CVA Electra Owner's Manual

• CVA recommended maximum powder charge or bullet weight has been

exceeded.

• Any form of plastic patch has been used (sabots and PowerBelts™ not

included).

• Gun is returned in an abused or neglected condition (rusty, corroded,

etc.).

• The ARC Electronic Ignition housing has been opened and/or the

electronics have been tampered with in any way.

14

Please return the entire gun even if you feel the problem is only with the barrel
or the stock. A detailed letter of instructions should be enclosed to facilitate
handling. Please be sure to include your name, shipping address, and a daytime
phone number. All firearms must be unloaded and cleaned prior to shipping to

CVA.

Our Repair Center will inspect and evaluate the problem. Should any work
not be covered by warranty, you will be advised of the cost. No unwarranted
work will be done without your approval. The address for the CVA Repair Center
is:

CVA Repair Department
5988 Peachtree Corners East
Norcross, GA 30071

LIMITED LIFETIME WARRANTY

CVA warrants all factory-finished firearms to be free of defects in workmanship

or materials. This Limited Lifetime Warranty only applies to the original

consumer owner. This warranty is put into effect by the return of the authorized

warranty card within 15 days of purchase and is not transferable. To save time
and postage, the warranty information may also be transmitted electronically via
our web site at www.cva.com.

Any covered CVA firearm or part thereof that is returned postage paid to the

Repair Center or Customer Service Department will be repaired or replaced to
our commercial standard, free of charge, and returned to the consumer postage
prepaid.

This warranty does not cover damage to any structures, buildings, vehicles,
persons or animals, or any other damage resulting from careless handling,
improper loading, rust or corrosion, neglect, improper maintenance or customer
alterations.

CVA reserves the right to refuse to repair or replace any firearm or parts thereof

damaged by any of the above.

The warranty does not cover normal wear of any part, metal or stock finish, cost

of inconvenience due to product failure, or transportation to the Repair Center.

This warranty gives you certain specific legal rights. You may also have other

rights, which vary from state to state. This warranty is void if:

• Any propellant other than the correct type of blackpowder or blackpowder

substitute is used.

• Unauthorized repair work has been performed by the owner or a third

party.

13

5. Use a properly fitting Bore Brush on a Range Rod or extended ramrod to
scrub the bore. This loosens the accumulated fouling from the rifling.

6. Use several solvent soaked patches to remove the fouling (as an alternative
to this step, use the Barrel Blaster Wonder Gel as per the instructions on the
tube).

7. Push several dry, clean patches through the bore. Repeat step 4 and 5 as
necessary until the dry patches come out clean. Use a Barrel Blaster Rust
Prevent Patch or a patch dampened with rust preventing gun oil to coat the
bore.

8. Brush the face of the breech plug then wipe of excess fouling with a solvent
dampened patch (or soak it clean in the CVA Barrel Blaster Parts Soaker
(CVA Part # AC1686). Apply Breech Plug Grease to the threads of the plug

and install it back into the gun, tightening only finger tight. Do not over
tighten as this may cause the breech plug to seize.

9. Use an oily rag or a Rust Prevent Patch to wipe down the exterior of the gun
to prevent rust and corrosion.

10. Replace the barrel into the stock making sure to tighten the 2 barrel retention
screws evenly and securely. Remember-the short screw goes in the forward
position.

SCOPE MOUNTING

The CVA Electra is drilled and tapped for scope mounts. A DuraSight®
Scope Rail is supplied and installed at the factory. While this mount is
compatible with any Weaver-style ring, CVA strongly recommends that you use
genuine DuraSight® Z-2 rings with this base (visit www.DuraSight.com for
more information). These quality rings should be available from the CVA Dealer

where you bought your rifle. If not, contact CVA Customer Service at 770-449-

4687. Once you have your rings and you are ready to install your scope, check

the rail base screws individually to make sure they are tight, and then follow the
manufacturer’s instructions on the scope ring package.

Tip: Take care to assure that the front bell of the scope is not contacting the
barrel. Make sure that the rear bell of the scope is an appropriate distance from
your eye so that you are not struck by the scope during recoil.

FOR SERVICE & REPAIR, PLEASE CALL [phone], MONDAY –
FRIDAY 8:30AM - 4:00PM EASTERN STANDARD TIME.

