This chapter provides information to familiarize you with the product features,
guide you through the installation process, and get started using web-based
Configuration Utility. It includes the following sections:
•Product Overview
•Mounting the RV315W
•Connecting the RV315W
•Getting Started with the Configuration
•Performing Basic Configuration Tasks
1
Product Overview
Thank you for choosing the Cisco RV315W Broadband Wireless VPN Router. The
RV315W provides routing, switching, security, wireless, 3G, Virtual Private
Network (VPN), quality of service (QoS), and flow-control capabilities for small
businesses.
Before you use the RV315W, become familiar with the lights on the front panel and
the ports on the rear panel.
Front Panel
The lights are located on the front panel of the RV315W.
LAN1-8 PortsThese ports provide a LAN connection to network devices,
such as PCs, print servers, or switches.
RESETThe RESET button has two functions:
•Reboot: Press the RESET button for at least 1, but no
more than 5 seconds with a paper clip or a pencil tip
to reboot the unit.
•Restore to Factory Defaults: Press and hold the
RESET button for more than 5 seconds to reboot the
unit and restore to factory defaults. Changes that you
have previously made to the RV315W settings are
lost.
POWER (12VDC)The POWER port is where you connect the supplied power
adapter (12 V/3 A).
Power SwitchPowers the unit on or off.
Default Settings
These are the default settings used when configuring your RV315W for the first
time.
ParameterDefault Value
Username cisco
Passwordcisco
LAN IP192.168.1.1
DHCP Range192.168.1.100 to 192.168.1.200
NOTE Press and hold the RESET button for more than 5 seconds with a paper clip or a
pencil tip to reboot the unit and restore the factory defaults. Changes that you have
previously made to the RV315W settings are lost.
You can place your RV315W on a desktop or mount it on a wall.
Placement Tips
•Ambient Temperature—To prevent the RV315W from overheating, do not
operate it in an area that exceeds an ambient temperature of 104°F (40°C).
•Air Flow—Be sure that there is adequate air flow around the RV315W.
•Mechanical Loading—Be sure that the RV315W is level and stable to avoid
any hazardous conditions.
Place the RV315W horizontally on a flat surface so that it sits on its four rubber
feet.
1
Wall-Mounting
The RV315W can be wall-mounted. The wall-mounting hardware is
user-supplied. The ports on the back panel must face either upward or downward
when mounting the RV315W to the wall. The recommended dimensions for the
mount kit are as follows:
STEP 1 Determine where you want to mount the RV315W. Verify that the surface is
smooth, flat, dry, and sturdy.
STEP 2 Drill two pilot holes into the surface 5.9 inches (150 mm) apart.
STEP 3 Insert a screw into each hole, leaving a gap between the surface and the base of
the screw head of at least 0.1 inches (3 mm).
STEP 4 Place the RV315W wall-mount slots over the screws and slide the RV315W down
until the screws fit snugly into the wall-mount slots.
Connecting the RV315W
1
NOTE The wireless module of the RV315W is enabled by default. You can connect one
PC with an Ethernet cable or through a wireless connection to perform the initial
configuration. Use the default wireless network name (SSID) and pre-shared key
that are provided on the product label at the bottom of the RV315W to connect the
PC to your wireless network for the first time.
STEP 1 Power off all equipment, including the cable or DSL modem, the PC that you will
use to connect to the RV315W, and the RV315W.
STEP 2 Connect one end of an Ethernet cable to your cable or DSL modem. Connect the
other end to the WAN0 port on the back panel of the RV315W.
STEP 3 Connect one end of a different Ethernet cable to one of the LAN ports on the back
panel. Connect the other end to an Ethernet port on the PC that you will use to run
web-based Configuration Utility.
NOTE Skip this step if you want to connect the PC to the RV315W through a
wireless connection.
STEP 4 Connect the supplied power adapter to the POWER port on the back panel. Plug
the other end of the power adapter into an electrical outlet. Make sure that the
power switch is turned off.
