Catalog Number Selection
Family
XP =X86 Microsoft Windows
XPe operating system
Branding and Bezel
00 = No bezel (blind node)
10 = Standard blank front bezel with
Eaton branded product label
Display Size Display Technology OS Build
2
84 = 8.4 in
10 = 10.4 in
12 = 12.1 in
15 = 15.0 in
BOX = Blind node
(no display)
TSI = TFT (SVGA) Infrared
TXI = TFT (XVGA) Infrared
Blank = No display
J = XPe OS and License
Visual Designer Runtime
4000 tags
K = XPe OS and License
Visual Designer Runtime
64,000 tags
Features
Base Unit Variant
1
Features
Additional COMM Options
E = 1 GHz Celeron with 1 GB RAM
4 GB C drive CF and 1 GB D drive CF
F = 1.8 GHz Pentium with 2GB RAM
4 GB C drive CF and 1 GB D drive CF
0 = No additional
communication options
Performance Class
702 = XPe, metal housing,
2nd gen
XP – 702 –F0–84TSIK–10
XP Operator Interface
XP Operator Interface
XP
Operator Interface Products
XV and XP Operator Interface
5.4
5
Product Selection
Series Information
All XP models have a Microsoft Windows XP embedded operating system and are pre-licensed
with Visual Designer runtime. The standard models are licensed for 4000 tags, 5 simultaneous
communication drivers, and 1 web session. The enterprise models are licensed for 64,000 tags,
8 simultaneous communication drivers, and 1 web session. Field upgrades are available for up
to 64,000 tags, 8 drivers, and 2, 4, 8, 16, 32, 64, 128, or 256 simultaneous web sessions.
XP Operator Interface
Description Catalog Number
XP 8.4 in TFT, 1 GHz Celeron, 1 GB RAM, 4 GB C drive, 1 GB D drive, 4000 tags, 5 drivers, 1 web session XP-702-E0-84TSIJ-10
XP 10.4 in TFT, 1 GHz Celeron, 1 GB RAM, 4 GB C drive, 1 GB D drive, 4000 tags, 5 drivers, 1 web session XP-702-E0-10TSIJ-10
XP 12.1 in TFT, 1 GHz Celeron, 1 GB RAM, 4 GB C drive, 1 GB D drive, 4000 tags, 5 drivers, 1 web session XP-702-E0-12TXIJ-10
XP 15.0 in TFT, 1 GHz Celeron, 1 GB RAM, 4 GB C drive, 1 GB D drive, 4000 tags, 5 drivers, 1 web session XP-702-E0-15TXIJ-10
XP blind node (no display), 1 GHz Celeron, 1 GB RAM, 4 GB C drive, 1 GB D drive, 4000 tags, 5 drivers, 1 web session XP-702-E0-BOXJ-00
XP 8.4 in TFT, 1.8 GHz Pentium, 2 GB RAM, 4 GB C drive, 1 GB D drive, 64k tags, 8 drivers, 1 web session XP-702-F0-84TSIK-10
XP 10.4 in TFT, 1.8 GHz Pentium, 2 GB RAM, 4 GB C drive, 1 GB D drive, 64k tags, 8 drivers, 1 web session XP-702-F0-10TSIK-10
XP 12.1 in TFT, 1.8 GHz Pentium, 2 GB RAM, 4 GB C drive, 1 GB D drive, 64k tags, 8 drivers, 1 web session XP-702-F0-12TXIK-10
XP 15.0 in TFT, 1.8 GHz Pentium, 2 GB RAM, 4 GB C drive, 1 GB D drive, 64k tags, 8 drivers, 1 web session XP-702-F0-15TXIK-10
XP blind node (no display), 1.8 GHz Pentium, 2 GB RAM, 4 GB C drive, 1 GB D drive, 64k tags, 8 drivers, 1 web session XP-702-F0-BOXK-00
Notes
1
All 7xx Performance Class units have 1 x 10/100, 1 x 10/100/1000 Ethernet, 4 x USB Host V2.0, 2 x RS-232.
2
Standard software on embedded hardware.