Should your CVA Electra require repair, please call our CVA Customer
Service Department at 770-449-4687. We may be able to determine the problem
and resolve the issue in a phone call. If we cannot correct the situation over the
phone we recommend that you return the gun to our Warranty Repair Center.
This will assure that our competent staff of trained technicians performs all work.

12

2.

Attach the Electra Breech Brush to the Range Rod and scrub the breech
face, rotating the brush both clockwise and counter-clockwise. See Photo 3

3. Attach a Bore Brush to the Range Rod
and work the brush up and down through the
barrel.

4. Run two damp patches to remove
the fouling debris loosened by the brushing
procedures.

5. Using Barrel Blaster™ Wonder-Gel or
some other high quality black powder solvent,
follow the cleaning directions as given on the

package until patches come out completely clean.

6. Treat the bore of the barrel using a Barrel Blaster™ Rust Prevent Patch or a
Bore Swab that has been lightly saturated with gun oil.

Note: Due to the suction created by the Electra’s sealed
breech, occasionally a patch may be sucked down
the barrel as you remove the cleaning rod from the
bore. A screw-tipped Patch/Bullet Puller is included
in your tool kit for the express purpose of removing
such patches (or even bullets, if one is loaded without
powder). Simply attach the screw puller to the end of
the ramrod, insert it into the bore and twist clockwise
until the patch is engaged, then pull the patch from the
bore. See Photo 4.

COMPLETE CLEANING METHOD

1. Turn the gun’s On / Off Switch to the “OFF” position, making sure the Status
Indicator Light is not lighted.

2. Remove the barrel from the stock by unscrewing the Barrel Retention Screws
with the supplied wrench.

3. Swab the bore several full strokes with a properly fitting wet patch. We
recommend this first patch to be wet with cleaning solvent. Follow with

several dry patches.

4. Using the supplied tool, or a 6-point, 12mm, deep-well socket wrench,
remove the breech plug, wet with cleaner and set aside. If the breechplug

is difficult to remove, use the Breech Plug Removal Assist Rod to provide

added leverage (See Photo 2). To install the Rod, turn the threaded end into
one of the lower barrel lugs until tight. Next, lay the barrel down on a table

or other flat surface with the Rod pointing to your left, insert the breech plug

tool or socket wrench, and then turn counter-clockwise to remove the plug.

Photo 3

Photo 4

11

if you desire an extra measure of safety, it is recommended that you turn
the Main Power Switch to the “OFF” position.

Note: If your rifle does not fire (usually the result of excess fouling or

solvent on the breech plug face), wait at least 1 minute and pull the
trigger again. If this does not fire the gun turn the main power switch
to the “OFF” position, wait at least 1 minute, disassemble the gun and
remove the breech plug from the barrel. Clean the breech plug face with
a brush and solvent patch, with the muzzle pointed in a safe direction,
and, after the Status Indicator Light begins to blink, pull the trigger to
fire the gun. Once the gun has fired, you can the resume normal firing
and reloading procedures. If the gun still does not fire after following the
above described process, turn the main power switch to the “off” position,
thoroughly soak the powder charge with water (at least 30 min.), then
remove the breech plug and push the charge out with a ramrod.

CLEANING YOUR CVA ELECTRA MUZZLELOADER

One advantage of the Electra’s ARC™ Electronic Ignition is that the need for
a 209 primer is eliminated, and, therefore, the fouling that would normally exit a

primer flash hole is eliminated. It is because of this design that the Electra does not
get as dirty with fouling as would a conventional primer ignition muzzleloader.
There are two methods for cleaning the Electra rifle – The “Abbreviated

Cleaning Method” and the “Complete Cleaning Method.” One of these two
cleaning methods should be employed after each shooting session or hunt, as
leaving corrosive powders in the bore, even overnight, is inviting corrosion
damage that will not be covered by your warranty and could even render your
gun unsafe to shoot.
For routine “in-season” cleaning, under normal weather conditions,

the “Abbreviated Cleaning Method” is all that is required. The “Complete
Cleaning Method” is only necessary after lengthy range sessions, extremely
wet weather conditions, or before the gun goes into long-term storage – say,
after the hunting season is over. Both of these methods are outlined below.

