PSoC® FirstTouch™ Embedded Design Starter Kit
Easy and Affordable Starter Kit to Accelerate Mixed-Signal Embedded Application Development
The Cypress PSoC FirstTouch starter kit provides a quick, easy, and affordable way for embedded customers to evaluate the integration, exibility, and real
mixed-signal programmability of PSoC mixed-signal arrays. Without writing a single line of C or Assembly code, you can experience the power of PSoC mixedsignal arrays. Right-out-of-the box you can see a single PSoC device perform several designs — Cypress CapSense™ touch sensing, temperature sensing,
light sensing, and CapSense™ proximity sensing. And with Cypress’s PSoC Express visual embedded system design tool, you can modify these designs as
you wish or even create your own applications.
ADVANTAGES - Embedded Designs Available for Use Right Out of the Box
Highly Integrated Programmable Kit Optimized for Embedded Applications
— Integrates four embedded applications in a single thumbdrive form factor
— General purpose I/O pins accessible for further evaluation and development
— Detachable multifunction expansion card enables adding PSoC functionality to existing
system boards
— USB connectivity for convenient plug and play operation
Design Functionality Applications
Controls LED color depending White goods, handsets, consumer
on a nger’s position on the electronics, computers and
CapSense touch sensing slider computer peripherals
Controls LED color and buzzer Air conditioning, alarm systems,
based on ambient temperature system and industrial fan control
variation
Controls LED intensity based Consumer electronics, PCs,
on ambient light variation monitors, mobile phones
Controls LED color based on White goods, handsets, consumer
proximity to a proximity sensor electronics, computers, and
computer peripherals
Rapid Time to Market for Embedded Applications
— Design embedded control applications in minutes
— No C or Assembly code necessary with PSoC Express design software
— Accommodates last-minute design changes
— Real mixed-signal programmability provides complete analog and digital functionality
on-chip
Visit www.cypress.com/FirstTouch
for more information.
428-2018-ND FirstTouch™ Starter Kit $37.16
C
PSoC® Mini Programming Kit
This evaluation kit allows a user to program PSoC devices via the MiniProg programming unit. A MiniEval
board is also included in the kit. The MiniEval board is programming and evaluation board which allows
socket programming of DIP devices. The MiniEval also includes LEDs and a POT for simple evaluation
and demonstration, but does not include a prototyping area. The MiniProg1 utilizes a 5-pin ISSP header to
program PSoC Devices on the MiniEval board or directly on a users target board.
CY3210-MiniProg1 Kit Includes:
• MiniProg Programming Unit • MiniEval Socket Programming and Evaluation Board • Device Samples
• Cable • Software
CY3217 Kit Includes:
• MiniProg Programming Unit • USB Cable • Software
428-1585-ND MiniProg1 Demo Board ..................................................................$71.60
428-2021-ND MiniProg Demo Board ...................................................................$30.59
PSoC® Evaluation Kit
CY3210-PSoCEval1:
The PSoC Evaluation Kit features an evaluation board and MiniProg1 Programming unit. The evaluation
board includes an LCD module, Potentiometer, LEDs and plenty of bread boarding space to meet all of your
evaluation needs. The MiniProg1 programming unit will program PSoC devices directly on the evaluation
board, or on other boards via a 5-pin header. The MiniProg1 is small and compact, and connects to the
users PC via a provided USB 2.0 Cable
Kit Includes:
• Evaluation board with LCD module • MiniProg1 Programming unit • PSoC Designer Soft ware CD
• CY8C29466-24PXI Samples • USB 2.0 Cable • Getting Started Guide
428-1584-ND Evaluation Kit for PSoC with MiniProg1 ................................................ $142.70
EZ-Color™ Evaluation Kit
CY3261A-RGB:
The CY3261A-RGB board is a preprogrammed HB LED color mix board with seven pre-set colors using the
CY8CLED16 EZ-Color HB LED Controller. The board is accompanied by a CD containing the color selector
software application, PSoC® Express 3.0, PSoC Programmer, and a suite of documents, schematics, and
rmware examples. The color selector software application can be installed on a host PC and is used to
control the EZ-Color HB LED controller using the included USB cable. The application enables you to select
colors via a CIE 1931 chart or entering coordinates.
Kit Includes:
• RGB Industrial Lighting Demo Board • Power Supply • Software • Documentation
428-1953-ND Evaluation Kit for EZ-Color ..............................................................$184.89
PSoC® Development Kit
CY3215-DK:
The PSoC Development Kit includes an In-Circuit Emulator (ICE) which consists of a base unit, USB 2.0
cable, and power supply. The base unit is connected to the host PC via the USB port. The ICE is driven by
the Debugger subsystem of PSoC Designer. This software interface allows the user to run, halt, and single
step the processor. It also allows the user to set complex event points. Event points can start and stop
the trace memory on the ICE, as well as break the program execution. In addition to the Development Kit,
different Emulation Pods are available to support the range of devices in the PSoC family. The ICE-cube also
serves as a single-site device programmer via an ISSP (In-System Serial Programming) Cable and MiniEval
board included in the kit. The MiniEval board is a programming and evaluation board that connects to the
ICE-Cube via an ISSP Cable and allows programming of DIP devices. There are also other Programming
boards available for programming other packages.
System Requirements:
• 500MHz Processor • 256MB Ram • 150MB Free Space • USB Port • Windows®, NT4.0, 2000, Me, XP
• Internet Explorer 6.0 • Adobe Acrobat Reader
Development Kit Includes:
• ICE-Cube Unit • Emulation Pod for CY8C29466-24PXI • CY8C29466-24PXI Samples • PSoC Designer
Software CD • ISSP Cable • MiniEval Socket Programming and Evaluation board • Backward com pat i bility
cable (for connecting to legacy Pods) • Power Supply European Plug Adapter • USB 2.0 Cable • Getting
Started Guide • De velopment Kit Registration form • Image Craft C-Compiler License
428-1583-ND Development Kit for PSoC .............................................................. $496.33
CapSense™ Successive Approximation
(CSA) Training Kit
CY3203A-CAPSENSE:
The CY3203A CapSense Training Kit includes software, hardware and example projects to help designers
learn how to implement PSoC® CapSense in their own design using the CY8C20x34 family. A training board
is included that is hardwired for buttons and sliders as well as LCD control and I2C communication.
Kit Includes:
• Training Board (CY8C20x34) • PSoC Designer and Example Project CD • CSA User Module • Mini
Programmer Unit • LCD Module • USB Cable
428-1924-ND Evaluation Kit for CapSense CSA ......................................................$110.42
CapSense™ Sigma-Delta
(CSD) Training Kit
CY3213A-CAPSENSE:
The CY3213A CapSense Training Kit includes software, hardware and example projects to help designers
learn how to implement PSoC® CapSense in their own design using the CY8C21x34 family. A training board
is included that is hardwired for buttons and sliders as well as LCD control and I2C communication.
Kit Includes:
• Training Board (CY8C21x34) • PSoC Designer and Example Project CD • CSD User Module • Mini
Programmer Unit • LCD Module • USB Cable
428-1925-ND Evaluation Kit for CapSense Sigma Delta ..............................................$110.42
Free shipping on orders over $200 CAD! All prices in Canadian dollars and include duty and brokerage fees.
1-800-344-4539 • ca.digikey.com • 218-681-6674 • Fax: 218-681-3380
(C091)
683
®
PSoC
The Programmable System-on-Chip (PSoC) microcontrollers integrate
a microcontroller and the analog and digital components that typically
surround it in an embedded system. Easy-to-use development tools
enable designers to select the precise peripheral functionality they
desire, including analog functions such as ampli ers, ADCs, DACs,
Analog Digital HW Digi-Key Price Each Cypress
Blocks Blocks Flash SRAM Comm Bus I/O Vcc Package Part No. 1 25 100 Part No.
