Cybex Eagle® Incline Pull

Owner’s and Service Manual

Strength Systems

Part Number 11020-999 J

www.cybexinternational.com

Cybex Eagle® Incline Pull

Owner’s and Service Manual

Strength Systems

Part Number 11020-999 J

Cybex® and the Cybex logo are registered trademarks of Cybex International, Inc.

Eagle

and its mark are registered trademarks of Cybex International, Inc.

DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or changes.

10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX 508-533-5183 www.cybexinternational.com • techhelp@cybexintl.com • 11020-999 J • March 2010

Table of Contents

1 Safety

Safety. . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Warning/Caution Decals . . . . . . . . . . . 1-2

Regular Maintenance Activities . . . . . . 1-5

Using Proper Form . . . . . . . . . . . . . . . 1-5

2 Exercises

General Exercise Guidelines . . . . . . . . 2-1

3 Customer Service

Contacting Service. . . . . . . . . . . . . . . . 3-1

Ordering parts . . . . . . . . . . . . . . . . . . . 3-1

Return Material Authorization (RMA). . 3-1

Damaged Parts . . . . . . . . . . . . . . . . . . 3-2

4 Assembly

Assembly . . . . . . . . . . . . . . . . . . . . . . . 4-1

5 Maintenance

Daily Procedures . . . . . . . . . . . . . . . . . 5-1

Weekly Procedures . . . . . . . . . . . . . . . 5-4

Yearly Procedures . . . . . . . . . . . . . . . . 5-6

Environment. . . . . . . . . . . . . . . . . . . . . 5-7

Storage . . . . . . . . . . . . . . . . . . . . . . . . 5-7

6 Service

Parts Lists . . . . . . . . . . . . . . . . . . . . . . 6-4

Exploded-View Diagram . . . . . . . . . . . 6-5

Page i

Cybex Eagle 11020 Incline Pull Owner’s Manual

1 - Safety

Safety

Read the Owner’s Manual carefully before assembling, servicing or using the equipment. It is the responsibility of the facility owner and/or owner of the equipment to instruct users on proper operation of the

equipment and review all labels.

WARNING: Serious injury could occur if these safety precautions are not observed:

User Safety Precautions

Obtain a medical exam prior to beginning an exercise program.• Read and understand warning labels and user manual prior to exercising. Obtain instruction •

prior to use. Keep body and clothing free from and clear of all moving parts.• Inspect machine prior to use. • DO NOT use if it appears damaged or inoperable. DO NOT • attempt to ﬁ x a broken or jammed machine. Notify ﬂ oor staff. Use the machine only for the intended use. • DO NOT modify the machine. Be sure that the weight pin is completely inserted. Use only the pin provided by the manufacturer. •

If unsure seek assistance. Never pin the weights in an elevated position. • DO NOT use the machine if found in this condition.

See assistance from ﬂ oor staff. Children must not be allowed near these machines. Teenagers must be supervised.•

DO NOT• use if guards are missing or damaged. DO NOT • use dumbbells or other incremental weights, except those provided by the manufacturer.

Inspect all cables and belts and connections prior to use. • DO NOT use if any components are worn, frayed or damaged.

DO NOT• remove any labeling from equipment. Replace any damaged labels. Stop exercising if you feel faint, dizzy or experience pain at any time while exercising and consult your •

physician.

Facility Safety Precautions

Read the Owner’s Manual carefully before assembling, servicing or using the equipment. • Securely anchor each machine to the ﬂ oor using the anchor holes provided in each machine.•

NOTE: Cybex is not responsible for the actual anchoring of equipment. Consult with a professional

contractor.

NOTE: Use fasteners having a minimum of 500 lbs. tensile capacity (3/8” grade 2 bolts or better). NOTE: If legs/frame does not contact surface, DO NOT pull down with anchors. Shim any

leg or frame not in contact with surface using ﬂ at washers.

Safety

Page 1-1

Cybex Eagle 11020 Incline Pull Owner’s Manual

Make sure that each machine is set up and operated on a solid level surface. • Do not install equipment on an uneven surface.

Make sure that all users are properly trained on how to use the equipment.• Make sure there is enough room for safe access and operation of the equipment. • Perform regular maintenance checks on the equipment. Also pay close attention to all areas most susceptible to wear, •

including (but not limited to) cables, pulleys, belts and grips. Immediately replace worn or damaged components. If unable to immediately replace worn or damaged components •

then remove from service until the repair is made. Use only Cybex supplied components to maintain/repair the equipment.• Keep a repair log of all maintenance activities.• Inspect all cables and belts and connections prior to use. • DO NOT use if any components are worn, frayed or

damaged.

NOTE: It is the sole responsibility of the user/owner or facility operator to ensure that regular maintenance is performed.

Safety Guidelines And Practices

Cybex recommends that all ﬁ tness equipment be used in a supervised area. It is recommended that the equipment be located in an access controlled area. Control is the responsibility of the owner. The extent of control is at the discretion of the owner.

It is the responsibility of the purchaser/user of Cybex products to read and understand the owner’s manual, and warning labels; as well as instruct all individuals, whether end users or supervising personnel, on proper usage of the equipment.

PROPER USAGE:

Use machine only as described in the manual. Failing to follow proper instructions may result in injury. Do Not Lean Against or Pull On the framework, weight stack, or any component, whether machine is at rest or in use.