While many cleaning products are on the market, we recommend that you

use the CVA Barrel Blaster™ line of products for your CVA rifle (visit www.cva.

com for more information). However, regardless of the brand of products you
choose, you will need to carefully follow the instructions below to insure that

your rifle is cleaned properly.

ABBREVIATED CLEANING METHOD

1. Turn the gun’s On / Off Switch to the “OFF” position, making sure the Status
Indicator Light is not lighted.

10

6. Next, turn the Main Power Switch to the “OFF” position and make sure the
Safety Switch is in the “SAFE” position.

7. Measure the appropriate charge of granular powder, or select an appropriate
number of powder pellets (see “PROPELLANTS” section above). With the

muzzle in an upward facing direction, pour the powder or drop the pellets
into the muzzle.

8. Place the bullet into the muzzle of the barrel and, using a bullet starter, start

the bullet into the bore. Then use a ramrod to push the bullet down the
barrel until it contacts the powder charge. If using pellets, continue to exert

pressure until you feel a “secondary seating” of about 1/8 of an inch as

the first pellet seats firmly onto the breech plug face (actually, the edge

of the pellet crushing slightly on the raised grounding electrode on the

breech plug). This “secondary seating” is a design feature of the rifle and
is very important to insure the optimal ignition of pelletized propellants.

Note: When using Hodgdon Triple 7 Pellets, in particular, this procedure
is absolutely necessary to insure acceptable ignition times.

FIRING YOUR CVA ELECTRA MUZZLELOADING RIFLE

1. With the muzzle pointing in a safe direction turn the Main Power Switch
to the “ON” position (the Status Indicator Light should glow solid red).
After about 25 to 30 seconds, the light will begin to blink, indicating that the

ignition is fully charged and the rifle is ready to fire.

2. With the muzzle pointing at the intended target, and hearing and vision
protection in place, push the Safety Switch forward into the “FIRE” position,

verify the target, aim, then squeeze the trigger to fire the rifle. Note: If
properly functioning, the safety lever will return to the “SAFE” position

after each firing.

3. Reload the rifle by following steps 6 - 9 again. Tech Note: After every 4 to
5 shots the breech plug face should be cleaned with the Electra Breech
Plug Brush, followed by a damp patch and a dry patch. Cleaning the
breech face with the Electra Breech Plug Brush is essential to achieving
reliable and full-powered ignition of the ARC Electronic Ignition

System. Also, you may find that some powders and/or bullets may provide

more consistent accuracy if you run a slightly damp patch down the barrel
between every shot.

Important Warning: For quick follow-up shots at game animals, the

circuitry of the Electra allows you approximately 25 to 30 seconds to

reload before the capacitor is fully charged – but the gun will be capable

of firing after as few as 10 to 15 seconds and before the Status Indicator
Light begins to flash. While the safety mechanism will automatically
reset to “SAFE” after each firing, and must be in the “FIRE” position
(and the trigger must pulled) to allow completion the electronic circuit,

9

FASTER LOADING, FASTER IGNITION, FASTER CLEANIN

G

F

orm 106

REV: 05/07

QUAKE INDUSTRIES

electra_owner_manual_cover04.indd 1 6/12/07 10:09:28 AM

Electra Print File.indd 1 7/11/07 4:37:48 PM

OVERVIEW AND SAFETY WARNINGS

WARNING: YOU ARE RESPONSIBLE FOR FIREARM SAFETY!
AS A GUN OWNER, YOU MUST ACCEPT A SET OF DEMANDING
RESPONSIBILITIES. AT ALL TIMES YOU MUST HANDLE YOUR RIFLE
WITH RESPECT FOR ITS POTENTIAL DANGERS. THE INFORMATION
CONTAINED IN THIS MANUAL IS CRITICAL FOR THE PROPER USE
AND CARE OF YOUR ELECTRA™ RIFLE. A SEPARATE GENERAL
SAFETY PROCEDURES / MANUAL IS INCLUDED WITH YOUR GUN.
DO NOT ATTEMPT TO LOAD OR FIRE YOUR GUN UNTIL YOU READ
AND THOROUGHLY UNDERSTAND THE INFORMATION PROVIDED IN
BOTH MANUALS.

