CyberPower Systems OL6KRT2UTF, OL6KRT2UTFHW, OL8K10KRT3UTF, OL8K10KRT3UTFHW User Manual

User’s Manual

Step-Down Transformer

OL6KRT2UTF OL8K10KRT3UTF OL6KRT2UTFHW

OL8K10KRT3UTFHW



CyberPower Systems (USA), Inc. 4241 12th Avenue East Suite 400 Shakopee, MN 55379 Phone: 877-297-6937 Fax: 952-403-0009 www .CPSww.com



K01‐0000212‐00



The CyberPower Step-Down Transformers support installation wit h power cord L6-30P (OL6KRT2UTF / OL8K10KRT3UTF) o r hardwire (OL6KRT2UTFHW / OL8K10KRT3UTFHW), and are designed for a variety of CyberPower UPS systems. When combined with the UPS, the Step-Down Transformer converts voltage from 200-240V down to 100-120V.

OVERVIEW



UNPACKING



2U or 3U Step-Down Transformer

2U or 3U Rackmount ears (Stands) (2) * 1 set

Flat head screws: M5X8L (8) * 1 set

Pan head screws: M5X12L (12) * 1 set

 

User’s manual Registration card

Rackmount left rail Rackmount right rail

Tie plate (1) * 1 set

Plastic washers (8) * 1 set

Screw hole dust covers (10) * 1 set

Input terminal block cover

1



HARDWARE INSTALLATION



HARDWA RE INSTALLATION

These versatile Step-Down Transformers can be mounted in a rackmount or vertical tower orientation. This versatility is especially important to growing organizations with changing needs that value having the option to position a Step-Down Transformer on a floor or in a rackmount system. Please follow the instructions below for the respective mounting methods.

SAFETY PRECAUTIONS

CAUTION! To prevent the risk of fire or el ectric shock, only use the

supplied hardware to attach the mounting brackets.

RACKMOUNT INSTALLATION

Step 1: Rackmount ears installation

Attach the two rackmount ears to the Step-Down Transformer using th e provided screws M5X8L*8pcs.

Step 3: Adjust rackmount rails to fit your rack

Attach the rackmount rail to your rack with two M5X12L screws and two plastic washers at the front of the rack. (Loc ated in position 1 & position 6) Do not tighten the screws. Adjust the rail size on the rail as s embly of y our rack. Secure the rail to the rear of the rack with two M5X12L screws and two plastic washers. Tighten all screws at the front and rear of the rail.

Step 2: Rackmount rail Installation

The rails adjust to mount in 48-cm (19-inch) panel racks from 52 to

91.5cm (20.5 to 36 inches) deep. Select the proper holes in the rack for positioning the Step-Down Transformer in the rack. The 2U Step-Down Transformer takes up position 1 through position 6. The 3U Step-Down Transformer takes up position 1 through position 9.

Place the Step-Down Transformer on a flat stable surface with the front of the unit facing toward you. Secure the Step-Down Transformer to your rack with four M5X12L screws at the front of t he rac k . T he 2U Step-Down Transformer takes up position 2 through position 5. The 3U Step-Down Transformer takes up position 2 through position 8.

CAUTION! The Step-Down Transformer must be installed above the

power module.



2



VERTICAL/TOWER INSTALLATION

HARDWARE INSTALLATION

Step 1: Rotate the Multifunction LCD Module

Unscrew the right panel of the power modu le. Separate the right panel from the UPS. Gently lift the LCD module out. Rotate it to the tower orientation. Reinstall it for a tower configuration.

Step 2: Attach the base stands

Secure the tie bracket with the screws (M5X8*4pcs). Tighten the screws (M5X12*4pcs) of the base stands (rack mount ears) onto the bottom of the power module and the Battery module.

Step 3: Attach dust covers

Insert dust covers into the rackmount ear screw hol es that are not being used.



SAFETY PRECAUTIONS

CAUTION! Installation environment should be in a temperature and

humidity controlled indoor area free of con ductive contaminants. Do not install this UPS where excessive moisture or hea t is present (Pleas e see specifications for acceptable temperature and humidity range).

CAUTION! Never install a UPS, or associated wiring or equipment,

during a lightning storm.

CAUTION! Do not work alone under hazardous conditions. CAUTION! In case of the risk of electric shock, do not remove the top

cover.