1 CapSense 0 8K 512 I2C 28 2.4 ~ 5.25 32-QFN 428-1914-ND 5.08 2.73 2.19 CY8C20434-12LKXI
6 8-SOIC 428-1682-ND 2.21 1.36 1.11 CY8C21123-24SXI
4K
16 20-SSOP 428-1684-ND 2.64 1.63 1.32 CY8C21323-24PVXI
16 24-QFN 428-1685-ND 2.95 1.82 1.48 CY8C21323-24LFXI
4 4
16 20-SSOP 428-1612-ND 3.77 2.92 2.36 CY8C21334-24PVXI
28 32-QFN 428-2061-ND NEW! 4.55 3.65 2.84 CY8C21434-24LTXI
24 28-SSOP 428-1614-ND 4.07 3.17 2.45 CY8C21534-24PVXI
26 32-QFN 428-1615-ND 4.39 3.42 2.75 CY8C21634-24LFXI
C
6 8-DIP 428-1602-ND 3.66 2.20 1.84 CY8C24123A-24PXI
6 8-SOIC 428-1603-1-ND† 3.39 2.03 1.70 CY8C24123A-24SXIT
6 8-SOIC 428-1603-2-ND‡ 4057.58/2,500 CY8C24123A-24SXIT
16 20-DIP 428-1604-ND 4.57 2.74 2.29 CY8C24223A-24PXI
6 4 4K 256 I2C 16 2.4 ~ 5.25 20-SSOP 428-1605-ND 4.16 2.50 2.08 CY8C24223A-24PVXI
16 20-SOIC 428-1606-ND 4.53 2.72 2.27 CY8C24223A-24SXI
24 28-SSOP 428-1608-ND 4.78 2.87 2.39 CY8C24423A-24PVXI
24 28-SOIC 428-1609-ND 4.78 2.87 2.39 CY8C24423A-24SXI
24 32-QFN 428-1610-ND 4.12 3.17 2.58 CY8C24423A-24LFXI
6 4 16K 1K I2C, USB 50 3 ~ 5.25 56-QFN 428-1651-ND 6.82 5.31 4.27 CY8C24794-24LFXI
49 56-QFN 428-1917-ND 8.87 5.31 4.27 CY8C24894-24LFXI
6 2 16K 1K I2C, USB 56 3 ~ 5.25 100-VFBGA 428-1915-ND 11.02 6.80 5.51 CY8C24994-24BVXI
56 68-QFN 428-1916-ND 11.02 6.80 5.51 CY8C24994-24LFXI
8K 256 — 16 3 ~ 5.25 20-SSOP 428-1640-ND 7.38 5.11 4.58 CY8C26233-24PVXI
12 8
6 8-DIP 428-1593-ND 6.20 3.73 3.11 CY8C27143-24PXI
16 20-SSOP 428-1594-ND 6.70 4.03 3.36 CY8C27243-24PVXI
16 20-SOIC 428-1595-ND 6.70 4.03 3.36 CY8C27243-24SXI
12
24 28-SSOP 428-1597-ND 7.05 4.23 3.53 CY8C27443-24PVXI
24 28-SOIC 428-1598-ND 7.05 4.23 3.53 CY8C27443-24SXI
44 48-SSOP 428-1600-ND 7.48 4.49 3.74 CY8C27643-24PVXI
44 48-QFN 428-1601-ND 8.66 5.20 4.33 CY8C27643-24LFXI
24 28-DIP 428-1586-ND 10.89 6.54 5.45 CY8C29466-24PXI
24 28-SSOP 428-1587-ND 9.49 5.96 4.75 CY8C29466-24PVXI
24 28-SOIC 428-1588-ND 9.49 5.70 4.75 CY8C29466-24SXI
12 16 32K 2K I2C 40 3 ~ 5.25 44-TQFP 428-1589-ND 10.58 6.35 5.29 CY8C29566-24AXI
44 28-SSOP 428-1590-ND 9.96 5.98 4.98 CY8C29666-24PVXI
44 48-QFN 428-1591-ND 11.35 6.82 5.68 CY8C29666-24LFXI
64 100-TQFP 428-1592-ND 12.14 7.28 6.07 CY8C29866-24AXI
† Cut Tape ‡ Tape and Reel
12 16-SOIC 428-1611-ND 3.50 2.73 2.19 CY8C21234-24SXI
8K 512 I
24
16K 256 —
8
16K
(Programmable System on Chip) Microcontrollers
256
256
lters and comparators and digital functions such as timers, counters,
PWMs, SPI and UARTs.
The PSoC family’s analog features include rail-to-rail inputs,
programmable gain ampli ers and up to 14-bit ADCs with exceptionally
low noise, input leakage and voltage offset. PSoC devices include up
16
2
C
I
28
2
C
24 28-SOIC 428-1644-ND 7.67 5.31 4.76 CY8C26443-24SXI
24
I2C
16-SOIC 428-1683-ND 2.58 1.59 1.29 CY8C21223-24SXI
2.4 ~ 5.25
32-QFN 428-1613-ND 4.05 3.11 2.53 CY8C21434-24LFXI
2.4 ~ 5.25
28-SSOP 428-1643-ND 7.63 5.29 4.74 CY8C26443-24PVXI
3 ~ 5.25
28-DIP 428-1596-ND 7.32 4.40 3.67 CY8C27443-24PXI
3 ~ 5.25
to 32KB of ash memory, 2KB of SRAM, an 8x8 multiplier with 32-bit
accumulator, power and sleep monitoring circuits, and hardware I2C
USB and Capsense Technology communications.
Operating Voltage from 2.4V ~ 5.25V
Temperature Range: -40C ~ 85C
®
CapSense Express™
The CapSense Express Family, supported by PSOC Express™ Visual Embedded System Design Tool and
the CapSense Express Con guration Tool, is the quickest and easiest to use for touch sensing functionality.
Analog Digital HW Digi-Key Price Each Cypress
Blocks Blocks Flash SRAM Comm Bus I/O Vcc Package Part No. 1 25 100 Part No.
10 16-QFN 428-2046-ND 2.71 2.16 1.62 CY8C20110-LDX2I
10 16-SOIC 428-2047-5-ND 2.48 1.99 1.55 CY8C20110-SX2I
4 16-QFN 428-2048-ND 2.10 1.68 1.31 CY8C20140-LDX2I
4 16-SOIC 428-2049-5-ND 2.12 1.70 1.33 CY8C20140-SX2I
4 8-SOIC 428-2050-5-ND 2.07 1.66 1.29 CY8C20142-SX1I
1 CapSense 0 2K 512 I2C 6 2.4 ~ 5.25 16-QFN 428-2051-ND 2.21 1.77 1.38 CY8C20160-LDX2I
6 16-SOIC 428-2052-5-ND 2.23 1.79 1.39 CY8C20160-SX2I
8 16-QFN 428-2053-ND 2.32 1.86 1.45 CY8C20180-LDX2I
8 16-SOIC 428-2054-5-ND 2.35 1.88 1.46 CY8C20180-SX2I
10 16-QFN 428-2055-ND 2.57 2.06 1.60 CY8C201A0-LDX2I
10 16-SOIC 428-2056-5-ND 2.63 2.10 1.64 CY8C201A0-SX2I
The CapSense Express family supports up to ten general purpose I/Os for buttons, multi-segment sliders,
LEDs and other general purpose functions, all con gured via I2C registers.
Port Expanders
Digi-Key Price Each Cypress
Flash I/O Vcc Package Part No. 1 25 100 Part No.
3KB EEPROM 28 28-SSOP 428-2015-5-ND 3.91 3.13 2.44 CY8C9520A-24PVXI
11KB EEPROM 48 3.0 ~ 5.25 48-SSOP 428-2016-5-ND 6.99 5.59 4.35 CY8C9540A-24PVXI
27KB EEPROM 100 100-TQFP 428-2017-ND 6.56 5.25 4.09 CY8C9560A-24AXI
EZ-Color™ High-Brightness LED Controllers
Cypress’ EZ-Color family of devices offers the ideal control solution for High Brightness LED applications
requiring intelligent dimming control.
