CyberData 011405, 011404 Operation Manual

SIP Loudspeaker Amplifier

The IP Endpoint Company

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

(PoE)



Operations Guide



Part #011405

Document Part #931236C

for Firmware Version 11.6.2

CyberData Corporation

3 Justin Court

Monterey, CA 93940

[phone]

Operations Guide 931236C

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Part # 011405

COPYRIGHT NOTICE:
© 2016, CyberData Corporation, ALL RIGHTS RESERVED.

This manual and related materials are the copyrighted property of CyberData Corporation. No part
of this manual or related mate
(except for internal use by licensed customers), without prior express written permission of
CyberData Corporation. This manual, and the products, software, firmware, and/or hardware
described in this manual are the property of CyberData Corporation, provided under the terms of an
agreement between CyberData Corporation and recipient of this manual, and their use is subject to
that agreement and its terms.

DISCLAIMER: Except as expressly and specifically stated in a written agreement executed by
CyberData Corporation, CyberData Cor
implied, including any warranty or merchantability or fitness for any purpose, with respect to this
manual or the products, software, firmware, and/or hardware described herein, and CyberData
Corporation assumes no liability for damages or claims resulting from any use of this manual or such
products, software, firmware, and/or hardware. CyberData Corporation reserves the right to make
changes, without notice, to this manual and to any such product, software, firmware, and/or
hardware.

rials may be reproduced or transmitted, in any form or by any means

poration makes no representation or warranty, express or

OPEN SOURCE STATEMENT: Certain software componen
subject to the GNU Gener
“open source” or “free software” licenses. Some of this Open Source Software may be owned by
third parties. Open Source Software is not subject to the terms and conditions of the CyberData
COPYRIGHT NOTICE or software licenses. Your right to copy, modify, and distribute any Open
Source Software is determined by the terms of the GPL, LGPL, or third party, according to who
licenses that software.

Software or firmware developed by CyberData that is unrelated to Open Source Software is
copyri

ghted by CyberData, subject to the terms of CyberData licenses, and may not be copied,
modified, reverse-engineered, or otherwise altered without explicit written permission from
CyberData Corporation.

TRADEMARK NOTICE: CyberData Corporation and the CyberData Corporation logos are
trademar
be the trademarks or registered trademarks of their respective owners.

ks of CyberData Corporation. Other product names, trademarks, and service marks may

al Public License (GPL) and Lesser GNU General Public License (LGPL)

ts included in CyberData products are

Operations Guide 931236C CyberData Corporation

Revision Information

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Revision 931236C, which corresponds to firmware version 11.6.2, was released on October 28,
2016, and has the following changes:

• Updates Figure 2-6, "Using the Amplified Outputs—Low Power Mode with One Speaker"

• Updates Figure 2-7, "Using the Amplified Outputs—High Power Mode with One Speaker"

• Updates Figure 2-8, "Using the Amplified Outputs—High Power Mode with Two Speakers"

• Updates Figure 2-13, "Connections Behind the Port Cover"

• Updates Figure 2-14, "Connecting the Strobe"

• Updates Figure 2-15, "Connecting the Strobe"

Browsers Supported

The following browsers have been tested against firmware version 6.5.0:

• Internet Explorer (version: 10)

• Firefox (also called Mozilla Firefox) (version: 23.0.1 and 25.0)

• Chrome (version: 29.0.1547.66 m)

• Safari (version: 5.1.7)

Operations Guide 931236C CyberData Corporation

Pictorial Alert Icons

GENERAL ALERT

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Hazard Levels

Danger: Indicates an imminently hazardous situation which, if not avoided, will result in death or
serious injury. This is limited to the most extreme situations.

Warning: Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injur

General Alert

This pictoral alert indicates a potentially hazardous situation. This alert will be
followed by a hazard level heading and

more specific information about the

hazard.

Ground

This pictoral alert indicates the Earth grounding connection point.

y.

Caution: Indicates a potentially hazardous situation which, if not avoide
moderate injury. It may also alert users against unsafe practices.

Notice: Indicates a statement of company policy (that is, a saf

• The safety guidelines for the equipment in this manual do not purport to address all the safety
issues of the equipment. It is the responsibility of the user to estab
ergonomic, and health practices and determine the applicability of regulatory limitations prior to
use. Potential safety hazards are identified in this manual through the use of words Danger,
Warning, and Caution, the specific hazard type, and pictorial alert icons.

ety policy or protection of property).

d, could result in minor or

lish appropriate safety,

Operations Guide 931236C CyberData Corporation

Important Safety Instructions

GENERAL ALERT

GENERAL ALERT

GENERAL ALERT

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any v entilation openings . Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers , stov es , or other apparatus
(includin

g amplifiers) that produce heat.

9. Do not d
two bl
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they

11. Only use attachments/accessories specified by the manufacturer.

12. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any w
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.

13. Prior to installation, consult local building and electrical code requirements.

14. WARNING: The SIP Loudspeaker Amplifier (PoE) enclosure is not rated fo
voltages!

efeat the safety purpose of the polarized or grounding-type plug. A polarized plug has

ades with one wider than the other. A grounding type plug has two blades and a third

exit from the apparatus.

ay, such as power-supply cord or plug is damaged, liquid has been

r any AC

Warning

Electrical Hazard: This product should be installed by a licensed electrician

according to all local electrical and building codes.

Warning

Electrical Hazard: To prevent injury, this apparatus must be securely attached to

the floor/wall in accordance with the installation instructions.

Warning

The PoE connector is intended for intra-building connections only and does not
route to the outside plant.

Operations Guide 931236C CyberData Corporation

Abbreviations and Terms

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Abbreviation or Term Definition

A-law A standard companding algorithm, used in European digital

communications systems to optimize, i.e., modify, the dynamic range of an

analog signal for digitizing.
AVP Audio Video Profile
Cat 5 TIA/EIA-568-B Ca
DHCP Dynamic Host Configuration Protocol
LAN Local Area Network
LED Light Emitting Diode
Mbps Megabits per Second.
NTP Network Time Protocol
PBX Private Branch Exchange
PoE Power over Ethernet (as per IEEE 802.3af standard)
RTFM Reset Test Function Management
SIP Session Initiated Protocol
u-law A companding algorithm, primarily used in the digital telecommunication
UC Unified Communications
VoIP Voice over Internet Protoc ol

tegory 5

Operations Guide 931236C CyberData Corporation

Contents

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Chapter 1 Product Overview 1

1.1 How to Identify This Product .....................................................................................................1

1.2 Typical System Installation .......................................................................................................2

1

.3 Product Features ......................................................................................................................3

1

.4 Supported Protocols .................................................................................................................4

.5 Supported SIP Servers .............................................................................................................4

1
1

.6 Specifications ...........................................................................................................................5

1

.7 Typical Coverage ......................................................................................................................5

.8 Typical Warehouse Paging Setup .............................................................................................6

1

Chapter 2 Installing the SIP Loudspeaker Amplifier (PoE) 7

2.1 Parts List ..................................................................................................................................7

2.2 SIP Loudspeaker Amplifier (PoE) Setup ...................................................................................8

2.2.1 SIP Loudspeaker Amplifier (PoE) Components .............................................................9

2.2.2 NEMA Box Components of the SIP Loudspeaker Amplifier (PoE) ...............................10

2.2.3 Connecting the SIP Loudspeaker Amplifier (PoE) .......................................................11

2.2.4 SIP Loudspeaker Amplifier (PoE) System Installation and Connection Options ..........14

2.2.5 Strobe Connections Behind the Port Cover .................................................................16

2.2.6 Connecting the Strobe .................................................................................................17

2.2.7 SIP Loudspeaker Amplifier (PoE) Jumpers ..................................................................19

2.2.8 Ethernet Connection ....................................................................................................19

2.2.9 Loudspeaker Type ........................................................................................................20

2.2.10 Cabling/Wiring ............................................................................................................

2.2.11 Confir

2.2.12 Confirm the IP Address and Test the Audio ...............................................................22

2.2.13 Adjust the Volume ......................................................................................................23

2.3.1 Factory Default Settings ...............................................................................................25

2.3.2 SIP Loudspeaker Amplifier (PoE) Web Page Navigation .............................................26

2.3.3 Using the Toggle Help Button .......................................................................................27

2.3.4 Log in to the Configuration Home Page .......................................................................29

2.3.5 Configure the Device ....................................................................................................33

2.3.6 Configure the Network Parameters .............................................................................40

2.3.7 Configure the SIP (Session Initiation Protocol) Parameters .........................................43

2.3.8 Configure the Multicast Parameters .............................................................................53

2.3.9 Configure the Sensor Configuration Parameters ..........................................................57

2.3.10 Configure the Audio Configuration Parameters ..........................................................61

2.3.11 Configure the Events Parameters ..............................................................................66

2.3.12 Configure the Autoprovisioning Parameters ...............................................................72

2.4.1 Downloading the Firmware ...........................................................................................84

2.4.2 Reboot the Device ........................................................................................................8

2.5.1 Command In

m Operation ......................................................................................................21

terface Post Commands ..........................................................................87

20

i

6

Appendix A Mounting the Amplifier 91

A.1 Mount the Amplifier ...............................................................................................................91

Appendix B Setting up a TFTP Server 93

B.1 Set up a TFTP Server ............................................................................................................93

B.1.1 In a LINUX Environment ..............................................................................................93

B.1.2 In a Windows Environment .........................................................................................93

Appendix C Troubleshooting/Technical Support 94

C.1 Frequently Asked Questions (FAQ) ........................................................................................94

C.2 Documentation .......................................................................................................................94

.3 Contact Information ................................................................................................................95

C
C

.4 Warranty and RMA Information ..............................................................................................95

Index 96

Operations Guide 931236C CyberData Corporation

1 Product Overview

SIP LOUDSPEAKER AMPLIFIER,

PoE, RoHS COMPLIANT

011405A / 021111H

Model number

WWW.CYBERDATA.NET

405000001

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

The CyberData SIP-enabled SIP Loudspeaker Amplifier (PoE) (PoE) provides an easy method for
implementing an IP-based overhead paging system for both new and legacy installations.

1

The SIP Loudspeaker Amplifier (P oE) provides direct driv
a line-out connector for connection to an external amplifier. The interface is compatible with most
SIP-based IP PBX servers that comply with the SIP RFC 3261. For non-SIP environments, the SIP
Loudspeaker Amplifier (PoE) can be configured to listen to multicast address and port number
combinations to form paging zones.

1.1 How to Identify This Product

To identify the SIP Loudspeaker Amplifier (PoE), look for a model number label similar to the one
shown in Figure 1-1. Confirm the following:

• The model number on the label should be 011405.

Figure 1-1. Model Number Label

e of a standard Horn speaker and supports

Operations Guide 931236C CyberData Corporation

1.2 Typical System Installation

Compliant Non-PoE Ethernet Switch

VoIP Phone

SIP Server

Loudspeaker Amplifier

GENERAL ALERT

GENERAL ALERT

GENERAL ALERT

GENERAL ALERT

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Figure 1-2 illustrates how the SIP Loudspeaker Amplifier (PoE) is normally installed as part of a

public address system.

Figure 1-2. Typical Installation

Product Overview

Typical System Installation

2

Warning

Electrical Hazard: The SIP Loudspeaker Amplifier (PoE) enclosure is not rated

for any AC voltages.

Warning

Electrical Hazard: This product should be installed by a licensed electrician

according to all local electrical and building codes.

Warning

Electrical Hazard: To prevent injury, this apparatus must be securely attached to

the floor/wall in accordance with the installation instructions.

Warning

The PoE connector is intended for intra-building connections only and does not
route to the outside plant.

Operations Guide 931236C CyberData Corporation

1.3 Product Features

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

• SIP-enhanced interoperability for hosted environments

• 9 user-uploadable page messages

• Support for security code access for SIP paging

• Autoprovisioning via HTTPS

• HTTPS web based configuration

• Higher Power PoE 802.3AT

• 802.11q VLAN tagging

• Configurable sense input for use with fault detection

• Configurable event generation for device health and status monitoring

• Optional direct connect RGB strobe kit connection

• Support for G.711 u-law, G.711 a-law, and G.722 codecs

• HTTP Command Interface

• 10 channel prioritized Multicast ports

• Built-in diagnostics

• Delayed page support

• Cisco SRST

• Packaged in a NEMA 3R/IP42-rated enclosure

• SIP and Simultaneous Multicast

• Dual-speed ethernet 10/100 Mbps

• Web-based configuration

• PoE 802.3at and 802.3af-enabled

• Line-in for background music

• Line-out connector

• DTMF controlled relay

• Direct 8 Ohm speaker drive

• User-uploadable tones and messages

• Digital and manual volume control

• Second SIP endpoint "Night Ringer"

• Autoprovisioning

• Auto-call voice message from input port sense

• Can support two horns

Product Overview

Product Features

3

Operations Guide 931236C CyberData Corporation

1.4 Supported Protocols

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

The SIP Loudspeaker Amplifier (PoE) supports:

•SIP

• Multicast

• HTTP and HTTPS web-based configuration
Provides an intuitive user interface for easy system configuration and verification of SIP

oudspeak

L

• DHCP Client
Dynamically assigns IP addresses in addition to the option to use static addressing.

• TFTP Client
Facilitates hosting for the configuration file for Autoprovisioning.

•RTP

• RTP/AVP - Audio Video Profile

• SPEEX

• Audio Encodings
PCMU (G.711 mu-law)
PCMA (G.711 A-law)
G.722
Packet Time 20 ms

er Amplifier (PoE) operations.

Product Overview

Supported Protocols

4

1.5 Supported SIP Servers

The following link contains information on how to configure the SIP Loudspeaker Amplifier (PoE) for
the supported SIP servers:

http://www.cyberdata.net/connecting-to-ip-pbx

-ser

vers/

Operations Guide 931236C CyberData Corporation

1.6 Specifications

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Specifications

Ethernet I/F 10/100 Mbps
Protocol SIP RFC 3261 Compatible
Power Input PoE 802.3at or 802.3af
Audio Output 802.3af - SPL 114 dB @ 1 meter

Line In:
Input Signal Amplitudes
Input Impedance

Line Out:
Output Signal Amplitudes
Output Level
Total Harmonic Distortion
Output Impedance

Operating Temperature -10
Payload Types G.711 a-law, G.711 u-law, and G.722
Dimensions

Boxed Weight 6.5 lbs. [2.95 kg]

b

Table 1-1. Specifications

802.3at - SPL 117 dB @ 1 meter

2.0 VPP maximum
10k Ohm

2.0 VPP maximum
+2dBm nominal

0.5% maximum
10k Ohm

o

C to 50o C (14o F to 122o F)

10 in. [254 mm] Length
4 in. [101.6 mm] Width
14 in. [355.6 mm] Height

Product Overview

Specifications

a
a

5

Part Number 011405
Loudspeaker Part Number 011068

a.When used with the 011068 Mini Horn.
b. Dimensions are measured from the perspective of the product being upright with the front of the
product facing you.

