Reduced Voltage Motor Starters
Solid-State Starters
1.2
Technical Data and Specifications
Soft Starters—S811
S811 Soft Starter (Partial Catalog Number)
Description
Max. current capacity 37 66 105 135
FLA range 11–37 20–66 32–105 42–135
General Information
Bypass mechanical lifespan 10M 10M 10M 10M
Insulating voltage Ui 660V 660V 660V 660V
Ramp time range 0.5–180 seconds
Resistance to vibration 3g 3g 3g 3g
Resistance to shock 15g 15g 15g 15g
Electrical Information
Operating voltage 200–600V 200–600V 200–600V 200–600V
Operating frequency 47–63 Hz 47–63 Hz 47–63 Hz 47–63 Hz
Overload setting 30–100% 30–100% 30–100% 30–100%
Trip class 5, 10, 20 and 30 5, 10, 20 and 30 5, 10, 20 and 30 5, 10, 20 and 30
Cabling Capacity (IEC 947)
Number of conductors 1111
Wire sizes 14–2 14–2 14–4/0 14–4/0
Type of connectors Box lug Box lug Box lug Box lug
Control Wiring (12-Pin)
Wire sizes in AWG 22–14 22–14 22–14 22–14
Number of conductors (stranded) 2 (or one AWG 12) 2 (or one AWG 12) 2 (or one AWG 12) 2 (or one AWG 12)
Torque requirements in lb-in 3.5 3.5 3.5 3.5
Solid, stranded or flexible max. size in mm
Control Power Requirements
Voltage range (24V ±10%) 21.6–26.4 21.6–26.4 21.6–26.4 21.6–26.4
Steady-state current amps 1.0 1.0 1.0 1.0
Inrush current amps 10 10 10 10
Ripple 1% 1% 1% 1%
Relays (1) Class A and C
Voltage AC—maximum 240 240 240 240
Voltage DC—maximum 120 120 120 120
Amps—maximum3333
Environment
Temperature—operating –30 to 50°C (no derating) consult
Temperature—storage –50 to 70°C –50 to 70°C –50 to 70°C –50 to 70°C
Altitude <2000m—consult factory
Humidity <95% noncondensing <95% noncondensing <95% noncondensing <95% noncondensing
Operating position Any Any Any Any
Pollution degree IEC947-13333
Impulse withstand voltage IEC947-4-1 6000V 6000V 6000V 6000V
S811N37 S811N66 S811R10 S811R13
(0.5–360 seconds extended ramp)
2
3.31 3.31 3.31 3.31
factory for operation >50°C
for operation >2000m
0.5–180 seconds
(0.5–360 seconds extended ramp)
–30 to 50°C (no derating) consult
factory for operation >50°C
<2000m—consult factory
for operation >2000m
0.5–180 seconds
(0.5–360 seconds extended ramp)
–30 to 50°C (no derating) consult
factory for operation >50°C
<2000m—consult factory
for operation >2000m
0.5–180 seconds
(0.5–360 seconds extended ramp)
–30 to 50°C (no derating) consult
factory for operation >50°C
<2000m—consult factory
for operation >2000m
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Reduced Voltage Motor Starters
1.2
Soft Starters—S811, continued
1
Description
1
Max. current capacity 180 240 304 360
FLA range 56–180 75–240 95–304 112–360
1
General Information
1
Bypass mechanical lifespan 10M 10M 10M 10M
Insulating voltage Ui 660V 660V 660V 660V
1
Ramp time range 0.5–180 seconds
1
Resistance to vibration 3g 3g 3g 3g
Resistance to shock 15g 15g 15g 15g
1
Electrical Information
Operating voltage 200–600V 200–600V 200–600V 200–600V
1
Operating frequency 47–63 Hz 47–63 Hz 47–63 Hz 47–63 Hz
1
Overload setting 30–100% 30–100% 30–100% 30–100%
Trip class 5, 10, 20 and 30 5, 10, 20 and 30 5, 10, 20 and 30 5, 10, 20 and 30
1
Cabling Capacity (IEC 947)
Number of conductors 1 or 2 1 or 2 1 or 2 1 or 2
1
Wire sizes 4 AWG to 500 kcmil 4 AWG to 500 kcmil 4 AWG to 500 kcmil 4 AWG to 500 kcmil
Type of connectors Add-on lug kit Add-on lug kit Add-on lug kit Add-on lug kit
1
Control Wiring (12-Pin)
1
Wire sizes in AWG 22–14 22–14 22–14 22–14
Number of conductors (stranded) 2 (or one AWG 12) 2 (or one AWG 12) 2 (or one AWG 12) 2 (or one AWG 12)
