CyberData 10845 User Manual

Operations Guide for the

4-Port PoweredUSB 2.0 Hub

with Serial Ports and External Power Supply

Part #010845

930105B

CyberData Corporation

2555 Garden Road

Monterey, CA 93940

[phone]

Operations Guide for the 4-Port PoweredUSB 2.0 Hub 930105B

Phone: [phone]
Technical Support Ext. 333
[e-mail]
Fax: [phone]
Company and product information at www.cyberdata.net

with External Power Supply 010845

COPYRIGHT NOTICE:
© 2008, CyberData Corporation, ALL RIGHTS RESERVED.

This manual and related materials are the copyrighted property of CyberData Corporation. No part
of this manual or related materials may be reproduced or transmitted, in any form or by any means
(except for internal use by licensed customers), without prior express written permission of
CyberData Corporation. This manual, and the products, software, firmware, and/or hardware
described in this manual are the property of CyberData Corporation, provided under the terms of an
agreement between CyberData Corporation and recipient of this manual, and their use is subject to
that agreement and its terms.

DISCLAIMER: Except as expressly and specifically stated in a written agreement executed by
CyberData Corporation, CyberData Corporation makes no representation or warranty, express or
implied, including any warranty or merchantability or fitness for any purpose, with respect to this
manual or the products, software, firmware, and/or hardware described herein, and CyberData
Corporation assumes no liability for damages or claims resulting from any use of this manual or
such products, software, firmware, and/or hardware. CyberData Corporation reserves the right to
make changes, without notice, to this manual and to any such product, software, firmware, and/or
hardware.

OPEN SOURCE STATEMENT: Certain software components included in CyberData products are
subject to the GNU General Public License (GPL) and Lesser GNU General Public License (LGPL)
“open source” or “free software” licenses. Some of this Open Source Software may be owned by
third parties. Open Source Software is not subject to the terms and conditions of the CyberData
COPYRIGHT NOTICE or software licenses. Your right to copy, modify, and distribute any Open
Source Software is determined by the terms of the GPL, LGPL, or third party, according to who
licenses that software.

Software or firmware developed by CyberData that is unrelated to Open Source Software is
copyrighted by CyberData, subject to the terms of CyberData licenses, and may not be copied,
modified, reverse-engineered, or otherwise altered without explicit written permission from
CyberData Corporation.

TRADEMARK NOTICE: CyberData Corporation and the CyberData Corporation logos are
trademarks of CyberData Corporation. Other product names, trademarks, and service marks may be
the trademarks or registered trademarks of their respective owners.

CyberData Corporation 930105B Operations Guide

Contents

Chapter 1 Product overview 1

Chapter 2 Installing and Using the 4-Port PoweredUSB Hub 3

2.1 Product Components List .....................................................................................................................3

2.2 Installation ..................................................................................................................

2.3 Connections ...................................................................................................................

2.

4 Operation ....................................................................................................................

2.5 Port Electrical Specifications ..............................

Appendix A Regulatory and Safety Information 15

.............................5

.........................5

2.3.1 Power supply ...............................................................................................................

2.3.2 Host connector .............................................................................................................

2.3.3 Jumpers .....................................................................................................................

2.3.4 PoweredUSB connections ......................................................................................................

2.3.5 Connector color keys .........................................................................................................

2.3.6 Peripherals connections to the Cybe

2.3.7 Peripheral cable connection options ........................................................................................9

rData 4-Port PoweredUSB 2.0 Hub ...........................9

...........................13

................................................................................13

................5

................6

....................7

....7

.........7

i

Appendix B Setting up the Hub on Windows XP 17

Index 19

Operations Guide 930105B CyberData Corporation

ii

CyberData Corporation 930105B Operations Guide

1 Product overview

The CyberData 4-Port PoweredUSB 2.0 Hub provides a simple, affordable way to add up to four
PoweredUSB ports to your PC. These additional ports are controlled by the PC’s Standby and Wake
commands. This add-on Hub makes it easy to connect the PC to devices that require more than the
500mA of +5 volts supplied with the standard USB interface.

1

Product features

● 4 PoweredUSB ports

● One +24 volt up to 2.3A

● Three +12 volt up to 1.5A each

● Short circuit and over current protected

● Multiple power supply options

● Plug-n-Play installation

● Peripheral power controlled by PC stand-by and wake commands

● LED indicators for port power output and USB 2.0 status

● Two-year warranty

License note The PoweredUSB controller board contains certain technology that is

CyberData Corporation is licensed with IBM to manufacture, and to sell or lease products that
incorporate this technology. This license also permits other entities to resell or release these
Cyberdata products after they have been purchased from CyberData.

