Cyber Power OL3000RTXL2UN DATASHEET
OL3000RTXL2UN
SMART APP
ONLINE UPS
Prevent business interruptions and safeguard
mission-critical enterprise network equipment.
The CyberPower OL3000RTXL2UN is a rack/tower UPS with double
conversion topology. It provides sine wave output to critical applications and
equipment that require seamless power correction. The Extended Battery
Module (EBM) expands runtime, and Fast Charge Technology restores full
backup power faster. This model comes with an extendable LCD control
panel, Smart Battery Management charging technology, and energy-saving
GreenPower UPS™ ECO Mode.
The OL3000RTXL2UN oers generator compatibility and delivers clean AC
power with zero transfer time. A factory installed RM card allows remote
management and configuration of the UPS via a standard web browser,
command line interface (CLI), or network management system (NMS). Its sine
wave output keeps sensitive equipment working by preventing unnecessary
shutdowns that can occur with simulated sine wave output.
With a $400,000 lifetime connected equipment guarantee and a three-year
warranty, you can trust CyberPower’s commitment to high quality
SPECIFICATIONS
TYPICAL APPLICATIONS
• Corporate and Enterprise Servers
• Network and Storage Devices
• Edge Closets
• PBX and VoIP Installations
FE AT U R E S
• 3000VA / 2700W
• Double Conversion Topology
• Sine wave output, zero transfer time
• Configurable Output - 100, 110, 115, 120,
125 V, 50/60 Hz
• GreenPower UPS™ ECO Mode
• RM205CARD for remote monitoring
• 2U Rack Mount/Tower Convertible
• Outlets: (6) NEMA 5-20R,
(1) NEMA L5-30R
• PowerPanel® Business Edition
Management Software
GENERAL
UPS Topology Double Conversion
Energy Saving Yes, ECO Mode Eciency >95%
Energy Star Qualified Yes
OUTPUT
VA
Watts
Rated Power Factor 0.9
3,000 VA at 120, 125 V
2,700 VA at 115, 110 V
2,40 0 VA at 100 V
2,700 W at 120, 125 V
2,430 W at 115, 110 V
2,160 W at 100 V
INPUT
60 V to 69 V, 0% to 60% load
Input Voltage Range
Frequency Range 40 – 70 Hz (auto sensing)
Input Power Factor 0.99
Cold Start Yes
Plug Type NEMA L5-30P
Cord Length (ft) 10
Cord Length (m) 3
©2020 Cyber Power Systems (USA), Inc. CyberPower is a registered trademark and brand of Cyber Power Systems (USA), Inc. All rights reserved. All other trademarks are the property
of their respective owners. CyberPower reserves the right to change, without notice, marketing programs, product offerings and specifications. www.cyberpowersystems.com
70 V to 79 V, 0% to 70% load
80 V to 89 V, 0% to 80 % load
90 V to 95 V, 0% to 90% load
96 V to 150 V, 0% to 100% load
On Battery Waveform Sine wave
On Battery Voltage 10 0, 110, 115 , 120, 125 V ±2% (configurable)
On Battery Frequency
Harmonic Distortion
Crest Factor 3:1
Outlet s - Total 7
Ou t let Type NEMA 5 -20R (6), NEMA L5 -30R ( 1)
50/60 Hz ± 0. 25 Hz
(auto-sensing or configurable)
THD < 3% at Linear Load,
< 5% at Non -linear Load
OL3000RTXL2UN
SMART APP ONLINE UPS
SPECIFICATIONS CONT.
OUTPUT - CONT.
Line Mode:
105% to 125% load for 1 min
Overload Protection
Bypass Internal Bypass (Automatic and Manual)
Transfer Time 0ms
126% to 15 0% loa d for 10 sec
Battery Mode:
105% to 130% load for 10 se c
131% to 1 50% load for 2 sec
BAT TE RY
Runtime at Half Load 11 minutes
Runtime at Full Load 3.5 minutes
Ba t ter y Type Sealed Lead-Acid
Battery Size 1 2V/ 9A h
Battery Quantity 6
Replacement Battery Cartridge RB1290X6A
Replacement Battery Cartridge
Quantity
Hot Swappable Yes
Typical Recharge Time 4 h (0% to 90%)
Smart Battery Management (SBM)
Mode
Extended B atter y Option BP72V60ART2U
1
Yes
SURGE PROTECTION & FILTERING
Surge Protection 1335 Joules, pe r IEC 61 000 -4-5 Level 3
Phone RJ11 / Ethernet RJ45 1-In / 1-Out (combo)
EMI/RFI Filtration Yes
MANAGEMENT & COMMUNICATIONS
LCD Multifunction LCD
Rotatable LCD Control Panel
Option
Removable LCD Control Panel
Option
HID Compliant USB Port Yes
Serial Port Yes
EPO Por t Yes
Dry Contacts Yes
Cables Included USB Cable, Serial Cable
LED Indicators
Audible Alarms
Software PowerPanel® Business Edition
Upgradeable Firmware Yes
Expansion Slot RMCARD205 pre-installed
Yes
Yes - Requires a separate DB26 C able
Power On (white)
Line Mo de (green)
Battery Mod e (yellow)
Bypass Mode (yellow)
Fau lt (red)
Replace Battery (red)
Battery Mode
Battery Low
Overload
UPS Fault
PHYSICAL
Form Factor Rack/Tower
Color Black
Enclosure Construction Steel
Mounting Hardware Included
Dimensions (WxHxD, cm) 43.18 x 8.89 x 59.99 (mm)
Dimensions (WxHxD, in) 17 x 3.5 x 23.62 (in)
Dimensions (WxHxD, mm) 432 x 89 x 600 (mm)
Weight (lbs) 68.2
Weight (kg) 30.93
Rack Size 2U
SHIPPING DIMENSIONS
Shipping - Dimensions (WxHxD, in) 22. 5 x 9.0 x 35 .0 (in)
Shipping - Dimensions (WxHxD, mm) 571 .5 x 228.6 x 8 89.0 (mm)
Shipping - Weight (lb) 8 7.08
Shipping - Weight (kg) 39.5
Shipping Dimensions - (WxHxD, cm) 57.15 x 22. 86 x 88.9 (cm)