1
Torque requirements in lb-in 3.5 3.5 3.5 3.5
Solid, stranded or flexible max. size in mm
1
Control Power Requirements
1
Voltage range (24V ±10%) 21.6–26.4 21.6–26.4 21.6–26.4 21.6–26.4
Steady-state current amps 1.0 1.0 1.0 1.0
1
Inrush current amps 10 10 10 10
Ripple 1% 1% 1% 1%
1
Relays (1) Class A and C
Voltage AC—maximum 240 240 240 240
1
Voltage DC—maximum 120 120 120 120
1
Amps—maximum3333
Environment
1
Temperature—operating –30 to 50°C (no derating) consult
1
Temperature—storage –50 to 70°C –50 to 70°C –50 to 70°C –50 to 70°C
Altitude <2000m—consult factory
1
Humidity <95% noncondensing <95% noncondensing <95% noncondensing <95% noncondensing
1
Operating position Any Any Any Any
Pollution degree IEC947-13333
1
Impulse withstand voltage IEC947-4-1 6000V 6000V 6000V 6000V
1
Solid-State Starters
S811 Soft Starter (Partial Catalog Number)
S811T18 S811T24 S811T30 S811U36
(0.5–360 seconds extended ramp)
2
3.31 3.31 3.31 3.31
factory for operation >50°C
for operation >2000m
0.5–180 seconds
(0.5–360 seconds extended ramp)
–30 to 50°C (no derating) consult
factory for operation >50°C
<2000m—consult factory
for operation >2000m
0.5–180 seconds
(0.5–360 seconds extended ramp)
–30 to 50°C (no derating) consult
factory for operation >50°C
<2000m—consult factory
for operation >2000m
0.5–180 seconds
(0.5–360 seconds extended ramp)
–30 to 50°C (no derating) consult
factory for operation >50°C
<2000m—consult factory
for operation >2000m
1
1
1
1
Reduced Voltage Motor Starters
Solid-State Starters
1.2
Soft Starters—S811, continued
S811 Soft Starter (Partial Catalog Number)
Description
Max. current capacity 420 500 360 420
FLA range 131–420 156–500 112–360 131–420
General Information
Bypass mechanical lifespan 10M 10M 10M 10M
Insulating voltage Ui 660V 660V 660V 660V
Ramp time range 0.5–180 seconds
Resistance to vibration 3g 3g 3g 3g
Resistance to shock 15g 15g 15g 15g
Electrical Information
Operating voltage 200–600V 200–600V 200–600V 200–600V
Operating frequency 47–63 Hz 47–63 Hz 47–63 Hz 47–63 Hz
Overload setting 30–100% 30–100% 30–100% 30–100%
Trip class 5, 10, 20 and 30 5, 10, 20 and 30 5, 10, 20 and 30 5, 10, 20 and 30
Cabling Capacity (IEC 947)
Number of conductors 1 or 2 1 or 2 2, 4 or 6 2, 4 or 6
Wire sizes 4 AWG to 500 kcmil 4 AWG to 500 kcmil 4 AWG to 500 kcmil 4 AWG to 500 kcmil
Type of connectors Add-on lug kit Add-on lug kit Add-on lug kit Add-on lug kit
Control Wiring (12-Pin)
Wire sizes in AWG 22–14 22–14 22–14 22–14
Number of conductors (stranded) 2 (or one AWG 12) 2 (or one AWG 12) 2 (or one AWG 12) 2 (or one AWG 12)
Torque requirements in lb-in 3.5 3.5 3.5 3.5
Solid, stranded or flexible max. size in mm
Control Power Requirements
Voltage range (24V ±10%) 21.6–26.4 21.6–26.4 21.6–26.4 21.6–26.4
Steady-state current amps 1.0 1.0 1.4 1.4
Inrush current amps 10 10 10 10
Ripple 1% 1% 1% 1%
Relays (1) Class A and C
Voltage AC—maximum 240 240 240 240
Voltage DC—maximum 120 120 120 120
Amps—maximum3333
Environment
Temperature—operating –30 to 50°C (no derating) consult
Temperature—storage –50 to 70°C –50 to 70°C –50 to 70°C –50 to 70°C
Altitude <2000m—consult factory
Humidity <95% noncondensing <95% noncondensing <95% noncondensing <95% noncondensing
Operating position Any Any Any Any
Pollution degree IEC947-13333
Impulse withstand voltage IEC947-4-1 6000V 6000V 6000V 6000V
Note
1
U-Frame 500A unit does not have IEC certification.