CAUTION! The battery can energize hazardous live parts inside even

when the AC input power is disconnected.



3



HARDWIRING THE INPUT TERMINALS

 

SAFETY PRECAUTIONS

CAUTION! Input and Output circuit breakers must be “OFF” during the building installation. CAUTION! The OL6KRT2UTF and OL8K10KRT3UTF with power cord L6-30P DO NOT require hardwiring. Use the attached power cord to connect to the

UPS outlet.

CAUTION! The OL6KRT2UTFHW and OL8K10KRT3UTFHW require them to be hard wired into the UPS. Only qualified maintenance personnel should

perform this task.

CHECK WIRING

Check wiring dimensions with the following table.

Step-Down Transformers with hardwire Wiring AWG Wiring mm2

OL6KRT2UTFHW 10 AWG 5.5 mm2

OL8K10KRT3UTFHW 8 AWG 8.0 mm2



Step 1: Separate the top and bottom covers

Loosen the four screws to separate the top and bottom covers.

Step 2: Fix the bottom cover on the terminal block

Tighten the two screws to fix the bottom cover on the terminal block.

4



Step 3: Input configuration

Insert the input cable through the appropriate cable gland (not included).

HARDWIRING THE INPUT/ OUTPUT TERMINALS

Connect the three wires to the input terminal block.



5



HARDWIRING THE INPUT/ OUTPUT TERMINALS

 

Step 4: Fix the top cover on the bottom cover

Tighten the five screws to fix the top cover on the bottom cover.



Step 5: Connect the other side of the input cable to UPS output terminal block.

 



6



BASIC OPERATION



STEP-DOWN TRANSFORMER FRONT/REAR PANEL DESCRIPTION

1. Input Circuit Breaker

Provides input overload and fault protection.

2. Input Power Cord / Input Terminal Block

Connect to UPS outlet / output terminal block.

3. Battery Backup & Surge Protected Outlets (120Vac)

Provides battery backup and surge protection. They ensure power is provided to connected equipment over a period of time during a power failure.

4. Output Circuit Breaker (120Vac)

Provides output overload and fault protection.

5. Battery Backup & Surge Protected Outlets (208Vac)

Provides battery backup and surge protection. They ensure power is provided to connected equipment over a period of time during a power failure.

6. Output Circuit Breaker (208Vac)

Provides output overload and fault protection.

OL6KRT2UTF

OL8K10KRT3UTF

OL6KRT2UTFHW

OL8K10KRT3UTFHW

7



TECHNICAL SPECIFICATIONS



Model Configuration

Maximum Output Power (VA) 5000VA 6000VA 5000VA 8000VA Maximum Output Power (W) 5000W 5400W 5000W 7200W Form Factor Rackmount / Tower

Input

Nominal Input Voltage 208Vac Input Voltage Range 200-240Vac Input Current Rating 24A 30A 24A 40A Input Frequency 50/60Hz

Output

Nominal Output Voltage 120Vac UPS Outlets (12) 5-20R (12) 5-20R, (2) L6-20R, (2) L6-30R

Physical

Dimensions Net Weight 128.3lbs(58.3Kg) 159.7lbs(72.6Kg)

Environment

Operating Temperature Operating Relative Humidity 0 to 90% Non-Condensing

Safety

Conformance Approvals CE, UL

OL6KRT2UTF OL6KRT2UTFHW OL8K10KRT3UTF OL8K10KRT3UTFHW

L x W x H = 26 x 17 x 3.46in.

(66 x 43.3 x 88cm)

32℉ to 104℉ ( 0℃ to 40℃)

L x W x H = 26 x 17 x 5.2in.

(66 x 43.3 x 13.2cm)

SAFETY PRECAUTIONS

CAUTION! Before connecting to the UPS, check that the input voltage into the UPS is within specifications.

CyberPower Systems Inc.

www.cpsww.com



Business Edition and PowerPanel® Personal Edition are trademarks of

8



PRODUCT REGISTRATION



CyberPower requests that you complete and return the Warranty Registration Card enclosed with the Product or register the Product at its website (www.cpsww.com) to establish that you are the Initial Customer of the Product, and therefore entitled coverage under the Limited Warranty and the Connected Equipment Guarantee. (Registration is not required for coverage, but note: if you do not register your purc hase, you will be required to provide proof of purchase.)