Inappropriate or improper use may result in injury to users or third parties (bystanders). Do not use machine if it is not located on a solid level surface or is improperly installed. Provide an adequate safety perimeter between the machine, walls and other equipment to ensure that the facility has the

proper clearance for usage and training.

SECURING EQUIPMENT:

The machine has holes in the feet, which allow for ease in anchoring to the ﬂ oor. Cybex strongly recommends that, to eliminate rocking, tipping or falling over due to incorrect usage and misuse, equipment be secured to a solid, level surface.

1. The solid, level surface should not deviate more than 1/8” over a 10’ distance or as deﬁ ned and required by local building and architectural codes.

2. Anchoring of equipment must be completed by a qualiﬁ ed licensed contractor.

Safety Page 1-2

Cybex Eagle 11020 Incline Pull Owner’s Manual

3. Anchoring holes are provided on the feet of the frame. All anchoring locations must be used when anchoring the equipment to the ﬂ oor.

4. Due to the wide variation of ﬂ ooring on which machines may be anchored or installed, verify anchoring method and anchoring fasteners with a qualiﬁ ed and licensed contractor.

5. A minimum pull out force of 220 lbs/100 kgs is required for each anchor position..

6. Do not use machine until it is properly anchored. MAINTENANCE:

Preventative maintenance allows proper equipment operation and reduces the risk of injury. Perform the maintenance requirements as speciﬁ ed in the manual.

STANDARD COMPLIANCE:

Cybex products meet or exceed applicable ASTM and EN Standards.

Warning/Caution Decals

Warning decals indicate a potentially hazardous situation, which, if not avoided, could result in death or serious injury. Caution decals indicate a potentially hazardous situation, which, if not avoided, could result in minor or moderate injury. The warning and caution decals are shown on the following page. The diagrams following the decals show where each

decal is located.

Safety

Page 1-3

Cybex Eagle 11020 Incline Pull Owner’s Manual

CAUTION

Personal injury may occur.

Keep away from moving parts to avoid injury.

CAUTION

Seat may fall if improperly engaged.

4000Y316-4

4605-381-4 A

Verify seat is secure before exercising to avoid injury.

4520-362-4

CAUTION

Keep away from moving parts. Failure to do so could result in personal injury.

8500-026-4

Safety Page 1-4

Cybex Eagle 11020 Incline Pull Owner’s Manual

Incline Pull - 11020

DESCRIPTION PART NO.

Warning LabelA. ................4605-381-4

CB. aution Decal .................4000Y316-4

Caution DecalC. .................4520-362-4

Caution Decal.................8500-026-4D.

Safety

Page 1-5

Cybex Eagle 11020 Incline Pull Owner’s Manual

Regular Maintenance Activities

Preventative maintenance activities must be performed to maintain normal operation of your equipment. Keeping a log sheet of all maintenance actions will assist you in staying current with all preventative maintenance activities. The preventative maintenance actions are described in detail in Chapter 5. Brieﬂ y, they include:

Daily

1. Clean upholstery. Weekly

1. Inspect all nuts and bolts for looseness. Tighten as required.

2. Inspect all cables and belts for damage or wear (see Chapter 5).If a cable or belt is worn or

damaged, immediately discontinue use until cable or belt has been replaced.

3. Check for worn handles, worn snap links, and worn warning labeling. Replace all worn parts

immediately.

4. Inspect for loose or worn grips. Replace all loose or worn grips immediately.

5. Inspect weight stacks for proper alignment and operation. Correct all improper alignment and

operation issues immediately.

6. Lubricate guide rods using automotive engine oil only. Yearly

1. Replace all cables and belts at least annually.

Using Proper Form

Before working out, read and understand the exercises located on the placard and in Chapter 2.

Safety Page 1-6

Cybex Eagle 11020 Pulldwn Owner’s Manual

2 - Exercise

Intended Use

The intended use of this equipment is to aid or improve general physical ﬁ tness and exercise. For Commercial use.

Instructions

Read and understand all instructions and warnings prior to using this machine. See Chapter 1, Safety in the Eagle Owner’s Manual or consult with ﬂ oor staff.

START FINISH

MUSCLES USED

Latissimus Dorsi, Teres Major, Rhomboid,

Posterior Deltoid, Lower and Middle

Trapezius, Biceps (basic movement)

Triceps (advanced movement)

NOTE: Motions Developed: Shoulder Adduction, Elbow Felxion, Elbow Extension

NOTE: Do not turn knob when weight stack is elevated NOTE: All adjustment points on the machine have yellow handles or knobs. NOTE: See next page for “Set Up” and “Movement”.

Exercise Page 2-1

Cybex Eagle 11020 Pulldown Owner’s Manual

Set Up

1. Adjust seat for desired reach angle with ﬁ ngers tip reach..

2. Adjust chest pad for desired support.

3. Grasp handles. Basic Movement

1. Pull handles down until elbows are by your sides and your hands are

approximately level with shoulders.

Advanced Movement

1. While pushing the handles outward, pull down until your elbows are even with your back.

Exercise Page 2-2

Cybex Eagle 11020 Incline Pull Owner’s Manual

3 - Customer Service

Contacting Service

Hours of phone service are Monday through Friday from 8:30 to 6:00 p.m. Eastern Standard Time. For Cybex customers living in the USA, contact Cybex Customer Service at 888-462-9239. For Cybex customers living outside the USA, contact Cybex Customer Service at 508-533-4300

or fax 508-533-5183.