S811U42 S811U50
(0.5–360 seconds extended ramp)
2
3.31 3.31 3.31 3.31
factory for operation >50°C
for operation >2000m
1
0.5–180 seconds
(0.5–360 seconds extended ramp)
–30 to 50°C (no derating) consult
factory for operation >50°C
<2000m—consult factory
for operation >2000m
S811V36 S811V42
0.5–180 seconds
(0.5–360 seconds extended ramp)
–30 to 50°C (no derating) consult
factory for operation >50°C
<2000m—consult factory
for operation >2000m
0.5–180 seconds
(0.5–360 seconds extended ramp)
–30 to 50°C (no derating) consult
factory for operation >50°C
<2000m—consult factory
for operation >2000m
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Reduced Voltage Motor Starters
1.2
Soft Starters—S811, continued
1
Description
1
Max. current capacity 500 650 720 850 1000
FLA range 156–500 203–650 225–720 265–580 320–1000
1
General Information
1
Bypass mechanical lifespan 10M 10M 10M 10M 10M
Insulating voltage Ui 660V 660V 660V 660V 660V
1
Ramp time range 0.5–180 seconds (0.5–360
1
Resistance to vibration3g3g3g3g3g
Resistance to shock 15g 15g 15g 15g 15g
1
Electrical Information
Operating voltage 200–600V 200–600V 200–600V 200–600V 200–600V
1
Operating frequency 47–63 Hz 47–63 Hz 47–63 Hz 47–63 Hz 47–63 Hz
Overload setting 30–100% 30–100% 30–100% 30–100% 30–100%
1
Trip class 5, 10, 20 and 30 5, 10, 20 and 30 5, 10, 20 and 30 5, 10, 20 and 30 5, 10, 20 and 30
1
Cabling Capacity (IEC 947)
Number of conductors 2, 4 or 6 2, 4 or 6 2, 4 or 6 2, 4 or 6 2, 4 or 6
1
Wire sizes 2/0 to 500 kcmil 2/0 to 500 kcmil 2/0 to 500 kcmil 2/0 to 500 kcmil 2/0 to 500 kcmil
Type of connectors Add-on lug kit Add-on lug kit Add-on lug kit Add-on lug kit Add-on lug kit
1
Control Wiring (12-Pin)
Wire sizes in AWG 22–14 22–14 22–14 22–14 22–14
1
Number of conductors (stranded) 2 (or one AWG 12) 2 (or one AWG 12) 2 (or one AWG 12) 2 (or one AWG 12) 2 (or one AWG 12)
1
Torque requirements in lb-in 3.5 3.5 3.5 3.5 3.5
Solid, stranded or flexible max. size in mm
1
Control Power Requirements
Voltage range (24V ±10%) 21.6–26.4 21.6–26.4 21.6–26.4 21.6–26.4 21.6–26.4
1
Steady-state current amps 1.4 1.4 1.4 1.4 1.4
Inrush current amps 10 10 10 10 10
1
Ripple 1% 1% 1% 1% 1%
1
Relays (1) Class A and C
Voltage AC—maximum 240 240 240 240 240
1
Voltage DC—maximum 120 120 120 120 120
Amps—maximum33333
1
Environment
Temperature—operating –30 to 50°C (no derating)
1
1
Temperature—storage –50 to 70°C –50 to 70°C –50 to 70°C –50 to 70°C –50 to 70°C
Altitude <2000m—consult factory
1
Humidity <95% noncondensing <95% noncondensing <95% noncondensing <95% noncondensing <95% noncondensing
1
Operating position Any Any Any Any Any
Pollution degree IEC947-133333
1
Impulse withstand voltage IEC947-4-1 6000V 6000V 6000V 6000V 6000V
1
Note
1
1
UR recognized product.
Solid-State Starters
S811 Soft Starter (Partial Catalog Number)
S811V50 S811V65 S811V72 S811V85 S811V10
seconds extended ramp)
2
3.31 3.31 3.31 3.31 3.31
consult factory for
operation >50°C
for operation >2000m
0.5–180 seconds (0.5–360
seconds extended ramp)
–30 to 50°C (no derating)
consult factory for
operation >50°C
<2000m—consult factory
for operation >2000m
0.5–180 seconds (0.5–360
seconds extended ramp)
–30 to 50°C (no derating)
consult factory for
operation >50°C
<2000m—consult factory
for operation >2000m
0.5–180 seconds (0.5–360
seconds extended ramp)
–30 to 50°C (no derating)
consult factory for
operation >50°C
<2000m—consult factory
for operation >2000m
0.5–180 seconds (0.5–360
seconds extended ramp)
–30 to 50°C (no derating)
consult factory for
operation >50°C
<2000m—consult factory
for operation >2000m
1
1
1
1
