Cutler Hammer, Div of Eaton Corp Global Proximity Catalog Page
Inductive Proximity Sensors
1
Global Proximity
PG.05D.03.T.E
December 2008
Global
Inductive Proximity Sensors
Contents
Overview . . . . . . . . . . . . . . . . . . . . . 1
Model Selection, Sensors . . . . . . . . 2
Model Selection, Compatible
Connector Cables . . . . . . . . . . . . . 4
Model Selection, Accessories . . . . . 4
Wiring Diagrams . . . . . . . . . . . . . . . 5
Specifications . . . . . . . . . . . . . . . . . 5
Dimensions . . . . . . . . . . . . . . . . . . . 6
The Cutler-Hammer
ity Sensor Family was created by
Eaton’s electrical business with the
high volume OEM in mind. It has
been optimized to include only those
functions necessary for basic,
reliable sensing. Why pay for extra
features when you don’t need them?
That’s not to say these sensors lack
the performance or features you
expect. Our DC units are short circuit
protected and will sense up to 2,000
operations per second. Plus, all sensors include a bright LED indicator to
show output status.
There’s no need to design your
machine around these sensors. The
Global family includes models in a
variety of diameters so they will fit
right where you need them. Select
models from 8 mm diameter all the
way up to 30 mm, for just the size or
sensing range that you require. Need
something smaller? Our standard
line includes inductive proximity
sensors as small as 4 mm in
diameter.
The Global Proximity is available in
AC or DC, 2-wire or 3-wire, and NPN
or PNP. You can even choose between
cable wiring or quick-disconnect
connectors. For power handling,
our DC units feature a 100 mA load
current rating and AC units are rated
up to 200 mA.
®
Global Proxim-
Cost-Effective Inductive Proximity Sensing for
High Volume Use
Industry-Standard
Housing Diameters
8 mm
12 mm
18 mm
Choose from
Unshielded or
Shielded Versions
LED Output Indicator
on All Sensors
30 mm
Product Features
The Global Proximity Line features solid performance and a basic feature
■
set for reliable, cost-effective sensing
■
Available in a variety of sizes to fit in all of your applications: 8 mm, 12 mm,
18 mm and 30 mm diameters
■
DC sensors operate on 10 – 30V DC in 2-wire and 3-wire (NPN or PNP)
configurations
AC sensors operate on 20 – 250V AC in 2-wire configuration
■
■
Switching frequency of 2 kHz for DC models
■
Shielded and unshielded versions available
Terminations include 2-meter cable, micro-connector and nano-connector
■
■
DC units include short circuit protection
All Models
Available with
Quick-Disconnect
Connector or
2-Meter Cable
Approvals
(DC models only)
cCSAus
Unless otherwise noted, the
products contained in this
document are not designed
or intended for use in human
safety applications.
For Customer Service in the U.S. call 1-877-ETN CARE (386-2273) ,
For more information visit: www.eaton.com
in Canada call 1-800-268-3578 .
For Application Assistance in the U.S. and Canada
call 1-800-426-9184 .
PG.05D.03.T.E
Inductive Proximity Sensors
Global Proximity
December 2008
Model Selection — Global Proximity Sensors
Operating
2-Wire Sensors
12 mm Diameter 20 – 250V AC 2 mm Shielded N.O. 2-meter Cable
18 mm Diameter 20 – 250V AC 5 mm Shielded N.O. 2-meter Cable
30 mm Diameter 20 – 250V AC 10 mm Shielded N.O. 2-meter Cable
3-Wire Sensors
8 mm Diameter 10 – 30V DC 1 mm Shielded N.O. (NPN) 2-meter Cable
See listing of compatible connector cables on Page 4 .
Fast turn product with typical one business day lead-time to shipment.
Stocked product, typical order quantities guaranteed in stock.
Voltage
10 – 30V DC 2 mm Shielded N.O.
10 – 30V DC 5 mm Shielded N.O.
10 – 30V DC 10 mm Shielded N.O.
Sensing
Range
4 mm Unshielded N.O. 2-meter Cable
4 mm Unshielded N.O.
8 mm
(Extended
Range)
8 mm Unshielded N.O. 2-meter Cable
16 mm 3-pin Micro AC Connector
8 mm Unshielded N.O.