Find information on the web at www.cybexintl.com or by e-mail at techhelp@cybexintl.com.

Ordering Parts

Fax order to 508-533-5183. To speak with a customer service representative, call 888-462-9239 (for customers living within the USA) or 508-533-4300 (for customers outside the USA). You may also contact us through e-mail at techhelp@cybexintl.com

Having the following information ready when calling will assist our Cybex representatives in serving you.

Unit Serial Number

•

Product Name•

The unit serial number and product name can be found on the serial number decal. See Chapter 6 for exact location of serial number decal.

Part Description• Part Number•

Part descriptions and part numbers are located in Chapter 6 of this manual.

Shipping Address

•

Contact Name•

Return Material Authorization (RMA)

In addition to your shipping address and contact name, your account number is helpful but not required. The Return Material Authorization (RMA) system outlines the procedures to follow when returning

material for placement, repair or credit. The system assures that returned materials are properly handled and analyzed. Follow the following procedures carefully.

Contact your authorized Cybex dealer on all warranty-related matters. Your local Cybex dealer will request a RMA from Cybex, if applicable. Under no circumstances will defective parts or equipment be accepted by Cybex without proper RMA and an Automated Return Service (ARS) label.

Customer

Service

Page 3-1

Cybex Eagle 11020 Incline Pull Owner’s Manual

1. Call the Customer Service Hot Line listed above for the return of any item that is defective.

2. Provide the technician with a detailed description of the problem you are having or the defect in the item you wish to return.

3. Provide the model and serial number of your Cybex equipment.

4. At Cybex’s discretion, the technician may request that you return the problem part(s) to Cybex for evaluation and repair or replacement. The technician will assign you a RMA number and will send you an ARS label. The ARS label and the RMA numbers must be clearly displayed on the outside of the package that contains the item(s) to be returned. Include the description of the problem, the serial number of the equipment and the name and address of the owner in the package along with the part(s).

5. Forward the package through UPS to Cybex.

Attn: Customer Service Department Cybex International, Inc. 1975 24th Ave SW

Owatonna, MN 55060

NOTE: Merchandise returned without an RMA number on the outside of the package or shipments sent

COD will not be accepted by the Cybex receiving department.

Damaged Parts

Materials damaged in shipment should not be returned for credit. Shipping damages are the responsibility of the carrier (UPS, Federal Express, trucking companies, etc.)

Apparent Damage - Upon receipt of your shipment, check all items carefully. Any damage seen with a visual check must be noted on the freight bill and signed by the carrier’s agent. Failure to do so will result in the carriers refusal to honor your damage claim. The carrier will provide you with the required forms for ﬁ ling such claims.

Concealed Damage - Damage not seen with a visual check upon receipt of a shipment but notices later must be reported to the carrier as soon as possible. Upon discovery of the damage, a written or phone request to the carrier asking them to perform an inspection of the materials must be made within ten days of the delivery date. Keep all shipping containers and packing materials as they will be needed in the inspection process. The carrier will provide you with an inspection report and the necessary forms for ﬁ ling a concealed damage claim. Concealed damage claim is the carrier’s responsibility.

Customer Service Page 3-2

Cybex Eagle 11020 Incline Pull Owner’s Manual

4 - Assembly

TOOLS REQUIRED

7/32” Allen Wrench • 3/4” Allen wrench• 9/16” Wrench• External snap ring pliers• Phillips Screwdriver• Medium weight automotive engine oil• Torque Wrench•

NOTE: Two people will be required for this procedure. NOTE: It is the responsibility of the facility owner/owner of the equipment to ensure that

there is appropriate clearance around each machine to allow for safe use and passage.

1. Read and understand all instructions thoroughly before starting any of the procedures listed on this instruction sheet.

2. Verify you have received the appropriate conﬁ guration.

Verify that you received the correct color machine that you ordered.A. Verify you received weight plates and weight plate decals.B. Verify you received the Cybex Eagle Incline Pull Owner’s Manual. C. Verify you received the warranty sheet.D.

3. Move to desired location.

Note the diminsions of the machine:A. Idle - 66 L x 47 W x 62 H inches

167.64 L x 119.38 W x 157.48 H cm In use - 66 L x 58 W x 62 H inches

167.64 L x 147.32 W x 157.48 H cm Machine Weight with weight stack - 644 lbs. (292.11 kg)

Determine if you can move your machine through the required doorway(s).B. If the machine ﬁ ts through the the doorway(s), move machine to desired location and skip to step 5. C. If weight stacks need to be installed proceed to step 6.D. If the machine does not ﬁ t through the door-way(s) then see step 4. E.

4. Doorway Instructions.

NOTE: If your machine ﬁ ts through the doorway then skip step 4.

If your machine does not ﬁ t through the doorway, then perform step 4.

Carefully remove each (standard) cone-shaped shipping support using a 3/4” socket or wrench.A. Make a note of the current belt routings and connections. This will assist you in reinstalling them properly. B. Cut shipping tie securing top weight.C.

Assembly

Page 4-1

Cybex Eagle 11020 Incline Pull Owner’s Manual

Rotate cam and disconnect weight stack belt from cam D. (by loosening the two set screws on the belt clamp with a 7/32” Allen wrench). See Figure 1.