EZ-Color devices combine the power and flexibility of PSoC® (Programmable System-on-Chip); with
Cypress’ PrISM (Precise illumination signal modulation) drive technology providing lighting designers a fully
LED Analog Digi-Key Price Each Cypress Evaluation
Channels Blocks Flash SRAM Package Part No. 1 25 100 Part No. Kit
4 6 16KB 1KB 68-QFN 428-1947-ND 12.10 7.45 6.05 CY8CLED04-68LFXI
8 12 16KB 256B 48-QFN 428-1948-ND 20.16 12.41 10.09 CY8CLED08-48LFXI
8 12 16KB 256B 48-SSOP 428-1949-5-ND 20.16 12.41 10.09 CY8CLED08-48PVXI
16 12 32KB 2KB 28-SSOP 428-1950-5-ND 22.96 14.15 11.48 CY8CLED16-28PVXI
16 12 32KB 2KB 48-QFN 428-1951-ND 24.05 14.83 12.03 CY8CLED16-48LFXI
16 12 32KB 2KB 48-SSOP 428-1952-5-ND 24.05 14.83 12.03 CY8CLED16-48PVXI
®
Most SMT cutdown parts are available on a Digi-Reel ®. For Digi-Reel part number, change 1-ND to 6-ND or CT-ND to DKR-ND. See Digi-Key ® Services on page 2 for additional information.
customizable and integrated lighting solution platform.
EZ-Color devices support up to 16 independent LED channels with up to 32 bits of resolution per channel,
enabling lighting designers the exibility to choose the LED array size and color quality. EZ-Color’s virtually
limitless analog and digital customization allow for simple integration of features.
428-1953-ND
Free shipping on orders over $200 CAD! All prices in Canadian dollars and include duty and brokerage fees.
684
(C091)
1-800-344-4539 • ca.digikey.com • 218-681-6674 • Fax: 218-681-3380
PSoC
CY3210-ExpressDK:
The PSoC Express development kit provides a feature-rich hardware platform for developing and testing
designs created with PSoC Express. This kit contains a complete PSoC Express development environment
including a large, full featured development board, fan modules, proto modules, 28-DIP samples, and a
MiniProg Programmer.
Kit Includes: • Development Board • Four Fan Modules • Two Proto Modules • MiniProg Insystem
Programmer • Mini Eval PCB Evaluation Board • Power Supply • PSoC Express CD-ROM • Jumper Wire Kit
• Cables • PSoC DIP Samples
428-1636-ND PSoC Express Development Kit ........................................................ $957.94
428-1637-ND Fan Module Kit ........................................................................... $248.17
428-1638-ND Proto Module Kit ......................................................................... $124.09
®
Express Development Kit
CapSense™ Proximity Detection
Demonstration Kit
CY3235-PROXDET:
The CapSense Proximity Detection Demonstration Kit allows quick and easy demonstration of a PSoC®
CapSense-enabled device (CY8C21434) to accurately sense the proximity of a hand or nger along the
length of a wire antenna. The kit also includes the I
debugging of PSoC applications by seamlessly connecting your PC’s USB port to your application’s I2C
interface.
Kit Includes: • Proximity Detection Demo Board with Antenna • I2C to USB Debugging/Communication
Bridge • USB Cable • Software • Quick Start Guide
428-1909-ND Evaluation Kit for PSoC Proximity Detection .......................................... $91.00
2
C to USB Bridge, which allows hardware and software
PSoC® Express II Evaluation Kit
CY3210-PSOCEXPEVAL1:
The PSoC Express Evaluation Kit is an all-in-one evaluation kit for experiencing rst-hand the speed and
depth of design offerings with PSoC Express, the code-free embedded development environment.
Kit Includes: • Two PSoC Evaluation boards • MiniProg USB Programmer • Cables • Software
428-1906-ND Evaluation Kit for PSoC Express ...................................................... $120.36
428-2025-ND Evaluation Kit for PSoC Express II .................................................... $151.38
PSoC® with USB Evaluation Kit
Special features of the board include both USB and capacitive touch sense development and debugging
support. The eval uation board also includes an LCD module, Potentiometer, LEDs, an enunciator, and plenty
of bread boarding space to meet all of your evaluation needs.
The PSoCEvalUSB board features an on-chip debugger and can be connected directly to an ICE-Cube
(available in the CY3215-DK) for full-featured, in-circuit emulation and debugging.
Kit Includes: • PSoCEvalUSB Board • LCD Module • MiniProg1 programmer • USB mini cable
• Documentation and Soft ware
428-1650-ND Evaluation Kit for CY8C24794-24LFXI ................................................ $122.83
CY3202-C iMAGEcraft C-Compiler
The CY3202-C iMAGEcraft C-Compiler is fully integrated into the PSoC® Designer IDE. PSoC Designer
supports C source level debugging. In order to activate the compiler, you must enable and upgrade.
Features: • ANSI C-Compiler • Supports In-line Assembly and can Interface with Assembly Modules
• Stack-Based • 7 Basic Data Types • Assemble and Linker • Math and String Libraries • C-Interrupt
Service Routines • Librarian
428-1413-ND iMAGEcraft C-Compiler ................................................................ $208.46
PSoC® ISSP (In-System Serial
Programming) Programmer
The ISSP Programmer programs PSoC ICs with .hex les created with Cypress SemiConductor PSoC
Designer™ software. The programmer programs a PSoC chip mounted on your PCB, one at a time. It
connects to your PCB with a 5-wire cable and to your PC with a USB cable. Programming operation can be
automated by incorporating the programmer into a PC-based test system. The tester software communicates
with the programmer-control software through a command-line interface. The ISSP programmer can also be
operated manually using the supplied Windows® GUI software.
Functions: • Program • Verify • Read • Flexible Connections to Target PSoC Devices: Devices can be
inserted directly into ISSP, using an on-board 48-ZIF socket, connected via a test xture or programmed
in-system on a product circuit board.
System Requirements: • Windows®, NT, ME, 2000 or XP • CD-ROM • USB Port • 128 MB RAM
Kit Includes: • ISSP Programmer • ISSP Software CD-ROM • 6-Foot USB Cable • 2-Foot Programming
Cable • 9V Power Supply • In-System Serial Programming (ISSP) CY3207ISSP User Guide
428-1495-ND PSoC USB In-System Programmer ................................................... $439.26
PSoC® SD Card Module Evaluation Kit
CY3210-SDCARD:
The SD Card Module Evaluation Kit assesses the PSoC SD Card user module’s ability to quickly and easily
write to, read from and seamlessly integrate an SD card module into an embedded design. SD ash memory
technologies are quickly becoming the preferred solution for portable, consumer and industrial electronic
devices around the world for storing a large amount of information in a small, durable, portable form factor.
Note: The SD Card user module and the example projects for this evaluation kit require the use of a C
compiler.
Kit Includes: • CY3210-PSoCEVAL • SD Card Adapter Board • SD Memory Card • USB to SD Card
Reader • MiniProg1 • USB Cable • Power Supply • Software
428-1907-ND Evaluation Kit for PSoC SD Card ...................................................... $322.62
PIR Motion Detection Evaluation Kit
The CY3236A-PIRMOTION EVK allows you to evaluate Cypress’ PSoC® device’s ability to control a
Pyro electric Infrared (PIR) sensor to implement motion sensing applications such as automatic lighting
controls, automatic door openers, security systems, kiosk wake-up and activating wireless cameras. The
CY3236A-PIRMOTION EVK includes all of the software, hardware, example projects and documentation
you need to implement all of these PIR sensing control functions in one exible and powerful PSoC device,
the CY8C27443.
