Cypress CP-1262HE Operation Manual

CP-1262HE

HDMI to PC/Component

Converter with

Audio Box

CP-1262HE

Operation Manual

1. Introduction................................................................................

2. Features......................................................................................

3. Operation Controls and Functions..........................................

3.1 Front Panel...........................................................................

3.2 Rear Panel............................................................................

4. Connection and Installation.....................................................

5. HDMI Connector Pin Assignment.............................................

6. Specifications.............................................................................

Table Of Contents

1

1

2

2

2

3

3

4

1. Introduction

This converter box converts digital HDMI to Analog PC or SD/HD output. It
enables to connect the HDMI sources to the analog PC monitor, Projector or
TV. Its high bandwidth capability supports a wide range of PC and HDTV
resolutions.

2. Features

 Supports HDMI input and Analog PC or SD/HD output.

 Supports output selection between YPbPr and RGB.

 Supports input/output resolution as below:

PC: 640x480= VGA59 , VGA60, VGA72, VGA75, VGA85

800x600= SVGA56, SVGA60, SVGA72, SVGA75, SVGA85
1024x768= XGA60, XGA70, XGA75, XGA85
1152x864= MAC70, MAC75, MAC85
1280x800= WXGA60
1280x1024= SXGA60, SXGA75, SXGA85,
1440x900= WXGA60
1600x1200= UXGA60
1680x1050=WSXGA+60
1920x1200= WUXGA60(pixel-rate=154MHz)

HD: 480I60, 576I50, 480P60, 576P50, 720P60, 720P50, 1080I60, 1080I50,

1080P60, 1080P50

Note: ① Due to the limitation of Tri-level synchronies output
the image will shift to the left side of the screen when
component output at 720p/1080i/1080p.
② If HDMI source includes HDCP(High-bandwidth Digital
Content Protection), output display is not supports
HDCP decryption and no image will display.

 Built in EDID.

 HDMI 1.3, HDCP 1.1 and DVI compliant.

1

2

1 YPbPr/RGB switch:

Set the switch to RGB when your HDMI source equipment is PC graphic
card or other digital RGB source signal. Use HD-15 to HD-15 VGA cable
to connect between the unit's RGB out and the RGB input of your PC
monitor, or projector. Set the switch to YPbPr when your HDMI source
equipment is DVD player, set-top-box or other High definition digital
video source. Use a VGA to 3 RCA adaptor cable to connect the unit's

YPbPr out to the YPbPr input connector of your HDTV.
Note: When YPbPr output from HD-15 D-Sub the H-pin and V-pin will
remain the signal at the same time.

2 HDMI input: Connect the HDMI input port to the HDMI output port of

your source equipment such as DVD player or set-top-box.

3 Power: Plug the 5VDC power supply into the unit and connect the

adaptor to AC wall outlet.

3. Operation Controls and Functions

3.1 Front Panel

1 2 3

DC 5V

RGB

YPbPr

OUTPUT HDMI INPUT

3.2 Rear Panel

1 HD-15 D-Sub output: Connect the output port to the PC/YPbPr input of

analog PC monitor, Projector or TV.

2 L/R: Stereo audio output via 3.5mm phone jack.

1 2

L/RPC/YPbPr

OUTPUT

3

4. Connection and Installation

HDMI out

DVD or, Set-Top-Box

DVD or, Set-Top-Box

HDMI

HDMI

DVI out

DVI to HDMI adaptor

VGA cable

3.5mm to 2 RCA
audio cable

LCD Monitor/TV Projector

or

HDMI cable

Connection 1(RGB out)

Connection 2 (YPbPr out)

HDMI cable

Audio

D-Sub to 3 RCA cable

YPbPr cable

5. HDMI Connector Pin Assignment

Pin#

1
3

5

7

9
11

13

15

17
19

Pin#

2
4

6

8

10
12

14

16

18

Function Assignment

TMDS Data2+
TMDS Data2-

TMDS Data1 Shield

TMDS Data0+

TMDS Data0­TMDS Clock Shield

CEC

SCL

DDC/CEC Ground
Hot Plug Detect

Function Assignment

TMDS Data2 Shield
TMDS Data1+

TMDS Data1-

TMDS Data0 Shield

TMDS Clock+
TMDS Clock-

Reserved (N.C. on device)

SDA

+5V Power

Output Format

1

67

11

12131415

2345

10 9 8

1

2

19

18

LCD TV

4

6. Specifications

Up to 225MHz
1 x HDMI
1 x HD-15 D-Sub (RGBHV or YPbPr)
1 x Analog L/R 3.5mm phone jack
RGB: 0.7Vp-p 75ohm
H/V: 3 to 5 Vp-p
Or Y: 1 Vp-p 75ohm
PB/Pr: 0.7 Vp-p 75ohm
PC: 640x480= VGA59 , VGA60, VGA72, VGA75, VGA85
800x600= SVGA56, SVGA60, SVGA72, SVGA75, SVGA85
1024x768= XGA60, XGA70, XGA75, XGA85
1152x864=MAC70, MAC75, MAC85
1280x800=WXGA60
1280x1024= SXGA60, SXGA75, SXGA85,
1440x900=WSXGA60
1600x1200= UXGA60
1680x1050=WSXGA+60
1920x1200= WUXGA60(pixel-rate=154MHz)
HD: 480I60, 576I50, 480P60, 576P50, 720P60, 720P50,
1080I60, 1080I50, 1080P60, 1080P50
PCM2
RGB, YUV
5V/1A DC (US/EU standards, CE/FCC/UL certified)
76(W) x 30(D) x 92(H)
172
Aluminum
Silver
0°C ~ 40°C

2.5W (max)

Operation Frequency
Input Port
Output Ports

Output Signal

Input/Output Resolution

HDMI Audio In
HDMI In Color Space
Power Supply
Dimensions (mm)
Weight(g)
Chassis Material
Silkscreen Color
Operating Temperature
Power Consumption

Part No. Pin No. Description (PC out)

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

DB15HD

RED

GREN

BLUE

GND

GND (DDC-RETURN)

GND-RED

GND-GREEN

GND-BLUE

N.C

GND-SYNC

GND

DDC-DATA

H-SYNC

V-SYNC

DDC-CLOCK

Part No. Pin No. Description (HD out)

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

DB15HD

Pr

Y

Pb

GND

GND (DDC-RETURN)

GND-Pr

GND-Y

GND-Pb

N.C

GND-SYNC

GND

DDC-DATA

H-SYNC

V-SYNC

DDC-CLOCK

B. Analog VGA output pin
assignment when output switch
set to RGB.

C. Analog VGA output pin assignment
when output switch set to YPbPr.

5

20080818 MPM-CP1262HE