Locate the pulley bracket that is located near the cam. E. See Figure 2.

Cam

Set Screws

Remove bolt, washer and hex nut securing the pulley to F.

Figure 1

the pulley bracket. Remove pulley from pulley bracket.G. Remove one of the two BHSCS (Button Head Socket Cap Screws) H.

securing the pivot shaft. See Figure 3. Carefully remove pivot shaft and pulley shaft. See Figure 3. I. NOTE: Be extremely

careful when removing shaft so you don’t ruin the threads on the shaft.

With an assistant, carefully remove the ﬁ ve BHSCS J. securing the two halves of the frame. See Figure 4.

Carefully move each half through the door-way to the K. desired location.

With an assistant, carefully attach each half together L. using the ﬁ ve BHSCS removed in step 4J. See Figure 4.

Carefully attach pulley shaft using the pivot shaft and M.

BHSCS

Washer

Pulley Shaft

BHSCS removed in steps 4H and 4I. See Figure 3. Reconnect pulley/cable to pulley bracket (removed in N.

steps 4F and 4G). Verify both cables are routed properly.O.

Figure 3

Cam Bolt

Figure 2

Pulley/Cable

Pivot Shaft

Nylon Locknut

Washer

Connect the weight stack belt to the belt clamp of cam P. (removed in step 4D). See Figure 1.

Continue on with Step 5C.Q.

5. Remove shipping feet and remove the back shrouds.

Carefully remove each (standard) cone-shaped A. shipping support (using a 3/4” socket or wrench).

Cut shipping tie securing top weight.B. Carefully place rubber feet (supplied with machine) C.

on each foot of the frame. Lift top weight and turn the Increment Weight Adjusting D.

Knob to select all 15 lbs. (three increment weights each side).

Remove the three Phillips head screws securing the E. top (back) shroud and carefully remove the shroud. See Figure 5.

Assembly Page 4-2

BHSCS (qty 3)

Figure 4

Figure 5

Nylon Locknut (3)

Nylon Locknut (2)

BHSCS (qty 2)

Phillips Head Screw (3)

Cybex Eagle 11020 Incline Pull Owner’s Manual

Loosen bottom two screws shown in Figure 6. F. NOTE: Do not remove the bottom two screws.

Remove the top two screws securing the back shroud. See Figure 7.G. Carefully slide rear shroud assembly upward and remove.H.

6. Install the weight stack.

Note how the increment weights are installed.A. With an assistant holding the increment weights, B.

move the adjusting knob to 0 lbs. and remove all six increment weights (three each side).

Using an external snap ring pliers, remove the upper C. snap ring from one of the guide rods and carefully lower the guide rod. See Figure 8.

Remove lower snap ring and wave washer from the guide D. rod. Repeat steps 6C and 6D to remove both snap rings from other guide rod.

If possible, lean guide rods outward, away from E. machine in order to provide the most room for installing weight plates.

Slide top weight up and out of machine and carefully set F. it aside.

Wipe guide rods clean over entire length. Lubricate with light coating of medium weight automotive G. engine oil.

Figure 7

Guide rod

Figure 8

Frame

Screw (loosen do not remove)

Figure 6

Screw

Upper snap ring

Wave washer

Lower snap ring

Carefully install each weight plate one at a time. H. NOTE: When installing weight plates, position plates so wide edges of bushing face upward and narrow edges of bushing face downward. See Figures 9A and 9B.

CORRECT

WRONG

NARROW

WIDE bushing

bushing edge

edge faces

upward

Figure 9A Figure 9B

Slide top weight onto guide rods.I. Place lower snap ring and wave washer onto guide rod (about 3” from the top end of guide rod).J. Raise guide rod up through mounting hole and install the upper snap ring.K.

NOTE: The narrow bushing

edge must face downward.

Assembly

Page 4-3

Cybex Eagle 11020 Incline Pull Owner’s Manual

Lower guide rod and secure lower snap ring. Repeat L. steps 6J - 6L for the other guide rod.

7. Belt Routing.

Verify belt is routed through top of pulley bracket A. and then route end of belt down to the top weight.

Carefully lift top weight and verify that the position of B. the belt clamp (on the top weight) is aligned properly with the top pulley bracket (on the machine). See Figure 10.

Slide belt through slot in belt clamp.C. Verify belt and insert are installed properly, as shown in D.

Figure 11A. NOTE: Do not install the insert backwards

as shown in Figure 11B.

Pull belt tight and secure belt to clamp with the two E. set screws. See Figure 12. NOTE: Torque set screws

300-350 in./lbs.

Place weight stack pin in each plate to verify proper F. installation.

Without selecting any resistance, lift top weight up G. and down (simulating normal operation).

Insert and Set Screws (not

Belt

shown) are on this side.

Increment Weight Adjusting

Top Pulley

Knob

Figure 10 (top view from pulley down to belt clamp)

Correct belt routing Wrong belt routing

Insert

Belt

Stem

Figure 11A

Belt

Stem

Figure 11B

Belt clamp insert

Belt

Have an assistant verify that the belt is moving smoothly and is H. routed straight from the top pulley bracket to the to weight belt clamp.

Reinstall the six increment weights that were removed I. in step 6B. See Figure 13.

Turn the Increment Weight Adjusting Knob to select J. all 15 lbs.