Kit Includes: • PIR Motion Sensor Board • Power Supply • Software • Design Files
428-2022-ND PIR Motion Evaluation Kit .............................................................. $160.07
PSoC® CapSense™ Kits
CY3220-FPD:
This PSoC Demonstration Kit features a discrete button demonstration board for the Cypress CapSense
solution. The board features eight CapSense buttons that control an LCD Module in a car radio con guration.
The board is built using the CY8C21534-24PVXI PSoC, the only component necessary for sensing. The
PSoC senses the presence of a nger or other capacitive element through 3mm ABS plastic.
Kit Includes: • Demonstration Board • User Guide • Documentation and Software CD • Power Supply
CY3212-CAPSENSE:
This PSoC Training Kit includes software, hardware and example projects to help designers learn how to
implement PSoC CapSense in their own design. A training board is included that is hard wired for buttons
and sliders as well as LCD control and 12C communication.
Kit Includes: • Training board • PSoC Designer and Example Project CD • CSR User Module • Mini
Programmer unit • LCD Module • USB Cable
428-1652-ND PSoC CapSense Demo Kit (CY3220-FPD) ...........................................$126.57
428-1705-ND PSoC CapSense Training Kit (CY3212-CAPSENSE) ................................$145.18
CapSense™ Express Evaluation Kits
The CapSense Express evaluation kits enable designers to replace mechanical buttons by implementing
touch sensing designs in minutes with the newest CapSense Touch Sensing Family, CapSense Express.
With Cypress’s PSoC Express™ visual embedded system design tool and CapSense Express con guration
tool, designers con gure, monitor, and tune up to 10 I/O’s for buttons, LEDs and other general purpose I/O’s
over I2C in a real time using a graphical user interface.
CY3218-CAPEXP1 Kit Includes: • CapSense Evaluation Board with CY8C20110-LDX2I • CY3240-I2USB
Bridge Board • USB Cable • Battery
CY3218-CAPEXP2 Kit Includes: • CapSense Slider Evaluation Board with CY8C201A0-LDX2I • CY3240I2USB Bridge Board • USB Cable • Battery
CY3218-CAPEXP3 Kit Includes: • CapSense Evaluation Board with CY8C20142-SX2I • CY3240-I2USB
Bridge Board • USB Cable • Battery
428-2043-ND CapSense Evaluation Board Kit (CY3218-CAPEXP1) ................................ $65.14
428-2044-ND CapSense Slider Evaluation Board Kit (CY3218-CAPEXP2) ......................... $65.14
428-2045-ND CapSense Evaluation Board Kit (CY3218-CAPEXP3) ................................ $65.14
Universal CapSense™ Controller Kit
CY3280-BK1:
Designed for easy development and debugging of any CapSense design. It includes pre-de ned control
circuitry and plug-in hardware, along with controller boards for both the CY8C20x34 and CY8C21x34 PSoC
devices. It also offers a breadboard module and a module for implementing up to ve buttons and a slider
with sample overlays to encompass a wide variety of designs.
Kit Includes: • Universal Capsense Controller Boards • CapSense Linear Slider Module • CapSense
Protyping Module • CY3240-I2USB Board • CY3210 MiniProg1 Programmer • Software
428-2033-ND Universal CapSense Controller Kit ................................................... $219.63
PSoC® I2C to USB Bridge Kit
CY3240-I2USB:
The I2C to USB Bridge is a quick and easy link from any design or application’s I2C bus to a PC via USB
for design testing, debugging and communication. The bridge is based on 1 of Cypress’ CY8C24894, which
contains 6 analog blocks supporting ADCs, DACs and lters, 4 digital blocks supporting PWMs, timers and
counters, and a Full-Speed USB 2.0 peripheral.
Kit Includes:
• I2C USB Bridge • I2C Slave Demonstration Board • USB Mini B Cable • Software CD
428-1910-ND Evaluation Kit for PSoC I2C to USB ................................................... $96.80
PSoC® I2C Port Expander Evaluation Kits
The I2C Port Expander Evaluation Kit allows you to easily assess the following value propositions of
Cypress’ I2C port expander ICs from other vendors and exibly integrates I/O expansion, PWM functions
and user EEPROM. The kit also includes the I2C to USB Bridge, which allows hardware and software
debugging of PSoC applications by seamlessly connecting your PC’s USB port to your application’s I2C
interface.
CY3242-IOX Kit Includes:
• Port Expander Demo Board using containing CY8C9520/40/60 Port Expanders • I2C to USB Bridge
• USB Cable • Documentation
CY3242-IOXLITE Kit Includes:
• I2C Port Expander Demo Board using CY8C9520 Port Expander • USB Cable • Documentation
428-1911-ND CY3242-IOX Evaluation Kit ...........................................................$800.35
428-2023-ND CY3242-IOXLITE Evaluation Kit ......................................................$160.07
C
Free shipping on orders over $200 CAD! All prices in Canadian dollars and include duty and brokerage fees.
1-800-344-4539 • ca.digikey.com • 218-681-6674 • Fax: 218-681-3380
(C091)
685
Emulation Kits and Accessories
Emulation Kits
Function: Provides Connection Between ICE-Cube and Target
Contents: 1 Flexcable, 1 Pod, 2 Pod Feet
Digi-Key Price
For Use With Part No. Each
CY8C21x23 428-1886-ND 246.92
CY8C21x23 QFN Package 428-1871-ND 246.92
CY8C21x34 428-1887-ND 246.92
CY8C21x34 QFN Package 428-1872-ND 246.92
CY8C24x23A 428-1883-ND 246.92
CY8C24x23A QFN Package 428-1868-ND 246.92
CY8C24x94 QFN Package 428-1867-ND 246.92
CY8C27xxx 428-1884-ND 246.92
CY8C27xxx QFN Package 428-1869-ND 246.92
CY8C29xxx 428-1885-ND 246.92
C
CY8C29xxx QFN Package 428-1870-ND 246.92
CY8C20334 QFN Package 428-1955-ND 286.64
CY8C20434 QFN Package 428-1957-ND 286.64
RoHS Compliant
Evaluation Pods
Function: Allows evaluation of a device family using
28-DIP connector
Digi-Key Price
Family Part No. Each
C48C20x34 428-1994-ND 152.62
C48C21x23 428-1995-ND 152.62
C58C21x34 428-1996-ND 152.62
Digi-Key Price
Family Part No. Each
CY8C24x23 428-1997-ND 152.62
CY8C24x94 428-1998-ND 152.62
CY8C27x43 428-1999-ND 152.62
CY8C29x66 428-2000-ND 152.62
Foot Kits
Function: Replacement Pod Feet Contents: 4 Pod Feet
Digi-Key Price
Package Part No. Each
8-DIP 428-1890-ND 117.87
20-DIP 428-1888-ND 135.25
28-DIP 428-1889-ND 117.87
8-SOIC 428-1894-ND 135.25
16-SOIC 428-1891-ND 135.25
20-SOIC 428-1892-ND 135.25
28-SOIC 428-1893-ND 117.87
20-SSOP 428-1895-ND 117.47
28-SSOP 428-1896-ND 117.87
48-SSOP 428-1897-ND 117.46
44-TQFP 428-1899-ND 135.25
100-TQFP 428-1898-ND 317.97
24-QFN 428-1873-ND 244.45
32-QFN 428-1874-ND 210.93
48-QFN 428-1875-ND 210.93
56-QFN 428-1876-ND 210.93
For use with the 428-1583-ND (CY3215-DK) PSoC® Development Kit
Pod Kits
Function: Replacement Pod Kit
Contents: 2 Pods
Digi-Key Price
For Use With Part No. Each
CY8C21x23 428-1904-ND 162.55
CY8C21x23 QFN Package 428-1881-ND 162.55
CY8C21x34 428-1905-ND 140.64
CY8C21x34 QFN Package 428-1882-ND 162.55
CY8C24x23A 428-1901-ND 162.55
CY8C24x94 QFN Package 428-1877-ND 162.55
CY8C27xxx 428-1902-ND 140.61
CY8C27xxx QFN Package 428-1879-ND 162.55
CY8C29xxx 428-1903-ND 162.55
CY8C29xxx QFN Package 428-1880-ND 162.55
CY8C20334 QFN Package 428-1956-ND 162.55
CY8C20434 QFN Package 428-1958-ND 162.55
Replacement Flex Cable
for CY3250 Pod Kits 428-1866-ND 124.07
RoHS Compliant
CPLDs
Cypress offers a wide range of Programmable Logic Devices From PALs with 10 macrocells and 200 gates
up to CPLDs with 3072 macrocells and 200,000 gates. Cypress also provides voltages ranging from 2.5V up
to the typical 5.0V.