1.7 Typical Coverage

With one horn attached to Paging Amplifier under standard 802.3af PoE power, coverage is up to
5,000 square feet. With two horns attached to the P aging Amplifier under 802. 3at PoE (high power),
coverage is up to 10,000 square feet depending on ambient background noise levels.

Operations Guide 931236C CyberData Corporation

1.8 Typical Warehouse Paging Setup

Typical Example of a 70,000 Square Feet Warehouse Paging Set up

Office Bathroom

25' 25'

Loud Speaker Amplifier

Part Numbers: 011404 and 011405

Horn Speaker Horn SpeakerHorn Speaker Horn Speaker

"High Power Mode" with

Two (2) Horn Speakers Attached

Horn to Loud Speaker Amplifier

Horn Speaker to Horn Speaker

50'

Horn SpeakerHorn Speaker

Loud Speaker Amplifier

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Figure 1-3. Typical Warehouse Paging Setup

Product Overview

Typical Warehouse Paging Setup

6

Operations Guide 931236C CyberData Corporation

2 Installing the SIP Loudspeaker Amplifier

Sheet Metal Screw (3x)

#8x1.25" Truss Head Phillips

531032

Plastic Ribbed Anchor (3x)

151147

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

(PoE)

2.1 Parts List

Table 2-2 illustrates the parts for each SIP Loudspeaker Amplifier (PoE) and includes a kit for

mounting.

Table 2-2. Parts List

Quantity Part Name Illustration

1 SIP Loudspeaker Amplifier (PoE) Assembly

1 Enclosure

7

1 Installation Quick Reference Guide

1 Mounting Accessory Kit which includes:

(3) Plastic Ribbed Anchors
(3) #8 Sheet Metal Screws

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

2.2 SIP Loudspeaker Amplifier (PoE) Setup

Set up and configure each SIP Loudspeaker Amplifier (PoE) before you mount it.
CyberData delivers each SIP Loudspeaker Amplifier (PoE) with the factory default values indicated

in

Table 2-3:

Table 2-3. Factory Default Settings—Default of Network

Parameter Factory Default Setting

IP Addressing DHCP
IP Address
Web Access Username admin
Web Access Password admin
Subnet Mask
Default Gateway

a

a

a

a. Default if there is not a DHCP server present.

10.10.10.10

255.0.0.0

10.0.0.1

8

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Components

SPD Link/Act.

PWR Status

Volume

RTFM

VoIP

Loudspeaker

The IP Endpoint Company

Speaker Volume

Speed (SPD) LED (AMBER)

The Speed (SPD) LED illuminates AMBER for a 100Mb link 
or is off for 10MB when the network link to the device is 
established.

Status LED (GREEN)

After supplying power to the device, a steady GREEN Status LED
illuminates. After about 20 seconds, the

GREEN Status LED will

blink fast to indicate that the device is acquiring an IP address and
attempting to autoprovision. The

GREEN Status LED will turn off

thereafter until the device has finished booting. When the device
has fully booted, the

GREEN Status LED will turn on solid to

confirm the device is operational.
The GREEN Status LED will blink during a page when it is online.

Link/Activity (Link/Act.) LED (GREEN) 

The GREEN Link/Activity (Link/Act.) LED blinks to indicate

network traffic.

Power (PWR) LED (GREEN/BLUE)

The 802.3at power injector that is provided with the device should
cause the Power (PWR) LED to illuminate BLUE to indicate that
high power is available.

The Power (PWR) LED may illuminate GREEN if a low power
mode (

802.3af) power source is used (not included and sold

separately).

RTFM Switch

To broadcast the device’s current IP address, press and hold the
RTFM switch for a couple of seconds and then release it.

To restore the factory defaults, complete the following steps:

1. Press and hold the RTFM switch until you hear the device
announce the words, “restoring defaults” and “rebooting”.

2. Release the RTFM switch. The device will be restored to the
factory default settings.

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

2.2.1 SIP Loudspeaker Amplifier (PoE) Components

Figure 2-4 shows the components of the SIP Loudspeaker Amplifier (PoE).

Figure 2-4. SIP Loudspeaker Amplifier (PoE) Components

SIP Loudspeaker Amplifier (PoE) Setup

9

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

Speaker Connection

Ethernet Connection

RTFM Switch

Volume

LEDs

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

NEMA Box Components of the SIP Loudspeaker Amplifier (PoE)

2.2.2 NEMA Box Components of the SIP Loudspeaker Amplifier (PoE)

Figure 2-5 shows all of the NEMA box components of the SIP Loudspeaker Amplifier (PoE).

Figure 2-5. Loudspeaker Amplifier Components—PoE

10

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

Cat 5 Ethernet Cable

802.3af PoE Ethernet Switch

*

*Note

: The positive (+) wire coming from the speaker

may be red or white. The negative (-) wire is black.

Standard 1 Speaker Configuration

(802.3af mode)

8 Ohms

16 gauge wire

*Note: Use 16 gauge wire

coming out of screw terminals.

+

Note: You can use an

802.3af compliance
switch or an 802.3af
power injector and hub.

Note: Use wire nuts to connect wire
from the speakers to 16 gauge wire.

Twist wire nuts

*Note: Maximum recommended
length of the horn should be 50
feet from the amplifier.

+

802.3af PoE Injector (low power mode)

or

Mono(+)/Left Spkr (+) - 12

Left Spkr (-) - 11

Right Spkr (+) - 10

Mono(-)/Right Spkr (-) - 9

Line-Out (+) - 8

Line-Out (-) - 7

Line-In (-) - 6

Line-In (+) - 5

Relay COM - 4

Relay NO/NC - 3

Door Sense/Button Common (GND) - 2

Door Sense/Button Contact (+) - 1

CLASS II WIRING

+

*Note: Horn is connected to terminal
block pins 9 (-) and 12 (+) of the
paging amplifier for mono mode.

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Connecting the SIP Loudspeaker Amplifier (PoE)

2.2.3 Connecting the SIP Loudspeaker Amplifier (PoE)

2.2.3.1 Using the Amplified Outputs

11

Low Power Mode
(One Speaker)

The following figure illustrate how to connect the SIP Loudspeaker Amplifier (PoE) and use the
amplified outputs in low power mode to one speaker or horn.

Figure 2-6. Using the Amplified Outputs—Low Power Mode with One Speaker

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

Cat 5 Ethernet Cable

*

*Note

: The positive (+) wire coming from the speaker

may be red or white. The negative (-) wire is black.

Standard 1 Speaker Configuration

(802.3at mode)

8 Ohms

16 gauge wire

*Note: Use 16 gauge wire

coming out of screw terminals.

+

Note: Use wire nuts to connect wire
from the speakers to 16 gauge wire.

Twist wire nuts

*Note: Maximum recommended
length of the horn should be 50
feet from the amplifier.

+

802.3at PoE Ethernet Switch

802.3at PoE Injector
(high power mode)

or

Note: You can use an

802.3at compliance
switch or an 802.3at
power injector and hub.

Mono(+)/Left Spkr (+) - 12

Left Spkr (-) - 11

Right Spkr (+) - 10

Mono(-)/Right Spkr (-) - 9

Line-Out (+) - 8

Line-Out (-) - 7

Line-In (-) - 6

Line-In (+) - 5

Relay COM - 4

Relay NO/NC - 3

Door Sense/Button Common (GND) - 2

Door Sense/Button Contact (+) - 1

CLASS II WIRING

+

*Note: Horn is connected to terminal
block pins 9 (-) and 12 (+) of the
paging amplifier for mono mode.

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Connecting the SIP Loudspeaker Amplifier (PoE)

12

High Power Mode
(One Speaker)

The following figure illustrate how to connect the SIP Loudspeaker Amplifier (PoE) and use the
amplified outputs in high power mode to one speaker or horn.

Figure 2-7. Using the Amplified Outputs—High Power Mode with One Speaker

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

802.3at PoE Ethernet Switch

2 speakers in parallel (4 Ohm total)

+

Note: Use wire nuts to connect wire
from the speakers to 16 gauge wire.

Twist wire nuts

Optional 2 Speaker Configuration

(802.3at mode)

8 Ohms

Standard 1 Speaker Configuration

(802.3at mode)

8 Ohms

16 gauge wire

Use 16 gauge wire coming out of screw terminals.
Note: Make sure that the wire length going to the

wire nuts is kept short (approximately 6 inches).

*

*Note

: The positive (+) wire coming from the speaker

may be red or white. The negative (-) wire is black.

++

*Note: Maximum recommended
length of each horn should be 25
feet from the amplifier.

Cat 5 Ethernet Cable

802.3at PoE Injector
(high power mode)

or

Note: You can use an

802.3at compliance
switch or an 802.3at
power injector and hub.

Mono(+)/Left Spkr (+) - 12

Left Spkr (-) - 11

Right Spkr (+) - 10

Mono(-)/Right Spkr (-) - 9

Line-Out (+) - 8

Line-Out (-) - 7

Line-In (-) - 6

Line-In (+) - 5

Relay COM - 4

Relay NO/NC - 3

Door Sense/Button Common (GND) - 2

Door Sense/Button Contact (+) - 1

CLASS II WIRING

+

*Note: Horn is connected to terminal
block pins 9 (-) and 12 (+) of the
paging amplifier for mono mode.

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Connecting the SIP Loudspeaker Amplifier (PoE)

13

High Power Mode
(Two Speakers)

The following figure illustrate how to connect the SIP Loudspeaker Amplifier (PoE) and use the
amplified outputs in high power mode to two speakers or horns.

Figure 2-8. Using the Amplified Outputs—High Power Mode with Two Speakers

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

Mono(+)/Left Spkr (+) - 12

Left Spkr (-) - 11

Right Spkr (+) - 10

Mono(-)/Right Spkr (-) - 9

Line-Out (+) - 8

Line-Out (-) - 7

Line-In (-) - 6

Line-In (+) - 5

Relay COM - 4

Relay NO/NC - 3

Door Sense/Button Common (GND) - 2

Door Sense/Button Contact (+) - 1

CLASS II WIRING

Speaker Connections

(Figure 2-6) (Figure 2-7)(Figure 2-8)

Line-Out Connection (10K Ohm)

Line-In Connection (Figure 2-10)

Relay Connection (Figure 2-11)

Sensor Connection (Figure 2-12)

When line-in is enabled on
the device, the audio
received from the line-in
connection will be played
to the speaker(s) and line­out connection as the low­est priority audio.

Music Source

Loudspeaker Amplifier

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

SIP Loudspeaker Amplifier (PoE) System Installation and Connection Options

2.2.4 SIP Loudspeaker Amplifier (PoE) System Installation and Connection Options

The following figures show the connection options for the SIP Loudspeaker Amplifier (PoE).

Figure 2-9. SIP Loudspeaker Amplifier (PoE) Connections

14

Figure 2-10. Line-In Connection

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) System Installation and Connection Options

When the device is called from a
remote phone, the relay on the
device can be programmed to blink
and drive an LED Strobe Light.

High PIV Ultrafast
Switching Diode

Output Contacts

AC or DC-rated

depending upon

controlled device

requirements

DC Power Supply
(Max. 30 VDC @ 1A)

Solid State or 
Mechanical Relay

AC or DC

Power

Source

IN

OUT

External device
such as an
electric door strike
or an LED Strobe
Light

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Figure 2-11. Relay or LED Strobe Connection

Figure 2-12. Sensor Connection

SIP Loudspeaker Amplifier (PoE) Setup

15

Operations Guide 931236C CyberData Corporation

2.2.5 Strobe Connections Behind the Port Cover

5
4
3
2
1

3
2
1

CLASS II WIRING

MIC IN

STROBE

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

See Figure 2-13 for the additional connection options for the SIP Loudspeaker Amplifier (PoE).

Figure 2-13. Connections Behind the Port Cover

SIP Loudspeaker Amplifier (PoE) Setup

Strobe Connections Behind the Port Cover

16

Microphone Connections
Name Connection Description

MIC IN J6-2 Microphone positive input

Strobe Connections
Name Connection Description

STROBE J9-3 Ground

See Table 2-4 for the descriptions of the connections behind the port cover.

Table 2-4. Connections Behind the Port Cover

J6-1 Microphone chassis ground connections

J6-3

J9-1 Ground
J9-2 Strobe positive power (+24V)

J9-4 I2C data
J9-5 I2C clock

Microphone negative input

Operations Guide 931236C CyberData Corporation

2.2.6 Connecting the Strobe

Rubber Grommets

then Connect Network Cable in to Paging Amplier.

Network Cable

Note:
Network Cable is Not Included.

Network Port

Plugged in to

Network Cable

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

1. Insert the network cable through any available rubber grommet at the bottom of the enclosure.
See Figure 2-14.

2. Connect the Network Cable to the Paging Amplifier. See Figure 2-14.

Figure 2-14. Connecting the Strobe

SIP Loudspeaker Amplifier (PoE) Setup

Connecting the Strobe

17

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

J1

Slot

Slot

Hole Plug &

Grommet

Mounting Screw

Cover Plate

Strobe Cable Kit

(Part of RGB Strobe)

Grommet

RGB Strobe

Cable

Back Plate

Screw

Mounting

MIC IN

STROBE

to STROBE

011288 Auxiliary RGB Strobe Kit

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Connecting the Strobe

3. Remove the mounting screw to remove the cover plate. See Figure 2-15.

4. Remove the hole plug and grommet. See Figure 2-15.

5. Slide the cover plate through the slot on the cable grommet. See Figure 2-15.

6. Install the mounting screw to secure the cover plate. See Figure 2-15.

18

Figure 2-15. Connecting the St

robe

Operations Guide 931236C CyberData Corporation

2.2.7 SIP Loudspeaker Amplifier (PoE) Jumpers

JP4

JP5

JP3

JP2

JP1

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

See Figure 2-16 for the jumper locations.

Figure 2-16. Jumper Locations

SIP Loudspeaker Amplifier (PoE) Setup

SIP Loudspeaker Amplifier (PoE) Jumpers

19

See Table 2-5 for the jumper descriptions.

Jumper Description

JP1 Reset—Factory Only
JP2 RTFM (not installed)
JP3 Audio Enable Jumper—Factory Only
JP4 Rel ay NO/NC (default to NO)—Factory Only
JP5 PoE IEEE 802.3at—Factory Only

2.2.8 Ethernet Connection

See Table 2-6 for details about the SIP Loudspeaker Amplifier (PoE) connection.

Connection Connection Details Location

Ethernet Use a RJ 45 cable. SIP Loudspeaker Amplifier

Table 2-5. Jumper Descriptions

Table 2-6. SIP Loudspeaker Amplifier (PoE) Connection

(PoE)

Operations Guide 931236C CyberData Corporation

2.2.9 Loudspeaker Type

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Using the amplified output, the CyberData SIP Loudspeaker Amplifier (PoE) supports the 011068
Loudspeaker or equivalent unamplified loudspeaker.

SIP Loudspeaker Amplifier (PoE) Setup

Figure 2-17. 011068 Loudspeaker

Loudspeaker Type

20

2.2.10 Cabling/Wiring

Using the amplified output, you may connect a 011068 loudspeaker or equivalent unamplified
speaker to a SIP Loudspeaker Amplifier (PoE-powered) with good quality speaker wire that is 16
gauge and limited to 25 feet in length with two loudspeakers or 50 feet in length with one
loudspeaker.

