HP 802.11g printer card User’s Manual
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this
equipment.
IMPORTANT NOTE:
FCC / IC Radiation Exposure Statement:
This device complies with FCC RF Exposure limits set forth for an uncontrolled
environment, under 47 CFR 2.1093 paragraph (d)(2). This transmitter must not be
co-located or operating in conjunction with any other antenna or transmitter. This
device was tested for typical lap held conditions that may occur during normal notebook
and PDA use. To comply with FCC RF exposure requirements the user shall use this
product only in intended application as documented in this manual.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to
channels 1 through 11.
Industry Canada Statement
Operation is subject to the following two conditions:
1) This device may not cause interference and
2) This device must accept any interference, including interference that may cause
undesired operation of the device
2
![](/html/eb/ebf3/ebf3491256f9ab01caaca93028972beb8d8e669b755d15ee8667355d16c04a47/bg3.png)
HP 802.11g printer card User’s Manual
About this manual
This User’s Manual describes how to install and operate your Compact Flash
Wireless LAN Card. Please read this manual before you install the product.
This manual includes the following topics:
Product description and features.
Software installation procedure.
Specification
3
![](/html/eb/ebf3/ebf3491256f9ab01caaca93028972beb8d8e669b755d15ee8667355d16c04a47/bg4.png)
HP 802.11g printer card User’s Manual
Table of Contents
About this manual...............................................................3
Chapter 1 - Introduction...................................................5
Features............................................................................................5
What is Wireless LAN?..................................................................6
Wireless LAN Modes......................................................................7
Notes on Wireless LAN Configuration........................................8
Chapter 2 – Driver Installation for Windows....................9
Driver installation for Windows 2000...................................................9
Driver installation for Windows XP.................................................... 13
Appendix A – S pecifications...........................................16
4
![](/html/eb/ebf3/ebf3491256f9ab01caaca93028972beb8d8e669b755d15ee8667355d16c04a47/bg5.png)
HP 802.11g printer card User’s Manual
Chapter 1 - Introduction
The CB001A CF Card gives you the freedom to work your way, from wherever you
want. An enhanced 802.11g featuring advanced silicon chip design from Marvell
capable of delivering data transfer rates up to 54Mbps.
Features
• Compact Flash Type-I form factor.
• IEEE 802.11g compatible.
• Backward compatible with IEEE 802.11b standard.
• Wire-free access to networked resources from anywhere beyond the desktop.
• Delivers data rate up to 54 Mbps.
• 802.11g: Dynamically shifts between 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
network speed, based on signal strength, for maximum availability and
reliability of connection.
• 802.11b: Dynamically shifts between 11M, 5.5M, 2M, and 1 Mbps network
speed, based on signal strength, for maximum availability and reliability of
connection.
• Allows users move between Access Points without resetting their connection
reconfiguration.
• Built-In PCB antenna with diversity design (Two antennas required).
• Support advanced power management and power saving mode.
• Low CPU utilization through scatter gathers bus-mastering DMA architecture.
• Uses 2.4GHz frequency band, which complies with worldwide requirement.
• Fallback rat algorithm that sets the optimum transmission rate based on
actual signal-to-noise ratio and packet loss information
• Supports most popular operating systems: Window 98SE/2000/ME/XP and
WinCE/Linux.
• Ensures great security by providing the 64/128 bits Wired Equivalent Privacy
(WEP) and WiFi Protected Access (WPA) defined in the IEEE standard.
• 802.11i and WPA2 Support
• 802.11e (WMM) Support
• Future driver upgradeable