Volume 7—Logic Control, Operator Interface and Connectivity Solutions CA08100008E—December 2012 V7-T5-37
Page 3
Operator Interface Products
5.4
Accessories
XP Operator Interface
Description Catalog Number
Hard drive, 80 GB minimum for all XP models for application or data storage HDU-A7-S XP700
Industrial grade hard drive, 80 GB minimum for all XP models for application or data storage HDU-A7-SI XP700
XP700 externally mounted fan for all XP models (included with 1.8 GHz Enterprise models) ACC-FAN-700-S
CompactFlash memory card, minimum 4 GB, with Visual Designer image for all XP models OS-FLASH-A7-V
5
XP-702 spare part kit for all XP models—1 power connector, 8 mounting brackets, 1 sealing strip ACC-TP-57-RES-1
Technical Data and Specifications
XP Operator Interface
Series XP Performance Operator Interface
Model XP-702
Screen Size 8.4 in 10.4 in 12.1 in 15.0 in Blind Node (no display)
Operating system Windows XPe Windows XPe Windows XPe Windows XPe Windows XPe
Touchscreen technology Infrared, non-reflective safety glass N/A
Display, colors Color TFT, selectable 16 million, 64k, or 256 colors VGA and DVI-D output
Pixel resolution (landscape)—
Portrait mode also available
2
Brightness (cd/m
Backlight 2 CCFL 2 CCFL 2 CCFL 4 CCFL N/A
Lifespan of backlight
(half-life)
Processor
Standard models 1 GHz Celeron M 1 GHz Celeron M 1 GHz Celeron M 1 GHz Celeron M 1 GHz Celeron M
Enterprise models 1.8 GHz Pentium M 1.8 GHz Pentium M 1.8 GHz Pentium M 1.8 GHz Pentium M 1.8 GHz Pentium M
Volatile memory
Standard models 1 GB 1 GB 1 GB 1 GB 1 GB
Enterprise models 2 GB 2 GB 2 GB 2 GB 2 GB
Non-volatile memory
Standard models
Enterprise models
Real time clock Yes Yes Yes Yes Yes
Communication ports Ethernet 1 x 10/100 and 1 x 10/100/1000; 2 x RS232; 4 x USB 2.0 Host
Slots for COMM modules 1 x PCI 32-bit 1 x PCI 32-bit 1 x PCI 32-bit 1 x PCI 32-bit 1 x PCI 32-bit
Power supply rated voltage 24 Vdc nominal (–15%/+20%) with polarity protection
Note
1
All are removable CompactFlash.
) 400 400 400 400 N/A
1
1
XV and XP Operator Interface
SVGA 800 x 600 SVGA 800 x 600 XGA 1024 x 768 XGA 1024 x 768 800 x 600 to 1920 x 1200
50,000 hrs 50,000 hrs 50,000 hrs 50,000 hrs N/A
4 GB min C drive (OS), 1 GB min D drive
4 GB min C drive (OS), 1 GB min D drive
V7-T5-38 Volume 7—Logic Control, Operator Interface and Connectivity Solutions CA08100008E—December 2012
Page 4
Operator Interface Products
XV and XP Operator Interface
XP Operator Interface, continued
Series XP Performance Operator Interface
Model XP-702
Screen Size 8.4 in 10.4 in 12.1 in 15.0 in Blind Node (no display)
Continuous current
consumption (maximum amps)
Standard models 2.0 2.0 2.1 2.1 1.4
Enterprise models 3.1 3.1 3.2 3.2 2.8
2
Starting Current Inrush (A
Ambient conditions
Operation—relative humidity,
non-condensing
Storage/transport—relative
humidity, non-condensing
Shock IEC 60068-2-27 15g for 11 ms duration
Vibration IEC 60068-2-6 IEC 60068-2-6 IEC 60068-2-6 IEC 60068-2-6 IEC 60068-2-6
5–9 Hz 3.5 mm displacement 3.5 mm displacement 3.5 mm displacement 3.5 mm displacement 3.5 mm displacement
9–60 Hz 0.15 mm displacement 0.15 mm displacement 0.15 mm displacement 0.15 mm displacement 0.15 mm displacement
60–150 Hz 1g acceleration 1g acceleration 1g acceleration 1g acceleration 1g acceleration
Agency certifications and
standards
Protection type
Front IP65, NEMA 4X (indoor) IP65, NEMA 4X (indoor) IP65, NEMA 4X (indoor) IP65, NEMA 4X (indoor) IP20, NEMA 1
Rear IP20, NEMA 1 IP20, NEMA 1 IP20, NEMA 1 IP20, NEMA 1 IP20, NEMA 1
Housing material Metal Metal Metal Metal Metal
Dimensions WxHxD (mm) 275 x 208 x 102/140 345 x 260 x 91/129 361 x 279 x 98/136 427 x 322 x 101/139 264 x 194 x 58/96
Mounting cutout WxH (mm) 261 x 194 329 x 238 344 x 262 410 x 315 N/A
Approximate weight lbs (kg) 6.4/7.3 (3.2/3.6) 8.3/9.1 (4.1/4.5) 9.5/10.3 (4.7/5.1) 12.8/13.6 (6.3/6.7) 3.9/4.7 (1.9/2.3)
Development software Visual Designer (VISUALDXP) Visual Designer (VISUALDXP) Visual Designer (VISUALDXP) Visual Designer (VISUALDXP) Visual Designer (VISUALDXP)
Ability to run third party
software
Pre-licensed tags, drivers,
web sessions
Standard models 4000 tags, 5 drivers, 1 web session
Enterprise models 64,000 tags, 8 drivers, 1 web session
Field upgradeable max tags,
drivers, web sessions
s) 2.0 2.0 2.0 2.0 2.0
0 to 50°C, 10 to 95% 0 to 50°C, 10 to 95% 0 to 50°C, 10 to 95% 0 to 50°C, 10 to 95% 0 to 50°C, 10 to 95%
–20 to 60°C, 10 to 95% –20 to 60°C, 10 to 95% –20 to 60°C, 10 to 95% –20 to 60°C, 10 to 95% –20 to 60°C, 10 to 95%
CE, UL/cUL, CSA (pending), RoHS
Yes Ye s Yes Yes Ye s
64,000 tags, 8 drivers, 1, 2, 4, 8, 16, 32, 64, 128, or 256 web sessions simultaneously
5.4
5
Volume 7—Logic Control, Operator Interface and Connectivity Solutions CA08100008E—December 2012 V7-T5-39