LIMITED WARRANTY AND CONNECTED EQUIPMENT GUARNTEE



Read the following terms and conditions carefully before using the CyberPower OL6KRT2UTF / OL8K10KRT3UTF / OL6KRT2UTFHW / OL8K10KRT3UTFHW. By using the Product you consent to be bound by and become a party to the terms and conditions of this Limited Warranty and Connected Equipment Guarantee (together referre d to as this “ Warranty”). If you do not agree t o the terms and co nditions of t his Warranty, you should return the Product for a full refund prior to using it.

Who is Providing this Warranty?

CyberPower Systems (USA), Inc. (“CyberPower”) provides this Limited Warranty.

What Does This Warranty Cover?

This warranty covers defects in materials and workmanship i n the Product under normal us e and conditions. It also c overs equipment t hat was connected to the Product and damaged because of the failure of the Product.

What is the Period of Coverage?

This warranty covers the Product for three years and connected equipment for as long as you own the Product.

Who Is Covered?

This warranty only covers the original purchaser. Coverage ends if you sell or otherwise transfer the Product.

How Do You Get Warranty Service?

1. Before contacting CyberPower, identify Your Product model number, the Purchase Date, and each item of Connected Equipment.

2. Email us at tech@cpsww.com or Call us at (877) 297-6937.



3. If your product requires warranty service you must provide a copy of your dated purchase receipt or invoice.

How Do You Open A Connected Equipment Claim?

1. Call us at (877) 297-6937 or write to us at Cyber Power Systems (USA), Inc ., 4241 12th Ave. E., STE 400, Shakopee, MN 55379, or send us an e-mail message at claims@cpsww.com for instructions, within 10 days of the occurrence.

2. When you contact CyberPower, identify the Product, the Purchase Date, and t he item(s) of Connected Equipment. Have information on all applicable insurance or other resources of recovery/payment that are available to the Initial Customer and Request a Claim Number.

3. You must provide a dated purchase receipt (or other proof of the original purchase) and provide a description of the damage to your connected equipment.

4. Pack and ship the product to CyberPower and , if requested, t he item(s) of Con nected Equipment, a repair c ost estimate for the damage to the Connected Equipment, and all claim forms that Cy berPower provides to you. Show the Claim Number on the s hipping label or include it with the product. You must

prepay all shipping costs, you are responsible for packaging and shipment, and you must pay the cost of the repair estimate.

How Long Do I Have To Make A Claim?

All claims must be made within ten days of the occurrence.

What Will We Do To Correct Problems?

CyberPower will inspect and examine the Product. If the Product is defective in material or workmanship, CyberPower will repair or replace it at CyberPower's expense, or, if CyberPower is una ble to or decides

not to repair or replace the Product (if defective) within a re asonable time, CyberPower will refund to you the full purchase price you paid for the Product (purchase receipt showing price paid is required).

9



LIMITED WARRANTY AND CONNECTED EQUIPMENT GUARNTEE

Who Pays For Shipping?

We pay when we send items to you; you pay when you send items to us.

What Are Some Examples Of What This Warranty Does Not Cover?

1. This Warranty does not cover any software that was dam age d or n ee ds to be replaced due to the failure of the Product or any data that is los t as a result of the failure or the restoration of data or records, or the reinstallation of software.

2. This Warranty does not cover or apply to: misuse, modification, operation or storage outside environmental limits of the Product or the equipment connected to it, nor for damage while in transit or i n storage, nor if there has been improper oper ation or maintenance, or use with it ems not designed or intended for use with the Product, such as laser printers, appliances, aquariums, medical or life support devices, etc.

What Other Limitations Apply?

The sole and exclusive remedies of the Initial Customer are those provided by this Warranty.

1. This Warranty does not apply unless the Product and the equipment that was connected to it were connected to properly wired and grounded outl ets (including compliance with electrical and safety codes of the most current electrical code), without the use of any adapters or other connectors.

2. The Product must have been plugged direc tly into the power source and the equipment connected to the Product must be directly connected to the Product and not “daisy-chained” together in s erial fashion with any exte nsion cords , another Produc t or device simil ar to the Prod uct, surge su ppressor, or power tap. Any such installation voids the Limited Warranty.