Operations Guide 931236C CyberData Corporation

2.2.11 Confirm Operation

SPD

PWR

Link/Act

Status

Volume

Power (PWR) LED
(BLUE/GREEN)

Speed (SPD) LED
(AMBER)

Link/Activity (Link/Act.) LED
(GREEN)

Status LED
(GREEN)

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

After connecting the device to the 802.3af compliant ethernet hub, use the LEDs on the device to
confirm that the device is operational and linked to the network.

LED Color Function

SIP Loudspeaker Amplifier (PoE) Setup

Table 2-7. SIP Loudspeaker Amplifier (PoE) LEDs

Confirm Operation

21

Power (PWR) BLUE/GREEN

Status

Speed (SPD) AMBER The Speed (SPD) LED il

Link/Activity (Link/Act.) GREEN The Link/Activity (Link/Act.)

GREEN After supplying power to the device, a steady GREEN Status LED

The 802.3at power injector that is provided with the device should
cause the Power (PWR) LED to illuminate BLUE to indicate that high
power is available.

The Power (P WR) LED may illuminate GREEN if a low power mode
(802.3af) power source is used (not included and sold separately).

illuminates.
After about 20 seconds, the

indicate that the device is acquiring an IP address and attempting to
autoprovision. The
the device has finished booting. When the device has fully booted,
the GREEN Status LED will turn on solid to confirm the device is
operational.

The GREEN Status LED will blink during a page when it is online.

for 10MB when the network link to the device is established.

network traffic.

GREEN Status LED will turn off thereafter until

GREEN Status LED will blink fast to

luminates AMBER for a 100Mb link or is off

Figure 2-18. SIP Loudspeaker Amplifier (PoE) LEDs

GREEN LED blinks to indicate

Operations Guide 931236C CyberData Corporation

2.2.12 Confirm the IP Address and Test the Audio

GENERAL ALERT

RTFM switch

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

2.2.12.1 RTFM Switch

When the SIP Loudspeaker Amplifier (PoE) is operational and linked to the network, use the Reset
Test Function Management (RTFM) switch (Figure 2-19) on the SIP Loudspeaker Amplifier (PoE)
face to announce and confirm the SIP Loudspeaker Amplifier (PoE)’s IP Address and test the audio
to v

erify that it is working.

Figure 2-19. RTFM Switch

SIP Loudspeaker Amplifier (PoE) Setup

Confirm the IP Address and Test the Audio

22

Announcing the IP Address

Restoring the Factory Default Settings

To announce a SIP Loudspeaker Amplifier (PoE)’s current IP address:

• Press and hold the RTFM switch for a couple of seconds and then release it.

Caution

Equipment Caution: Pressing and holding the RTFM switch for more than five
seconds will restore the device to the factory default settings. See the “Restoring

the Factory Default Settings” section.

To restore the factory default settings, complete the following steps:

1. Press and hold the RTFM switch until you hear the device announce the words, “restoring
defaults” and “rebo

2. Release the RTFM switch. The device will be restored to the factory default settings.

oting”.

Operations Guide 931236C CyberData Corporation

2.2.13 Adjust the Volume

SPD

PWR

Link/Act

Status

Volume

External volume dial

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

There are two ways to adjust the volume for the SIP Loudspeaker Amplifier (PoE):

• The SIP Volume setting on the Device Configuration Page

• The external Vol

SIP Loudspeaker Amplifier (PoE) Setup

Adjust the Volume

ume dial (Figure 2-21) on the SIP Loudspeaker Amplifier (PoE) face

Figure 2-20. External Volume Dial

23

2.2.13.1 The SIP Volume Setting

To adjust the volume of the de vice with the SIP Volume setting on the Device Configuration Page,
complete the following steps:

1. Go to the Home Page.

2. Select the Device Configuration Page page.

3. In the SIP Volume box, type a number between 0 (lo

4. Select Save.

2.2.13.2 The Multicast Volume Setting

To adjust the Multicast Volume volume with the Multicast Volume setting on the Device

Configuration Page, complete the following steps:

1. Go to the Home Page.

2. Select the Device Configuration Page.

3. In the Multicast Volume box, type a number between 0 (lo

4. Select Save.

west) and 9 (highest).

west) and 9 (highest).

Operations Guide 931236C CyberData Corporation

2.2.13.3 The Ring Volume Setting

SPD

PWR

Link/Act

Status

Volume

External volume dial

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

To adjust the Ring Volume volume with the Ring Volume setting on the Device Configuration

Page, complete the following steps:

1. Go to the Home Page.

2. Select the Device Configuration Page.

SIP Loudspeaker Amplifier (PoE) Setup

Adjust the Volume

24

3. In the Multicast Volume box, type a number between 0 (lo

4. Select Save.

2.2.13.4 The Sensor Volume Setting

To adjust the Sensor V olume v olume with the Sensor V olume setting on the De vice Configuration

Page, complete the following steps:

1. Go to the Home Page.

2. Select the Device Configuration Page.

3. In the Sensor Volume box, type a number between 0 (lo

4. Select Save.

2.2.13.5 External Volume Dial

To adjust the SIP Loudspeaker Amplifier (PoE) volume with the external volume dial, complete the
following steps:

1. Turn the external Vol

Note For the lineout volume, the volume is fixed and the volume control is adjus

external amplifier.

west) and 9 (highest).

west) and 9 (highest).

ume dial (Figure 2-20) on the SIP Loudspeaker Amplifier (PoE) face.

ted through an

Figure 2-21. External Volume Dial

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Factory Default Settings

2.3 Configure the SIP Loudspeaker Amplifier (PoE) Parameters

To configure the SIP Loudspeaker Amplifier (PoE) online, use a standard web browser.

25

Configure each SIP Loudspeaker Amplifier (PoE) and verify its operation befor
you are ready to mount an SIP Loudspeaker Amplifier (PoE), refer to Appendix A, "Mounting the

Intercom" for instructions.

2.3.1 Factory Default Settings

All SIP Loudspeaker Amplifier (PoE)s are initially configured with the following default IP settings:
When configuring more than one SIP Loudspeaker Amplifier (PoE), attach the SIP Loudspeaker

Amplifier (PoE)s to the networ

Parameter Factory Default Setting

IP Addressing DHCP
IP Address
Web Access Username admin
Web Access Password admin
Subnet Mask
Default Gateway

e you mount it. When

k and configure one at a time to avoid IP address conflicts.

Table 2-8. Factory Default Settings

a

a

a

10.10.10.10

255.0.0.0

10.0.0.1

a. Default if there is not a DHCP server present.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

SIP Loudspeaker Amplifier (PoE) Web Page Navigation

2.3.2 SIP Loudspeaker Amplifier (PoE) Web Page Navigation

Table 2-9 shows the navigation buttons that you will see on every SIP Loudspeaker Amplifier (PoE)

web page.

Table 2-9. Web Page Navigation

Web Page Item Description

Link to the Home page.

Link to the Device page.

Link to the Network page.

Link to go to the SIP page.

26

Link to the Multicast page.

Link to the Sensor page.

Link to the Audiofiles page.

Link to the Events page.

Link to the Autoprovisioning page.

Link to the Firmware page.

Operations Guide 931236C CyberData Corporation

2.3.3 Using the Toggle Help Button

Toggle Help button

Question mark 
appears next to the
web page items

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

The Toggle Help button allows you to see a short description of some of the settings on the
webpage. To use the Toggle Help button, do the following:

SIP Loudspeaker Amplifier (PoE) Setup

Using the Toggle Help Button

27

1. Click on the Tog

2. You will see a question mark (
with a short description by the Help feature. See Figure 2-23.

Figure 2-23. Toggle Help Button and Question Marks

gle Help button that is on the UI webpage. See Figure 2-22 and Figure 2-23.

Figure 2-22. Toggle/Help Button

) appear next to each web page item that has been provided

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

A short description of the 
web page item will appear

Question mark

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Using the Toggle Help Button

3. Move the mouse pointer to hov er ov er the question mark ( ), and a short description of the web
page item will appear. See Figure 2-24.

Figure 2-24. Short Description Provided by the Help Feature

28

Operations Guide 931236C CyberData Corporation

2.3.4 Log in to the Configuration Home Page

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

1. Open your browser to the SIP Loudspeaker Amplifier (PoE) IP address.

SIP Loudspeaker Amplifier (PoE) Setup

Log in to the Configuration Home Page

29

Note If the network does not hav

address of 10.10.10.10.

Note Make sure that the PC is on the same IP network as the SIP Loudspeak
Note You may also

easily find and configure the default web address of the CyberData VoIP products. 



CyberData’s VoIP Discovery Utility program is available at the following website address:

http://www.cyberdata.net/assets/common/discovery.zip

Note The device ships in DHCP mode. To get to the Home page, use the discovery utility to scan

for the device on the network and open your browser from there.

2. When prompted, use the following default Web Acc
Password to access the Home Page (Figure 2-25):

Web Access Username: admin
Web Access Password: admin

download CyberData’s VoIP Discovery Utility program which allows you to

e access to a DHCP server, the device will default to an IP

er Amplifier (PoE).

ess Username and Web Access

Operations Guide 931236C CyberData Corporation

Figure 2-25. Home Page

v11.6.2

405000001

CyberData Paging Amplifier

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

SIP Loudspeaker Amplifier (PoE) Setup

Log in to the Configuration Home Page

30

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Log in to the Configuration Home Page

3. On the Home page, review the setup details and navigation buttons described in Table 2-10.

31

Note The question mark icon (

after the Toggle Help bu

) in the following table shows which web page items will be defined

tton is pressed.

Table 2-10. Home Page Overview

Web Page Item

Admin Settings

Username The username to access the web interface. Enter up to 25 characters.
Password
Confirm Password

Current Status

Serial Number Shows the devic e serial number.
Mac Address Shows the device Mac address.
Firmware Version Shows the current firmware version.
IP Addressing Shows the current IP addressing setting (DHCP or st

IP Address Shows the current IP address.
Subnet Mask Shows the current subnet mask address.
Default Gateway Shows the current default gateway address.
DNS Server 1 Shows the current DNS Server 1 address.

Description

The password to access the web interface. Enter up to 25 characters.
Confirm the web interface password.

atic).

DNS Server 2 Shows the current DNS Server 2 address.
SIP Mode Shows the current status of the SIP mode.
Multicast Mode Shows the current status of the Multicast mode.
Event Reporting Shows the current status of the Event Reporting mode.
Nightringer Shows the current status of the Nightringer mode.
Primary SIP Server Shows the current status of the Primary SIP Server.
Backup Server 1 Shows the current status of Backup Server 1.
Backup Server 2 Shows the current status of Backup Server 2.
Nightringer Server

Import Settings

Export Settings

Shows the current status of Nightringer Server.

Use this button to select a configuration file to import.

After selecting a configuration file, click Import to import the
configuration from the selected file. Then, click Save and Reboot to
store changes.

Click Export to export the current configuration to a file.

Click the Save button to save your configuration settings.
Note: You nee d to reboot for changes to take effect.

Operations Guide 931236C CyberData Corporation

Table 2-10. Home Page Overview (continued)

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Web Page Item Description

Click on the Reboot button to reboot the system.

Click on the Toggle Help button to see a short description of some of
the web page items. First click on the Toggle Help button, and you will
see a question mark (
Move the mouse pointer to hover over a question mark to see a short
description of a specific web page item.

SIP Loudspeaker Amplifier (PoE) Setup

Log in to the Configuration Home Page

) appear next to some of the web page items.

32

Operations Guide 931236C CyberData Corporation

2.3.5 Configure the Device

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

1. Click the Device menu button to open the Device page. See Figure 2-26.

Figure 2-26. Device Configuration Page

SIP Loudspeaker Amplifier (PoE) Setup

Configure the Device

33

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Device

2. On the Device page, you may enter values for the parameters indicated in Table 2-11.

34

Note The question mark icon (

after the Toggle Hel

p button is pressed.

) in the following table shows which web page items will be defined

Table 2-11. Device Configuration Parameters

Web Page Item Description

Volume Settings (0-9)

Disable Volume Control Dial Select this option to disable the volume control dial and enable digital

volume control settings.

SIP Volume

Multicast Vo lume

Ring Volume

Sensor Volume

Volume Boost:
No Volume Boost
+4dB

Clock Settings

Set Time with NTP Server on boot When selected, the time is set with an external NTP server when the

NTP Server

Posix Timezone String

Periodically sync time with server

Set the speaker volume for a SIP call. A value of 0 will mute the speaker
during SIP calls.

Set the speaker volume for multicast audio streams. A value of 0 will mute
the speaker during multicasts.

Set the ring volume for incoming calls. A value of 0 will mute the speaker
instead of playing the ring tone when Auto-Answer Incoming Calls is
disabled.

Set the speaker volume for playing sensor activated audio. A value of 0
will mute the speaker during sensor activated audio.

Set the Boost level to increase the volume output of the speaker. Using
Volume Boost may introduce audio clipping and/or distortion. Boost is
only recommended for use with volumes set to level 9.

device restarts.
Use this field to set the address (in IPv4 dotted decimal notation or as a

canonical name) for the NTP Server. This field can accept canonical
names of up to 64 characters in length.

See Section 2.3.5.1, "Time Zon e Strings" for information about how to
use the Posix Timezone String to specify time zone and daylight savings
time where applicable. Enter up to 63 characters.

When selected, the time is periodically updated with the NTP server at
the configured interval below.

Time update period (in hours)

Current Time

Power Settings

802.3AT Mode This device automatically detects if it is plugged into an 802.3AT (also

Force 802.3AT Mode (NOT recommended)

Auxiliary Pow er Supply

Operations Guide 931236C CyberData Corporation

The time interval after which the device will contact the NTP server to
update the time. Enter up to 4 digits.

Allows you to input the current time. (6 character limit)

known as PoE Plus) power source. 802.3AT provides more power than
older 802.3AT power sources and allows this speaker to play audio at
higher volumes. If you are sure this speaker is connected to an 802.3AT
power source, but it is not being detected correctly, you can override the
automatic settings below.

Enable this option if you are sure this speaker is connected to an 802.3A T
power source, but it is not being detected correctly (not recommended).

This device can be connected to a +24VDC auxiliary power supply.
Check this box if this is how this speaker is being powered.

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Device

Table 2-11. Device Configuration Parameters (continued)

Web Page Item Description

Line-In Settings

Enable Line-in to Line-out Loopback Line-in audio will play back out the device's audio output ports. This is the

lowest priority audio and will be preempted by any other audio stream.

DTMF Settings

Require Security Code When selected, the user will be prompted to enter a Security Code

(entered on this page) before being able to execute a page when calling
the device.

Security Code

Relay Settings

Activate Relay with DTMF Code Activates the relay when the DTMF Activation Code is entered on the

Relay Pulse Code

Relay Pulse Duration (in seconds)

Relay Activation Code

Relay Deactivation Code

Activate Relay During Ring

Activate Relay During Night Ring

Activate Relay While Call Active

Misc Settings

Type the Security Code in this field. The Security Code must only use
characters '0-9', '*' and '#'. Enter up to 25 characters.

phone during a SIP call with the device. RFC2833 DTMF payload types
are supported.

