Operations Guide for the
4-Port PoweredUSB 2.0 Hub
with Serial Ports and External Power Supply
Part #010845
930105B
CyberData Corporation
2555 Garden Road
Monterey, CA 93940
(831) 373-2601
Operations Guide for the 4-Port PoweredUSB 2.0 Hub 930105B
Phone: (831) 373-2601
Technical Support Ext. 333
support@cyberdata.net
Fax: (831) 373-4193
Company and product information at www.cyberdata.net
with External Power Supply 010845
COPYRIGHT NOTICE:
© 2008, CyberData Corporation, ALL RIGHTS RESERVED.
This manual and related materials are the copyrighted property of CyberData Corporation. No part
of this manual or related materials may be reproduced or transmitted, in any form or by any means
(except for internal use by licensed customers), without prior express written permission of
CyberData Corporation. This manual, and the products, software, firmware, and/or hardware
described in this manual are the property of CyberData Corporation, provided under the terms of an
agreement between CyberData Corporation and recipient of this manual, and their use is subject to
that agreement and its terms.
DISCLAIMER: Except as expressly and specifically stated in a written agreement executed by
CyberData Corporation, CyberData Corporation makes no representation or warranty, express or
implied, including any warranty or merchantability or fitness for any purpose, with respect to this
manual or the products, software, firmware, and/or hardware described herein, and CyberData
Corporation assumes no liability for damages or claims resulting from any use of this manual or
such products, software, firmware, and/or hardware. CyberData Corporation reserves the right to
make changes, without notice, to this manual and to any such product, software, firmware, and/or
hardware.
OPEN SOURCE STATEMENT: Certain software components included in CyberData products are
subject to the GNU General Public License (GPL) and Lesser GNU General Public License (LGPL)
“open source” or “free software” licenses. Some of this Open Source Software may be owned by
third parties. Open Source Software is not subject to the terms and conditions of the CyberData
COPYRIGHT NOTICE or software licenses. Your right to copy, modify, and distribute any Open
Source Software is determined by the terms of the GPL, LGPL, or third party, according to who
licenses that software.
Software or firmware developed by CyberData that is unrelated to Open Source Software is
copyrighted by CyberData, subject to the terms of CyberData licenses, and may not be copied,
modified, reverse-engineered, or otherwise altered without explicit written permission from
CyberData Corporation.
TRADEMARK NOTICE: CyberData Corporation and the CyberData Corporation logos are
trademarks of CyberData Corporation. Other product names, trademarks, and service marks may be
the trademarks or registered trademarks of their respective owners.
CyberData Corporation 930105B Operations Guide
Contents
Chapter 1 Product overview 1
Chapter 2 Installing and Using the 4-Port PoweredUSB Hub 3
2.1 Product Components List .....................................................................................................................3
2.2 Installation ................................................................................................................
2.3 Connections .................................................................................................................
2.4 Operation ..................................................................................................................
2.5 Port Electrical Specifications ............................
Appendix A Regulatory and Safety Information 15
...............................5
...........................5
2.3.1 Power supply .............................................................................................................
2.3.2 Host connector ...........................................................................................................
2.3.3 Jumpers ..................................................................................................................
2.3.4 PoweredUSB connections ....................................................................................................
2.3.5 Connector color keys .......................................................................................................
2.3.6 Peripherals connections to the
2.3.7 Peripheral cable connection options ........................................................................................
CyberData 4-Port PoweredUSB 2.0 Hub ...........................9
.............................13
..................................................................................13
..................5
..................6
.......................7
......7
...........7
i
9
Appendix B Setting up the Hub on Windows XP 17
Index 19
Operations Guide 930105B CyberData Corporation
ii
CyberData Corporation 930105B Operations Guide
1 Product overview
The CyberData 4-Port PoweredUSB 2.0 Hub provides a simple, affordable way to add up to four
PoweredUSB ports to your PC. These additional ports are controlled by the PC’s Standby and Wake
commands. This add-on Hub makes it easy to connect the PC to devices that require more than the
500mA of +5 volts supplied with the standard USB interface.
1
Product features
● 4 PoweredUSB ports
● One +24 volt up to 2.3A
● Three +12 volt up to 1.5A each
● Short circuit and over current protected
● Multiple power supply options
● Plug-n-Play installation
● Peripheral power controlled by PC stand-by and wake commands
● LED indicators for port power output and USB 2.0 status
● Two-year warranty
License note The PoweredUSB controller board contains certain technology that
CyberData Corporation is licensed with IBM to manufacture, and to sell or lease products that
incorporate this technology. This license also permits other entities to resell or release these
Cyberdata products after they have been purchased from CyberData.
