Cypress CH-506TXWP, CH-506RXWP User Manual

DRAFT
CH-506TXWP & RXWP
HDMI & IR over Single CAT5e/CAT6
Operation Manual
Operation Manual
DRAFT
DRAFT
DISCLAIMERS
The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document. Cypress also makes no commitment to update or to keep current the information contained in this document.
Cypress Technology reserves the right to make improvements to this document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2012 by Cypress Technology.
All Rights Reserved.
Version 1.1 June 2012
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be trademarks of the companies with which they are associated.
DRAFT
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this equipment:
Always follow basic safety precautions to reduce the risk of re, electrical shock and injury to persons.
To prevent re or shock hazard, do not expose the unit to rain, moisture or install this product near water.
Never spill liquid of any kind on or into this product.
Never push an object of any kind into this product through any openings or empty slots in the unit, as you may damage parts inside the unit.
Do not attach the power supply cabling to building surfaces.
Use only the supplied power supply unit (PSU). Do not use the PSU if it is damaged.
Do not allow anything to rest on the power cabling or allow any weight to be placed upon it or any person walk on it.
To protect the unit from overheating, do not block any vents or openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 14/02/12 Preliminary Release
DRAFT
CONTENTS
1. Introduction ............................................ 1
2. Applications
3. Package Contents
4. System Requirements
5. Features
6. Operation Controls and Functions
6.1 Transmitter
6.2 Receiver
7. D-Sub 9 Pin Denitions
8. Connection Diagram
9. Specications
10. Acronyms
........................................... 1
................................ 1
............................ 1
.................................................. 2
....... 3
.........................................3
............................................4
........................... 5
............................ 6
........................................ 7
............................................. 8
DRAFT
1. INTRODUCTION
The device that can make your home or ofce more efcient, this unit
of HDMI over Single CAT5e/6 can transmit and receive uncompressed audio/video, control through the built-in RS-232 and IR ports and Power on Ethernet(POE) over 100M with all plate design. Hence, if you
want to make your home or ofce more efcient, get the HDMI & IR over single CAT5e/CAT6 and prepare to be amazed.
2. APPLICATIONS
• Household entertainment sharing and control
• Lecture room display and control
• Showroom display and control
• Meeting room presentation and control
• Classroom display and control
3. PACKAGE CONTENTS
HDMI & IR over Single CAT5e/CAT6 Transmitter x 1
HDMI & IR over Single CAT5e/CAT6 Receiver x 1
IR Blaster x 1
IR Receiver x 1
3.5Ø to RS-232 female cable x 1 for transmitter
3.5Ø to RS-232 male cable x 1 for receiver
24V/1.25A DC Power Adaptor x 1
• Operation Manual
4. SYSTEM REQUIREMENTS
Input HDMI source equipment such as DVD/Blue-Ray player and output display with HDMI input jack.
1
DRAFT
5. FEATURES
HDMI 1.4 with 3D, 4k x 2k support, HDCP & DVI Compliant
• Supports HDCP repeater and CEC bypass
• Simultaneously uncompressed data sending over a single
100M/328ft with CAT6 or CAT5e cable
Uncompressed video 1080p, 60Hz, 36bits
Audio support up to 7.1CH & Dolby TrueHD, DTS-HD
4Play™ convergence: HDMI, POE & Control (IR & RS232)
• Wall plate design and Installation Friendly
Note: This system was tested with CAT6/23AWG cable, so if using cables of another type, results may vary.
2
DRAFT
6. OPERATION CONTROLS AND FUNCTIONS
RearFront
6.1 Transmitter
POWER
5
LINK
DC 24V
6
7
RS232INIR 2INIR 1
1
RS-232 IN: This slot is to connect with 3.5Ø phone jack RS-232 cable
from PC/NB equipment for sending RS-232 commands.
2
IR 2 IN: This slot is to connect with the IR receiver cable included in
the package for IR signal receiving.
3
IR 1 OUT: This slot is to connect with the IR blaster cableincluded in
the package for IR signal transmitting.