The Ultra37000™ family of CMOS CPLDs provides a range of high-density pro gram mable logic solutions with
unparalleled system performance. The Ultra37000 family is designed to bring the exibility, ease of use, and
performance of the 22V10 to high-density CPLDs. The architecture is based on a number of logic blocks that
are connected by a Programmable Inter-connect Matrix (PIM). Each logic block features its own product term
array, product term allocator, and 16 macrocells. The PIM distributes signals from the logic block outputs and
Memory Option Digi-Key Price Each Cypress
Voltage Type Tpd (ns) Macrocells Gates Power I/O Package Part No. 1 25 100 Part No.
ULTRA 37000 CPLDs
6 64 2,000 Standard 69 100-TQFP 428-1722-ND 12.20 10.99 9.74 CY37064P100-125AXC
6 64 2,000 Standard 37 44-TQFP 428-1723-ND 9.93 7.95 6.71 CY37064P44-125AXC
5.0 Flash 7.5 192 5,700 Standard 125 160-TQFP 428-1724-ND 28.11 26.24 24.36 CY37192P160-125AXC
7.5 256 7,700 Standard 133 160-TQFP 428-1725-ND 40.20 37.53 34.85 CY37256P160-125AXC
6 64 200 Standard 69 100-TQFP 428-1936-ND 13.34 12.01 10.65 CY37064P100-125AXI
3.3 Flash 8.5 64 200 Standard 37 44-TQFP 428-1937-ND 9.93 7.95 6.71 CY37064VP44-100AXC
DELTA 39K ISR CPLDs
2.5 ~ 3.3 Flash 7.2 512 30K Lp 136 208-PQFP 428-1939-ND 60.98 56.92 52.85 CY39030V208-125NTXC
all input pins to the logic block inputs. All of the Ultra37000 devices are electrically erasable and In-System
Reprogrammable (ISR).
The Delta39K™ ISR™ CPLD Family based on a 0.18 µm, six-layer metal CMOS logic process, offers a wide
range of high-density solutions at unparalleled system performance. The Delta39K family is designed to
combine the high speed, predictable timing, and ease of use of CPLDs with the high densities and low power
of FPGAs. With devices ranging from 15,000 to 200,000 usable gates, the family features devices ten times
the size of previously available CPLDs. Even at these large densities, the Delta39K family is fast enough to
implement a fully synthesizable 64-bit, 66-MHz PCI core.
Delta39K/Ultra37000 ISR Programming Kit
The Delta39K/Ultra37000 ISR Programming Kit enables users to program Ultra37000, Ultra37000V,
Delta39K, and PSI CPLDs on board with our ISR Programming Software, the USBISR Programming Cable,
and a personal computer. The USBISR Programming Cable connects to a USB 1.1USB 2.0 of a PC into a
standard 10-pin male connector mounted on the user’s board. The ISR software provides an easy-to-use
Graphical User Interface that accepts JEDEC or hex les as input. The JEDEC/.hex les are used to compose
platform independent STAPL.SVF les. STAPL/SVF les contain all the information needed to program the
device. The ISR software is used to de ne how many devices are in the daisy chain and what operation is to
be done on each Cypress device. The same chain can be used with other JTAG-compliant devices. The ISR
User’s Guide describes the operation of the ISR software. The application notes included with the kit describe
all system design considerations for programming with this Programming Kit.
Features: • Supports Cypress’ Ultra37000™, Ultra37000V™, Delta39K™, and PSI™ families of products
• STAPL (chain dependent and chain independent) programming language support • SVF programming
language support • Standard JTAG programming interface • Multi-device programming • Easy to use
interface that is compatible with Windows XP™, Windows 2000™, Windows ME™, Windows98™, and
Windows NT™ • Elimination of programming insertion which improves manufacturing efficiency, ability to
program in the lab, on the manufacturing oor and at remote sites • Automatic test equipment (ATE) support
via STAPL on ATE platforms.
CY3950I Includes:
UltraISR™ Programming Cable for use with Ultra37000, Delta39K, and PSI CPLD families, ISR Programming,
ISR Application Notes, and a Delta39K/Ultra37000™ Prototype Board.
428-2019-ND ISR Programming Kit ....................................................................$127.81
FTG Programming Kits
CY3670
The CY3670 FTG programming kit provides users with a PC the ability to program Cypress EPROM FieldProgrammable Clock Generators quickly and easily. The two setup requirements are a power connection and a
serial port connection with the PC.
Features: • Supports multiple Cypress EPROM Field Programmable Clock Generators: CY2071AF, CY2291F,
CY2292F, CY2292FZ, CY2907F8, and CY2907F14 • Separate device-speci c socket adapters • Allows
quick and easy prototyping • Compact design for ease of portability • Easy to use interface: Windows
compatible • User-friendly CYClocks™ software for JEDEC le development
Kit Includes: • Programmer Unit • Serial Port Cable • AC/DC Adapter • CD containing • CyClocks Software
• CY_FTG_V2 Programmer Software • Data sheets of supported devices • Device-speci c socket adapters for
the CY2071AF and CY2292F (socket adapters for the other devices are ordered separately)
428-1457-ND FTG Programming Kit ..................................................................$477.73
428-2042-ND Socket Adapter for CY2071AF .........................................................$162.55
Free shipping on orders over $200 CAD! All prices in Canadian dollars and include duty and brokerage fees.
686
(C091)
1-800-344-4539 • ca.digikey.com • 218-681-6674 • Fax: 218-681-3380
CY3672-USB
The CY3672 programming kit enables any user with a PC the ability to program Field Programmable Clock
generators quickly and easily. The only two setup requirements are a power connection and a parallel port
connection with the PC.
Features:
• Supports Field Programmable Clock Generators: CY2077FS, CY2077FZ, CY22050F, CY22150F,
CY22381F, CY22392F, CY22393F, CY22394F, and CY22395F • Allows quick and easy prototyping
• Compact design for ease of portability • Easy to use Windows 95, 98, NT,2K, ME, XP compatible interface
• User friendly CYClocksRT™ software for JEDEC le development
Kit Includes:
• Parallel Port cable • AC/DC adapter • CD containing: CyClocksRT, CY3672 programmer interface software,
and data sheets
428-1918-ND FTG Programming Kit ................................................................... $477.73
CY7C6XXX Series Of USB Microcontrollers
Cypress offers the industry’s broadest line of USB microcontrollers, as well as a full set of development tools, supporting
cost-driven applications such as keyboards and mice, as well as high-performance applications like printers, scanners, xDSL
modems, and digital cameras. Cypress has a wide range of solutions for Low-Speed USB applications, Full-Speed USB
Applications and USB Hub Applications. Temperature range, commercial (0F ~ 70F).
The CY7C63xxx is a family of 8-bit RISC One Time Programmable (OTP) microcontrollers. In addition, the microcontroller
features 96 ~ 256 bytes of internal RAM depending on the device. The Cypress USB Controller accepts a 6MHz ceramic
resonator as its clock source. This clock signal is doubled within the chip to provide a 12MHz clock for the microprocessor.
The CY7C64013 is an 8-bit One Time Programmable microcontroller that is designed for full-speed USB applications. The
instruction set has been optimized specifically for USB operations, although the microcontrollers can be used for a variety of
non-USB embedded applications.