DTMF code used to pulse the relay when entered on a phone during a
SIP call with the device. Relay will activate for Relay Pulse Duration
seconds then deactivate. Activate Relay with DTMF Code must be
enabled. Enter up to 25 digits (* and # are supported).

The length of time (in seconds) during which the relay will be activated
when the DTMF Relay Activation Code is detected. Enter up to 5 digits.

Activation code used to activate the relay when entered on a phone
during a SIP call with the device. Relay will be active indefinitely, or until
the DTMF Relay Deactivation code is entered. Activate Relay with DTMF
Code must be enabled. Enter up to 25 digits (* and # are supported).

Code used to deactivate the relay when entered on a phone during a SIP
call with the device. Activate Relay with DTMF Code must be enabled.
Enter up to 25 digits (* and # are supported).

When selected, the relay will be activated for as long as the device is
ringing. When Auto-Answer Incoming Calls is enabled, the device will not
ring and this option does nothing.

When selected, the relay will be activated as long as the Nightringer
extension is ringing.

When selected, the relay will be activated as long as the SIP call is active.

35

Device Name Type the device name. Enter up to 25 characters.
Auto-Answ er Incoming Calls

Beep on Init
Beep on Page

Disable HTTPS (NOT recommended)

Two Speakers Connected

Operations Guide 931236C CyberData Corporation

When selected, the device will automatically answer incoming calls.
When Auto-Answer Incoming Calls is disabled, the device will play a
ring tone (corresponds to Ring Tone on the Audiofiles page) out of the

r.

speake
Device will play the user-defined “pagetone” audio file when it boots.
Device will play the user defined “pagetone” audio file before playing a

SIP page.
Disables the encrypted connection to the webpage. We do not

recommend disabling HTTPS for security reasons.
Specify if one or two speakers are connected to the device. If only one is

connected, ensure that it is wired to the first set of terminal blocks.

Table 2-11. Device Configuration Parameters (continued)

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Web Page Item Description

RGB Strobe Status of optional RGB Strobe.

Click on the Test Audio button to do an audio test. When the Test Au dio
button is pressed, you will hear a voice message for testing the device
audio quality and volume.

Click on the Test Relay button to do a relay test.

Click the Save button to save your configuration settings.
Note: You need to reboo t for changes to take effect.

Click on the Reboot button to reboot the system.

Click on the Toggle Help button to see a short description of some of the
web page items. First click on the Toggle Help button, and you will see a
question mark ( ) appear next to some of the web page items. Mov e the
mouse pointer to hover over a question mark to see a short description of
a specific w

eb page item.

SIP Loudspeaker Amplifier (PoE) Setup

Configure the Device

36

Note You can change the SIP Volume, Multicast Volume, Ring Volume, and Sensor Volume

without rebooting the device. You must save and reboot the device for other changes to take
effect.

Operations Guide 931236C CyberData Corporation

2.3.5.1 Time Zone Strings

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

The posix time zone string tells the internal date and time utilities how to handle daylight savings
time for different time zones. Table 2-24 shows some common strings.

Time Zone Time Zone String

US Pacific time PST8PDT,M3.2.0/2:00:00,M11.1.0/2:00:00
US Mountain time MST7MDT,M3.2.0/2:00:00,M11.1.0/2:00:00
US Eastern Time EST5EDT,M3.2.0/2:00:00,M11.1.0/2:00:00
Phoenix Arizona
US Central Time CST6DST,M3.2.0/2:00:00,M11.1.0/2:00:00

a.Phoenix, Arizona does not use daylight savings time.

Table 2-25 shows a breakdown of the parts that constitute the following time zone string:

● CST6DST,M3.2.0/2:00:00,M11.1.0/2:00:00

SIP Loudspeaker Amplifier (PoE) Setup

Configure the Device

37

Table 2-12. Common Time Zone Strings

a

MST7

Table 2-13. Time Zone String Parts

Time Zone String

Meaning

Part

CST6CDT The time zone offset from GMT and three character identifiers for the time zone.
CST Central Standard Time
6 The (hour) offset from GMT/UTC
CDT
M3.2.0/2:00:00 The date and time when daylight savings begins.
M3 The third month (March)
.2 The 2nd occurrence of the day (next item) in the month
.0 Sunday
/2:00:00
M11.1.0/2:00:00 The date and time when daylight savings ends.
M11 The eleventh month (November)
.1 The 1st occurrence of the day (ne
.0 Sunday
/2:00:00 Time of day to change

Central Daylight Time

Time of day to change

xt item) in the m

onth

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Device

38

Time Zone String Examples

Time Zone Identifier

Table 2-26 has some more examples of time zone strings.

Table 2-14. Time Zone String Examples

Time Zone Time Zone String

a

Tokyo
Berlin

b

IST-9
CET-1MET,M3.5.0/1:00,M10.5.0/1:00

a.Tokyo does not use daylight savings time.
b.For Berlin, daylight savings time starts on the last Sunday in March at
01:00 UTC, and ends on the last Sunday in October at 01:00 UTC, and is one
hour ahead of UTC.

A user-definable three or four character time zone identifier (such as PST, EDT, IST, MUT, etc) is
needed at the beginning of the posix time zone string to properly set the time. However, the specific
letters or numbers used for the time zone identifier are not important and can be any three or four
letter or number combination that is chosen by the user. Ho w ever , the time z one identifier cannot be
blank.

Figure 2-27. Three or Four Character Time Zone Identifier

You can also use the f

ollowing URL when a certain time zone applies daylight savings time:

http://www.timeanddate.com/time/dst/2011.html

World GMT Table

Table 2-27 has information about the GMT time in various time zones.

Table 2-15. World GMT Table

Time Zone City or Area Zone Crosses

GMT-12 Eniwetok
GMT-11 Samoa
GMT-10 Hawaii
GMT-9 Alaska
GMT-8 PST, Pacific US
GMT-7 MST, Mountain US
GMT-6 CST, Central US
GMT-5 EST, Eastern US
GMT-4 Atlantic, Canada
GMT-3 Brazilia, Buenos Aries
GMT-2 Mid-Atlantic
GMT-1 Cape Verdes
GMT Greenwich Mean Time, Dublin
GMT+1 Berlin, Rome
GMT+2 Israel, Cairo
GMT+3 Moscow, Kuwait
GMT+4 Abu Dhabi, Muscat

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Table 2-15. World GMT Table (continued)

Time Zone City or Area Zone Crosses

GMT+5 Islamabad, Karachi
GMT+6 Almaty, Dhaka
GMT+7 Bangkok, Jakarta
GMT+8 Hong Kong, Beijing
GMT+9 Tokyo, Osaka
GMT+10 Sydney, Melbourne, Guam
GMT+11 Magadan, Soloman Is.
GMT+12 Fiji, Wellington, Auckland

Configure the Device

39

Operations Guide 931236C CyberData Corporation

2.3.6 Configure the Network Parameters

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

1. Click the Network menu button to open the Network page (Figure 2-28).

Figure 2-28. Network Configuration Page

SIP Loudspeaker Amplifier (PoE) Setup

Configure the Network Parameters

40

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Network Parameters

2. On the Network page, enter values for the parameters indicated in Table 2-16.

41

Note The question mark icon (

after the Toggle Hel

p button is pressed.

) in the following table shows which web page items will be defined

Table 2-16. Network Configuration Parameters

Web Page Item Description

Stored Network Settings

Addressing Mode Select either DHCP IP Addressing or Static Addressing by marking

the appropriate radio button. DHCP Addressing mode is enabled on
default and the device will attempt to resolve network addressing with
the local DHCP server upon boot. If DHCP Addressing fails, the
device will revert to the last known IP address or the factory default
address if no prior DHCP lease was established. See Section 2.3.1,

"Factory Default Settings" for f actory default settings. Be sure to click

Save and Reboot to store changes when configuring a Static
address.

Hostname This is the hostname provided by the DHCP server. See the

DHCP/DNS server documentation for more information. Enter up to

64 characters.
IP Address Enter the Static IPv4 network address in dotted decimal notation.
Subnet Mask Enter the Subnet Mask in dotted decimal notation.
Default Gateway Enter the Default Gateway IPv4 address in dotted decimal notation.
DNS Server 1 Enter the primary DNS Server IPv4 address in dotted decimal

notation.
DNS Server 2 Enter the secondary DNS Server IPv4 address in dotted decimal

notation.
DHCP Timeout in seconds Specify the desired time-out duration (in seconds) that the device will

wait for a response from the DHCP server before reverting back to

the stored static IP address. The stored static IP address may be the

last known IP address or the factory default address if no prior DHCP

lease was established. Enter up to 8 characters. A value of -1 will

retry forever.
Current Network Settings Shows the current network settings.
IP Address Shows the current Static IP address.
Subnet Mask Shows the current Subnet Mask address.
Default Gateway Shows the current Default Gateway address.
DNS Server 1 Shows the current DNS Server 1 address.
DNS Server 2 Shows the current DNS Server 2 address.

VLAN Settings

VLAN ID (0-4095) Specify the IEEE 802.1Q VLAN ID number. Enter up to 4 digits.

Note: The device supports 802.1Q VLAN tagging support. The

switch port connected to the device will need to be in “trunking mode”

for the VLAN tags to propagate.
VLAN Priority (0-7) Specify the IEEE 802.1p VLAN priority level. Enter 1 digit. A v alue of

0 may cause the VLAN ID tag to be ignored.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Network Parameters

Table 2-16. Network Configuration Parameters (continued)

Web Page Item Description

Click the Save button to save your configuration settings.

Note: You need to reboot for changes to take effect.

Click on the Reboot button to reboot the system.

Click on the Toggle Help button to see a short description of some of

the web page items. First click on the Toggle Help button, and you

will see a question mark ( ) appear next to some of the web page

items. Move the mouse pointer to hover over a question mark to see

a short description of a specific web page item.

Note You must click on the Save button and then the Reboot button for the changes to take

effect.

42

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the SIP (Session Initiation Protocol) Parameters

2.3.7 Configure the SIP (Session Initiation Protocol) Parameters

1. Click on the SIP menu button to open the SIP page (Figure 2-29).

Figure 2-29. SIP Configuration Page—Top

43

Operations Guide 931236C CyberData Corporation

Configure the SIP (Session Initiation Protocol) Parameters

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Figure 2-30. SIP Configuration Page—Bottom

SIP Loudspeaker Amplifier (PoE) Setup

44

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the SIP (Session Initiation Protocol) Parameters

2. On the SIP page, enter values for the parameters indicated in Table 2-17.

45

Note The question mark icon (

after the Toggle Hel

p button is pressed.

) in the following table shows which web page items will be defined

Table 2-17. SIP Configuration Parameters

Web Page Item Description

SIP Settings

Enable SIP Operation When enabled, the device will transmit, receive, and process SIP

messages according to the configured SIP settings below.

Register with a SIP Server When enabled, the device will attempt to register to the configured SIP

Server(s) on this page. To configure the device to send and receive point­to-point SIP calls, enable SIP Operation and disable Register with a SIP
Server (see Section 2.3.7.2, "Point-to-Point Configuration").

Use Cisco SRST When enabled, the backup servers are handled according to Cisco SRST

(Survivable Remote Site Telephony). It is required for use in clustered
Cisco Unified Communications Manager topologies.

Primary SIP Server Enter the SIP server address as an IPv4 address in dotted decimal

notation or a fully qualified domain name. This parameter also becomes
the host portion of the SIP-URI for the device's extension on the primary
SIP server. This field can accept entries of up to 255 characters in length.

Primary SIP User ID Specify the SIP User ID for the Primary SIP Server. This parameter

becomes the user portion of the SIP-URI for the de vice's e xtension on the
primary SIP server. Enter up to 64 alphanumeric characters.

Primary SIP Auth ID Specify the Authenticate ID for the Primary SIP Server. This parameter is

required for SIP registration authentication. Enter up to 64 alphanumeric
characters.

Primary SIP Auth Password Specify the Authenticate Password for the Primary SIP Server. This

parameter is required for SIP registration authentication. Enter up to 64
alphanumeric characters.

Backup SIP Server 1 Enter the backup SIP server address as an IPv4 address in dotted

decimal notation or a fully qualified domain name. This parameter also
becomes the host portion of the SIP-URI for the device's extension on the
backup SIP server. This field can accept entries of up to 255 characters in
length.

Backup SIP User ID 1 Specify the SIP User ID for the first backup SIP Server. This parameter

becomes the user portion of the SIP-URI for the de vice's e xtension on the
first backup SIP server. Enter up to 64 alphanumeric characters.

Backup SIP Auth ID 1 Specify the Authenticate ID for the first backup SIP server. This parameter

is required for SIP registration authentication. Enter up to 64 alphanumeric
characters.

Backup SIP Auth Password 1 Specify the Authenticate Password for the first backup SIP server. This

parameter is required for SIP registration authentication. Enter up to 64
alphanumeric characters.

Backup SIP Server 2 Enter a second backup SIP server address as an IPv4 address in dotted

decimal notation or a fully qualified domain name. This parameter also
becomes the host portion of the SIP-URI for the device's extension on the
second backup SIP server. This field can accept entries of up to 255
characters in length.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the SIP (Session Initiation Protocol) Parameters

Table 2-17. SIP Configuration Parameters (continued)

Web Page Item Description

Backup SIP User ID 2 Specify the SIP User ID for the second bac kup SIP Server. This par ameter

becomes the user portion of the SIP-URI for the de vice's e xtension on the
second backup SIP server. Enter up to 64 alphanumeric characters.

Backup SIP Auth ID 2 Specify the Authenticate ID for the second backup SIP server. This

parameter is required for SIP registration authentication. Enter up to 64
alphanumeric characters.

Backup SIP Auth Password 2 Specify the Authenticate P ass word f or the second backup SIP server . This

parameter is required for SIP registration authentication. Enter up to 64
alphanumeric characters.

Remote SIP Port The Remote SIP Port is the port number the device will use as the

destination port when sending SIP messages. The default Remote SIP
Port is 5060. The supported range is 0-65536. Enter up to 5 digits.

Local SIP Port The Local SIP Port is the port number the device will use to receive SIP

messages. The default Local SIP Port is 5060. The supported range is 0-

65536. Enter up to 5 digits.

Outbound Proxy Enter the Outbound Proxy address as an IPv4 address in dotted decimal

notation or a fully qualified domain name (FQDN). When an IP address is
configured, the device will send all SIP messages to this IP address.
When an FQDN is configured, the device will run DNS NAPTR, SRV, and
A queries on the FQDN to resolve an IP address to which it will send all
SIP messages. This field can accept entries of up to 255 characters in
length.

Outbound Proxy Port The Outbound Proxy Port is port number used as the destination port

when sending SIP messages to the outbound proxy. A value of 0 will
default to 5060. The supported range is 0-65536. Enter up to 5 digits.

Disable rport Discovery Disabling rport Discovery will prevent the device from including the public

WAN IP address and port number in the contact information that is sent to
the remote SIP servers. This will generally only need to be enabled when
using an SBC or SIP ALG in conjunction with a remote SIP server.