Documentation
no
te
The documentation for this product is released in an English language version only.
is covered by an IBM® patent.
Operations Guide 930105B CyberData Corporation
Product overview
2
Contact CyberData
CyberData Corporation
2555 Garden Road
Monterey, CA 93940
USA
www.cyberdata.net
Voicemail: 831-373-2601
Fax: 831-373-4193
Contact Sales Sales (831) 373-2601 Extension 334
Contact
T
echnical Support
Purchase cables
and con
nectors
Phone: 831-373-2601 Extension 333
Email: support@cyberdata.net
Product support page: http://www.cyber
data.net/support/4port20hub/
For additional information about PoweredUSB cables and connectors, go to:
http://www.cyberdata.net/products/poweredusb/pusbcables.html
Warranty CyberData warrants its product against defects in material or
years from the date of purchase. Should the product fail within the warranty period, CyberData will
repair or replace the product free of charge. This warranty includes all parts and labor.
Should the product fail out-of-warranty, a flat rate r
epair charge of one half the product purchase
price will be assessed. Repair costs for products that are in warranty, but damaged by improper
modifications or abuse, will be charged at the out-of-warranty rate. Products returned to CyberData,
both in and out-of-warranty, are shipped to CyberData at the expense of the customer. Charges for
shipping repaired products back to the customer will be paid by CyberData.
workmanship for a period of two
Contact Service If service is required, contact the CyberData Returned Materials
at (831) 373-2601 Extension 136.
When returning a product to CyberData, an approved CyberData RMA number must be printed on
the outside
of the original shipping package. No product will be accepted for return without an
approved RMA number. Send the product, in its original package, to the following address:
CyberData Corporation
2555 Garden Road
Monterey, CA 93940
Attention: RMA “your RMA number”
Authorization (RMA) department
CyberData Corporation 930105B Operations Guide
2 Installing and Using the 4-Port PoweredUSB Hub
This chapter provides the instructions, illustrations, and background information you need to
install, and begin working with the CyberData 4-Port PoweredUSB 2.0 Hub with Serial Ports.
3
2.1 Product Components List
The PoweredUSB Hub package includes these parts:
● (1) CyberData 4-Port PoweredUSB 2.0 Hub
● Power Supply, 24VDC, Desk-top, 4-Pin Hosiden style plug
● (1) Accessory Kit
• (1) Short USB 2.0 Hi-Speed host cable
• (1) Host USB cable strain relief clamp
Operations Guide 930105B CyberData Corporation
Installing and Using the 4-Port PoweredUSB Hub
● In GREEN Disabled Mode, when
24V power is applied with no host
plugged in, the Hub Power LED
(Blue) is and all four port Power
LEDs turn on. The Host Link
(connection) LED WILL NOT light.
● In GREEN Mode, when 24V power is
applied with no host plugged in, the
Hub Power LED (Blue) is on, the 4
port Power LEDs and the Host Link
(connection) LED DO NOT light.
● Connect a standard USB 2.0 cable
from host PC to Host connector on
back of hub with 24V power
connected and all four top Port
Power LEDs light and turn on green
sequentially and the host
(connection) Link LED connector
turns on green.
● When a peripheral is plugged into
the enumerated hub; into one of the
hub ports; and the peripheral
enumerates in the OS, the Status Led
for that Port will light and turn green
● On a peripheral load error on any
port, the Status LED turns orange
and 24V power to the upper portion
of the connector is turned off until
the hub is restarted.
Port power
(Pwr) and Hub
power LEDs
+24V up to 2.5 Amp load
+24V up to
6.5 Amp load
USB Host Connector Type B
+12V PoweredUSB Ports +24V
PoweredUSB Port
Link and
Port1
Status
LEDs
Standard USB 2.0 Hi-Speed
Type A Ports
Serial Ports
Strain
Relief
4
Product Components List
•(1) Operations Guide for the 4-Port PoweredUSB 2.0 Hub with Serial Ports
Component identification: external front and back
views
CyberData Corporation 930105B Operations Guide
Figure 2-1. Product Compatibility
The CyberData 4-Port PoweredUSB 2.0 Hub is compatible with the followin
USB standards.