The CY7C647XX (EZ-USB FX1™) is a family of full-speed highly integrated, USB microcontrollers. The FX1 family integrates
the USB transceiver, serial interface engine (SIE), enhanced 8051 microcontroller, and a programmable peripheral interface
in a single chip. The General Programmable Interface (GPIF) and Master/Slave Endpoint FIFO (8- or 16-bit data bus) provides
an easy and glueless interface to popular interfaces such as ATA, UTOPIA, EPP, PCMCIA, and most DSP/processors.
The CY7C68013-56PVC (EZ-USB FX2) is a single-chip integrated USB 2.0 Transceiver, Serial Interface Engine (SIE), and
Enhanced 8051 Microprocessor, High Speed 480Mbits/sec. Enhanced 8051 microcontroller, and a programmable peripheral
interface in a single chip. Integrated I2C-compatible controller, runs at 100 or 400kHz, 48MHz, 24MHz, or 12MHz 8051
operation. Four integrated FIFOs, brings glue and FIFO inside for lower system cost. Automatic conversion to and from 16-bit
buses, master or slave operation. FIFOs can use externally supplied clock or asynchronous strobes. Easy interface to ASIC
and DSP ICs, up to 40 general purpose I/Os.
EPROM External USB Application Number Core Temperature Pin Count Digi-Key Price Each Cypress
Memory Size RAM Oscillator Speed Configuration Speed I/O Arch. Range Voltage Package Part No. 1 25 100 Part No.
12 M-8 0C ~ 70C 4.0 ~ 5.25 20-SOIC 428-1313-ND 4.09 2.55 2.05 CY7C63001A-SC
12 M-8 0C ~ 70C 4.0 ~ 5.25 20-DIP 428-1849-ND 3.28 2.63 2.22 CY7C63001C-PXC
4K 128 6MHz Resonator OTP 1.5Mbps 12 M-8 0C ~ 70C 4.0 ~ 5.25 20-SOIC 428-1850-ND 3.28 2.63 2.22 CY7C63001C-SXC
16 M-8 0C ~ 70C 4.0 ~ 5.25 24-QSOP 428-1314-ND 4.84 2.98 2.42 CY7C63101A-QC
16 M-8 0C ~ 70C 4.0 ~ 5.25 24-QSOP 428-1618-ND 4.84 2.98 2.42 CY7C63101A-QXC
3K 96 6MHz Resonator OTP 1.5Mbps 12 M-8 0C ~ 70C 4.0 ~ 5.25 18-SOIC 428-1719-5-ND 3.28 2.63 2.22 CY7C63231A-SXC
32 M-8 0C ~ 70C 4.0 ~ 5.25 48-SSOP 428-1319-ND 5.31 3.29 2.66 CY7C63413-PVC
32 M-8 0C ~ 70C 4.0 ~ 5.25 48-SSOP 428-1852-ND 4.78 3.82 2.98 CY7C63413C-PVXC
11 M-8 0C ~ 70C 4.0 ~ 5.25 18-SOIC 428-1323-ND 4.47 2.80 2.24 CY7C63723-SC
8K 256 6MHz Resonator OTP 1.5Mbps
17 M-8 0C ~ 70C 4.0 ~ 5.25 24-DIP 428-1324-ND 4.81 2.98 2.41 CY7C63743-PC
17 M-8 0C ~ 70C 4.0 ~ 5.25 24-DIP 428-1856-ND 4.33 3.47 2.70 CY7C63743C-PXC
17 M-8 0C ~ 70C 4.0 ~ 5.25 24-SOIC 428-1325-ND 4.81 2.98 2.41 CY7C63743-SC
17 M-8 0C ~ 70C 4.0 ~ 5.25 24-SOIC 428-1622-ND 4.81 2.98 2.41 CY7C63743-SXC
17 M-8 0C ~ 70C 4.0 ~ 5.25 24-SOIC 428-1857-ND 4.33 3.47 2.70 CY7C63743C-SXC
19 M-8 0C ~ 70C 4.0 ~ 5.25 28-SOIC 428-1634-ND 6.23 4.99 4.21 CY7C64013A-SXC
8K 256 6MHz Xtal OTP 12Mbps 19 M-8 0C ~ 70C 4.0 ~ 5.25 28-SOIC 428-1847-ND 7.04 5.63 4.38 CY7C64013C-SXC
19 M-8 0C ~ 70C 4.0 ~ 5.25 28-DIP 428-1635-ND 6.25 5.01 4.23 CY7C64013A-PXC
40 8051 0C ~ 70C 3.3 128-TQFP 428-1678-ND 12.57 7.76 6.29 CY7C64713-128AXC
— 16K 24MHz Xtal RAM 12Mbps 40 8051 0C ~ 70C 3.3 100-TQFP 428-1679-ND 11.85 7.39 5.93 CY7C64713-100AXC
24 8051 0C ~ 70C 3.3 56-QFN 428-1680-ND 10.73 6.71 5.37 CY7C64713-56FXC
40 8051 0C ~ 70C 3.3 100-TQFP 428-1667-ND 19.77 12.23 9.89 CY7C68013A-100AXC
40 8051 0C ~ 70C 3.3 128-TQFP 428-1668-ND 20.95 12.91 10.47 CY7C68013A-128AXC
40 8051 -40C ~ 85C 3.3 128-TQFP 428-1943-ND 25.13 23.46 21.78 CY7C68013A-128AXI
24 8051 0C ~ 70C 3.3 56-QFN 428-1669-ND 18.71 11.54 9.36 CY7C68013A-56LFXC
24 8051 0C ~ 70C 3.3 56-SSOP 428-1627-ND 17.87 11.11 9.68 CY7C68013A-56PVXC
— 16K 24MHz Xtal RAM 12/480Mbps
40 8051 0C ~ 70C 3.3 100-TQFP 428-1670-ND 22.74 14.03 11.37 CY7C68014A-100AXC
40 8051 0C ~ 70C 3.3 128-TQFP 428-1671-ND 24.11 14.90 12.06 CY7C68014A-128AXC
24 8051 0C ~ 70C 3.3 56-QFN 428-1672-ND 21.53 13.28 10.77 CY7C68014A-56LFXC
24 8051 0C ~ 70C 3.3 56-SSOP 428-1673-ND 20.57 12.72 10.29 CY7C68014A-56PVXC
26 8051 0C ~ 70C 3.3 56-QFN 428-1674-ND 19.61 12.17 9.81 CY7C68015A-56LFXC
26 8051 0C ~ 70C 3.3 56-QFN 428-1676-ND 22.56 13.96 11.28 CY7C68016A-56LFXC
8K 256
6MHz Xtal 39 (4-port) M-8 0C ~ 70C 4-5.5 56-TSSOP 428-1808-ND 5.50 5.13 4.76 CY7C66113C-PVXC
— — 24MHz N/A 12/480Mbps
— None 0C ~ 70C 3.3 56-QFN 428-1942-ND 11.64 9.32 7.86 CY7C68001-56LFXC
— 256 12-48MHz Xtal RAM 1.5-12Mbps 8 No CPU 0C ~ 65C 3.3 48-TQFP 428-1721-ND 12.56 10.05 8.48 SL811HST-AXC
8K 16K 12MHz ROM/RAM — 32 CY16 -40C ~ 85C 3.3 100-TQFP 428-1865-ND 13.34 12.01 10.65 CY7C67300-100AXI
36 M8C 0C ~ 70C 2.7 ~ 3.6 48-SSOP 428-1795-ND 3.21 2.57 2.00 CY7C60123-PVXC
8K 256 12MHz — — 20 M8C 0C ~ 70C 2.7 ~ 3.6 24-QSOP 428-1798-ND 3.64 2.91 2.26 CY7C60223-QXC
20 M8C 0C ~ 70C 2.7 ~ 3.6 24-SOIC 428-1799-ND 3.82 3.06 2.38 CY7C60223-SXC
RoHS Compliant
24MHz Xtal
OTP
11 M-8 0C ~ 70C 4.0 ~ 5.25 18-DIP 428-1854-ND 4.02 3.22 2.51 CY7C63723C-PXC
11 M-8 0C ~ 70C 4.0 ~ 5.25 18-SOIC 428-1855-ND 4.02 3.22 2.51 CY7C63723C-SXC
Medium Performance Full-Speed Microcontrollers — RoHS Compliant
24 8051 -40C ~ 85C 3.3 56-SSOP 428-1944-5-ND 21.44 20.02 18.59 CY7C68013A-56PVXI
USB HUB and Integrated HUB Solutions — RoHS Compliant
4-port M-8 0C ~ 70C 3.3 56-QFN 428-1805-ND 13.29 10.64 8.27 CY7C65640A-LFXC
12Mbps Hub
EZ-USB SX2™ High Speed USB Interface — RoHS Compliant
— None 0C ~ 70C 3.3 56-SSOP 428-1864-ND 13.85 8.96 8.40 CY7C68001-56PVXC
EZ-Host™ USB Host/Peripheral Controller — RoHS Compliant
Wireless enCoRe™ II Microcontroller — RoHS Compliant
Low Speed USB Microcontrollers
EZ-USB FX1™ Full-Speed USB — RoHS Compliant
USB 2.0 (High Speed) — RoHS Compliant
USB Host/Slave Controller — RoHS Compliant
The CY7C65 Series offers high-performance, fixed-function Universal Serial Bus (USB) hub devices which comply with USB
Specification, Revision 1.1. Up to four downstream USB ports are available to expand the USB attachment points available in
your PC system. These self-contained devices require no firmware development for your design, thereby reducing the design
risk associated with some microcontroller solutions. These Application-Specific Standard Products (ASSP) can improve
time-to-market in a number of USB designs, including standalone hubs, motherboard hubs, and monitor hubs.