Buffer SIP Calls Also referred to as delayed paging. Device will buffer up to 4 minutes of

audio then play back the recording after hang up.

Re-registration Interval (in seconds) The SIP Re-registrati on interv al (in seco nds) is th e SIP Regist rati on lease

time, also known as the expiry. The supported range is 30-3600 seconds.
Enter up to 4 digits.

Unregister on Boot When enabled, the device will send one registration with an expiry of 0 on

boot.

46

Keep Alive Period The minimum time in milliseconds between keep-alive pack ets sent for nat

traversal. A value of 0 will disable keep alive pac kets.

SIP Strobe Settings

Blink Strobe on Ring When selected, the Strobe will blink a scene when ringing.
SIP Call Strobe Brightness How bright the strobe will blink when there is a SIP Call. This is the

maximum brightness for “fade” type scenes.

ADA Compliant Strobe will blink ON at the specified brightness for 150ms then OFF for

350ms during the duration of the event.

Slow Fade Strobe will increase in brightness from 0 to the specified brightness and

back to 0 over the course of about 3.5 seconds during the duration of the
event.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the SIP (Session Initiation Protocol) Parameters

Table 2-17. SIP Configuration Parameters (continued)

Web Page Item Description

Fast Fade Strobe will increase in brightness from 0 to the specified brightness and

back to 0 over the course of about 1.5 seconds during the duration of the
event.

Slow Blink Strobe will blink ON at the specified brightness for one second then OFF

for one second during the duration of the event.

Fast Blink Strobe will blink ON at the specified brightness then OFF five times per

second during the duration of the event.
SIP Call Color Select desired color (only one may be chosen).
Red The red LED value for SIP Call.
Green The green LED value for SIP Call.
Blue The blue LED value for SIP Call.

Use this button to preview the strobe flashing behavior for the MWI Str obe

Settings.

MWI Strobe Settings

Blink Strobe on MWI When selected, the strobe will blink a scene when a voicemail is waiting

for its extension.
MWI Strobe Brightness How bright the strobe will blink when there is a message waiting. This is

the maximum brightness for “fade” type scenes.

47

ADA Compliant Strobe will blink ON at the specified brightness for 150ms then OFF for

350ms during the duration of the event.
Slow Fade Strobe will increase in brightness from 0 to the specified brightness and

back to 0 over the course of about 3.5 seconds during the duration of the

event.
Fast Fade Strobe will increase in brightness from 0 to the specified brightness and

back to 0 over the course of about 1.5 seconds during the duration of the

event.
Slow Blink Strobe will blink ON at the specified brightness for one second then OFF

for one second during the duration of the event.
Fast Blink Strobe will blink ON at the specified brightness then OFF five times per

second during the duration of the event.
MWI Call Color Select desired color (only one may be chosen).
Red The red LED value for MWI.
Green The green LED value for MWI.
Blue The blue LED value for MWI.

Use this button to preview the strobe flashing behavior for the MWI Str obe

Settings.

Nightringer Settings

Enable Nightringer When Nightringer is enabled, the device will attempt to register a second

extension with the SIP server. Any calls made to this extension will play a

ringtone (corresponds to Night Ring on the Audiofiles page). By design,

it is not possible to answer a call to the Nightringer extension.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the SIP (Session Initiation Protocol) Parameters

Table 2-17. SIP Configuration Parameters (continued)

Web Page Item Description

SIP Server Enter the SIP server address as an IPv4 address in dotted decimal

notation or a fully qualified domain name. This parameter also becomes

the host portion of the SIP-URI for the device's Nightringer extension on

the SIP server. This field can accept entries of up to 255 characters in

length.
Remote SIP Port The Remote SIP Port is the port number the device will use as the

destination port when sending SIP messages for the Nightringer

extension. The default Remote SIP Port is 5060. The supported range is

0-65536. Enter up to 5 digits.
Local SIP Port The Local SIP Port is the port number the device will use to receive SIP

messages for the Nightringer extension. This value cannot be the same as

the Local SIP Port for the primary extension. The default Local SIP Port is

5061. The supported range is 0-65536. Enter up to 5 digits.

Outbound Proxy Enter the Outbo und Proxy address as an IPv4 address in dotted decimal

notation or a fully qualified domain name (FQDN). When an IP address is

configured, the device will send all SIP messages to this IP address for the

Nightringer extension. When an FQDN is configured, the device will run

DNS NAPTR, SRV, and A queries on the FQDN to resolve an IP address

to which it will send all SIP messages for the Nightringer extension. This

field can accept entries of up to 255 characters in length.
Outbound Proxy Port The Outbound Proxy Port is port number used as the destination port

when sending SIP messages to the outbound proxy for the Nightringer

extension. A value of 0 will default to 5060. The supported range is 0-

65536. Enter up to 5 digits.

48

User ID Specify the SIP User ID for the SIP server. This parameter becomes the

user portion of the SIP-URI for the device's Nightringer extension. Enter

up to 64 alphanumeric characters.
Authenticate ID Specify the Authenticate ID for the SIP Server. This parameter is required

for SIP registration authentication. Enter up to 64 alphanumeric

characters.
Authenticate Password Specify the Authenticate Password for the SIP Server. This parameter is

required for SIP registration authentication. Enter up to 64 alphanumeric

characters.
Re-registration Interval (in seconds) The SIP Re-registration Interval (in seconds) is the SIP Registration lease

time, also known as the expiry. The supported range is 30-3600 seconds.

Enter up to 4 digits.

Nightringer Strobe Settings

Blink Strobe on Nightring When selected, the Strobe will blink a scene when the Nightinger is

ringing.
Nightringer Strobe Brightness How bright the strobe will blink when the Nightringer is ringing. This is the

maximum brightness for “fade” type scenes.
ADA Compliant Strobe will blink ON at the specified brightness for 150ms then OFF for

350ms during the duration of the event.
Slow Fade Strobe will increase in brightness from 0 to the specified brightness and

back to 0 over the course of about 3.5 seconds during the duration of the

event.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the SIP (Session Initiation Protocol) Parameters

Table 2-17. SIP Configuration Parameters (continued)

Web Page Item Description

Fast Fade Strobe will increase in brightness from 0 to the specified brightness and

back to 0 over the course of about 1.5 seconds during the duration of the

event.
Slow Blink Strobe will blink ON at the specified brightness for one second then OFF

for one second during the duration of the event.
Fast Blink Strobe will blink ON at the specified brightness then OFF five times per

second during the duration of the event.
Nightringer Call Color Select desired color (only one may be chosen).
Red The red LED value for Nightringer.
Green The green LED value for Nightringer.
Blue The blue LED value for Nightringer.

Use this button to preview the strobe flashing behavior f or the Nightringer

Strobe Settings.

RTP Settings

RTP Port (even) Specify the port number used for the RTP stream after establishing a SIP

call. This port number must be an even number and defaults to 10500.

The supported range is 0-65536. Enter up to 5 digits.
Jitter Buffer Specify the size of the jitter buff er (in milliseconds) used for SIP calls. Valid

values are 50-1000.

Call Disconnection

Terminate Call After Delay Automatically terminate an active call after a given delay in seconds. A

value of 0 will disable this function. Enter up to 8 digits.

Codec Selection

Force Selected Codec When configured, this option will allow you to force the device to negotiate

for the selected codec. Otherwise, the device will perform codec

negotiation using the default list of supported codecs.
Codec Select the desired codec (only one may be chosen).

49

Click the Save button to save your configuration settings.

Note: You need to reboot for changes to take effect.

Click on the Reboot button to reboot the system.

Click on the To ggle Help button to see a short description of some of the

web page items. First click on the Toggle Help button, and you will see a

question mark ( ) appear next to some of the web page items. Move the

mouse pointer to hover over a question mark to see a short description of

a specific web page item.

Note You must click on the Save button and then the Reboot button for the changes to take

effect.

Note For sp

ecific server configurations, go to the following website address:

http://www.cyberdata.net/connecting-to-ip-pbx-servers/

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the SIP (Session Initiation Protocol) Parameters

2.3.7.1 Dial Out Extension Strings and DTMF Tones (using rfc2833)

On the SIP Configuration Page—Top, dial out e xtensions support the addition of comma delimited
pauses and sending additional DTMF tones (using rfc2833). The first comma will pause three
seconds after a call is
seconds. A pause of one second will be sent after each numerical digit.

Extension String Resulting Action

302 Dial out extension 302 and establish a call
302,2 Dial out extension 302 and establish a call, wait 3 seconds then send the

302,25,,,4,,1 Dial out extension 302 and establish a call, wait 3 seconds then send the

first established with a remote device. Subsequent commas will pause for 2

Table 2-18. Examples of Dial-Out Extension Strings

DTMF tone '2'

DTMF tone '2', send out DTMF tone 5, wait 6 seconds, send out DTMF
tone 4, wait 4 seconds, send out DTMF tone 1

50

Note The maxi

mum number of total characters in the dial-out field is 64.

Operations Guide 931236C CyberData Corporation

2.3.7.2 Point-to-Point Configuration

Device is set to NOT register with a SiP server

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

When the device is set to not register with a SIP server (see Figure 2-31), it is possible to set the
device to dial out to a single endpoint.

In this case, the dial-out extension should be the IP address of the remote device. The device can
al

so receive Point-to-Point calls. The delayed DTMF functionality is available in the Point-to-Point

Mode.
Note Receiving point-to-point SiP calls may not work with all phones.

Figure 2-31. SIP Page Set to Point-to-Point Mode

SIP Loudspeaker Amplifier (PoE) Setup

Configure the SIP (Session Initiation Protocol) Parameters

51

Operations Guide 931236C CyberData Corporation

2.3.7.3 Delayed DTMF

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

On the SIP Configuration page the dial out extension supports the addition of comma delimited
pauses and sending additional DTMF tones (using rfc2833). The first comma will pause three
seconds after a call is first established with a remote device. Subsequent commas will pause for 2
seconds. A pause of one second will be sent after each numerical digit.

Extension String Resulting Action

302 Dial out extension 302 and establish a call
302,2 Dial out extension 302 and establish a call, wait 3 seconds then send the

302,25,,,4,,1 Dial out extension 302 and establish a call, wait 3 seconds then send the

SIP Loudspeaker Amplifier (PoE) Setup

Configure the SIP (Session Initiation Protocol) Parameters

Table 2-19. Examples of Dial-Out Extension Strings

DTMF tone '2'

DTMF tone '2', send out DTMF tone 5, wait 6 seconds, send out DTMF
tone 4, wait 4 seconds, send out DTMF tone 1

52

Note The maxi

mum number of total characters in the dial-out field is 25.

Operations Guide 931236C CyberData Corporation

2.3.8 Configure the Multicast Parameters

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

The Multicast Configuration page allows the device to join up to ten paging zones for receiving
ulaw/alaw encoded RTP audio streams.

A paging zone can consist of one or many CyberData multicast group-enab led products. There is no
limit to ho
multicast address and port number.

Each multicast group is assigned a priority, allowing simultaneously arriving pages to be serviced
bas
supports simultaneous SIP and Multicast.

w many speakers can be in a given paging zone. Each multicast group is defined by a

ed on importance. Multicast groups are compatible with IGMP through version 3. The device

SIP Loudspeaker Amplifier (PoE) Setup

Configure the Multicast Parameters

53

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Multicast Parameters

1. Click on the Multicast menu button to open the Multicast page. See Figure 2-32.

Figure 2-32. Multicast Configuration Page

54

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Multicast Parameters

2. On the Multicast page, enter values for the parameters indicated in Table 2-20.

55

Note The question mark icon (

after the Toggle Hel

p button is pressed.

) in the following table shows which web page items will be defined

Table 2-20. Multicast Configuration Parameters

Web Page Item Description

Enable Multicast Operation Enables or disables multicast operation.
Priority Indicates the priority for the multica

highest (emergency streams). 0 is the lowest (background
music). SIP calls are considered priority 4.5. See Section 2.3.8.1,

"Assigning Priority" for more details.

Address Enter the multicast IP Address for this multicast group (15

racter limit).

cha

Po

rt Enter the port number for this multicast group (5 character limit

[range

can be from 2000 to 65535]).

Note: The multicast ports have to be even values. The webpage
will enforce this restriction.

Name Assign a descriptive name for this multicast group (25 character

).

limit

Buffer Device will buffer up to four minutes of audio and then play back

cording

the re
is full.

Beep When selected, the device will play a beep before multicast audio

sent.

is

after the multicast stream finishes or after the buffer

st group. Priority 9 is the

Rela

y When selected, the device will activate a relay before multicast

audi

o is sent.

Polycom Default Channel When a default Polycom channel/group number is selected, the

will subscribe to the default channel for one-way group

device
pages. Group Numbers 1-25 are supported. Or , select Disabled
to disable this channel.

Polycom Priority Channel When a priority Polycom channel/group number is selected, the

device will subscribe to the priority channel for one-way group
pages. Group Numbers 1-25 are supported. Or , select Disabled
to disable this channel.

Polycom Emergency Channel

Multicast Strobe Settings

Blink Strobe on Multicast When selected, the Strobe will blink a scene when a multicast is

Multicast Strobe Brightness

ADA Compliant

Slow Fade

When an emergency Polycom channel/group number is selected,
the device will subscribe to the default channel for one-way group
pages. Group Numbers 1-25 are supported. Or , select Disabled
to disable this channel.

received.
How bright the strobe will blink on a multicast page. This is the

maximum brightness for “fade” type scenes.
Strobe will blink ON at the specified brightness for 150ms then

OFF for 350ms during the duration of the event.
Strobe will increase in brightness from 0 to the specified

brightness and back to 0 over the course of about 3.5 seconds
during the duration of the event.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Multicast Parameters

Table 2-20. Multicast Configuration Parameters (continued)

Web Page Item Description

Fast Fade Strobe will increase in brightness from 0 to the specified

brightness and back to 0 over the course of about 1.5 seconds
during the duration of the event.

Slow Blink Strobe will blink ON at the specified brightness for one second

then OFF for one second during the duration of the event.

Fast Blink

Multicast Call Color
Red

Strobe will blink ON at the specified brightness then OFF five
times per second during the duration of the event.

Select desired color (only one may be chosen).
The red LED value for Multicast.

56

Green
Blue

Note You must click on the Save button and then the Reboot button for the changes to take

effect.

2.3.8.1 Assigning Priority

The green LED value for Multicast.
The blue LED value for Multicast.
Use this button to preview the strobe flashing behavior for the

Multicast Strobe Settings.

Click the Save button to save y our configuration settings.
Note: You need to reboot for changes to take effect.

Click on the Reboot button to reboot the system.

Click on the Toggle Help button to see a short description of
some of the web page items. First click on the Toggle Help
button, and you will see a question mark (
some of the web page items. Move the mouse pointer to hover
over a question mark to see a short description of a specific web
page item.

