/Meat

Select this to keep food fresh for a longer time.
The temperature of the FreshZone will be kept

around 37 °F (3 °C).
Select this to keep drinks cold and refreshing.
The temperature of the FreshZone will be kept

around 33 °F (1 °C).
Select this to keep meat or fish fresh for a longer

time.
The temperature of the FreshZone will be kept

around 29 °F (-1 °C).

Pineapple, lemon,
biscuits, potatoes,
cheese

Bottled water,
juice, soft drinks,
beer

Steak, cold cut,
bacon, chili dog

English20

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 20 2017-03-20  5:36:17

CAUTION

• Do not use the FreshZone for storing fruit or leafy vegetables. The food items may
suffer cold-temperature damage.

• Do not store glass bottles in the FreshZone in Chill/Meat mode. They may break and
cause physical injury.

03 Deodorizer Reset (3 sec)

After about 18 months of using the original deodorizer filter, the Filter

Deodorizer
Reset

04 Filter Reset (3 sec)

Filter Reset

indicator blinks red to remind you that the filter needs to be replaced.
If this happens, replace the filter, and press and hold Deodorizer Reset
for 3 seconds. The filter lifecycle will be reset and the Filter indicator
turns off.

After about 6 months of using the original water filter (which typically
amounts to about 300 gallons (1136 liters) of water), the Filter
indicator blinks red to remind you that the filter needs to be replaced.

When this happens, replace the filter, and then press and hold Filter
Reset for 3 seconds. This resets the filter lifecycle detector and turns
off the Filter indicator.

NOTE

• Some areas have relatively large amounts of lime in their water.
This may reduce the lifecycle of the filter. In these areas, you will
have to replace the water filter more often than specified above.

• If water is not dispensing properly, the water filter is most likely
clogged. Even if the Filter indicator is not blinking, replace the
water filter.

Operations

05 Override (3 sec)

Override

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 21 2017-03-20  5:36:17

The Override function activates/deactivates Smart Grid.
Press Override for 3 seconds to set the Override function on or off.

English 21

Operations

06 Door Alarm / °C  °F (3 sec)

Door Alarm

°C  °F

07 Control Lock (3 sec)

Control Lock

Operations

Device
authentication

You can enable or disable the door alarm by pressing Door Alarm.
When Door Alarm is enabled and a door is left open for more than 2
minutes, the alarm will sound and the alarm indicator will blink. The
Door Alarm function is enabled by factory default.

You can use the Door Alarm button to switch the temperature scale
between Celsius and Fahrenheit.

To switch the temperature scale, press and hold Door Alarm for
3 seconds.

To prevent accidental setting changes, press and hold Control Lock for
3 seconds. Main panel will be disabled and the Lock indicator (
turn on.

If you press and hold the button again for more than 3 seconds,
Control Lock will be deactivated. However, Control Lock will be
reactivated if no button is input for the next 1 minute.

To authenticate your device, press and hold Control Lock for
5 seconds. A chime sounds with a message of ‘on’ on the temperature
display for 5 seconds.

Authorized devices can be used with Samsung Smart TV apps where
the privacy information on the refrigerator can be shared to the TV.
Availability of this function depends on the device model.

) will

English22

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 22 2017-03-20  5:36:17

08 Network connection

You can control and monitor your refrigerator through the Dacor iQ Kitchen app. For more
information, see the Dacor iQ Kitchen section.

NOTE

• Recommended encryption systems include WPA/TKIP and WPA2/AES. Any newer or
unstandardized Wi-Fi authentication protocols are not supported.

• Wireless networks may be affected by the surrounding wireless communication
environment.

• If your Internet service provider has registered the MAC address of your PC or modem
for identification, your Dacor Smart Refrigerator may fail to connect to the Internet. If
this happens, contact your Internet service provider for technical assistance.

• The firewall settings of your network system may prevent your Dacor Smart
Refrigerator from accessing the Internet. Contact your Internet service provider for
technical assistance. If this symptom continues, contact a local Dacor service center or
retailer.

• To configure the wireless access point (AP) settings, see the user manual of the AP.

• Dacor Smart Refrigerators support both Wi-Fi 2.4 GHz with IEEE 802.11 b/g/n and
Soft-AP protocols (IEEE 802.11 n is recommended).

• Unauthorized Wi-Fi wireless routers may fail to connect to applicable Dacor Smart
Refrigerators.

Operations

09 Sabbath mode

The Sabbath mode stays active for 85 hours once it is activated. After that, it will be
deactivated automatically.

• To activate, press and hold Fridge and Door Alarm simultaneously for 5 seconds
to enter Sabbath mode. Then the refrigerator operates in Sabbath mode where the
buttons, the display, and the room lamps are all under control.

• To deactivate, press and hold the buttons again for 5 seconds to exit Sabbath mode.

NOTE

• If the Control Lock indicator turns on, you must first deactivate Control Lock.

• Even after the refrigerator powers off and restarts, the Sabbath mode remains active.
To exit, you must deactivate it first.

• If two refrigerator units are installed in pairs, you must set or change the settings of
Sabbath mode for each refrigerator respectively.

