2x10 HDMI 1.3 Splitter
Operation Manual
CLUX-210S
TABLE OF CONTENTS
1. Introduction................................................................................ 1
2. Features...................................................................................... 1
3. Operation Controls and Functions........................................... 2
3.1 Front Panel........................................................................... 2
3.2 Rear Panel........................................................................... 3
4. Remote Control......................................................................... 4
5. RS-232 Remote Control Protocol............................................. 4
5.1 Pins definition of modem cable.............................................. 4
5.2 Commands............................................................................ 4
6. Specifications............................................................................ 5
7. Cypress HDMI v1.3 Series:........................................................ 6
1
1. Introduction
The HDMI v1.3 Distribution Amplifier Series is the most advanced solution to
HDMI signal distribution. Each product in this series is compatible to HDMI v1.3
specifications, a cutting edge technology which defines the support to transfer
Deep Color (10-bit and 12-bit ) video and new lossless compressed (Dolby
TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, with a high
bandwidth up to 225MHz (6.75Gbps). Besides splitting and distributing, the HDMI
v1.3 DA series also does signal amplification and equalization, so as to provide
high performance I/O of audio and video. Each of the buffered output can run
up to 15 meters and can be cascaded.
2. Features
HDMI 1.3, HDCP1.1 and DVI1.0 compliant Receiver.
Deep color video up to 12bit, 1080p@60Hz.
Two HDMI sources to connect up to ten HDMI displays simultaneously.
HDCP keysets allows each output to work independently when
connecting to a HDMI display.
Splits a HDMI source up to ten outputs without signal loss.
Supports DVI source and DVI display by using HDMI to/from DVI adaptor
cable.
Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master
Audio transmission (32-192kHz Fs sample rate).
Supports a wide range of PC and HDTV resolutions from VGA to UXGA and
480i to 1080p.
HDMI cable distance test with 1080p resolution: Input/Output source can
run up to 15M/5.1CH.
Can selected EDID source from TV or this Splitter.
Full HDCP Compliant.
2
3. Operation Controls and Functions
3.1 Front Panel
1 Remote Control Sensor.
2 Key Lock: Press and hold the "Key Lock" button for 5 seconds the system
will enter into Key Lock mode. When the system in Key Lock made the Key
Lock LED will illuminate and all buttons will not function.
3 HDMI/DVI Indicator: The LED will illuminate when the selected HDMI input
source is originally from an HDMI output, the LED will not illuminate when
the selected HDMI input source is originally from a DVI output.
4 HDCP Indicator: The LED will illuminate when the selected HDMI input
source is HDCP-protected.
5 SYNC Indicator: The LED will illuminate when the selected HDMI IN
connects to an HDMI or DVI output correctly.
6 HDMI output Indicator: The LED will illuminate when the output sources are
been connected.
7 HDMI input Select/Indicator: Press the "Input" button sequentially to switch
to your desired input (HDMI 1 or HDMI 2), the LED will illuminate to indicate
which input source is selected
8 POWER Switch/Indicator: Press the "POWER" button to turn on/off the
power, the power LED illuminate in green color means the power is turned
on, illuminate in red color means the power is turned off.
81 2 3 5 6 7
4
POWERINPUTKEY LOCK SYNC
HDCPHDMI / DVI
1212345
678
OUTPUT
910
CLUX-210S
2X10 HDMI 1.3 SPLITTER
3
3.2 Rear Panel
1 EDID Control Jumper: Default factory setting is TV, leave as if the display
is properly. Switch to STD to use build-in EDID if the display has problems.
When the EDID control jumper in TV selection, the unit will detect the first
HDMI output source's EDID and record in the unit. If the first detected
output source is DVI it will pass to next source, until the first HDMI been
detected.
2 RS232: 9-pin D-Sub connector for connecting to your PC or other control
console for remote control.
3 HDMI Inputs 1 and 2: Connect each of the input ports to the HDMI or DVI
output of your source equipment such as DVD player or set-top-box.
4 HDMI Outputs 1 to 10: Connect each of the output ports to the HDMI
display. When more than one output connected, the HDMI outputs play
identical video signal simultaneously.
5 Power: Plug the 5V DC power supply into the this unit and connect the
adaptor to AC wall outlet.
DC 5V
RS-232
1 2
1 2 3 4 5 6 7 8 9 10
EDID
STD TV
HDMI OUT
HDMI IN
1 3 4 5
2
4
4. Remote Control
POWER: Press the button to turn on/off the unit.
Input Select for HDMI: Press '1" to select
HDMI 1 input, press "2" to select HDMI 2 input.
POWER
CR-37
1
2
1
2
5. RS-232 Protocol
* RS-232 transmission format:
Baud Rate : 9600 bps
Data Bit : 8 Bits
Parity: None
Stop Bit: 1 bit
5.2 Commands
Splitter
PIN
1
2
3
4
5
6
7
8
9
Definition
NC
T xD
R x D
NC
GND
NC
NC
NC
NC
PIN
1
2
3
4
5
6
7
8
9
Definition
NC
R xD
T x D
NC
GND
NC
NC
NC
NC
Remote Controller
5.1 Pins definition of modem cable
- The connection between Splitter and remote controller with
RS-232 modem cable.
COMMAND ACTION
POWER 00 Power Off (standby)
POWER 01 Power On
PORT 01 Select Input 1
PORT 02 Select Input 2
5
6. Specifications
Frequency bandwidth
Input ports
Output ports
Power Supply
Remote Control
Dimensions (mm)
Weight(g)
Chassis Material
Silkscreen Color
Operating Temperature
2.25Gbps (single link)
2x HDMI female ports (Type A connector)
10 x HDMI female ports
5VDC/5A (US/EU standards, CE/FCC/UL certified)
Discrete IR remote
436(W) x 160(D) x 44(H)
2000
Metal
Black
Operating from 0°C ~ 40°C
7. Cypress HDMI v1.3 Series:
20070727 MPM-CLUX210S
Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD.
Product Description
CLUX-11S 1x1 HDMI V1.3 Repeater
CLUX-12S 1x2 HDMI V1.3 Splitter
CLUX-14S 1x4 HDMI V1.3 Splitter
CLUX-18S 1x8 HDMI V1.3 Splitter
CLUX-21SY 2x1 HDMI V1.3 Switcher
CLUX-31S 3x1 HDMI V1.3 Switcher
CLUX-31SY 3x1 HDMI V1.3 Switcher
CLUX-41SY 4x1 HDMI V1.3 Switcher
CLUX-41AT 4x1 HDMI V1.3 Switcher with Digital Audio
CLUX-42S 4x2 HDMI V1.3 Switcher
CLUX-110S 1x10 HDMI V1.3 Splitter
CLUX-210S 2x10 HDMI V1.3 Splitter
CLUX-210T 2x10 HDMI V1.3 Splitter with Digital Audio