4
HDMI IN: This slot is to connect with HDMI source equipment such
as DVD/Blu-ray player.
5
POWER LED: This green LED will illuminate when the device is
attached with power supply.
6
LINK LED: This yellow LED will illuminate when the both CAT5e/6
input and output signal is connected.
7
DC 24V: This slot is where you plug the 24V DC power supply into
the unit and connect the adaptor to an AC outlet.
8
CAT5e/6 Out: Connect to the receiver unit with a single CAT5e/6
cable for transmission of all data signals.
OUT
31 4
HDMI
IN
82
3
DRAFT
6.2 Receiver
RearFront
RS232
IR 1INIR 2
OUT
OUT
HDMI
OUT
POWER
5
LINK
6
31 4
1
RS-232 OUT: This slot is to connect with 3.5Ø phone jack RS-232
cable from device equipment for receiving RS-232 commands.
2
IR 1 IN: This slot is to connect with the IR receiver cable included in
the package for IR signal receiving.
3
IR 2 OUT: This slot is to connect with the IR blaster cableincluded in
the package for IR signal transmitting.
4
HDMI OUT: This slot is to connect with HDMI TV/monitor for display
HDMI input source signal.
5
Power LED: This green LED will illuminate when the device is
connected to a power supply.
6
LINK LED: This yellow LED will illuminate when the both CAT5e/6
input and output signal is connected.
7
CAT5e/6 In: This slot is to be connected with a single CAT5e/6
cable from transmitter side for data transmitting.
72
4
DRAFT
7. D-SUB 9 PIN DEFINITIONS
Pin Dene TX/RX
1 N/C
2 TxD/RxD
3 RxD/TxD
4 N/C
5 GND
6 N/C
7 N/C
8 N/C
9 N/C
5
DRAFT
8. CONNECTION DIAGRAM
DC
POWER
CAT5e(100M)/
LINK
DC 24V
RS232INIR 2INIR 1
RS-232 Cable RS-232 Cable
IR2 Receiver
3m 3m
PC
HDMI
OUT
IN
IR1 Blaster
7m
CAT6(100M)
HDMI Cable HDMI Cable
IR1 Receiver
60°
1.5m
Blu-ray
60°
POWER
LINK
RS232
IR 1INIR 2
OUT
HDMI
OUT
OUT
IR2 Blaster
60°
1.5m
HD Monitor or TV
Projector
TV/HD Monitor's
Remote
3m 3m
60°
7m
Blu-ray's
Remote
6
DRAFT
9. SPECIFICATIONS
Transmitter
Input 1×HDMI, 1×IR Extender, 1×RS-232
Output 1×CAT5e/6, 1×IR Blaster
Receiver
Input 1×CAT5e/6, 1×IR Extender
Output 1×HDMI, 1×RS-232, 1×IR Blaster
Power Supply 24V / 1.25A DC (US/EU standards, CE/FCC/
UL certied)
ESD Protection Human-body Model:
±8kV (air-gap discharge)
±4kV (contact discharge)
IR Frequency 30~50 kHz
Dimensions (mm) 87(W) 97x (D) x 31(H)/Tx
87(W) 97x (D) x 29(H)/Rx
Weight (g) 200
Chassis Material Aluminum
Silkscreen Color Black
Power Consumption TX: 3W ; RX: 6W
Operating Temperature 0 °C~40 °C/32 °F~104 °F
Storage Temperature −20 °C ~ 60 °C/−4 °F~140 °F
Relative Humidity 20~90 % RH (non-condensing)
7
DRAFT
10. ACRONYMS
ACRONYM COMPLETE TERM
CAT5e Category 5 Cable
CAT6 Category 6 Cable
CEC Consumer Electronics Control
DVI Digital Visual Interface
HDCP High-bandwidth Digital Content Protection
HDMI High Denition Multimedia Interface
IR Infrared
8
DRAFT
DRAFT
DRAFT
CYPRESS TECHNOLOGY CO., LTD
Home page: http://www.cypress.com.tw