Operating systems USB
Windows 2000 and XP 2.0 Standard
LINUX PoweredUSB 0.8g
Mac OS-X
g operating systems and
2.2 Installation
+24V for
up to 2.5
Amp load
+24V for
up to 6.5
Amp load
USB Host
Connector
(Type B)
Strain
Relief
The CyberData 4-Port PoweredUSB 2.0 Hub is a tabletop unit with mounting feet that sit on a flat
surface.
2.3 Connections
This following topics provide illustrations and information on connecting the CyberData 4-Port
PoweredUSB 2.0 Hub to power supplies, the host, and peripheral devices.
2.3.1 Power supply
The PoweredUSB specification requires supplying +24V at 2.3A and +12V at 1.5A to each voltage
designated port. These requirements are met only if the power supply has sufficient wattage for this
amount of power.
Installing and Using the 4-Port PoweredUSB Hub
Installation
5
The Epson PS180 brick and Dell printer power supply ar
supplies that can be used with this Hub and peripherals requiring less power. Two power plug
receptacles are provided on the back of the CyberData 4-Port PoweredUSB 2.0 Hub to facilitate the
use of alternate power supplies.
The three-pin connector is normally used for the Dell and
used for a high-current power supply. See ”Figure 2-7”on page 9 for an illustration of cable routing
from the CyberData 4-Port Power
CAUTION The P1 and P2
power supplies into both input jacks simultaneously as equipment damage that might void the
product warranty could occur.
edUSB 2.0 Hub.
DC input jacks on the back of this Hub are for input only. Do not plug
Figure 2-2. Power Connectors—Back View
e examples of lower-cost alternate power
Epson Bricks. The four-pin connector is
Operations Guide 930105B CyberData Corporation
Installing and Using the 4-Port PoweredUSB Hub
6
Connections
2.3.2 Host connector
The connection to the host computer is achieved via a standard USB 2.0 certified Hi-Speed “A” to
“B” cable that is included in the Accessory Kit, or with any equivalent USB 2.0 certified Hi-Speed
cable. Refer to Section 2.1, "Product Components List" for information about the Accessory Kit.
Figure 2-3. Host Connector with Strain Relief
CyberData Corporation 930105B Operations Guide
2.3.3 Jumpers
C
A
B
C
A
B
C
A
B
Jumper Positions
Jumpers 3 and 4
Jumpers 5 and 6
Jumpers 1 and 2
Jumper Table AB C
Com Port A, Pin 1 JP3 12V 5V CD
Com Port A, Pin 9 JP4 12V 5V RI
Com Port B, Pin 1 JP5 12V 5V CD
Com Port B, Pin 9 JP6 12V 5V RI
Installing and Using the 4-Port PoweredUSB Hub
Figure 2-4. Jumpers
Connections
7
2.3.4 PoweredUSB connections
The PoweredUSB connections are standard USB “A” connectors with four extra pins to supply
higher voltages. See ”Figure 2-6”on page 8 for an illustration. The lower portion of the “A”
connector side on this product can be used alone,
without the locking PoweredUSB connector.
2.3.5 Connector color keys
The PoweredUSB connectors are color keyed so that only the correct voltage cables can be installed.
Operations Guide 930105B CyberData Corporation
Installing and Using the 4-Port PoweredUSB Hub
Teal Red
12 Volt Keyed
1.5A each
Ports 1,2, and 3
24 Volt Keyed
2.3A
Ports 4
PIN OUT
Pin Signal Description
1 Vbus USB standard “A”
2 D- USB standard “A”
3 D+ USB standard “A”
4 Ground USB standard “A”
5 Ground USB PlusPower
6 Vplus USB PlusPower
7 Vplus USB PlusPower
8 Ground USB PlusPower
Shell Shield
8
Connections
Figure 2-6. USB PoweredUSB Socket Connector Pin Assignments
Figure 2-5. Color-coding for Connectors
CyberData Corporation 930105B Operations Guide
Installing and Using the 4-Port PoweredUSB Hub
+24V PoweredUSB Connector
+12V PoweredUSB Connectors
CyberData 4-Port PoweredUSB Hub
Connections
2.3.6 Peripherals connections to the CyberData 4-Port PoweredUSB 2.0 Hub
This figure illustrates the cable routing from the CyberData 4-Port PoweredUSB 2.0 Hub to the Dell
Retail Integrator.
