EZ-BT™ WICED Module

General Description

Notes

1. The values in this section were calculated for a 90% efficient DC-DC at 3V in HCI mode, and based on a Class I configurationbench-marked at Class II. Lower values
are expected for a class II configuration using an external LPO and corresponding PAconfiguration

The CYBT-X430XX-01 is a fully integrated Bluetooth Smart
Ready wireless module. The CYBT-X430XX-01 includes an
onboard crystal oscillator, passive components, flash memory,
and the Cypress CYW20706 silicon device. Refer to the

CYW20706 datasheet for additional details on the capabilities of

the silicon device used in this module.
The CYBT-X430XX-01 supports peripheral functions (ADC and

PWM), UART and USB communication, and a Bluetooth audio
interface. The CYBT-X430XX-01 includes a royalty-free BLE
stack compatible with Bluetooth 4.2 in a 12.0 × 15.5 × 1.95 mm
package.

The CYBT-343026-01 includes 512KB of onboard serial flash
memory and is designed for stand-alone opperation. The
CYBT-343029-01 has the same characterisitcs as the
CYBT-343026-01, but also include an on-board Apple
Authentication co-processor for use with Apple products such as
Homekit. The CYBT-143038-01 does not contain onboard flash,
requiring hosted control or application RAM upload operating
modes. The CYBT-143038-01 can also interface to external
flash on the host board. The CYBT-X430XX-01 utilizes an
integrated power amplifer to achieve Class I or Class II output
power capability.

The CYBT-X430XX-01 is fully qualified by Bluetooth SIG and is
targeted at applications requiring cost optimized BLE wireless
connectivity.

Module Description

n Module size: 12.00 mm × 15.50 mm × 1.95 mm

n Bluetooth LE 4.2 Smart Ready module

p QDID: WAP3026

p Declaration ID: 7922A-3026
n Certified to FCC, IC, MIC, and CE regulations

n Castelated solder pad connections for ease-of-use

n 512-KB on-module serial flash memory ( CYBT-34302X-01)

n Up to 10 GPIOs

n Temperature range: –30 °C to +85 °C

n Cortex-M3 32-bit processor

n Maximum TX output power:

p +12 dbm for Bluetooth EDR

p +9 dBm for Bluetooth Low Energy
n RX Receive Sensitivity:

p –93.5 dBm for Bluetooth Classic

p –96.5 dBm for Bluetooth Low Energy

Power Consumption

n TX average current consumption: 12.5 mA (EDR) Class-II

n RX average current consumption: 20.0 mA (EDR)

n Low power mode support

p Sleep: 120 uA

[1]

Functional Capabilities

n 10-bit auxiliary ADC with nine analog channels

n Serial Communications interface compatible with I2C slaves

n Serial Peripheral Interface (SPI) support for both master and

slave modes

n HCI interface through USB or UART

n PCM/I2S Auido interface

n 2-wire Global Coexistence Interface (GCI)

n Bluetooth wideband speech support

n Integrated peripherals such as PWM, ADC, Triac control

n Programmable output power control

n Maximum of 100 LE Connections

n Supports extended synchronous connections (eSCO), for

enhanced voice quality by allowing for retransmission of
dropped packets

Benefits

CYBT-X430XX-01 provides all necessary components required
to operate BLE and/or EDR/BR communication standards.

n Proven hardware design ready to use

n Dual-mode operatoin eliminates the need for multiple modules

n Cost optimized for applications without space constraints

n Non-volatile memory for self-sufficient operation and

Over-the-air updates ( CYBT-34302X-01 only)

n Bluetooth SIG Listed with QDID and Declaration ID

n Fully certified module eliminates the time needed for design,

development and certification processes

n WICED™ STUDIO 4.0 provides an easy-to-use integrated

design environment (IDE) to configure, develop, and program
a Bluetooth application

n Pre-programmed EZ-Serial firmware platform to allow for

easy-to-use out of the box Bluetooth connectivity

Cypress Semiconductor Corporation • 198 Champion Court • San Jose, CA 95134-1709 • 408-943-2600
Document Number: 002-19525 Rev. ** Revised May 31, 2017

PRELIMINARY

CYBT-343026-01
CYBT-343029-01
CYBT-143038-01

More Information

Cypress provides a wealth of data at www.cypress.com to help you to select the right module for your design, and to help you to
quickly and effectively integrate the module into your design.

References

n Overview: EZ-BLE/BT Module Portfolio, Module Roadmap
n EZ-BT WICED Product Overview
n CYW20706 BT Silicon Datasheet

n Knowledge Base Article

p KBA97095 - EZ-BLE™ Module Placement

p KBA213260 - RF Regulatory Certifications for

n Development Kits:

p CYBT-343026-EVAL, CYBT-343026-01 Evaluation Board

n Test and Debug Tools:

p CYSmart, Bluetooth
p CYSmart Mobile, Bluetooth

®

LE Test and Debug Tool (Windows)

®

LE Test and Debug Tool

(Android/iOS Mobile App)

CYBT-343026-01 and CYBT-143038-01 EZ-BT™ WICED
Modules

p KBA213976 - FAQ for BLE and Regulatory Certifications with

EZ-BLE modules

p KBA210802 - Queries on BLE Qualification and Declaration

Processes

Development Environments
Two Easy-To-Use Design Environments to Get You Started Quickly

Wireless Connectivity for Embedded Devices (WICED) Studio Software Development Kit (SDK)

Cypress's WICED® (Wireless Connectivity for Embedded Devices) is a full-featured platform with proven Software Development Kits
(SDKs) and turnkey hardware solutions from partners to readily enable Wi-Fi and Bluetooth® connectivity in system design.

WICED Studio is the only SDK for the Internet of Things (ioT) that combines Wi-Fi and Bluetooth into a single integrated development
environment. In addition to providing WICED APIs and an application framework designed to abstract complexity, WICED Studio also
leverages many common industry standards.

EZ-Serial™ BT Firmware Platform

Cypress’s EZ-Serial Firmware Platform provides a simple way to access the most common hardware and communication features
needed in Bluetooth applications. EZ-Serial implements an intuitive API protocol over the UART interface and exposes various status
and control signals through the module’s GPIOs, making it easy to add BLE and/or EDR/BR functionality quickly to existing designs.

Use a simple serial terminal and evaluation kit to begin development without requiring an IDE.
EZ-BT modules with non-volatile memory are pre-flashed with the EZ-Serial Firmware Platform. If you do not have EZ-Serial

pre-loaded on your module, you can download each EZ-BT module’s firmware images on the EZ-Serial webpage.

Technical Support

n Cypress Community: Whether you’re a customer, partner or a developer interested in the latest Cypress innovations, the Cypress

Developer Community offers you a place to learn, share and engage with both Cypress experts and other embedded engineers

around the world.

n Frequently Asked Questions (FAQs): Learn more about our BLE ECO System.

n Visit our support page and create a technical support case or contact a local sales representatives. If you are in the United States,

you can talk to our technical support team by calling our toll-free number: [phone]. Select option 2 at the prompt.