English 23

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 23 2017-03-20  5:36:17

Operations

10 Cooling Off

Cooling Off mode (also called Shop mode) is designed for use by retailers when they are
displaying refrigerators on a retail floor.

In Cooling Off mode, the fan motor and lights operate normally, but the compressors do
not run so the refrigerator does not get cold.

• To enter Cooling Off mode, press and hold Deodorizer Reset, Filter Reset, and Override
simultaneously for 5 seconds. The fridge chime sounds and the temperature display
shows “oF”.

• To exit Cooling Off mode, press and hold Deodorizer Reset, Filter Reset, and Override
simultaneously for 5 seconds again. The fridge chime sounds and the temperature
display shows the current temperature.

NOTE

If the Control Lock indicator turns on, you must first deactivate Control Lock.

Operations

English24

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 24 2017-03-20  5:36:18

Dacor iQ Kitchen

Installation

Visit the Google Play Store, Galaxy Apps, or Apple App Store and search for “Dacor iQ
Kitchen”. Download and install the Dacor iQ Kitchen app to your smart device.

NOTE

• The Dacor iQ Kitchen app is designed for Android 4.0 (ICS) or higher, or iOS 8.0 or
higher.

• For improved performance, the Dacor iQ Kitchen app is subject to change without
notice, or discontinued support according to the manufacturer’s policy.

Samsung account

You are required to register your Samsung account to use the app. If you don’t have a
Samsung account, follow the app’s onscreen instructions to create a free Samsung account.

Getting started

1. Run the Dacor iQ Kitchen app and log in with your Samsung account. iPhone users are
required to provide the login information each time they access the app.

2. Select Add Device and then tap Refrigerator.

3. Follow the onscreen instructions to provide the necessary information about the

router, and then tap Next.

4. Press and hold Fridge for more than 5 seconds until the “AP” message appears on the
fridge display. Your refrigerator will be registered with the app.

5. When device registration is complete, the refrigerator icon will appear on the Dacor iQ
Kitchen app.

6. Tap the refrigerator icon to open the refrigerator page.

7. When a network connection is established, the Wi-Fi icon lights up on your refrigerator.

Operations

Refrigerator app

Integrated control

You can monitor and control your refrigerator at home and on the go.

• Tap the refrigerator icon in the Dacor iQ Kitchen to open the refrigerator page.

• Check the operation status or notifications related to your refrigerator, and change
options or settings if necessary.

NOTE

Some options or settings of the refrigerator may not be available for remote control.

English 25

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 25 2017-03-20  5:36:18

Operations

Category Item Description

Monitoring

Functions Power Cool

Alarms

Operations

Remote View

Shopping List

Fridge temperature

FreshZone settings Displays the settings of the FreshZone.
Self Check Detects abnormal operations of the refrigerator.

Energy monitoring

Abnormally high
temperature

Door opening

Deodorizer filter
replacement
(applicable models only)

Water filter
replacement

Displays the current temperature setting of the
fridge.

Checks the accumulated power consumption of
the refrigerator for the last 180 days.

You can turn Power Cool on or off, and check
the current settings.

This alarm is triggered when the fridge has
abnormally high temperatures.

This alarm is triggered if the fridge is left open
for a specific time.

This alarm reminds you that the deodorizer
filter must be replaced.

This alarm reminds you that the water filter
must be replaced.

You can check the inner view of the refrigerator,
and use different labels to register item-specific
storage periods and keep track of them for
food-management purposes.

You can create and edit a shopping list to your
needs.

English26

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 26 2017-03-20  5:36:18

SMART GRID Function (Demand Response)

When the refrigerator operates in SMART GRID (Demand Response) mode, the Energy
Management Refrigerator function can control energy usage or delay the operation of
some functions to save money when energy prices or demand are the highest.

NOTE

• You can deactivate the SMART GRID (Demand Response) function at any time using the
Override On/Off function.)

• To use the SMART GRID (Demand Response) function, you need a separate contract with
your electric utility company.

In addition, to use the Smart Grid (Demand Response) function, you must register for the
service with your electric company. The company must have an EMS (Energy Management
System) that supports SEP (Smart Energy profile).

Using the SMART GRID (Demand Response) Function

This feature monitors energy prices and demand information from your utility company
and sends notifications to the refrigerator to run high energy consuming tasks during off­peak times when electricity costs and demand are lower.

If the refrigerator receives a control signal from the utility company, the refrigerator will
display the DAL (L3) ~ TALR (L4) levels on the refrigerator display and control the power
consumption according to the level.

[Exception condition] The DAL and TALR control signals from a utility company work as
long as product performance is maintained.

If the refrigerator receives the SMART GRID (Demand Response) signal (DAL or TALR),
the refrigerator will operate in Delay Appliance Load (Display: Turn on “DAL” icon) or
Temporary Appliance Load Reduction (Display: Turn on “TALR” icon) mode.

• Delay Appliance Load (L3): The refrigerator responds to a DAL signal by providing a
moderate load reduction for the duration of the delay period. This function controls
functions that consume a lot of energy such as adjusting the Cooling system, running
the defrost cycle, and making ice.