8. Install back shrouds.

Carefully place shroud back into position on the A. two bottom screws. See Figure 14.

Belt clamp

Set screws

Figure 12

Grooves

Increment Weights

Figure 13

Assembly Page 4-4

Screw

Figure 14

Cybex Eagle 11020 Incline Pull Owner’s Manual

180

81.0

144.0

135.0

126.0

117.0

108.0

200

99.0

90.0

300

280

260

240

220

320

340

153.0

180.0

360

171.0

162.0

400

380

9.0

72.0

63.0

54.0

45.0

36.0

18.0

140

120

100

160

Install the top two screws securing the back shroud. B. See Figure 15.

Install the three Phillips head screws securing the C. top (back) shroud. See Figure 16.

9. Install weight plate decals.

NOTE: You have the option to use pounds, kilograms

or both.

Slowly and carefully peel off back side of decal.A. See Figure 17. NOTE: When peeling off back cover,

make sure that the decals remain attached to the front sticker.

Align holes in decal with appropriate holes in weight B. stack. NOTE: Do not allow the adhesive to touch

weight stack at this time.

Insert a guide pin through each hole of the template. C.

NOTE: A guide pin can be anything that ﬁ ts through the weight stack hole, such as a weight stack selector pin.

Carefully align decal and rub it onto weight plates. D. Carefully remove front side, leaving decals adhering E.

to weight plates. See Figure 18.

NOTE: It is important that you perform regular inspection

and maintenance activities on your equipment. See the CYBEX Eagle Owner’s Manual for inspection and maintenance activities. If you do not have a CYBEX Eagle Owner’s Manual or if you have any questions or concerns, call CYBEX Customer Relations at 888-462-9239.

Screw

Figure 15

Phillips Head Screw (3)

Figure 16

Front

Back

Figure 17

Guide Rod

10. Verify proper operation

11. Anchor machine to the ﬂ oor.

Securely anchor machine to the ﬂ oor using the A. anchor holes provided in each machine.

NOTE: Cybex is not responsible for the actual anchoring of

equipment. Consult with a professional contractor.

NOTE: Use fasteners having a minimum of 500 lbs. tensile

capacity (3/8” grade 2 bolts or better).

NOTE: If legs/frame does not contact surface, DO NOT pull

down with anchors. Shim any leg or frame not in

contact with surface using ﬂ at washers.

Weight Stack

Kilograms

Pounds

Figure 18

Assembly

Page 4-5

Cybex Eagle 11020 Incline Pull Owner’s Manual

This page intentionally left blank.

Assembly Page 4-6

Cybex Eagle 11020 Incline Pull Owner’s Manual

Chapter 5 - Maintenance

All preventive maintenance activities must be performed on a regular basis. Performing routine preventive maintenance actions can aid in providing safe, trouble-free operation of all Cybex Strength Systems equipment.

NOTE: Cybex is not responsible for performing regular inspection and maintenance actions for your machines. Instruct all personnel in equipment inspection and maintenance actions and also in accident reporting/recording. Cybex phone representatives are available to answer any questions or concerns that you may have.

NOTE: All inspections and repairs must be performed by trained service personnel only.

Cybex will void warranty if non-Cybex replacement parts are used.

Daily Procedures

1. Upholstery - Wipe down all upholstery as per the recommendations listed below for light

soiling and more difficult stains. Light Soiling

• A solution of 10% household liquid dish soap with warm water applied with a soft damp cloth.

• If necessary, a solution of liquid cleanser and water applied with a soft bristle brush. Wipe away the residue with a water dampened cloth.

Maintenance

Page 5-1

Cybex Eagle 11020 Incline Pull Owner’s Manual

More Difficult Stains

• Dampen a soft white cloth with a solution of 10% household bleach (sodium hypochlorite), 90% water. Rub gently. Rinse with a water dampened cloth to remove bleach concentration.

• The same procedure can be used with full strength household bleach, if necessary.

• Allow bleach to puddle on the affected area or apply with a soaked cloth for approximately 30 minutes. Rinse with a water dampened cloth to remove any remaining bleach concentration.

Alternative Method for Difficult Stains

• Dampen a soft white cloth with rubbing alcohol and rub gently. Rinse with a water dampened cloth to remove any remaining rubbing alcohol concentration.

NOTE: To restore luster, a light coat of spray furniture wax can be used. Apply for 30 seconds and follow with a light buffing using a clean white cloth.

Please Review Carefully When using strong cleaning agents such as rubbing alcohol or bleach, it is advisable to first test in an

inconspicuous area. Other cleaning agents may contain harsh or unknown solvents and are subject to formula changes by the product manufacturer without notice. Should you desire to use other cleaning agents, carefully try them in an inconspicuous area to determine potential damage to the material. Never use harsh solvents or cleaners which are intended for industrial applications. To clean stained or soiled areas, a soft white cloth is recommended. Avoid use of paper towels.

Cleaning products may be harmful/irritating to your skin, eyes, etc. Use protective gloves and eye protection. Do not inhale or swallow any cleaning product. Protect surrounding area/clothing from exposure. Use in a well ventilated area. Follow all product manufacturer’s warnings. CYBEX and its vendors cannot be held responsible for damage or injuries resulting from the use or misuse of cleaning products.

2. Frames - Wipe down all frames using a mild solution of warm water and car wash soap. Be sure to dry thoroughly. AVOID acid or chlorine based cleaners and also cleaners containing abrasives as these could scratch or damage the equipment.