3. The Product and equipment conn ected to it must have been used properly in a suitable and proper environment and in conformance with any license, instruction manual, or warnings provided with the Product and the equipment connected to it.

4. The Product must have been used at all times within the limitations on the Product’s VA capacity. The Product was designed to eliminate disrupting and damaging effects of momentary (less than 1ms) voltage spikes or imp ulses from lightning or other

power transients. If it can be shown t hat a v olta ge s pike las ting l onger than 1ms has oc curr ed, th e occ urrenc e will b e deeme d o utside the r ate d ca pabilit ies of the Product and the Limited Warranty is void. CyberPower Does Not Cover or Undertake Any Liability in Any Event for Any of the Following:

1. Loss of or damage to data, records, or software or the restoration of data or records, or the reinstallation of software.

2. Damage from causes other than AC Power Line Transients, spikes, or surges on properly installed, grounded and cod e-compliant 120 volt power lines in the United States and Canada; transients, s urges or spikes on standard telephone land lines, PBX telephone equipment lines or Base 10T Ethernet lines, when properly installed and connec ted. (This exclusio n applies , for ex ample, to fluc tuations in data transmi ssion or receptio n, by CATV or RF transmission or fluctuations, or by transients in such transmission.)

3. Damage from any circumstance described as excluded above with respect to the Product.

4. Damages from fire, flood, wind, r ain, rising water, leakage or breakage of plumbing, abus e, misuse or alteration of either t he product or the Connected Equipment.

5. CyberPower excludes any liability for personal injur y under the Limit ed Warranty and Connected Equ ipment Guarante e. CyberPower ex cludes any liability for direct, indirect, special, incidenta l or consequential damages, whether for damage t o or loss of property [EXCEPT FOR (AND ONLY FOR) the specific limited agreement of CyberPower to provide certain warranty benefits regarding "Connected Equipment" under this Warranty], loss of profits, business interruption, or loss of informati on or data. NOTE: So me States or Prov inces do not a llow the exclusion or limitation of incidental or conseque ntial damages, so the above limitation may not apply to you.

6. The Product is not for use in hi gh-risk activities or with aquariums. The Product is not designed or intended for us e in hazardous envir onments requiring fail-safe performance, or for use in any circums tance in which the failure of the Product coul d lead directly to death, personal injury, or severe physical or property damage, or that would affect operation or safety of any medical or life support device (collectively, "High Risk Activities"). CyberPower expres sly disclaims any express or implie d war r anty o f f itn es s for High Risk Activities or with aquariums. CyberPower does not authorize use of any Product in any High Risk Activities or with Aquariums. ANY SUCH USE IS IMPROPER AND IS A MISUSE OF THE PRODUCT.

Where Can I Get More Information?

The application of the United Nations Convention of Contracts for the International Sale of Goods is expressly excluded. CyberPower is the warrantor under this Limited Warranty. For further information please feel free to contact Cy berPower at Cy berP ower Sys tems (USA), Inc . 4241 12th Ave E., STE 400, Shakop ee, MN 55 379; ca ll us

at (877) 297-6937; or send us an e-mail message at claims@cyberpowersystems.com.



CONFORMANCE APPROV ALS



FCC Notice

This device complies with part 15 of t he FCC Rules . Operation is subject to the following two conditi ons: (1) T his dev ice may not cause harmful interference, and (2) this device must accept any interference that may cause undesired operation.



WARNING!! This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FC C Rules. These

limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can rad iate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communic ations. Operation of this equipm ent in a residenti al area is likely to cause harmful in terferenc e in which case th e user will be required to correct the interference at his own e xpense. Shielded signal c ables must be used with t his product to ensur e compliance with the Clas s A FCC limits.



The Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulation. Cet appareil numerique de la class A respecte toutes les exigencies du Reglement sur le materiel brouilleur du Canada.



This document is believed to be accurate, but CyberP ower reserves the right to change or correct the conte nts and does not assume any respons ibility for omissions or errors.



Need Additional Help?

Feel free to contact our Tech Support department with installation, troubleshooting, or general product questions.

CyberPower Technical Support Phone: 1-877-297-6937 Email: tech@cpsww.com Web: www.CPSww.com Mail: 4241 12th Avenue E, Suite 400 Shakopee, MN 55379

Hours of Operation: Monday – Friday, 8:00am – 5:00pm (CST)