NOTE Use only the power adapter that is supplied with the unit. Using a different
STEP 5 Power on all connected devices including the cable or DSL modem and the PC
and wait until the connections are active.
STEP 6 Power on the RV315W.
STEP 7 To connect the PC to your wireless network for the first time, you can configure the
wireless connection using the default SSID name and pre-shared key that are
provided on the product label.
A sample configuration is illustrated here.
Wireless
Devices
Internet
Access
Devices
Network
Devices
1
Power
Supply
Getting Started with the Configuration
You can use web-based Configuration Utility of the RV315W to view the system
information, configure the key parameters, upgrade system firmware, reboot the
unit, or restore the unit to its factory default settings.
Before You Begin
Before you begin to use web-based Configuration Utility, make sure that you have
a computer with Microsoft Internet Explorer 6.0 (or later) or Mozilla Firefox 3.0 (or
later).
NOTE The minimum recommended display resolution for the PC running the web browser
To log in to the utility and launch the Setup Wizard to complete the initial
configuration:
STEP 1 Connect a computer to an available LAN port on the back panel. After you power
on the PC, your PC becomes a DHCP client of the RV315W and receives an IP
address in the 192.168.1.xxx range.
STEP 2 Start a web browser. In the Address bar, enter the default IP address of the
RV315W: 192.168.1.1.
STEP 3 When the login page appears, choose the language that you prefer to use in the
utility, and then enter the username and password.
The default administrator username is cisco. The default administrator password
is cisco. Both usernames and passwords are case sensitive.
1
For security purposes, change the default administrator password as soon as
possible. See Changing the Default Administrator Password for more
information.
STEP 4 Click Login.
STEP 5 Click Setup Wizard in the left-hand navigation pane. The Setup Wizard launches.
STEP 6 Follow the on-screen prompts to complete the initial configuration.
After the initial configuration is complete, you can configure other advanced
features. See the help pages for more information.
Using the Help System
The Configuration Utility provides a context-sensitive help file for all configuration
tasks. To view the Help page, click the Help link in the top right corner of the
screen. A new window opens with information about the page that you are
currently viewing.
We recommend that you complete the tasks in this section before you configure
the RV315W.
Changing the Default Administrator Password
The default administrator account (admin) has full privilege to set the configuration
and read the system status. For security purposes, we recommend that you
change the default administrator password after your first login.
To change the default administrative password:
STEP 1 Click System Management > User Management. The User Management page
opens.
1
STEP 2 Check the default administrator account (admin) and click Change Password.
STEP 3 Enter the following information:
•Old Password: Enter the current administrator password.
•New Password: Enter a new administrator password. Passwords are case
sensitive.
•Password Confirm: Enter the password again for confirmation.
STEP 4 Click OK to save your settings.
Upgrading Your Firmware After Your First Login
After you log in to web-based Configuration Utility for the first time, we
recommend that you upgrade your firmware to the latest version before you do
any other tasks.
NOTE This feature requires that you have an active WAN connection to access the
STEP 1 Choose System Management > Firmware Upgrade. The Firmware Upgrade
page opens.
The following information is displayed:
•Device Model: Displays the device model.
•PID VID: Displays the product ID and version ID.
•Current Firmware Version: Displays the firmware version (primary
•Backup Firmware Version: Displays the firmware version (secondary
1
firmware) that the RV315W is currently using.
firmware) that is used as a backup. When you upgrade the firmware to a
newer version, the system first overwrites the secondary firmware with the
new version in the flash, and then reboots with the new firmware. The new
firmware becomes the primary firmware and the previous primary firmware
becomes the secondary firmware.
STEP 2 In the Download the latest firmware field, click Download to download the latest
version of the firmware from the specified website to your local PC. Make sure that
you have an active WAN connection.
STEP 3 In the Locate & select the upgrade file field, click Browse to locate and select the
downloaded firmware image from your local PC.
STEP 4 Click Upgrade.