Your CVA Electra muzzleloading rifle is different from any muzzleloader
you have ever shot before. The ARC™ Electronic Ignition is an entirely
new type of muzzleloading ignition system, and it is the technical heart of
the Electra rifle. Therefore, it is extremely important that you familiarize
yourself completely with the operational techniques which are essential to
the proper use of this new technology. Certain portions of this manual that
refer to such unique and/or important techniques are noted in YELLOW
HIGHLIGHTS.

If, after reading the instructions and warnings detailed in this manual, you are not
willing to accept the responsibilities involved in the safe handling and shooting

of your Electra rifle, please return it unfired and in its entirety to the place of

purchase. If you have any questions about the safe use of your gun, please visit
our web site at www.cva.com, or write, call, or e-mail our Customer Service
Department at:

5988 Peachtree Corners East
Norcross, GA 30071
770-449-4687
[e-mail]

NOTE: If you sell, trade, or give this gun to any other person, this owner’s

manual must accompany the firearm. Replacements are available free of charge

from CVA, or online at www.cva.com.

YOU, AND ONLY YOU, ARE RESPONSIBLE FOR SAFELY CONTROLLING
THE MUZZLE OF YOUR GUN. ALWAYS BE SURE THAT THE MUZZLE
OF YOUR GUN IS POINTED IN A SAFE DIRECTION.

1

FEATURES OF THE ELECTRA™

The CVA Electra™ is the world’s first electronic ignition muzzleloader.
The Electra’s ARC™ Electronic Ignition system utilizes a standard 9 volt battery,
along with specialized circuitry and a high-performance capacitor, to deliver a

high-voltage spark to the base of the powder charge. This eliminates the need for

a percussion cap or shotgun primer. The result is a muzzleloading rifle that has

lightning fast ignition time, is easier and faster to load, simpler to clean, more

efficient in the burning of the powder charge, almost totally weather-proof, and

extremely accurate.

The CVA Electra rifle also features a state-of-the-art Bergara Barrel™ that is

manufactured in one of the world’s most highly respected gun-making regions

-- Northern Spain. These Bergara Barrels™ are made on the most modern and

precise barrel making machines in the world. After precision deep-hole drilling,

the barrel blank is honed to size in a three-step process using diamond-coated
tools. This honing process leaves a finish that is far smoother than traditional
reaming and is ideal for the button rifling process. Bergara Barrels are the highest
quality production muzzleloading barrels in the world and will provide unmatched

accuracy. Please visit www.BergaraBarrels.com for more information.

BATTERY INFORMATION

Your Electra rifle is equipped with a quality 9-volt alkaline battery, which

should be installed into the battery housing (see Photo 1). This battery will give you
excellent performance under normal shooting and hunting conditions. However,

if you live or hunt where the temperature is regularly below 30 degrees
Fahrenheit, you will have better results with a lithium battery. Lithium
batteries are designed to function perfectly even in sub-zero temperatures.

Lithium batteries are available in most camera, electronic and specialty battery
shops. As a service to our customers, CVA provides a quality lithium battery at a

reasonable price (CVA Part # AC1618). Therefore, if you have difficulty finding

9-volt lithium batteries in your area, you may purchase them at your local CVA
Dealer or through CVA’s Customer Service Department (1-770-449-4687).

The ARC Electronic Ignition is very efficient in its use of battery power.

Battery
Housing

LED Status
Indicator

Main Power
Switch

DuraSight

®

Rail

Scope Base

Safety Switch

CrushZone™
Recoil Pad

Barrel Retention
Screws

Bergara Barrel™

Extendable
Ramrod

Electronics
Housing

DuraSight Fiber
Optic Sights

2

A 9-volt lithium battery should, with
proper care and handling, allow the
system to spark up to 500 times. Even if
the gun is inadvertently left in the “ON”
position for an extended period of time,
the battery life of a lithium battery should
exceed 600 hours (25 days). However,
in order to preserve the battery life, it
is recommended that you turn the ARC
Electronic Ignition off when the gun
is not in use. Alkaline battery life will be somewhat less, depending on conditions.
As a general rule of thumb, we recommend that you replace the battery at the

beginning of each hunting season, or if you find that the ARC Electronic Ignition

has been left “ON” for an undetermined period of time. During long-term

storage, the battery should be removed to prevent possible damage to the rifle in

case of battery leakage.

