Cycle Torch MicroBot User Manual

User Manual EN

MicroBot

Taillight

1

III.

If for any reason you are not satisfied, please contact us as soon as
possible at: [e-mail] , so that we can work with you to
solve whatever issues!

Thank you for purchasing one of our products !!!

We are truly honored to be able to serve you and provide you with the best

Experience possible. If you’ve enjoyed our product, we would sincerely appreciate

your honest feedback.

To insure maximum experience and safety, familiarize yourself with ALL

aspects of your new taillight and battery system:

I. Safety precaution .......................................................................................... 3

II. How to mount the MicroBot ........................................................................ 3

III. How to charge the MicroBot ......................................................................... 4

IV. Switching the lighting modes ........................................................................ 5

V. Model Specifications...................................................................................... 5

VI. Warranty, Support and Customer Service .................................................... 6

2

I. Safety Precaution

III.

side (A)

side (B)

1. Never look directly into the MicroBot;

2. Do not place it within children’s reach;

3. Before your trip, please make sure that the MicroBot is firmly mounted to the
seat post, it lights up, and the light is not blocked by baggage;

5. This product is waterproof under normal daily use and can be used in the
rain. However, do not intentionally submerge it in water.

Failure to follow these cations may expose you to risks, can cause

damage to the light system and will void the warranty !

A lighting system can make riding safer and you more visible, but lights are no
substitute for common sense. Ride within your capability with consideration for
the riding environment.

This product contains components that must be recycled per EU Directive
2002/96/EC and may not be disposed as unsorted municipal waste!

ll. How to mount MicroBot:

1. Attach the rubber strip to the side A of the MicroBot’s clips;

2. Hold the MicroBot with one hand and with another hand secure it with the

rubber strip across the seat post, and fix the rubber strip to the side B;

3. For further details, click the link and watch the VIDEO.

3

III. How to charge MicroBot

III.

WARNING: The cable (or other accessories) supplied with the Cycle Torch bike

light MUST be used only to charge the Cycle Torch bike light. The Manufacture

or/and the Seller are not responsible for any damage caused by using the supplied

accessories with other devices, other than Cycle Torch bike lights.

Operation/Power

Button

micro USB port

How to charge:

1. Remove the rubber cap at the bottom of MicroBot;

2. Connect the MicroBot to your PC or a 5V USB battery charger with the USB

cable. The Power Button lights up RED, and charging starts;

3. When the Power Button lights up BLUE, charging is complete. Remove the USB cable;

4. Full charging time: 1 hour 30 minutes

Tips and tricks:

1. When your PC is in sleep state, the MicroBot cannot be charged;

2. Flashing light of the Power Button shows that a charging error has occurred.

Remove and reinsert the USB cable, then begin the recharge process again;

3. Charging and lighting times are approximate values, and will vary by

environmental and user conditions.

4

IV. Switching the lighting modes

Operating modes:

quick flash

slow flash

C.F. quick

C.F. slow

steady

Run time (in hours)

6 9 10

14

1,5

Power (in lumens)

25

25

10

10

25

III.

Operation Modes: Short press of the power button will switch through cycles

& shut down the MicroBot. The initial short press of the power button will turn on
the light on High mode. Each additional short press of the power button switches
the light from one mode to the next, in the following order: (1) quick flash; (2) slow

flash; (3) circular flash quick; (4) circular flash slow; (5) steady; (6) OFF.

To turn off the MicroBot, press and hold the power button for about three
seconds.

Low Battery Level: The MicroBot will automatically turn off when the
battery level is too low. This system protects the battery from damage, but since
it draws a small amount of current, and can drain the battery beyond the
minimum voltage for the battery.

Do not wait until the MicroBot goes completely out as this will greatly
reduce the number of charge cycles that the battery can be used and can
render the battery unusable. It is highly recommended to recharge periodically
the MicroBot.

Charge your bike light each 2-3 months when stored or not in use to
prevent battery degradation.

V. Model Specifications

 Model range: MicroBot
 Water-resistant rear tail light brightness: 25 LM
 Waterproof Grade: IP65
 Light Source: 3 x 3535 LED ultra lumineux
 LED lifespan: 50,000 hours
 Low power consumption

5

 Battery: lithium-polymère rechargeable

III.

For further information concerning warranty conditions or for any
additional issues, please e-mail us at: [e-mail]

 Charge time: 1 hour 30 minutes
 Material: top-class nylon plastic (ABS), weighing only 16 g
 Finish: black

VII. Warranty, Support and Customer Service

To register you product please go to http://cycletorch.com and follow the steps.
Our product quality is controlled strictly in accordance within the standards

of CYCLE TORCH quality certification program.

To ensure that all users enjoy the product, we offer one year warranty
within one year from purchase date, under normal use, the consumer will be
provided free warranty service for any quality related problems!

When requesting warranty service, customer should present Order ID .

Warranty Service Exclusions:

A) Any damages that are caused by other than normal use, including, but not
limited to physical damages.

B) Any user modification, repairs or disassembly of the product without
factory authorization.

C) Missing warranty Registration.
