CAC-Tx&Rx
Active Connect
Multimedia Transmitter
and Receiver Box
Operation Manual
CAC-TX&RX
Revision History
Version No Date Summary of Change
V1 20080929 Preliminary Release
Precaution
Failure to follow the precautions described below may cause damage
to Active Connect Multimedia Transmitter and Receiver Box and void the
warranty.
DO NOT open the case. Doing so will void the warranty. If you find
problem with it, please return back to your retailer or seller who will
assist you or provide you with solution.
DO NOT use third-Party AC adapter or power cord. Doing so may
damage Active Connect Multimedia Transmitter and Receiver Box.
DO NOT bump, jar or drop contents of the products as it may
damage it and result in warranty void.
DO NOT set any liquids or beverages on the drive as they may
damage Active Connect Multimedia Transmitter and Receiver Box.
Active Connect Multimedia Transmitter and Receiver Box’s 5
BNC (Bayonet Nut Connector) cables need to be connected rightly
according to the instruction. Wrongly connection will cause burn
down.
Table of Contents
1
1
1
1
2
3
4
1. Introduction …………………………………………................................
2. Application.............................……………………………………………
3. Contents .............................……………………………………………….
4. System Require ............................………………………………………..
5. Features .............................………………………………………………..
6. Installation ............................……………………………………………..
7. Specication........................................................................................
1. Introduction
Thank you for purchasing Active Connect Multimedia Transmitter and
Receiver Box. Active Connect Multimedia Transmitter and Receiver Box is
an useful device for long distance display of your game/player devices to
your HDMI displayer. It allows distance up to 100M at 1080p/8bit and more
in total for display and support up to HDMI V1.3 specification further, Active
Connect Multimedia Transmitter and Receiver Box’s digital transmit format
makes no delay or loss for images. Active Connect Multimedia Transmitter
and Receiver Box include no firmware inside and therefore, it is easy to install
and simple to operate.
Please follow this manual to begin enjoying the benefit of your Active
Connect Multimedia Transmitter and Receiver Box. We suggest keeping it in
a safe place for future reference.
2. Application
Designed to support long distance HDMI application.
Enable high bandwidth communication over loss media.
Also designed to equalize and restore signals receiver over 75Ωcoaxial
cable.
Simply connected the source to the Transmitter unit and over RGBHV
coaxial cable to the Receiver unit, then HDMI output to the display.
3. Contents
HDMI 5 COAX TX
HDMI 5 COAX RX
Power adaptor x 2
User Manual
BNC to F connectors x 10
4. System Requirements
HDMI input device, RGB*, Clock*, Power* cables, HDMI output device.
*Recommend cables use:
Channel Master®
1
RG6 Type 75Ω coaxial cable (for cable TV) x 5
1080P/8bit →100M
1080P/12Bit→75M
Or
Belden™ 7789A 23 solid AWG and solid 25AWG RGBHV Cable with 5 BNC.
AWG RESOLUTION DISTANCE
23
1080P-8bit 85±5 m
1080P-12bit 60±5 m
25
1080P-8bit 65±5 m
1080P-12bit 40±5 m
Or
Total Technologies, Ltd.© E193793 28 AWG RGBHV Cable with 5 BNC.
AWG RESOLUTION DISTANCE
28
1080P-8bit 45±5 m
1080P-12bit 15±5 m
5. Features
Compliant with HDMI 1.3 and DVI 1.1.
Higher data rates enabling new features and applications.
New and improved color gamut (i.e. deep color xvYCC).
HD audio (8 channel audio support).
High Resolutions from PC (640~480) to WUXGA (1920 x 1200).
HDTV resolutions from 480I~1080P/12 bit.
Built in Consumer electronics control (CEC).
Support Deep Color.
Gigabit digital transport needs:
HDMI 1.3(Category)/DVI(10.2Gb/s).
The RG6 type 75 Ω coaxial cables can run up to 100m at 10.8Gb/s.
HDMI 5 COAX RX power setting (externally/internally).
Support seamless for VESA DDC, CEC and Hot Plug Detect (HPD).
Support xvYCC.
Easy to install and simple to operate.
2
1 Connect one of the power adaptors to Active Connect multimedia
Transmitter Box and plug in the power. May also plug the other adaptor to
Active Connect Multimedia Receiver Box.
2 Switch the power selection on Active Connect Multimedia Receiver Box
to INT without adaptor connection or EXT and connect the other adaptor
with plug in power. (Suggest using external power supply when long
distance cables are used).
3 Connect your HDMI input device (Blue-Ray DVD or PS3) to Active Connect
Multimedia Transmitter Box with HDMI cable (Suggest to use HDMI cable
under 1M for quality performance).
6. Installation
Please follow the step-by-step instruction below to install your Active Connect
Multimedia Transmitter and Receiver Box.
1
DC 6.5V
LINK
HDMI INPUT
CAC-TX
HDMI 5 COAX TX
7 3
LINK
HDMI OUTPUT
CAC-RX
HDMI 5 COAX RX
DC 6.5V
POWER
EXT
INT
1
7 6
2
R
G
B
CLK
PWR
4 5
4 Connect BNC-F connectors to both sides of the 5 cables.
5 Connect RGB, Clock, and Power with 75Ω cables accordingly to Active
Connect Multimedia Transmitter and Receiver Box. MAKE SURE TO
CONNECT RIGHTLY ACCORING TO THE INSTRUCTION. (Suggest using no
longer than 100Ms cables for 1080P/8bit’s resolution and 75Ms cables for
1080P/12bit’s resolution)
6 Connect HDMI output device (LCD TV or HDMI monitor) to Active
Connect Multimedia Receiver Box with HDMI cable (Suggest to use HDMI
cable under 1M for quality performance).
7 Link’s green led light will light up when all connection is rightly connected
and power on.
3
Blue-ray
PS3
HDMI-Cable
HDMI-Cable
OR
CoaxialX5
HDMI-Cable
Input port 1 HDMI to 5 BNC connectors
Output port 5 BNC connectors to 1 HDMI
HDMI Specification V 1.3
HDMI Resolution 480i~1080p 50/60, 1080p 24, VGA~WUXGA
CEC Function Bypass
HDMI Audio PCM2, PCM 5.1, PCM 7.1, Dolby 5.1, DD+, D-TruHD,
DTS-HD
Color Space RGB 24~36, Y444 24~36, Y422 16~24
Deep Color 1080P/12bit
HDMI Cable In 1080p/8bit up to 3M, 1080p/12bit up to 1M
HDMI Cable Out 1080p/8Bit up to 15M, 1080p/12bit up to 1M
RF Cable 1080p/8bit up to 100M, 1080p/12bit up to 75M
Power Supply 6.5V/2ADC (US/EU standards, CE/FCC/UL certified)
Dimensions (mm) 125mm x 110mm x 30mm/pc
Weight(g) 270g/pc
Chassis Material Aluminum
Silk Skin Color Black
Operating Temperature Operating from 0°C ~ 40°C
Power Consumption TX: 1.9W; RX:2.2W
7. Specications
4
20081013 MPM-CACRX&TX
Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD.
