ESF 461 ST
fan oven
Users Operating Instructions
Before operating this oven,
please read these instructions carefully
2
Dear Customer,
Thank you for having purchased and given your preference to our
product.
The safety precautions and recommendations within this booklet
are for your own safety and that of others. They will also provide
a means by which to make full use of the features offered by your
appliance.
Please preserve this booklet carefully. It may be useful in future,
either to yourself or to others in the event that doubts should arise
relating to its operation.
This appliance must be used only for the task it has explicitly
been designed for, that is for cooking foodstuffs. Any other form
of usage is to be considered as inappropriate and therefore dangerous.
The manufacturer declines all responsibility in the event of damage caused by improper, incorrect or illogical use of the appliance.
DECLARATION OF CECONFORMITY
– This oven has been designed to be used only for cooking. Any other use (such as
heating a room) is improper and dangerous.
– This oven has been designed, constructed, and marketed in compliance with:
- safety requirements of EEC Directive “Low voltage” 73/23
- safety requirements of EEC Directive “EMC” 89/336;
- requirements of EEC Directive 93/68.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN
ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste. It
must be taken to a special local authority differentiated waste collection centre or to a
dealer providing this service.
Disposing of a household appliance separately avoids possible negative
consequences for the environment and health deriving from inappropriate disposal and enables the constituent materials to be recovered to
obtain significant savings in energy and resources. As a reminder of
the need to dispose of household appliances separately, the product is
marked with a crossed-out wheeled dustbin.
3
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS
– After having unpacked the appliance, check to ensure that it is not damaged.
If you have any doubts, do not use it and contact the store from where you
purchased it.
– Packing materials (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.)
should not be left around within easy reach of children, as these may cause serious
injuries.
– Do not attempt to modify the technical characteristics of the appliance as it may
become dangerous to use.
– Do not carry out cleaning or maintenance operations on the appliance without having
previously disconnected it from the electric power supply.
– If you should decide not to use this appliance any longer (or decide to substitute an
older model), before disposing of it, it is recommended that it be made inoperative in
an appropriate manner in accordance to health and environmental protection regulations, ensuring in particular that all potentially hazardous parts be made harmless,
especially in relation to children who could play with old appliances.
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS FOR USE OF ELECTRICAL
APPLIANCES
Use of any electrical appliance implies the necessity to follow a series of fundamental
rules. In particular:
– Never touch the appliance with wet hands or feet;
– do not operate the appliance barefooted;
– do not allow children or disabled people to use the appliance without your supervision.
The manufacturer cannot be held responsible for any damages caused by improper,
incorrect or unreasonable use of the appliance.
USING THE OVEN FOR THE FIRST TIME
You are advised to carry out the following operations:
– Assemble the interior of the oven as described under the heading “Cleaning and main-
tenance”
– Switch the empty oven ON at maximum temperature for about two hours to eliminate
traces of grease and smell from the components.
– Let the oven cool down, switch off the electrical supply, then clean the inside of the
oven with a cloth soaked in water and neutral detergent and dry thoroughly.
4
Control panel
11
CONTROL PANEL
1. Oven thermostat knob
2. Function selector knob
3. Power on indicator lamp
4. Oven temperature indicator lamp
5. Timer (120’ cut-off)
Fig. 1.1
21 5
4 3
5
How to use the oven
22
GENERAL FEATURES
The heating and cooking in electrical hot
air ovens take place by forced convection.
The two elements which make this process take place are:
- Grill element 2000 W
- Circular element 2200 W
NOTE:
Upon first use, it is advisable to operate
the oven at the maximum temperature
(thermostat knob on the maximum position) for 60 minutes in the position
to eliminate possible traces of grease on
the heating elements.
Repeat the operation for another 15
minutes with the grill element on as
explained in the chapters GRILLING
and USE OF THE GRILL.
OPERATING PRINCIPLES
Heating and cooking in the fan oven are
obtained in the following ways:
a. by forced convection
A fan sucks in the air contained in the
oven, which circulates it through the
circular heating element and then
forced back into the oven by the fan.
Before the hot air is sucked back
again by the fan to repeat the
described cycle, it envelops the food
in the oven, provoking a complete and
rapid cooking. It is possible to cook
several dishes simultaneously.
b. by radiation
The heat is radiated by the infra red
grill element.
c. by ventilation
The food is defrosted by using the
fan only function without heat.
Attention: the oven door becomes
very hot during operation.
Keep children away.
6
THERMOSTAT KNOB (fig. 2.1)
To turn on the heating elements of the
oven, set function selector knob to the
required position and the thermostat
knob to the desired temperature.
To set the temperature, turn the thermostat control knob indicator mark to the
required temperature.
The elements will turn on or off automatically which is determined by the thermostat.
The operation of the heating elements is
signalled by a light placed on the control
panel.
Fig. 2.2Fig. 2.1
FUNCTION SELECTOR KNOB (fig. 2.2)
Rotate the knob clockwise to set the
oven to one of the following functions:
OVEN LIGHT
By turning the function selector knob to
this setting, the oven light will illuminate
in the oven cavity (15W).
The oven light will operate on all selected functions.
DEFROSTING FROZEN FOODS
Only the oven fan is on.
To be used with the thermostat knob in
the off “●” position because the other
positions have no effect.
The defrosting is done by simple ventilation without heat.
Recommended for:
To rapidly defrost frozen foods; 1 kilogram requires about one hour.
The defrosting times vary according to
the quantity and type of foods to be
defrosted.