) appear next to

The device will prioritize simultaneous audio streams according to their priority in the list.
If both SIP and Multicast is enabled, SIP audio streams are considered priority 4.5. SIP audio will

interrupt mu

lticast streams with priority 0 through 4 and will be interrupted by multicast streams with

priority 5 through 9.
During priority 9 multicast streams, t

Note SIP calls, multica

st streams, ring tones, ringback tones, and nightring tones are all

he volume is set to maximum.

prioritized.

Ringtones and Nightringtones

Operations Guide 931236C CyberData Corporation

Ringtones all play at the same priority level. This means that it is possible to have a nightring tone
and a normal ringtone playing at the same time.

Configure the Sensor Configuration Parameters

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

2.3.9 Configure the Sensor Configuration Parameters

The door sensor (pins 1 and 2) on the terminal block can be used to monitor a door's open or closed
state. There is an option on the Sensor Configuration P age to trigger on an open or short condition
o

n these pins. The door sensor alarm will be activated when the Sensor Timeout (in seconds)

parameter has been met.
Each sensor can trigger up to five different actions:

• Flash the LED until the sensor is deactivated (roughly 10 times/second)

• Activate the relay until the sensor is deactivated

• Loop an audio file out of the speaker until the sensor is deactivated

• Call an extension and establish two way audio

• Call an extension and play a pre-recorded audio file
eset extension can be set up as a point-to-point call, but currently can't send

Note Calling a p

delayed DTMF tones.

r

SIP Loudspeaker Amplifier (PoE) Setup

57

1. Click Sensor men

u button to open the Sensor Configuration Page (Figure 2-33).

Operations Guide 931236C CyberData Corporation

Configure the Sensor Configuration Parameters

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Figure 2-33. Sensor Configuration Page

SIP Loudspeaker Amplifier (PoE) Setup

58

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Sensor Configuration Parameters

2. On the Sensor page, enter values for the parameters indicated in Table 2-21.

59

Note The question mark icon (

after the Toggle Hel

p button is pressed.

) in the following table shows which web page items will be defined

Table 2-21. Sensor Configuration Parameters

Web Page Item Description

Sensor Settings

Sensor Normally Closed Select the inactive state of the sensor. The sensor is also known

as the Sense Input on the de vi ce' s terminal block.

Sensor Timeout (in seconds) The time (in seconds) the device will wait before it performs an

action when the on-board door sensor is activated. The action(s)
performed are based on the configured Sensor Settings below.
Enter up to 5 digits.

Activate Relay When selected, the device's on-board relay will be activated until

the on-board sensor is deactivated.

Play Audio Locally When selected, the device will loop an audio file out of the

speaker until the sensor is deactivated.

Make call to extension When selected, the device will call an extension when the on-

board door sensor is activated. Use the Dial Out Extension field
below to specify the extension the device will call.

Dial Out Extension Specify the extension the device will call when the on-board

sensor is activated. Enter up to 64 alphanumeric characters.

Dial Out ID An additional Caller identification string added to outbound calls.

Enter up to 64 alphanumeric characters.

Play recorded audio When selected, the device will call the Dial Out Extension and

play an audio file to the phone answering the SIP call
(corresponds to Sensor Triggered on the Audiofiles

Configuration Page page).

Repeat Sensor Message The number of times to repeat the audio message through the

local speaker or to the remote endpoint. A value of 0 will repeat
forev er. Enter a value from 0-65536.

Click the Test Sensor b u tt on to test the sensor.

Sensor Strobe Settings

Blink Strobe on Sensor When selected, the Strobe will blink a scene when the sensor is

triggered.

Sensor Strobe Brightness How bright the strobe will blink when the sensor is triggered. This

is the maximum brightness for “fade” type scenes.

ADA Compliant Strobe will blink ON at the specified brightness for 150ms then

OFF for 350ms during the duration of the event.

Slow Fade Strobe will increase in brightness from 0 to the specified

brightness and back to 0 over the course of about 3.5 seconds
during the duration of the event.

Fast Fade Strobe will increase in brightness from 0 to the specified

brightness and back to 0 over the course of about 1.5 seconds
during the duration of the event.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Sensor Configuration Parameters

Table 2-21. Sensor Configuration Parameters (continued)

Web Page Item Description

Slow Blink Strobe will blink ON at the specified brightness for one second

then OFF for one second during the duration of the event.

Fast Blink Strobe will blink ON at the specified brightness then OFF five

times per second during the duration of the event.
Sensor Color Select desired color (only one may be chosen).
Red The red LED value for Sensor.
Green The green LED value for Sensor.
Blue The blue LED value for Sensor.

Use this button to preview the strobe flashing behavior for the

Sensor Strobe Settings.

Click the Save button to save your configuration settings.

Note: You need to reboot for changes to take effect.

Click on the Reboot button to reboot the system.

60

Click on the Toggle Help button to see a short description of

some of the web page items. First click on the T og gle Help

button, and you will see a question mark ( ) ap pear next to

some of the web page items. Move the mouse pointer to hover

over a question mark to see a short description of a specific web

page item.

Note You must click on the Save button for the changes to take effect.

Operations Guide 931236C CyberData Corporation

Configure the Audio Configuration Parameters

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

2.3.10 Configure the Audio Configuration Parameters

The Audiofiles page is used to add custom audio to the board. User uploaded audio will take
precedence over the audio files shipped with the device.

SIP Loudspeaker Amplifier (PoE) Setup

61

1. Click on the Au

Figure 2-34. Audiofiles Configuration Page

diofiles menu button to open the Audiofiles page (Figure 2-34).

Operations Guide 931236C CyberData Corporation

Figure 2-35. Audiofiles Page

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

SIP Loudspeaker Amplifier (PoE) Setup

Configure the Audio Configuration Parameters

62

2. On the Audiofiles page, enter values for the parameters indicated in Table 2-22.

Note The question mark icon (

after the Toggle Hel

p button is pressed.

) in the following table shows which web page items will be defined

Table 2-22. Audiofiles Configuration Parameters

Web Page Item Description

Available Space Shows the space available f or the user to sa v e custom audio files if they w ant to change the

message when the door or sensor is triggered.

0-4 The name of the audio configuration option is the same as the spoken

the board (24 character limit).
'0' corresponds to the spoken word “zero.”
'1' corresponds to the spoken word “one.”
'2' corresponds to the spoken word “two.”
'3' corresponds to the spoken word “three.”
'4' corresponds to the spoken word “four.”

Operations Guide 931236C CyberData Corporation

audio that plays on

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Audio Configuration Parameters

Table 2-22. Audiofiles Configuration Parameters (continued)

Web Page Item Description

5-9 The name of the audio configuration option is the same as the spoken audio that plays on

the board (24 character limit).
'5' corresponds to the spoken word “five.”
'6' corresponds to the spoken word “six.”
'7' corresponds to the spoken word “seven.”
'8' corresponds to the spoken word “eight.”

'9' corresponds to the spoken word “nine.”
Dot Corresponds to the spoken word “dot.” (24 character limit)
Audio Test Correspon ds to the message “This is the CyberDa

character limit)

ta IP speaker test message...” (24

63

Enter Code Corresponds to the message “Enter Code”
Invalid Code Corresponds to the message “Invalid Code” (24 characte
Page Tone Corresponds to a simple tone used for beep on initialization and beep on page (24 character

limit).
Your IP Address is Corresponds to the message “Your IP address is...” (24 character limit).
Rebooting Corresponds to the spoken word “Re
Restoring Default Corresponds to the message “Restoring default” (24 character limit).
Ring Tone This is the tone that plays when set to ring when receiving a call (24 character limit).
Sensor Triggered Corresponds to the message “Sensor Triggered” (24 character limit).
Night Ring Specifies the ringtone for nightring. By default this parameter uses the same audio file that is

selected for the Ring Tone parameter.

Click on the Browse button to navigate to and select an audio file.

The Play button will play that audio file.

The Delete button will delete any user uploaded audio and restore the stock audio file.

The Save button will download a new user audio file to the board once you've selected the

file by using the Browse button. The Save button will delete any pre-existing user-uploaded

audio files.

(24 character limit).

ting” (24 character limit).

boo

r limit).

Operations Guide 931236C CyberData Corporation

2.3.10.1 User-created Audio Files

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

User created audio files should be saved in the following format:
RIFF (little-endian) data, WAVE audio, Microsoft PCM, 16 bit, mono 8000 Hz

SIP Loudspeaker Amplifier (PoE) Setup

Configure the Audio Configuration Parameters

64

You can use the free utility Audacity to con

Figure 2-38.

Figure 2-36. Audacity 1

Figure 2-37. Audacity 2

vert audio files into this format. See Figure 2-36 through

Operations Guide 931236C CyberData Corporation

Configure the Audio Configuration Parameters

WAV (Microsoft) signed 16 bit PCM

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

When you export an audio file with Audacity, save the output as:

• WAV (Microsoft) signed 16 bit PCM.

Figure 2-38. WAV (Microsoft) signed 16 bit PCM

SIP Loudspeaker Amplifier (PoE) Setup

65

Operations Guide 931236C CyberData Corporation

2.3.11 Configure the Events Parameters

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

The Events page specifies a remote server that can be used to receive HTTP POST events when
actions take place on the board.

SIP Loudspeaker Amplifier (PoE) Setup

Configure the Events Parameters

66

1. Click on the Events menu

Figure 2-39. Event Configuration Page

button to open the Events page (Figure 2-39).

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Events Parameters

2. On the Events page, enter values for the parameters indicated in Table 2-23.

67

Note The question mark icon (

after the Toggle Hel

p button is pressed.

) in the following table shows which web page items will be defined

Table 2-23. Events Configuration Parameters

Web Page Item Description

Enable Event Generation The device will send HTTP POST events to the specified remote

server and port number whenever a certain action takes place.
Select an event type below to generate an HTTP POST event.

Events

Enable Call Start Events When selected, the device will report the start of a SIP call.
Enable Call Terminated Events
Enable Relay Activated Events
Enable Relay Deactivated Events
Enable Night Ring Events

Enable Power On Events
Enable Multicast Start Events

Enable Multicast Stop Events

Enable Sensor Events

When selected, the device will report the end of a SIP call.
When selected, the device will report relay activation.
When selected, the device will report relay deactivation.
When selected, the device will report when it starts ringing upon an

incoming SIP call to the Nightringer extension. As a reminder, the
Nightringer extension always rings upon an incoming SIP call and it
is not possible to alter this behavior.

When selected, the device will report when it boots.
When selected, the device will report when the device starts playing

a multicast audio stream.
When selected, the device will report when the device stops playing

a multicast audio stream.
When selected, the device will report when the on-board sensor is

activated.

Enable 60 Second Heartbeat Events

Check All Click on Check A
Uncheck All

Event Server

Server IP Address The IPv4 address of the event server in dotted decimal notation.
Server Port

Server URL

When enabled, the device will report a Heartbeat event every 60
seconds. SIP registration is not required to generate Heartbeat
events.

ll to select all of the events on the page.

Click on Uncheck All to de-select all of the events on the page.

Specify the event server port number. The supported range is 0-

65536. Enter up to 5 digits.
Generally, the destination URL is the name of the application that

receives the events and the string in the HTTP POST command. It
can be a script used to parse and process the HTTP POST events.
Enter up to 127 characters.

Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.

Click on the Reboot button to reboot the system.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Events Parameters

Table 2-23. Events Configuration Parameters(continued)

Web Page Item Description

Click on the T ogg le Help button to see a short description of some
of the web page items. First click on the Toggle Help button, and
you will see a question mark (
page items. Move the mouse pointer to hover o ver a question mark
to see a short description of a specific web page item.

) appear next to some of the web

Note You must click on the Save button and then the Reboot button for the changes to take

effect.

68

Operations Guide 931236C CyberData Corporation

2.3.11.1 Example Packets for Events

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

The server and port are used to point to the listening server and the 'Remote Event Server URL' is
the destination URL (typically the script running on the remote server that's used to parse and
process the POST events).

SIP Loudspeaker Amplifier (PoE) Setup

Configure the Events Parameters

69

Note The XML is URL-encoded befo

accurate.

Here are example packets for every event:

POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Content-Length: 197
Content-Type: application/x-www-form-urlencoded

<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>POWERON</event>
</cyberdata>

POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Content-Length: 199
Content-Type: application/x-www-form-urlencoded

<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>HEARTBEAT</event>
</cyberdata>

re transmission so the following examples are not completely

POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Content-Length: 196
Content-Type: application/x-www-form-urlencoded

<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>BUTTON</event>
</cyberdata>

POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Content-Length: 201
Content-Type: application/x-www-form-urlencoded

<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>CALL_ACTIVE</event>
</cyberdata>
POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Events Parameters

User-Agent: CyberData/1.0.0
Content-Length: 205
Content-Type: application/x-www-form-urlencoded

<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>CALL_TERMINATED</event>
</cyberdata>

POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Content-Length: 197
Content-Type: application/x-www-form-urlencoded

<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>RINGING</event>
</cyberdata>

POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Content-Length: 234
Content-Type: application/x-www-form-urlencoded

70

<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>MULTICAST_START</event>
<index>8</index>
</cyberdata>

POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Content-Length: 233
Content-Type: application/x-www-form-urlencoded

<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>MULTICAST_STOP</event>
<index>8</index>
</cyberdata>

POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Content-Length: 234
Content-Type: application/x-www-form-urlencoded
<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>RELAY_ACTIVATED</event>
</cyberdata>
POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Events Parameters

User-Agent: CyberData/1.0.0
Content-Length: 234
Content-Type: application/x-www-form-urlencoded
<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>RELAY_DEACTIVATED</event>
</cyberdata>

POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Content-Length: 234
Content-Type: application/x-www-form-urlencoded
<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>NIGHTRINGING</event>
</cyberdata>

71

Operations Guide 931236C CyberData Corporation

2.3.12 Configure the Autoprovisioning Parameters

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Autoprovisioning can be used to automatically configure your device. The autoprovisioning file is an
xml file with the device configuration. Values found in this file will override values stored in on-board
memory.

SIP Loudspeaker Amplifier (PoE) Setup

Configure the Autoprovisioning Parameters

72

Note By default, the devi

1. Click the Aut

oprov menu button to open the Autoprovisioning page. See Figure 2-40.

Figure 2-40. Autoprovisioning Page

ce will try to set up its configuration with autoprovisioning.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Autoprovisioning Parameters

2. On the Autoprovisioning page, you may enter values for the parameters indicated in Table 2-

24.

73

Note The question mark icon (

after the Toggle Hel

p button is pressed.

) in the following table shows which web page items will be defined

Table 2-24. Autoprovisioning Configuration Parameters

Web Page Item Description

Disable Autoprovisioning Prevent the device from automatically trying to download a

configuration file. See Section 2.3.12.1, "Autoprovisioning" for
more information.

Autoprovisioning Server

Autoprovisioning Filename

Use tftp

Username

Enter the IPv4 address of the provisioning server in dotted
decimal notation.

The autoprovisioning filename is the configuration filename.
The default autoprovisioning filename is in the format of
<mac address>.xml.

Supported filename extensions are .txt, and .xml. The current
filename is denoted by an asterisk at the bottom of the

Autoprovisioning Page. Enter up to 256 characters.