Figure 2-7. Top view of Hub PoweredUSB cable routing
9
2.3.7 Peripheral cable connection options
Figures 10 through 16 provide examples of peripheral cable combinations and connection options
for the CyberData 4-Port PoweredUSB 2.0 Hub. The following table provides details about the
CyberData PoweredUSB Cables displayed in these figures.
PoweredUSB
ca
ble sources
Figure PoweredUSB Cable Description CyberData Part Number
”Figure 2-8”on page 10 12V to 2x4 010693C
”Figure 2-9”on page 10 12V to 12V Power Jack Contact CyberData
”Figure 2-10”on page 11 24V PoweredUSB to 3-Pin Power Mini-DIN 010631A
Operations Guide 930105B CyberData Corporation
Custom cables of different lengths and colors can be purchased from CyberData as follows:
● Via email: sales@cyberdata.net
● Via phone: Sales (831) 373-2601 Extension 334
CyberData PoweredUSB Cables
Installing and Using the 4-Port PoweredUSB Hub
10
Connections
CyberData PoweredUSB Cables
Figure PoweredUSB Cable Description CyberData Part Number
”Figure 2-11”on page 11 24V to “Y” Cable 3-Pin Power Mini-DIN to USB “B” 010714A
”Figure 2-12”on page 12 12V to “Y” Cable, RS232 and Power Jack 010763
”Figure 2-13”on page 12 24V to 1x8 010617A
”Figure 2-14”on page 12 24V to “Y” Cable, RS232 and Power Jack
Figure 2-8. Cable, +12V PoweredUSB to 2x4 PoweredUSB
Figure 2-9. Cables; +12V PoweredUSB to +12V Power Jack and RS-232 to RS-232
CyberData Corporation 930105B Operations Guide
Installing and Using the 4-Port PoweredUSB Hub
Connections
Figure 2-10. Cables; +24V PoweredUSB to 3-Pin Mini-DIN and RS-232 to RS-232 or Parallel to
Parallel
11
Figure 2-11. “Y” Cable, +24V PoweredUSB to 3-Pin Power Mini-DIN and USB “B” Connectors
Operations Guide 930105B CyberData Corporation
Installing and Using the 4-Port PoweredUSB Hub
12
Connections
Figure 2-12. RS232 to USB Converter “Y” Cable +12V (PC Enumerates this device as an RS-
232 COM port)
Figure 2-13. Cable, +24V PoweredUSB to 1x8 PoweredUSB
Figure 2-14. RS232 to USB Converter “
Y” Cable +24V
CyberData Corporation 930105B Operations Guide
2.4 Operation
The CyberData 4-Port PoweredUSB 2.0 Hub is a standard USB Hub that complies with the USB 2.0
specification, and adds PoweredUSB ports. When connected to a Host, it is enumerated as a Generic
USB Hub. This Hub also meets the PoweredUSB .08g specification. For more information about this
specification, go to www.poweredusb.org.
Installing and Using the 4-Port PoweredUSB Hub
Operation
13
POS peripheral
ca
veat
According to the USB 2.0 specification, devices attached to a USB interface should enumerate from
the Hub’s USB Vbus, regardless of the PoweredUSB powered ports. Some POS devices do not
comply with this specification, and will not enumerate unless the upper sections of the PoweredUSB
ports are active.
When running on operating systems such as Windows XP with no devi
the operating system turns the Hub off. The operating system does not detect non-compliant
peripherals when they are hot-plugged into an empty Hub. Consequently PoweredUSB power is
not supplied to the peripheral. In this case, you can restore correct operation as follows.
1. Unplug the Host side connection for five
2. Be sure that at least one USB device is plugge
standby mode.
3. Plug in a standard USB compliant device, such as a mouse or keyboard.
4. Disable the low-power, standby operation. With this
the PoweredUSB ports regardless of the PC’s operational state. For more information, contact
CyberData as instructed in Section , "Contact Technical Support".
2.5 Port Electrical Specifications
ces attached (an empty Hub),
seconds, and then plug it in again.
d in when the computer is booted, or leaves
configuration, power is always supplied to
The CyberData 4-Port PoweredUSB 2.0 Hub adheres to the USB 2.0 electrical specifications as
follows:
Standard USB
lo
wer A supply
PoweredUSB
su
pply
Operations Guide 930105B CyberData Corporation
Each lower portion of the PoweredUSB port provides +5V @ 500mA. If more than 500mA are drawn
from a port, that port goes into USB over current, the +5 volts is turned off, and the condition is
reported to the host according to USB 2.0 specifications.