3. Chrome - Clean chrome tubes, first using chrome polish and then using a car wax seal. Neutral cleaners with a pH between 5.5 and 8.5 are recommended. Be sure to dry thoroughly. AVOID acid or chlorine based cleaners and also cleaners containing abrasives as these could scratch or damage the equipment.

Maintenance Page 5-2

Cybex Eagle 11020 Incline Pull Owner’s Manual

4. Guidelines for cleaning front panel:

• Use clean soft cloths or sponges for application of cleaners and again for washing and rinsing.

• Follow up the application with warm water rinse.

• Don’t use abrasives or high alkaline cleaners.

• Don’t leave cleaners on for long periods, wash immediately.

• Don’t apply cleaners in direct sunlight or at elevated temperatures.

• Don’t use scrapers, squeegees or razors.

• Don’t clean with gasoline.

Compatible Cleaners and Detergents:

• Formula 409

• Top Job

• Joy

• Palmolive

• Windex with Ammonia D

To Minimize Fine or Hairline Scratches:

Mild automotive polish applied and removed with a soft, clean cloth will help fill scratches.

Suggested Polishes:

• Johnson Paste Wax

• Mirror Glaze #10 Plastic Polish (by Mirror Bright Polish Co.)

• Novus Plastics Polish #1, #2 (by Novus Inc.)

Maintenance

Page 5-3

Cybex Eagle 11020 Incline Pull Owner’s Manual

Weekly Procedures

1. Check all nuts and bolts for looseness. Tighten as required.

2. Inspect all belts (entire length) for any

non-uniformity and wear.

Immediately replace belt if any of the following conditions are present:

Maintenance Page 5-4

Cybex Eagle 11020 Incline Pull Owner’s Manual

3. Some machines use cables in addition to belts. Inspect all cables for wear or damage and proper tension. When inspecting cables, run your fingers on the cable, paying particular attention to bends

in the cable and attachment points.

Replace all worn cables immediately. The following conditions may indicate a worn

cable:

• A tear or crack in the cable sheath that exposes the cable. See Figure 1.

Figure 1

• A kink in the cable. See Figure 2.

Figure 2

• A curled sheath. See Figure 3.

Figure 3

• “Necking”, a stretched cable sheath. See Figure 4.

Figure 4

Maintenance

Page 5-5

Cybex Eagle 11020 Incline Pull Owner’s Manual

4. Inspect bars and handles for wear, paying particular attention to tab area connecting points.

Replace all worn handles immediately.

5. Inspect snap links for proper latching (indicates wear).

Replace all worn snap links immediately.

. Inspect for loose or worn grips.

Replace all loose or worn grips immediately.

7. Inspect all labeling for readability. This includes instructional placards, warning and caution decals.

Replace all worn labeling immediately.

Inspect all weight stacks for proper alignment and operation.

Correct all improper alignment and operation issues immediately.

9. Wipe Weight Stack Guide Rods clean over entire length. Lubricate with a light coat of medium

weight automotive engine oil.

Yearly Procedures

1. Replace all belts and cables at least annually.

Maintenance Page 5-6

Cybex Eagle 11020 Incline Pull Owner’s Manual

Environment

Static Electricity - Depending upon where you live, you may experience dry air, causing a common experience of static electricity. This may be especially true in the winter time. You may notice a static build-up just by walking across a carpet and then touching a metal object. The same can hold true while working out on your unit. You may experience a shock due to the build-up of static electricity on your body and the discharge path of the unit. If you experience this type of situation, you may want to increase the humidity to a comfortable level through the use of a humidifier.

Humidity - The unit is designed to function normally in an environment with a relative humidity range of 30% to 75%.

NOTE: Do not install or use the unit in an area of high humidity, such as in the vicinity of a steam room, sauna, indoor pool or outdoors. Exposure to extensive water vapor, chlorine and/or bromine could adversely affect the electronics as well as other parts of the machine.

Temperature - The unit is designed to function normally in an environment with an ambient temperature range of 50

Storage

F (10o C) to 104o F (40o C) degrees.

Humidity - The unit can be shipped and stored in an environment with a relative humidity range of 10% to 90%.

NOTE: Do not store the unit in an area of high humidity, such as in the vicinity of a steam room, sauna, indoor pool or outdoors. Exposure to extensive water vapor, chlorine and/or bromine could adversely affect the electronics as well as other parts of the machine.

Temperature - The unit can be shipped and stored in an environment with an ambient temperature range of 32 and 140

F (60o C) degrees.

F (0o C)

Maintenance

Page 5-7

Cybex Eagle 11020 Incline Pull Owner’s Manual

Maintenance Page 5-8

Cybex Eagle 11020 Incline Pull Owner’s Manual

6 - Service

Please refer to the next several pages for parts lists, exploded-view diagrams.

NOTE: All inspections and repairs must be performed by trained service personnel only.

Cybex will void warranty if non-Cybex replacement parts are used.

Service

Page 6-1

Cybex Eagle 11020 Incline Pull Owner’s Manual

This page intentionally left blank

Service Page 6-2

(Both Sides)

Cybex Eagle 11020 Incline Pull Owner’s Manual

INCLINE PULL

PRODUCT NO. 11020

NOTE: See exploded-view diagram for location of J (serial number decal), K (belt), L (cable sub assembly), M (cable sub assembly) and O (Cybex Decal).

