CH-107 TX & RX
HDMI v1.3 over ONE
CAT6 HDMI Transmitter &
Receiver
Operation Manual
CH-107 TX & RX
Disclaimers
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes
no commitment to update or to keep current the information
contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
Copyright Notice
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer file, in any form or by any means
- electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise - without express written permission and consent from
Cypress Technology.
© Copyright 2010 by Cypress Technology.
All Rights Reserved.
Version 1.0 August 2010
Trademark Acknowledgments
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
Safety Precautions
Please read all instructions before attempting to unpack or install or
operate this equipment, and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
Always follow basic safety precautions to reduce the risk of
fire, electrical shock and injury to persons.
To prevent fire or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
Never spill liquid of any kind on or into this product.
Never push an object of any kind into this product through
module openings or empty slots, as you may damage parts.
Do not attach the power supply cabling to building surfaces.
Do not allow anything to rest on the power cabling or allow it to
be abused by persons walking on it.
To protect the equipment from overheating, do not block the
slots and openings in the module housing that provide
ventilation.
Revision History
Version No Date Summary of Change
V1 20100317 Preliminary release
Table of Contents
1
1
1
1
2
3
3
3
4
4
5
1. Introduction ……………………..……………………...…........….…….
2. Applications …………………..………………….……...................…..
3. Package Contents ………………………...........……….................…
4. System Requirements ……………..……….........………............…….
5. Features …………………………………………......……........…...……
6. Specications ………………………………...……..........………....….
7. Operation Controls and Functions ……………...……..............……
7.1 Front Panel ..............................................................................
7.2 Rear Panel .…………………………………..…….......…...….…
8. Connection and Installation ….………………….........…..…..…......
9. Acronyms …......................................................................................
1. Introduction
The HDMI 1.3 transmitter and receiver over ONE CAT 6 is a tool for displaying
HDMI content at long distances. Instead of using expensive HDMI cables, your
existing CAT 6 cables/sockets can perform functions like transferring Deep
Color (12 bits/color) video and new lossless compressed (Dolby TrueHD, Dolby
Digital Plus and DTS-HD Master Audio) Digital audio, with a bandwidth up to
2.25Gbps. The HDMI 1.3 Transmitter and receiver, over ONE CAT6 extender is
your preferred HDMI extension tool.
2. Applications
Long distance HDMI signal distribution
Showroom display
Hypermarket display
Lecture room display
3. Package Contents
HDMI v1.3 Transmitter x 1
HDMI v1.3 Receiver x 1
5V DC Power Supply adaptor x 2
Operation Manual x 1
4. System Requirements
Input HDMI source equipment and output HDMI display with connection
cables and one CAT6 cable.
1
5. Features
Compliant with HDMI 1.3, HDCP 1.1 and DVI1.1 standards.
Supports digital video formats in Deep Color Mode at up to 36 bits (12bits/
color) and new lossless compressed (Dolby TrueHD, Dolby Digital Plus
and DTS-HD Master Audio) Digital audio .
Supports one CAT-6 cable for data/DDC transmission.
Equalizes and recovers incoming TMDS data before re-transmitting it in
optimal quality regardless of the incoming signal quality.
Cable testing showed that with 1080p 12bit resolution the HDMI input/
output source can be 10meters away.
Cable testing showed that with 1080p 12bit resolution the CAT6 input/
output device can be 45/15 meters away.
Support xvYCC
2
6. Specications
Frequency Bandwidth 2.25Gbps (single link)
Transmitter
Input/Output Ports 1 x HDMI Female port/1 x CAT6
Receiver
Output/Input Ports 1 x HDMI Female port/1 x CAT6
Power Supply 5V/ 1A DC (US/EU standards, CE/FCC/UL
certified)
ESD Protection Human Body Model:± 8kV (air-gap discharge)
±
4kV (contact discharge)
Dimensions (mm) 78.5 (W) x 72 (D) x 30 (H) / each
Weight(g) 90 / each
Chassis Material Aluminum
Silkscreen Color
Silver
Power Consumption TX: 3.5w ; RX: 2w
Operating Temperature 0˚C ~ 40˚C / 32˚F ~ 104˚F
Storage Temperature -20˚C ~ 60˚C / -4˚F ~ 140˚F
Relative Humidity 20~90% RH (non-condensing)
7. Operation Controls and Functions
7.1 Front Panel
CH-107TX CH-107RX
① ②
DC 5V
HDMI INPUT
② ③
DC 5V
HDMI OUT
①
HDMI INPUT: This slot is where you connect the HDMI or DVI output
port of your source device such as a DVD player or Set-top-box with an
HDMI cable or connect the unit to another unit from the same product
family to extend your transmission over long distances.
②
DC 5V: This slot is where you plug the 5V DC power supply into the unit
and connect the adaptor to an AC outlet.
3
③
HDMI OUTPUT: This slot is where you connect the HDMI or DVI input port of
your display such as an HDTV/HD monitor or connect it to another
transmitter from the same family in order to extend your transmission over
long distances.
7.2 Rear Panel
CH-107TX CH-107RX
①
CAT6 OUT
①
CAT6 IN
①
CAT6 OUT/IN: Connect the CAT6 output of the transmitter with a CAT6
cable to the CAT6 input of the receiver.
Note:
A. Cable tested with CAT-6E/23AWG/Solid, using cables of another type
may result in a different operating distance.
B. Equipment used in cable distance testing included: PS3 20G, 37" Philips
8 bit LCD TV and 40" Samsung 12 bit LCD TV.
C. Figures provided in this manual are for reference only, actual
performance may depend on the source and display used along with
the type of cable.
8. Connection and Installation
DVD
HDMI
Cable
HDMI
Cable
CAT6
Cable
LCD TV
CH-107TX CH-107RX
HDMI
HDMI
HDMI
HDMI
4
Acronyms
A
Acronym Complete Term
CAT6 Category 6 Cable
HDMI High-Definition Multimedia Interface
5
20100325 MPM-CH107TX&RX
Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD.