TURNING YOUR ELECTRONIC ARC™ IGNITION SYSTEM ON/OFF

The Main Power Switch is located to the rear of the trigger guard. Use your

fingers to turn the switch to the “ON” or “OFF” position as needed. Turning the

switch to the “OFF” position fully disarms the electronic circuits. Turning the
switch to the “ON” position re-starts the charging of the circuits. The LED Status

Indicator Light (see below) will confirm the mode.

LED STATUS INDICATOR LIGHT

Located just behind the safety switch, the red LED light indicates the
following conditions.

• NO LIGHT -- The main power switch is in the “OFF” position. Or,

if the switch is in the “ON” position, this would indicate that the
battery is dead.

• SOLID -- The capacitor is in the process of charging. This stage lasts

approximately 25 to 30 seconds. WARNING-Although it takes 25

to 30 seconds to fully charge the capacitor for the optimum spark,
only approximately 13 - 15 seconds are required to provide enough
voltage to create a weaker, but potentially effective spark. Your

Electra rifle should be considered capable of firing whenever the

main power switch is in the “ON” position. Therefore, the Status
Indicator Light should not be used as a “safety.”

• FLASHING -- When the light is flashing approximately once each

second, the circuits are fully charged and the ARC Electronic
Ignition is ready to spark with full power.

Photo 1

3

• RAPID FLASHING - - Indicates the circuits are charged and

ready to fire, but that the battery is reaching the end of its useful
life and should be replaced as soon as possible. Rapid flashing that
occurs when a battery is replaced indicates a weak battery has been
installed.

Note: LED lights can sometimes fail. Therefore, the Electra should

always be treated as if it is ready to fire, regardless of the status indicated
by the Status Indicator Light.

PREPARING YOUR NEW ELECTRA RIFLE FOR USE

1. After fully reading and understanding this manual, remove the gun and the
included tools (Breech Plug Wrench, Breech Plug Removal Assist Rod, Allen
Wrench, Electra Breech Plug Brush, Patch/Bullet Puller) from the box.

2. Safety First! Verify that the gun is unloaded and the barrel is clear!

Do this by inserting the ramrod into the barrel (do not extend the jag). The

ramrod should stick out of the barrel only about 1/8”. If it sticks out farther
than this the barrel must be considered loaded and/or obstructed and should

not be loaded or fired until the barrel is completely cleared.

3. Check all mechanical functions described in this manual.

4. Using the supplied Allen wrench, remove the 2 barrel retention screws and
lift barrel from stock.

5. Remove the breech plug by unscrewing it using the provided tool (and using
the Breech Plug Removal Assist Rod for added leverage, if necessary). See
Photo 2.

6. Clean the shipping grease from the inside and outside of the barrel.

7. After fully coating the threads with CVA Breech Plug Grease or some other

high quality anti-seize compound, replace the breech plug. Turn it in only

until it is snug. Do not over tighten.

8. Replace the barrel in the stock and tighten the barrel retention screws firmly

and evenly. The short screw goes in the forward position.

Photo 2

4

9.

Install the battery, making sure the positive and negative terminals are correctly
aligned as indicated on the rim of battery compartment. The battery housing is
easily accessible -- located inside the pistol grip cap, and opened by removing
the 2 cap screws with either a screw driver or a coin. See Photo 1.

NECESSARY LOADING ACCESSORIES

These are the items you will need to successfully load and prepare your Electra

muzzleloader for firing.

• Propellant -- Blackpowder or an approved blackpowder substitute.

• Projectile -- PowerBelt™ Bullet, saboted bullet, or conical bullet.

• Powder Flask -- For carrying a supply of loose powder (not necessary with

pelletized powder).

• Powder Measure -- For measuring the correct volume of loose powder and

for transferring a single charge to the muzzle of the gun (not required with
pelletized powder).

• Bullet Starter -- To start the bullet into the muzzle of the gun.

• Speed Loader -- To carry extra pre-measured powder charges and bullets for

quick reloading.

• Range Rod -- The Range Rod is a long, heavy duty rod used for loading at the

range and for cleaning. It is easier to use than the under barrel rod, which is

essentially only intended for in-the-field reloading.

NECESSARY CLEANING ACCESSORIES

These are the items you will need to properly clean your muzzleloader, both

between shots and before storage.

• Electra Breech Plug Brush (Included) – This brush attaches to the end

of the cleaning rod and is used to clean the breech face of fouling. This

brush should be used, at a minimum, after the firing of 5 successive shots,
to remove any build up of fouling on the electrodes.