The CY7C68001 (EZ-USB SX2™) USB interface device is designed to work with any external master, such as standard
microprocessors, DSPs, ASICs, and FPGAs to enable USB 2.0 support for any peripheral design. SX2 has a built-in USB
transceiver and Serial Interface Engine (SIE), along with a command decoder for sending and receiving USB data. The
controller has four endpoints that share a 4KB FIFO space for maximum flexibility and throughput, as well as Control
Endpoint 0. SX2 has three address pins and a selectable 8- or 16- bit data bus for command and data input or output.
The SL811HS is a single-chip, dual-speed USB Embedded Host controller that can operate as either a USB Host or USB
peripheral device. The SL811HS can interface to devices such as microprocessors, microcontrollers, DSPs or directly to a
variety of buses such as ISA, PCMCIA and others.
The CY7C67300 (EZ-Host™) is Cypress Semiconductor’s first full-speed, low-cost multiport host/peripheral controller.
EZ-Host is designed to easily interface to most high-performance CPUs to add USB host functionality. EZ-Host has its
own 16-bit RISC processor to act as a coprocessor or operate in standalone mode. EZ-Host also has a programmable I/O
interface block allowing a wide range of interface options.
The Wireless enCoRe II family brings the features and benefits of the enCoRe™ II to non-USB applications. The enCoRe
II family has an integrated oscillator that eliminates the external crystal or resonator, reducing overall cost. Also integrated
into this chip are other external components such as wake-up circuitry.
C
Free shipping on orders over $200 CAD! All prices in Canadian dollars and include duty and brokerage fees.
1-800-344-4539 • ca.digikey.com • 218-681-6674 • Fax: 218-681-3380
(C091)
687
CY7B923 HOTLink
The CY7B923 HOTLink Transmitter and CY7B933 HOTLink Receiver are point-to-point communications building blocks that trans fer data over high-speed serial links ( ber, coax, and twisted pair). Standard HOTLink
data rates range from 160-330 Mbits/second. Higher speed HOTLink is also available for high-speed applications (160-400 Mbits/second), as well as for those low-cost applications HOTLink-155 (150-160 Mbits/second
operations).
Features:
• Fibre-Channel compliant • IBM ESCON com pliant • DVB-ASI compliant • ATM compliant • B/10B coded or
10-bit unencoded • Stan dard HOTLink: 160–330Mbps • High-speed HOTLink 160–400 Mbps for high-speed
applications • Low-speed HOTLink: 150–160Mbps for low-cost ber
Applications:
• TTL synchronous I/O • No external phase-locked-loop (PLL) components • Triple PECL 100K serial outputs
• Dual PECL 100K serial inputs • Low power: 350mW (Tx), 650mW (Rx) • Compatible with ber optic modules,
coaxial cable, and twisted pair media • Built-In Self-Test • Single +5V supply • 28-pin SOIC/PLCC/LCC • 0.8
BiCMOS
Digi-Key Price Each Cypress
Description Package Part No. 1 25 100 Part No.
28-PLCC 428-1706-5-ND 69.74 55.79 47.08 CY7B923-JXC
Transmitter,
Standard Speed
Receiver,
Standard Speed
28-SOIC 428-1707-5-ND 69.74 55.79 47.08 CY7 B923-SXC
28-PLCC 428-1708-5-ND 69.74 55.79 47.08 CY7B933-JXC
28-SOIC 428-1709-5-ND 69.74 55.79 47.08 CY7B933-SXC
Developer Kits
C
CY3674
The development kits for the EZ-USB FX™ family provide complete hardware and software solutions for
accelerating the rmware and device driver development for all the products in the family. The development
kits use the actual silicon for the entire development. Software utilities and example of rmware allow the
user to generate USB traffic in hours, not weeks! Includes an evaluation version of the 8051 Keil Software
Tools in the Full Speed USB 2.0 development kit. The evaluation version of the C-Compiler lets the designer
write 8051 microcontroller applications in C and still get the efficiency and speed of assembly language.
Advanced features from Keil Tools include the ability to single step through code. This makes it easy to
detect errors, handle source level debugging, and set breakpoints. With the ability to debug code one line at
a time and to quickly compile and one-step download new code, developers have a more efficient means to
complete rmware faster than using emulators. The supplied Keil Tools are fully functional, but are limited in
object size to 4 kilobytes.
Devices Supported: CY7C64713-56LFXC, CY7C64713-100AXC, CY7C64713-128AXC
Kit Includes:
• EZ-USB Development Board with CY7C64713-128AXC • Peripheral Board for proto typing • USB cable
• RS-232 9-pin to 9-pin cable
428-1681-ND EZ-USB FX1 Development Kit ......................................................... $608.02
SL11R-DK
The SL11R from Cypress, is a low cost, full speed Universal Serial Bus (USB) RISC based Controller. The
SL11R contains a 16-bit RISC processor with built-in BIOS ROM that greatly reduces rmware development
time. This unique architecture provides the ability to upgrade products, in the eld, without changing the
peripheral hardware. The pro cessor can execute code either from internal ROM/RAM or external DRAM,
SRAM and ROM.
Kit Includes: • HW reference design for SL11R evaluation board • Assem bler/Debugger and built in emulator
• App lication notes • BIOS ROM information • System Software demo program source code • Generic
WDM mini-port driver for WIN98/2000-object code • 2 sample chips
Devices Supported: SL11R-IDE
428-1344-ND SL11 Development Tools ............................................................ $614.22
Email support.
CY4636
WirelessUSB LP RDK (CY4636) provides an exemplary implementation of a 2:1, bidirectional Wireless
desktop keyboard and mouse to single wireless receiver. The RDK will help jump-start your Keyboard and
Mouse development using WirelessUSB LP (CYRF6936) Radio System on Chip. WirelessUSB LP is the
next generation WirelessUSB device, with high data throughput and low power designed to operate in 2.4
GHz ISM band. WirelessUSB has many powerful features that allow users to create never before seen radio
applications.