After the new firmware image is validated, the new image is written to flash. The
RV315W will be automatically rebooted with the new firmware.
At any point during the configuration process, you can back up your configuration.
Later, if you make changes that you want to abandon, you can easily restore the
saved configuration.
To back up your configuration:
STEP 1 Click System Management > Configuration Management. The Configuration
Management page opens.
STEP 2 To back up the settings currently used on your RV315W, click Backup
Configuration.
STEP 3 Select where to locate the configuration file, and then click OK.
This chapter describes how to use the Setup Wizard to quickly configure the initial
settings of your RV315W. It includes the following sections:
•Starting the Setup Wizard
•Configuring WAN Connection
•Configuring Default LAN Settings
•Configuring Wireless Connection
•Completing the Setup Wizard
2
Starting the Setup Wizard
STEP 1 Click Setup Wizard in the left-hand navigation pane. The Setup Wizard launches.
STEP 2 If you are an expert, you can exit the Setup Wizard and click the menu in the left-
hand navigation pane to configure the specific feature directly. If you want to
continue, click Next to proceed to the WAN Configuration page. Or you can click
Exit to exit the Setup Wizard.
Configuring WAN Connection
From the WAN Configuration page you can configure the WAN connection by
using the information provided by your Internet Service Provider (ISP).
Depending on the requirements of your ISP, choose the Internet connection type
and configure the corresponding fields. The RV315W supports four types of
network addressing modes: DHCP, Static IP, PPPoE, and L2TP.
STEP 3 Choose WAN0 or WAN1 (only available when the WAN1/LAN0 port on the back
STEP 4 Choose a proper network addressing method from the Internet Connection Type
2
panel is set to a secondary WAN port) from the WAN Interface drop-down menu
to connect to the Internet.
drop-down menu and specify the corresponding settings.
The following table provides the configuration instruction for each Internet
connection type. Confirm that you have proper network information from your ISP
or a peer router to configure the RV315W to access the Internet.
Internet
Connection
Type
DHCPConnection type often used with cable modems. Choose this
Static IPChoose this option if your ISP provides you with a static
Configuration
option if your ISP dynamically assigns an IP address on
connection.
(permanent) IP address and does not assign it dynamically.
Use the corresponding information from your ISP to complete
the following fields:
•IP Address: Enter the IP address of the WAN port that
can be accessible from the Internet.
•Subnet Mask: Enter the IP address of the subnet mask.
•Default Gateway: Enter the IP address of default
gateway.
•Primary DNS Server: DNS servers map Internet
domain names to IP addresses. Enter the IP address of
the primary DNS server. You can get the DNS server
address from your ISP.
PPPoEPPPoE uses Point-to-Point Protocol over Ethernet (PPPoE) to
Configuration
connect to the Internet.
Choose this option if your ISP provides you with client
software, username, and password.
•User Name: Enter the username that is required to log
into the ISP.
•Password: Enter the password that is required to log
into the ISP.
•Service Name: Enter the name for the PPPoE service.
•Keep Alive: Choose one of the following options:
-Connect Idle Time: Let the RV315W disconnect
from the Internet after a specified period of
inactivity (Idle Time). This option is recommended if
your ISP fees are based on the time that you spend
online. If you choose this option, enter the idle time
in the field. The default value is 300 seconds.
-Keep Alive: Keep the connection always on,
regardless of the level of activity. This option is
recommended if you pay a flat fee for your Internet
service. If you choose this option, enter the interval
to automatically reestablish the WAN connection
after the connection is down. The default value is 30
seconds.
L2TPChoose this option if you want to use Layer 2 Tunneling
Configuration
Protocol (L2TP) to connect to the Internet.
Use the necessary information from your ISP to complete the
L2TP configuration:
•Auto Get IP: Enable or disable to automatically obtain
an IP address.
•L2TP Server IP Address: Enter the IP address of the
L2TP server.
•User Name: Enter the username that is required to log
into the L2TP server.