The listed maximum currents depend on the selected power supply. Both the +12V and +24V
PoweredUSB ports are protected with active over current circuits. If an over current condition
occurs, unplug the DC connection, remove the overcurrent condition, and re-cycle the DC
connection to the Hub by unplugging it, and then plugging it in again.
● +12V Ports (3) – 1.5A each
● +24V Port (1) – 2.3A
Installing and Using the 4-Port PoweredUSB Hub
14
Port Electrical Specifications
CyberData Corporation 930105B Operations Guide
Appendix A: Regulatory and Safety
Information
15
Regulatory standards
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
Safety standards
● UL60950-1; Information Technology Equipment
● CSA C22.2 No. 60950-01, Information Technology Equipment
● EN60950-1, Information Technology Equipment
● IEC60950-1, Information Technology Equipment
EMC For the USA and Canada, this device complies with:
● Title 47 of the CFR, Part 15, Subpart B, Section 15.107(b)
● Title 47 of the CFR, Part 15, Subpart B, Section 15.109 (b)
● ICES-003
CE Declaration of
Co
nformity
This device complies with:
● Directive 89/336/EEC
● EN55022 Class A 1998
• EN61000-3-2: 2000
• EN61000-3-3: 1995
● EN55024: 1998
• EN61000-4-2: 1995
• EN 61000-4-3:1996
• EN 61000-4-4: 1995
• EN 61000-4-5: 1995
• EN 61000-4-6: 1996
• EN 61000-4-8: 1993
• EN 61000-4-11: 1995
Operations Guide 930105B CyberData Corporation
16
CyberData Corporation 930105B Operations Guide
Appendix B: Setting up the Hub on
Windows XP
For connecting the CyberData 4-Port PoweredUSB 2.0 Hub to a PC running the Windows XP
operating system, keep in mind:
1. Microsoft XP Service Pack 1 or higher must be installed.
17
2. When connecting the Hub for the first time, it is
correctly. A Microsoft XP Service Pack issue does not enumerate and recognize a Hub when no
devices are attached to it. To correctly enumerate the CyberData 4-Port PoweredUSB 2.0 Hub,
attach a peripheral whose drivers are included in Windows XP, such as a USB mouse, prior to
enumerating the Hub. To accomplish this:
a. Connect a USB mouse to one of the lower
b. Connect the power cord to the Hub.
c. With the PC powered up, connect the host control cable from the Hub to a USB port on the
P
C. Doing so displays the Found new hardware dialog, indicating that the PC is searching for
drivers for the Hub.
d. When the PC completes the driver search, it displays the Found new
search of a driver for the mouse. If required, click Next in all screens of the wizard to
complete the driver selection for the mouse.
At this point, you should be able to plug in and install
installed its drivers, or have them available for installation.
important to perform the enumeration
, standard USB, Hub ports.
hardware dialog, in
a USB device provided you have also
Operations Guide 930105B CyberData Corporation
18
CyberData Corporation 930105B Operations Guide
Index
19
A
accessory kit 3, 6
active over current circuits. 13
C
cable routing 9
cable strain relief clamp 3
cables for connecting peripherals 9
CE conformity 15
CFR 15
color keys for ports 7
compatibility matrix 4
components list 3
connector color keys 7
contact information 2
CyberData
contact information 2
license with IBM 1
product warranty 2
sales 2
service and repairs 2
G
generic USB hub 13
H
high-current power supply 5
host connector 3, 6
I
IBM 1
ICES 15
Information Technology Equipment 15
installation 5
J
jumpers 7
D
DC input jacks 5
Dell printer power supply 5
E
EMC 15
enumeration 13, 17
Epson PS180 brick 5
F
FCC 15
features 1
L
license 1
M
Microsoft XP Service Pack 1 17
O
over current protection 1
P
peripheral connections 9
power supply connections 5
PoweredUSB .08g specification 13
PoweredUSB connections 7
product
Operations Guide 930105B CyberData Corporation
20
accessory kit 3, 6
CE conformity 15
compatibility matrix 4
components list 3
enumerating 13
enumeration 17
features 1
installation 5
regulatory standards 15
resell/release conditions 1
R
regulatory standards 15
RMA returned materials authorization 2
S
sales contact information 2
service contact information 2
short circuit protection 1
U
USB
2.0 specification 13
over current 13
W
warranty 1, 2
Windows XP 13, 17
CyberData Corporation 930105B Operations Guide
Loading...
