DèLonghi ESS 601 User Operating Instructions Manual
ESS 601
ceramic cooker
Before operating this cooker,
please read these instructions carefully
Users Operating Instructions
2
Dear Customer
Thank you for choosing one of our appliances which has been carefully designed and
built by our specialist staff and thoroughly tested to satisfy your cooking requirement.
We suggest that you read this Instruction Booklet so that you will understand fully how
to operate the appliances.
Please keep the booklet handy. You may wish to refer to it at a later date.
De Longhi
Contents
Models: ESS 601 W, ESS 601
Page Number
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Stability bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Levelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Features and technical data
- Cooking zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
- Fan oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
- Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
- How to use the vitroceramic hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 11
How to use the fan oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 - 15
Temperature recipe guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Do’s and do not’s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Care and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 - 21
After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3
Introduction
Congratulations on your purchase of this De Longhi ceramic cooker which has been
carefully designed and produced to give you many years of satisfactory use.
Before using this appliance it is essential that the following instructions are carefully read and
fully understood.
We would emphasise that the installation section must be fully complied with for your safety
to ensure that you obtain the maximum benefits from your appliance.
Fig. 1
Identification
label
When you open the oven
door the indentification
label is at the bottom right
hand side.
This cooker has been designed, constructed and marketed in compliance with:
- safety requirements of EEC Directive “Low voltage” 73/23;
- protection requirements of EEC Directive “EMC” 89/336;
- requirements of EEC Directive 93/68.
4
Installation
Electrical requirements
The appliance must be connected to the mains checking that the voltage corresponds
to the value given in the rating plate and that the electrical cable sections can withstand
the load specified on the plate.
The appliance must be connected directly to the mains placing an omnipolar switch
with minimum opening between the contacts of 3 mm between the appliance and the
mains.
The power supply cable must not touch the hot parts and must be positioned so that it
does not exceed 75°C at any point.
Once the appliance has been installed, the switch or socket must always be accessible.
If the power supply cable is damaged it must be substituted by a suitable cable available
according to current electrical regulations.
N.B. The connection of the appliance to earth is mandatory.
If the installation requires alterations to the domestic electrical system call a qualified electrician.
The electrician should also check that the socket cable section is suitable for the power
drawn by the appliance.
Replacing the power cord must be done by a qualified electrician in accordance with
the instructions supplied by the manufacturer and in compliance with established
electrical regulations.
Voltage
230 Volts AC - 50 Hz
Maximum rated current : 8340 W
5
FOR THE INSTALLER
The cooker has type “X” overheating protection.
The cooker must be installed no less than 50 mm away from any side wall which exceed
the height of the cooktop;
The appliance must be housed in heat resistant units.
The walls of the units must be capable of resisting temperatures of 75 °C above
room temperature.
Do not install the appliance near inflammable materials (eg. curtains).
Fig. 2
Location
450
mm
750 mm
50 mm min.
Important
– The appliance should be installed by a qualified technician in compliance with the laws
in force in your country and in observation of the instructions supplied by the
manufacturer.
Failure to comply with this condition will render the guarantee invalid.
– Always disconnect the cooker from mains power supply before carrying out any
maintenance operations or repairs.
6
Fig. 3
Levelling
The cooker is equipped with a 4 levelling
feet which must be fitted to the base of
the cooker in the following manner:
– Place the cooker on its back as shown
in the figure 3.
– Screw the 4 leveling feet to the cooker.
– Stand the cooker and levelling it by
screwing or unscrewing the feet with a
spanner.
7
Features and technical data
Fan oven
– Inside oven dimensions
(Width x Height x Depth)
44 x 33,5 x 42 cm
– Usable oven volume
61 dm
3
Control panel (Fig. 4)
5. Front right hotplate control
knob
6. Rear right hotplate control
knob
7. Rear left hotplate control
knob
8. Front left hotplate control
knob
9. Fan oven thermostat knob
10. Fan oven switch knob
Pilot lamps:
11. Oven thermostat indicator
light
12. On/off indicator light
Fig. 4
900 mm
600 mm
600 mm
213 4
10 9 8 7 6 5
1112
Cooking zones (Fig. 4)
1. 3 circuits hotplate Ø 180 1700 W
2. 3 circuits hotplate Ø 145 1200 W
3. 3 circuits hotplate Ø 180 1700 W
4. 3 circuits hotplate Ø 145 1200 W
Attention: Detach the appliance from the mains if the ceramic hob is cracked.
8
How to use the vitroceramic hob
The ceramic surface of the hob allows a
fast transmission of heat in the vertical
direction, from the heating elements
underneath the ceramic glass to the pans
sat on it.
The heat does not spread in the horizontal
direction, so that the glass stays “cool” at
only a few centimeters from the cooking
plate.
The 4 cooking plates are shown by dark
disks on the ceramic surface.
3 circuits hotplate
Incorporating 3 heating elements you can
control and light up all together or separately by a 6 position switch.
Reaches the working temperature in a very
short time.
Fig. 5
0
6
5
4
3
2
1
Fig. 6
Model: ESS 601
Model: ESS 601 W