• Range Rod -- The Range Rod is a long, heavy duty rod used for loading at the

range and for cleaning. It is easier to use than the under barrel rod, which is

essentially only intended for in-the-field reloading.

• Patch/Bullet Puller (Included) -- The Patch/Bullet Puller is used to

retrieve patches that may become lodged in the barrel during the cleaning

process.

• Cleaning Jag (.50 Cal.) – This ramrod attachment holds the cleaning patch to

the cleaning rod.

• Bore Brush (.50 Cal.) – This ramrod attachment is used to loosen fouling in

the barrel prior to cleaning.

• Breech Plug Wrench (included) – This tool is used to remove the breech plug

from the gun when employing the Complete Cleaning Method. A 12mm, deep­well socket wrench can also be used for this purpose.

5

• Breech Plug Removal Assist Bar (Included) – This “leverage bar” screws

into the barrel lug on the underside of the barrel and provides greater
leverage for easy removal of the breech plug. See Photo 2.

• Allen Wrench (Included) – This wrench is for use in the removal of the

Barrel Retention Screws, allowing separation of the stock from the barrel when
employing the Complete Cleaning Method.

• Cleaning Patches – These patches are used to clean fouling from the barrel

bore. They may be standard cleaning patches or pre-saturated.

• Cleaning Solvent – Cleaning solvents allow easy removal of fouling from

the barrel. CVA Barrel Blaster™ Wonder Gel (CVA Part # AC1684) is
recommended.

• Rust Preventative – Used to coat the bore of the barrel after cleaning. CVA Barrel

Blaster™ Rust-Prevent Patches (CVA Part # AC1689) are recommended.

PROPELLANTS

All CVA Electra muzzleloaders are capable of handling a “magnum charge”
of propellant up to 150 volume equivalent grains of pelletized powder (typically

charges of loose powder exceeding 110 grains will not fully burn in the barrel).

All muzzleloader shooters are limited in their choices of propellants. Only

the following propellants should be considered as being safe for use:

• BLACKPOWDER - Blackpowder is available in several granulations (the

average size of each particle of the powder) which are rated as FG, FFG, FFFG,

and FFFFG. ONLY FFG POWDER OR ITS EQUIVALENT GRANULATION
OF BLACKPOWDER SUBSTITUTE SHOULD BE USED IN YOUR CVA
MUZZLELOADING RIFLE. The use of other granulations may result in
improper burning or higher than acceptable pressures.

• BLACKPOWDER SUBSTITUTES - Safer and cleaner burning substitutes

for blackpowder have been developed and are perfectly suitable for use in your

Electra muzzleloader. Some of the brands available at the time of this printing

are Hodgdon’s Pyrodex™ and Triple Seven™, American Pioneer Powder™,
Goex Pinnacle™, and Black Mag3™. Some of these are available in both
granular and pellet form. An important thing to remember is that individual

rifles will perform differently with the same propellant and bullet combinations.

Each of these blackpowder substitutes have their own unique performance
characteristics in the Electra. For example, some propellants that may be

the most accurate may also be the most difficult to clean. Others that are

very clean burning may be less accurate. Therefore, CVA recommends
that you try several propellants to see which one best suits your particular
needs. Factors to be considered are the likely distances of the shot, weather
conditions, convenience of cleaning, etc. Please refer to the propellant

manufacturer’s written instructions for the specific propellant you are using.

6

If you have technical questions concerning your propellant, please visit the
manufacturer’s web site or contact their Customer Service Department. Contact
info should be provided on the product label or instructions brochure.

WARNING: NEVER USE ANY AMOUNT OF MODERN SMOKELESS
POWDER IN ANY MUZZLELOADER! The use of any amount of modern

smokeless powder in a muzzleloader will create dangerously high pressures upon

ignition which may burst the barrel, possibly resulting in severe injury or death
to the shooter and/or bystanders. The use of smokeless powder will immediately
void your gun’s warranty.

