Cycliq FLY12 CE122 User Manual

Fly12 CE122 Instruction Manual

CE122

What you get

Features

What’s in the box

Video resolution

Functions

Electronic image stabilisation

Changing your Fly12 CE settings

High dynamic range

Registering your Fly12 CE

Looping function

Manual footage capture

Read this before your set-up your Fly12 CE122

Incident protection function

Disclaimer

HomeSafe™ function

Warning against copyright infringement

Bike alarm

Safety, operating and care information

Idle mode

Caution

Charging on the fly

Fly12 CE layout

Cycliq Quick Release System™

Nanotechnology

Setting up your Fly12 CE122

Dashcam mode

Charging the battery

Heat protection

Battery level indicator

Master reset

Formatting your microSD card

Inserting and removing microSD Card

Using your footage

Mounting your Fly12 CE122

Accessing your footage

Video segment length

Using your Fly12 CE

Editing footage

Turning on your Fly12 CE

The CycliqPlus mobile app

Turning off your Fly12 CE

Join the Cycliq community

Light mode settings

Technical data

Visual and audible alerts summary

FCC compliance statement

Audio settings

IC compliance statement

Airplane mode

Regulatory information

Garmin Connect IQ app – CycliqPlus Connect

FLY12 CE122 – User Manual

What you get

1 x Fly12 CE122

1 x Tapered rubber handlebar adapter

1 x Handlebar mount including 2.5mm hex bolt

1 x Quick start guide

1 x Universal mount adapter

1 x Safety information and warranty sheet

1 x M5 screw for universal mounting adapter

1 x USB to USB-C cable 1 x 22.2mm rubber handlebar adapter

1 x Safety tether

What’s in the box

FLY12 CE122 – User Manual

Functions

Full HD video and stereo audio recording Multiple light modes Looping recording for set and forget use Incident protection technology 6-axis image stabilisation HomeSafe™ function Bike alarm Idle mode Audio recording Ultra-wide viewing angle Audible status alerts Bluetooth and ANT+ connectivity

FLY12 CE122 – User Manual

Changing your Fly12 CE settings

Most of the primary functions of the Fly12 CE can be controlled using the buttons on the side of the device.

Summary

1. On the Fly12 CE device All primary functions can be accessed using the two buttons on the device.

2. On the CycliqPlus mobile app There are other settings and features that are only accessible via the CycliqPlus mobile app (iOS and Android). Please download this from the App Store or Google Play.

3. On your PC or Mac This option offers similar functionality to the CycliqPlus mobile app. It is accessible on your PC or Mac

when you plug your Fly12 CE into your computer using the supplied USB cable. Alternatively insert your microSD card into your computer’s microSD card reader.

Attention: Garmin users, an important note.

You can use your compatible Garmin bike computer to adjust some functions of the Fly12 CE. Our CycliqPlus Connect app (different from the CyclicPlus mobile app) will allow you to change light modes, flashing sequences, check the battery level of your Fly12 CE and turn the device on and off from your compatible Garmin bike computer. See Garmin Connect IQ information on page 20.

To download our CycliqPlus Connect app, go to apps.garmin.com or visit Connect IQ via your Garmin device.

FLY12 CE122 – User Manual

Registering your Fly12 CE

We strongly advise that you register your Fly12 CE with Cycliq. Once registered, you’ll receive any notifications of new software or firmware updates, new features and user tips. Registration also speeds up the process should you require assistance with technical support or warranty queries.

To register your device, either visit cycliq.com/register, use the CycliqPlus mobile app.

Read this before you set-up your Fly12 CE122

Disclaimer

Fly12 CE122 is designed specifically to be used as a front light with video and audio capabilities for bicycles. While every effort has been made to ensure it will fit most bicycles on the market, it may not fit all bicycles, depending on how the bike is set up.

Please note that Cycliq, its subsidiaries and affiliates, and its distributors are not liable for any consequential damages arising from any malfunction of the device, including memory cards.

Warning against copyright infringement

The images recorded with this camera are intended for personal use. Do not record images that infringe upon copyright laws without the prior permission of the copyright holder. Please be advised that in certain cases the copying of images from performances, exhibitions, or commercial properties by means of a camera or other device may contravene copyright or other legal rights even if the image was shot for personal use.

FLY12 CE122 – User Manual

Safety, operating and care information

Following is important information which relates to the safe operation and care of your Fly12 CE. For

more information, please read your ‘Safety Information & Limited Warranty Guide’ contained in your accessory box or visit cycliq.com for more information.

Caution

• Warning! No modification of this device is allowed.

• The Fly12 CE is not a toy: children should not play with the device.

• Do not look directly at the LED lights when operating.

• Avoid dropping or knocking the Fly12 CE in any way.

• Pay attention and care when closing the waterproof port door. Please ensure it is closed completely prior to

operation (unless using in dashcam mode, then see below on page 26).

• Cycliq does not accept any liability for damage caused by non-compliance with these instructions or any

other improper use or mishandling.

• The Fly12 CE has a lithium ion battery. When disposing of this, it should be done in compliance with the laws, rules

and regulations of your relevant local authorities.