A file may have any name with an xml extension. If a file
name is entered, the device will look for the specified file
name, and only that file.

The device will use TFTP (instead of http) to download
autoprovisioning files.

The username used to authenticate with an autoprovisioning
server. Leave this field blank to disable authentication.

Password

Autoprovisioning Autoupdate 
(in minutes)

Autoprovision at time (HHMMSS)

Autoprovision when idle
(in minutes > 10)

The password used to authenticate with an autoprovisioning
server. Leave this field blank to disable authentication.

The reoccurring time (in minutes) the device will wait before
checking for new autoprovisioning files. Enter up to 6 digits. A
value of 0 will disable this option.

Note: To use the auto update options, enable the Set Time

th NTP Server on boot setting on the Device

wi
Configuration Page page (see Table 2-11).

The time of day the device will check for a new
autoprovisioning file. The time must be 6 characters in length
and in HHMMSS format. An empty value will disable this
option.

Note: To use the auto update options, enable the Set Time

th NTP Server on boot setting on the Device

wi
Configuration Page page (see Table 2-11).

The idle time (in minutes greater than 10) after which the
device will check for a ne w autoprovisioning file. Enter up to 6
digits. A value of 0 will disable this option.

Note: To use the auto update options, enable the Set Time

th NTP Server on boot setting on the Device

wi

Configuration Page page (see Table 2-11).

Click the Save button to save your configuration settings.
Note: You need to reboo t for changes to take effect.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Autoprovisioning Parameters

Table 2-24. Autoprovisioning Configuration Parameters (continued)

Web Page Item Description

Click on the Reboot button to reboot the system.

Click on the Toggle Help button to see a short description of
some of the web page items. First click on the Toggle Help
button, and you will see a question mark (
some of the web page items. Move the mouse pointer to
hover over a question mark to see a short description of a
specific web page item.

Press the Download Template button to create an
autoprovisioning file for the device. See Section 2.3.12.3,

"Download Template Button"

Autoprovisioning log The autoprovisioning log provides information about the latest

topro

au
accessed and files parsed or not found).

visioning attempt (i.e. dhcp options and server

) appear next to

Note You must click on the Save button and then the Reboot button for the changes to take

effect.

74

2.3.12.1 Autoprovisioning

On boot, the device will look for an autoprovisioning server configured on the A utopro visioning Page
or specified as a DHCP option. When it finds a server, it will try to download the following (in order of
pref

erence):

1. The file configured on the autoprovisioning page.

2. A file named according to it's mac address (for example: 0020f7350058.xml).

3. The file 000000cd.xml

The file can be hosted using a standard web server (like apache, IIS
download over SSL. The file server can be an ipv4 address in dotted decimal notation or a fully
qualified domain name.

By default, the device will get its autoprovisioning server from the DHCP options. See Section

2.3.12.2, "Sample dhcpd.conf" for an example of how to configure dhcpd to offer autoprovisioning

server addresses. If multiple options are set, the device will attempt to download autoprovisioning
files from e

The DHCP option determines the protocol used to download the autoprovisioning file. The device
looks for DHCP options in the follo

1. Option 43 - a FQDN or an IP address to an http server

2. Option 72 - an IP address to an http server

very server.

, or nginx), and the device can

wing order:

3. Option 150 - an IP address to a tftp server

4. Option 66 - an IP address to a tftp server or if the entry starts with 'http', a FQDN to a http server.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Autoprovisioning Parameters

You can download an autoprovisioning template file from the Autoprovisioning Page using the
Download Template button

(see Table 2-24). This file contains every configuration option that can

be set on the board.
Autoprovisioning files can contain the whole configuration or a subset of this file. The first

autopro

visioning file can also contain links to other autoprovisioning files.

The <MiscSettings> section contains some examples of additional autoprovisioning files:

<MiscSettings>
<DeviceName>CyberData Device</DeviceName>
<!-- <AutoprovFile>common.xml</AutoprovFile>-->
<!-- <AutoprovFile>sip_reg[macaddress].xml</AutoprovFile>-->
<!-- <AutoprovFile>audio[macaddress]</AutoprovFile>-->
<!-- <AutoprovFile>device[macaddress].xml</AutoprovFile>-->
</MiscSettings>

After downloading the first autoprovisioning file, the device will step through up to twenty additional
<AutoprovFile> entries and try to download these files from the same server.

75

When the device finds a filename with the string [macaddress], it will replac

e this string with the

mac address.
As an example, the user has configured option 43 on their DHCP server to “http://example.com,” and

on their ser

ver, they have a file named 0020f7123456.xml (the same as the mac address of the

device).

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Autoprovisioning Parameters

The file 0020f7123456.xml contains:

<?xml version="1.0" encoding="utf-8" ?>
<specific>

<MiscSettings>

<DeviceName>Newname</DeviceName>
<AutoprovFile>common.xml</AutoprovFile>
<AutoprovFile>sip_reg[macaddress].xml</AutoprovFile>
<AutoprovFile>audio[macaddress]</AutoprovFile>
<AutoprovFile>device.xml</AutoprovFile>

</MiscSettings>

</specific>

1. The device will first set it's name to 'Newname'.

2. It will try to download http://example.com/common.xml.

3. It will try to download http://example.com/sip_reg0020f7123456.xml.

4. It will try to download http://example.com/audio0020f7123456.

5. It will try to download http://example.com/device.xml.

The device is reconfigured every time it downloads a new file so if two files configure the same

n the last one will be the one that is saved.

optio

76

Checking for New Autoprovisioning Files after Boot

It is possible to autoprovision autoprovisioning values (for e

xample, to disable autoprovisioning or to

configure a time to check for new files).

The device will always check for an autoprovisioning files on boot but it can be configured to also
check after a periodic delay, when idle, or at a specified time. When one of these options is set, the
device will download its autoprovisioning files again, and if it finds any differences from the files it
downloaded on boot, it will force a reboot and reconfigure.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Autoprovisioning Parameters

77

The Autoprovisioning Filename

The autoprovisioning filename can contain a file, a file path, or a directory.

Table 2-25. Autoprovisioning File Name

Autoprovisioning
Filename

config.xml
/path/to/config.xml

subdirectory/path/ 10.0.1.3 10.0.1.3/subdirectory/path/0020f7020002.xml

Autoprovisioning

File Downloaded

Server

10.0.1.3 10.0.1.3/config.xml

10.0.1.3 10.0.1.3/path/to/config.xml

TFTP options may not support subdirectories. If a directory is set in the filename field, firmware and
audio files will also be do

wnloaded from this subdirectory.
If the filename ends with a forward slash “/,” the device will treat it as a subdirectory.
For example:
The autoprovisioning server is set to “https://www.example.com”
The autoprovisioning filename is set to “cyberdata/”
On boot, the device will try to download:
https://www.example.com/cyberdata/0020f7123456.xml
...and if this fails:
https://www.example.com/cyberdata/000000cd.xml
Audio files and firmware files will also add “cyberdata” to the URL before downloading.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Autoprovisioning Parameters

78

Autoprovisioning Firmware Updates

<FirmwareSettings>

<FirmwareFile>505-uImage-ceilingspeaker</FirmwareFile>
<FirmwareServer>10.0.1.3</FirmwareServer>
<OutdoorIntercom30>firmware_file_v9.3.0</OutdoorIntercom30>
<OutdoorIntercom31>firmware_file_v10.3.0</OutdoorIntercom31>
<CallButton31>firmware_file_v10.3.0</CallButton31>

</FirmwareSettings>

In the <FirmwareSettings> section, the <FirmwareServer> element can be used to specify a
different server for hosting firmware files. When this element is not available, the device will try to
download the file from the autoprovisioning server.

The device will use the filename to determine when to autoprovision firmware updates. The default
configur

ation is blank, so the first time you set a value in your autoprovisioning file, it may force a

firmware update even if the firmware version has not changed.
The <FirmwareFile> name can contain path elements (i.e. /path/to/firmware/10.3.0-uImage-

[d

evice_file_name]).

The device also supports product strings for downloading firmware. If the <FirmwareFile> option is
not set, the de

vice will look for its particular product string for a firmware filename. In this way, a

generic autoprovisioning file can specify unique firmware for a range of products.
The list of valid product strings:

<ProductString>CallButton31</ProductString>

<ProductString>EmergencyIntercom31</ProductString>
<ProductString>EmergencyIntercom31SW</ProductString>
<ProductString>IndoorIntercom31</ProductString>
<ProductString>IndoorIntercom31SW</ProductString>
<ProductString>IndoorKeypad31</ProductString>
<ProductString>IndoorKeypad31SW</ProductString>
<ProductString>OfficeRinger31</ProductString>
<ProductString>OfficeRinger31SW</ProductString>
<ProductString>OutdoorIntercom31</ProductString>
<ProductString>OutdoorIntercom31SW</ProductString>
<ProductString>OutdoorKeypad31</ProductString>
<ProductString>OutdoorKeypad31SW</ProductString>
<ProductString>Strobe31</ProductString>
<ProductString>Strobe31SW</ProductString>

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Autoprovisioning Parameters

79

Autoprovisioning Example 1

Here's a simple example using four autoprovisioning files to configure two devices:
We boot up two devices with mac addresses 00:20:f7:02:00:01 and

00:20:f7:02:00:02 (Device1

and Device2).
The devices are set to use DHCP and that server provides an autoprovisioning server address with

opti

on 43. The address is “https://autoprovtest.server.net.” The files on this server are as follows:

000000cd.xml

<MiscSettings>
<DeviceName>CyberData Autoprovisioned</DeviceName>
<AutoprovFile>sip_common.xml</AutoprovFile>
<AutoprovFile>sip_[macaddress].xml</AutoprovFile>
</MiscSettings>

sip_common.xml

<SIPSettings>
<SIPServer>10.0.0.253</SIPServer>
<RemoteSIPPort>5060</RemoteSIPPort>
</SIPSettings>

sip_0020f7020001.xml

<SIPSettings>
<SIPUserID>198</SIPUserID>
<SIPAuthPassword>ext198</SIPAuthPassword>
<DialoutExtension0>204</DialoutExtension0>
</SIPSettings>

sip_0020f7020002.xml

<SIPSettings>
<SIPUserID>500</SIPUserID>
<SIPAuthPassword>ext500</SIPAuthPassword>
<DialoutExtension0>555</DialoutExtension0>
</SIPSettings>

On boot, Device1 tries to fetch the file 0020f7023614.xml from “https://autoprovtest.server.net”. This
file is not availab le, so de vice1 then tries to f etch the file 000000cd.xml. This file e xists, and Device1
parses the three elements.

1. Device1 changes its device name to CyberData Au

toprovisioned.

2. Device1 finds an AutoprovFile element containing the filename sip_common.xml. The device
ownloads sip_common.xml from “https://autoprovtest.server.net,” and imports this

d
configuration, setting the sip server to 10.0.0.253 and the remote port to 5060.3.

3. Device1 finds another AutoprovFile element containing the filename sip_[macad

dress].xml.
The device replaces the [macaddress] with its own mac address value creating
sip_0020f7020001.xml, downloads this file from “https://autoprovtest.server.net,” and imports
this configuration. This sets the user ID to 198, the password to ext198, and the dialout
extension to 204. Device1 is now finished with autoprovisioning.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Autoprovisioning Parameters

Device2 goes through the same steps by setting its device name to CyberData Autoprovisioned,
its SIP server to 10.0.0.253, and its port to 5060. When Device2 “sees” sip_[macaddress].xml,
Device2 replaces it with its own mac address and downloads sip_0020f7020002.xml from
“https://autoprovtest.server.net.” Device2 sets the SIP User ID to 500, the password to ext500, and
the dialout extension to 555.

80

Autoprovisioning Example 2

Here is another example of setting up your autoprovisioning files:
We boot up two devices with mac addresses 00:20:f7:02:00:01 and

00:20:f7:02:00:02 (Device1
and Device2) and boot them on a network with a DHCP server configured with an autoprovisioning
server at 10.0.1.3 on option 150. Our TFTP server has three files:

0020f7020001.xml

<MiscSettings>
<AutoprovFile>common_settings.xml</AutoprovFile>
</MiscSettings>
<SIPSettings>
<SIPUserID>198</SIPUserID>
<SIPAuthPassword>ext198</SIPAuthPassword>
<DialoutExtension0>204</DialoutExtension0>
</SIPSettings>

0020f7020002.xml

<MiscSettings>
<AutoprovFile>common_settings.xml</AutoprovFile>
</MiscSettings>
<SIPSettings>
<SIPUserID>500</SIPUserID>
<SIPAuthPassword>ext500</SIPAuthPassword>
<DialoutExtension0>555</DialoutExtension0>
</SIPSettings>

common_settings.xml

<MiscSettings>
<DeviceName>CyberData Autoprovisioned</DeviceName>
</MiscSettings>
<SIPSettings> <SIPServer>10.0.0.253</SIPServer>
<RemoteSIPPort>5060</RemoteSIPPort>
</SIPSettings>

1. On boot, Device1 downloads 0020f7020001.xml from 10.0.1.3 and imports these values. The SIP
User ID is 198, the password is ext198, and the dialout extension is 204.

2. Device1 then gets the filename common_settings.xml

from the AutoprovFile element and
downloads this file from the TFTP server at 10.0.1.3. and imports these settings. The device name is
set to CyberData Autoprovisioned, the SIP server is set to 10.0.0.253, and the port is set to 5060.

Device2 does the same except it downloads 0020f7020002.xml on boot and imports these v

alues
instead. The Sip User ID is 500, password is ext500, and dialout extension is 555. Device2 then
downloads the common_settings.xml file and imports those values. The device name is set to
CyberData Autoprovisioned, the SIP server is set to 10.0.0.253, and the port is set to 5060.

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Configure the Autoprovisioning Parameters

81

XML Files

Autoprovisioned
Audio Files

XML files can contain <AutoprovFile> elements. If multiple DHCP options are specified, the device
will try to download autoprovisioning files from each in turn. The device will only look for
<AutoprovFile> elements in the first file downloaded from each server. You can specify up to 20
<AutoprovFile> elements in the first autoprovisioning file.

There are numerous ways to change an element of the configuration(xml) file. U

sing sip ext as an

example, the extension can be changed:
Within the device-specific xml, i.e. [macaddress].xml, via

the AutoprovFile

element:<SIPSettings>/<SIPExt>
From the device specific xml, a pointer to a sip_common file
From the device specific xml, a pointer to the device specific sip_[macaddress].xml
From the common file, a pointer to sip_common.xml
From the common file, a pointer to the device specific (sip_[macaddress].xml)

Audio files are stored in non-volatile memory and an autoprovisioned audio file will only have to be
downloaded once for each device. Loading many audio files to the device from the web page could
cause it to appear unresponsive. If this happens, wait until the transfer is complete and then refresh
the page.

The device uses the file name to determine when to download a new audio file. This means that if
you used autopro

visioning to upload a file and then changed the contents of this file at the TFTP

server, the device will not recognize that the file has changed (because the file name is the same).
Since audio files are stored in non-volatile memory, if autoprovisioning is disabled after they have

been l

oaded to the board, the audio file settings will not change. You can force a change to the audio
files on the board by clicking Restore Default on the Audio Configuration page or by changing the
autoprovisioning file with “default” set as the file name.