16 mm
(Extended
Range)
15 mm Unshielded N.O. 2-meter Cable
15 mm Unshielded N.O.
25 mm
(Extended
Range)
3 mm
(Extended
Range)
2 mm Unshielded N.O. (NPN) 2-meter Cable
6 mm
(Extended
Range)
Shielding Output Type Connection Type Catalog Number
3-pin Micro AC Connector
3-pin Micro AC Connector
(NPN/PNP)
(NPN/PNP)
N.C. 2-meter Cable
N.O.
(NPN/PNP)
N.C.
(NPN/PNP)
(NPN/PNP)
(NPN/PNP)
N.O.
(NPN/PNP)
N.C.
(NPN/PNP)
(NPN/PNP)
(NPN/PNP)
N.O.
(NPN/PNP)
N.C.
(NPN/PNP)
N.O. (PNP) 2-meter Cable
N.O. (NPN) 2-meter Cable
N.C. (NPN) 2-meter Cable
N.O. (PNP) 2-meter Cable
N.O. (PNP) 2-meter Cable
N.O. (NPN) 2-meter Cable
N.O. (PNP) 2-meter Cable
2-meter Cable
4-pin Micro DC Connector
2-meter Cable
4-pin Micro DC Connector
2-meter Cable
4-pin Micro DC Connector
2-meter Cable
4-pin Micro DC Connector
3-pin Micro AC Connector
3-pin Micro AC Connector
2-meter Cable
4-pin Micro DC Connector
2-meter Cable
4-pin Micro DC Connector
2-meter Cable
4-pin Micro DC Connector
2-meter Cable
4-pin Micro DC Connector
3-pin Micro AC Connector
3-pin Micro AC Connector
2-meter Cable
4-pin Micro DC Connector
2-meter Cable
4-pin Micro DC Connector
2-meter Cable
4-pin Micro DC Connector
2-meter Cable
4-pin Micro DC Connector
3-pin Nano-Connector
4-pin Micro DC Connector
3-pin Nano-Connector
4-pin Micro DC Connector
3-pin Nano-Connector
4-pin Micro DC Connector
3-pin Nano-Connector
4-pin Micro DC Connector
3-pin Nano-Connector
4-pin Micro DC Connector
3-pin Nano-Connector
4-pin Micro DC Connector
4-pin Micro DC Connector
4-pin Micro DC Connector
2
E57-12GS02-A
E57-12GS02-AAB
E57-12GU04-A
E57-12GU04-AAB
E57-12GS02-D
E57-12GS02-DDB
E57-12GU04-D
E57-12GU04-DDB
E57-12GU04-D1
E57-12GE08-D
E57-12GE08-DDB
E57-12GE08-D1
E57-12GE08-D1DB
E57-18GS05-A
E57-18GS05-AAB
E57-18GU08-A
E57-18GU08-AAB
E57-18GE16-AAB
E57-18GS05-D
E57-18GS05-DDB
E57-18GU08-D
E57-18GU08-DDB
E57-18GE16-D
E57-18GE16-DDB
E57-18GE16-D1
E57-18GE16-D1DB
E57-30GS10-A
E57-30GS10-AAB
E57-30GU15-A
E57-30GU15-AAB
E57-30GS10-D
E57-30GS10-DDB
E57-30GU15-D
E57-30GU15-DDB
E57-30GE25-D
E57-30GE25-DDB
E57-30GE25-D1
E57-30GE25-D1DB
E57-08GS01-C
E57-08GS01-CNB
E57-08GS01-CDB
E57-08GS01-G
E57-08GS01-GNB
E57-08GS01-GDB
E57-08GE03-C
E57-08GE03-CNB
E57-08GE03-CDB
E57-08GBE03-C
E57-08GE03-G
E57-08GE03-GNB
E57-08GE03-GDB
E57-08GU02-C
E57-08GU02-CNB
E57-08GU02-CDB
E57-08GU02-G
E57-08GU02-GNB
E57-08GU02-GDB
E57-08GE06-C
E57-08GE06-CDB
E57-08GE06-G
E57-08GE06-GDB
PG.05D.03.T.E For more information visit:
www.eaton.com
Inductive Proximity Sensors
3
Global Proximity
Model Selection — Global Proximity Sensors (Continued)
Operating
Voltage
3-Wire Sensors
12 mm Diameter 10 – 30V DC 2 mm Shielded N.O. (NPN) 2-meter Cable
18 mm Diameter 10 – 30V DC 5 mm Shielded N.O. (NPN) 2-meter Cable
30 mm Diameter 10 – 30V DC 10 mm Shielded N.O. (NPN) 2-meter Cable
See listing of compatible connector cables on Page 4 .