- When the refrigerator operates in DAL (L3) mode, turn on the “DAL” icon on the

refrigerator display.

- DAL mode is automatically deactivated after it lasts for the amount of time

stipulated by the DAL signal (max. 4.5 hours) or when the Override key is pressed.

Operations

English 27

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 27 2017-03-20  5:36:18

Operations

• Temporary Appliance Load Reduction (L4): The refrigerator responds to a TALR signal

To check the MAC address

1. In this mode, the MAC address appears on the temperature panel sequentially for

2. For example, if the MAC address is “11-22-33-44-55-66”, the temperature panel

Operations

by aggressively reducing the load for a short time period. This function reduces energy
consumption by stopping the compressor and controlling the functions that consume a
lot of energy such as the defrost cycle and making ice.

- When the refrigerator operates in TALR (L4) mode, turn on the “TALR” icon on the
refrigerator display.

- TALR (L4) mode is automatically deactivated after it lasts for the received duration
(max. 15 minutes), or when the Override key is pressed. The mode is immediately
deactivated and the refrigerator returns to the normal state when the door is
opened or closed, or the dispenser is used.

1 minute.
Press and hold both Fridge and Filter Reset for 6 seconds. The temperature display
blinks. Then, press Control Lock to display the MAC address. The fridge beeps.

displays the address for 1 minute in this sequence: “--”  “11”  “22”  “33”  “44” 
“55”  “66”  “--”.
After the 1 minute, the MAC address disappears and the temperature panel returns to
the normal state.

NOTE

The temperature panel displays “-- / --” for an unknown MAC address or if a Wi-Fi
connection is not established or is lost.

Override Mode

When you want the refrigerator to ignore the SMART GRID (Demand Response) signal
from the utility company, you can activate OVERRIDE mode.

When you activate OVERRIDE mode, the refrigerator ignores the SMART GRID (Demand
Response) signal and is not controlled by the utility company.

Activating and deactivating Override mode

1. Press and hold Override for 3 seconds.

2. A chime sounds with a message of ‘Or’ on the temperature display for 5 seconds. The

Override indicator (

3. If the refrigerator receives a SMART GRID (Demand Response) signal from the utility
company, `Or’ is displayed in the fridge temperature display.

4. To deactivate OVERRIDE mode, press and hold Override for 3 seconds.

5. A chime sounds with a message of ‘Or’ on the temperature display for 5 seconds. The

Override indicator (

) turns on.

) turns off.

English28

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 28 2017-03-20  5:36:18

NOTE

• Alternatively, you can activate or deactivate OVERRIDE mode using the Dacor iQ
Kitchen app and the Energy Management function. See the next page.

Using the Energy Management Function

The Energy Management function enables you to control and monitor your Energy
Management refrigerator using the Dacor iQ Kitchen app for your convenience.

NOTE

• To use the Energy Management refrigerator functions, you have to install the
corresponding app first.

1. Operational Status, User Settings & Messages

- You can view the fridge temperature settings.

- You can receive an alarm when the fridge door is open for 2 minutes.

- You can check the DR and Override status.

2. Remote Management

- Power Cool Setting: You can remotely activate the Power Cool function.

3. Energy Consumption Reporting

- Shows the accumulated power consumption. Power consumption data is updated

every 10 minutes.

NOTE

The energy consumption report may differ from the power consumption specifications of
the product depending on the operating environment and the stored food.

4. Delay Defrost Capability

- The Delay Defrost Capability function saves energy by delaying the defrost

operation to a time specified by the user. You can configure the time. and this
function will save energy during the specified period in a 24 hour cycle. If the
time is not set, the function works with the default time settings. The default time
settings are below:

- 6 am to 10 am: 1st. November ~ 30th. April

- 3 pm to 7 pm: 1st. May ~ 31th. October

Operations

To change the time setting for the Delay Defrost Capability

You can change the time setting for the Delay Defrost Capability on the app.

English 29

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 29 2017-03-20  5:36:18

Operations

Provision for Open Access to the Connected Product Requirements

1. SGIP Open Standards (Smart Energy Profile 2.0 - http://www.csep.org/)

- Energy Consumption Reporting

- Demand Response

2. OPEN API

- Operational Status, User Settings & Messages

- ICE Maker Status: GET /devices/0/Fridge/iceMaker

- Door Open Alarm: GET /devices/0/Door/<<id>>/openState

- DR Status: GET /devices/0/drlc

- Delay Defrost Capability

- Set Schedule of the Defrost Delay: PUT /devices/0/fridge/<<id>>/DefrostReservation

- Get Schedule of the Defrost Delay: GET /devices/0/fridge/<<id>>/DefrostReservation

- Delete Schedule of the Defrost Delay: DELETE /devices/0/fridge/<<id>>/
DefrostReservation

- Defrost Delay On/OFF: PUT /devices/0/Fridge/delayDefrost

Operations

English30

Dacor_BRR9000M_REF_DA68-03607B-02_EN.indd 30 2017-03-20  5:36:18