Kit Includes: • CYRF6936 WirelessUSB LS transceiver • Optical Sensor Mouse • WirelessUSB keyboard
• Batteries • CD
428-1858-ND Wireless USB REF Kit ................................................................ $308.66
CY3684
The CY3684 development kit for the EZ-USB FX2LP™ family provides complete hardware and software
solutions for accelerating the rmware and device driver development for all of the products in the family.
The development kits use the actual silicon for the entire development. Software utilities and example
rmware allow the user to generate USB traffic in hours, not weeks! Includes an evaluation version of
the 8051 Keil Software Tools. The evaluation version of the C-Compiler lets the designer write 8051
microcontroller applications in C and still get the efficiency and speed of assembly language. The supplied
Keil tools are fully functional, but are limited in object size to 4 kilobytes.
Kit includes:
• EZ-USB development board • Peripheral board for prototyping • USB cable • RS232 9-pin to 9-pin cable
428-1677-ND Development Kit for EZ-USB FX2LP .................................................... $651.45
CY3655
The enCoRe™ II development system, based on the highly re ned PSoC™ (Programmable System-onChip™) tools, supplies the user with an incircuit emulator (ICE) that works in conjunction with actual silicon to
provide an accurate and efficient development system. The PSoC Designer™ software consists of a graphical
user interface, assembler, C-Compiler, linker and debugger for a highly integrated code development
environment. A compliant USB “User Module” along with PS/2 and other peripheral User Modules simpli es
the learning curve and speeds development time.
Kit Includes:
• Application Board enCoRe II Pod • Wireless enCoRe II Pod • PDIP feet • Modular Programmer Base Board
• Programming Adapter Plug • USB Cable PS/2 Male to Male Cable • Software • Printed Documentation
428-1773-ND Development Kit for enCoRe II ..................................................... $1446.83
428-1774-ND Extension Kit for enCoRe II .......................................................... $763.12
8, 16, and 32-Bit Flash Microcontrollers
Toshiba 8-bit microcontrollers feature low-power consumption and low voltage operation. The on-chip peripherals options include LCD, VFT and LED display drivers. The 870/C series has a single register bank to increase
C-Compiler efficiency.
Features: • Minimum Instruction cycle time: 0.25µs at 16MHz • Low-power modes including HALT, IDLE and clock gear and dual clocks • Powerful instruction set with 731 instructions including multiply, divide, 16-bit
operations, bit manipulations, etc. • On-chip peripherals including A/D, PWM, UARTS and LCD • Oper ating Temperature: -40 ~ 85C
Kits Include: Evaluation Board, C-Compiler (3000 lines per module), Assembler, Linker, RS-232 Cable, Batteries, Quick Start Guide, Datasheet, Manuals, CD with Tools
Memory Size Supply Digi-Key Price Each Toshiba
EPROM RAM I/O Voltage Package Part No. 1 25 100 Part No.
512K 24KB 143 2.7 ~ 3.6 193-FBGA TMP19A43FDXBG-ND 15.67 14.11 12.51 TMP19A43FDXBG
2MB 64KB 209 2.7 ~ 3.6 281-FBGA TMP19A64F20AXBG-ND 51.68 46.54 41.26 TMP19A64F20AXBG
32K 2K 39 1.8 ~ 3.6 64-QFP TMP86FM29FG-ND 6.95 5.56 4.33 TMP86FM29FG
32K 2K 39 1.8 ~ 3.6 64-LQFP TMP86FM29UG-ND 6.95 5.56 4.33 TMP86FM29UG
32K 2K 56 1.8 ~ 3.6 64-QFP TMP86FM48FG-ND 9.93 7.95 6.71 TMP86FM48FG
32K 2K 56 1.8 ~ 3.6 64-LQFP TMP86FM48UG-ND 9.80 7.85 6.62 TMP86FM48UG
48K 2K 48 1.8 ~ 3.6 80-LQFP TMP86FP24FG-ND 7.79 6.23 5.26 TMP86FP24FG
8K 256 22 2.7 ~ 5.5 30-SSOP TMP86F807MGEY-ND 6.70 5.37 4.17 TMP86F807MG(EY)
8K 256 24 2.7 ~ 5.5 30-SSOP TMP86F808DMGEY-ND 6.70 5.37 4.17 TMP86F808DMG(EY)
16K 512 26 4.5 ~ 5.5 32-SDIP TMP86FH09NGZM-ND 3.15 2.53 1.97 TMP86FH09NG(ZM)
16K 512 24 2.7 ~ 5.5 30-SSOP TMP86FH12MGZ-ND 4.47 3.58 2.78 TMP86FH12MG(Z)
16K 512 33 2.7 ~ 5.5 42-SDIP TMP86FH46ANGZ-ND 6.20 4.97 4.19 TMP886FH46ANG(Z)
16K 512 35 2.7 ~ 5.5 44-LQFP TMP86FH47UG-ND 3.57 2.86 2.41 TMP86FH47UG
60K 2K 48 2.7 ~ 5.5 64-LQFP TMP86FS23UGJZ-ND 5.93 4.75 3.70 TMP86FS23UG(JZ)
60K 1K 55 2.7 ~ 5.5 80-LQFP TMP86FS27FG-ND 11.76 9.41 7.94 TMP86FS27FG
60K 2K 62 2.7 ~ 5.5 80-LQFP TMP86FS28DFGJZ-ND 6.28 5.03 4.24 TMP86FS28DFG(JZ)
60K 2K 62 2.7 ~ 5.5 80-QFP TMP86FS28FGTZ-ND 6.28 5.03 4.24 TMP86FS28FG(TZ)
60K 2KB 56 2.7 ~ 5.5 60-QFP TMP86FS49AFGZ-ND 6.45 5.17 4.36 TMP86FS49AFG(Z)
60K 2KB 56 2.7 ~ 5.5 60-LQFP TMP86FS49AUGJZ-ND 6.45 5.17 4.36 TMP86FS49AUG(JZ)
60K 2KB 91 2.7 ~ 5.5 100-QFP TMP86FS64FGTZ-ND 6.87 5.51 4.28 TMP86FS64FG(TZ)
16K 512 32 1.8 ~ 5.5 44-LQFP TMP86PH22UGJZ-ND 5.45 4.36 3.39 TMP86PH22UG(JZ)
128K 4KB 61 2.4 ~ 3.6 100-LQFP TMP91FW40FGJZ-ND 9.26 7.41 6.25 TMP91FW40FG(JZ)
256K 16KB 81 2.4 ~ 3.6 100-LQFP TMP91FY42FGJZ-ND 12.67 11.41 10.12 TMP91FY42FG(JZ)
128K 8KB 81 2.4 ~ 3.6 100-QFP TMP91FW60DFGTZ-ND 9.26 7.41 6.25 TMP91FW60DFG(TZ)
128K 8KB 83 2.4 ~ 3.6 100-LQFP TMP91FW60FGBJZ-ND 9.26 7.41 6.25 TMP91FW60FG(B,JZ)
8K 288KB 136 2.4 ~ 3.6 228-FBGA TMP92CZ26AXBG-ND 12.41 11.17 9.91 TMP92CZ26AXBG
86FH47 Starter Kit........................................................................ BMSKTOPASFM47AND-ND 122.78 — — BMSKTOPASFM47(AND)
86FM29 Starter Kit ....................................................................... BMSKTOPASFMA-ND 122.78 — — BMSKTOPASFM29(AND)
86FM29 Starter Kit ....................................................................... BMSKTOPASFM48AND-ND 122.78 — — BMSKTOPASFM48(AND)
TMP86FS49 Evaluation Kit .............................................................. BMSKTOPAS86FS49A-ND 122.78 — — BMSKTOPAS86FS49(A)
RoHS Compliant
Free shipping on orders over $200 CAD! All prices in Canadian dollars and include duty and brokerage fees.
688
(C091)
1-800-344-4539 • ca.digikey.com • 218-681-6674 • Fax: 218-681-3380
Loading...