Stocked product, typical order quantities guaranteed in stock.
(Continued)
Sensing
Range
5 mm
(Extended
Range)
4 mm Unshielded N.O. (NPN) 2-meter Cable
10 mm
(Extended
Range)
8 mm
(Extended
Range)
8 mm Unshielded N.O. (NPN) 2-meter Cable
18 mm
(Extended
Range)
15 mm
(Extended
Range)
15 mm Unshielded N.O. (NPN) 2-meter Cable
29 mm
(Extended
Range)
Shielding Output Type Connection Type Catalog Number
4-pin Micro DC Connector
N.O. (PNP) 2-meter Cable
4-pin Micro DC Connector
N.O. (NPN) 2-meter Cable
4-pin Micro DC Connector
N.O. (PNP) 2-meter Cable
4-pin Micro DC Connector
4-pin Micro DC Connector
N.O. (PNP) 2-meter Cable
4-pin Micro DC Connector
N.O. (NPN) 2-meter Cable
4-pin Micro DC Connector
N.O. (PNP) 2-meter Cable
4-pin Micro DC Connector
4-pin Micro DC Connector
N.O. (PNP) 2-meter Cable
4-pin Micro DC Connector
N.O. (NPN) 2-meter Cable
4-pin Micro DC Connector
N.O. (PNP) 2-meter Cable
4-pin Micro DC Connector
4-pin Micro DC Connector
N.O. (PNP) 2-meter Cable
4-pin Micro DC Connector
N.O. (NPN) 2-meter Cable
4-pin Micro DC Connector
N.O. (PNP) 2-meter Cable
4-pin Micro DC Connector
4-pin Micro DC Connector
N.O. (PNP) 2-meter Cable
5-meter Cable
4-pin Micro DC Connector
N.O. (NPN) 2-meter Cable
4-pin Micro DC Connector
N.O. (PNP) 2-meter Cable
4-pin Micro DC Connector
4-pin Micro DC Connector
N.O. (PNP) 2-meter Cable
4-pin Micro DC Connector
N.O. (NPN) 2-meter Cable
4-pin Micro DC Connector
N.O. (PNP) 2-meter Cable
4-pin Micro DC Connector
December 2008
E57-12GS02-C
E57-12GS02-CDB
E57-12GS02-G
E57-12GS02-GDB
E57-12GE05-C
E57-12GE05-CDB
E57-12GE05-G
E57-12GE05-GDB
E57-12GU04-C
E57-12GU04-CDB
E57-12GU04-G
E57-12GU04-GDB
E57-12GE10-C
E57-12GE10-CDB
E57-12GE10-G
E57-12GE10-GDB
E57-18GS05-C
E57-18GS05-CDB
E57-18GS05-G
E57-18GS05-GDB
E57-18GE08-C
E57-18GE08-CDB
E57-18GE08-G
E57-18GE08-GDB
E57-18GU08-C
E57-18GU08-CDB
E57-18GU08-G
E57-18GU08-GDB
E57-18GE18-C
E57-18GE18-CDB
E57-18GE18-G
E57-18GE18-GDB
E57-30GS10-C
E57-30GS10-CDB
E57-30GS10-G
E57-30GS10-G5
E57-30GS10-GDB
E57-30GE15-C
E57-30GE15-CDB
E57-30GE15-G
E57-30GE15-GDB
E57-30GU15-C
E57-30GU15-CDB
E57-30GU15-G
E57-30GU15-GDB
E57-30GE29-C
E57-30GE29-CDB
E57-30GE29-G
E57-30GE29-GDB
For more information visit: www.eaton.com
PG.05D.03.T.E