DESCRIPTION PART NO.

A. Caution Decal ................... 4000Y316

B. Caution Decal .................... 4520-362

C. Caution Decal .................... 8500-026

D. Warning Decal .................... 4605-381

E. Placard Decal .................... 11020-610

F. Eagle Plaque ...................... 11040-789

G. Chest Pad .......................... 4800-168

H. Seat Pad ........................... 4800-188

DESCRIPTION PART NO.

I. Grip ................................ 4605-507

J. Serial Number Decal

K. Belt ................................ GB000202

L. Cable Sub Assembly ..... 11000-002

M. Cable Sub Assembly ..... 11020-002

N. Weight Selector Pin ....... BH030207

O. Cybex Decal .................. 3900-441

P. Increment Weight Decal. 11000-407

Service

Page 6-3

Cybex Eagle 11020 Incline Pull Owner’s Manual

ITEM QTY PART NO. DESCRIPTION

1 5 08014 PULLEY ASSEMBLY - 4.50 2 1 08229 PIN,DETENT 3 1 11000-002 CABLE S/A 4 1 11000-212 FLOATING PULLEY 5 2 11000-303 SPRING, TORSION 6 2 11000-365 SHAFT, SECONDARY PIVOT 7 6 11000-384 BLOCK, STOP 8 2 11000-389 ENDCAP, BEARING HOUSING 9 4 11000-390 VINYL CAP 10 1 11020-002 CABLE S/A 11 1 11020-200 MAIN FRAME 12 1 11020-201 WEIGHT FRAME 13 1 11020-202 CAM RH 14 1 11020-203 CAM LH 15 1 11020-204 HANDLE RH 16 1 11020-205 HANDLE LH 17 1 11020-207 PULLEY SHAFT 18 2 11010-330 COUNTERWEIGHT 19 1 11020-327 GUARD 20 1 11020-332 SHAFT, CROSS 21 1 11020-333 CAM GAURD 22 1 11020-334 SHIM, STOP BLOCK 23 1 11020-610-X* PLACARD, EAGLE INCLINE PULL 24 1 11020-999-X* OWNER’S MANUAL 25 1 11030-205 SEAT BOTTOM 26 1 11030-206 SEAT BOTTOM LINK 27 1 11040-301 CLAMP BLOCK INSERT 28 2 11040-401 WT ROD .625 X 47.50 29 2 11040-440 KNOB 30 2 11040-750 EXT INC WT CHANNEL 31 2 11040-754 EXTRUDED GUARD 32 2 11040-751 EXT INC WT CHANNEL 33 1 11040-767 COVER, TOP 34 1 11040-772 COVER, TOP 35 2 11040-776 CHASSIS 36 2 11040-777 TRAY, BOTTOM 37 1 11040-760 PANEL, SHROUD BACK 38 2 11040-762 PANEL, SHROUD FRONT 39 1 11040-560 DECAL, WEIGHT PLATE (10 - 290) 40 1 11050-205 LINK 41 4 11050-375 PIVOT PIN 42 2 11090-370 SHAFT, PIVOT 43 2 11090-374 END CAP 44 2 11090-376 RING, HANDLE GRIP 45 4 11090-392 FOOT COVER 46 1 3900-441 DECAL, CYBEX INTERNATIONAL 47 1 4605-381-X* WARNING LABEL 48 2 4000Y316-X* DECAL, CAUTION 49 1 11020-210 CUSHION TUBE 50 1 4520-357 DECAL ADJUSTING 51 1 4520-362-X* DECAL, CAUTION 52 1 4605-322 PIN, DETENT 53 1 4605-512 INSERT PLASTIC, 7.94 54 1 51198 WARRANTY BOOKLET (NOT SHOWN) 55 2 8500-026-X* DECAL, CAUTION 56 1 8650-204 CAM BOLT 57 4 BR030214 RETAINING RING, .625 DIA