Operations Guide 931236C CyberData Corporation

2.3.12.2 Sample dhcpd.conf

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

#
# Sample configuration file for ISC dhcpd for Debian
#

ddns-update-style none;

option domain-name "voiplab";
option domain-name-servers 10.0.0.252;
option option-150 code 150 = ip-address;
option ntp-servers north-america.pool.ntp.org;
option space VendorInfo;
option VendorInfo.text code 10 = { text };
authoritative;
log-facility local7;

subnet 10.0.0.0 netmask 255.0.0.0 {
max-lease-time 3600;
default-lease-time 3600;

option routers 10.0.0.1;
option subnet-mask 255.0.0.0;

option domain-name "voiplab";
option domain-name-servers 10.0.0.252;

SIP Loudspeaker Amplifier (PoE) Setup

Configure the Autoprovisioning Parameters

82

option time-offset -8; # Pacific Standard Time

# option www-server 99.99.99.99; # OPTION 72

# option tftp-server-name "10.0.1.52"; # OPTION 66
# option tftp-server-name "http://test.cyberdata.net"; # OPTION 66

# option option-150 10.0.0.252; # OPTION 150

# These two lines are needed for option 43
# vendor-option-space VendorInfo; # OPTION 43
# option VendorInfo.text "http://test.cyberdata.net"; # OPTION 43

range 10.10.0.1 10.10.2.1; }

Operations Guide 931236C CyberData Corporation

2.3.12.3 Download Template Button

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

The Download Template button allows the user to generate, download, edit, and then store an
autoprovisioning template on the server that serves the autoprovisioning files for devices.

To generate an autoprovisioning template directly from the device, complete the following steps:

SIP Loudspeaker Amplifier (PoE) Setup

Configure the Autoprovisioning Parameters

83

1. On the Au

2. You will see a window prompting you to save a configuration file (.xml) to a location on your
computer (Figure 2-41). The
for your unit).

3. Choose a location to save the configuration file and click on OK. See Figure 2-41.

toprovisioning page, click on the Download Template button.

configuration file is the basis for the default configuration settings

Figure 2-41. Configuration File

4. At this point, you can open and edit the autoprovisioning template to change the configuration
settings in the te

5. You can then upload the autoprovisioning file to a TFTP or HTTP server where the file can be
loaded onto other de

Operations Guide 931236C CyberData Corporation

mplate f

or the unit.

vices.

SIP Loudspeaker Amplifier (PoE) Setup

GENERAL ALERT

v11.6.2

CyberData Paging Amplifier

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Downloading the Firmware

2.4 Upgrade the Firmware and Reboot the SIP Loudspeaker Amplifier (PoE)

2.4.1 Downloading the Firmware

To download the firmware to your computer:

84

1. Download the latest firmware file from the Downloads tab at the follo

http://www.cyberdata.net/voip/011405/

2. Unzip the firmware version file. This file may contain the following:

• Firmware file

• Release notes

3. Log in to the home page as instructed in Section 2.3.4, "Log in to the Configuration Home

Page".

4. Click on the Firmwar

e menu button to open the Firmware page. See Figure 2-42.

wing webpage:

Caution

Equipment Hazard: CyberData strongly recommends that you first reboot the
device before attempting to upgrade the firmware of the device. See Section 2.4.2,

"Reboot the Device".

Figure 2-42. Firmware Page

5. Click on the Browse

6. Select the firmware file.

Operations Guide 931236C CyberData Corporation

7. Click on the Upload button.

Note Do not reboot the d

button, and then navigate to the location of the firmware file.

ev

ice after clicking on the Upload button.

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Downloading the Firmware

Note This starts the upgrade process. Once the SIP Loudspeaker Amplifier (PoE) has uploaded

the file, the Uploading Firmware countdown page appears, indicating that the firmware is
being written to flash. The SIP Loudspeaker Amplifier (PoE) will automatically reboot when
the upload is complete. When the countdown finishes, the Firmware page will refresh. The
uploaded firmware filename should be displayed in the system configuration (indicating a
successful upload and reboot).

85

8. Table 2-26 shows the web page items on the Firmware page

Table 2-26. Firmware Parameters

Web Page Item Description

Current Firmware Version Shows the current firmware version.

Use the Browse bu
firmware file that you want to upload.

Click on the Upload b
firmware and reboot the system.

tton to navigate to the location of the

utton to automatical

.

ly upload the selected

Operations Guide 931236C CyberData Corporation

2.4.2 Reboot the Device

v11.6.2

405000001

CyberData Paging Amplifier

Reboot

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

To reboot a SIP Loudspeaker Amplifier (PoE), log in to the web page as instructed in Section 2.3.4,

"Log in to the Configuration Home Page".

SIP Loudspeaker Amplifier (PoE) Setup

Reboot the Device

86

1. Click on the Reboot b

utton on the Home page (Figure 2-43). A normal restart will occur.

Figure 2-43. Home Page

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Command Interface Post Commands

2.5 Command Interface

Some functions on the device can be activated using simple POST commands to the web interf ace.
The examples in Table 2-27 use the free unix utility, wget, b
commands to the device should work.

2.5.1 Command Interface Post Commands

Note These commands require an authenticated session (a valid username and password to

work).

Table 2-27. Command Interface Post Commands

Device Action HTTP Post Command

Trigger relay (for configured delay) wget --user admin --password admin --auth-no-challenge --no-

check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi­bin/command.cgi" --post-data "test_relay=yes"

Place call to extension (example: extension 130) wget --user admin --password admin --auth-no-challenge --no-

check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi­bin/command.cgi" --post-data "call=130"

Terminate active call wget --user admin --password admin --auth-no-challenge --no-

check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi­bin/command.cgi" --post-data "terminate=yes"

Force reboot wget --user admin --password admin --auth-no-challenge --no-

check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi­bin/command.cgi" --post-data "reboot=yes"

Test Audio button wget --user admin --password admin --auth-no-challenge --no-

k-cer

chec
bin/command.cgi" --post-data "test_audio=yes"

Announce IP address wget --user admin --password admin --auth-no-challenge --no-

chec
bin/command.cgi" --post-data "speak_ip_address=yes"

Play the "0" audio file wget --user admin --password admin --auth-no-challenge --no-

chec
bin/audiofiles.cgi" --post-data "play_0=yes"

Play the "1" audio file wget --user admin --password admin --auth-no-challenge --no-

chec
bin/audiofiles.cgi" --post-data "play_1=yes"

Play the "2" audio file wget --user admin --password admin --auth-no-challenge --no-

chec
bin/audiofiles.cgi" --post-data "play_2=yes"

Play the "3" audio file wget --user admin --password admin --auth-no-challenge --no-

chec
bin/audiofiles.cgi" --post-data "play_3=yes"

Play the "4" audio file wget --user admin --password admin --auth-no-challenge --no-

chec
bin/audiofiles.cgi" --post-data "play_4=yes"

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

k-cer

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

k-cer

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

k-cer

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

k-cer

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

k-cer

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

k-cer

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

ut any program that can send http POST

a

87

Operations Guide 931236C CyberData Corporation

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Command Interface Post Commands

Table 2-27. Command Interface Post Commands (continued)

Device Action HTTP Post Command

Play the "5" audio file wget --user admin --password admin --auth-no-challenge --no-

check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi­bin/audiofiles.cgi" --post-data "play_5=yes"

Play the "6" audio file wget --user admin --password admin --auth-no-challenge --no-

check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi­bin/audiofiles.cgi" --post-data "play_6=yes"

Play the "7" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "play_7=yes"

Play the "8" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "play_8=yes"

Play the "9" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "play_9=yes"

Play the "Dot" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "play_d=yes"

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

a

88

Play the "Audio Test" audio file (from Audio Config) wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "play_audiotest=yes"

Play the "Page Tone" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "play_pagetone=yes"

Play the "Your IP Address Is" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "play_youripaddressis=yes"

Play the "Rebooting" audio file wge t --user admin --pas sword admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "play_rebooting=yes"

Play the "Restoring Default" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "play_restoringdefault=yes"

Play the "Ringback tone" audio file wget --user admin --pas sword admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "play_ringback=yes"

Play the "Ring tone" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "play_ringtone=yes"

Play the "Door Ajar" audio file wget --user admin --pas sword admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "play_doorajar=yes"

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

Play the "Night Ring" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "play_nightring=yes"

Delete the "0" audio file wget --user admin --password admin --auth-no-challenge --no-

chec
bin/audiofiles.cgi" --post-data "delete_0=yes"

Operations Guide 931236C CyberData Corporation

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

k-cer

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Command Interface Post Commands

Table 2-27. Command Interface Post Commands (continued)

Device Action HTTP Post Command

Delete the "1" audio file wget --user admin --password admin --auth-no-challenge --no-

check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi­bin/audiofiles.cgi" --post-data "delete_1=yes"

Delete the "2" audio file wget --user admin --password admin --auth-no-challenge --no-

check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi­bin/audiofiles.cgi" --post-data "delete_2=yes"

Delete the "3" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "delete_3=yes"

Delete the "4" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "delete_4=yes"

Delete the "5" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "delete_5=yes"

Delete the "6" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "delete_6=yes"

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

a

89

Delete the "7" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "delete_7=yes"

Delete the "8" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "delete_8=yes"

Delete the "9" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "delete_9=yes"

Delete the "Audio Test" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "delete_audiotest=yes"

Delete the "Page Tone" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "delete_pagetone=yes"

Delete the "Your IP Address Is" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "delete_youripaddressis=yes"

Delete the "Rebooting" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "delete_rebooting=yes"

Delete the "Restoring Default" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "delete_restoringdefault=yes"

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

Delete the "Ringback tone" audio file wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/audiofiles.cgi" --post-data "delete_ringback=yes"

Delete the "Ring tone" audio file wget --user admin --password admin --auth-no-challenge --no-

chec
bin/audiofiles.cgi" --post-data "delete_ringtone=yes"

Operations Guide 931236C CyberData Corporation

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

k-cer

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

SIP Loudspeaker Amplifier (PoE) Setup

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Command Interface Post Commands

Table 2-27. Command Interface Post Commands (continued)

Device Action HTTP Post Command

Delete the "Door Ajar" audio file wget --user admin --password admin --auth-no-challenge --no-

check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi­bin/audiofiles.cgi" --post-data "delete_doorajar=yes"

Delete the "Night Ring" audio file wget --user admin --password admin --auth-no-challenge --no-

check-certificate --quiet -O /dev/null "https://10.0.3.71/cgi­bin/audiofiles.cgi" --post-data "delete_nightring=yes"

Trigger the Door Sensor Test (Sensor Config page) wget --user admin --password admin --auth-no-challenge --no-

check-cer
bin/sensor.cgi" --post-data "doortest=yes"

tificate --quiet -O /dev/null "https://10.0.3.71/cgi-

a

a.Type and enter all of each http POST command on one line.

90

Operations Guide 931236C CyberData Corporation

Appendix A: Mounting the Amplifier

Sheet Metal Screw (3x)

#8x1.25" Truss Head Phillips

531032

Plastic Ribbed Anchor (3x)

151147

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

A.1 Mount the Amplifier

Before you mount the enclosure, make sure that you have received all of the parts for each
enclosure. Refer to Table A-1.

Table A-1. Wall Mounting Components (Part of the Accessory Kit)

Quantity Part Name Illustration

1 Mounting Accessory Kit which includes:

(3) Plastic Ribbed Anchors

(3) #8 Sheet Metal Screws

91

Note The SIP Loudspeaker Amplifier (PoE) was designed for indoor use. Mounting it on the

external part of a building will require additional hardware for weatherproofing, cabling
access, and lightning suppression. Consult a certified electrician for details.

Note For mounting, use the three #8 SHEET META

L SCREWS to secure the enclosure.

Operations Guide 931236C CyberData Corporation

Operations Guide 931236C

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

Part # 011405

COPYRIGHT NOTICE:
© 2016, CyberData Corporation, ALL RIGHTS RESERVED.

This manual and related materials are the copyrighted property of CyberData Corporation. No part
of this manual or related mate
(except for internal use by licensed customers), without prior express written permission of
CyberData Corporation. This manual, and the products, software, firmware, and/or hardware
described in this manual are the property of CyberData Corporation, provided under the terms of an
agreement between CyberData Corporation and recipient of this manual, and their use is subject to
that agreement and its terms.

DISCLAIMER: Except as expressly and specifically stated in a written agreement executed by
CyberData Corporation, CyberData Cor
implied, including any warranty or merchantability or fitness for any purpose, with respect to this
manual or the products, software, firmware, and/or hardware described herein, and CyberData
Corporation assumes no liability for damages or claims resulting from any use of this manual or such
products, software, firmware, and/or hardware. CyberData Corporation reserves the right to make
changes, without notice, to this manual and to any such product, software, firmware, and/or
hardware.

rials may be reproduced or transmitted, in any form or by any means

poration makes no representation or warranty, express or

OPEN SOURCE STATEMENT: Certain software componen
subject to the GNU Gener
“open source” or “free software” licenses. Some of this Open Source Software may be owned by
third parties. Open Source Software is not subject to the terms and conditions of the CyberData
COPYRIGHT NOTICE or software licenses. Your right to copy, modify, and distribute any Open
Source Software is determined by the terms of the GPL, LGPL, or third party, according to who
licenses that software.

Software or firmware developed by CyberData that is unrelated to Open Source Software is
copyri

ghted by CyberData, subject to the terms of CyberData licenses, and may not be copied,
modified, reverse-engineered, or otherwise altered without explicit written permission from
CyberData Corporation.

TRADEMARK NOTICE: CyberData Corporation and the CyberData Corporation logos are
trademar
be the trademarks or registered trademarks of their respective owners.

ks of CyberData Corporation. Other product names, trademarks, and service marks may

al Public License (GPL) and Lesser GNU General Public License (LGPL)

ts included in CyberData products are

Operations Guide 931236C CyberData Corporation

Appendix B: Setting up a TFTP Server

VoIPon www.voipon.co.uk [e-mail] Tel: [phone] Fax: [phone]

B.1 Set up a TFTP Server

Autoprovisioning requires a TFTP server for hosting the configuration file.

B.1.1 In a LINUX Environment

To set up a TFTP server on LINUX:

1. Create a directory dedicated to the TFTP server, and move the files to be uploaded to that
di

rectory.

93

2. Run the following command where /tftpboot/

Step 1: the directory that contains the files to be uploaded. For example:

in.tftpd -l -s /tftpboot/your_directory_name

B.1.2 In a Windows Environment

You can find several options online for setting up a Windows TFTP server. This example explains
how to use the Solarwinds freeware TFTP server, which you can download at:

http://www.cyberdata.net/support/voip/solarwinds.html

To set up a TFTP server on Windows:

1. Install and start the software.

2. Select File

3. Make a note of the default directory name, and then move the firmware files to be uploaded to
that director

/Configure/Security tab/Transmit Only.

y.

is the path to the directory you created in

Operations Guide 931236C CyberData Corporation