PROJECTILES

• POWERBELT™ BULLETS- PowerBelt™ Bullets are conical projectiles with

a patented plastic base designed to create a perfect gas seal, and thereby trap the
pressures created by the explosion of the propellant. This provides consistent
pressures, which results in the consistent velocities necessary for excellent
accuracy. Unlike most sabots, the PowerBelt™ bullet is easy to load and leaves
no plastic residue to foul the barrel. All weights of PowerBelt™ bullets can be

used in CVA rifles. PowerBelt™ bullets are specifically recommended by CVA
for all in-line rifles. For more information visit www.PowerBeltBullets.com

• SABOTED BULLETS -- The sabot is a plastic sleeve that is utilized to hold

a smaller-than-bore diameter bullet tightly in the bore. Saboted bullets from
various manufacturers have been tested and found to deliver acceptable

accuracy in CVA muzzleloaders when used in accordance with the sabot

manufacturer’s instructions. Sabots typically leave a heavy plastic fouling in

the bore requiring cleaning of the barrel between each shot. Specific bore

solvents may also be necessary to remove the plastic fouling. An exception to

this is the CVA SlickLoad™ Sabot, which is specifically designed to eliminate
these common problems. CVA specifically recommends SlickLoad Sabots for
use in all in-line rifles. CAUTION: Do not use saboted bullets weighing more

than 350 grains in your CVA rifle.

• CONICAL BULLETS- These pure lead, pre-lubricated bullets are an

economical choice and provide acceptable accuracy as well as good “knock­down” power. These bullets tend to foul the bore with both lead and residual
lubricant. To maintain acceptable accuracy, the bore will have to be cleaned
before each shot. CAUTION: Do not use conical lead bullets weighing more

than 400 grains in your CVA rifle.

RECOMMENDED PROPELLANT CHARGES

The proper “powder charge” for any muzzleloading firearm is a load that

provides reliable ignition and consistent velocity while keeping breech pressures

7

below the maximum safe levels. It is important to remember that shooting

muzzleloaders is not an exact science. Each individual rifle may have its own

preference in propellant type, propellant charge, bullet type, and bullet weight.

The accuracy minded muzzleloader shooter must be willing to experiment to
some degree if he is to find the “perfect load” for his rifle.

It is recommended that you start shooting with 100 grains of propellant. If
using granular powder, remember that powder propellants are measured by volume
– not by actual weight. Experimentation with greater and lesser measurements

of powder volume will enable you to find the most accurate load for your Electra
rifle. The maximum recommended load is 120 grains equivalent, by volume, of

granular (loose) powder -- or 150 grains equivalency of pelletized propellant. If

you have any questions regarding these instructions, please call CVA Customer
Service immediately at 770-449-4687 or email at [e-mail].

LOADING YOUR CVA ELECTRA MUZZLELOADING RIFLE

Warning: Before attempting to load and shoot your rifle, protect your eyes and

hearing with appropriate safety equipment.

WARNING: NO MECHANICAL SAFETY SHOULD EVER BE RELIED
UPON TO TAKE THE PLACE OF SAFE GUN HANDLING!

1. Verify that your rifle is unloaded and the bore is unobstructed.

2. Swab the bore with a dry patch, rotating it aggressively clockwise and
counter-clockwise on the breech plug face to remove all oil and/or
moisture from the electrodes.

3. Turn the Main Power Switch to the “ON” position and allow the rifle to

charge. The LED Status Indicator Light behind the safety switch will glow

solid red until the unit is charged, at which time it will begin to flash. This

should take about 20 seconds.

4. With the rifle pointing in a safe direction, push the Safety Switch forward,

then pull the trigger to discharge a spark at the breech plug (you should
be able to hear the ignition of the spark in the barrel). If you don’t hear
the spark, run a patch to the breech plug face and rotate it on the face
of the plug to remove any excess oil or moisture, and then repeat the
process. Note: The Safety Switch should reset to the “SAFE” position

after each firing.

5. Pour a small amount (30 to 40 grains) of loose powder or drop one pellet
of pelletized powder into the bore of the gun and repeat this step. Then,
with the muzzle pointed in a safe direction, pull the trigger. The small
“fouling charge” should ignite, burning off any residual oil or moisture
which may be remaining on the face of the breech plug or in the barrel.
If the charge does not ignite, allow the ARC Electronic Ignition to
recharge and pull the trigger again. If there is still no ignition, dump the
propellant charge and repeat the process above, starting with step 4.

8

Electra Print File.indd 2 7/11/07 4:37:49 PM