Documentation
no

te

he documentation for this product is released in an English language version only.

T

covered by an IBM® patent.

Operations Guide 930105B CyberData Corporation

Product overview

2

Contact CyberData

CyberData Corporation
2555 Garden Road
Monterey, CA 93940
USA
www.cyberdata.net
Voicemail: 831-373-2601
Fax: [phone]

Contact Sales Sales [phone] Extension 334

Contact
T

e

chnical Support

Phone: [phone] Extension 333
Email: [e-mail]
Product support page: http://www.cyberdata.net/support/4port20hub/

Pur

chase cables

and conn

ectors

For additional information about PoweredUSB cables and connectors, go to:
http://www.cyberdata.net/products/poweredusb/pusbcables.html

Warranty CyberData warrants its product against defects in material or workmanship for a

years from the date of purchase. Should the product fail within the warranty period, CyberData will
repair or replace the product free of charge. This warranty includes all parts and labor.

Should the product fail out-of-warranty, a flat rate re

pair charge of one half the product purchase
price will be assessed. Repair costs for products that are in warranty, but damaged by improper
modifications or abuse, will be charged at the out-of-warranty rate. Products returned to CyberData,
both in and out-of-warranty, are shipped to CyberData at the expense of the customer. Charges for
shipping repaired products back to the customer will be paid by CyberData.

period of two

Contact Service If service is required, contact the CyberData Returned Materials

at [phone] Extension 136.

When returning a product to CyberData, an approved CyberData RMA number must be printed on
the outside of the original

shipping package. No product will be accepted for return without an

approved RMA number. Send the product, in its original package, to the following address:

CyberData Corporation
2555 Garden Road
Monterey, CA 93940
Attention: RMA “your RMA number”

Authorization (RMA) department

CyberData Corporation 930105B Operations Guide

2 Installing and Using the 4-Port PoweredUSB Hub

This chapter provides the instructions, illustrations, and background information you need to
install, and begin working with the CyberData 4-Port PoweredUSB 2.0 Hub with Serial Ports.

3

2.1 Product Components List

The PoweredUSB Hub package includes these parts:

● (1) CyberData 4-Port PoweredUSB 2.0 Hub

● Power Supply, 24VDC, Desk-top, 4-Pin Hosiden style plug

● (1) Accessory Kit

• (1) Short USB 2.0 Hi-Speed host cable

• (1) Host USB cable strain relief clamp

Operations Guide 930105B CyberData Corporation

Installing and Using the 4-Port PoweredUSB Hub

● In GREEN Disabled Mode, when

24V power is applied with no host
plugged in, the Hub Power LED
(Blue) is and all four port Power
LEDs turn on. The Host Link
(connection) LED WILL NOT light.

● In GREEN Mode, when 24V power is

applied with no host plugged in, the
Hub Power LED (Blue) is on, the 4
port Power LEDs and the Host Link
(connection) LED DO NOT light.

● Connect a standard USB 2.0 cable

from host PC to Host connector on
back of hub with 24V power
connected and all four top Port
Power LEDs light and turn on green
sequentially and the host
(connection) Link LED connector
turns on green.

● When a peripheral is plugged into

the enumerated hub; into one of the
hub ports; and the peripheral
enumerates in the OS, the Status Led
for that Port will light and turn green

● On a peripheral load error on any

port, the Status LED turns orange
and 24V power to the upper portion
of the connector is turned off until
the hub is restarted.

Port power
(Pwr) and Hub
power LEDs

+24V up to 2.5 Amp load

+24V up to

6.5 Amp load

USB Host Connector Type B

+12V PoweredUSB Ports +24V

PoweredUSB Port

Link and
Port1
Status
LEDs

Standard USB 2.0 Hi-Speed
Type A Ports

Serial Ports

Strain
Relief

4

Product Components List

•(1) Operations Guide for the 4-Port PoweredUSB 2.0 Hub with Serial Ports

Component identification: external front and back views

CyberData Corporation 930105B Operations Guide

Fig

ure 2-1. Product Compatibility

The CyberData 4-Port PoweredUSB 2.0 Hub is compatible with the following
USB standards.

Operating systems USB

Windows 2000 and XP 2.0 Standard

LINUX PoweredUSB 0.8g

Mac OS-X

operating systems and