ITEM QTY PART NO. DESCRIPTION

5 8 2 BS070201 COM SPRING .56 x .66 1.50 LG 59 1 CM000211 DECAL, PATENT PENDING 60 1 EZ000006 GAS SPRING 250N 61 10 FB030232 BEARING, RADIAL 17 mm EXTENDED RACE 62 8 FB130207 BRG FLG 17mm X 19mm X 25mm 63 96” GB000202 BELT .95 WIDE 64 2 GP000209 PULLEY ASSEMBLY-3.50 65 6 HC620431 BHSCS .250-20 X 2.00 66 9 HC700417 BHSCS .375-16 X 1.00 67 1 HC700428 BHSCS .375-16 X 2.25 68 1 HC700430 BHSCS .375-16 X 2.50 69 2 HF449063 INSERT 3/4 X 1/4-20 70 10 HF540200 GROMMET, NYLON 71 2 HN-60065 NUT, HEX SELF- LOCKING .312-18 BLK ZINC 72 2 HN625200 LOCKNUT, .250-20 NYLON 73 12 HN704901 LOCKNUT, .375-16 NYLON 74 1 HP286819 SPIRAL PIN .188 X 1.12 75 21 HS347600 WASHER, SAE .375 76 2 HS407100 WASHER, SPRING .650 ID x .790 OD x .062 THK 77 6 HT102214 PHIL, HEX, WASHER HD, TYPE 23, 10-24 78 18 HT542514 PN HD PHIL SC # 8 X .625 BLK 79 2 HX-60184 BALL STUD, .312 - 18 UNC x 10 mm 80 2 HY740000 SET SCREW 81 8 JC620415 BHSCS .250-20 X .75 82 2 JC620422 BHSCS .250-20 x 1.50 83 18 JC700412 BHSCS .375-16 X .50 84 4 JC700420 BHSCS .375-16 X 1.25 85 4 JC700424 BHSCS .375-16 X 1.75 86 3 PN149101 CLAMP, HOSE, SNAP GRIP 87 2 PP080226 INSERT, DOMED PLASTIC 2.00, RIB 88 2 PP090202 INSERT, PLASTIC 1.50 x 3.00 x 11 GA 89 1 PP090211 INSERT, PL 1.50 SQ X 10-14 GA 90 2 PR060005 BUMPER, WEIGHT 91 2 PR250203 STRIP, FOAM .12 X .25 X ROLL 92 2 4605-507 GRIP 1.38 OD X .94 ID 93 1 PU060201 BUMPER 94 1 11000-394 DECAL, INDICATOR 95 1 11020-336 DECAL, SEAT ADJUSTING 96 4 JS347400 LOCKWASHER, INT TOOTH .375 97 4 11090-403 CAM SHEILD 98 4 HC572814 SHCS .190-10-24 X .625 99 1 HT512517 TAP SC 10-24 X 1.00 TYPE WB PN HD PHIL BLK 100 1 PR060006 BUMPER, RECESS 101 1 11040-789 EAGLE PLAQUE 102 4 HN575100 LOCKNUT .190-No 10-24 103 4 HT572512 TAP SC NO. 10-24 X .50 PN HD PHIL 104 1 4800-168 CHEST PAD 105 1 4800-188 SEAT PAD 106 1 13000-401 MOUNT, WATER BOTTLE HOLDER 107 1 13000-400 HOLDER, WATER BOTTLE 108 1 HT552515 TAP SC NO 8-16X.75 109 2 HT512517 TAP SC 10-24 X 1.00 TYPE WB 110 1 11000-407-X* DECAL, INCREMENT WEIGHT 111 1 11040-790 DECAL, MADE IN USA

*Language Key 1-German 2-French 3-Spanish English 6-Japanese 7-Swedish 8-Russian

Service Page 6-4

Cybex Eagle 11020 Incline Pull Owner’s Manual

11020 INCLINE PULL MAIN ASSEMBLY DETAIL

107

106

108

109

104

105

Service

Page 6-5

Cybex Eagle 11020 Incline Pull Owner’s Manual

SHROUD AND WEIGHT ROD ASSEMBLY DETAIL

101

Service Page 6-6

103

110

111

Cybex Eagle 11020 Incline Pull Owner’s Manual

RIGHT ARM ASSEMBLY DETAIL

LEFT ARM ASSEMBLY DETAIL

Service

Page 6-7

Cybex Eagle 11020 Incline Pull Owner’s Manual

SEAT ASSEMBLY DETAIL

100

104

105

Service Page 6-8

1.0

126

9.0

220

72.

18.

100

Cybex Eagle 11020 Incline Pull Owner’s Manual

BELT AND CABLE ROUTING DETAIL

Service

Page 6-9

Cybex Eagle 11020 Incline Pull Owner’s Manual

INCLINE PULL TOP WEIGHT ASSEMBLY

ITEM QTY PART NO. DESCRIPTION

1 1 11040-366 Top Weight Assembly, Molded 2 1 11040-367 Hub, Molded 3 2 11040-369 Rod, Linkage 4 2 11040-370 Pin 5 1 11040-427 Rod 6 1 11040-426 Stem 7 1 11040-424 Cover Plate 8 1 11040-416 Cover, Top Weight 9 1 11040-425 Knob 10 1 BH030207 Pin, Weight Selector 11 1 4700-251 Lifting Post 15 12 4 BR030209 External Retaining Ring .188 13 2 BR030220 Internal Retaining Ring 1.250 14 1 HP016820 Cotter Pin .125 X 1.25 15 1 HP266765 Roll Pin, .125 X .938

ITEM QTY PART NO. DESCRIPTION

16 2 HS720004 Felt Washer, .641 1.250 .125 T 17 4 HT562715 Tap SC NO 10 x .750 F Phil 18 4 HT582510 Tap SC NO 10 x .375 PN HD Phil 19 2 11040-409 Molded Bumper Pad 20 12 11040-572 Guard, Increment Weight 21 6 11040-573 Weight Increment 22 1 11040-216 Belt Clamp 23 1 11040-301 Clamp Block Insert 24 1 11040-428 Adjustment Decal 25 1 11040-429 Rotation Decal 26 1 HT552512 Screw, Pan HD Phil HD Self Tapping 8-16 x .50, Type WB 27 3 HY740000 Set Screw 28 14 4000C101 Weight Stack Plate 29 1 4701-013 Weight Pack (Not Shown)

TOURQUE SET SCREWS 300-350 IN./LBS

Service Page 6-10

NOTE: Increment weights are located in the increment weight channel. See main assembly.

10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX 508-533-5183

www.cybexinternational.com • techhelp@cybexintl.com

CYBEX Eagle 11020, Eagle Incline Pull Owner's And Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