•Password: Enter the password that is required to log
into the L2TP server.
•Keep Alive: Choose one of the following options:
-Connect Idle Time: Let the RV315W disconnect
from the Internet after a specified period of
inactivity (Idle Time). This option is recommended if
your ISP fees are based on the time that you spend
online. If you choose this option, enter the idle time
in the field. The default value is 300 seconds.
-Keep Alive: Keep the connection always on,
regardless of the level of activity. This option is
recommended if you pay a flat fee for your Internet
service. If you choose this option, enter the interval
to automatically reestablish the WAN connection
after the connection is down. The default value is 30
seconds.
STEP 5 In the Enable VLAN area, click Enable when the ISP uses the VLAN ID to add the
tag to the users, and then enter the following information:
•VLAN ID: Enter the tag of the VLAN ID.
•802.1p Priority: Enter the value of the 802.1p priority.
STEP 6 If you want to continue, click Next to proceed to the LAN Configuration page. If you
want to return to the previous page, click Back. If you want to exit the Setup
Wizard, click Exit.
Configuring Default LAN Settings
From the LAN Configuration page you can configure the default LAN settings of
the RV315W.
STEP 7 Enter the following information:
•VLAN: Select a VLAN from the drop-down menu. See Configuring LAN
Interfaces for more information on configuring the VLANs.
•IP Address: Enter the subnet IP address of the default LAN.
2
•Subnet Mask: Enter the subnet mask of the default LAN.
•DHCP Service: Check Enable to allow the RV315W to act as a DHCP server
and assign IP addresses to all devices that are connected to the LAN. Any
new DHCP client joining the LAN is assigned an IP address of the DHCP pool.
Check Disable to disable the DHCP server on the RV315W.
•Start IP: Enter the starting IP address of the DHCP pool if you enable the
DHCP server.
•End IP: Enter the ending IP address of the DHCP pool if you enable the DHCP
server.
•Lease Time: Enter the maximum connection time in minutes that a dynamic
IP address is “leased” to a network user. When the time elapses, the dynamic
IP address of the user is automatically renewed. The default is 0, indicates
that the lease time is 1 day.
STEP 8 If you want to continue, click Next to proceed to the Wireless Configuration page.
If you want to return to the previous page, click Back. If you want to exit the Setup
Wizard, click Exit.
From the Wireless Configuration page you can configure the wireless network of
the RV315W and the security settings for the selected SSID.
STEP 9 Enter the following information:
•Current SSID: Select a SSID as the default wireless access point of the
RV315W.
•SSID Name: Displays the name of the selected SSID. You can edit the SSID
name. Enter a unique name for the SSID for identification.
•Enable Current SSID: Check Enable to enable this SSID, or check Disable
to disable the SSID.
•Security Mode: Choose the security mode and configure the
corresponding security settings. For security purposes, we strongly
recommend that you use WPA2 for wireless security. The following table
lists all available security modes:
2
Security ModeConfiguration
OpenAny wireless device that is in range can connect to the SSID.
WEPWEP encryption is an older encryption method that is not
2
considered to be secure and can easily be broken. Choose
this option only if you need to allow access to devices that do
not support WPA or WPA2.
If you choose this option, enter the following information:
•Authentication Type: Choose either Open System or
Shared key. The default is Open System.
•Key Length: Choose either 64 bits or 128 bits. The
default is 64 bits. The larger size keys provide stronger
encryption, which makes the key more difficult to
crack.
•Passphrase: If you want to generate WEP keys by
using a Passphrase, enter any alphanumeric phrase
(between 4 to 63 characters) and then click Generate
to generate 4 unique WEP keys. Select one key to use
as the key that devices must have to use the wireless
network.
•Key Index: Choose a key index as the default transmit
key. Key indexes 1 through 4 are available.
•Key 1-4: If a WEP Passphrase is not specified, a key
can be entered directly into one of the Key boxes. The
length of the key should be 5 ASCII characters (or 10
hex characters) for 64-bit encryption and 13 ASCII
characters (or 26 hex characters) for 128-bit
encryption.
