Cybex Big Iron Half Rack User Manual
Cybex® 19000/19010 Half Rack
Owner’s Manual
Strength Systems
Part Number 19000-999-4 A
www.cybexintl.com
Cybex® 19000/19010 Half Rack
Owner’s Manual
Strength Systems
Part Number 19000-999-4 A
Cybex® and the Cybex logo are registered trademarks of Cybex International, Inc.
DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to
revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such
revisions or changes.
© Copyright 2011, Cybex International, Inc. All rights reserved.
Printed in the United States of America. 10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX 508-533-5183
www.cybexintl.com • techhelp@cybexintl.com • 19000-999-4 A
Table of Contents
Safety
Safety ..................................7
Safety Guidelines and Practices ..............8
Warning/Caution Decals ...................10
Regular Maintenance Activities..............11
Exercise
Intended Use............................13
Customer Service
Contacting Service .......................15
Ordering Parts...........................15
Return Material Authorization (RMA) .........16
Damaged Parts ..........................17
Assembly
Tools Required ..........................19
Maintenance
Daily Procedures.........................25
Weekly Procedures.......................25
Cybex 19000/19010 Half Rack Owner’s Manual
Safety
Safety
Read the Owner’s Manual carefully before assembling, servicing or using Cybex equipment.
WARNING: Serious injury could occur if these safety precautions are not observed:
User Safety Precautions
Obtain a medical exam before beginning any exercise program.•
Stop exercising if feeling faint, dizzy or experiencing pain and consult your physician.•
Obtain instructions before using. •
Read and understand the owner’s manual and all warnings posted on the machine •
before using.
Keep all children (12 and under) away. Teenagers (13 and over) and disabled must be •
supervised.
Use a spotter.•
Keep body and clothing free from and clear of all moving parts.•
Use the machine only for the intended use. • DO NOT modify the machine.
Inspect machine prior to use. • DO NOT use if it appears damaged or inoperable.
DO NOT • attempt to x a broken or jammed machine.
Report any malfunctions, damage or repairs to the facility• .
Replace any warning labels if damaged, worn or illegible.•
Facility Safety Precautions
Read the Owner’s Manual carefully before assembling, servicing or using this equipment. •
Make sure that each machine is set up and operated on a solid level surface. • Do not install
equipment on an uneven surface.
CAUTION: Cybex is not responsible for the actual anchoring of equipment. Consult with
a professional contractor.
7
Cybex 19000/19010 Half Rack Owner’s Manual
WARNING: Use fasteners having a minimum of 500 lbs. tensile capacity (3/8’’ grade 2
bolts or better).
WARNING: If legs/frame does not contact surface, DO NOT pull down with anchors. Shim
any leg or frame not in contact with surface using at washers.
Make sure that all users are properly trained on how to use the this equipment.•
Make sure there is enough room for safe access and operation of this equipment. •
Perform regular maintenance checks on this equipment. Also pay close attention to all areas most •
susceptible to wear.
Immediately replace worn or damaged components. If unable to immediately replace worn or •
damaged components then remove from service until the repair is made.
NOTE: It is the sole responsibility of the user/owner or facility operator to ensure that regular
maintenance is performed.
Safety Guidelines and Practices
Cybex recommends that all tness equipment be used in a supervised area. It is recommended that
the equipment be located in an access controlled area. Control is the responsibility of the owner. The
extent of control is at the discretion of the owner.
It is the responsibility of the purchaser/user of Cybex products to read and understand the owner’s
manual, and warning labels; as well as instruct all individuals, whether end users or supervising
personnel, on proper usage of the equipment.
PROPER USAGE:
Use machine only as described in the manual. Failing to follow proper instructions may result in injury.
Do Not Lean Against or Pull On the framework, weight stack, or any component, whether machine
is at rest or in use. Inappropriate or improper use may result in injury to users or third parties
(bystanders).
Do not use machine if it is not located on a solid level surface or is improperly installed.
Provide an adequate safety perimeter between the machine, walls and other equipment to ensure
that the facility has the proper clearance for usage and training.
SECURING EQUIPMENT:
The machine has holes in the feet, which allow for ease in anchoring to the oor. Cybex strongly
recommends that, to eliminate rocking, tipping or falling over due to incorrect usage and misuse,
equipment be secured to a solid, level surface
8
Cybex 19000/19010 Half Rack Owner’s Manual
1. The solid, level surface should not deviate more than 1/8” over a 10’ distance or as dened and
required by local building and architectural codes.
Anchoring 2. of equipment must be completed by a qualied licensed contractor.
Anchoring 3. holes are provided on the feet of the frame. All anchoring locations must be used
when used when anchoring the equipment to the oor.
Due 4. to the wide variation of ooring on which machines may be anchored or installed, verify
anchoring method and anchoring fasteners with a qualied and licensed contractor.
A 5. minimum pull out force of 220 lbs/100 kgs is required for each anchor position.
Do 6. not use machine until it is properly anchored.
MAINTENANCE:
Preventative maintenance allows proper equipment operation and reduces the risk of injury. Perform
the maintenance requirements as specied in the manual.
STANDARD COMPLIANCE:
Cybex products meet or exceed applicable ASTM and EN Standards.
9