Wi-Fi Protected Access (WPA) provides better security than
WEP because it uses dynamic key encryption. This standard
was implemented as an intermediate measure to replace
WEP, pending final completion of the 802.11i standard for
WPA2.
WPA-Personal supports Temporal Key Integrity Protocol
(TKIP) or Advanced Encryption System (AES) encryption
mechanisms for data encryption (default is TKIP). TKIP uses
dynamic keys and incorporates Message Integrity Code
(MIC) to provide protection against hackers. AES uses
symmetric 128-bit block data encryption.
If you choose this option, enter the following information:
•WPA Pre-Shared Key: The Pre-shared Key (PSK) is
the shared secret key for WPA. Enter a string of at least
8 characters to a maximum of 63 characters.
•WPA Key Renewal Timeout: Enter a value to set the
interval at which the key is refreshed for clients
associated to this SSID. A value of zero (0) indicates
that the key is not refreshed. The default value is 3600
seconds.
•WPA Encryption: Choose TKIP, AES, or TKIP+AES as
the encryption algorithm for data encryption. The
default is TKIP.
WPA2 provides the best security for wireless transmissions.
This method implements the security standards specified in
the final version of 802.11i. WPA2-Personal always uses AES
encryption mechanism for data encryption.
If you choose this option, enter the following information:
•WPA Pre-Shared: The Pre-shared Key (PSK) is the
shared secret key for WPA. Enter a string of at least 8
characters to a maximum of 63 characters.
•WPA Key Renewal Timeout: Enter a value to set the
interval at which the key is refreshed for clients
associated to this SSID. A value of zero (0) indicates
that the key is not refreshed. The default value is 3600
seconds.
•WPA Encryption: Choose TKIP, AES, or TKIP+AES as
the encryption algorithm for data encryption. The
default is AES.
WPA-Enterprise uses WPA with RADIUS authentication. This
mode supports TKIP and AES encryption mechanisms
(default is TKIP) and requires the use of a RADIUS server to
authenticate users.
If you choose this option, enter the following information:
•WPA Key Renewal Timeout: Enter a value to set the
interval at which the key is refreshed for clients
associated to this SSID. A value of zero (0) indicates
that the key is not refreshed. The default value is 3600
seconds.
•WPA Encryption: Choose TKIP, AES, or TKIP+AES as
the encryption algorithm for data encryption. The
default is TKIP+AES.
•RADIUS Server IP Address: Enter the IP address of
the RADIUS server.
•RADIUS Server Port: Enter the port number of the
primary RADIUS server. The default value is 1812.
•RADIUS Server Key: Enter the key for authentication
WPA2-Enterprise uses WPA2 with RADIUS authentication.
This mode always uses AES encryption mechanism for data
encryption and requires the use of a RADIUS server to
authenticate users.
If you choose this option, enter the following information:
•WPA Key Renewal Timeout: Enter a value to set the
interval at which the key is refreshed for clients
associated to this SSID. A value of zero (0) indicates
that the key is not refreshed. The default value is 3600
seconds.
•WPA Encryption: Choose TKIP, AES, or TKIP+AES as
the encryption algorithm for data encryption. The
default is AES.
•RADIUS Server IP Address: Enter the IP address of
the RADIUS server.
•RADIUS Server Port: Enter the port number of the
primary RADIUS server. The default value is 1812.
•RADIUS Server Key: Enter the key for authentication
STEP 10 If you want to continue, click Next to proceed to the Complete Setup Wizard page.
If you want to return to the previous page, click Back. If you want to exit the Setup
Wizard, click Exit.
Completing the Setup Wizard
From the Complete Setup Wizard page you can see the summary information for
all configurations.
STEP 11 If you want to return to the previous page, click Back. If you want to exit the Setup
Wizard, click Exit.
STEP 12 If the configuration is correct, click Finish to apply the settings and complete the
